ECS 900SD Schematic

5

࣯ࣤࣟ

࣭ࣦ࣠࣢

ࣰࣣ࣑ࣟ࣍࣍࣪ࣥ

࣑ࢽࣦ࣡࣪

ࣰࣩࣳ࣡

ࣰࣲࣟ

ࣩࣦࣞࣷࣞࣞ

࣭ࣦ࣠࣢࣏ࣼ

࣭ࣦ࣠࣢࣐ࣼ

ࣩ࣭࣠

࣑࣍࣍࣪ࣥ

࣠ࣾࢽࣞ

ࣰࣲ࣭࣑ࣟࣼ

ࣰࣲ࣭ࣟࣼࣔ

ࣰࣲ࣭࣏࣐ࣟࣼ࣎࣌࣌

ࣰࣱࣞࣞࢽ࣍

࣭ࣦ࣠࣢ࣼ࣎

ࣰࣲ࣭࣒ࣟࣼ

4

3

2

1

01_Block Diagram 02_System Setting 03_Power Sequence 04_EC Pin Define 05_HISTORY

D D

06_Clock Gen 07_Dothan_HOST 08_Dothan_PWR_GND 09_910GML_HOST_DMI 10_910GML_DRAM 11_910GML_VGA_LVDS_TV 12_910GML_PWR 13_910GML_GND 14_ICH6-M_Azalia_GPIO_PCI_LAN 15_ICH6-M_USB_PCIE_DMI_IDE_SATA 16_ICH6-M_PWR_GND 17_Onboard DRAM_Bottom A1 18_Onboard DRAM_Top A1 19_Onboard DRAM_Bottom A2 20_Onboard DRAM_Top A2

C C

21_DDR2_Termination 22_ONBOARD_VGA 23_LCD-CONN 24_3G Module 25_WLAN 26_LAN 27_RJ45 28_Flash_Ctrl_JMF601 29_On Board NAND Flash 30_USB_PORT 31_CARD_READER 32_CAMERA 33_ALC269-1 34_ALC269-2

B B

35_ALC269-3 36_EC_ENE KB3310 37_Switch_SPI ROM_Debug Conn 38_KB_Touch Pad 39_Thermal Sensor 40_LED 41_Discharge 42_PWR Jack 43_Srew Hole 44_EMI 45_POWER FLOW 46_CHARGER 47_VCORE 48_+3VO_+5VO

A A

49_VTT_DDR_+1.8V_HD 50_+1.8V 51_VCCP 52_1.5_2.5V

5

SD/MMC Card Reader

On Board NAND Flash

Flash Module

4

http://hobi-elektronika.net

CPU

Celeron-M ULV

(Dothan)

FCBGA479

LCD

CRT

Debug Conn

EC

ENE KBC3310

Touch PadInternal KBSPI ROM

USB Port *3

Card Reader

AU 6336

Camera

JMF601

NORTH BRIDGE

910GML

SOUTH BRIDGE

ICH6-M

3

CLOCK GEN

ICS9LPRS427

THERMAL CONTROL

On Board Memory

AZALIA CODEC

Realtek ALC269

3G Card

WLAN

LAN

AR 8113

2

900SD_MB

R1.0G

LINE OUT

Speaker

EXT MIC

INT MIC

RJ-45

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

Block Diagram

Hauld_Zhou

151Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

D D

C C

B B

ICH6 GPIO SETTING

B7 E8 D9 C7 C6 M3 AD19 AE19 R1 C23 D23 W6 M2 R6 C25 C24 D8 F6 AC21 AB21 AD22 AD20 NA AD21 V3 P5

Pin Name

GPI0/REQ6# GPI1 / REQ5# GPI2 / PIRQE# GPI3 / PIRQF# GPI4 / PIRQG# GPI5 / PIRQH# GPI6 / BMBUSY# GPI7 GPI8 GPI9/OC4# GPI10/OC5# GPI11 / SMBALERT# GPI12 GPI13 GPI14/OC6# GPI15 /OC7# GPO16/GTN6# GPO17 / GNT5# GPO18 / STP_PCI# GPO19 GPO20 / STP_CPU# GPO21 GPIO22 GPO23 GPIO24 GPIO25

Connect to

10K Pull +3V 10K Pull +3V 10K Pull +3V 10K Pull +3V 10K Pull +3V

NB BMBUSY# NC EC KBC_SCI# 10K Pull +3V 10K Pull +3V 10K Pull +3V NC EC EXTSMI# 10K Pull +3V 10K Pull +3V

NC

NC Clock GEN STP_PCI# WLAN_LED# STP_CPU#

NC

NA

NC

3G

NC

Type

Input/Output Set

I

fixed as Input only fixed as Input only

I

fixed as Input only

I

fixed as Input only

I

fixed as Input only

I

fixed as Input only Input

I

fixed as Input only

GPI

fixed as Input only

GPI I

Input NC

I

Input

I

Input fixed as Input only

GPI

fixed as Input only

GPI I Input

Input

I O

Output

O

Output Output

O GPO

fixed as Output only

O

Output GPO NA

NA GPO

fixed as Output only

Output

I/O I/O

Output

AF17

Pin Name

GPI26/SATA0GP

R3

GPIO28

T3

GPI29 / SATA1GP

AE18

GPI30 / SATA2GP

AF18 AG18

GPI31 / SATA3GP

AF19

GPIO32 / CLKRUN#

AF20

GPIO33

AC18 Output

GPIO34 GPIO35

NA NA

GPIO36 GPIO37

NA

GPIO38

NA NA

GPIO39 GPI40 / REQ4#

F7

GPI41 / LDRQ1#

P4 NA

GPIO42

NA

GPIO43 GPIO44

NA

GPIO45

NA NA

GPIO46

NA

GPIO47

E7

GPO48 /GNT4# GPO49 / CPUPWRGD

AC25

Connect to

NC NC NC PCBVER0 NC PCBVER1 10K Pull +3V NC

Type

GPII I/OGPIO27 I/O GPI GPI GPI I/O I/O

Input/Output Set

(GPI)Input Output Output (GPI)Input (GPI)Input10K Pull +3V (GPI)Input Input Output

I/O NA NA NA NA NA 10K Pull +3V NC NA

NA NA NA NA NC Output CPU Power Ok

NA

I

NA

O

NA NA NA NA NA Input Input NA NANA NA NA NA NA

Output

A A

Default Group-A7V8X MX

1

System Setting

Kell_Huang

251Monday, November 10, 2008

of

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

fixed as Output only

3

2

Date: Sheet

900SD_MB

Engineer:

5

*This sequence is for Battery Plug-in and no Adapter, if Adapter Plug-in,the sequence change to: A/D_DOCK_IN--->AC_BAT_SYS--->+3VA--->VSUS_ON--->+3VSB & +5VSB

--->VSUS_GD--->PM_REMRST#--->PWR_SW#--->PM_PWRBTN--->PM_SUSC#--->PM_SUSB#

4

http://hobi-elektronika.net

3

Only Battery Adapter In

2

Signal

VSUS_ON

SUSC_ON

S0/S1

H HSUSB_ON H

S3

S4/S5LPower

H

H L

L

1

VSBVSUS_ON H LH VSB Main DUALH

D D

21

C C

24

VID[0..5]

+VCCP

VCORE

23

Adapter

Battery

DOTHAN CPU

2

A/D_DOCK_IN

2

BAT_CON

MAX8724ETI

H_CPURST#

3

AC_BAT_SYS

6

3

AC_BAT_SYS

6

29

VSUS_ON

NB 910GM

AP4800+H431

APM7120

PMB3904 +AP2310

25

PLT_RST#

28

(logic AND of PWROK and VRM_PWROK)

+

BATT

B B

H_PWRGD

VCC_RTC

4

PWR_SW#

5

VSUS_ON

+3VA

1

6

27

RTCRST#

28

PCI_RST#

VRM_PWRGD

PM_RSMRST#

9

SB ICH6

PM_PWRBTN#

10

11

PM_SUSC#

12

EC KB3110

25

VRM_PWRGD

A A

28

PCI_RST#

IDE FLASH CONTROLLOR SM223

5

28

PLT_RST#

LAN ATTANSIC L2

4

PM_PWROK

PM_SUSB#

28

PLT_RST#

4

+3VA

7

+3VSB

7

+5VSB

7

AC_VCC

26

PM_PWROK

(160mS after VRM_PWRGD)

26

13

14

19

(55mS after SUSB_ON)

8

2*PMBS3904 +2N7002

(PLT_RST# is 34--41 RTCC LK( =1 mS ) later than PM_PWROK,H_ CPU RST# i s 1mS after PLT_RST#)

VSUS_GD

8

SUSC_ON

SUSB_ON

CPU_VRON

VSUS_GD

MINICARD

3

19

7

+5VSB

CPU_VRON

AC_BAT_SYS

3

13

7

AC_BAT_SYS

3

LM358+ PMBT2222

22

3

AC_BAT_SYS

14 23

CPU_VRON

19

SUSC_ON

14

7

14

AC_VCC

20

1.05V_OCSET

VCCP_OK

+5V

VID[0..5]

2

APM7120

+5VSB

7

SUSB_ON

+3VSB

SUSB_ON

15

+1.8V_DUAL

15

ISL6218CRZ

+1.8V_DUAL

+5V

15

AP2301

15

SI4835BDY

+3V

+5V

LM358+ PMBT2222

16

LM358+

+5V

AP70T03

21

APW7120

+VCCP

CLK_PCI_EC

CLK_PCIE_ICH

CYS28442

CLK_BCLK_CPU

24

VCORE

VCORE_PG

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

RT9173

+5V

+3V

+2.5V

+1.5V

DELAY

23

VCCP_OK

25

AND

Engineer:

900SD_MB

VTT_DDR

22

VRM_PWRGD

Title :

1

VCCP_OK

Power Sequence

Kell_Huang

351Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

EC KB3310 GPIO SETTING

Pin No.

1 2 6 13

D D

14 15 16 17 18 19 20 21 23 25 26 27 28 29

C C

30 31 32 34

36

38 39 40 41 42

Pin Name

GA20 KBRST#

GPIO04

PCIRST# GPIO07 GPIO08 GPIO0A GPIO0B GPIO0C GPIO0D SCI# PWM1 PWM2 GPIO11 FANPWM1 FANPWM2 FANFB1 FANFB2 GPIO16 GPIO17 GPIO18 GPIO19

GPIO1A

CLKRUN# KSO0 KSO1 KSO2 KSO3

43

KSO5

44 45

KSO6 KSO7

46 47

B B

KSO8 KSO9

48

KSO10 KSO11

50

KSO12

51

KSO13

52 53

KSO14

54

KSO15 KSI0

55

KSI1

56

KSI2

57

KSI3

58 59

KSI4

60

KSI5

61

A A

KSI6

62

KSI7

63

AD0

64

AD1

65

AD2 AD3

66

GPO3C

68

5

Signal Name

A20GATE RC_IN#

CTRL_CAMER_PWR

PCI_RST# N.C EXTSMI# LID_EC# P LCD_CSB LCD_SDA DISTP_SW#

BL_PWM_DA LCD_SCL PM_PWRBTN# FAN0_PWM FAN1_PWM FAN0_TACH FAN1_TACH E51_TX N.C PWR_SW# MAIL_LED# CTRL_L2_PWR

CTRL_Mincard_PWR

N.C KSO0 KSO1 KSO2 KSO3 KSO4 KSO5 KSO6 KSO7 KSO8 KSO9 KSO1049 KSO11 KSO12 KSO13 KSO14 KSO15 KSI0 KSI1 KSI2 KSI3 KSI4 KSI5 KSI6 KSI7 P_PMON_10 BAT_IN N.C N.C DOC

NOTE

Type

A20GATE

O O

KBRST#

Default : High

I I

PCI Reset Reserved

O

EXTSMI#, 10K Pull +3VSUS

O I

LID_EC#, * LCD chip select

O

LCD Data

I/O

Touch Pad Disabled,*

I

KBC_SCI#, 10K Pull +3VSUS

O O

LCD Light Switch

O

LCD clock

OD

Power Button to SB, *

O

CPU Fan(Unused) VGA Fan(Unused)

O I

CPU FanTach(Unused)

I

VGA FanTach(Unused)

O

RS232 debug port

O

Reserved power button, *

I

Mail LED(Unused)

O

Default : High

O

Reserved

O

For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

O O

For Keyboard interface

O

For Keyboard interface For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

O O

For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

O

For Keyboard interface

I I

For Keyboard interface

I

For Keyboard interface

I

For Keyboard interface For Keyboard interface

I

For Keyboard interface

I

For Keyboard interface

I

For Keyboard interface

I I

Sense Power Loading sense Battery

I I

Reserved

I

Reserved

O

Trigger Clock Gen

4

http://hobi-elektronika.net

Type

Pin No.

