Preface
Copyright 2009
All Rights Reserved.
The information in this document is subject to change without
prior notice in order to improve reliability, design and function and
does not represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect,
special, incidental, or consequential damages arising out of the use
or inability to use the product or documentation, even if advised of
the possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.
Limitation of Liability
While reasonable efforts have been made to ensure the accuracy of
this manual, the manufacturer and distributor assume no liability
resulting from errors or omissions in this manual, or from the use
of the information contained herein.
Notice:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment. Shielded interface cables and a nonshielded AC power cord must be used in order to comply with
emission limits.
This equipment is to be used with power supply:
65W
There is no internal power supply.
ii
Table of Content
BEFORE YOU START ............................................................................... 2
LET YOUR COMPUTER ACCLIMATE ITSELF .............................................. 9
HEAT, COLD, HUMIDITY, AND GLARE .................................................... 9
SUITABLE PLACE TO WORK ................................................................. 10
INTRODUCTION...................................................................................... 12
FRONT VIEW ..................................................................................... 13
LEFT VIEWS ...................................................................................... 15
RIGHT VIEW ...................................................................................... 16
GETTING STARTED ............................................................................... 19
CONNECTING THE AC ADAPTER ......................................................... 19
TO INSTALL THE BATTERY PACK: ........................................................ 22
TO REMOVE THE BATTERY PACK: ...................................................... 22
USING THE NOTEBOOK COMPUTER ....................................................... 25
LCD CARE ........................................................................................ 25
EXTERNAL CRT DISPLAY ................................................................... 25
POWER SAVING MODE....................................................................... 29
NORMAL MODE ................................................................................. 30
HIGH PERFORMANCE MODE ............................................................... 30
DVD PLAY MODE .............................................................................. 31
DYNAMIC SWITCH MODE .................................................................... 31
TOUCHPAD PRECAUTIONS ................................................................. 33
DATA STORAGE AND RETRIEVAL ........................................................ 33
THE BATTERY POWER SYSTEM .......................................................... 34
PREPARING THE BATTERY PACK FOR USE (BATTERY CALIBRATION) .... 34
AUTOMATIC BATTERY PACK CHARGING FUNCTION .............................. 35
BATTERY STATUS .............................................................................. 35
BATTERY LOW WARNING ................................................................... 36
HELP WINDOWS ................................................................................ 38
DESKTOP .......................................................................................... 38
INTERNET CONNECTION ........................................................................ 44
RUNNING BIOS SETUP ......................................................................... 48
INFO SETUP ...................................................................................... 49
MAIN SETUP ..................................................................................... 50
ADVANCED ........................................................................................ 51
SECURITY ......................................................................................... 52
BOOT SETUP ..................................................................................... 52
EXIT SETUP ...................................................................................... 53
VGA UTILITIES ..................................................................................... 55
ADJUST RESOLUTION ........................................................................ 56
iii
CALIBRATE COLOR ............................................................................ 57
ADJUST DISPLAY SETTING ................................................................. 57
CONNECT TO A PROJECTOR ............................................................... 58
ADJUST CLEAR TYPE TEXT ................................................................ 58
3G CONNECTION .................................................................................. 60
TROUBLESHOOTING .............................................................................. 65
NO SPEAKER OUTPUT ........................................................................ 66
SOUND CANNOT BE RECORDED .......................................................... 66
THE HARD DISK DRIVE DOES NOT WORK OR IS NOT RECOGNIZABLE ....... 67
THE HARD DRIVE IS MAKING ABNORMAL WHINING NOISES ..................... 67
THE HARD DISK DRIVE HAS REACHED ITS CAPACITY ............................. 67
THE HARD DISK TAKES LONGER TO READ A FILE ................................... 68
THE FILES ARE CORRUPTED ............................................................... 68
THE DISPLAY PANEL IS BLANK WHEN THE SYSTEM IS TURNED ON .......... 68
THE SCREEN IS DIFFICULT TO READ .................................................... 68
THE SCREEN FLICKERS ...................................................................... 68
THE BUILT-IN TOUCH PAD PERFORMS ERRATICALLY ............................. 69
THE BUILT-IN KEYBOARD ACCEPTS NO INPUT ....................................... 69
THE CHARACTERS ON THE SCREEN REPEAT WHILE I TYPE .................... 69
A MESSAGE “CMOS CHECKSUM FAILURE” DISPLAYS DURING THE
BOOTING PROCESS OR THE TIME
(CLOCK) RESETS WHEN BOOTING ....... 69
THE POST DOES NOT SHOW AN INCREASED MEMORY CAPACITY WHEN
YOU HAVE ALREADY INSTALLED ADDITIONAL MEMORY
.......................... 70
THE O/S ISSUES AN INSUFFICIENT MEMORY ERROR MESSAGE DURING
OPERATION
....................................................................................... 70
PC CARDS DO NOT FUNCTION ............................................................ 70
THE PC CARD CANNOT BE RECOGNIZED ............................................. 70
WINDOWS CRASHES OR FREEZES WHEN YOU REMOVE THE PC CARD ... 71
THE COMPUTER BECOMES HOT .......................................................... 71
THE PROGRAM APPEARS STOPPED OR RUNS VERY SLOWLY ................. 71
THE USB DEVICE DOES NOT WORK .................................................... 72
UNABLE TO USE THE EXTERNAL USB DEVICE ..................................... 72
UNABLE TO RECOGNIZE THE EXTERNAL USB DEVICE ......................... 72
SPECIFICATION ..................................................................................... 74
1
2
B
B
B
e
e
e
f
f
f
o
o
o
r
r
r
e
e
e
y
y
y
o
o
o
u
u
u
S
S
S
t
t
t
a
a
a
r
r
r
t
t
t
CCoonnvveennttiioonnss ooff TThhiiss MMaannuuaall
Use this manual will help you get the most from your notebook
computer.
If you are an experienced user of computers and/or Microsoft’s
Windows operating systems, you might find it useful to read
the Quick Start Guide that comes along with your accessories.
If you are a less experienced user, you should through the
manual carefully before using your system.
Whether or not you are an experienced user, you should consult on
the Troubleshooting Chapter if you encounter any problems with
your notebook.
SSaaffeettyy PPrreeccaauuttiioonnss
This section is designed to assist you in identifying potentially
unsafe conditions while working with this product. Required safety
features have been installed in the computer to protect you from
injury. However, you should use good judgment to identify
potential safety hazards:
1. Please read these safety instructions carefully.
2. Please keep this User's Manual for later reference.
3. Please disconnect this equipment from AC outlet before
cleaning. Don't use liquid or sprayed detergent for cleaning.
Use moisture sheet or cloth for cleaning.
4. For pluggable equipment, that the socket-outlet shall be
installed near the equipment and shall be easily accessible.
5. Please keep this equipment from humidity.
6. Lay this equipment on a reliable surface when installed. A
drop or fall could cause injury.
3
7. Make sure to use the right voltage for the power source when
connecting the equipment to the power outlet.
8. Place the power cord in such a way that people can not step
on it. Do not place anything on top of the power cord.
9. All cautions and warnings on the equipment should be noted.
10. If the equipment is not use for a long time, disconnect the
equipment from the main power outlet to avoid being damaged
by transient overvoltage.
11. Never pour any liquid into the opening, this could cause fire or
electrical shock.
12. Never open the equipment. For safety reason, the equipment
should only be opened by a qualified service personnel.
13. If on the following situations arises, get the equipment
checked by a service personnel:
a. The Power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment has not worked well or you cannot get it
work according to the user's manual.
e. The equipment has dropped and damaged.
f. If the equipment has obvious sign of breakage.
14. Do not leave this equipment in an environment unconditioned,
storage temperature above 60C (140f), it may damage the
equipment.
15. The unit can be operated at an ambient temperature of max.
5C to 35C.
16. The sound pressure level at the operators position according
to IEC 704-1: 1982 is equal or less than 70 dB(A).
17. Power Cord Requirements
The power cord set used with the AC adaptor must meet the
requirements of the country where you use the AC adaptor,
whether it is 100-240 Vac. The following information explains
the requirements for power cord set selection.
The cord set must be approved for the country in
which it is used.
