H110T-SI01
Intel® Skylake LGA1151 SoC
USER’S GUIDE
Version:1.0
®
H110T-SI01 USER MANUAL
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
the author.
Version 1.0
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof
and specifically disclaims any implied warranties of merchantability or fitness for
any particular purpose. The manufacturer reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation
of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, MS-DOS and Windows are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by the system’s
manufacturer could void the user’s authority to operate the equipment.
ii
H110T-SI01 USER MANUAL
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interferencecausing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
The manual consists of the following:
Describes features of the
motherboard.
page 1
Describes installation of
motherboard components.
page 7
page 27
page 51
Installing the Motherboard
Introducing the Motherboard
Provides information on using the BIOS Setup Utility.
Describes the motherboard
software.
Limits and methods of mesurement of radio disturbance characteristics of information technology equipment
EN 55022
EN 61000-3-2
Disturbances in supply systems caused
EN 61000-3-3
Disturbances in supply systems caused by household appliances and similar electrical equipment “ Voltage fluctuations”
EN 55024
Information technology equipment-Immunity characteristicsLimits and methods of measurement
EN 60950
Safety for information technology equipment including electrical business equipment
CE marking
About the Manual
This device is in conformity with the following EC/EMC directives:
Chapter 4
Chapter 1
Chapter 2
Chapter 3
Using BIOS
Using the Motherboard Software
Chapter 5
Trouble Shooting
Provides basic trouble shooting tips.
page 55
iii
H110T-SI01 USER MANUAL
Chapter 2 7
Installing the Motherboard 7
Safety Precautions.............................................................................7
Installing the Motherboard in a Chassis......................................7
Checking Jumper Settings...........................................................8
Installing Hardware..................................................................10
Installing the Processor...........................................................10
Installing the CPU Cooler.........................................................12
Installing Memory Modules....................................................13
Installing Add-on Cards...........................................................14
Connecting Optional Devices..................................................16
Installing a Hard Disk Drive/Optical Disk Drive......................23
Connecting Case Components.......................................................24
TABLE OF CONTENTS
Preface i
Chapter 1 1
Introducing the Motherboard 1
Introduction...................................................................................1
Pakage Contents............................................................................1
Specifications................................................................................2
Motherboard Components..........................................................4
I/O Ports..............................................................................................6
Chapter 3 27
Using BIOS 27
About the Setup Utility........................ .......................................27
The Standard Configuration........................ ...........................27
Entering the Setup Utility.......................................................27
Resetting the Default CMOS Values.....................................28
Using BIOS........................................................................................28
BIOS Navigation Keys..............................................................29
Main Menu.............................................................................30
Advanced Menu......................................................................31
Chipset Menu..........................................................................43
Tweak Menu...........................................................................46
Security Menu.........................................................................47
Boot Menu..............................................................................48
Exit Menu................................................................................49
Updating the BIOS.............................................................................50
iv
H110T-SI01 USER MANUAL
Chapter 4 51
Using the Motherboard Software 51
Auto-installing under Windows 7/8.............................................51
Running Setup.........................................................................51
Manual Installation..........................................................................53
Chapter 5 55
Trouble Shooting 55
Start up problems during assembly..............................................55
Start up problems after prolong use............................................56
Maintenance and care tips..............................................................56
Basic Troubleshooting Flowchart...................................................57
1
H110T-SI01 USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the H110T-SI01 motherboard. This motherboard is a high
performance, enhanced function motherboard designed to support the LGA1151
socket for Intel® Skylake processor.
This motherboard is based on Intel® H110 Express Chipset for best desktop platform
solution. It supports up to 32 GB of system memory with dual channel DDR4 2400
MHz SO-DIMM. Two M.2 slots are for extending usage.
It integrates USB 2.0 ports and USB 3.0 interface, supporting up to three USB 2.0
ports (one 5-pin USB 2.0 header supports additional one USB 2.0 port and two USB
2.0 ports at the rear panel) and four USB 3.0 ports (two USB 3.0 ports at the rear panel
and one USB 3.0 header supports additonal two USB 3.0 ports).
This motherboard is equipped with advanced full set of I/O ports in the rear panel,
including one 19V DC_IN port, one HDMI in port (For All-In-One Specification), one
HDMI out port, two USB 2.0 ports, two USB 3.0 ports, one RJ45 LAN connector, and
audio jacks for line-out and mircophone.
In addition, this motherboard supports two SATA 6Gb/s connectors for storage
expansion.
Your motherboard package ships with the following items:
Package Contents
H110T-SI01 Motherboard
QIG
DVD
I/O Shield
1 SATA Cable and 1 SATA/Power Cable
Accessories may vary, please refer to actual goods you purchase.
