BK630e V1.7D / V7.1 MAINBOARD
KEY FEATURES:
SiS 630e chipset.
Onboard 128-bit graphics system supports up to 1920 x
1200 resolution, and hardware DVD accelerator
Onboard 10/100 Base-T Ethernet adapter.
Onboard V.90 HSP 56K Voice/Data/Fax modem in CMI
8738 chipset.
Onboard 3D Surround Sound system.
Integrated hardware monitoring circuit.
Advanced ATX power management
133/100/66MHz FSB for the latest Intel Celeron &
FCPGA Pentium III processors.
Proprietary Flex - ATX form-factor.
NOTE: v.7.1 w/ extra serial port
Click image for enlarge
FEATURES:
Main Chipset
SiS630e Chipset
Integrated the UltraAGP technology and advance 64-bit graphic display interface, share Main Memory up to 64MB
Delivers AGP 4X performance and up to 1GB/s memory bandwidth.
Powerful hardware decoding DVD accelerator to improve the DVD playback performance
Integrated all peripheral controllers/accelerators/interfaces
Total communication solution including 10/100Mb Fast Ethernet for Office requirement
Integrated AC'97 compliant interface that comprises digital audio engine with 3D-hardware accelerator
Supports 133/100/66MHz FSB (Front-side BUS) processors including the Intel Celeron and FC-PPGA Pentium III CPUs
Low Pin Count (LPC) operating at 33MHz clock, and dual USB host controller up to 5 USB ports
Built-in fast PCI IDE controller supports the ATA PIO/DMA, and Ultra DMA 33/66 function support
Onboard Modem
CMI 8738 HSP56 flex/V.90 Modem Chip
Dual mode V.90/56Kflex support
PCI v2.2 compliant interface.
ACPI supports 'On Now'
Optional support for Caller ID
On Chip PnP logic
PC 97 & 99 compliant
Supports Windows 95/98/NT/2000 and Linux
Supports V.90, V.34, V.32, V32bis, V.22 and V.22bis protocols
Onboard Sound
C-Media CMI8738
HRTF-based 3Dm positional audio supporting DirectSound 3D and A3D interface.
Supports rear side speakers, C3DX positional audio in 4-channel speaker mode.
Legacy SoundBlaster 16 compatible.
Downloadable DLS-based WaveTable music synthesizer with DirectMusic support.
Professional digital audio interface supporting 24-bit SPDIF input and output in both 44.1KHz and 48KHz formats.
Built-in 32ohm earphone buffer.
Built-in PCTel HSP56 Modem interface.
Drivers support AC3 5.1 channel interface.
MPU-401 port.
16-bit full duplex CODEC for playback and recording.
4-channel 16-bit DAC
32-bit PCI bus master
Onboard LAN Adapter
Embedded in SiS 630E
Integrated Fast Ethernet MAC, Physical Layer and transceiver.
+3.3v power supply with +5v tolerant I/O
PCI 2.2 compliant interface
Independent receive FIFO and transmit FIFO
IEEE 802.3u 100Base-TX and 802.3u 10Base-T compliant
Full and half duplex mode support
Supports Wake on LAN features
High performance 100Mbps clock generator and data recovery circuit.
Provides loopback mode for easy system diagnostics
Onboard I/O Ports
External Ports
(1) Parallel port which supports EPP and ECP modes
(2) USB ports
(2) PS/2 ports
(1) 15-pin VGA port
(1) Serial port
All ports are PC 99 compliant for easy identification
Internal Ports
(1) Primary EIDE controller with support for two UltraDMA 33/66 devices
(1) Floppy drive controller with support for up to two drives
Memory Support
(2) 168-pin DIMM slots for 3.3v SDRAM PC-100/133 modules
Supports a maximum of 1024MB RAM
Processor Support
The Bk630 Book PC (iCue Bk630) will support Celeron CPUs @ 66MHz FSB and FC-PPGA ( Corpermine) CPUs @
100/133MHz FSB
Expansion Slots
NOTE: The Book PCs (iCue BK Series) do not have any expansion slots. There are no ISA, PCI or AGP slots.