The appliance coupler must have a configuration for
mating with a CEE7/EN60320/IEC 320/NEMA/ JIS C
8303 appliance inlet.
A. For U.S. and Canada:
The cord set must be UL Listed and CSA Certified.
4
The minimum specifications for the flexible cord are
No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor.
B. For Japan:
All components of the cord set must bear a “PSE”
mark and in accordance with the Japanese Dentori
Law.
The minimum specifications for the flexible cord
are .75m ㎡ conductors, (2) Type VCTR or VCTFK,
and (3) 2-conductor.
The cord set must have minimum rated current
capacity of 7 A.
The attachment plug must be a two-pole, grounded
type with a Japanese Industrial Standard C8303 (15
A, 125 VAC) configuration.
C. For Other Countries:
The cord set fittings must bear the certification mark
of the agency responsible for evaluation in a specific
country.
The flexible cord must be of a HAR (harmonized)
type H03VVH2-F.
The cord set must have a current capacity of a least
2.5 Amperes and voltage rating of 125 or 250 Vac.
CCAAUUTTIIOONN:: MMOODDEELL II5588IIIIXX ((xx==00~~99)) IISS DDEESSIIGGNNEEDD TTOO UUSSEE
WWI
ITTHH TTHHEE FFLLLLOOWWIINNGG AACC AADDAAPPTTEERR MMOODDEELL OONNLLYY
LLiittee--OOnn TTeecch
h
nnoollooggyy CCoorrppoorraattiioonn
PPAA--11665500--6655 ((6655WW,, 22ppiinn))
DDeellttaa EElle
eccttrroonniicc,, IInncc..
AADDPP--6655JJHH AABB ((6655WW,, 22ppiinn))
AADDPP--6655JJHH BBBB
((6655WW,, 33ppiinn))
AADDPP--6655HHBB AADD ((6655WW,, 22ppiinn))
LLii SShhiinn iinntteerrnna
attiioonnaall EEnntteerrpprriissee CCoorrppoorraattiioonn....
00333355CC22006655 ((6655WW,, 22p
p
iinn))
18. When using your telephone equipment, basic safety
precautions should always be followed to reduce the risk of
fire, electric shock and injury to persons. These precautions
includes the following:
Do not use this product near water, for example, near a
bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
5
Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
Do not use the telephone to report a gas leak in the
vicinity of the leak.
Use only the power cord and batteries indicated in this
manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special
instructions.
19. Do not use the AC adapter near open water or other liquids.
Never spill liquid into the AC adapter.
20. Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer's instructions. Never remove the battery pack
while the power is on as this may result in data loss when the
system loses power.
21. The input receptacle is used as the main disconnecting device.
TThhiiss ppaarrtt iiss hhoott.. BBee ccaarreeffuull..
DDiieessee FFllaacchheewwiirrdd sseehhrr hheeiissss..
WWhheenn yyoouu sseeee tthhiiss ssyymmb
booll,, bbee ccaarreeffuull aass tthhiiss ssppoott mmaayy
bbee vveerryy hhoott..
22. Laser Warning: Laser Class I Product Caution - Invisible laser
radiation when open avoid exposure to beam.
The optical drive used with this computer is certified as a
Class1 laser device according to the U.S. Department of
Health and Human Services (DHHS) Radiation Performance
Standard and International Standards IEC 60825-1
(EN60825-1). The device is not considered harmful, but the
following precautions are recommended:
Do not open the unit.
Avoid direct exposure to the laser beam.
If the unit requires service, contact an authorized
service center.
Ensure proper use by reading and following the
instructions carefully.
Do not attempt to make any adjustment of the unit.
6
CCllaassss 11 LLaasseerr PPrroodduucctt
AAppppaarreeiill AA LLaasseerr DDee CCllaassssee 1
1
LLaasseerrsscchhuuttzzkkllaassssee 11 PPrroodduukktt
DDoo nnoott aatttteemmpptt ttoo ddiissaasssseemmbbllee
tthhee ccaabbiinneett ccoonnttaaiinniin
ngg tthhee llaasseerr.. TThhee llaasseerr bbeeaamm uusseedd iinn
tthhiiss pprroodduucctt i
i
ss hhaarrmmffuull ttoo tthhee eeyyeess.. TThhee uussee ooff ooppttiiccaall
iinnssttrruummeen
nttss,, ssuucchh aass mmaaggnniiffyyiinngg lleennsseess,, wwiitthh tthhiiss
pprroodduucctt i
i
nnccrreeaassee tthhee ppootteennttiiaall hhaazzaarrdd ttoo yyoouurr eeyyeess.. FFoorr
yyoouur
r ssaaffeettyy,, hhaavvee tthhiiss eeqquuiippmmeenntt sseerrvviicceedd oonnllyy bbyy aann
a
a
uutthhoorriizzeedd sseerrvviiccee pprroovviiddeerr..
WWiicchhttiiggee SSiicchheerrhheeiittsshhiinnwweeiissee
1. Bitte lesen Sie diese Hinweis sorgfältig durch.
2. Heben Sie dirse Anleitung für den späteren Gebrauch auf.
3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen.
Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am
besten eignet sich ein angefeuchtetes Tuch zur Reinigung.
4. Die Netzanschluβsteckdose soll nahe dem Gerät angebracht
und leicht zugänglich sein.
5. Das Gerät ist vor Feuchtigkeit zu schützen.
6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu
achten. Ein Kippen oder Fallen könnte Beschädigungen
hervorrufen.
7. Beachten Sie beim Anschluß an das Stromnet die
Anschlußwerte.
8. Verlegen Sie die Netzanschlußleitung so, daß niemand
darüber fallen kann. Es sollte auch nichts auf der Leitun
abgestellt werden.
9. Alle Hinweise und Warnungen, die sich am Gerät befinden,
sind zu beachten.
10. Wird das Gerät üeinen längeren Zeitraum nicht benutzt,
sollten Sie es vom Stromnetz trennen. Somit wird im Falle
einer Überspannung eine Beschädigung vermieden.
11. Durch die Lüftungsöffnungen dürfen niemals Gegenstände
oder Flüssigkeien in das Gerät gelangen. Dies könne einen
Brand bzw. Elektrischen Schlag auslösen.
12. Öffnen Sie niemals das Gerät. Das Gerät darf aus Gründen
der elektrischen Sicherheit nur von authorisiertem
7
Servicepersonal geöffnet werden.
13. Wenn folgende Situationen auftreten ist das Gerät vom
Stromnetz zu trennen und von einer qualifizierten Servicestelle
zu Überprüfung.:
a. Netzlabel oder Netzstecker sind beschädigt.
b. Flüssigkeit ist in das Gerät eingedrungen.
c. Das Gerät war Feuchtigkeit ausgesetzt.
d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend
funktioniert oder Sie mit Hilfe dieser Anleitung keine
Verbesserung erzielen.
e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt.
f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
14. VORSICHT: Explosiongsgetahr bei unsachgemäßen
Austausch der Batterie. Ersatz nur durch denselben oder
einem vom Hersteller empfohlenem ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben des
Herstellers.
15. Dieses Schaltnetzteil kann bis zu einer Außentemperatur von
maximal 5ºC 35ºC.
16. Die Ausgangswerte dürfen nicht die auf dem Label
angegebenen Werte überschreiten.
17. Anforderungen an das Stromkabel
Das Kabel-Set, das an das Netzteil angeschlossen wird,
muss den Anforderungen des Landes, in dem Sie das
Netzteil einsetzen, genügen, je nachdem, ob die
Netzspannung 100-240V Wechselspannung beträgt.
Das Kabel-Set muss für das Land, in dem es
eingesetzt wird, zugelassen sein.
Der Gerätestecker des Kabels muss in eine
CEE7/EN60320/IEC 320/NEMA/ JIS C 8303 Buchse
passen.
A. Für die USA und Kanada:
Das Kabel-Set muss UL-gelistet und CSA zertifiziert
sein.
Die Minimalanforderungen für das Kabel
entsprechen No. 18 AWG. (2) Type SPT-2, und (3)
2-conductor.
B. Für Japan:
Alle Teile des Kabel-Sets müssen entsprechend
dem japanischen Dentori Law mit einem
„PSE“ markiert sein
8
Die Minimalanforderungen für das Kabel sind .75m
㎡ Leiter. (2) Type VCTF oder VCTFK, und (3) 2conductor.
