ECS P43T-A2 User Manual
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
the author.
Version 2.0
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof and
specifically disclaims any implied warranties of merchantability or fitness for any
particular purpose. The manufacturer reserves the right to revise this publication and
to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective
owners and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by the system’s
manufacturer could void the user’s authority to operate the equipment.
Preface
ii
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the
following conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that may cause undesired operation
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interferencecausing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur
le matériel brouilieur du Canada.
About the Manual
The manual consists of the following:
Chapter 1
Introducing the Motherboard
Chapter 2
Installing the Motherboard
Chapter 3
Using BIOS
Chapter 4
Using the Motherboard Software
Chapter 5
Setting Up eJIFFY
Chapter 6
Trouble Shooting
Preface
Describes features of the
motherboard.
Go to
Describes installation of
motherboard components.
Go to
Provides information on us-
ing the BIOS Setup Utility.
Go to
Describes the motherboard
software
Go to
Describes the eJIFFY
setting up
Go to
Provides ba sic trouble shoot ing tips
Go to
H
H
H
H
H
H
page 1
page 7
page 25
page 41
page 45
page 55
TT
ABLE OF CONTENTSABLE OF CONTENTS
T
ABLE OF CONTENTS
TT
ABLE OF CONTENTSABLE OF CONTENTS
Preface i
iii
Chapter 1
Introducing the Motherboard 1
Introduction......................................................................................1
Feature ..............................................................................................2
Motherboard Components.............................................................4
Chapter 2
Installing the Motherboard 7
Safety Precautions...........................................................................7
Choosing a Computer Case............................................................7
Installing the Motherboard in a Case...........................................7
Checking Jumper Settings..............................................................8
Setting Jumpers....................................................................8
Checking Jumper Settings....................................................9
Jumper Settings....................................................................9
Installing Hardware........................................................................10
Installing the Processor......................................................10
Installing Memory Modules................................................12
Expansion Slots....................................................................15
Connecting Optional Devices.............................................17
Installing a Hard Disk Drive/CD-ROM/SAT A Har d Drive...19
Connecting I/O Devices...............................................................21
Connecting Case Components....................................................22
Front Panel Header............................................................24
1 1
1
1 1
7 7
7
7 7
Chapter 3
Using BIOS 25
About the Setup Utility ................................................................ 25
The Standard Configuration...............................................25
Entering the Setup Utility....................................................25
Using BIOS.....................................................................................26
Standard CMOS Setup.......................................................27
Advanced Setup..................................................................29
Advanced Chipset Setup.....................................................31
2525
25
2525
iv
Integrated Peripherals.......................................................32
Power Ma nagement Setup.................................................33
PCI/PnP Setup...................................................................34
PC Health Status................................................................35
Frequency/Voltage Contr ol................................................36
Load Default Settings........................................................38
Supervisor Password........................................................38
User Password..................................................................39
Save & Exit Setup...............................................................40
Exit Without Saving............................................................40
Updating the BIOS.............................................................40
Chapter 4
41 41
41
41 41
Using the Motherboard Software 41
About the Software DV D-ROM/CD-ROM..................................41
Auto-installing under W indows XP/Vista/7...............................41
Running Setup....................................................................42
Ma nual Installation........................................................................44
Utility Software Reference............................................................44
Chapter 5
45 45
45
45 45
Setting Up eJIFFY 45
Installation a nd BIOS Setup......................................................46
Entering eJIFFY....................................................................................49
Features Icons........................................................................................50
Usage FAQ...............................................................................................51
Chapter 6
55 55
55
55 55
T r ouble Shooting 55
Start up problems during assembly...........................................55
Start up problems after prolong use..........................................56
Maintena nce a nd care ti ps............................................................56
Basic Troubleshooting Flowchart..............................................57
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the P43T-A2 motherboard. This motherboard is a high
performance, enhanced function motherboard designed to support the LGA775 socket
®
Intel
Yorkfield/Wolfdale processors for high-end business or personal desktop mar-
kets.