Chapter 1
2
H110T-SI01 USER MANUAL
Specifications
• Dual-channel DDR4 memory architecture
• 2 x 260-pin DDR4 SO-DIMM sockets support up to 32 GB
• Supports DDR4 2400 MHz DDR4 SDRAM
Memory
• 2 x M.2 slots
- 1 x type 2230 for wifi/BT
- 1 x type 2280 for SSD
• Supported by Intel® H110 Express Chipset
- 2 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x 19V DC_IN port
• 1 x HDMI in port (For All-In-One Specification)
• 1 x HDMI out port
• 2 x USB 2.0 ports
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x Audio port (1 x line-out, 1 x Microphone)
Rear Panel I/O
LAN • Realtek RTL8111H
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Realtek ALC662-VD0-GR 48P
- 6 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio
CPU
• LGA1151 socket for Intel® Skylake processor
• Supports CPU up to 65W TDP
• 1 x 4-pin CPU_FAN connector with smart fan function
• 1 x 4-pin SYS_FAN connector with smart fan function
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 1 x 10-pin USB 2.0 header (black) supports card reader and
camera
• 1 x 5-pin USB 2.0 header (yellow) supports touch panel or other
2.0 device
• 2 x Serial SATA 6Gb/s connectors
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x SATA power connector
• 1 x Consumer infrared header (CIR)
• 1 x Digital microphone header (For All-In-One Specification)
• 1 x 2 channel audio speaker header (For All-In-One Specification)
• 1 x LVDS connetor (For All-In-One Specification)
• 1 x LVDS brightness switch header (For All-In-One Specification)
• 1 x Debug Card header (LDC)
• 1 x LCD panel select jumper (For All-In-One Specification)
Internal I/O
Connectors &
Headers
• Intel® H110 Chipset
Chipset
3
H110T-SI01 USER MANUAL
Chapter 1
• AMI BIOS with 64Mb SPI Flash ROM
- Supports Plug and Play
- Supports ACPI & DMI
- Supports STR (S3) /STD (S4)
- Supports Hardware monitor
- Audio, LAN, can be disabled in BIOS
- F7 hot key for boot up devices option
- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)
- Add the function of copying BIOS parameters to USB flash
drive
System BIOS
Form Factor • Thin Mini ITX Size, 170mm x 170mm
Chapter 1
4
H110T-SI01 USER MANUAL
Motherboard Components
5
H110T-SI01 USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA1151 socket for Intel® Skylake Processor
2. LDC Debug Card header
3. DMIC Digital microphone header (For All-In-One Specification)
4. SPKR 2 Channels audio speaker header (For All-In-One Specification)
5. F_AUDIO Front panel audio header
6. NGFF Type 2230 for wifi/BT
7. NGFF1 Type 2280 for SSD
8. SO-DIMM1~2 260-pin DDR4 SDRAM SO-DIMMs
9. CLR_CMOS Clear CMOS jumper
10. USB3F Front panel USB 3.0 header
11. USB_TP USB 2.0 header for touch panel or other USB 2.0 device
12. SATA1~2 Serial ATA 6Gb/s connectors
13. SYS_FAN 4-pin system cooling fan connector with smart fan function
14. CPU_FAN 4-pin CPU cooling fan connector with smart fan function
15. CIR Consumer infrared header
16. F_PANEL Front panel switch/LED header
17. MON_SW LVDS brightness switch header (For All-In-One Specification)
18. SATA_PWR SATA power connector
19. LVDS LVDS connector (For All-In-One Specification)
20. DISP_BRT LVDS brightness control header (For All-In-One Specification)
21. LCD_SEL LCD panel select jumper (For All-In-One Specification)
22. USB_CR_CAM 10-pin USB 2.0 header supports card reader and camera
Chapter 1
6
H110T-SI01 USER MANUAL
I/O Ports
1. 19V DC_IN Port
Connect the DC_IN port to the power adapter.
2. HDMI_IN Port (For All-In-One Specification)
You can connect the HDMI output of other computer or other HDMI source to the
HDMI_IN port.
3. HDMI_OUT Port
You can connect the display device to the HDMI_OUT port.
4. USB 2.0 Ports
Use the USB 2.0 ports to connect USB 2.0 devices.
5. USB 3.0 Ports
Use the USB 3.0 ports to connect USB 3.0 devices.
6. LAN Port
Connect an RJ-45 jack to the LAN port to connect your computer to the Network.
7. Line-out (lime)
It is used to connect to speakers or headphones.
8. Microphone (pink)
It is used to connect to a microphone.
LAN LED Status Description
OFF No da ta
Orange blinking Active
OFF No link
Green Link
Activity LED
Link LED
Link LED
LAN Port
PC HDMI_IN port LCD_MODE button pulse
Power ON Un-plugged PC
LCD off
Power OFF Plugged HDMI
LCD off
Power ON Plugged PC
HDMI
LCD off
Power OFF Un-plugged LCD off
1. Please press button to switch the mode manually, it will not be
automatically switched when inserting the HDMI cable.
2. When HDMI_IN is in use, front panel audio header will be invalid.
Chapter 2
7
H110T-SI01 USER MANUAL
Chapter 2
Installing the Motherboard
2-1. Safety Precautions
2-2. Installing the motherboard in a Chassis
This motherboard carries a Thin Mini ITX form factor of 170 x 170 mm. Choose a
chassis that accommodates this form factor. Make sure that the I/O template in the
chassis matches the I/O ports installed on the rear edge of the motherboard. Most
system chassis have mounting brackets installed in the chassis, which corresponds
to the holes in the motherboard. Place the motherboard over the mounting brackets and secure the motherboard onto the mounting brackets with screws.
Follow these safety precautions when installing the motherboard:
• Wear a grounding strap attached to a grounded device to avoid damage
from static electricity.
• Discharge static electricity by touching the metal case of a safely grounded
object before working on the motherboard.
• Leave components in the static-proof bags.
• Always remove the AC power by unplugging the power cord from the power
outlet before installing or removing the motherboard or other hardware
components.
Do not over-tighten the screws as this can stress the motherboard.
Chapter 2
8
H110T-SI01 USER MANUAL
This section explains how to set jumpers for correct configuration of the
motherboard.
2-3. Checking Jumper Settings
1. LCD_SEL: LCD panel select jumper (For All-In-One Specification)
1.When your panel connects to LVDS, please check LCD_SEL header setting
first.
2.Due to the differences of the panel parameters, please follow the above
illustration to place the jumper caps.
Chapter 2
9
H110T-SI01 USER MANUAL
To avoid the system instability after clearing CMOS, we recommend users to
enter the main BIOS setting page to “Load Default Settings” and then “Save
and Exit Setup”.
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
2. CLR_CMOS: Clear CMOS jumper
Chapter 2
10
H110T-SI01 USER MANUAL
2-4. Installing Hardware
• This motherboard has an LGA1151 socket.
• When choosing a processor, consider the performance requirements of
the system. Performance is based on the processor design, the clock speed
and system bus frequency of the processor, and the quantity of internal
cache memory and external cache memory.
• You may be able to change the settings in the system Setup Utility. We
strongly recommend you do not over-clock processor or other
components to run faster than their rated speed.
• The following illustration shows CPU installation components.
A. Press the hook of lever down with your thumb and pull it to the right
side to release it from retention tab.
B. Lift the tail of the load lever and rotate the load plate to fully open
position.
C. Grasp the edge of the package substrate. Make sure pin 1 indicator
is on your bottom-left side. Aim at the socket and place the package
carefully into the socket by purely vertical motion.
2-4-1. Installing the Processor
Chapter 2
11
H110T-SI01 USER MANUAL
D. Rotate the load plate onto the package IHS (Intergraded Heat
Spreader). Engage the load lever while pressing down lightly onto the
load plate. Secure the load lever with the hook under retention tab. Then
the cover will flick automatically.
Please save and replace the cover onto the CPU socket if processor is removed.
Chapter 2
12
H110T-SI01 USER MANUAL
A. Apply some thermal grease onto the contacted area between the
heatsink and the CPU, and make it to be a thin layer.