70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 Reserved 86 87 88 89 90

91

92 93 95 97 98 99 100 101 102 103 104 105 106 107 108 109 110 112 114 115 116 117 118 121 126 127

Pin Name

GPO3D GPO3E GPO3F GPIO40 GPIO41 GPIO42 GPIO43 SCL1 SDA1 SCL2 SDA2 KSO16 KSO17 PSCLK1 PSDAT1 PSCLK2 PSDAT2 PSCLK3 PSDAT3 GPIO50 GPIO52

GPIO53

GPIO54 GPIO55 GPIO56 GPXOA00 GPXOA01 GPXOA02 GPXOA03 GPXOA04 GPXOA05 GPXOA06 GPXOA07 GPXOA08 GPXOA09 GPX0A10 GPXOA11 GPXID0 GPXID1 GPXID2 GPXID3 GPXID4 GPXID5 GPXID6 GPXID7 GPIO57 SPICLK GPIO59

Signal Name

LCD_BACKOFF# CLK_PWRSAVE# BAT_LL# AC_OK PM_RSMRST# N.C N.C SMB0_CLK SMB0_DAT SMB1_CLK SMB1_DAT N.C N.C N.C N.C N.C N.C TP_CLK TP_DAT BATSEL_3S CHG_LED_UP#

PWR_LED_UP SCRL_LED# PWR4G_SW# SPI_MODE# SUSC_ON VSUS_ON CPU_VRONKSO4 SUSB_ON ICH8_PWROK N.C CHG_EN# PRECHG SPI_WP# OP_SD# BAT_LEARN BATSEL_2P# N.C THRO_CPU SUSB# SUSC# CPUPWR_GD VSUS_GD N.C INTERNET# SPI_CLK N.C

3

NOTE

O

LCD_BACKOFF#

Active when BAT_IN=1 and

O

AC_OK=0(Unused)

Battery Low Low

O I

AC Adaptor Plug in

O

10K Pull GND Reserved

O

Reserved

O I/OD

4.7K Pull +3VA_EC

I/OD

4.7K Pull +3VA_EC 10K Pull +3VS

I/OD

10K Pull +3VS

I/OD

Reserved

O O

Reserved

O

Reserved Reserved

O O

Reserved

O I/OD

10K Pull +3VS 10K Pull +3VS

I/OD

Battery series. Hi:3S,

O

Lo:4S(Unused)

charger LED

O

Default : High

O

EC H/W blinking

O

EC H/W controls

O

*

I

"HW Strap for SPI Flash deExternal

O

Pull Down 100K ohm to GND"

O O O O O

Reserved

O O

Battery charging enabled O O

Audio OP

O O

Battery parallel. Hi:1P,

O

Lo:2P~3P

Reserved

O

Active if Battery

O

Temperature is over spec

Pull Down 100K ohm to GND

I

Pull Down 100K ohm to GND

I

10K Pull +3VS

I

Disabled **

I O

Reserved *

I

SPI Clock

O

Reserved

O

EC KB3310 Other Pin SETTING

Pin No.

4 5 7 8 9 10 11 12 22 24 33 35 37 67 69 94 96 111 113 119 120 112 123 124 125 128

SERIRQ LFRAME# LAD3 LAD2 LAD1 VCC LAD0 GND PCICLK VCCKBC_SCI# GND VCC GND ECRST# AVCC AGND GND VCC VCC GND RD# WR# XCLKI XCLKO V18R VCC SPICS#

2

Pin Name

Signal Name

INT_SERIRQ LPC_FRAME# LPC_AD3 LPC_AD2 LPC_AD1

Type

I/OD I I/O I/O

I/O +3VA_EC LPC_AD0 GND CLK_PCI_EC +3VA_EC GND +3VA_EC GND EC_RST# +3VACC AGND GND +3VA_EC +3VA_EC GND SPI_SO SPI_SI 32KXCLKI 32KXCLKO K_V18R +3VA_EC SPI_CE#

Default Group-A7V8X MX

I/O

P

I

P

I

Add 100K ohm to GND P P P P P P I O I O

Reserved 1uF to GND P O

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

NOTE

8.2K Pull +3VS3

EC Pin Define

Kell_Huang

451Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

CIRCUIT UPDATED HISTORY

http://hobi-elektronika.net

Rev DescriptionDate

1.0G

D D

C C

2008.10.15900SD

Initial Release

B B

A A

Default Group-A7V8X MX

1

History

Hauld Zhou

551Monday, November 10, 2008

Rev

R1.0G

of

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

4

3

2

1

http://hobi-elektronika.net

12

CC1 10uF/10V

/427 c0805

+3VSUS_CLK

C_REQ#_L2_R

C_PCI_EC_R

C_PCI_SB_R C_48M_R

C_FSLA

C_FSLB

C_PCI_EC_R CLK_RST#

C_PCI_SB_R

CLKREQ#_MINICARD

C_REQ#_L2_R

12

CC2

0.1UF/16V

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29

GND

CR2 10KOhm CR16 10KOhm

3 4

5 6

7 8

CC4

CC3

0.1UF/16V

/X/427

CU1

VDD1 GND1 PEREQ1# PEREQ2# FS4/PCICLK0 GND2 VDDPCI ITP_EN/PCICLK_F0 SEL12_48#/12_48MHz Vtt_PwrGd/PD# VDD2 FSLA/USB_48MHz GND3 DOTT_96MHzLR DOTC_96MHzLR FSLB PCIeT_LR0 PCIeC_LR0 PCIeT_LR1 PCIeC_LR1 VDDPCIEX1 PCIeT_LR2 PCIeC_LR2 PCIeT_LR3 PCIeC_LR3 SATACLKT_LR SATACLKC_LR VDDPCIEX2 GND6

ICS9LPRS427AGLF

10KOhm 10KOhm 10KOhm 10KOhm

DOC_PEREQ3#/SELDOC#

CPUITPT_LR2/PCIeT_LR6

CPUITPC_LR2/PCIeC_LR6

12

/X/427

12

/X

CRN1B CRN2B CRN2C CRN2D

12

CC5

0.1UF/16V

/X/427

25MHz

PCI&PCIEX_STOP#

CPU_STOP#

REF0/FSLC

GND4

VDDREF

SDATA

SCLK

GND5

CPUT_LR0

CPUC_LR0

VDDCPU

CPUT_LR1

CPUC_LR1

RESET#

GNDA VDDA

VDDPCIEX3

PCIeT_LR5 PCIeC_LR5 PCIeT_LR4 PCIeC_LR4

+3VSUS_CLK

12

CC6

0.1UF/16V

/X/427

X1 X2

12

CC8

0.1UF/16V

+3VSUS_CLK

12

CC9

0.1UF/16V

/X/427

CC7

0.1UF/16V

/X/427

+3VSUS_CLK

56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30

GND

C_FSLC

C_XIN C_XOUT

CLK_RST#

12

CC10

0.1UF/16V

/X/427

CR4 33Ohm

1 2

CR15 0Ohm

12

CC11

0.1UF/16V

/X/427

/X

STP_PCI# 14 STP_CPU# 14 CLK_REF_ICH 14 DOC 36

S_SMB_DATA 15 S_SMB_CLK 15

CLK_BCLK_CPU 7 CLK_BCLK_CPU# 7

CLK_BCLK_MCH 9 CLK_BCLK_MCH# 9 SYS_RESET# 7,14

CLK_BCLK_ITP 7 CLK_BCLK_ITP# 7

CLK_PCIE_MCH 11 CLK_PCIE_MCH# 11 CLK_PCIE_ICH 15 CLK_PCIE_ICH# 15CLK_SATA_ICH#15

S_SMB_DATA S_SMB_CLK

CLK_RST#

1 2

10.23 For EMI

CLK_PCIE_3GCARD

CLK_PCIE_3GCARD#

C_PCIE_LAN C_PCIE_LAN#

CLK_PCI_ICH

CLK_PCI_EC

CLK_PCI_DEBUG

CLK_REF_ICH

CLK_48M_USB

CLK_48M_CR CLK_96M_UMA CLK_96M_UMA# CLK_LCD_LVDS CLK_LCD_LVDS#

CC28 5PF/50V CC29 5PF/50V

CC36 10PF/50V

CC42 10PF/50V

CC38 10PF/50V

CC39 22PF/25V

CC40 15PF/50V

CC35 15PF/50V CC43 10PF/50V CC44 10PF/50V CC45 10PF/50V CC46 10PF/50V

For RF Advise

CC14 10PF/50V

12

EC139

EC140

1 2 1 2

12

12 12 12 12 12

/X/427 /x/427

10PF/50V

/x/427

10PF/50V

/x/427

/X /X

/x/427

/x/427 /x/427 /x/427 /x/427 /x/427

GND

CC15 10PF/50V

EC165

/X

0.1UF/16V

GND

CR1 1MOHM

1 2

C_XIN

12

CC12 27PF/50V

D D

GND

/X/427

CX1

12

C_XOUT

14.318Mhz

12

GND

CC13 27PF/50V

+3VSUS

1 2

+3VS

1 2

CR17

0Ohm

/X/427

CR11

0Ohm

+3VSUS_CLK

GND

N/A for Debug,pR will /X

CR10 0Ohm

C_REQ#_LAN26

CLKREQ#_MINICARD25

CLK_PCI_DEBUG37

CLK_PCI_EC36 CLK_PCI_ICH14 CLK_48M_CR31

C C

1:Disable 0:Enable

B B

PEREQ1:PCIEx0 & PCIEx1 PEREQ2:PCIEx2 & PCIEx3 & SATA PEREQ3:PCIEx4 & PCIEx5 & PCIEx6

CLK_48M_USB15 CLK_96M_UMA9

CLK_96M_UMA#9 C_PCIE_LAN26

C_PCIE_LAN#26 CLK_PCIE_3GCARD24 CLK_PCIE_3GCARD#24

CLK_LCD_LVDS9

CLK_LCD_LVDS#9

CLK_PCIE_MINICARD25

CLK_PCIE_MINICARD#25

CLK_SATA_ICH15

+VCCP_OK46,50

1 2

CR3 33Ohm

1 2

33OHM

5 6

33OHM

7 8

33OHM

3 4

33OHM

CRN8A CRN8C CRN8D

CRN8B

/X/427 /DEBUG

CR5

7.15KOhm

GND

1 2

12

CR7

4.7KOhm

1%

CLK_FSLC

1.8V-3.3V 10

0.7V-1.8V 0V-0.35V

Straping Define enter Test Mode FSB trap High FSB trap Low

2

+3VSUS_CLK

C_FSLA

A A

5

C_FSLB

C_48M_R C_PCI_EC_R

4

5 6 1 2

7 8 1 2

10KOhm 10KOhm

CRN1C CRN1A

CRN1D CRN2A

GND

3

C_FSLC

FSLC

FSLB

0

1

Default Group-A7V8X MX

FSLA

1

CPU(MHZ)

133.33

100

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

Clock Gen_ICS9LPR427

Hauld Zhou

Rev

651Monday, November 10, 2008

R1.0G

of

5

4

3

2

1

H_D#[63:0] 9 H_DINV#[3:0] 9 H_DSTBN#[3:0] 9 H_DSTBP#[3:0] 9

D D

C C

B B

H_ADSTB#09

H_A#[31:3] 9 H_REQ#[4:0] 9

A A

H_ADSTB#19

H_DPWR#9

H_D#15 H_D#14 H_D#13 H_D#12 H_D#11 H_D#10 H_D#9 H_D#8 H_D#7 H_D#6 H_D#5 H_D#4 H_D#3 H_D#2 H_D#1 H_D#0 H_DINV#0 H_DSTBN#0 H_DSTBP#0

H_D#31 H_D#30 H_D#29 H_D#28 H_D#27 H_D#26 H_D#25 H_D#24 H_D#23 H_D#22 H_D#21 H_D#20 H_D#19 H_D#18 H_D#17 H_D#16 H_DINV#1 H_DSTBN#1 H_DSTBP#1