The motherboard incorporates the Intel Eaglelake P43 Northbridge (NB) and Intel
ICH10 Southbridge (SB) chipsets. The Northbridge supports a Front Side Bus (FSB)
frequency of 1333/1066/800 MHz using a scalable FSB Vcc_CPU. The memory
controller supports DDR2 memory DIMM frequencies of 800/667. It supports four
DDR2 sockets with maximum memory size of 16 GB. DDR2 memory bandwidth of
12.8 GB/s in dual-channel symmetric mode assuming DDR2 800 MHz. High resolu-
tion graphics via one PCI Express x16 slot, intended for Graphics Interface, is fully
compliant to the PCI Express Base Specification Revision 2.0.
The ICH10 Southbridge supports two PCI slots which are PCI v2.3 compliant. In
addition, three PCI Express x1 slots are supported, fully compliant to the PCI
Express Base Specification, Revision 1.1. It implements an EHCI compliant interface that provides 480 Mb/s bandwidth for twelve USB 2.0 ports (four USB ports and
four USB 2.0 headers support additional eight USB ports). One onboard IDE connector supports two IDE devices in Ultra ATA 133/100/66/33 mode. The Southbridge
supports six SATA ports with maximum transfer rate up to 3.0 Gb/s each.
1
There is an advanced full set of I/O ports in the rear panel, including PS/2 mouse and
keyboard connectors, COM, four USB ports, one LAN port and audio jacks for
microphone, line-in and 6-ch line-out.
Introducing the Motherboard
2
Feature
Processor
This motherboard uses
th
e following features:
• Accommodates Intel® Yorkfield/Wolfdale processors
• Supports a system bus (FSB) of 1333/1066/800 MHz
an LGA775 type of Intel® Yorkfield/Wolfdale that carries
Chipset
The P43 Northbridge (NB) and ICH10 Southbridge (SB) chipsets are based on an
innovative and scalable architecture with proven reliability and performance.
P43 (NB)
ICH10 (SB)
• Supports 36-bit host bus addressing, allowing the
CPU to access the entire 64 GB of the memory address space.
• 2 GB/s point-to-point Direct Media Interface (DMI) to
ICH10 (1 GB/s each direction)
• One, 16-lane PCI Express x16 port for Graphics Attach, compliant to the PCI Express Base Specification
revision 2.0
• Supports 512-Mb and 1-Gb DDR2 and 512-Mb, 1Gb,and 2-Gb DDR3 DRAM technologies for x8 and
x16 devices
• Enhanced DMA Controller , interrupt controller, and timer
functions
• Compliant with PCI Express Base Specification, revision 1.1
• Compliant with PCI v2.3 specificaiton
• Compliant with SATA 3.0 Gb/s Host Controller
• Integrated USB 2.0 Host Controller supporting up to
twelve USB 2.0 ports
Memory
• Supports DDR2 800/667 DDR2 SDRAM with Dual-channel architecture
• Accommodates four unbuffered DIMMs
• Up to 4 GB per DIMM with maximum memory size up to 16 GB
Audio
• 5.1 Channel High Definition Audio Codec
• ADCs supports 96k/48k/44.1kHz sample rate
• Meets Microsoft WLP 3.08 Vista premium and mobile PCs audio requirements
• Direct Sound 3DTM compatible
Introducing the Motherboard
Onboard LAN
• Integrated 10/100/1000 Base-T Transceiver
• Integrated 10/100/1000 Mbps IEEE 802.3 compliant
• IEEE 802.3u Auto-Negotiation
Expansion Options
The motherboard comes with the following expansion options:
• One PCI Express x16 slot for Graphics Interface
• Three PCI Express x1 slots
• Two 32-bit PCI v2.3 compliant slots
• One IDE connector supporting up to two IDE devices
• Six 7-pin SATA connectors
This motherboard supports Ultra DMA bus mastering with transfer rates of 133/
100/66/33 Mb/s.
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• One Serial port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and 6-ch line-out
BIOS Firmware
The motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
3
The firmware can also be used to set parameters for different processor clock
speeds.
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be operated in the ambiance between 0 and 50 °C.