B. Fasten the cooling fan supporting base onto the CPU socket on the
motherboard. And make sure the CPU fan is plugged to the CPU fan
connector.
C. Connect the CPU cooler power connector to the CPU_FAN connector.
2-4-2. Installing the CPU Cooler
• Install the cooling fan in a well-lit work area so that you can clearly see the
motherboard and processor socket.
• Avoid using cooling fans with sharp edges in case the fan casing and the
clips cause serious damage to the motherboard or its components.
• To achieve better airflow rates and heat dissipation, we suggest that you
use a high quality fan with 3800 rpm at least. CPU fan and heat sink
installation procedures may vary with the type of CPU fan/heatsink
supplied. The form and size of fan/heatsink may also vary.
• DO NOT remove the CPU cap from the socket before installing a CPU.
• Return Material Authorization (RMA) requests will be accepted only if the
motherboard comes with the cap on the LGA1151 socket.
• The following illustration shows how to install CPU fan.
Chapter 2
13
H110T-SI01 USER MANUAL
2-4-3. Installing Memory Modules
• This motherboard accommodates two memory modules. It can support
two 204-pin DDR4 2400 MHz.
• Do not remove any memory module from its antistatic packaging until
you are ready to install it on the motherboard. Handle the modules only
by their edges. Do not touch the components or metal parts. Always wear
a grounding strap when you handle the modules.
• You must install at least one module in any of the two slots. Total memory
capacity is 32 GB.
• Refer to the following to install the memory modules.
Install the DIMM module into the slot and press it firmly down until it fits
in place. Check that the cutouts on the DIMM module edge connector
match the notches in the DIMM slot.
SO-DIMM2
SO-DIMM1
Chapter 2
14
H110T-SI01 USER MANUAL
2-4-4. Installing Add-on Cards
The slots on this motherboard are designed to hold expansion cards and connect
them to the system bus. Expansion slots are a means of adding or enhancing the
motherboard’s features and capabilities. With these efficient facilities, you can
increase the motherboard’s capabilities by adding hardware that performs tasks
that are not part of the basic system.
Before installing an add-on card, check the documentation for
the card carefully. If the card is not Plug and Play, you may have
to manually configure the card before installation.
NGFF/NGFF1
Slots
The NGFF slot is M.2 for 2230/2280 SATA or PCIE SSD installing. It
will provide high transfer performance than original SATA interface.
Chapter 2
15
H110T-SI01 USER MANUAL
Follow these instructions to install the M.2 SSD card:
1 Demount the screw not used according to the length of your M.2 SSD card.
2 Insert the M.2 SSD card into NGFF slot in the fool-proof way.
3 Lock the screw as the following picture shows to make sure the M.2 SSD
card is installed in place.
Chapter 2
16
H110T-SI01 USER MANUAL
2-4-5. Connecting Optional Devices
Refer to the following for information on connecting the motherboard’s optional
devices:
No. Components No. Components
1 SATA1~2 7 LD C
2CIR8DMIC
3MON_SW 9F_AUDIO
4LVDS10USB3F
5DISP_BRT11USB_TP
6USB_CR_CAM
SATA1~2 connectors are used to support the Serial ATA 6Gb/s device. Simpler disk
drive cabling and easier PC assembly. It eliminates limitations of the current
Parallel ATA interface. But maintains register compatibility and software
compatibility with Parallel ATA.
1. SATA1~2: Serial ATA III connectors
Chapter 2
17
H110T-SI01 USER MANUAL
2. CIR: Consumer infrared header
3. MON_SW: LVDS brightness switch header (For All-In-One Specification)
Chapter 2
18
H110T-SI01 USER MANUAL
5. DISP_BRT: LVDS brightness control header (For All-In-One Specification)
4. LVDS: LVDS connector (For All-In-One Specification)
1. You can connect the large end of the cable to the LED Panel, and connect
the other small end to the slot on the motherboard.
2.Due to the chipset limitation, using dual displays LVDS(AIO) + VGA or
LVDS(AIO) + HDMI will cause the problem that you may not enter BIOS setup
or have the display problem.
Chapter 2
19
H110T-SI01 USER MANUAL
6 & 11. USB_CR_CAM (10-pin USB 2.0 header supports card reader and camera
or other USB 2.0 devices) & USB_TP (5-pin USB 2.0 header supports one USB
2.0 device)
Users please note to install the card to the correct header.
Chapter 2
20
H110T-SI01 USER MANUAL
The front panel audio header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. This header supports HD audio by
default. If you want connect an AC’ 97 front panel audio to HD onboard headers,
please set as below picture.
9. F_AUDIO: Front panel audio header
8. DMIC: Digital microphone header (For All-In-One Specification)
Chapter 2
21
H110T-SI01 USER MANUAL
If you use AC’ 97 Front Panel, please tick off the option of “Disabled Front Panel
Detect ”. If you use HD Audio Front Panel, please don’ t tick off “Disabled Front Panel
Detect ” .
* For reference only
AC’ 97 Audio Configuration: To enable the front panel audio connector to
support AC97 Audio mode.
Chapter 2
22
H110T-SI01 USER MANUAL
10. USB3F: Front USB 3.0 header
This motherboard implements one USB 3.0 header supporting two extra front USB
3.0 ports, which delivers 5Gb/s transfer rate.
To avoid the system instability after clearing CMOS, we recommend users
to enter the main BIOS setting page to “Load Default Settings” and then
“Save and Exit Setup”.
Chapter 2
23
H110T-SI01 USER MANUAL
* For reference only
2-4-6. Installing a Hard Disk Drive/Optical Disk Drive
This section describes how to install a Hard Disk Drive/Optical Disk Drive.
About SATA Connectors
Your motherboard features two SATA connectors supporting a total of two drives.
SATA refers to Serial ATA (Advanced Technology Attachment) is the standard interface
for the IDE hard drives which are currently used in most PCs. These connectors are
well designed and will only fit in one orientation. Locate the SATA connectors on the
motherboard and follow the illustration below to install the Hard Disk Drive/Optical
Disk Drive.
Installing Hard Disk Drive/Optical Disk Drive
To install the Hard Disk Drive (HDD)/Optical Disk Drive (ODD), use the HDD/ODD/SATA
cables that support the Hard Disk Drive/Optical Disk Drive/Serial ATA protocol.