Der Kabelsatz muss mindestens für eine
Stromstärke von 7A geeignet sein.
Der Wandstecker muss ein zweipoliger geerdeter
Steckertyp gemäß dem Japanese Industrial
Standard C8303 (15A, 125 VAC) sein.
C. Für andere Länder:
Die Zubehörteile des Kabel-Sets müssen das
Prüfsiegel derjenigen Stelle, die in dem jeweiligen
Land für die Sicherheitsprüfung zuständig ist, tragen.
Das Kabel muss vom HAR (harmonisierten) Typ
H03VVH2-F sein.
Das Kabel-Set muss eine Stromkapazität von
mindestens 2,5 Ampere haben und Spannungen von
125 oder 250 V Wechselstrom gestatten.
AACCHHTTUUNNGG:: MMiitt ddeemm II5588IIIIXX ((xx==00~~99)) mmuussss eeiinn AACC--AAddaapptteer
r
ffoollggeennddeenn MMooddeellllss vveerrwweennddeett wweerrddeenn
LLiittee--OOnn TTeecchhnno
o
llooggyy CCoorrppoorraattiioonn
PPAA--11665500--6655 ((6655WW,, 22ppiinn))
DDeellttaa EElleecct
trroonniicc,, IInncc..
AADDPP--6655JJHH AABB ((6655WW,, 22ppiinn))
AADDPP--6655JJHH BBBB ((6
6
55WW,, 33ppiinn))
AADDPP--6655HHBB AADD ((6655WW,, 22ppiinn))
LLii SShhiinn iinntteerrnnaatti
ioonnaall EEnntteerrpprriissee CCoorrppoorraattiioonn....
00333355CC22006655 ((6655WW,, 22ppiin
n
))
18. Bei der Benutzung Ihres Telefongerätes sollten Sie immer die
grundlegenden Sicherheitsmaßnahmen beachten, um das
Risiko von Feuer, Stromschlägen und Verletzungen zu
minimieren. Zu beachten sind u.a. folgende Punkte:
Benutzen Sie das Gerät nicht in der Nähe von Wasser,
wie zum Beispiel Badewanne, Waschbecken,
Spülbecken, Waschbottich, in feuchten Kellerräumen
oder in der Nähe von Schwimmbecken.
Benutzen Sie kein Telefon (ausgenommen schnurlose
Modelle) während eines Gewitters. Es besteht das
geringe Restrisiko eines Blitzschlages.
Benutzen Sie das Telefon nicht um ein Gasleck zu
9
melden, falls es sich in der Nähe des Lecks befindet.
Verwenden Sie nur die in diesem Benutzerhandbuch
angegebenen Stromkabel und Batterien. Werfen Sie die
Batterien nicht ins Feuer, sie könnten explodieren.
Informieren Sie sich über die örtlichen Bestimmungen
bezüglich der Entsorgung.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu
Wasser oder anderen Flüssigkeiten. Gießen Sie nie
Flüssigkeiten über das Netzteil.
20. Es besteht Explosionsgefahr, wenn der Akku nicht
ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur
durch einen Akku gleichen oder äquivalenten Typs, der vom
Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend
den Anweisungen des Herstellers. Entfernen Sie den Akku auf
keinen Fall bei eingeschaltetem notebook, da hierdurch Daten
verloren gehen könnten.
21. Der Netzeingabeanschluss dient als Hauptschalter des Geräts.
TThhiinnggss yyoouu mmuusstt rreemmeemmbbeerr bbeeffoorree wwoorrkkiinngg oonn
yyoouurr ccoom
mppuutteerr
Let your computer acclimate itself
Your notebook can easily stand temperature extremes but it doesn’t
like rapid changes in temperature, like going from the cold
outdoors to a warm office.
Rapid changes in temperature can cause water droplets to condense
inside your case, threatening to damage the electronic parts inside.
After receiving your notebook when it’s hot or cold outside, try not
to power up the computer immediately, let the computer adjust to
the room temperature gradually at least for three to four hours.
IIff yyoouurr ssyysstteemm aarrrriivveess iinn ccoolldd
wweeaatthheerr,, ddoo nnoott aappppl
lyy ppoowweerr ttoo tthhee ccoommppuutteerr oorr mmoonniittoorr
uunnttiill tthheeyy hhaavve
e
bbeeeenn aalllloowweedd ttoo ccoommee ttoo rroooomm
tteemmppeerraattuurree..
Heat, Cold, Humidity, and Glare
Find a suitable place for your computer that’s not too hot, too cold,
too dark, or too bright. Glare can make it hard to read the screen.
10
Try to avoid the computer components from being destroyed if
it is over heated, so try to allow plenty of room for air to
circulate around the case.
Do not block the ventilation opening.
Do not place your computer in direct sunlight.
Suitable place to work
Your computer will run well wherever you’re comfortable but
extremes of temperature and humidity can be challenging to your
system’s parts.
There are some things you can tolerate that the computer can’t –
things like static electricity, dust, water, steam and oil. In case you
decide to pull over for roadside computing, try to choose a clean,
comfortable work area for your system.
A lithium-ion battery pack will be available when you are traveling.
If you are running your system for the first time on battery power,
remove the battery from the package, install it into the system and
recharge the battery to fully prepare for service.
11
12
I
I
I
n
n
n
t
t
t
r
r
r
o
o
o
d
d
d
u
u
u
c
c
c
t
t
t
i
i
i
o
o
o
n
n
n
PPlleeaassee uussee tthhee aaddaapptteerr
rreeccoommmmeennddeedd iinn tthhiiss mmaannuuaall..
PPrreeppaarriinngg yyoouurr CCoommppuutteerr
Install the battery pack
Connecting the AC adapter
Opening the display panel
13
Turning on your computer
KKnnoowwiinngg yyoouurr CCoommppuutteerr
With the LCD screen open, you will see several features important
for operating your notebook computer.
TToo aavvooiidd ddaammaaggee ttoo tthhee
ddiissppllaayy ppaanneell::
11.. TTrryy nnoott tto
o ssllaamm tthhee ddiissppllaayy uuppoonn cclloossiinngg iitt..
22.. TTrryy nnoott ttoo p
p
llaaccee aannyy oobbjjeecctt oonn ttoopp wwhheenn iitt iiss cclloosseedd oorr
ooppeenn..
3
3.. BBee ssuurree tthhee ssyysstteemm iiss ttuurrnneedd ooffff oorr iinn ssuussppeenndd mm
ooddee
bbeeffoorree yyoouu cclloossee tthhee ddiissppllaayy ppaanneell..
Front View
PPiiccttuurree iiss oonnllyy ffoorr rreeffeerreennccee
Camera (Optional)
14
FFoorr bbeesstt ssyysstteemm ppeerrffoorrmmaannccee,, iimmaaggee
iiss ccoommpprreesssseedd wwh
heenn uussiinngg tthhee CCrraazzyy TTaallkk CCaammssuuiittee
PPRROO''ss pprreevviieeww ffuun
n
ccttiioonn.. PPhhoottooggrraapphhss ttaakkeenn wwiitthh
''ssnnaappsshhoott'' rreettaaiinn iit
tss oorriiggiinnaall qquuaalliittyy..
LCD Display
TThhiiss LLCCDD ppaanneell ccaann oonnllyy
ssuuppppoorrtt uupp ttoo aa mmaaxxiimmuumm ooppe
enniinngg ooff 112200--113355 ddeeggrreeeess,,
pplleeaassee ddoo nnoott ppuusshh iitt ffoor
r
cciibbllyy..
Keyboard
TThhee kkeeyybbooaarrdd ddiiffffeerrss ffoorr eeaacchh
tteerrrriittoorryy
Microphone
LED Status Indicator
System & Power Status Indicators
LED Graphic
Symbol
Indication
Blue light indicates the system is ON. Blinking
Blue light indicates the notebook is in suspend
mode.
Blue light indicates the WLAN is active.
Battery status
Charging – Blue light flashing
Full – Blue
Low – Red light flashing
15
Blue light indicates the hard drive and/or optical
drive is being accessed.