5

H_A#16 H_A#15 H_A#14 H_A#13 H_A#12 H_A#11 H_A#10 H_A#9 H_A#8 H_A#7 H_A#6 H_A#5 H_A#4 H_A#3

H_REQ#4 H_REQ#3 H_REQ#2 H_REQ#1 H_REQ#0

H_A#31 H_A#30 H_A#29 H_A#28 H_A#27 H_A#26 H_A#25 H_A#24 H_A#23 H_A#22 H_A#21 H_A#20 H_A#19 H_A#18 H_A#17

U16A

C25

D[15]#

E23

D[14]#

B23

D[13]#

C26

D[12]#

E24

D[11]#

D24

D[10]#

B24

D[9]#

C20

D[8]#

B20

D[7]#

A21

D[6]#

B26

D[5]#

A24

D[4]#

B21

D[3]#

A22

D[2]#

A25

D[1]#

A19

D[0]#

D25

DINV[0]#

C23

DSTBN[0]#

C22

DSTBP[0]#

K25

D[31]#

N25

D[30]#

H26

D[29]#

M25

D[28]#

N24

D[27]#

L26

D[26]#

J25

D[25]#

M23

D[24]#

J23

D[23]#

G24

D[22]#

F25

D[21]#

H24

D[20]#

M26

D[19]#

L23

D[18]#

G25

D[17]#

H23

D[16]#

J26

DINV[1]#

K24

DSTBN[1]#

L24

DSTBP[1]#

860555INT_FCBGA479

01G011920001PM

U16B

AA2

A[16]#

Y3

A[15]#

AA3

A[14]#

U1

A[13]#

Y1

A[12]#

Y4

A[11]#

W2

A[10]#

T4

A[9]#

W1

A[8]#

V2

A[7]#

R3

A[6]#

V3

A[5]#

U4

A[4]#

P4

A[3]#

U3

ADSTB[0]#

T1

REQ[4]#

P1

REQ[3]#

T2

REQ[2]#

P3

REQ[1]#

R2

REQ[0]#

AF1

A[31]#

AE1

A[30]#

AF3

A[29]#

AD6

A[28]#

AE2

A[27]#

AD5

A[26]#

AC6

A[25]#

AB4

A[24]#

AD2

A[23]#

AE4

A[22]#

AD3

A[21]#

AC3

A[20]#

AC7

A[19]#

AC4

A[18]#

AF4

A[17]#

AE5

ADSTB[1]#

C19

DPWR#

860555INT_FCBGA479

01G011920001PM

D[47]# D[46]# D[45]# D[44]# D[43]# D[42]# D[41]# D[40]# D[39]# D[38]# D[37]#

DATA GROUP 0DATA GROUP 1

D[36]# D[35]#

DATA GROUP 2DATA GROUP 3

D[34]# D[33]# D[32]#

DINV[2]# DSTBN[2]# DSTBP[2]#

D[63]# D[62]# D[61]# D[60]# D[59]# D[58]# D[57]# D[56]# D[55]# D[54]# D[53]# D[52]# D[51]# D[50]# D[49]# D[48]#

DINV[3]# DSTBN[3]# DSTBP[3]#

ADS# PRDY# PREQ#

BNR#

BPRI#

DBR#

ADDRESS GROUP 0ADDRESS GROUP 1

DEFER#

DRDY# DBSY#

BR0#

CONTROL

IERR#

INIT#

LOCK#

RESET#

RS[2]# RS[1]# RS[0]#

TRDY#

HIT#

HITM#

Y25 AA26 Y23 V26 U25 V24 U26 AA23 R23 R26 R24 V23 U23 T25 AA24 Y26 T24 W25 W24

AF26 AF22 AF25 AD21 AE21 AF20 AD24 AF23 AE22 AD23 AC25 AC22 AC20 AB24 AC23 AB25 AD20 AE24 AE25

N2 A10 B10

L1 J3

A7

L4 H2 M2

N4

A4

B5

J2

B11 L2 K1 H1

M3

K3 K4

H_D#47 H_D#46 H_D#45 H_D#44 H_D#43 H_D#42 H_D#41 H_D#40 H_D#39 H_D#38 H_D#37 H_D#36 H_D#35 H_D#34 H_D#33 H_D#32 H_DINV#2 H_DSTBN#2 H_DSTBP#2

H_D#63 H_D#62 H_D#61 H_D#60 H_D#59 H_D#58 H_D#57 H_D#56 H_D#55 H_D#54 H_D#53 H_D#52 H_D#51 H_D#50 H_D#49 H_D#48 H_DINV#3 H_DSTBN#3 H_DSTBP#3

H_BPM#4 H_BPM#5

H_DBR#

H_IERR#

H_RS#2 H_RS#1 H_RS#0

1

4

http://hobi-elektronika.net

HC1 10PF/50V

12

HC2 10PF/50V

12

GND

H_PWRGD14

For Dothan 800

U16 use 01G011920000PM

H_ADS# 9

H_BNR# 9 H_BPRI# 9

T9TPC26T

+VCCP

1 2 12

GND

+VCCP

HR24 56OHM

/X

HC7

0.1UF/16V

/X

H_DEFER# 9 H_DRDY# 9 H_DBSY# 9

H_BR0# 9

H_INIT# 14

H_LOCK# 9

H_RS#[2:0] 9

H_TRDY# 9

H_HIT# 9 H_HITM# 9

CLK_BCLK_CPU

/X

CLK_BCLK_CPU#

/X

1 2

HR3 49.9Ohm 1%

1 2

HR5 49.9Ohm 1%

GND

1 2

HR9

200Ohm

1%

HR14 56OHM

/900/X

HR28

54.9Ohm

1%

H_CPURST# 9

+VCCP

1 2 12

GND

+VCCP

1 2

HC3

0.1UF/16V

CLK_BCLK_CPU6 CLK_BCLK_CPU#6

+VCCA

H_THERMTRIP#9,14

H_A20M#14

H_FERR#14 H_IGNNE#14 H_DPSLP#14

H_INTR14 H_NMI14 H_SMI#14 H_STPCLK#14

T3 TPC26T T177TPC26T T178TPC26T

H_THERMDA39 H_THERMDC39

T170 TPC26T T4 TPC26T T5 TPC26T T6 TPC26T T7 TPC26T T8 TPC26T

HR18

1 2

0Ohm

r0603_h24

+VCCP

HR91

3

H_ITP_CLK H_ITP_CLK#

H_CPUSLP#

H_VCCA3

1

H_VCCA2

1

H_VCCA1

1

H_PROCHOT# PM_PSI#

1

CPU_BSEL0

1

H_RSVD3

1

CPU_BSEL1

1

H_RSVD1

1

H_RSVD0

1

+VCCA+1.5VS

12

HC5 22UF/6.3V

/X

H_PWRGD

62Ohm

/XDP/X

120 mA

AC26

12

HC6

0.1UF/16V

GND

HR25 0Ohm

/XDP

1 2 12

U16C

B15

BCLK[0]

B14

BCLK[1]

A16

ITP_CLK[0]

A15

ITP_CLK[1]

C2

A20M#

D3

FERR#

A3

IGNNE#

A6

SLP#

D1

LINT0

D4

LINT1

B4

SMI#

C6

STPCLK#

E4

PWRGOOD

H4

VID[5]

G4

VID[4]

G3

VID[3]

F3

VID[2]

F2

VID[1]

E2

VID[0]

VCCA[3]

N1

VCCA[2]

B1

VCCA[1]

F26

VCCA[0]

B18

THERMDA

A18

THERMDC

C17

THERMTRIP#

B17

PROCHOT#

E1

RSVD5

C16

RSVD4

C3

RSVD3

C14

RSVD2

AF7

RSVD1

B2

RSVD0

860555INT_FCBGA479

01G011920001PM

H_BPM#0 H_BPM#1 H_BPM#2 H_BPM#3

H_BPM#4

XDP_PWRGD

TESTIN#

SMB_CLK15,25 SMB_DATA15,25

COMP[3] COMP[2]

HOSTCLKLEGACY CPU

COMP[1] COMP[0]

BPM[3]#DPSLP# BPM[2]# BPM[1]# BPM[0]#

GTLREF[3] GTLREF[2] GTLREF[1] GTLREF[0]

TEST1 TEST2

MISC

TDO TMS

TRST#

VCCSENSE

VSSSENSE

TCK

TDI

+VCCP

H_CPUSLP#

H_COMP3

AB1

H_COMP2

AB2

H_COMP1

P26

H_COMP0

P25

H_BPM#3

C9B7

H_BPM#2

A9

H_BPM#1

B8

H_BPM#0

C8

H_GTLREF3

AC1

H_GTLREF2

G1

H_GTLREF1

E26

H_GTLREF

AD26

H_TEST1

C5

H_TEST2

F23

H_TCK

A13

H_TDI

C12

H_TDO

A12

TMS

H_

C11

H_TRST#

B13

H_VCCSENSE

AE7

H_VSSSENSE

AF6

Close to CPU

3 4 1 2 7 8 5 6

HR90 51Ohm

51OHM 51OHM 51OHM 51OHM

1 2

HRN10B HRN10A HRN10D HRN10C

HR1 0Ohm

1 2

HR2 0Ohm /X

1 2

HR4 54.9Ohm 1%

1 2

HR6 27.4Ohm 1%

1 2

HR7 54.9Ohm 1%

1 2

HR8 27.4Ohm 1%

1 2

1 1

HR11 1KOhm 1% /X HR12 1KOhm 1% /X

/XDP

T1TPC26T

HR10 0Ohm

1 2

T2TPC26T

1 2 1 2

HR16 54.9Ohm

1 2

HR17 54.9Ohm

1 2

/XDP /XDP /XDP /XDP

1%/X

+VCCP

XDP

H_BPM#5

2

H_BPM#3 H_BPM#4 H_BPM#2

H_TCK

GND

GND1

4

BPM3#

6

BPM2#

8

GND2

10

PWRGOOD

12

RESERVED

14

VTT

16

GCLKp

18

GCLKn

20

GND3

22

SCL

24

SDA

26

GND4

28

NC

30

TCK

BTOB_CON_31P

/XDP/X

2

1

BPM5#

3

BPM4#

5

GND5 BPM1# BPM0#

GND6 BCLK0 BCKL1

GND7

RESET#

DBR#

TDO

TRST#

GND8

TMS

H_BPM#1

7

H_BPM#0

9 11 13 15 17 19 21

H_TDO

23

H_TRST#

25 27 29

TDI

31

GND

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

GND

/X

H_TDI H_TMS

H_DPRSTP# 14

GND

H_BPM#5 H_TDO

H_TMS H_TDI H_TCK H_TRST#

CPURST_ITP#

SYS_RESET# 6,14

Default Group-A7V8X MX

900SD_MB

N_CPUSLP# 9 S_CPUSLP# 14

+VCCP

HR13 1KOhm

1%

H_GTLREF

1 2

12

HR15

HC4

2KOhm

0.1UF/16V

1%

1 2

GND GND

HR20 54.9Ohm 1%

1 2

HR21 56OHM /XDP

1 2

56Ohm 56Ohm 56Ohm 56Ohm

CLK_BCLK_ITP 6 CLK_BCLK_ITP# 6

H_CPURST#

HR22 0Ohm

/XDP

Title :

Engineer:

1

HRN1A HRN1B HRN1C HRN1D

Dothan_HOST

Kell_Huang

751Monday, November 10, 2008

1 2 3 4 5 6 7 8

1 2

+VCCP

GND

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

+VCCP +VCORE

2.5 A

U16D

D D

C C

B B

W4

P23

D10 D12 D14 D16 E11 E13 E15 F10 F12 F14 F16

L21 M22 N21 P22 R21 T22

U21

VCCQ[1] VCCQ[0]

