ECTACO
Professional Talking Electronic Dictionary & eBook
Partner® C-4ER
EnglishRussian
USER MANUAL
ECTACO® Partner® C-4ER
Англо-русский и русско-английский
профессиональный говорящий электронный
словарь и электронная книга
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
ECTACO® Partner® C-4ER User Manual
Ectaco, Inc. assumes no responsibility for any damage or loss resulting from the
use of this manual.
Ectaco, Inc. assumes no responsibility for any loss or claims by third parties,
which may arise through the use of this product.
Ectaco, Inc. assumes no responsibility for any damage or loss caused by deletion
of data as a result of malfunction, repairs, or battery replacement. Be sure to
back up all important data on other media to avoid data loss.
The contents of this manual are subject to change without notice.
No part of this manual shall be reproduced, stored in a retrieval system, or
transmitted by any means, electronic, mechanical, photocopying, recording, or
otherwise, without permission from Ectaco, Inc.
®
is a registered trademark of ECTACO, Inc., NY, USA.
Partner
© 1990–2008 ECTACO, Inc., New York, USA.
All rights reserved.
ECTACO, Inc. не несет ответственности за любой ущерб, возникший
вследствие неправильного использования данного руководства.
ECTACO, Inc. не несет ответственности по рекламациям третьей стороны, а
также за любой ущерб, возникший в процессе эксплуатации устройства.
ECTACO, Inc. не несет ответственности за любой ущерб от потери или
повреждения данных вследствие неправильного функционирования,
ремонта, замены батареек. Всегда храните резервную копию важных
данных на других носителях.
Производитель оставляет за собой право внесения изменений в данное
руководство.
Никакая часть данного руководства не может быть скопирована или
воспроизведена электронным, механическим или иным способом без
согласия ECTACO, Inc.
®
является зарегистрированной торговой маркой компании ECTACO,
Partner
Inc., США, Нью-Йорк.
© 1990–2008 ECTACO, Inc., США, Нью-Йорк.
Все права защищены.
ECTACO® Partner® C-4ER User Manual
CONTENTS
INTRODUCTION..................................................................................... 5
General View ........................................................................................ 6
Power Supply........................................................................................ 6
SD card................................................................................................. 7
Initialization ........................................................................................... 7
Keyboard .............................................................................................. 7
Display .................................................................................................. 9
Main Menu .......................................................................................... 10
Context Menu ..................................................................................... 10
DICTIONARIES..................................................................................... 11
EnglishRussian Dictionary ............................................................. 11
PhraseBook ........................................................................................ 17
Popular Idioms.................................................................................... 18
Irregular Verbs .................................................................................... 19
EXERCISES.......................................................................................... 19
FlashCards ......................................................................................... 19
Hangman Word Game........................................................................ 21
SAT 200.............................................................................................. 22
SAT 5000............................................................................................ 22
English Grammar Guide ..................................................................... 23
Calculator............................................................................................ 23
Metric Conversion............................................................................... 23
Currency Conversion .......................................................................... 24
USA Interview ..................................................................................... 24
World Time ......................................................................................... 25
SETUP .................................................................................................. 26
Set language....................................................................................... 26
Set font size ........................................................................................ 26
3
ECTACO® Partner® C-4ER User Manual
Speech settings .................................................................................. 27
Slang lock ........................................................................................... 27
Time settings ...................................................................................... 27
System settings .................................................................................. 28
4
ECTACO® Partner® C-4ER User Manual
INTRODUCTION
Congratulations on purchasing ECTACO® Partner® C-4ER! This product is the
result of the combined efforts of Ectaco's linguists, engineers, and programmers,
and represents the last generation of the highest-performance integrated
linguistic systems available.
®
ECTACO
1,000,000-word EnglishRussian dictionary database including specialized
vocabulary: business – 25,000 words, finance – 57,000 words, law – 69,000
words, medicine – 34,000 words, oil and gas – 43,000 words, information
technologies and telecommunications – 24,000 words
Crystal-clear output of native-speaker voice narration for over 14,000 useful
phrases for daily communication
WordNet vocabulary – 70,000 words with definitions
Unlimited voice function in English and Russian
Instant reverse translation
Russian Standard and Phonetic keyboard layouts
Look-up function
Vector Ultima™ spell-checking system
Phonetic transcription
English irregular verbs
Over 200 popular American idioms
SAT 200 and SAT 5000 vocabularies
Hangman word game
FlashCards game
Metric and currency converters
World time
English Grammar guide
USA interview
Calculator
Slang lock
Partner® C-4ER features:
5
ECTACO® Partner® C-4ER User Manual
Three font sizes
Bilingual interface
AC/DC adapter jack
Headphone jack
SD slot
As continuous efforts are being made by the manufacturer to ensure the best
quality and performance of the ECTACO Partner
characteristics of the device you have purchased may slightly differ from their
description in this manual.