4 in 1 CardReader (SDHC/MS/MMC/MS pro
Memory Card)
Wireless Button
Power/Suspend Button
Press for 1~1.5 seconds to turn on the system.
Press and hold for at least 4 seconds to turn off the
system.
Press the power / suspend button again to return from
the suspend mode.
Persistent Blue light indicates the Power is ON
Touchpad
Touchpad Buttons
Left Views
16
CRT Port
HDMI Port
Enhanced USB 2.0 Port
Microphone/Audio Line-in Jack
Stereo Headphone Jack
DC In
Right View
USB 2.0 Port
Optical Drive
Modem Port (Optional)
AAllwwaayyss ddiissccoonnnneecctt aallll tteelleepphhoonnee
lliinneess ffrroomm tthhee wwaalll
l oouuttlleett bbeeffoorree sseerrvviicciinngg oorr
17
ddiissaasssseemmbblliinngg tthhiiss eeqquuiippmmeenntt.. TToo rreedduuccee tthhee rriisskk oof
f ffiirree
uussee oonnllyy NNoo.. 2266 AAWWGG oorr llaarrggeerr tteelleeccoommmmuunniiccaat
t
iioonn lliinnee
ccoorrdd..
Ethernet / LAN Port
WWhheenn uussiinngg aa LLAANN,, pplleeaassee uussee aann
EEMMII SShhiieellddiinngg CCaabblle
e ttoo mmiinniimmiizzee aann iinntteeffeerreennccee wwhheenn
ttrraannssmmiittttiinngg
Kensington Lock
BBoottttoomm VViieeww
Battery Lock
Battery Compartment
Battery Release Latch
18
19
G
G
G
e
e
e
t
t
t
t
t
t
i
i
i
n
n
n
g
g
g
S
S
S
t
t
t
a
a
a
r
r
r
t
t
t
e
e
e
d
d
d
CCoonnnneeccttiinngg ttoo aa PPoowweerr SSoouurrccee
Connecting the AC Adapter
A universal AC adapter is provided to supply your computer with
power and also charge the computer’s battery pack. The adapter’s
AC input voltage can range anywhere from 100 to 240 volts,
covering the standard voltages available in almost every country.
To connect the computer to an external power source:
DDoo nnoott uussee iinnffeerriioorr eexxtteennssiioonn
ccoorrddss aass tthhiiss mmaayy rrees
suulltt iinn ddaammaaggee ttoo yyoouurr nnootteebbooookk..
TThhee nnootteebbooookk ccoommees
s
wwiitthh iittss oowwnn AACC aaddaapptteerr.. DDoo nnoott
uussee aa ddiiffffeerreenntt aad
daapptteerr ttoo ppoowweerr tthhee ccoommppuutteerr aanndd
ootthheerr eelleeccttrriiccaall
ddeevviicceess..
20
Whenever possible, keep the AC adapter plugged into the
notebook and an electrical outlet to recharge the battery.
NNeevveerr ttuurrnn ooffff oorr rreesseett yyoouurr
nnootteebbooookk wwhhiillee tthhee hhaar
rdd ddiisskk iiss iinn uussee ssttaattuuss iiccoonn iiss lliitt;;
ddooiinngg ssoo ccaann
rreessuulltt iinn lloossss oorr ddeessttrruuccttiioonn ooff yyoouurr ddaattaa..
AAllwwaayys
s wwaaiitt aatt lleeaasstt 55 sseeccoonnddss aafftteerr ttuurrnniinngg ooffff yyoouurr
nno
o
tteebbooookk bbeeffoorree ttuurrnniinngg iitt bbaacckk oonn;; ttuurrnniinngg tthhee ppoowweer
r
oonn aanndd ooffff iinn rraappiidd ssuucccceessssiioonn ccaann ddaammaaggee tthhee
nnoot
t
eebbooookk’’ss eelleeccttrriiccaall cciirrccuuiittrryy..
TTuurrnniinngg OOnn YYoouurr NNootteebbooookk CCoommppuutteerr
Hold the button down for a second or two and release. The PowerOn Self Test (POST) runs automatically.
After the POST is completed, the computer reads the operating
system from the hard disk drive into computer memory (this is
commonly referred to as “booting” a computer). If your OS
(Operating System such as Windows Vista…. etc) is installed, it
should start automatically.
To turn the notebook off, save your work and close all open
applications, click on Start, then Shu
t Down and select Shut
down the computer and click "Y
es" or press the power button for
4-6 seconds.
OOppeerraattiinngg oonn BBaatttteerryy PPoowweerr
Your computer comes with a rechargeable battery pack that lets
you operate the computer without an external power source. When
the battery pack is fully charged, you can operate the computer
under the following conditions:
The battery pack initially has a full charge.
No peripheral devices are installed.
The disk/DVD-ROM drives run no more than 10% of the time
OOnnllyy uussee bbaatttteerriieess tthhaatt aarree
aapppprroovveedd bbyy aann aauutthhoorriiz
zeedd ddeeaalleerr.. AAllll bbaatttteerriieess aarree nnoott
tthhee ssaammee aanndd tthhe
e
rreeffoorree sshhoouulldd nnoott bbee ttrreeaatteedd aass ssuucchh..
UUssiinngg tthhee wwr
roonngg bbaatttteerryy ccoouulldd ccaauussee sseerriioouuss ddaammaaggee ttoo
21
yyoouurr ccoommppuutteerr aanndd yyoouurrsseellff tthhrroouugghh ttooxxiicc eemmiissssiioonnss.
.
22
DDaannggeerr ooff eexxpplloossiioonn iiff bbaatttteerryy
iiss iinnccoorrrreeccttllyy rreepplla
acceedd.. RReeppllaaccee oonnllyy wwiitthh ssaammee oorr
eeqquuiivvaalleenntt ttyyppee rreec
c
oommmmeennddeedd bbyy tthhee mmaannuuffaaccttuurreerr..
DDiissccaarrdd uusseedd bbaatttteerriie
ess aaccccoorrddiinngg ttoo tthhee mmaannuuffaaccttuurreerr’’ss
iinnssttrruuccttiioonnss oorr
llooccaall llaawwss..
EExxpplliissiioonnssggeeffaahhrr
bbeeii
uunnssaacchhggeerrnnaazzeenn AAuussttaauusscchh ddeerr B
Baatttteerriiee.. EErrssaattzz nnuurr
dduurrcchh ddeennsseellbbeenn ooddeerr eeiinneemm vvoom
m
HHeerrsstteelllleerr
eemmppffoohhlleenneemm aahhnnlliicchheenn TTyypp.. EEnnttssoorrgguunngg g
geebbrraauucchhtteerr
BBaatttteerriieenn nnaavvhh AAnnggaabbeenn ddeess HHeerrsstteelllleerrss.
.
IInnssttaalllliinngg aanndd RReemmoovviinngg tthhee BBaatttteerryy PPaacckk
To Install the Battery Pack:
To Remove the Battery Pack:
23
CChhaarrggiinngg tthhee BBaatttteerryy PPaacckk
The installed battery pack charges automatically any time the
computer is connected to the AC adapter and an external power
source. It is a good idea to occasionally discharge the battery pack
fully to preserve its operating performance.
24
25
U
U
U
s
s
s
i
i
i
n
n
n
g
g
g
t
t
t
h
h
h
e
e
e
N
N
N
o
o
o
t
t
t
e
e
e
b
b
b
o
o
o
o
o
o
k
k
k
C
C
C
o
o
o
m
m
m
p
p
p
u
u
u
t
t
t
e
e
e
r
r
r
AAddjjuussttiinngg tthhee LLCCDD SSccrreeeenn DDiissppllaayy
The LCD screen display can be adjusted by the following key
combinations.
Fn + F4 Changes Display Mode: LCD-only, CRT-only and LCD&CRT.
Fn + F7 Decrease the brightness level.
Fn + F8 Increase the brightness level.
LCD Care
LCD screens are delicate devices that need careful handling.
Please pay attention to the following precautions:
When you are not using the computer, keep the LCD screen
closed to protect it from dust.
If you need to clean your LCD screen, use a soft tissue to
gently wipe the LCD surface.
