ECS Intel-powered Classmate PC User Manual
i
i
Preface
Copyright 2010
All Rights Reserved.
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does
not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect,
special, incidental, or consequential damages arising out of the
use or inability to use the product or documentation, even if
advised of the possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy
of this manual, the manufacturer and distributor assume no liability
resulting from errors or omissions in this manual, or from the use of
the information contained herein.
ii
Table of Content
ATTENTION: TEACHERS, PARENTS AND ADULT SUPERVISORS ................. 2
AGENCY REGULATORY NOTICES ............................................................. 5
MODIFICATIONS ................................................................................... 5
CONNECTIONS TO PERIPHERAL DEVICES .............................................. 6
SAR EXPOSURE ................................................................................. 6
DECLARATION OF CONFORMITY ............................................................ 6
EUROPEAN NOTICE ............................................................................. 6
CANADIAN NOTICE............................................................................... 7
ATTACHMENT LIMITATIONS STATEMENT ................................................ 7
POWER CORD REQUIREMENT .............................................................. 8
U.S. AND CANADA ............................................................................... 8
BATTERY PACK SAFETY ....................................................................... 9
LITHIUM BATTERY WARNING / BRIDGE BATTERY WARNING .................... 10
GETTING TO KNOW THE BASICS ........................................................... 12
OPENING THE LCD PANEL ................................................................. 12
FRONT VIEW ..................................................................................... 13
WATER RESISTANCE PRECAUTIONARY MEASURES ON KEYBOARD,
POWER BUTTON AND TOUCH PAD BUTTONS ....................................... 16
LEFT VIEWS ...................................................................................... 18
RIGHT VIEW ...................................................................................... 19
BOTTOM VIEW ................................................................................... 20
CARDREADER ................................................................................... 21
GETTING STARTED ............................................................................... 23
CONNECTING THE AC ADAPTER ......................................................... 23
TO REMOVE THE BATTERY PACK: ...................................................... 25
BATTERY LOW-POWER WARNING....................................................... 27
CHARGING THE BATTERY AND CHARGING TIME ................................... 27
CHECKING THE BATTERY LEVEL ......................................................... 28
PROLONGING THE BATTERY’S LIFE AND USAGE CYCLES...................... 28
STANDBY SUSPEND ........................................................................... 29
HIBERNATE SUSPEND ........................................................................ 29
USING INTEL-POWERED CLAMSHELL CLASSMATE PC ........................... 32
LCD CARE ........................................................................................ 32
iii
FUNCTION KEYS (QUICK KEYS) .......................................................... 33
FUNCTION KEYS (QUICK KEYS) .......................................................... 33
TOUCHPAD PRECAUTIONS ................................................................. 34
BIOS SETUP AND SECURITY FEATURE .................................................. 37
MAIN SETUP ..................................................................................... 39
ADVANCED SETUP ............................................................................. 40
SECURITY ......................................................................................... 40
BOOT SETUP ..................................................................................... 41
EXIT SETUP ...................................................................................... 41
3G CONNECTION (OPTION) ................................................................... 44
TROUBLESHOOTING .............................................................................. 54
SPECIFICATION ..................................................................................... 56
1
2
AAtttteennttiioonn:: TTeeaacchheerrss,, PPaarreennttss
aanndd AAdduulltt SSuuppeerrvviissoorrs
s
This product is an educational tool designed for school children,
ages 6 and up. There must be supervision by an adult on school
children under 10 when using this Intel-powered classmate PC. It
is a must to have a thorough explanation to students on safe and
proper handling of the Intel-powered classmate PC, power supply,
battery pack, and power cord.
Be sure to keep the power cord away from
younger children
Please ensure that students understand the following:
Emphasize to students that this device is an educational tool
and not a toy. The computer, power supply, battery pack or
power cord should not be dropped, crushed, stepped on or
otherwise abused.
Ensure students understand the safe and proper handling of
power cord and power supply. Misuse could result in serious
injury.
The teacher, parent or adult supervisor should periodically
inspect the computer; power supply and power cord for
damage and replace it, if necessary.
Students should report any damage or loose parts to their
teacher, p arent or adult supervisor, immediately.
Do not leave PC plugged in or “on” when enclosed in a non-
vented container, such as a school backpack, as overheating
may occur.
It is recommended that students should take a 5 minute break
every 30 minutes of use.
3
SSaaffeettyy PPrreeccaauuttiioonnss
The following are lists of precautionary measure the students must
understand before using this computer inside the classroom or
home environment:
1. Do not place near fire or other sources of heat.
2. Do not expose to magnetic fields.
3. Do not expose to direct sunlight.
4. Do not expose to rain or moisture.
5. Do not place heavy objects to add heavy pressure on the
computer.
6. Do not drop the computer.
CCaarriinngg ffoorr yyoouurr CCoommppuutteerr
Be sure not to clean the computer when it is plugged into a
wall socket.
