User Manual R1.0
ESSAN-10 Pocket CO2 Meter
Distribu
ted & Supported By:
Edaphic Scientific Pty Ltd
www.edaphic.com.au
info@edaphic.com.au
Ph: 1300 430 928
2
Contents
INTRODUCTION ............................................................................................................................. 3
FEATURES ................................................................................................................................................... 3
MONITOR ...................................................................................................................................... 3
LCD DISPLAY .............................................................................................................................................. 4
OPERATION ..........................................................................................................................................4
MENU/CONFIGURATION ........................................................................................................................... 5
Calibration ................................................................................................................................6
Alarm Threshold ....................................................................................................................... 6
MAN DOWN FEATURE ................................................................................................................. 7
MAINTENANCE.............................................................................................................................. 7
SPECIFICATIONS ............................................................................................................................ 8
TROUBLESHOOTING ..................................................................................................................... 9
WARRANTY ................................................................................................................................... 9
CONTACT US .................................................................................................................................. 9
3
INTRODUCTION
Congratulations on your purchase of the ESSAN-10 Pocket CO2 Personal Safety Monitor. The
ESSAN-10 is a smart carbon dioxide (CO2) monitor using NDIR technology to provide long
term stability. The ESSAN-10 Personal Safety CO2 Monitor is designed for employees who
work in enclosed areas where carbon dioxide buildup may cause personal harm. It is
designed to alert people in the area with excessive carbon dioxide gas. ESSAN-10 is shipped
fully tested and calibrated and, with proper use, will provide years of reliable service.
FEATURES
• Audible, visual strobe and vibrating alarms
• Large LCD display
• Man down alarm – leveraging accelerometer technology
• Rugged design with protective rubber enclosure
• Heavy duty metal clip
• Front facing sensor unit
• Rechargeable Li-ion Battery 4.2v, 1500mAh – 18+ hours per charge
• Black Micro USB cable and Wall USB charger
• Dual calibration methods: Ambient Air (300-600ppm) and Nitrogen
(0-200ppm)
• Automatic atmospheric pressure compensation for CO2 concentrations
• No over-exposure or negative memory effects
• IP54 housing
• Stable NDIR sensor for CO2 detection
MONITOR
1. Visual alarm/strobe
2. Front facing sensor
3. Charging indicator
4. LCD display
5. Power button
6. Temperature unit button
7. USB charging inlet (bottom side)
8. Heavy duty metal clip
9. Factory reset button
4
LCD DISPLAY
1. Low alarm indicator
2. High alarm indicator
3. Battery indicator
4. CO2 concentration
5. CO2 concentration units (ppm or % when >9,999 ppm)
6. Calibration icon
7. Man down alarm
8. Air Temperature
9. Temperature unit (Fahrenheit or centigrade degrees)
10. % Relative Humidity
OPERATION
Note:
LCD backlight will turn off automatically after 5 seconds of inactivity.
➢ When LCD backlight is off, press either button to turn on the backlight. It will notturn
the monitor off or change the °C/°F setting.
1. Power button
1.1 When the Monitor is turned off, press to turn on the unit.
1.2 When the Monitor is turned on, press for 3 seconds to turn off the unit.
When the unit is first turned on, it performs 5 seconds countdown for Monitor warm up, then
enters normal display with current CO2, temperature, and humidity readings displayed. The
monitor starts taking measurements when power on and updates readings every 2 seconds.
The device can’t shut off alarm, if power off will come back in alarm mode and must delay.
2. Temperature Units Button
2.1 Temperature Unit
Press shortly to switch two temperature units: °F and °C.
5
2.2 Menu and Configuration Settings
Menu Items
Functional Description
AIR
“AIR” means Ambient Air Calibration. User presses the
power button to implement Ambient Air
Calibration (300~600ppm).
N2
“N2” means Nitrogen Calibration. User presses the power
button to implement Nitrogen
Calibration (0~200ppm).
H0.5/H0.5T/H1.0/
H1.5/H3.0
Current Defaults are L.0.5 H1.0
High Alarm Threshold setup.
User presses the power button to switch the high alarm
threshold: H0.5 (5000 ppm), H0.5A (5000 ppm), H1.0 (10000
ppm), H1.5 (15000
ppm), and H3.0 (30000 ppm).
L0.5/L0.5A/L1.0/L1.5/L3.0
Low Alarm Threshold setup. User presses the power button
to switch the low alarm threshold: L0.5 (5000 ppm), L0.5T (5000
ppm TWA), L1.0 (10000 ppm), L1.5 (15000 ppm),
and L3.0 (30000 ppm).
A ON/ AOFF
Setting Man down alarm function on/off. User presses the
power button to switch “A ON” (allowing Man down
alarm) or “AOFF”
(prohibiting Man down alarm).
E
User presses the temperature
button to exit the menu
status.
By pressing the temperature button for 13 seconds, the unit enters in to Menu status. There
are six menu items by pressing the temperature button shortly to loop switching between
AIR, N2, LX.X, HX.X, A ON/AOFF and E (exit).
The menu items are described in the following table.
6
3. Calibration
There are two calibration methods: Ambient Air (300-600ppm) and Nitrogen (0-200ppm).