Do not put your fingers or sharp objects directly on the surface
and never spray cleaner directly onto the display.
Do not press on, or store any objects on the cover when it is
closed. Doing so may cause the LCD to break.
External CRT Display
You can hook up an external monitor through the 15-pin CRT
connector.
LCD only
CRT only
Simultaneous LCD&CRT
26
You can switch between these display configurations by pressing
the key combination [Fn] + [F4].
TThhee NNootteebbooookk’’ss HHoott KKeeyy CCoonnttrroollss
Action System Control
Fn + Esc Enable/Disable Bluetooth
Fn + F1 Enters Suspend Mode.
Fn + F2 Enters the Silent Mode.
Fn + F3 Mute/Unmute Audio/ PC beep to Output
Fn + F4 Changes Display Mode: LCD-only, CRT-only and
simultaneous LCD&CRT.
Fn + F5 Decrease the speaker volume.
Fn + F6 Increase the speaker volume.
Fn + F7 Decrease the brightness level.
Fn + F8 Increase the brightness level.
Fn + F9 Eable/Disable the Touchpad
Fn + F10 Enable/Disable the WLAN
Fn + F11 Enable/Disable the CCD camera
Fn + F12 Enable/Disable 3G application
OOnn SSccrreeeenn DDiissppllaayy ((OOSSDD))
OSD (On Screen Display) provides you an easy access to the
function key you normally use in executing some of the application
you would like to perform.
Other alternative is by executing the hot key combination we
provide which is imprinted on the upper portion of the keyboard.
After you activate the function key, the icon will be shown at the
upper right hand corner of your window screen.
Screen Display Icon
T/P On/Off
WebCam On/Off
Fn + F11
Silent Mode On/Off
Caps Locks On/Off
27
Num Locks On/Off
Scroll Locks On/Off
WLAN On/Off
Fn + F10
BlueTooth On/Off
3G On/Off
Fn + F12
Brightness
Fn + F7/F8
Mute On/Off
Fn + F3
Volume
Fn + F5/F6
OSD-Bar Icon
Caps Locks On
Num Locks On
Scroll Locks On
Silent Mode ON
Touchpad Off
WLAN On
RF On (By project)
Web Cam On
BlueTooth On
Mobile Broadband On
The OSD bar can be shown on the side bar or you can drag it
anywhere either on top (horizontally) or on the sides (vertically) of
your screen.
28
Horizontally
Top or Bottom
Vertically - Right or Left
LLiivvee PPoowweerr ((OOppttiioonnaall))
Live Power is a saving scheme technique that provides saving your
battery consumption by disabling some devices thus extending the
battery life.
Click on the Live Power icon
from the lower right bar
of your screen to open up the
Live Power Display.
The Live Power provides five modes according to the application
that you are executing:
Power saving mode: Provides the low consumption function,
suitable for low utilization ratio and suspend mode.
Normal mode: Provides for general work status.
High Performance mode : For highest efficiency condition.
DVD player mode: Provide for watching movie playback.
Dynamic mode: For system power utilization mode, switching
the CPU loading and battery life to appropriate mode.
Power
Saving
Normal
High
Performance
DVD
Player
Dynamic
Power off
LCD panel
Available Available Available *Available
(4)
Available
Long Bat
mode
Available Available Available Available Available
Power off
LCD panel
Available Available Available Not
available
Available
Power off
DVD drive
Available Available Available Not
available
Available
Power off
Voice device
Available Available Available Not
available
Available
29
Power off
LAN/WLAN/
HDMI/
Bluetooth
Available Available Available Available Available
Enable
advance
power
engine
Available Available Not
available
Available Not
available
Turbo mode
Not
available
Available Available Available Available
This Live Power application provides a super saving options if the
following items are selected:
Power Off LCD panel
Enable advance power saving engine
Power Saving Mode
LCD Brightness: Level 1
CPU Speed: Level 0
LCD Off: Idle after 5 minutes
HDD Off: Idle after 3 minutes
Sleep: Idle after 5 minutes
Hibernate: Idle after 10 minutes
30
Normal Mode
LCD Brightness: Level 5
CPU Speed: Maximum level
LCD Off: Idle after 15 minutes
HDD Off: Idle after 30 minutes
Sleep: Idle after 1 hour
Hibernate: Idle after 2 hours
High Performance Mode
LCD Brightness: Level 5
CPU Speed: Maximum level
LCD Off: Never
HDD Off: Never
Sleep: Never
Hibernate: Never
31
DVD Play Mode
LCD Brightness: Level 5
CPU Speed: Maximum level
LCD Off: Idle 4 hours
HDD Off: Idle after 4 hours
Sleep: Idle after 1 hour
Hibernate: 2 hours
Dynamic Switch Mode
32
Battery
life%
CPU Loading
High Middle plus Middle Low
50% up 30% up 4%up <4%
level 5 90%
up
High Performance
mode
High Performance
mode
High Performance
mode
Normal
mode
level 4 50%
up
High Performance
mode
High Performance
mode
Normal mode
Normal
mode
level 3 30%
up
High Performance
mode
Normal mode Normal mode
Power
Saving mode
level 2 15%
up
Normal mode Normal mode
Power Saving
mode
Power
Saving mode
level 1 6%
up
Normal mode
Power Saving
mode
Power Saving
mode
Power
Saving mode
level
0
less
than
5%
Power Saving
mode
Power Saving
mode
Power Saving
mode
Power
Saving mode
TThhee CCPPUU llooaadd iiss aauuttoommaattiiccaallllyy sshhoowwnn
oonn tthhee aapppplliiccaat
tiioonn ddiissppllaayy iinnddiiccaattiinngg tthhee ppoowweerr ssaavviinngg
mmooddee..
TThhee TToouucchhPPaadd
The touchpad is a rectangular electronic panel located just below
your keyboard. You can use the static-sensitive panel of the
touchpad and slit it to move the cursor. You can use the buttons
below the touchpad as left and right mouse buttons.
33
TouchPad Precautions
The TouchPad is a pressure sensitive device. Please take note of
the following precautions.
Make sure the TouchPad does not come into contact with dirt,
liquids or grease.
Do not touch the TouchPad if your fingers are dirty.
Do not rest heavy objects on the TouchPad or the TouchPad
buttons.
You can use the TouchPad with Microsoft Windows as well as
non-Windows applications.
CCoonnnneeccttiinngg aann EExxtteerrnnaall TTrraacckkiinngg DDeevviicceess
The system will only enable you to use one tracking device
whether it is an internal or external tracking device.
Data Storage and Retrieval
Data storage and retrieval are two of the most fundamental tasks
you will perform when working with your computer. The
Notebook is equipped with a hard disk drive (HDD). The HDD is
removable allowing for easy upgrades.
PPoowweerr SSaavviinngg MMooddeess
This section contains information on the notebook’s power system,
including the AC Adapter, the battery system, recharging the
battery, and tips for conserving battery power.
34
The power system is comprised of two parts, the AC Adapter and
the battery system. The AC Adapter converts AC power from a
wall outlet to the DC power required by the computer.
The Battery Power System
Before using the computer on battery power for the first time,
check the battery status icon on the Windows Toolbar to make sure
the battery is fully charged.
See Battery Status later in this section for a description and
explanation of the Windows Battery icon.
Charging the battery takes about 2.5 hours to charge when the
system is in off state. If possible, always charge the battery
completely.
IIff yyoouu uussee tthhee bbaatttteerryy ssoo ffrreeqquueennttllyy
tthhaatt iitt eexxcceeeed
d mmoorree tthhaann 2200 ttiimmeess bbyy ffuullllyy
ddiisscchhaarrggiinngg//cchhaarrggiinngg
iinn aa ssiinnggllee mmoonntthh aalloonnee,, wwee
rreeccoommmmeenndd yyoouu ttoo ppeerrffoor
rmm tthhee ““BBaatttteerryy CCaalliibbrraattiioonn””
pprroocceessss eevveerryy 33 mmoonntthhs
s
ttoo mmaaiinnttaaiinn tthhee bbaatttteerryy lliiffee..