When cleaning the unit, clean only with a damp soft cloth. Do
not pour liquid onto the unit..
Do not clean while computer is “on” or plugged into wall
socket.
Caution students to avoid using this device under wet
conditions and also to protect the unit when carrying under
this condition.
Be sure the touch pad does not come into contact with dirt,
liquids, or grease.
4
5
AAggeennccyy RReegguullaattoorryy NNoottiicceess
FFeeddeerraall CCoommmmuunniiccaattiioonnss CCoommmmiissssiioonn NNoottiiccee
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio or television
technician for help.
This transmitter must not be colocated or operating in conjunction with any other antenna or
transmitter.
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that is not expressly approved by
the Manufacture may void the user’s authority to operate the
equipment.
6
Connections to Peripheral Devices
Connections to this device must be made with shielded cables with
metallic RFI/EMI connector hoods to maintain compliance with
FCC Rules and Regulations.
SAR Exposure
Intel-powered clamshell classmate PC has been tested for and
found to be in compliance with FCC RF Exposure Limit. During
extended periods of use the integrated antenna located at the top
left corner of the display screen should be positioned at least 20cm
from users or nearby persons.
Declaration of Conformity
This device complies with Part 15 the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
European Notice
Products with the CE Marking comply with both the EMC Directive
(2004/108/EC) and the Low Voltage Directive (2006/95/EC) and
R&TTE Directive (1999/5/EC) issued by the Commission of the
European Community.
Compliance with these directives implies conformity to the
following European Norms:
EN55022: 2006, CLASS B
EN61000-3-2: 2006, CLASS D
EN61000-3-3: 1995+A1: 2001+A2: 2005
EN55024: 1998+A1: 2001+A2: 2003
IEC61000-4-2: 2001 ED. 1.2
IEC61000-4-3: 2006 ED. 3.0
IEC61000-4-4: 2004 ED. 2.0
IEC61000-4-5: 2005 ED. 2.0
IEC61000-4-6: 2006 ED. 2.2
IEC61000-4-8: 2001 ED. 1.1
IEC61000-4-11: 2004 ED. 2.0
EN 300 328-2, EN 300 328-1, EN 301 489-1, EN 301 489-17
7
(ETSI 300 328, ETSI 301 489) Electro-magnetic Compatibility
and Radio Spectrum Matter.
EN60950 (IEC60950) I.T.E. Product Safety
Canadian Notice
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus as set out in the radio
interference regulations of the Canadian Department of
Communications.
Le present appareil numerique nemet pas de bruits
radioelectriques depassant les limites applicables aux appa reils
numeriques de Classe B prescrites dans le reglement sur le
brouillage radioelectrique edicte par le Ministere des
Communications du Canada.
Attachment Limitations Statement
This equipment meets
telecommunications network protective, operational and
safety requirements as prescribed in the appropriate Terminal
Equipment Technical Requirements document(s).
This is confirmed by marking the equipment with the Industry
Canada certification number. The Department does not guarantee
the equipment will operate to the user's satisfaction.
Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local
telecommunications company.
The equipment must also be installed using an acceptable method
of connection. The customer should be aware that compliance with
the above conditions may not prevent degradation of service in
some situations.
Repairs to certified equipment should be coordinated by a
representative designated by the supplier. Any repairs or
alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
8
Users should ensure for their own protection that the electrical
ground connections of the power utility, telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas.
Users should not attempt to make such
connections themselves, but should contact the appropriate
electric inspection authority, or electrician, as appropriate.
Power Cord Requirement
The power cord supplied with the AC adapter should match the
plug and voltage requirements for your local area. Regulatory
approval for the AC adapter has been obtained using the power
cord for the local area.
However, if you travel to a different area and need to connect to a
different outlet or voltage, you should use one of the power cords
listed below. To purchase a power cord (including one for a country
not listed below) or a replacement AC adapter, contact your local
dealer.
U.S. and Canada
The cord set must be UL/ETL-Listed and CSA-Certified or
UL/C-ETL Listed.
The minimum specifications for the flexible cord are (1) No.
18 AWG, (2) Type SPT-2, and (3) 2-conductor.
The cord set must have a rated current capacity of at least 7A.
The attachment plug must be NEMA 1-15P (7A, 125V)
configuration.
Other Countries
The cord set fittings must bear the certification mark of the
agency responsible for evaluation in a specific country.
Acceptable agencies are:
CCC (China)
The flexible cord must be of a HAR (harmonized) type
HO5VV-F 3-conducto r co rd with a minimum conductor size of
0.03 square inches.
9
The minimum specification for the flexible cord for Class II
product are: (1) 2X0.75 mm
2
conductors, (2) 2-conductor cord.
The cord set must have a current capacity of at least 10 A and
a nominal voltage rating of 125 / 250 VAC.
This model is designed to use with the
following AC Adapter model only.
Manufacture: LISHIN INTERNATIONAL ENTERPRISE CORP.