VCCP1 VCCP2 VCCP3 VCCP4 VCCP5 VCCP6 VCCP7 VCCP8 VCCP9 VCCP10 VCCP11

K6

VCCP12

L5

VCCP13 VCCP14

M6

VCCP15 VCCP16

N5

VCCP17 VCCP18

P6

VCCP19 VCCP20

R5

VCCP21 VCCP22

T6

VCCP23 VCCP24 VCCP25

VCC72

AF18

VCC71

AF16

VCC70

AF14

VCC69

AF12

VCC68

AF10

VCC67

AF8

VCC

VCC63

VCC64

VCC65

VCC66

AE13

AE15

AE17

AE19

VCC62

AE11

D6

VCC1

D8

VCC2

D18

VCC3

D20

VCC4

D22

VCC5

E5

VCC6

E7

VCC7

E9

VCC8

E17

VCC9

E19

VCC10

E21

VCC11

F6

VCC12

F8

VCC13

F18

VCC14

F20

VCC15

F22

VCC16

G5

VCC17

G21

VCC18

H6

VCC19

H22

VCC20

J5

VCC21

J21

VCC22

K22

VCC23

U5

VCC24

V6

VCC25

V22

VCC26

W5

VCC27

W21

VCC28

Y6

VCC29

Y22

VCC30

AA5

VCC31

AA7

VCC32

AA9

VCC33

AA11

VCC34

AA13

VCC35

AA15

VCC36

AA17

VCC37

AA19

VCC38

AA21

VCC39

AB6

VCC40

AB8

VCC41

AB10

VCC42

AB12

VCC43

AB14

VCC44

AB16

VCC45

AB18

VCC46

AB20

VCC47

AB22

VCC48

AC9

VCC49

AC11

VCC50

AC13

VCC51

AC15

VCC52

AC17

VCC53

AC19

VCC54

AD8

VCC55

AD10

VCC56

AD12

VCC57

AD14

VCC58

AD16

VCC59

AD18

VCC60

VCC61

860555INT_FCBGA479

AE9

01G011920001PM

Celeron-M(Dothan) ULV max 7 A

+VCORE

12

HCE1

10UF/6.3V

N/A

c0805

GND GND

+VCCP

12

HC28 10UF/6.3V

/CAP/X

12

HC27 10UF/6.3V

12

+

HCE2

100U/2.5V

/CAP/X

+VCORE

12

HC23

0.1UF/16V

/CAP/X

HC29 10UF/6.3V

12

HC20

0.1UF/16V

+VCCP

12

HCE3

10UF/6.3V

/X

c0603

0.1U All X7R

12

HC24

0.1UF/16V

GND

12

HC21

0.1UF/16V

12

+

HCE4

100U/2.5V

/CAP/X

900SD R1.0G

12

HC26

0.1UF/16V

/CAP/X

12

HC22

0.1UF/16V

/CAP/X

GND

12

HC25

0.1UF/16V

U16E

A2

VSS1

A5

VSS2

A8

VSS3

A11

VSS4

A14

VSS5

A17

VSS6

A20

VSS7

A23

VSS8

A26

VSS9

B3

VSS10

B6

VSS11

B9

VSS12

B12

VSS13

B16

VSS14

B19

VSS15

B22

VSS16

B25

VSS17

C1

VSS18

C4

VSS19

C7

VSS20

C10

VSS21

C13

VSS22

C15

VSS23

C18

VSS24

C21

VSS25

C24

VSS26

D2

VSS27

D5

VSS28

D7

VSS29

D9

VSS30

D11

VSS31

D13

VSS32

D15

VSS33

D17

VSS34

D19

VSS35

D21

VSS36

D23

VSS37

D26

VSS38

E3

VSS39

E6

VSS40

E8

VSS41

E10

VSS42

E12

VSS43

E14

VSS44

E16

VSS45

E18

VSS46

E20

VSS47

E22

VSS48

E25

VSS49

F1

VSS50

F4

VSS51

F5

VSS52

F7

VSS53

F9

VSS54

F11

VSS55

F13

VSS56

F15

VSS57

F17

VSS58

F19

VSS59

F21

VSS60

F24

VSS61

G2

VSS62

G6

VSS63

G22

VSS64

860555INT_FCBGA479

01G011920001PM

AF24

AF21

VSS192

VSS65

G23

G26H3H5

AF19

AF17

VSS191

VSS190

VSS66

VSS67

AF15

AF13

VSS189

VSS188

VSS68

VSS69

H21

H25J1J4J6J22

AF11

AF9

VSS187

VSS186

VSS70

VSS71

AF5

AF2

VSS185

VSS184

VSS72

VSS73

AE26

AE23

VSS183

VSS182

VSS74

VSS75

J24K2K5

AE20

AE18

VSS181

VSS180

VSS76

VSS77

K21

VSS179

VSS78

AE16

AE14

AE12

AE10

AE8

VSS178

VSS177

VSS176

VSS175

GND

VSS82

VSS81

VSS80

VSS79

L22L6L3

K26

K23

AE6

AE3

VSS174

VSS173

VSS84

VSS83

AD25

AD22

VSS172

VSS171

VSS86

VSS85

AD19

AD17

VSS170

VSS169

VSS88

VSS87

M24

M21M5M4M1L25

AD15

AD13

VSS168

VSS167

VSS90

VSS89

AD11

AD9

VSS166

VSS165

VSS92

VSS91

N23

N22N6N3

AD7

AD4

VSS164

VSS163

VSS94

VSS93

P2

N26

AD1

VSS162

VSS161

VSS95

VSS96

P5

VSS160 VSS159 VSS158 VSS157 VSS156 VSS155 VSS154 VSS153 VSS152 VSS151 VSS150 VSS149 VSS148 VSS147 VSS146 VSS145 VSS144 VSS143 VSS142 VSS141 VSS140 VSS139 VSS138 VSS137 VSS136 VSS135 VSS134 VSS133 VSS132 VSS131 VSS130 VSS129 VSS128 VSS127 VSS126 VSS125 VSS124 VSS123 VSS122 VSS121 VSS120 VSS119 VSS118 VSS117 VSS116 VSS115 VSS114 VSS113 VSS112 VSS111 VSS110 VSS109 VSS108 VSS107 VSS106 VSS105 VSS104 VSS103 VSS102 VSS101 VSS100

VSS99 VSS98 VSS97

AC24 AC21 AC18 AC16 AC14 AC12 AC10 AC8 AC5 AC2 AB26 AB23 AB21 AB19 AB17 AB15 AB13 AB11 AB9 AB7 AB5 AB3 AA25 AA22 AA20 AA18 AA16 AA14 AA12 AA10 AA8 AA6 AA4 AA1 Y24 Y21 Y5 Y2 W26 W23 W22 W6 W3 V25 V21 V5 V4 V1 U24 U22 U6 U2 T26 T23 T21 T5 T3 R25 R22 R6 R4 R1 P24 P21

GND

+VCORE

HC10 10UF/6.3V

/CAP/X

12

A A

5

HC11 10UF/6.3V

/CAP/X

12

4

HC12 10UF/6.3V

12

HC13 10UF/6.3V

12

HC14 10UF/6.3V

/CAP/X

12

HC15 10UF/6.3V

/CAP/X

12

HC16 10UF/6.3V

/CAP/X

3

12

HC17 10UF/6.3V

/CAP/X

c0805

GND

12

HC18 10UF/6.3V

/CAP/X

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

2

Date: Sheet

900SD_MB

Monday, November 10, 2008

Engineer:

Dothan_PWR_GND

Kell_Huang

1

8

Rev

R1.0G

of

51

5

4

3

2

1

http://hobi-elektronika.net

H_D#[63:0] 7 H_A#[31:3] 7

H_D#0 H_D#1

D D

C C

B B

N_HXSCOMP N_HYSCOMP

A A

N_HXRCOMP N_HYRCOMP

H_D#2 H_D#3 H_D#4 H_D#5 H_D#6 H_D#7 H_D#8 H_D#9 H_D#10 H_D#11 H_D#12 H_D#13 H_D#14 H_D#15 H_A#18 H_D#16 H_D#17 H_D#18 H_D#19 H_D#20 H_D#21 H_D#22 H_D#23 H_D#24 H_D#25 H_D#26 H_D#27 H_D#28 H_D#29 H_D#30 H_D#31 H_D#32 H_D#33 H_D#34 H_D#35 H_D#36 H_D#37 H_D#38 H_D#39 H_D#40 H_D#41 H_D#42 H_D#43 H_D#44 H_D#45 H_D#46 H_D#47 H_D#48 H_D#49 H_D#50 H_D#51 H_D#52 H_D#53 H_D#54

H_D#56 H_D#57 H_D#58 H_D#59 H_D#60 H_D#61 H_D#62 H_D#63

N_HXRCOMP N_HXSCOMP N_HXSWING N_HYRCOMP N_HYSCOMP N_HYSWING

NR17 54.9Ohm 1%

1 2

NR18 54.9Ohm 1%

1 2

NR19 24.9Ohm 1%

1 2

NR20 24.9Ohm 1%

1 2

E4 E1 F4

H7

E2 F1 E3

D3

K7 F2 J7 J8

H6

F3

K8 H5 H1 H2

K5

K6

J4 G3 H3

J1

L5

K4

J5

P7

L7

J3

P5

L3 U7

V6 R6 R5

P3

T8 R7 R8 U8 R4

T4

T5 R1

T3

V8 U6 W6 U3

V5 W8 W7 U2 U1

Y5

Y2

V4

Y7 W1 W3

Y3

Y6 W2

C1 C2 D1

T1

L1

P1

5

U1D

HD0# HD1# HD2# HD3# HD4# HD5# HD6# HD7# HD8# HD9# HD10# HD11# HD12# HD13# HD14# HD15# HD16# HD17# HD18# HD19# HD20# HD21# HD22# HD23# HD24# HD25# HD26# HD27# HD28# HD29# HD30# HD31# HD32# HD33# HD34# HD35# HD36# HD37# HD38# HD39# HD40# HD41# HD42# HD43# HD44# HD45# HD46# HD47# HD48# HD49# HD50# HD51# HD52# HD53# HD54# HD55# HD56# HD57# HD58# HD59# HD60# HD61# HD62# HD63#

HXRCOMP HXSCOMP HXSWING HYRCOMP HYSCOMP HYSWING

QG82910GMLE

+VCCP

GND

H_DSTBN#[3:0] 7 H_DSTBP#[3:0] 7

HA3# HA4# HA5# HA6# HA7# HA8#

HA9# HA10# HA11# HA12# HA13# HA14# HA15# HA16# HA17# HA18# HA19# HA20# HA21# HA22# HA23# HA24# HA25# HA26# HA27# HA28# HA29# HA30# HA31#