PPlleeaassee rreeffeerr ttoo tthhe
e ttooppiicc oonn ““BBaatttteerryy CCaalliibbrraattiioonn””
ddeessccrriibbiinngg hhooww ttoo
ccaalliibbrraattee yyoouurr ssyysstteemm bbaatttteerryy
ddiissccuusssseedd oonn tthhee llaattt
teerr ppaarrtt ooff tthhiiss cchhaapptteerr..
IIff yyoouu ddiissccoovveerr tthhee bbaatttte
e
rryy lliiffee iiss ggeettttiinngg sshhoorrtteerr,, pplleeaassee
ppeerrffoorrmm tthhee ““BBaat
ttteerryy CCaalliibbrraattiioonn”” pprroocceessss iimmmmeeddiiaatteellyy..
RReemmoovviinngg tthhee BBaatttteerryy PPaacckk
To remove the battery pack from its compartment, please refer to
Chapter 3, Inserting and Removing the Battery Pack.
Preparing the Battery Pack for Use (Battery
Calibration)
Before using the battery pack for the first time, battery pack should
be calibrated in order to get accurate reporting of remaining battery
life status..
To calibrate the battery pack follows the instructions below:
1. Insert the battery into the battery compartment and turn on the
35
notebook. If the battery is completely without power go to the
next step. Otherwise, let the battery run down until the battery
low-low warning beeps are heard. The system will
automatically enter Suspend mode.
2. Turn the notebook off. Connect the AC adapter and let the
battery fully recharge. When the battery charge indicator
turns off, the battery is fully charged.
3. Turn On the notebook, let the battery run down until the
battery is in low-low state and you hear a warning beeps.
The system will automatically enter the Suspend mode. You
can now connect the AC adapter.
4. The battery pack is now calibrated properly.
In general, using the battery until the low-low battery-warning
indicator appears and fully recharges the battery each time (full
discharge/charge cycle) will ensure the accurate reporting of the
battery gauge status.
Automatic Battery Pack Charging Function
To charge the battery, while the battery pack is in the notebook,
plug the AC adapter into the notebook and an electrical outlet.
The charging time is approximately 3-4 hours when the notebook
is turned off and approximately 6-7 hours when the notebook is
turned on.
When the battery is fully charged, the battery charge indicator
becomes off.
IIff ssyysstteemm rruunnss aatt hheeaavvyy llooaaddiinngg oorr iinn
aa hhiigghh tteemmppeer
raattuurree eennvviirroonnmmeenntt,, tthhee bbaatttteerryy mmaayy nnoott bbee
ffuullllyy cch
h
aarrggeedd.. YYoouu nneeeedd ttoo ccoonnttiinnuuee ttoo cchhaarrggee iitt wwiitthh tthhee
A
ACC aaddaapptteerr pplluuggggeedd iinn uunnttiill tthhee cchhaarrggiinngg LLEEDD ttuurrnnss
ooffff.
.
Battery Status
Windows 7 has an applet in the Control Panel that will display an
icon in the Windows taskbar indicating when the notebook is
running on battery power or is attached to the AC adapter.
This applet also displays a meter that indicates how much charge is
remaining in the battery.
36
Battery Low Warning
When the pack initially reaches the “Battery Low” state
approximately 7 ~ 10 minutes of the usable battery life is left.
You will hear an audible beep signal every 15 seconds alerting you
to the “Battery Low” status. When the battery power reaches the
“Battery Low Low” status the beeping sound will accelerate.
Your battery now has 1 ~ 2 minutes of battery charge remaining.
You must save your data or connect AC power immediately;
otherwise, you may lose your data.
Sound Meaning
Continuous
beeping every 5
seconds
Battery Low: Indicates that there is 7 to 10 minutes
charge remaining.
Beeping
accelerates
Battery Low Low: Indicates that there is 1 to 2
minutes of battery charge remaining. Save your
work and turn off the notebook, or connect the AC
adapter.
When there is only one minute of battery charge remaining, the
notebook will suspend to the HDD and power off. You should
connect AC power and resume to save your work.
DDaannggeerr ooff eexxpplloossiioonn iiff bbaatttteerryy
iiss iinnccoorrrreeccttllyy rreepplla
acceedd.. RReeppllaaccee oonnllyy wwiitthh tthhee ssaammee oorr
eeqquuiivvaalleenntt ttyyppe
e
rreeccoommmmeennddeedd bbyy tthhee mmaannuuffaaccttuurreerr..
DDiissppoossee ooff uusseedd
bbaatttteerriieess aaccccoorrddiinngg ttoo tthhee
mmaannuuffaaccttuurreerr''ss iinnssttrruucct
t
iioonnss.. NNeevveerr rreemmoovvee tthhee bbaatttteerryy
ppaacckk wwhhiillee tthhee ppoowwe
err iiss oonn aass tthhiiss mmaayy rreessuulltt iinn ddaattaa
lloossss wwhheenn tthhee s
s
yysstteemm lloosseess ppoowweerr..
RReesseettttiinngg tthhee SSyysstteemm
After installing a software application package, you may be
prompted to reset the system to load the changed operating
environment.
To reset the system, or “reboot,” press the [Ctrl]+[Alt]+[Delete]
keys simultaneously. This is known as “warm boot.” This key
combination acts as “software” reset switch when you encounter
hardware or software problems, which lock up the notebook.
37
If this key combination does not shut down the notebook, you can
reset the notebook by using the notebook’s power button. Should
the notebook lock up for some reason, pressing this button powers
the notebook off.
AAddjjuussttiinngg tthhee BBrriigghhttnneessss
To adjust the brightness on the LCD screen, press and hold down
the [Fn] key in the lower left hand corner of the keyboard and
press the [F8] key to increase the brightness or [F7] to decrease the
brightness.
38
UUssiinngg tthhee WWiinnddoowwss
Help Windows
For Windows 7 help,
click Start Help
and Support icon will
open the dialog box.
Desktop
Desktop may vary differently on the software installed in your
notebook with different or additional shortcuts.
39
Recycle Bin
Used for storing deleted files in case you want to recover and save
it in your system. The files will only be deleted from the Recycle
Bin permanently only if you empty it by right clicking your mouse
and select the “Empty Recycle Bin”.
Start Button
Allows easy access to all Windows programs.
40
The Start menu allows you to adapt and show the programs used
most frequently. If you wish to keep an item, right click the item
and click Pin to Start menu.
Log Off will enable the current user to log off and allows a new
user to log on.
Turn Off Computer allows you to shut down, restart, and Stand
by modes for power saving purposes.
Taskbar
When you open a program, its icon is displayed at the taskbar for
you to conveniently move between programs by clicking the
relevant button.
To add or remove toolbars from the taskbar: right click an empty
spot on the taskbar, select Toolbars choose the toolbar you
want to add.
Notification
The icons that appear here are for quick access to some programs
and computer functions that you frequently used. To prevent
Windows 7 from hiding icons:
41
From an empty spot on the Taskbar, right click your mouse and
select the Properties, remove the checked mark on the Auto-hide
the taskbar.
CCoonnttrrooll PPaanneell
It is in this area that you can change how Windows looks and
works. Click Start Control Panel dialog box. There are two
interfaces – Classic View.
42
43
44
I
I
I
n
n
n
t
t
t
e
e
e
r
r
r
n
n
n
e
e
e
t
t
t
C
C
C
o
o
o
n
n
n
n
n
n
e
e
e
c
c
c
t
t
t
i
i
i
o
o
o
n
n
n
UUssiinngg aa mmooddeemm ffoorr CCoonnnneeccttiioonn ttoo IInntteerrnneett
((ooppttiioonnaall)
)
45
FFoorr mmoorree ddeettaaiill oonn tthhee NNeettwwoorrkk kkeeyy,,
pplleeaassee rreeffeerr tto
o yyoouurr llooccaall IISSPP pprroovviiddeerr aanndd ffoollllooww tthhee
pprroocceedduurrees
s
ddeessccrriibbee iinn tthhee ““IISSPP IInnssttaallllaattiioonn GGuuiiddee”” ttoo
pprroocceee
edd wwiitthh tthhee iinnssttaallllaattiioonn..