Introducing the Motherboard
4
Motherboard Components
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONE NTS
1. CPU Socket
LGA775 socket Intel
Family processors
®
Yorkfield/ Wolfda le
2. CPU_FAN1 CPU cooling fan connector
3. DDR2_DIMM1~4 240-pin DDR2 SDRAM slot s
4. ATX_POWER St andard 24-Pin ATX Power connector
5. SATA1~6 Serial AT A connectors
6. CASE_FAN Case cooling fan connector
7. F_PANEL Front Panel Switch/LED header
8. USBPWR_F1~2 Front Panel USB Power Select jumpers
9. F_USB1~4 Front P anel USB headers
10. SPK Speaker header
1 1. CL R_CMOS Cle ar CMO S jum per
12. IDE Primary IDE connecto r
13. SPDIFO SPDIF out header
14. F_AUDIO Front Panel Audio header
15. CD_IN Analog Audio Input connector
16. PCI2~3 32-bit add-on card slots
17. PCIE1~3 P CI Express x1 slots
18. PCIE16X_1 PCI Express x16 graphics card slot
19. USBPWR_R1 Rear Panel USB/PS2 Power Select jumper
20. ATX12V 4-pin +12V power connector
21. SYS_FAN1 System cooling fan connector
5
This concludes Chapter 1. The next chapter explains how to install the motherboard.
Introducing the Motherboard
6
Memo
Introducing the Motherboard
Chapter 2
Installing the Motherboard
Safety Precautions
• Follow these safety precautions when installing the motherboard
• Wear a grounding strap attached to a grounded device to avoid damage from static electricity
• Discharge static electricity by touching the metal case of a safely
grounded object before working on the motherboard
• Leave components in the static-proof bags they came in
• Hold all circuit boards by the edges. Do not bend circuit boards
Choosing a Computer Case
There are many types of computer cases on the market. The motherboard complies
with the specifications for the FULL ATX system case. Firstly, some features on the
motherboard are implemented by cabling connectors on the motherboard to indicators and switches on the system case. Make sure that your case supports all the
features required. Secondly, this motherboard supports two enhanced IDE drives.
Make sure that your case has sufficient power and space for all drives that you intend
to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that the I/O
template in the case matches the I/O ports installed on the rear edge of the
motherboard.
This motherboard carries a FULL ATX form factor of 305 x 244 mm. Choose a case
that accommodates this form factor.
7
Installing the Motherboard in a Case
Refer to the following illustration and instructions for installing the motherboard in
a case.
Most system cases have mounting brackets installed in the case, which correspond
the holes in the motherboard. Place the motherboard over the mounting brackets
and secure the motherboard onto the mounting brackets with screws.
Ensure that your case has an I/O template that supports the I/O ports and expansion
slots on your motherboard.
Installing the Motherboard
8
Do not over-tighten the screws as this can stress the motherboard.
Checking Jumper Settings
This section explains how to set jumpers for correct configuration of the motherboard.
Setting Jumpers
Use the motherboard jumpers to set system configuration options. Jumpers with
more than one pin are numbered. When setting the jumpers, ensure that the jumper
caps are placed on the correct pins.
The illustrations show a 2-pin jumper. When
the jumper cap is placed on both pins, the
jumper is SHORT. If you remove the jumper
cap, or place the jumper cap on just one pin,
the jumper is OPEN.
This illustration shows a 3-pin jumper. Pins
1 and 2 are SHORT
SHORT OPEN
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper Type Description Setting (default)
1-2: NORMAL
CLR_CMOS
3-pin
CLEAR CMOS
2-3: CLEAR
Before clearing the
CMOS, make sure to
turn the system off.
1
CLR_CMOS
9
USBPWR_R1
USBPWR_F1~2
To avoid the system instability after clearing CMOS, we recommend
1.
users to enter the main BIOS setting page to “Load Default Settings”
and then “Save & Exit Setup”.
Make sure the power supply provides enough 5VSB voltage before se-
2.
lecting the 5VSB function.
3.
It is required that users place the USBPWR_F1~2 & USBPWR_R1 cap
onto 2-3 pin rather than 1-2 pin as default if you want to wake up the
computer by USB/PS2 KB/Mouse.
3-pin
3-pin
Rear USB/PS2
Power Select
Jumper
Front Pa
USB Power
Select Jumper
nel
1-2: VCC
2-3: 5VSB
1-2: VCC
2-3: 5VSB
Installing the Motherboard
1
USBPWR_R1
1
USBPWR_F1~2
10
Installing Hardware
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the motherboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes
across the motherboard, you may cause serious damage to the motherboard
or its components.