Refer to the illustration below for proper installation:
1 Attach either end of the single SATA cable to the SATA port on the
motherboard.
2 Attach the other end of the single SATA cable to the hard disk drive.
3 Attach the linked end of the combo HDD/ODD cable to the Hard Disk Drive/
Optical Disk Drive. Please note that, connect the black cable to the hard
disk Drive, then connect the orange cable to the optical disk drive.
4 Attach the other end of the combo HDD/ODD cable to the SATA port and
SATA_PWR connector on the motherboard. Please note that, connect the
black cable to the SATA_PWR connector, and connect the orange cable to
the SATA port.
Chapter 2
24
H110T-SI01 USER MANUAL
After you have installed the motherboard into a case, you can begin connecting the
motherboard components. Refer to the following:
2-4-7. Connecting Case Components
No. Components No. Components
1SYS_FAN4 SPKR
2 CPU_FAN 5 SATA_PWR
3F_PANEL
1 & 2 . SYS_FAN (System cooling FAN connector) &CPU_FAN (CPU cooling FAN
connector)
Users please note that the fan connector supports the CPU cooling fan of 1.1A
~ 2.2A (26.4W max) at +12V.
Connect the CPU cooling fan cable to CPU_FAN.
Connect the system cooling fan connector to SYS_FAN.
Chapter 2
25
H110T-SI01 USER MANUAL
3. F_PANEL: Front panel header
The front panel header (F_PANEL) provides a standard set of switch and LED headers
commonly found on ATX or Micro ATX cases.
Hard Drive Activity LED
Connecting pins 1 and 3 to a front panel mounted LED provides visual indication that
data is being read from or written to the hard drive. For the LED to function properly,
an IDE drive should be connected to the onboard IDE interface. The LED will also
show activity for devices connected to the SCSI (hard drive activity LED) connector.
Power/Sleep/Message waiting LED
Connecting pins 2 and 4 to a single or dual-color, front panel mounted LED provides
power on/off, sleep, and message waiting indication.
Reset Switch
Supporting the reset function requires connecting pin 5 and 7 to a momentary-contact switch that is normally open. When the switch is closed, the board resets and
runs POST.
Power Switch
Supporting the power on/off function requires connecting pins 6 and 8 to a momentary-contact switch that is normally open. The switch should maintain contact for at
least 50 ms to signal the power supply to switch on or off. The time requirement is
due to internal de-bounce circuitry. After receiving a power on/off signal, at least
two seconds elapses before the power supply recognizes another on/off signal.
Chapter 2
26
H110T-SI01 USER MANUAL
Connect the case speaker cable to SPKR.
4. SPKR: 2 Channel audio speaker header (For All-In-One Specification)
This concludes Chapter 2. The next chapter covers the BIOS.
5. SATA_PWR: SATA power connector
Chapter 3
H110T-SI01 USER MANUAL
27
About the Setup Utility
The computer uses the latest “American Megatrends Inc. ” BIOS with support for
Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup
instructions for configuring the motherboard BIOS.
The BIOS (Basic Input and Output System) Setup Utility displays the system’s configuration status and provides you with options to set system parameters. The parameters are stored in battery-backed-up CMOS RAM that saves this information
when the power is turned off. When the system is turned back on, the system is
configured with the values you stored in CMOS.
The BIOS Setup Utility enables you to configure:
The settings made in the Setup Utility affect how the computer performs. Before
using the Setup Utility, ensure that you understand the Setup Utility options.
This chapter provides explanations for Setup Utility options.
The Standard Configuration
A standard configuration has already been set in the Setup Utility. However, we recommend that you read this chapter in case you need to make any changes in the
future.
This Setup Utility should be used:
• when changing the system configuration
• when a configuration error is detected and you are prompted to make
changes to the Setup Utility
• when trying to resolve IRQ conflicts
• when making changes to the Power Management configuration
• when changing the password or making other changes to the Security
Setup
Entering the Setup Utility
When you power on the system, BIOS enters the Power-On Self Test (POST) routines.
POST is a series of built-in diagnostics performed by the BIOS. After the POST routines
are completed, the following message appears:
Press DEL to enter SETUP
Chapter 3
Using BIOS
• Hard drives, diskette drives and peripherals
• Video display type and display options
• Password protection from unauthorized use
• Power Management features
Chapter 3
H110T-SI01 USER MANUAL
28
Using BIOS
When you start the Setup Utility, the main menu appears. The main menu of the
Setup Utility displays a list of the options that are available. A highlight indicates
which option is currently selected. Use the cursor arrow keys to move the highlight
to other options. When an option is highlighted, execute the option by pressing
<Enter>.
Some options lead to pop-up dialog boxes that prompt you to verify that you wish to
execute that option. Other options lead to dialog boxes that prompt you for information.
Some options (marked with an icon ) lead to submenus that enable you to change
the values for the option. Use the cursor arrow keys to scroll through the items in the
submenu.
Resetting the Default CMOS Values
When powering on for the first time, the POST screen may show a “CMOS Settings
Wrong” message. This standard message will appear following a clear CMOS data
at factory by the manufacturer. You simply need to Load Default Settings to reset
the default CMOS values.
Note: Changes to system hardware such as different CPU, memories, etc. may
also trigger this message.
Press the delete key to access BIOS Setup Utility.
Chapter 3
H110T-SI01 USER MANUAL
29
The default BIOS setting for this motherboard apply for most conditions
with optimum performance. We do not suggest users change the default
values in the BIOS setup and take no responsibility to any damage caused
by changing the BIOS settings.
In this manual, default values are enclosed in parenthesis. Submenu items are
denoted by an icon .
BIOS Navigation Keys
The BIOS navigation keys are listed below:
KEY FUNCTION
Scrolls through the items on a menu
+/-Change Opt.
F2 Previous Value
F3 Optimized Defaults
F1 General Help
ESC Exits the current menu
Enter Select
F4 Save & Exit
1. For the purpose of better product maintenance, the manufacture
reserves the right to change the BIOS items presented in this manual. The
BIOS setup screens shown in this chapter are for reference only and may
differ from the actual BIOS. Please visit the manufacture’s website for
updated manual.
2. In this Gui BIOS, you can operate by mouse or keyboard. Click : select
item; Double click: enter; Right click: exit.