46
UUssiinngg WWiirreelleessss LLAANN NNeettwwoorrkk ffoorr CCoonnnneeccttiioonn
ttoo IInntteerrn
neett
47
48
R
R
R
u
u
u
n
n
n
n
n
n
i
i
i
n
n
n
g
g
g
B
B
B
I
I
I
O
O
O
S
S
S
S
S
S
e
e
e
t
t
t
u
u
u
p
p
p
The Setup Utility is a hardware configuration program built into
your computer’s BIOS (Basic Input/Output System). It runs and
maintains a variety of hardware functions. It is menu-driven
software, which allows you to easily configure and change the
settings.
The BIOS contains manufacture’s default settings for the
computer’s standard operations. However, there are occasions
when you may be required to modify the default settings in the
BIOS.
The BIOS allows you to set up passwords to limit access to users.
This is an important feature because a great deal of vital
information is carried within the computer nowadays.
Unauthorized access can be prevented. Later in this chapter, you
will learn how to use this security feature.
EEnntteerriinngg tthhee BBIIOOSS SSeettuupp SSccrreeeenn
First turn on the power. When the BIOS performs the POST
(Power-On Self Test), press F2 key quickly to activate the BIOS
Setup Utility.
YYoouu mmaayy nneeeedd ttoo pprreessss FF22 kkeeyy ffaaiirrllyy
qquuiicckkllyy.. OOnnccee t
thhee ssyysstteemm bbeeggiinnss ttoo llooaadd WWiinnddoowwss,, yyoouu
mmaayy hhaavvee ttoo
rreettrryy bbyy ccyyccllee--ppoowweerr oonn aaggaaiinn
LLeeaavviinngg tthhee BBIIOOSS SSeettuupp SSccrreeeenn
When you have finished modifying the BIOS settings, exit the
BIOS. It takes a few seconds to record changes in the CMOS.
49
BBIIOOSS AAccttiioonn KKeeyyss
Function Key Command Description
ESC Exit
Leaves a sub-menu to return to the
previous menu OR exits the BIOS setup
while saving changes.
Enter Go to Sub Screen Shows the Sub Menu
F1 General Help Shows the Help Screen
F9 Default Set to default
F10 Save and Exit
Saves changes and reboots the
computer.
<Tab> Select a field Selects the next field.
Select an item Selects the next upper item.
Select an item Selects the next lower item.
Select a menu Selects the right item
Select a menu Selects the left item
- Lower value Selects the lower value within a field.
+ Higher value Selects the higher value within a field.
MMooddiiffyyiinngg tthhee BBIIOOSS SSeettttiinnggss
The BIOS setup main menu is subdivided into sub-menus. Each
menu item is described in this section.
Info Setup
50
Main Setup
Under this menu, you may change time/date and view basic
processor and system memory information.
51
Advanced
52
Security
Boot Setup
53
Exit Setup
54
55
V
V
V
G
G
G
A
A
A
U
U
U
t
t
t
i
i
i
l
l
l
i
i
i
t
t
t
i
i
i
e
e
e
s
s
s
You can click the touchpad or mouse right button and select the
“Personalize” item.
56
Adjust Resolution
57
Calibrate Color
Adjust Display Setting
58
Connect to a Projector
Adjust Clear Type Text
59
60
3
3
3
G
G
G
C
C
C
o
o
o
n
n
n
n
n
n
e
e
e
c
c
c
t
t
t
i
i
i
o
o
o
n
n
n
3G is the third generation of mobile phone standards and
technology. 3G enable users a wide range of more advanced
service while achieving greater network capacity through improved
spectral efficiency.
Press Fn + F12 to run the 3G application. Procedures in installing
61
the application
Insert the SIM card into the SIM slot.
Execute the application by pressing the Mobile Partner icon
From the Mobile Partner display window, click on the “Tools”
item
Select the “Options”.
62
Double click on the “Profile Management” and click on the
“New” tab
Click on the “OK” tab.
63
On the next window, click on the “Connect” tab.
The HSPA is successfully connected
64
65
T
T
T
r
r
r
o
o
o
u
u
u
b
b
b
l
l
l
e
e
e
s
s
s
h
h
h
o
o
o
o
o
o
t
t
t
i
i
i
n
n
n
g
g
g
Your computer has been fully tested and complies with the system
specifications before shipping. However, incorrect operations
and/or mishandling may cause problems.
This chapter provides a reference for identifying and correcting
common hardware and software problems that you may encounter.
When you encounter a problem, you should first try to go through
the recommendations in this chapter. Instead of returning the
computer and waiting for repair, you may easily solve the
problems by considering the following scenarios and possible
solutions. If the error continues, contact your reseller for service
information.
Before taking further actions, consider the following suggestions:
Check to see if the problem persists when all the external
devices are removed.
Check to see that the Blue light indicator on the AC adapter is
lit.
Check to see the power cord is properly plugged to the wall
outlet and to the computer.
Check to see the power indicator of the computer is on.
Check to see if your keyboard is operational by pressing and
holding any key.
Check for any incorrect or loose cable connections. Make
sure the latches on the connectors latch securely on to the
receptor end.
Be sure you have not performed an incorrect setting on the
hardware devices in the BIOS Setup utility. A faulty setting
may cause the system to misbehave. If you are not sure of
the changes you made, try to restore all the settings to factory
defaults.
66
Be sure all the device drivers are installed properly. For
example, without the audio driver properly installed, the
speakers and microphone will not work.
If external devices such as USB camera, scanner, printer do
not function correctly when connected to the system, it is
usually the device’s own problem. Consult the device’s
manufacturer first.
Some software programs, which have not gone through
rigorous coding and testing, may cause problems during your
routine use. Consult the software vendor for problem solving.
Legacy peripheral are not plug-and-play capable. You need to
restart the system with these devices powered up and
connected first.
Be sure to go to BIOS SETUP and load DEFAULT SETTING
after BIOS re-flash.
AAuuddiioo PPrroobblleemmss
No speaker output
Software volume control is turned down in Microsoft Sound
System or is muted. Double-click the speaker icon on the
lower right corner of the taskbar to see if the speaker has
been muted or turned down all the way.
Most audio problems are software-related. If your computer
worked before, chances are software may have been set
incorrectly.
Go to [Start > Settings > Control Panel] and double-click the
Sounds and Audio Devices icon. In the Audio page, make
sure that the audio codec mentioned in the spec is the default
playback device.
Sound cannot be recorded
You will need to plug-in an external microphone to the
microphone connector to record sound.
Double-click the speaker icon on the lower right corner of the
taskbar to see if the microphone has been muted.
Click Options and select Properties.
Select Recording and click the OK button.
After Click OK button, the recording volume control
panel will appear.
67
Go to [Start > Settings > Control Panel] and double-click the
Multimedia icon (or Sounds and Audio Devices icon). In the
Volume or Audio page, make sure that the audio codec
mentioned in the spec is the default recording device.
HHaarrdd DDiisskk PPrroobblleemmss
The hard disk drive does not work or is not
recognizable
If you had just performed a hard disk upgrade, make sure the
hard drive connector is not loose and the hard disk drive is
also correctly seated. Remove it and reinsert it firmly, and
restart your PC.
The new HDD may need to be partitioned and reformatted.
O/S and drivers will need to be re-installed as well.
Check the hard disk indicator LED. When you access a file,
the LED lamp should light up momentarily.
The new HDD may be defective or is not compatible.
If your computer has been subjected to static electricity or
physical shock, you may have damaged the disk drive.
The hard drive is making abnormal whining noises
You should back up your files as soon as possible.
Make sure the source of noise is indeed from the hard drive
and not the fan or other devices.
The hard disk drive has reached its capacity
Run Disk Cleanup utility in Windows. [Start > All Programs >
Accessories > System Tools > Disk Cleanup] The system will
prompt you for what to do.
Archive files or programs that you had no longer used by
moving them to an alternative storage medium (floppy disk,
optical record-able disk, etc.) or uninstall programs that no
longer use.
68
Many browsers store files in the hard drive as a cache to
speed up the performance. Check the program’s Online Help
for instructions on decreasing the cache size or on removing
temporary Internet files.
Empty the Recycle Bin to create more disk space. When you
delete files, Windows saves them to the Recycle Bin.
The hard disk takes longer to read a file
If you have been using the drive for a period, the files may be
fragmented. Go to [Start > Programs > Accessories > System
Tools > Disk Defragmenter] to perform a disk defragmentation.