®
products, some
General View
The general view and external features of ECTACO® Partner® C-4ER are shown
below.
Power Supply
ECTACO® Partner® C-4ER is powered by a special Li-Polymer rechargeable
battery.
The battery is not user-replaceable.
When the battery becomes weak, the battery life picture is shown as
case, the voice function will be disabled in order to prevent excessive discharge
6
. In that
ECTACO® Partner® C-4ER User Manual
of the battery and a resulting loss of data in RAM. To restore full functionality of
the device, recharge the battery as soon as possible.
How to Recharge the Battery
ECTACO® Partner® C-4ER is equipped with a jack for external power supply.
Only a special charger may be used with your ECTACO
Use of an inappropriate external power supply may cause failure of the
device and will void the warranty. The AC/DC adapter should provide 5V
and min 250mA DC.
• Connect the AC/DC adapter to your device via the AC/DC adapter jack (see
General View). The battery charging process will start.
®
Partner® C-4ER.
SD card
Before you start using your ECTACO® Partner® C-4ER, please make sure the SD
card (included in the standard package) is installed into the SD slot of the device.
If the card is not installed, slide it into the slot located on the lower edge of the
device – the contacts of the card face up (if the device is unfolded), label face
down. Push the card gently until it clicks into place. To eject the card, just push it
in slightly.
Initialization
The initialization routine is started:
when ECTACO
after the system has been reset with the Reset button.
The Reset button is located on the left-hand side of the keyboard (over the
SHIFT key). It can be accessed with any thin object like a paper clip. Never
use a needle or pin for this purpose since it can damage the device.
• If you see the Initialize system? (y/n) message, press the N key to abort
initialization and customization.
The System initialized! message indicates that system initialization has been
completed and the factory defined default settings have been restored.
®
Partner® C-4ER is turned on for the first time;
Keyboard
The standard American QWERTY keyboard is combined with Russian layout.
• Enter the desired symbol from the keyboard by pressing the corresponding
key.
7
ECTACO® Partner® C-4ER User Manual
ECTACO® Partner® C-4ER has standard and phonetic modes of entering
Russian letters. Russian standard mode allows you to enter Russian letters
corresponding to the keyboard marks. Russian phonetic mode allows you to
enter Russian letters by their phonetic consonance with English letters, e.g. you
can press the F key to enter the Russian letter "Ф".
The table below shows the Russian and English layouts in the Russian phonetic
1
.
mode
q я w
ш/щ e е/э r р t т
a а s с d д f
ф g г/ж h х
z
Unlike PC keyboards, there is no need to keep a key (such as SHIFT) down
while pressing another one. It is enough to press it only once and release.
The available set of national characters is dependent on the selected keyboard
layout.
Function shortcut keys
ON/OFF Turn the device on or off
Reset Re-initialize system
SHIFT+
SHIFT+ Switch to the preceding entry shown in the title bar on the
SHIFT+ Switch to the subsequent entry shown in the title bar on the
з
x
ь/ъ c ц/ч v в
Activate the Context Menu
Pronounce a highlighted item
Pronounce translation
left-hand display (available in the Dictionary, Popular
Idioms, Irregular Verbs, SAT 200 and SAT 5000
applications)
right-hand display (available in the Dictionary, Popular
Idioms, Irregular Verbs, SAT 200 and SAT 5000
applications)
y ы u
у/ю i и o о p п
j
й k к
b б n н m м
l
л
1
Press ALT to enter letters shown after the slash (/) in the table.
8
ECTACO® Partner® C-4ER User Manual
SHIFT+ Page Up
SHIFT+ Page Down
Other shortcut keys open sections or applications corresponding to the marks on
the keys (press SHIFT+ shortcut key; for example, SHIFT+DICT).
Control and edit keys
SHIFT+ Enter space
Enter Execute
ESC Cancel / return to the previous page / switch to Main Menu
ALT Enter the Russian letters Х, Э, Ж, Б, Ю, Ъ (press the
SHIFT Type in uppercase
BS Delete character to the left of the cursor
Move cursor / move highlight up / switch Main Menu / scroll
text
Move cursor / move highlight down / switch Main Menu /
enter space (when the cursor is at the end of line) / scroll
text
Scroll up / switch Main Menu / change values
Scroll down / switch Main Menu / change values
corresponding key + ALT). To enter such letters in caps,
press SHIFT + the corresponding key + ALT.
Switch translation direction
Display
ECTACO® Partner® C-4ER features two high-resolution screens (255x160 pixels
each).
The indicator lines are at the top and at the bottom of the display and show the
following indicators:
SHIFT SHIFT key pressed
INS Insert mode selected
OVR Overtype mode selected
Battery life indicator
9