HADS# HADSTB0# HADSTB1#

HVREF

HBNR#

HBPRI#

HBREQ0#

HCPURST#

HCLKN

HCLKP

HOST

HDBSY#

HDEFER#

HDINV0# HDINV1# HDINV2# HDINV3#

HDPWR#

HDRDY# HDSTBN0# HDSTBN1# HDSTBN2# HDSTBN3# HDSTBP0# HDSTBP1# HDSTBP2# HDSTBP3#

RSVD32

HHIT#

HHITM# HLOCK# RSVD33 HREQ0# HREQ1# HREQ2# HREQ3# HREQ4#

HRS0# HRS1# HRS2#

HCPUSLP#

HTRDY#

H_DINV#[3:0] 7 H_REQ#[4:0] 7

H_A#3

G9

H_A#4

C9

H_A#5

E9

H_A#6

B7

H_A#7

A10

H_A#8

F9

H_A#9

D8

H_A#10

B10

H_A#11

E10

H_A#12

G10

H_A#13

D9

H_A#14

E11

H_A#15

F10

H_A#16

G11

H_A#17

G13 C10

H_A#19

C11

H_A#20

D11

H_A#21

C12

H_A#22

B13

H_A#23

A12

H_A#24

F12

H_A#25

G12

H_A#26

E12

H_A#27

C13

H_A#28

B11

H_A#29

D13

H_A#30

A13

H_A#31

F13 F8

B9 E13

N_HVREF

J11 A5 D5 E7 H10

AB1 AB2

C6 E6

H_DINV#0

H8

H_DINV#1

K3

H_DINV#2

T7

H_DINV#3

U5 G6 F7

H_DSTBN#0

G4

H_DSTBN#1

K1

H_DSTBN#2

R3

H_DSTBN#3H_D#55

V3

H_DSTBP#0

G5

H_DSTBP#1

K2

H_DSTBP#2

R2

H_DSTBP#3

W4

N_HEDRDY#

N_HPCREQ# H_REQ#0 H_REQ#1 H_REQ#2 H_REQ#3 H_REQ#4 H_RS#0 H_RS#1 H_RS#2

GND

1

12

NC11

0.1UF/16V

F6 D4 D6 B3 A11 A7 D7 B8 C7 A8 A4 C5 B4 G8 B5

+VCCP

NR13 221Ohm

1%

N_HXSWING

1 2

NR21 100Ohm

1%

1 2

GND GND

CLK_BCLK_MCH CLK_BCLK_MCH#

H_ADS# 7 H_ADSTB#0 7 H_ADSTB#1 7

H_BNR# 7 H_BPRI# 7 H_BR0# 7 H_CPURST# 7

CLK_BCLK_MCH# 6 CLK_BCLK_MCH 6

H_DBSY# 7 H_DEFER# 7

H_DPWR# 7 H_DRDY# 7

T54TPC26T

H_HIT# 7 H_HITM# 7 H_LOCK# 7

T56TPC26T

N_CPUSLP# 7 H_TRDY# 7

+VCCP

NR14 221Ohm

1%

N_HYSWING

1 2

NR22 100Ohm

1%

1 2

GND

4

12

GND

H_RS#[2:0] 7

NC3 10PF/50V

12 12

+VCCP

/X /X

NR15 100Ohm

1%

N_HVREF

1 2

NR23 200Ohm

1%

1 2

NC4 10PF/50V

NC12

0.1UF/16V

GND

12

NC13

0.1UF/16V

JP1 JP2

+1.8V

GND

3

NR16 1KOhm

1%

N_MVREF

1 2

NR24 1KOhm

1%

1 2

MCLK_DDR017,19 MCLK_DDR118,20

T44 TPC26T

MCLK_DDR0#17,19 MCLK_DDR1#18,20

T50 TPC26T

MA_CKE019,20,21 MA_CKE117,18,21

MA_CS#019,20,21 MA_CS#117,18,21

MA_ODT019,20,21 MA_ODT117,18,21

1 2 1 2

12

GND

SHORTPIN SHORTPIN

NC14

0.1UF/16V

DMI_RXN[3:0] 15 DMI_RXP[3:0] 15

DMI_TX DMI_TXN1 DMI_TXN2 DMI_TXN3

DMI_TXP0 DMI_TXP1 DMI_TXP2 DMI_TXP3

DMI_RXN0 DMI_RXN1 DMI_RXN2 DMI_RXN3

DMI_RXP0 DMI_RXP1 DMI_RXP2 DMI_RXP3

MCLK_DDR2

1

MCLK_DDR2#

1

N_MOCDCOMP0 N_MOCDCOMP1

N_MRCOMPN N_MRCOMPP N_MVREF

N_MXSLEWIN N_MXSLEWOUT N_MYSLEWIN N_MYSLEWOUT

N0

AA31 AB35 AC31 AD35

Y31 AA35 AB31 AC35

AA33 AB37 AC33 AD37

Y33 AA37 AB33 AC37

AM33

AL1 AE11

AJ34

AF6

AC10 AN33

AK1

AE10

AJ33

AF5

AD10 AP21

AM21 AH21 AK21

AN16 AM14 AH15 AG16

AF22 AF16

AP14

AL15 AM11 AN10

AK10 AK11 AF37

AD1 AE27 AE28

AF9 AF10

N_MRCOMPN N_MRCOMPP

N_MOCDCOMP0 N_MOCDCOMP1

U1A

DMI_RXN0 DMI_RXN1 DMI_RXN2 DMI_RXN3

DMI_RXP0 DMI_RXP1 DMI_RXP2 DMI_RXP3

DMI_TXN0 DMI_TXN1 DMI_TXN2 DMI_TXN3

DMI_TXP0 DMI_TXP1 DMI_TXP2 DMI_TXP3

SM_CK0 SM_CK1 RSVD28 SM_CK3 SM_CK4 RSVD30

SM_CK0# SM_CK1# RSVD29 SM_CK3# SM_CK4# RSVD31

SM_CKE0 SM_CKE1 SM_CKE2 SM_CKE3

SM_CS0# SM_CS1# SM_CS2# SM_CS3#

SMOCDCOMP0 SMOCDCOMP1

SM_ODT0 SM_ODT1 SM_ODT2 SM_ODT3

SMRCOMPN SMRCOMPP SMVREF0 SMVREF1 SMXSLEWIN SMXSLEWOUT SMYSLEWIN SMYSLEWOUT

QG82910GMLE

NR9 80.6Ohm

1 2

NR10 80.6Ohm

1 2

NR11 40.2Ohm

1 2

NR12 40.2Ohm

1 2

2

DMI_TXN[3:0] 15 DMI_TXP[3:0] 15

G16

CFG0

H13

CFG1

G14

CFG2

F16

CFG3

F15

CFG4

G15

CFG5

E16

CFG6

D17

CFG7

J16

CFG8

D15

CFG9

E15

CFG10

D14

CFG11

E14

CFG12

H12

CFG13

DMIDDR MUXING

PM

THRMTRIP#

DREF_CLKN

DREF_CLKP

CLK

DREF_SSCLKN DREF_SSCLKP

NC

CFG14 CFG15 CFG16 CFG17 CFG18 CFG19

CFG20 RSVD21 RSVD22 RSVD23 RSVD24 RSVD25 RSVD26 RSVD27

BM_BUSY#

EXT_TS0# EXT_TS1#

PWROK

RSTIN#

NC1 NC2 NC3 NC4 NC5 NC6 NC7 NC8

NC9 NC10 NC11

1% 1%

C14 H15 J15 H14 G22 G23 D23 G25 G24 J17 A31 A30 D26 D25

J23 J21 H22 F5 AD30 AE29

A24 A23 C37 D37

AP37 AN37 AP36 AP2 AP1 AN1 B1 A2 B37 A36 A37

+1.8V

GND

N_CFG0 N_CFG2 N_CFG1 N_CFG6

7 8

1KOhm

5 6

1KOhm

1 2

1KOhm

3 4

1KOhm

FSB fix 100MHz

N_CFG0 N_CFG1 N_CFG2 N_CFG3 N_CFG4 N_CFG5 N_CFG6 N_CFG7 N_CFG8 N_CFG9 N_CFG10 N_CFG11 N_CFG12 N_CFG13 N_CFG14 N_CFG15 N_CFG16 N_CFG17 N_CFG18 N_CFG19 N_CFG20 N_LT_TRUST N_LT_RST# N_TESTIN# N_LADATAN3 N_LADATAP3 N_LBDATAN3 N_LBDATAP3

N_EXT_TS#0

_EXT_TS#1

N

N_NC11

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

CFG5 pull down for DMI x2; floating is for x4.

1 1

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

CLK_96M_UMA CLK_96M_UMA# CLK_LCD_LVDS CLK_LCD_LVDS#

PM_PWROK PLT_RST#

T25TPC26T T26TPC26T

NR28 1KOhm

1 2

T172TPC26T T29TPC26T T30TPC26T T31TPC26T T32TPC26T T33TPC26T T34TPC26T T35TPC26T T36TPC26T T37TPC26T T38TPC26T T39TPC26T T40TPC26T T41TPC26T T42TPC26T T43TPC26T T45TPC26T T46TPC26T T47TPC26T T48TPC26T T49TPC26T

N_EXT_TS#0 N_EXT_TS#1

1

1 2 3 4

PM_BMBUSY# 14

H_THERMTRIP# 7,14 PM_PWROK 14,36 PLT_RST# 14,24,25,26

CLK_96M_UMA# 6 CLK_96M_UMA 6 CLK_LCD_LVDS# 6 CLK_LCD_LVDS 6

NC5 10PF/50V NC6 10PF/50V NC7 10PF/50V NC8 10PF/50V

T55TPC26T

NC9 0.1UF/16V

1 2

NC10 0.1UF/16V

1 2

Engineer:

900SD_MB

NRN1D NRN1C NRN1A NRN1B

/X

GND

4.7KOhm

12 12 12 12

Title :

1

/X /X /X /X

/X /X

+2.5VS

GND

+2.5VS

NRN3A NRN3B

GND

910GML_HOST_DMI

Kell_Huang

951Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

MA_DQ[63:0] 17,18,19,20 MA_DM[7:0] 17,18,19,20

AG35 AH35

AL35 AL37

AH36

AJ35

AK37

AL34 AM36 AN35 AP32 AM31 AM34 AM35

AL32 AM32 AN31 AP31 AN28 AP28

AL30 AM30 AM28

AL28 AP27 AM27 AM23 AM22

AL23 AM24 AN22 AP22

AM9

AL9 AL6

AP7 AP11 AP10

AL7 AM7 AN5 AN6 AN3 AP3 AP6 AM6

AL4 AM3 AK2 AK3 AG2 AG1

AL3 AM2 AH3 AG3

AF3 AE3 AD6 AC4

AF2

AF1 AD4 AD5

U1B

SA_DQ0 SA_DQ1 SA_DQ2 SA_DQ3 SA_DQ4 SA_DQ5 SA_DQ6 SA_DQ7 SA_DQ8 SA_DQ9 SA_DQ10 SA_DQ11 SA_DQ12 SA_DQ13 SA_DQ14 SA_DQ15 SA_DQ16 SA_DQ17 SA_DQ18 SA_DQ19 SA_DQ20 SA_DQ21 SA_DQ22 SA_DQ23 SA_DQ24 SA_DQ25 SA_DQ26 SA_DQ27 SA_DQ28 SA_DQ29 SA_DQ30 SA_DQ31 SA_DQ32 SA_DQ33 SA_DQ34 SA_DQ35 SA_DQ36 SA_DQ37 SA_DQ38 SA_DQ39 SA_DQ40 SA_DQ41 SA_DQ42 SA_DQ43 SA_DQ44 SA_DQ45 SA_DQ46 SA_DQ47 SA_DQ48 SA_DQ49 SA_DQ50 SA_DQ51 SA_DQ52 SA_DQ53 SA_DQ54 SA_DQ55 SA_DQ56 SA_DQ57 SA_DQ58 SA_DQ59 SA_DQ60 SA_DQ61 SA_DQ62 SA_DQ63

QG82910GMLE

MA_DQS[7:0] 17,18,19,20 MA_DQS#[7:0] 17,18,19,20

SA_DQS0# SA_DQS1# SA_DQS2# SA_DQS3# SA_DQS4# SA_DQS5# SA_DQS6# SA_DQS7#

DDR SYSTEM MEMORY A

SA_RCVENIN#

SA_RCVENOUT#

SA_BS0 SA_BS1 SA_BS2

SA_DM0 SA_DM1 SA_DM2 SA_DM3 SA_DM4 SA_DM5 SA_DM6 SA_DM7

SA_DQS0 SA_DQS1 SA_DQS2 SA_DQS3 SA_DQS4 SA_DQS5 SA_DQS6 SA_DQS7

SA_MA0 SA_MA1 SA_MA2 SA_MA3 SA_MA4 SA_MA5 SA_MA6 SA_MA7 SA_MA8

SA_MA9 SA_MA10 SA_MA11 SA_MA12 SA_MA13

SA_CAS# SA_RAS#

SA_WE#

D D

MA_DQ0 MA_DQ1 MA_DQ2 MA_DQ3 MA_DQ4 MA_DQ5 MA_DQ6 MA_DQ7 MA_DQ8 MA_DQ9 MA_DQ10 MA_DQ11 MA_DQ12 MA_DQ13 MA_DQ14 MA_DQ15 MA_DQ16 MA_DQ17

C C

B B

MA_DQ18 MA_DQ19 MA_DQ20 MA_DQ21 MA_DQ22 MA_DQ23 MA_DQ24 MA_DQ25 MA_DQ26 MA_DQ27 MA_DQ28 MA_DQ29 MA_DQ30 MA_DQ31 MA_DQ32 MA_DQ33 MA_DQ34 MA_DQ35 MA_DQ36 MA_DQ37 MA_DQ38 MA_DQ39 MA_DQ40 MA_DQ41 MA_DQ42 MA_DQ43 MA_DQ44 MA_DQ45 MA_DQ46 MA_DQ47 MA_DQ48 MA_DQ49 MA_DQ50 MA_DQ51 MA_DQ52 MA_DQ53 MA_DQ54 MA_DQ55 MA_DQ56 MA_DQ57 MA_DQ58 MA_DQ59 MA_DQ60 MA_DQ61 MA_DQ62 MA_DQ63