Select the language icon and press <Enter> or double click the left key of the mouse
to display the screen. Then you can choose the language: English, Traditional
Chinese, Simple Chinese, Russian, Korean, German, Spanish, Italian, Portuguese,
Japanese.
Language
Select the default icon and press <Enter> or double click the left key of the mouse
to display the screen. Then you can load optimized defaults or not.
Default
Select the advanced icon and press <Enter> or double click the left key of the mouse
to display the screen.
Advanced
Chapter 3
H110T-SI01 USER MANUAL
30
Main Menu
System Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
System Language (English)
This item is used to set system language.
This menu shows the information of BIOS and enables you to set the system
language, date and time.
Choose the system default
language
Main Advanced Chipset T weak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
BIOS Information
System Language English
System Date Wed 05/04/2016
System Time 22:33:21
Chapter 3
H110T-SI01 USER MANUAL
31
The Advanced menu items allow you to change the settings for the CPU and other
system.
Advanced Menu
LAN Configuration
Parameters
Main Advanced Chipset T weak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
LAN Configuration
PC Health Status
Power Management Setup
ACPI Settings
CPU Configuration
SAT A Configuration
USB Configuration
Super IO Configuration
Trusted Computing
Chapter 3
H110T-SI01 USER MANUAL
32
Onboard LAN Controller (Enabled)
Use this item to enable or disable the Onboard LAN.
LAN Configuration
The item in the menu shows the LAN-related information that the BIOS
automatically detects.
Press <Esc> to return to the Advanced Menu page.
Enabled/Disabled Onboard
LAN Controller
Main Advanced Chipset T weak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
LAN Configuration
Onboard LAN Controller Enabled
Chapter 3
H110T-SI01 USER MANUAL
33
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Tweak Security Boot Exit
CPU T emperature (DTS) 4 1
System T emperature 34oC
CPU Fan Speed 726 RPM
System Fan Speed 0 RPM
Core Voltage 0.935V
DIMM Voltage 1.199V
+12V 12.210V
+5V 5.159V
+VCC 5.137V
TCC Activation T emperature (DTS) 100
PC Health Status
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
• CPU Temperature (DTS)
• System Temperature
• CPU Fan Speed
• System Fan Speed
• Core Voltage
• DIMM Voltage
• +12V
• +5V
• +VCC
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
Chapter 3
H110T-SI01 USER MANUAL
34
Power Management Setup
This page sets up some parameters for system power management operation.
Resume By USB (Disabled)
This item allows you to enable or disable the USB device wakeup function from S3
mode.
EUP Function (Enabled)
This item allows user to enable or disable EUP support.
Resume By RING (Disabled)
An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call
on the modem) awakens the system from a soft off state.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
About Resume by Ring
Resume By PME (Disabled)
This item specify whether the system will be awakened from power saving modes
when activity or input signal of the specified hardware peripheral or components
is detected.
Resume By RTC Alarm (Disabled)
The system can be turned off with a software command. If you enable this item, the
system can automatically resume at a fixed time based on the system’s RTC
(realtimeclock). Use the items below this one to set the date and time of the
wake-up alarm. You must use an ATX power supply in order to use this feature.
Power Management Setup
Resume By RING Disabled
Resume By PME Disabled
Resume By USB Disabled
Resume By RTC Alarm Disabled
EUP Function Enabled
Power LED Type Dual Color LED
Press <Esc> to return to the Advanced Menu page.
Power LED Type (Dual Color LED)
This item shows the type of the power LED.
Chapter 3
H110T-SI01 USER MANUAL
35
ACPI Settings
The item in the menu shows the highest ACPI sleep state when the system enters
suspend.
ACPI Sleep State [S3(Suspend to RAM)]
This item allows user to enter the ACPI S3 (Suspend to RAM) Sleep State (default).
Press <Esc> to return to the Advanced Menu page.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Select the highest ACPI
sleep state the system
will enter when the
SUSPEND button is pressed.
ACPI Settings
ACPI Sleep State S3 (Suspend to RAM)
Chapter 3
H110T-SI01 USER MANUAL
36
Number of cores to enable
in each processor package.
Main Advanced Chipset Tweak Security Boot Exit
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
This is display-only field and displays the information of the CPU installed in your
computer.
EM64T (Supported)
This item shows the computer supports EM64T.
Processor Speed (2500MHz)
This item shows the current processor speed.
Processor Stepping (506E3)
This item shows the processor stepping version.
Microcode Revision (76)
This item shows the Microcode version.
Processor Cores (4)
This item shows the core number of the processor.
Intel HT Technology (Not Supported)
This item shows the computer not support Intel HT Technology or not.
CPU Configuration
The item in the menu shows the CPU configuration.
Enter/Dbl Click : Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
/Click: Select Item
: Select Screen
Intel VT-x Technology (Supported)
This item shows the computer support Intel VT-x Technology or not.
CPU Configuration
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
EM64T Supported
Processor Speed 2500 MHz
Processor Stepping 506E3
Microcode Revision 7 6
Processor Cores 4
Intel HT Technology Not Supported
Intel VT -x Technology Supported
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Intel Virtualization T echnology Enabled
Package C State limit AUTO
Enhanced Halt (C1E) Enabled
HardWare P states (HWP) Disabled
Active Processor Cores (All)
Use this item to control the number of active processor cores.
Intel HT Technology (Not Supported)
This item shows the computer not support Intel HT Technology or not.
Chapter 3
H110T-SI01 USER MANUAL
37
Limit CPUID Maximum (Disabled)
Use this item to enable or disable the maximum CPUID value limit. You can enable
this to prevent the system from “rebooting” when trying to install Windows NT 4.0.
Excute Disable Bit (Enabled)
This item allows the processor to classify areas in memory by where application
code can execute and where it cannot. When a malicious worm attempts to insert
code in the buffer, the processor disables code execution, preventing damage or
worm propagation. Replacing older computers with Execute Disable Bit enabled
systems can halt worm attacks, reducing the need for virus related repair.
Intel Virtualization Technology (Enabled)
When disabled, a VMM cannot utilize the additional hardware capabilities provided
by Vandor Pool Technology.
Enhanced Halt (C1E) (Enabled)
Use this item to enable the CPU energy-saving function when the system is not
running.
Press <Esc> to return to the Advanced Menu page.
Package C State limit (AUTO)
Use this item to set the package C state limit.
HardWare P states (HWP) (Disabled)
Use this item to enable or disable the hardware P states.