Model: 0225C2040 (AC 2 Pin)
Model: 0225A2040 (AC 3 Pin)
Manufacture: DELTA ELECTRONICS, INC.
Model: ADP-40MH AD (AC 2 Pin)
Model: ADP-40MH BD (AC 3 Pin)
Battery Pack Safety
The battery pack is intended to use only with this notebook.
The battery pack should be replaceable by the end user.
Only qualified service technicians should replace the battery
pack.
Do not disassemble the pack.
Do not dispose of the battery pack in fire or water.
To avoid risk of fire, burns, or damage to your battery pa ck,
does not allow a metal object to touch the battery contacts.
Handle a damaged or leaking battery with extreme care. If
you come in contact with the electrolyte, wash the exposed
area with soap and water. If it contacts the eye, flush the eye
with water for 15 minutes and seek medical attention.
Do not charge the battery pack if the ambient temperature
exceeds 45℃ (113℉).
To obtain a replacement battery, contact your local dealer.
Do not expose the battery pack to high storage temperatures
(above 60℃, 140℉).
When discarding a battery pack, contact your local waste
disposal provider regarding local restrictions on the disposal
or recycling of batteries.
Use only supplied AC Adapter for charging.
10
Danger of explosion if battery is
incorrectly replaced. Only qualified service technicians
should replace and discard the battery pack. Replace only
with same or equivalent type recommended by the
manufacturer. Discard used batteries according to the
manufacturer’s instructions or local laws.
Explisionsgefahr bei unsachgernazen
Austausch der Batterie. Ersatz nur durch denselben oder
einem vom Hersteller empfohlenem ahnlichen Typ.
Entsorgung gebrauchter Batterien navh Angaben des
Herstellers.
Lithium battery warning / Bridge battery warning
This computer contains a lithium battery to power the clock and
calendar circuitry.
Der Arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635
betragt 70dB (A) oder weniger.
Zum Netzanschlua dieses Gerates ist eine geprufte Leitung zu
verwenden. Fur einen Nennstrom bis 6A und einem Gerategewicht
groBer 3kg ist eine Leitung nicht leichter als (1)H05VV-F, 3G,
0.75mm
2
(2)2X0.75 mm2 conductors einzusetzen.
Die Steckdose muB nahe dem Gerat angebracht und leicht
zuganglich sein.
This part is hot. Be careful.
Diese Flachewird sehr heiss.
When you see this symbol, be careful as this spot may be
very hot.
When you see this symbol, be careful as this spot may be very hot.
11
12
GGeettttiinngg TToo KKnnooww TThhee BBaassiiccss
WWeellccoommee ttoo tthhee IInntteell--ppoowweerreedd CCllaammsshheellll CCllaassssmmaattee PPCC
Congratulations on your purchase of Intel-powered classmate PC.
Intel-powered clamshell classmate PC features the latest advances
in portable computing technology. Intel-powered clamshell
classmate PC modular design provides maximum expandability
without compromising portability.
GGeettttiinngg ttoo KKnnooww YYoouurr CCoommppuutteerr
Opening the LCD Panel
The Intel-powered clamshell
classmate PC also features a rugged design that helps protect
the computer from scratches and light falls. Please be careful
when handling your computer and recommended not to let
the computer fall from high places.
13
To avoid damage to the display
panel:
1. Try not to slam the display upon closing it.
2. Try not to place any object on top when it is closed or open.
3. Be sure the system is turned off or in suspend mode before
you close the display panel.
With the LCD screen open, you will see several features important
for operating your Intel-powered clamshell classmate PC.
Front View
14
1. LCD Display
The panel is where the system content is displayed.
2. Power/Suspend Button
Press momentarily to turn on the system.
Press the power/suspend button again to return from
the suspend mode.
3. LED Status Indicator
The LED Status Indicator displays the operating status of your
Intel-powered classmate PC. When a certain function is
enabled, the LED will light up. The following section describes
each indicator.
SystemandPowerStatusIndicators
LED Graphic
Symbol
Indication
Blue light indicates the numeric keypad is activated.
Blue light indicates the cap-lock is activated.
Blue light indicates the is reading/writing data.
Blue light indicates the WLAN module is active.
Blue light indicates the system is ON.
15
The battery LED reflects according to the following
status:
Blue light indicates the battery is fully charged
and the AC Adapter is plugged in.
Red light indicates the battery is charging.
Blinking red light indicates the battery power is
low.
No light indicates that the battery pack is not
installed in your system.
Red light indicates the system is operated by
battery where the capacity is low.
4. Keyboard
The keyboard is used to enter data.
5. Built-in Microphone
The microphone is used when you are having an audio/video
conference with the other party.
6. Touch Pad
The touch pad is a built-in pointing device with functions
similar to a mouse.
The touch pad is also equipped with a
scroll bar so you can move around in a large document.
Sliding a vertical presentation of content, such as text,
drawings, or images, across a screen or display window. It is
often used to show large amounts of data that could not fit on
the viewport all at the same time.
Loading...