By pressing the temperature unit button for 5 seconds, the monitor will enter CO2 calibration
mode. While in calibration mode, press the temperature button quickly to switch between
AIR (Ambient Air Calibration) or N2 (Nitrogen Calibration). Press the power
button to confirm.
Zero calibration requires 100% nitrogen (0% CO2) calibration gas, a flow regulator and flexible
tubing.
The Atmospheric calibration will not require additional materials but must be performed in
outdoor (300-600ppm fresh air) during the entire procedure.
See Section 2.2 Menu and Configuration Settings, to change settings.
4. Alarm Threshold
There are default thresholds: 5,000 ppm CO2 (low alarm) and 1% CO2 (Short Term Exposure Limit)
(high alarm). The alarm thresholds can be changed dependent on the user, to L0.5 (5000 ppm),
L0.5T (5000 ppm TWA), L1.0 (10000 ppm), L1.5 (15000 ppm), or L3.0 (30000 ppm).
If the measured CO2 value exceeds the define Low Alarm threshold, the alarm LED will flash red
at 2Hz and the audio alarm “de de … de de …” will sound. If the CO2 level exceeds the
High Alarm threshold, the LED will flash faster and the audio alarm will increase. To alert
users in a noisy environment, the monitor will also vibrate.
See Section 2.2 Menu and Configuration Settings, to change settings.
5. Automatic Atmospheric Pressure Compensation
The displayed CO2 level is affected by atmospheric pressure or change in altitude. To insure
maximum accuracy, this monitor has automatic atmospheric pressure compensation for CO2
concentrations by means of a digital atmospheric pressure sensor integrated in the unit. No
calculations or maintenance is required.
See Section 2.2 Menu and Configuration Settings, to change settings.
7
6. Man down alarm
Falling by breathing dangerous gases can cause serious injury and even fatality to workers. If the
Man down alarm function in ESSAN-10 is set on, ESSAN-10 can detect falls and send a man
down alert which will activate the audible and visual alarms and alert other people in the area.
The man-down detection uses a three-axis accelerometer to automatically monitor the user’s
movements. If a sudden fall/impact is followed by a lack of movement for 6 seconds, the
alarm will sound. Turn off the alarm by pressing either of the two buttons.
See Section 2.2 Menu and Configuration Settings, to change settings.
7. Reset Button
Users can reset the unit by pushing a reset button through a
hole on back of shell.
MAINTENANCE
Calibration
The ESSAN-10 comes pre-calibrated from the factory. However, the CO2 sensor should be
calibrated at least once a year, or as described in your company’s safety procedures. You can
perform the calibration yourself, or you can return it to us for factory calibration at a nominal
fee.
The temperature and humidity sensors do not require calibration and should remain accurate for
the life of your unit.
Cleaning and Storage
The front cover and case can be cleaned with a mild solution of detergent and water.
Apply sparingly with a soft cloth and allow to dry completely before using. Do not use
aromatic hydrocarbons or chlorinated solvents for cleaning.
8
SPECIFICATIONS
Operating Environment
32~122°F (0~50°C), <95% RH non-condensing
Storage
14~140°F (-10~60°C), <99% RH non-condensing
Power Supply
Li-ion battery (4.2V, 1500mAh), Micro USB cable w. Wall USB charger
Dimensions
3.9 x 2.0 x 1.7 in. (98x50x42mm)
Weight
4.76 oz. (135 grams)
CO2 Sensor
Single-beam NDIR diffusion sampling
Measurement Range
5% Vol (0~50,000ppm) display
Display Resolution
1ppm / 0.01%
Accuracy
±200ppm or ±10% of reading
Repeatability
±20ppm @ 400ppm
Temperature
Dependence
Typ. ±0.3% of reading per °C or ±4ppm per °C, whichever is
greater, referenced to 25 °C
Pressure Dependence
0.13% of reading per mmHg
Response Time
About 2 min for 90% of step change
Warm-up Time
< 5 seconds at 22°F
IAQ LED Display
Green: <800ppm • Yellow: 800~1200ppm • Red: >1200ppm
Measurement interval
2 seconds
Temperature Range
50~140°F (10~60°C) display
Display Resolution
0.1°F (0.1°C)
Display Options
°F/°C switchable
Accuracy
±0.9°F (±0.5°C)
Response Time
5~30 seconds (device must equilibrate with environment)
Measurement Range
0~99.9%RH
Display Resolution
1%RH
Accuracy
±4.5%RH
Response Time
<8 seconds for 63% of step change
Device Specifications
CO2 Sensor Specifications
Temperature Sensor Specifications
Relative Humidity Sensor Specifications
Out of range of operating conditions will impact the accuracy of the CO2 measurement. A warning
will display when humidity or temperature is above the rated thresholds (>95% RH condensing, >
122°F or < 32°F).
9
TROUBLESHOOTING
Cannot power on
Press the Power Button for more than 0.5 seconds.
Check that the Li-ion battery is charged.
If monitor is charged but will not turn on, contact support.
Slow response
Power cycle → Verify Unit
Readings do not
change
Confirm the monitor has sufficient charge.
WARRANTY
The monitor comes with a one (1) year warranty starting from the date the monitor was shipped
to the buyer.
CONTACT US
Distributed & Supported By:
Edaphic Scientific Pty Ltd
www.e
info@edaphic.com.au
daphic.com.au
Ph: 1300 430 928