MA_MA[13:0] 17,18,19,20,21 MA_BA[2:0] 17,18,19,20,21

MA_BA0

AK15

MA_BA1

AK16

MA_BA2

AL21

MA_DM0

AJ37

MA_DM1

AP35

MA_DM2

AL29

MA_DM3

AP24

MA_DM4

AP9

MA_DM5

AP4

MA_DM6

AJ2

MA_DM7

AD3

MA_DQS0

AK36

MA_DQS1

AP33

MA_DQS2

AN29

MA_DQS3

AP23

MA_DQS4

AM8

MA_DQS5

AM4

MA_DQS6

AJ1

MA_DQS7

AE5

MA_DQS#0

AK35

MA_DQS#1

AP34

MA_DQS#2

AN30

MA_DQS#3

AN23

MA_DQS#4

AN8

MA_DQS#5

AM5

MA_DQS#6

AH1

MA_DQS#7

AE4

MA_MA0

AL17

MA_MA1

AP17

MA_MA2

AP18 AM17 AN18 AM18 AL19 AP20 AM19 AL20 AM16 AN20 AM20 AM15

AN15 AP16 AF29 AF28 AP15

_MA3

MA MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_RCVENIN# MA_RCVENOUT#

U1C

AE31

SB_DQ0

AE32

SB_DQ1

AG32

SB_DQ2

AG36

SB_DQ3

AE34

SB_DQ4

AE33

SB_DQ5

AF31

SB_DQ6

AF30

SB_DQ7

AH33

SB_DQ8

AH32

SB_DQ9

AK31

SB_DQ10

AG30

SB_DQ11

AG34

SB_DQ12

AG33

SB_DQ13

AH31

SB_DQ14

AJ31

SB_DQ15

AK30

SB_DQ16

AJ30

SB_DQ17

AH29

SB_DQ18

AH28

SB_DQ19

AK29

SB_DQ20

AH30

SB_DQ21

AH27

SB_DQ22

AG28

SB_DQ23

AF24

SB_DQ24

AG23

SB_DQ25

AJ22

SB_DQ26

AK22

SB_DQ27

AH24

SB_DQ28

AH23

SB_DQ29

AG22

SB_DQ30

AJ21

SB_DQ31

AG10

SB_DQ32

AG9

SB_DQ33

AG8

SB_DQ34

AH8

SB_DQ35

AH11

SB_DQ36

AH10

SB_DQ37

AJ9

SB_DQ38

AK9

SB_DQ39

AJ7

SB_DQ40

AK6

SB_DQ41

AJ4

SB_DQ42

AH5

SB_DQ43

AK8

SB_DQ44

AJ8

SB_DQ45

AJ5

SB_DQ46

AK4

SB_DQ47

MA_CAS# 17,18,19,20,21

1 1

T57TPC26T T58TPC26T

MA_RAS# 17,18,19,20,21

MA_WE# 17,18,19,20,21

AG5 AG4 AD8 AD9 AH4 AG6

AD7 AC5

AC8 AC7

AE8

AB8 AB6 AA8

AA4 AA5

SB_DQ48 SB_DQ49 SB_DQ50 SB_DQ51 SB_DQ52 SB_DQ53 SB_DQ54 SB_DQ55 SB_DQ56 SB_DQ57 SB_DQ58 SB_DQ59 SB_DQ60 SB_DQ61 SB_DQ62 SB_DQ63

QG82910GMLE

DDR SYSTEM MEMORY B

SB_RCVENIN#

SB_RCVENOUT#

SB_BS0 SB_BS1 SB_BS2

SB_DM0 SB_DM1 SB_DM2 SB_DM3 SB_DM4 SB_DM5 SB_DM6 SB_DM7

SB_DQS0 SB_DQS1 SB_DQS2 SB_DQS3 SB_DQS4 SB_DQS5 SB_DQS6 SB_DQS7

SB_DQS0# SB_DQS1# SB_DQS2# SB_DQS3# SB_DQS4# SB_DQS5# SB_DQS6# SB_DQS7#

SB_MA0 SB_MA1 SB_MA2 SB_MA3 SB_MA4 SB_MA5 SB_MA6 SB_MA7 SB_MA8

SB_MA9 SB_MA10 SB_MA11 SB_MA12 SB_MA13

SB_CAS# SB_RAS#

SB_WE#

AJ15 AG17 AG21

AF32 AK34 AK27 AK24 AJ10 AK5 AE7 AB7

AF34 AK32 AJ28 AK23 AM10 AH6 AF8 AB4

AF35 AK33 AK28 AJ23 AL10 AH7 AF7 AB5

AH17 AK17 AH18 AJ18 AK18 AJ19 AK19 AH19 AJ20 AH20 AJ16 AG18 AG20 AG15

AH14 AK14 AF15 AF14 AH16

A A

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

910GML_DRAM

1

Kell_Huang

10 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

SDVOCRTL_DATA Int PD

SDVO SMbus have internal pull down

D D

CLK_PCIE_MCH CLK_PCIE_MCH#

150OHM 150OHM 150OHM 150OHM

N_LCTLA_CLK N_LCTLB_DATA

G_DDC_CLK G_DDC_DATA

N_LIBG

G_DDC_CLK23

G_DDC_DATA23

12

NRN2B NRN2C NRN2D NRN2A

3 4 5 6 7 8 1 2

NC70 15PF/50V

NC71 15PF/50V

NC72 15PF/50V

C C

GND

B B

NC1 10PF/50V NC2 10PF/50V

CRT_BLUE CRT_GREEN CRT_RED

CRT_BLUE

CRT_GREEN

CRT_RED

NR29 4.7KOhm1% NR30 4.7KOhm

NR7 1.5KOHM

12 12

1%

5 6

4.7KOhm

7 8

4.7KOhm

1 2

1%

12 12

CRT_VSYNC22 CRT_HSYNC22

NRN3C NRN3D

/X /X

GND

+2.5VS

GND

T10 TPC26T T11 TPC26T

CLK_PCIE_MCH#6 CLK_PCIE_MCH6

DDC_CLK22 DDC_DATA22 CRT_BLUE22

CRT_GREEN22 CRT_RED22

NR4 39Ohm

1 2

NR5 39Ohm

1 2

NR6 255Ohm

1 2

G_CLKN23

G_CLKP23

G_DATAN023 G_DATAN123 G_DATAN223

G_DATAP023 G_DATAP123 G_DATAP223

G_NBL_CTRL23 G_NBL_EN23

G_LVDD_EN23

T14 TPC26T T15 TPC26T T16 TPC26T

T17 TPC26T T18 TPC26T

T19 TPC26T T20 TPC26T T21 TPC26T

T22 TPC26T T23 TPC26T T24 TPC26T

1%

1 1

1 1 1

1 1

1 1 1

0 : No SDVO device 1 : SDVO device present

N_SDVOCTRL_DATA N_SDVOCTRL_CLK

CRT_VSYNC_R CRT_HSYNC_R N_CRT_REFSET

N_LCTLA_CLK N_LCTLB_DATA

G_DDC_CLK G_DDC_DATA

N_LIBG N_LVBG N_LVREFH N_LVREFL

N_LBCLKN N_LBCLKP

N_LBDATAN0 N_LBDATAN1 N_LBDATAN2

N_LBDATAP0 N_LBDATAP1 N_LBDATAP2

GND

GNDGND

H24

H25 AB29 AC29

A15

C16

A17

B15

B16

B17

E24

E23

E21

D21

C20

B20

A19

B19

H21

G21

E25

F25

C23

C22

F23

F22

F26

C33

C31

F28

F27

B30

B29

C25

C24

B34

B33

B32

A34

A33

B31

C29

D28

C27

C28

D27

C26

J18

J20

U1F

SDVOCTRL_DATA SDVOCTRL_CLK GCLKN GCLKP

TVDAC_A TVDAC_B TVDAC_C TV_REFSET TV_IRTNA TV_IRTNB TV_IRTNC

DDCCLK DDCDATA BLUE BLUE# GREEN GREEN# RED RED# VSYNC HSYNC REFSET

LBKLT_CRTL LBKLT_EN LCTLA_CLK LCTLB_DATA LDDC_CLK LDDC_DATA LVDD_EN LIBG LVBG LVREFH LVREFL

LACLKN LACLKP LBCLKN LBCLKP

LADATAN0 LADATAN1 LADATAN2

LADATAP0 LADATAP1 LADATAP2

LBDATAN0 LBDATAN1 LBDATAN2

LBDATAP0 LBDATAP1 LBDATAP2

QG82910GMLE

U1 use 02G010007610

N_EXP_COMP

EXP_RXN0 EXP_RXN1 EXP_RXN2 EXP_RXN3 EXP_RXN4 EXP_RXN5 EXP_RXN6 EXP_RXN7 EXP_RXN8 EXP_RXN9

EXP_RXP0 EXP_RXP1 EXP_RXP2 EXP_RXP3 EXP_RXP4 EXP_RXP5 EXP_RXP6 EXP_RXP7 EXP_RXP8 EXP_RXP9

EXP_TXN0 EXP_TXN1 EXP_TXN2 EXP_TXN3 EXP_TXN4 EXP_TXN5 EXP_TXN6 EXP_TXN7 EXP_TXN8 EXP_TXN9

EXP_TXP0 EXP_TXP1 EXP_TXP2 EXP_TXP3 EXP_TXP4 EXP_TXP5 EXP_TXP6 EXP_TXP7 EXP_TXP8 EXP_TXP9

D36 D34

E30 F34 G30 H34 J30 K34 L30 M34 N30 P34 R30 T34 U30 V34 W30 Y34

D30 E34 F30 G34 H30 J34 K30 L34 M30 N34 P30 R34 T30 U34 V30 W34

E32 F36 G32 H36 J32 K36 L32 M36 N32 P36 R32 T36 U32 V36 W32 Y36

D32 E36 F32 G36 H32 J36 K32 L36 M32 N36 P32 R36 T32 U36 V32 W36

PCI-E signals can be left NC, If unused.