Chapter 3
H110T-SI01 USER MANUAL
38
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Determines how SATA
controller(s) operate.
SATA Mode (AHCI)
Use this item to select SATA mode.
SATA Port 1~2/M.2 (Not Present)
This motherboard supports two SATA channels and one M.2 channel, each channel
allows one SATA/M.2 device to be installed. Use these items to configure each
device on the SATA/M.2 channel.
Press <Esc> to return to the Advanced Menu page.
Spin Up Device (Disabled)
Use this item to enable or disable the spin up device.
External SATA (Disabled)
Use this item to enable or disable the external SATA.
SA TA Configuration
SAT A Mode AHCI
SAT AII Port1
Not Present
Spin Up Device Disabled
External SAT A Disabled
SAT AII Port2
Not Present
Spin Up Device Disabled
External SAT A Disabled
M.2
Not Present
Chapter 3
H110T-SI01 USER MANUAL
39
All USB Devices (Enabled)
Use this item to enable or disable all USB devices.
USB Configuration
Use this item to show the information of USB configuration.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
USB Support Parameters
USB Configuration
All USB Devices Enabled
Legacy USB Support Enabled
Press <Esc> to return to the Advanced Menu page.
Chapter 3
H110T-SI01 USER MANUAL
40
CIR Controller (Enabled)
This item allows you to enable or disable CIR controller.
Scroll to this item and press <Enter> and view the following screen:
CIR Controller Configuration
Enable or Disable CIR
Controller
Main Advanced Chipset Tweak Security Boot Exit
Super IO Configuration
Use this item to show the information of Super IO configuration.
Super IO Chip (IT8613)
This item shows the information of the super IO chip.
Set Parameters of CIR
Controller (CIR)
Main Advanced Chipset Tweak Security Boot Exit
Super IO Configuration
Super IO Chip IT8613
CIR Controller Configuration
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Press <Esc> to return to the Super IO Configuration page.
Press <Esc> to return to the Advanced Menu page.
Device Settings (IO=3E0h; IRQ=10;)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.
CIR Controller Configuration
CIR Controller Enabled
Device Settings IO=3E0h; IRQ=10;
Change Settings Auto
Chapter 3
H110T-SI01 USER MANUAL
41
TPM Support (Enabled)
Use this item to enable or disable the TPM port. O.S. will not show TPM. Reset of
platform is required.
Trusted Computing
Use this item to show the information of trusted computing configuration.
Active PCR banks (SHA-1)
Use this item to show the Active PCR banks.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enables or Disables BIOS
support for security device.
O.S. will show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Available PCR banks (SHA-1, SHA-256)
Use this item to show the Available PCR banks.
SHA-1 PCR Bank (Enabled)
Use this item to enable or disable the SHA-1 PCR Bank.
SHA256 PCR Bank (Disabled)
Use this item to enable or disable the SHA256 PCR Bank.
TPM20 Device Found
TPM Support Enabled
Active PCR banks SHA-1
Available PCR banks SHA-1, SHA256
SHA-1 PCR Bank Enabled
SHA256 PCR Bank Disabled
Platform Hierarchy Enabled
Storage Hierarchy Enabled
Endorsement Hierarchy Enabled
TPM2.0 UEFI Spec Version 1.0
TPM 20 InterfaceType CRB
Device Select Auto
Press <Esc> to return to the Advanced Menu page.
Platform Hierarchy (Enabled)
Use this item to enable or disable the Platform Hierarchy.
Storage Hierarchy (Enabled)
Use this item to enable or disable the Storage Hierarchy.
Endorsement Hierarchy (Enabled)
Use this item to enable or disable the Endorsement Hierarchy.
TPM2.0 UEFI Spec Version (1.0)
Use this item to show the TPM2.0 UEFI Spec Version.
TPM 20 InterfaceType (CRB)
Use this item to show the TPM 20 InterfaceType.
Device Select (Auto)
TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM
2.0 devices, Auto will support both with default set to TPM 2.0 devices if not found,
TPM 1.2 devices will be enumerated.
Chapter 3
H110T-SI01 USER MANUAL
42
The chipset menu items allow you to change the settings for the North Bridge
chipset, South Bridge chipset and other system.
Chipset Menu
System Agent (SA)
Parameters
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
IGD Memory (64M)
This item shows the information of the IGD (Internal Graphics Device) memory.
DVMT Memory (256M)
When set to Fixed Mode, the graphics driver will reserve a fixed position of the
system memory as graphics memory, according to system and graphics
requirements.
Select DVMT 5.0
Pre-Allocated (Fixed)
Graphics Memory size used
by the Internal Graphics
Device.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
/Click: Select Item
System Agent Configuration
IGD Memory 64M
DVMT Memory 256M
System Agent Configuration
PCH Configuration
ME Configuration
Scroll to this item and press <Enter> and view the following screen:
System Agent Configuration
Press <Esc> to return to the Chipset Menu page.
Chapter 3
H110T-SI01 USER MANUAL
43
Restore AC Power Loss (Power Off)
This item enables your computer to automatically restart or return to its operating
status.
Audio Configuration
This item shows the information of the audio configuration.
Azalia HD Audio (Enabled)
This item enables or disables Azalia HD audio.
PCH Configuration
Scroll to this item and press <Enter> to view the following screen:
Select AC power state when
power is re-applied after
a power failure.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
PCH Configuration
Restore AC Power Loss Power Off
Audio Configuration
Azalia HD Audio Enabled
Press <Esc> to return to the Chipset Menu page.
Chapter 3
H110T-SI01 USER MANUAL
44
ME FW Version (11.0.0.1205)
This item shows the ME FW version.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
ME Configuration
Scroll to this item and press <Enter> to view the following screen:
Enable/Disable ME
Firmware
Press <Esc> to return to the Chipset Menu page.
ME Control (Enabled)
Use this item to enable or disable the ME Firmware.
Management Engine T echnology Configuration
ME Control Enabled
ME FW Version 1 1.0.0.1205
Chapter 3
H110T-SI01 USER MANUAL
45
Total Memory (4096 MB)
This item shows the total memory.
Processor Speed (2500 MHz)
This item shows the current processor speed.
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Memory Frequency (2133 Mhz)
This item shows the memory frequency.
Tweak Menu
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enhanced Intel
SpeedStep T echnology
Tweak
EIST (Enabled)
This item allows you to enable or disable the EIST (Enhanced Intel SpeedStep
Technology).