This operation may take a while.
Interrupt requests or problems with other hardware devices
may have occupied the CPU and therefore slows down the
system performance.
The files are corrupted
Run the Error-checking utility in Windows to check the HDD.
Double-click My Computer. Right-click C: and select
Properties. Click Check Now in Error-checking in Tools.
DDiissppllaayy PPrroobblleemmss
The display panel is blank when the system is
turned on
Make sure the computer is not in the Standby or Hibernate
suspend modes. The display is turned off to conserve energy
in these modes.
The screen is difficult to read
The display resolution should at least be set to at least 1366 x
768 for optimal viewing.
Go to [Start > Settings > Control Panel] and double-click
the Display icon.
Under the Settings page, set screen resolution to at
least 1366 x 768.
The screen flickers
It is normal if the display flickers a few times during shutting
69
down or powering up.
KKeeyybbooaarrdd aanndd MMoouussee PPrroobblleemmss
The built-in touch pad performs erratically
Make sure there is no excess perspiration or humidity on your
hand when using the touch pad. Keep the surface of the
touch pad clean and dry.
Do not rest your palm or wrist on the surface of the touchpad
while typing or using the touch pad.
The built-in keyboard accepts no input
Please try to make sure the system doesn’t hang up and is
still working.
The characters on the screen repeat while I type
You may be holding the keys down too long while you’re
typing.
Keep the keyboard clean. Dust and dirt under the keys could
cause them to stick.
Configure the keyboard to wait longer before the auto repeat
feature starts. To adjust this feature, Go to [Start > Settings >
Control Panel], and double-click the Keyboard icon.
A dialogue box shows up with the adjustable settings for the
keyboard.
CCMMOOSS BBaatttteerryy PPrroobblleemm
A message “CMOS Checksum Failure” displays
during the booting process or the time (clock)
resets when booting
Try to reboot the system.
If the message “CMOS Checksum Failure” appears during the
booting procedure even after rebooting, it may indicate failure
of the CMOS battery. If so, you need to replace the battery.
This battery normally lasts two to five years. The battery is of
type CR2032 (3V). Send the battery to the dealer for
replacement.
70
MMeemmoorryy PPrroobblleemmss
The POST does not show an increased memory
capacity when you have already installed additional
memory
Certain brands of memory module may not be compatible with
your system. You should ask your vendor for a list of
compatible DIMM.
The memory module may be defective.
The O/S issues an insufficient memory error
message during operation
This is often a software or Windows-related problem. A
program is draining the memory resources.
Close the application programs you’re not using and restart
the system.
PPCC CCaarrdd PPrroobblleemmss
SSoommee ssyysstteemm mmaayy nnoott hhaavvee tthhee PPCC
CCaarrdd SSlloott ooppttiioonn..
PC Cards do not function
Make sure you have properly installed the driver for the card.
Consult the card’s manual or contact the vendor for trouble-
shooting.
The PC card cannot be recognized
Make sure the card is fully inserted; the outer end of the card
should be even with the edge of the computer.
Remove and insert the PC card again.
Make sure there is no IRQ conflict with the card. See
Windows on-line help for solving IRQ conflicts.
Reboot the computer and see if the problem persists.
The card may be defective. Try the card on another system, if
possible.
71
Windows crashes or freezes when you remove the
PC card
Make sure you have <Stop> the PC card before removing it.
Double-click the Safely Remove Hardware icon at the lower
right corner of the task bar and select the card you wish to
stop. When you click <Close>, in few seconds Windows will
prompt you to remove the card.
PPeerrffoorrmmaannccee PPrroobblleemmss
The computer becomes hot
In a 35
o
C environment, the certain areas of the computer’s
back case are expected to reach 50 degrees.
Make sure the air vents are not blocked.
If the fan does not seem to be working at high temperature
(50 degrees Celsius and up), contact the service center.
Certain programs that are processor-intensive may increase
the computer temperature to a degree where the computer
automatically slows down its CPU clock to protect itself from
thermal damage.
The program appears stopped or runs very slowly
Press CTRL+ALT+DEL to see if an application is still
responding.
Restart the computer.
This may be normal for Windows when it is processing other
CPU-intensive programs in the background or when the
system is accessing slow-speed devices such the floppy disk
drive.
You may be running too many applications. Try to close some
applications or increase system memory for higher
performance.
The processor may have been overheated due to the
system’s inability to regulate its internal heat. Make sure the
computer’s ventilation grills are not blocked.
72
UUSSBB22..00 PPrroobblleemmss
The USB device does not work
Check the settings in the Windows Control Panel.
Make sure you have installed the necessary device drivers.
Contact the device vendor for additional support.
Unable to use the External USB Device
Detach the external device; insert it into the Enhanced USB
port. Separate the cable with the equipment; first insert the
wire into the port, then connect the device with the cable that
is inserted into the Enhanced USB port.
Unable to Recognize the External USB Device
Please make sure power cable is inserted into the Enhanced
USB port, if it is inserted then follow the normal procedures in
disconnecting the device; power cable will not be disconnect,
connect back the signal cab le.
73
74
S
S
S
p
p
p
e
e
e
c
c
c
i
i
i
f
f
f
i
i
i
c
c
c
a
a
a
t
t
t
i
i
i
o
o
o
n
n
n
O.S.
Supports Windows 7 Home Premium
CPU
Intel Arrandale MCP Processor support, Dual core ,32nm, 3
MB L3 Cache,1066MHz, TDP: 35 W
Memory
DDRIII 800/1066/1333 MHz support
RAM socket * 2
System DDRIII up to 4 GB total, depends on module
availability
Core Logic
Intel Calpella Arrandale + Ibex Peak(HM55)
Audio Codec
Realtek ALC269Q-GR
Card reader (4 in 1)
Support SDHC/MS/MMC/MS pro Memory Card
USB2.0 interface
75
LAN Controller
Supports 10/100 Mb/Sec (8103EL-VB) or 10/100/1000Mb/Sec
(8111DL).
PCI-E interface
Wireless LAN
PCI-E interface
Half-Card size
IEEE 802.11 B/G w/Single antenna
IEEE 802.11n compatible (WO WiFi logo)
Camera CCD (Optional)
Support 1.3M / 1.3M HD / 2.0M Camera
Keyboard
339.7mm length skirt type KB
US / UK 100 Keys KB support
Pointing Device
PS2 Touch Pad with 2 buttons
Support gesture function (optional)
LCD
15.6” HD (high definition), resolution 1366 x 768
Support 16:9 5.5mm thickness LED panel
Battery Pack
4 cells, 14.4V/2200mAh/LG (4S1P)
Celxpert I58-4S2200-C1L3
4 cells, 14.6V/2200mAh/ATL (4S1P)
Getac I58-4S2200-M1A2
8 cells, 14.4V/4400mAh/LG (4S2P)
Celxpert I58-4S4400-C1L3
76
8 cells, 14.6V/4400mAh/ATL(4S2P)
Getac I58-4S4400-M1A2
AC-Adapter
Automatics Voltage adjustment between 100 and 240VAC
50/60Hz, LV5-19V / LV4-20V , 65 Watts., 2 pin / 3pin
Lite-On Technology Corporation
PA-1650-65 (65W, 2pin)
Delta Electronic, Inc.
ADP-65JH AB (65W, 2pin)
ADP-65JH BB (65W, 3pin)
ADP-65HB AD (65W, 2pin)
Li Shin international Enterprise Corporation..
0335C2065 (65W, 2pin)
Speaker/MIC
Build-in 2 speakers
Internal Microphone support
BIOS
Supports PnP, ACPI 3.0
Support external USB flash memory card boot up.
Be with Phoenix BIOS and 2MB flash ROM
Power Management (default: Silent mode)
“Smart Power II” Power Management
Physical Outline
Dimension:
383.8mm x 248mm x 37.2~46 (w/ rubber foot, w/ ODD)
383.8mm x 248mm x 31.1~42 (w/o rubber foot, w/ ODD)
Weight
2.3Kg w/ 4 cell battery
2.5Kg w/ 8 cell battery
77
EMI
CE
RF
CE, R&TTE report/document
Safety
CB/CCC
Loading...