EXP_COMPI

EXP_ICOMPO

MISCTVVGALVDS

EXP_RXN10 EXP_RXN11 EXP_RXN12 EXP_RXN13 EXP_RXN14 EXP_RXN15

EXP_RXP10 EXP_RXP11 EXP_RXP12 EXP_RXP13 EXP_RXP14 EXP_RXP15

PCI-EXPRESS GRAPHICS

EXP_TXN10 EXP_TXN11 EXP_TXN12 EXP_TXN13 EXP_TXN14 EXP_TXN15

EXP_TXP10 EXP_TXP11 EXP_TXP12 EXP_TXP13 EXP_TXP14 EXP_TXP15

NR27 24.9Ohm

1 2

1%

+1.5VS

12

CC47

22PF/25V

/x

GND

For RF Advise

900SD R1.0G

A A

Default Group-A7V8X MX

910GML_VGA_LVDS

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

1

Hauld_Zhou

11 51Monday, November 10, 2008

of

Rev

R1.0G

5

+VCCP

2

3

1 2

1

ND1 BAT54CW

+1.5VS

D D

2 1

ND2 BAT54CW

NR25

10Ohm

r0603_h24

NR26

10Ohm

r0603_h24

+2.5VS

+3VS

U1 use 02G010007610

+VCCP

12

NC28 10uF/10V

GND

C C

B B

+3VS_TV

+1.5VS_TV

T29

R29

N29

M29

K29

J29

V28

VCC1

VCC2

VCC3

VCC4

VCC5

VCC6

VCC7

VCCA_TVDACA1

VCCA_TVDACA2

VCCA_TVDACB1

VCCA_TVDACB2

VCCA_TVDACC1

VCCA_TVDACC2

F17

E17

D18

C18

F18

E18

+1.5VS

60 mA 60 mA

12

NC53 10uF/10V

/CAP/X

GND GND

12

NC29 10uF/10V

/CAP/X

U28

T28

R28

P28

VCC8

VCC9

VCC10

VCC11

VCCA_TVBG

VSSA_TVBG

VCCD_TVDAC

H18

G18

D19

GND

12

NC54

0.1UF/16V

+2.5VS

GND

1.05V 3700 mA

12

NC30 10uF/10V

/CAP/X

N28

M28

L28

K28

J28

VCC12

VCC13

VCC14

VCC15

VCC16

VCCDQ_TVDAC

VCCD_LVDS1

VCCD_LVDS2

VCCD_LVDS3

H17

B26

B25

A25

10 mA

12

NC59 1UF/16V

/CAP/X

H28

G28

V27

VCC17

VCC18

VCCA_LVDS

A35

12

NC60

0.1UF/16V

U27

VCC19

VCC20

VCCHV1

B22

12

NC31

0.1UF/16V

T27

R27

VCC21

VCC22

VCCHV2

VCCHV3

B21

A21

12

P27

N27

M27

VCC23

VCC24

VCC25

VCCSM1

VCCSM2

AM37

AH37

2 mA

NC55

0.1UF/16V

12

NC32

0.1UF/16V

L27

K27

J27

VCC26

VCC27

VCC28

VCCSM3

VCCSM4

VCCSM5

AP29

AD28

AD27

+1.8V_CAP3 +1.8V_CAP2 +1.8V_CAP1

+2.5VS

12

4

http://hobi-elektronika.net

12

NC15 10uF/10V

/CAP/X

12

NC21 10uF/10V

/CAP/X

150 mA

NC34 10uF/10V

/CAP/X

K20

V19

U19

VCC41

VCC42

VCCSM18

VCCSM19

AN25

AM25

AL25

12

K19

VCC43

VCC44

VCCSM20

VCCSM21

AK25

NC44

0.1UF/16V

W18

VCC45

VCCSM22

AJ25

40 mA

12

40 mA

12

NC35

0.1UF/16V

V18

T18

VCC46

VCC47

VCCSM23

VCCSM24

AH25

AG25

+1.8V

GND

NC16

0.1UF/16V

NC22

0.1UF/16V

K18

K17

VCC48

VCC49

VCCSM25

VCCSM26

VCCSM27

AF25

AE25

AE24

12

NC45 10uF/10V

AC2

AC1

VCCD_HMPLL1

VCCD_HMPLL2

8

VCCSM29

VCCSM2

AE23

AE22

B23

C35

AA1

AA2

VCCA_HPLL

VCCA_MPLL

VCCA_DPLLA

VCCA_DPLLB

VCCSM30

VCCSM31

VCCSM32

VCCSM33

AE21

AE20

AE19

AE18

950 mA

12

NC46 10uF/10V

/CAP/X

VCCSM34

AE17

F19

AE16

NL1

21

120Ohm/100Mhz

NL4

NC33

0.1UF/16V

K24

K23

K22

VCC34

VCC35

VCC36

21

K21

VCC37

W20

VCC38

GND

+1.5VS

12

GND

U20

T20

VCC39

VCC40

+1.5VS +1.5VS_DPLLA

120Ohm/100Mhz

12

H27

K26

H26

K25

J25

VCC29

VCC30

VCC31

VCC32

VCC33

POWER

VCCSM6

VCCSM7

VCCSM8

VCCSM9

VCCSM10

VCCSM11

VCCSM12

VCCSM13

VCCSM14

VCCSM15

VCCSM16

VCCSM17

AC27

AP26

AN26

AM26

AL26

AK26

AJ26

AH26

AG26

AF26

AE26

AP25

12

NC43

NC42

0.1UF/16V

NC56 1UF/16V

/CAP/X

0.1UF/16V

GND GND

45 mA

12

NC17

0.1UF/16V

GND

45 mA

12

NC19

0.1UF/16V

GND

+2.5VS

2 mA

GND

E19

G19

H20

VCC_SYNC

VSSA_CRTDAC

VCCA_CRTDAC1

VCCA_CRTDAC2

VCCSM35

VCCSM36

VCCSM37

VCCSM38

VCCSM39

VCCSM40

AE15

AE14

AP13

AN13

AM13

AL13

12

NC47

0.1UF/16V

3

12

NC18

120Ohm/100Mhz 10uF/10V

/CAP/X

+1.5VS_DRAM_PLL +1.5VS

12

NC20

120Ohm/100Mhz 10uF/10V

/CAP/X

68 mA

12

NC23

0.1UF/16V

12

NC36

0.1UF/16V

GND

K13

J13

K12

W11

V11

U11

T11

R11

P11

N11

VTT1

VTT2

VTT3

VTT4

VTT5

VTT6

VTT7

VTT8

VTT9

VCCSM41

VCCSM42

VCCSM43

VCCSM44

VCCSM45

VCCSM46

VCCSM47

VCCSM48

VCCSM49

VCCSM50

AK13

AJ13

AH13

AG13

AF13

AE13

AP12

AN12

AM12

AL12

12

NC48

NC49

0.1UF/16V

NL2

NL3

M11

L11

VTT10

VTT11

VTT12

VCCSM51

VCCSM52

VCCSM53

AK12

AJ12

0.1UF/16V

+1.5VS+1.5VS_HOST_PLL+1.5VS_DPLLB+1.5VS

21

12

NC24 22UF/6.3V

/CAP/X

K11

W10

V10

U10

T10

VTT13

VTT14

VTT15

VTT16

VTT17

VCCSM54

VCCSM55

VCCSM56

VCCSM57

VCCSM58

AH12

AG12

AF12

AE12

AD11

+1.8V_CAP4 +1.8V_CAP5 +1.8V_CAP6

12

NC50

+2.5VS

12

0.1UF/16V

GND

NL8

120Ohm/100Mhz

2

+2.5VS+2.5VS_CRTDAC

NR31

1 2

0Ohm

R10

P10

N10

VTT18

VTT19

VTT20

VCCSM59

VCCSM60

VCCSM61

AC11

AB11

AB10

NC57 22UF/6.3V

/CAP/X

21

+VCCP

1.05V 640 mA

12

NC25 10uF/10V

GND

M10

K10

J10Y9W9U9R9P9N9M9L9J9N8M8N7M7N6M6N5M5N4M4N3M3N2M2B2V1N1M1G1

VTT21

VTT22

VTT23

VTT24

VTT25

VTT26

VTT27

VTT28

VTT29

VTT30

VTT31

VTT32

VTT33

VCCSM62

VCCSM63

VCCSM64

VCCSM65

VCCTX_LVDS1

VCCTX_LVDS2

VCCTX_LVDS3

VCCA_SM1

VCCA_SM2

VCCA_SM3

AB9

AP8

AM1

AE1

B28

A28

A27

AF20

AP19

AF19

12

NC58

0.1UF/16V

+1.5VS_DRAM+1.5VS

GND

12

NC64 10uF/10V

215 mA

12

NC65 1UF/16V

12

NC26 10uF/10V

/CAP/X

VTT34

VTT35

VCCA_SM4

AF18

12

NC66

0.1UF/16V

VTT36

VCC3G1

AE37

VTT37

VCC3G2

W37

VTT38

VCC3G3

U37

A6

VTT39

VCC3G4

R37

12

NC27

0.1UF/16V

VTT40

VCC3G5

N37

L37

VTT41

VTT42

VCC3G6

VCC3G7

J37

12

NC61

0.1UF/16V

VTT43

VTT44

VTT45

VTT46

VTT47

VTT48

VTT49

VTT50

VCCA_3GPLL1

VCCA_3GPLL2

VCCA_3GPLL3

VCCA_3GBG

VSSA_3GBG

Y29

Y28

Y27

F37

G37

GND

+1.5VS_NPCIE_PLL +1.5VS

12

NC51

NC52

0.1UF/16V

10uF/10V

/CAP/X

GND

12

NC62 10uF/10V

/CAP/X

1

+VCCP_GMCH_CAP1 +VCCP_GMCH_CAP2 +VCCP_GMCH_CAP3 +VCCP_GMCH_CAP4

VTT51

VTT52

U1G

QG82910GMLE

+2.5VS

0.15 mA

12

NC41

0.1UF/16V

GND

NL6

21

120Ohm/100Mhz

12

NC37

0.1UF/16V

12

NC38

0.1UF/16V

12

NC39

0.1UF/16V

12

GND

+1.5V_PCIE & +1.5V_PCIE_PLL total 1500 mA

+1.5VS

12

SC21 10uF/10V

/CAP/X

GND

NC40

0.1UF/16V

A A

+3VS_TV

+1.5VS_TV

5

JP3

JP4

1 2

SHORTPIN

GND

Default Group-A7V8X MX

1

910GML_PWR

Kell_Huang

12 51Monday, November 10, 2008

of

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

4

3

2

1

http://hobi-elektronika.net

+VCCP

D D

C C

+VCCP

GND

AB25

Y26

AA26

AB26

VSS_NCTF66

VSS_NCTF67

VSS_NCTF68

VSS_NCTF69

VCC_NCTF76

VCC_NCTF77

VCC_NCTF78

VCC_NCTF79

T26

U26

V26

W26

AA24

AB24

Y25

AA25

VSS_NCTF62

VSS_NCTF63

VSS_NCTF64

VSS_NCTF65

VCC_NCTF72

VCC_NCTF73

VCC_NCTF74

VCC_NCTF75

M26

N26

P26

R26

Y23

AA23

AB23

Y24

VSS_NCTF58

VSS_NCTF59

VSS_NCTF60

VSS_NCTF61

VCC_NCTF68

VCC_NCTF69

VCC_NCTF70

VCC_NCTF71

U25

V25

W25

L26

AB21

Y22

AA22

AB22

VSS_NCTF54

VSS_NCTF55

VSS_NCTF56

VSS_NCTF57

VCC_NCTF64

VCC_NCTF65

VCC_NCTF66

VCC_NCTF67

N25

P25

R25

T25

AB20

R21

Y21

AA21

VSS_NCTF50

VSS_NCTF51

VSS_NCTF52

VSS_NCTF53

VCC_NCTF60

VCC_NCTF61

VCC_NCTF62

VCC_NCTF63

V24

W24

L25

M25

AB18

AA19

AB19

AA20

VSS_NCTF46

VSS_NCTF47

VSS_NCTF48

VSS_NCTF49

VCC_NCTF56

VCC_NCTF57

VCC_NCTF58

VCC_NCTF59

P24

R24

T24

U24

Y17

AA17

AB17

AA18

VSS_NCTF42

VSS_NCTF43

VSS_NCTF44

VSS_NCTF45

VCC_NCTF52

VCC_NCTF53

VCC_NCTF54

VCC_NCTF55

W23

L24

M24

N24

Y16

AA16

AB16

R17

VSS_NCTF38

VSS_NCTF39

VSS_NCTF40

VSS_NCTF41

VCC_NCTF48

VCC_NCTF49

VCC_NCTF50

VCC_NCTF51

R23

T23

U23

V23

T16

U16

V16

W16

VSS_NCTF34

VSS_NCTF35

VSS_NCTF36

VSS_NCTF37

VCC_NCTF44

VCC_NCTF45

VCC_NCTF46

VCC_NCTF47

L23

M23

N23

P23

M16

N16

P16

R16

VSS_NCTF30

VSS_NCTF31

VSS_NCTF32

VSS_NCTF33

VCC_NCTF40

VCC_NCTF41

VCC_NCTF42

VCC_NCTF43

T22

U22

V22

W22

Y15

AA15

AB15

L16

VSS_NCTF26

VSS_NCTF27

VSS_NCTF28

VSS_NCTF29

VCC_NCTF36

VCC_NCTF37

VCC_NCTF38

VCC_NCTF39

M22

N22

P22

R22

T15

U15

V15

W15

VSS_NCTF22

VSS_NCTF23

VSS_NCTF24

VSS_NCTF25

VCC_NCTF32

VCC_NCTF33

VCC_NCTF34

VCC_NCTF35

U21

V21

W21

L22

M15

N15

P15

R15

VSS_NCTF18

VSS_NCTF19

VSS_NCTF20

VSS_NCTF21

VCC_NCTF28

VCC_NCTF29

VCC_NCTF30

VCC_NCTF31

M21

N21

P21

T21

Y14

AA14

AB14

L15

VSS_NCTF14

VSS_NCTF15

VSS_NCTF16

VSS_NCTF17

NCTF

VCC_NCTF24

VCC_NCTF25

VCC_NCTF26