Turbo Boost (Enabled)
This item allows you to enable or disable the Turbo Boost.
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
Processor Speed 2500 MHz
Memory Frequency 2133 Mhz
T otal Memory 4096 MB
EIST Enabled
Turbo Boost Enabled
Chapter 3
H110T-SI01 USER MANUAL
46
This page enables you to set setup administrator password and user password.
Security Menu
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Set Administrator Password
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Administrator Password Status (Not Install)
This item shows administrator password installed or not.
User Password Status (Not Install)
This item shows user password installed or not.
Secure Boot state (Not Active)
This item allows you to enable or disable the secure boot state.
Administrator Password
Administrator Password Status Not Install
User Password Status Not Install
System Mode state Setup
Secure Boot state Not Active
Secure Boot Enabled
Secure Boot Mode Standard
System Mode state (Setup)
This item shows system mode setup or not.
Secure Boot (Enabled)
This item is used to control the secure boot flow, it is possible only if system runs in
User Mode.
Secure Boot Mode (Standard)
This item is used to select the secure boot mode.
Chapter 3
H110T-SI01 USER MANUAL
47
This page enables you to set the keyboard NumLock state.
Boot Menu
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Windows 7 or other OS:
Boot policy for Legacy OS.
Windows 8.x/10: Boot policy
for UEFI OS without
Compatibility Support
Module (CSM).
Manual: User customized
CSM parameters & Boot
policy.
Boot Configuration
This item shows the information of the Boot Configuration.
Operation System Select (Windows 8.x / 10)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Fast Boot (Disabled)
This item enables or disables boot with initialization of a minimal set of device
required to launch active boot option. Has no effect for BBS boot options.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Update System BIOS (Disabled)
Use this item to enable or disable update system BIOS.
Boot mode select (UEFI)
Use this item to select boot mode.
Boot Option #1 /2 /3 /4 /5 /6 /7
Use these items to set the system boot order.
UEFI USB Flash Drive Priorities
This item enables you to specify the sequence of loading the operating system. Press
<Enter> to see the submenu.
Boot Configuration
Operation system select Windows 8.x / 10
Launch PXE OpROM Disabled
Launch Storage OpROM Enabled
Fast Boot Disabled
Bootup NumLock State On
Update System BIOS Disabled
Boot mode select UEFI
Set Boot Priority
Boot Option #1 Hard Disk
Boot Option #2 CD/DVD
Boot Option #3 USB Hard Disk
Boot Option #4 USB CD/DVD
Boot Option #5 USB Flash:UEFI: PNY...
Boot Option #6 USB Floppy
Boot Option #7 Network
UEFI USB Flash Drive Priorities
Chapter 3
H110T-SI01 USER MANUAL
48
Save Options
This item enables you to save the options that you have made.
Save Changes
This item enables you to save the changes that you have made.
Discard Changes
This item enables you to discard any changes that you have made.
Restore Defaults
This item enables you to restore the system defaults.
Save as User Defaults
This item enables you to save the changes that you have made as user defaults.
Restore User Defaults
This item enables you to restore user defaults to all the setup options.
Save Changes and Exit
This item enables you to exit system setup after saving the changes.
Discard Changes and Exit
This item enables you to exit system setup without saving any changes.
Discard Changes and Reset
This item enables you to reset system setup without saving any changes.
This page enables you to exit system setup after saving or without saving the
changes.
Exit Menu
Main Advanced Chipset Tweak Security Boot Exit
Go back to EZ Mode
Back to EZ Mode
Save Changes and Exit
Discard Changes and Exit
Save Changes and Reset
Discard Changes and Reset
Save Options
Save Changes
Discard Changes
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
UEFI: PNY USB 2.0 FD 8192, Partition 1
Boot Override
Use this item to select the boot device.
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Save Changes and Reset
This item enables you to reset system setup after saving the changes.
Back to EZ Mode
This item enables you to back to EZ mode.
Chapter 3
H110T-SI01 USER MANUAL
49
Updating the BIOS
You can download and install updated BIOS for this motherboard from the
manufacturer’s Website. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows:
This concludes Chapter 3. Refer to the next chapter for information on the software
supplied with the motherboard.
1 If your motherboard has a BIOS protection jumper, change the setting to
allow BIOS flashing.
2 If your motherboard has an item called Firmware Write Protect in Ad-
vanced BIOS features, disable it. (Firmware Write Protect prevents BIOS
from being overwritten.)
3 Prepare a bootable device or create a bootable system disk. (Refer to
Windows online help for information on creating a bootable system disk.)
4 Download the Flash Utility and new BIOS file from the manufacturer’s
Web site. Copy these files to the bootable device.
5 Turn off your computer and insert the bootable device in your computer.
(You might need to run the Setup Utility and change the boot priority items
on the Advanced BIOS Features Setup page, to force your computer to
boot from the bootable device first.)
6 At the C:\ or A:\ prompt, type the Flash Utility program name and the file
name of the new BIOS and then press <Enter>. Example: AFUDOS.EXE
040706.ROM
7 When the installation is complete, remove the bootable device from the
computer and restart your computer. If your motherboard has a Flash
BIOS jumper, reset the jumper to protect the newly installed BIOS from
being overwritten. The computer will restart automatically.
Chapter 3
H110T-SI01 USER MANUAL
50
Memo
51
H110T-SI01 USER MANUAL
Chapter 4
Chapter 4
Using the Motherboard Software
The auto-install DVD-ROM makes it easy for you to install the drivers and software.
The support software DVD-ROM disc loads automatically under Windows 7/10. When
you insert the DVD-ROM disc in the DVD-ROM drive, the auto-run feature will
automatically bring up the installation screen. The screen has four buttons on it:
Setup, Utilities, Browse CD and Exit.
Auto-installing under Windows 7/10
Displays the path for all
software and drivers
available on the disk.
Open Windows Explorer
and show the contents
of the support disk.
Click “Exit” button to
close the Auto-Setup
window.
Browse CD:
Click the “Setup”
button to select and
run the software
installation program.
Click the “ Utilities”
button to select and
install the Intelligent
Utility.
Information:
Follow these instructions to install device drivers and software for the
motherboard:
The following screens are examples only. The screens and driver lists will be
different according to the motherboard you are installing.
1. Click Setup. The installation program begins:
Running Setup
The motherboard identification is located in the upper left-hand corner.