On most motherboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the clips.
Also, install the cooling fan in a well-lit work area so that you can clearly
see the motherboard and processor socket.
Before installing the Processor
This motherboard automatically determines the CPU clock frequency and system
bus frequency for the processor. You may be able to change the settings in the system
Setup Utility. We strongly recommend that you do not over-clock processors or
other components to run faster than their rated speed.
Warning:
1. Over-clocking components can adversely affect the reliability of the
system and introduce errors into your system. Over-clocking can permanently damage the motherboard by generating excess heat in components
that are run beyond the rated limits.
2. Always remove the AC power by unplugging the power cord from the
power outlet before installing or removing the motherboard or other
hardware components.
This motherboard has an LGA775 socket. When choosing a processor, consider the
performance requirements of the system. Performance is based on the processor
design, the clock speed and system bus frequency of the processor, and the quantity
of internal cache memory and external cache memory.
Installing the Motherboard
CPU Installation Procedure
The following illustration shows CPU installation components.
A. Read and follow the instructions shown
on the sticker on the CPU cap.
B. Unload the cap
· Use thumb & forefinger to hold the
lifting tab of the cap.
· Lift the cap up and remove the cap
completely from the socket.
C. Open the load plate
· Use thumb & forefinger to hold the
hook of the lever, pushing down and
pulling aside unlock it.
· Lift up the lever.
· Use thumb to open the load plate. Be
careful not to touch the contacts.
D. Install the CPU on the socket
· Orientate CPU package to the socket.
Make sure you match triangle marker
to pin 1 location.
E. Close the load plate
· Slightly push down the load plate onto
the tongue side, and hook the lever.
· CPU is locked completely.
11
F. Apply thermal grease on top of the CPU.
G. Fasten the cooling fan supporting base
onto the CPU socket on the motherboard.
H. Make sure the CPU fan is plugged to the
CPU fan connector. Please refer to the
CPU cooling fan user’s manual for more
detail installation procedure.
1. To achieve better airflow rates and heat dissipation, we suggest
that you use a high quality fan with 3800 rpm at least. CPU fan and
heatsink installation procedures may vary with the type of CPU fan/
heatsink supplied. The form and size of fan/heatsink may also vary.
2. DO NOT remove the CPU cap from the socket before installing a
CPU.
3. Return Material Authorization (RMA) requests will be accepted
only if the motherboard comes with the cap on the LGA775 socket.
Installing the Motherboard
12
Installing Memory Modules
This motherboard accommodates four memory modules. It can support four 240-pin
DDR2 800/667. The total memory capacity is 16 GB.
DDR2 SDRAM memory module table
Memory module Memory Bus
DDR2 667 333 MHz
DDR2 800 400 MHz
You must install at least one module in any of the four slots. Each module can be
installed with 4 GB of memory; total memory capacity is 16 GB.
The four DDR2 memory sockets (DDR2_DIMM1, DDR2_DIMM2, DDR2_DIMM3,
DDR2_DIMM4) are divided into two channels and each channel has two memory
sockets as following:
Channel 0: DDR2_DIMM1, DDR2_DIMM2
ff
Channel 1: DDR2_DIMM3, DDR2_DIMM4
ff
Do not remove any memory module from its antistatic packaging until
you are ready to install it on the motherboard. Handle the modules only
by their edges. Do not touch the components or metal parts. Always
wear a grounding strap when you handle the modules.
Installation Procedure
Refer to the following to install the memory modules.
1 This motherboard supports unbuffered DDR2 SDRAM only.
2 Push the latches on each side of the DIMM slot down.
3 Align the memory module with the slot. The DIMM slots are keyed with
notches and the DIMMs are keyed with cutouts so that they can only be
installed correctly.
4 Check that the cutouts on the DIMM module edge connector match the
notches in the DIMM slot.
5 Install the DIMM module into the slot and press it firmly down until it
seats correctly. The slot latches are levered upwards and latch on to
the edges of the DIMM.
6 Install any remaining DIMM modules.
Installing the Motherboard
Ta ble A: DDR2 (memory module) QVL (Qualified V endor List)
The following DDR2 800/667/533 memory modules have been tested and qualified
for use with this motherboard.