Drives
1.44MB 3 ½" drive (MITSUMI)
52x CD-ROM drive (Top-Glory Electronic)
Case Specifications
External dimensions 310mm (L) x 272mm (W) x 82mm (H)
External 5 ¼" drive bay occupied by the CD/DVD-ROM drive
External customized 3 ½" floppy drive bay occupied by the floppy drive (ZIP drives will not fit)
Internal 3 ½" drive bay (for hard drive)
PS/2 ports (for keyboard and mouse)
USB ports
RJ45 Ethernet port
Modem port for both Phone and Line
EPP/ECP Parallel port
(1) 9-pin Serial port (for V7.1 only)
(1) 15-pin VGA port
(1) 15-pin MIDI port
Sound ports for Mic, Line-In and Speakers
Front panel: 2xUSB ports (share with back panel), Audio Out and Mic
Power Supply
100Watt, 110/220C Auto Switch
Dimensions 10.25cm (W) x 6cm (L) x 7.25cm (H)
Certifications: FCC, CE, UL, TUV
Package Contents
Case with 100W power supply
BK630e Mainboard v7.1
Top-Glory Electronic 52x CD-ROM drive with 40-pin ribbon cable
Mitsumi 3 ½" floppy drive with cable
CD-ROM audio cable
PS/2 Key board / Mouse
2 Amplifier Speaker
User's manual
System Support CD
Low profile CPU cooling fan
JUMPER SETTINGS AND HEADER PIN-OUTS
JUMPER PIN(s) FUNCTION
J9 - 6 Channel Setting
On 6 Channel
Off 4 Channel
JUMPER PIN(s) FUNCTION
J4 - Short 3-4, 5-6, 7-8
respectively
J20 - VTT Settings
Please short 2-3
J5
Only for factory test
J11
1 Power supply Vcc5
2 Power supply Vcc5
3 Power supply Vcc5
4 Mainboard Vcc3
5 Mainboard Vcc3
6 Mainboard Vcc3s
Always Short every jumper
respectively, then Power
will pass electricity to
Mainboard
Front 2
J10
1 Power supply Vcc5
2 Power supply Vcc5
3 Power supply Vcc5
4 Power supply Vcc5
5 Power supply Vcc5
6 Mainboard Vcc3s
7 Mainboard Vcc3s
8 Mainboard Vcc3s
9 Mainboard Vcc3s
10 Mainboard Vcc3s
Always Short every jumper
respectively, then Power
will pass electricity to
Mainboard
J2 - For Front Panel
MIC short 1-3, 2-4 2 MIC OUT
1 N/A
3 MICTOSUB
4 MMICOUT
1 N/A
2 N/A
3 MIN
4 MICOUT
5SR
6 SPOUTR
7SL
8 SPOUTL
1 USB PO-
2 USB PO+
3 UP-
4 UP+
5 VCC
6 Ground
7 IRTX
8 IRRX
9 N/A
10 Ground
11 kEYBOARD clk
12 EXTK CLK
13 K DATA
14 EXTK DATA
15 5VSB
16 Ground
17 M CLK
18 EXTM CLK
19 M DATA
20 EXTM DATA
For Front Panel
CENTER short 3-5, 4-6 5 CENTER
6 BASS-
Modem - Modem DAA
Conn.
PANEL1 - Front Panel
1 Ground
2 Power Supply
3 Ground
4 Reset
5 Ground
6 Power LED
7 HDD LED
8 Vcc
9 ACPI LED
10 Vcc
J2 - SPDIF Input
1 SPDIF In
2 Ground
1 Ground
2 AFEM CLK
3 Ground
4 HSPFS
5 Ground
6 MS CLK
7 PVCC3
8 Modem Ring On
9 Off Hook
10 GPIOX
11 RIN
12 HSPSDO
13 5vSB
14 HSPSDI
15 Mute
16 AFERET
J3 - SPDIF Output
1 12v
2 GPPIO
3 SPDIF In
4 Ground
5 SPDIF Out
6 Ground
A_CD1 - CD-ROM Audio
Power Connector
Designs, specifications and package contents are subject to change without notice. Various trademarks belong to their respective owners. Please read
the legal notice
.©1997-2004 All rights reserved. Amptron International Inc. 17501 Rowland St., City of Industry CA., 91748 (626) 912-5789
1 Left Channel
2 Ground
3 Ground
4 Right Channel
1 5v SB
2 Ground
3 Ground
4 PS-ON#
5 +12v
6 +12v