52
H110T-SI01 USER MANUAL
Chapter 4
2. Click Next. The following screen appears:
3. Check the box next to the items you want to install. The default options are recommended.
5. Follow the instructions on the screen to install the items.
4. Click Next to run the Installation Wizard. An item installation screen appears:
Drivers and software are automatically installed in sequence. Follow the
onscreen instructions, confirm commands and allow the computer to
restart a few times to complete the installation.
Windows 10 will show the following screen after system restart, you must
select “Desktop” in the bottom left to install the next driver.
53
H110T-SI01 USER MANUAL
Chapter 4
If the auto-install DVD-ROM does not work on your system, you can still install
drivers through the file manager for your OS (for example, Windows Explorer). Look
for the chipset and motherboard model, and then browse to the directory and path
to begin installing the drivers. Most drivers have a setup program (SETUP.EXE) that
automatically detects your operating system before installation. Other drivers have
the setup program located in the operating system subfolder.
Manual Installation
If the driver you want to install does not have a setup program, browse to the
operating system subfolder and locate the readme text file (README.TXT or
README.DOC) for information on installing the driver or software for your operating
system.
Windows 7/10 will appear below UAC (User Account Control) message after the system restart. You must select “Yes” to install the next driver. Con-
tinue this process to complete the drivers installation.
54
H110T-SI01 USER MANUAL
Chapter 4
Memo
55
H110T-SI01 USER MANUAL
Chapter 5
Chapter 5
Trouble Shooting
Start up problems during assembly
After assembling the PC for the first time you may experience some start up
problems. Before calling for technical support or returning for warranty, this
chapter may help to address some of the common questions using some basic
troubleshooting tips.
a) System does not power up and the fans are not running.
1. Disassemble the PC to remove the VGA adaptor card, DDR memory, LAN, USB and
other peripherals including keyboard and mouse. Leave only the motherboard,
CPU with CPU cooler and power supply connected. Make sure the power cord is
plugged into the wall socket & the switch on the Power Supply Unit (PSU) is turned
“ on “ as well. Turn on again to see if the CPU and power supply fans are running.
2. Make sure to remove any unused screws or other metal objects such as
screwdrivers from the inside PC case. This is to prevent damage from short circuit.
3. Check the CPU FAN connector is connected to the motherboard.
4. For Intel platforms check the pins on the CPU socket for damage or bent. A bent
pin may cause failure to boot and sometimes permanent damage from short circuit.
b) Power is on, fans are running but there is no display
1. Make sure the monitor is turned on and the monitor cable is properly connected
to the PC.
2. Check the VGA adapter card (if applicable) is inserted properly.
3. Listen for beep sounds. If you are using internal PC speaker make sure it is
connected.
a. continuous 3 short beeps: memory not detected
b. 1 long beep and 8 short beeps: VGA not detected
c) The PC suddenly shuts down while booting up.
1. The CPU may experience overheating so it will shutdown to protect itself. Apply
the thermal grease onto the CPU heatsink & ensure the CPU fan is well-connected
with the CPU heatsink. Check if the CPU fan is working properly while the system
is running.
2. From the BIOS setting, try to disable the Smartfan function to let the fan run at
default speed. Doing a Load Optimised Default will also disable the Smartfan.
56
H110T-SI01 USER MANUAL
Chapter 5
Start up problems after prolong use
After a prolong period of use your PC may experience start up problems again. This
may be caused by breakdown of devices connected to the motherboard such as
HDD, CPU fan, etc. The following tips may help to revive the PC or identify the cause
of failure.
1. Clear the CMOS values using the CLR_CMOS jumper. Refer to CLR_CMOS jumper
in Chapter 2 for Checking Jumper Settings in this user manual. When completed,
follow up with a Load Optimised Default in the BIOS setup.
2. Check the CPU cooler fan for dust. Long term accumulation of dust will reduce its
effectiveness to cool the processor. Clean the cooler or replace a new one if
necessary.
3. Remove the hard drive, optical drive or DDR memory to determine which of
these components may be at fault.
4. Check whether there is any bulked up electrolytic capacitor or abnormal
component.
Your computer, like any electrical appliance, requires proper care and
maintenance. Here are some basic PC care tips to help prolong the life of the
motherboard and keep it running as best as it can.
1. Keep your computer in a well ventilated area. Leave some space between the
PC and the wall for sufficient airflow.
2. Keep your computer in a cool dry place. Avoid dusty areas, direct sunlight and
areas of high moisture content.
3. Routinely clean the CPU cooler fan to remove dust and hair.
4. In places of hot and humid weather you should turn on your computer once
every other week to circulate the air and prevent damage from humidity.
5. Add more memory to your computer if possible. This not only speeds up the
system but also reduces the loading of your hard drive to prolong its life span.
6. If possible, ensure the power cord has an earth ground pin directly from the
wall outlet. This will reduce voltage fluctuation that may damage sensitive devices.
Maintenance and care tips
uB rewoP
desserp si no
.trats ot sliaf CP tub
seY
ylppuS rewoP fi kcehC
tinU
gnikrow si )USP(
oN
oN
dnuos peeB ynA
oN
kcehc dna SOMC RLC
rewop V21 UPC fi
detcennoc si
CP eht tratseR
?draob ro USP htiw melborP
AMR tcatnoc >- melborp draob fI
deulp si droc rewop CA gg
?no denrut si hctiws USP dna
seY
melborp draoB
AMR tcatnoc >-
oN
:speeb trohs 3 fI -
ylreporp ton yromem MMID
eruliaf yromem ro detresni
:speeb trohs 8 dna peeb gnol 1 fI -
detceted ton AGV
seY
seY
neercs TSOP ta tlaH
seY
OMC RL dna SC tser .tra
AMR tcatnoc ,liaf fI
seY
oN
eussi ecived larehpireP
.melborp DDH-
,rorre putes SOMC-
d .SOMCRLC ot een
ts ot liaf metsyS elbatsnu ro tra
a
es SOIB yfidom re
.gn
M SOC RLC tratser dna
hctiws USP no nruT
tekcos llaw ot tcennoc ro
.tratser dna
oN
h rotinom fi kcehC sa
sid
yalp
rotinom fi kcehC
yalpsid sah
Basic Troubleshooting Flowchart
57
58
H110T-SI01 USER MANUAL
Chapter 5
Memo
Loading...