Type Size Vendor Module Name
DDR2 533
DDR2 667
512 MB
1 GB
512 MB
1 GB
2 GB
4 GB
Samsung PC2-4200U-4444-10-B1
A-data A-DATA/Vitesta
Kingmax KLBD48F-A8KE4
Apacer 78.91G92.9K5
Micron MT4HTF6464AY-667E1
PSC AL6E8E63J-6E1
Ramxel RML1520M38D6F-667
Samsung PC2-5300U-555-12-D3
AU01GE667C5KBGC
Apacer
Corsair VS1GB667D2
Hexon HYNT7AUDR-30M48
Kingston KVR667D2N5
Micron MT8HTF12864AY-667E1
PSC
Samsung Golden Bar M378T2863DZS 0742
Aeneon AET860UD00-30DB08X
Apacer 78.A1G9O.9K4
Hexon HYNT8AUDR-30M88
Hynix HYMP125U64AP8-Y5 AB-A 0623
Kingston KVR667D2N5/2G
LeadMax PC2-5300U
PSC AL8E8F73C-6E1
Qimonda HYS64T256020EU-3S-C2
Aeneon AET960UD00-30D
78.01G9O.9K5
1GB UNB PC2-5300 CL5
AL7E8E63B-6E1T
AL7E8F63J-6E1
AL7E8F73C-6E1
13
Installing the Motherboard
14
Type Size Vendor Module Name
KVR800D2N5/512 1.8V
9905315-019.A02LF
AET760UD00-30DB97X
AET760UD00-25DC08X
AU01GE800C5KBGC
78.01GAO.9K5
Geil Millenary
/Geil/GL2L64M088BA18H
Geil Platinum E dition
KHX6400D2ULK2/2G 9905315 -
078.A00LF//Boxed
KVR800D2N5/1G 1.8V
9905316-054.A01LF
Golden Bar M378T2953EZ3-
CE7 0726
SP001GBLRU800S01
Red A-DATA
M2OMI6H3J4720L1C5Z /A-
DATA/Boxed
AL8E8F73C-8E1
AL8E8F73C-8E1
SP002GBLRU800S01
Geil/Boxed
DDR2 800
512 MB
1 GB
2 GB
4 GB
Kingston
Micron MT8HTF6464AY-80ED4
Qimonda HYS72T64000HU-2.5-B
A-DATA M2GVD6G3I41P0U1E5E
Aeneon
Apacer
APOGEE AU1G082-800P000
Geil
Hexon ELPT7AUDR-25M48
Infinity 04701G16CZ5U2G
Kingston
PSC AL7E8F73C-8E1
Ramaxel RML1320EH38D7F-800
Samsung
Silicon
Power
Transcend 507301-1571
A-DATA
Aeneon AET860UD00-25DC08X
Apacer 78.A1GAO.9K4
CORSAIR CM2X2048-6400C5
Hexon ELPT8AUDR-25M88
Kingston KVR800D2N5/2G
Micron MT16HTF25664AY-800E1
PSC
Qimonda HYS64T256020EU-25F-C2
Samsung M378T5663QZ3-CF7
Silicon
Power
Aeneon AET960UD00-25D
Installing the Motherboard
Expansion Slots
Installing Add-on Cards
The slots on this motherboard are designed to hold expansion cards and connect them
to the system bus. Expansion slots are a means of adding or enhancing the
motherboard’s features and capabilities. With these efficient facilities, you can increase the motherboard’s capabilities by adding hardware that performs tasks that
are not part of the basic system.
15
PCIEX16_1 Slot The PCI Express x16 slot is used to install the external PCI
PCIE1~3 Slots
PCI2~3 Slots
Before installing an add-on card, check the documentation for the card
carefully. If the card is not Plug and Play, you may have to manually
configure the card before installation.
Express graphics cards that are fully compliant to the PCI
Express Base Specification Revision 2.0.
The PCI Express x1 slots are fully compliant to the PCI
Express Base Specification Revision 1.1.
This motherboard is equipped with two standard PCI slots.
PCI stands for Peripheral Component Interconnect and is a
bus standard for expansion cards, which for the most part, is a
supplement of the older ISA bus standard. The PCI slots on
this board are PCI v2.3 compliant.
Installing the Motherboard
Loading...