VCC_NCTF27

P20

R20

Y20

L21

T14

U14

V14

W14

VSS_NCTF10

VSS_NCTF11

VSS_NCTF12

VSS_NCTF13

VCC_NCTF20

VCC_NCTF21

VCC_NCTF22

VCC_NCTF23

Y19

L20

M20

N20

M14

N14

P14

R14

VSS_NCTF6

VSS_NCTF7

VSS_NCTF8

VSS_NCTF9

VCC_NCTF16

VCC_NCTF17

VCC_NCTF18

VCC_NCTF19

M19

N19

P19

R19

AA12

Y13

AA13

L14

VSS_NCTF2

VSS_NCTF3

VSS_NCTF4

VSS_NCTF5

VCC_NCTF12

VCC_NCTF13

VCC_NCTF14

VCC_NCTF15

P18

R18

Y18

L19

Y12

VSS_NCTF1

VCC_NCTF8

VCC_NCTF9

VCC_NCTF10

VCC_NCTF11

W17

L18

M18

N18

V13

W13

VTT_NCTF18

VCC_NCTF5

VCC_NCTF6

VCC_NCTF7

P17

T17

U17

V17

P13

R13

T13

U13

VTT_NCTF13

VTT_NCTF14

VTT_NCTF15

VTT_NCTF16

VTT_NCTF17

VCC_NCTF1

VCC_NCTF2

VCC_NCTF3

VCC_NCTF4

L17

M17

N17

U12

V12

W12

L13

M13

N13

VTT_NCTF8

VTT_NCTF9

VTT_NCTF10

VTT_NCTF11

VTT_NCTF12

VCCSM_NCTF28

VCCSM_NCTF29

VCCSM_NCTF30

VCCSM_NCTF31

VCCSM_NCTF32

AC24

AD24

AC25

AD25

AC26

AD26

L12

M12

N12

P12

R12

T12

VTT_NCTF2

VTT_NCTF3

VTT_NCTF4

VTT_NCTF5

VTT_NCTF6

VTT_NCTF7

VCCSM_NCTF22

VCCSM_NCTF23

VCCSM_NCTF24

VCCSM_NCTF25

VCCSM_NCTF26

VCCSM_NCTF27

AC21

AD21

AC22

AD22

AC23

AD23

VTT_NCTF1

VCCSM_NCTF16

VCCSM_NCTF17

VCCSM_NCTF18

VCCSM_NCTF19

VCCSM_NCTF20

VCCSM_NCTF21

AC18

AD18

AC19

AD19

AC20

AD20

VCCSM_NCTF10

VCCSM_NCTF11

VCCSM_NCTF12

VCCSM_NCTF13

VCCSM_NCTF14

VCCSM_NCTF15

AC15

AD15

AC16

AD16

AC17

AD17

VCCSM_NCTF4

VCCSM_NCTF5

VCCSM_NCTF6

VCCSM_NCTF7

VCCSM_NCTF8

VCCSM_NCTF9

AB13

AC13

AD13

AC14

AD14

QG82910GMLE

VCCSM_NCTF1

VCCSM_NCTF2

VCCSM_NCTF3

AB12

AC12

AD12

+1.8V

U1E

U1 use 02G010007612

GND

B36Y1D2G2J2L2P2T2V2

VSS1

VSS2

B B

VSSA_LVDS

VSS3

VSS4

VSS5

VSS6

VSS7

AD2

VSS8

AE2

VSS9

AH2

VSS10

VSS11

AL2

VSS12

AN2A3C3

VSS13

VSS14

AA3

VSS15

VSS16

AB3

AC3

AJ3C4H4L4P4U4Y4

VSS17

VSS18

VSS19

VSS20

VSS21

VSS22

VSS23

VSS24

VSS25

AF4

VSS26

AN4E5W5

VSS27

VSS28

AL5

VSS29

AP5B6J6L6P6T6AA6

VSS30

VSS31

VSS32

VSS33

VSS34

VSS35

VSS36

VSS37

AC6

VSS38

AE6

VSS39

AJ6G7V7

AA7

AG7

AK7

AN7C8E8L8P8Y8AL8A9H9K9T9V9AA9

VSS40

VSS41

VSS42

VSS43

VSS44

VSS45

VSS46

VSS47

VSS48

VSS49

VSS50

VSS51

VSS52

VSS53

VSS54

VSS55

VSS56

VSS57

AC9

VSS58

VSS59

AE9

VSS60

AH9

VSS61

AN9

VSS62

D10

L10

VSS63

VSS

Y10

VSS64

VSS65

AA10

VSS66

F11

VSS67

H11

VSS68

Y11

VSS69

AA11

VSS70

AF11

VSS71

AG11

VSS72

AJ11

VSS73

AL11

VSS74

AN11

VSS75

B12

VSS76

D12

VSS77

J12

VSS78

A14

VSS79

B14

VSS80

F14

VSS81

J14

VSS82

K14

VSS83

AG14

VSS84

AJ14

VSS85

AL14

VSS86

AN14

VSS87

C15

VSS88

K15

VSS89

A16

VSS90

D16

VSS91

H16

VSS92

K16

VSS93

AL16

VSS94

C17

VSS95

G17

VSS96

AF17

VSS97

AJ17

VSS98

AN17

VSS99

A18

B18

VSS100

AL18

U18

VSS101

VSS102

C19

H19

VSS103

VSS104

J19

T19

VSS105

VSS106

W19

AG19

VSS107

VSS108

AN19

A20

VSS109

VSS110

D20

E20

VSS111

VSS112

F20

G20

VSS113

VSS114

V20

AK20

VSS115

VSS116

C21

F21

VSS117

VSS118

AF21

AN21

VSS119

VSS120

A22

D22

VSS121

VSS122

E22

J22

VSS123

VSS124

AH22

AL22

VSS125

VSS126

H23

AF23

VSS127

VSS128

B24

D24

VSS129

VSS130

F24

J24

VSS131

VSS132

AG24

AJ24

VSS133

VSS134

VSS135

U1H QG82910GMLE

VSS204

VSS205

VSS206

VSS207

VSS208

VSS209

VSS210

VSS211

VSS212

VSS213

VSS214

VSS215

VSS216

VSS217

VSS218

VSS219

VSS220

VSS221

VSS222

VSS223

VSS224

VSS225

VSS226

VSS227

VSS228

VSS229

VSS230

VSS231

VSS232

VSS233

VSS234

VSS235

VSS236

VSS237

VSS238

VSS239

VSS240

VSS241

VSS242

VSS243

VSS244

VSS245

VSS246

VSS247

VSS248

VSS249

VSS250

VSS251

VSS252

VSS253

VSS254

VSS255

VSS256

VSS257

VSS258

VSS259

VSS260

VSS261

VSS262

VSS263

VSS264

VSS265

VSS266

VSS267

VSS268

VSS269

VSS270

VSS271

M37

P37

T37

V37

Title :

1

VSS272

Y37

AG37

GND

910GML_GND

Kell_Huang

13 51Monday, November 10, 2008

Rev

R1.0G

of

VSS136

VSS137

VSS138

VSS139

VSS140

VSS141

VSS142

VSS143

VSS144

VSS145

VSS146

VSS147

VSS148

VSS149

VSS150

VSS151

VSS152

VSS153

VSS154

VSS155

VSS156

VSS157

VSS158

VSS159

VSS160

VSS161

VSS162

VSS163

VSS164

VSS165

VSS166

VSS167

VSS168

VSS169

VSS170

VSS171

VSS172

VSS173

VSS174

VSS175

VSS176

VSS177

VSS178

VSS179

VSS180

VSS181

VSS182

VSS183

VSS184

VSS185

VSS186

VSS187

VSS188

VSS189

VSS190

VSS191

VSS192

VSS193

VSS194

VSS195

VSS196

VSS197

VSS198

VSS199

VSS200

VSS201

VSS202

VSS203

AL24

AN24

A26

E26

G26

J26

B27

E27

G27

W27

AA27

AB27

AF27

AG27

AJ27

AL27

AN27

E28

W28

AA28

AB28

AC28

A29

D29

E29

F29

G29

H29

L29

P29

U29

V29

W29

AA29

AD29

AG29

AJ29

AM29

C30

Y30

AA30

AB30

AC30

AE30

AP30

D31

E31

F31

G31

H31

J31

K31

L31

M31

N31

P31

R31

T31

U31

V31

W31

AD31

AG31

AL31

A32

C32

Y32

AA32

AB32

AC32

AD32

AJ32

AN32

D33

E33

F33

G33

H33

J33

K33

L33

M33

N33

P33

R33

T33

U33

V33

W33

AD33

AF33

AL33

C34

AA34

AB34

AC34

AD34

AH34

AN34

B35

D35

E35

F35

G35

H35

J35

K35

L35

M35

N35

P35

R35

T35

U35

V35

W35

Y35

AE35

C36

AA36

AB36

AC36

AD36

AE36

AF36

AJ36

AL36

AN36

E37

H37

K37

A A

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

4

3

2

1

http://hobi-elektronika.net

STP_PCI#

SR20 10KOhm /X

STP_CPU#

LPC_AD[3:0] 36,37

C10

A10 F11 F10 B10

E10

D12

F13

D11

B12

F12 B11 E12

E11 C13 C12 C11

E13

AF22 AF23 AE27 AE20 AE24 AD27 AG26 AE22 AF27 AG24 AF24 AF25 AD23 AB20 AG27 AE26 AE23

P4

P2 N3 N5 N4

N6 P3

C9 B9

U2D

LDRQ[1]#/GPI[41]

LAD[0]/FWH[0] LAD[1]/FWH[1] LAD[2]/FWH[2] LAD[3]/FWH[3]

LDRQ[0]# LFRAME#/FWH[4]

ACZ_BIT_CLK ACZ_RST# ACZ_SDIN[0] ACZ_SDIN[1] ACZ_SDIN[2] ACZ_SDOUT ACZ_SYNC CLK14

EE_CS EE_DIN EE_DOUT EE_SHCLK

LAN_CLK LAN_RSTSYNC LAN_RXD[0] LAN_RXD[1] LAN_RXD[2] LAN_TXD[0] LAN_TXD[1] LAN_TXD[2]

A20GATE A20M# CPUSLP# DPRSLPVR/TP[1] DPRSTP#/TP[4] DPSLP#/TP[2] IGNNE# INIT3_3V# INIT# INTR FERR# NMI RCIN# SERIRQ SMI# STPCLK# THRMTRIP#

D D

C C

B B

T65 TPC26T

T67 TPC26T

LPC_FRAME#36,37

ACZ_SDIN0 CODEC ACZ_SDIN1

CLK_REF_ICH6

A20GATE36 H_A20M#7 S_CPUSLP#7

H_DPRSTP#7 H_DPSLP#7 H_IGNNE#7

H_INIT#7 H_INTR7

H_NMI7

RC_IN#36 INT_SERIRQ36 H_SMI#7 H_STPCLK#7

NC

A_Z_SDIN033

T199 TPC26T T71 TPC26T

T75 TPC26T T76 TPC26T

T81 TPC26T

S_LDRQ#1

1

LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3

S_LDRQ#0

1

S_ACZ_BITCLK S_ACZ_RST#

S_ACZ_SDIN1

1

S_ACZ_SDIN2

1

S_ACZ_SDOUT S_ACZ_SYNC

S_EE_CS

1

S_EE_DOUT

1

S_INIT3_3V#

H_FERR#_R

H_THERMTRIP#_R

S_INIT3_3V#

1

BMBUSY#/GPI[6]

GPI[7]

SMBALERT#/GPI[11]

CPUPWRGD/GPO[49]

SUS_STAT#/LPCPD#

GPI[8]

GPI[12] GPI[13]

STP_PCI#/GPO[18]

GPO[19]

STP_CPU#/GPO[20]

GPO[21]

GPO[23] GPIO[24] GPIO[25] GPIO[27] GPIO[28]

CLKRUN#/GPIO[32]

GPIO[33] GPIO[34]

MCH_SYNC#

PWRBTN#

SLP_S3# SLP_S4# SLP_S5#

SUSCLK

SYS_RESET#

LAN_RST#

BATLOW#/TP[0]

TP[3]

VRMPWRGD

THRM#

1 2

SR21 10KOhm /X

1 2

AD19

S_GPI7

AE19 R1

S_SMBALERT#

W6

S_GPI12

M2 R6 AC21 AB21 AD22 AD20 AD21 V3 P5 R3 T3

S_CLKRUN#

AF19 AF20 AC18 AG25

S_MCHSYNC#

AG21 U1

S_RI#

T2

RI#

T4 T5

S_SLP_S5#

T6

S_SUSSTAT#

W3

S_SUSCLK

V6 U2

PLT_RST#

V5 V2

S_TP3

U3

AF21

THRM_ALERT#

AC20

VRM_PWRGD

+3VS

PM_BMBUSY# 9 KBC_SCI# 36

EXTSMI# 36 STP_PCI# 6 WLAN_LED 40 STP_CPU# 6 CAMERA_EN 32

+VCCP_UP 50

MINICARD_EN 25 3GLAN_OFF 24 CARD_READER_EN# 31

+3VSUS_DOWN# 47 +VCCP_DOWN# 50

+1.5VS_DOWN# 51

H_PWRGD 7

PM_PWRBTN# 36

PM_SUSB# 23,36 PM_SUSC# 36

1

1 1

1

T77TPC26T

T78TPC26T T79TPC26T

SYS_RESET# 6,7

PM_BATLOW# 36

T80TPC26T

VRM_PWRGD 36,46

SC55 0.1UF/16V

1 2

/X

GND

T64 TPC26T

CLK_PCI_ICH6

PCI_RST#36 PLT_RST#9,24,25,26

T70 TPC26T

PCI_PAR

1

PCI_DEVSEL#

PCI_IRDY# PCI_PME# PCI_SERR# PCI_STOP# PCI_PLOCK# PCI_TRDY# PCI_PERR# PCI_FRAME#

S_GNT#4

1

S_GNT#5 S_GNT#6

PCI_REQ#0 PCI_REQ#1 PCI_REQ#2 PCI_REQ#3 PCI_REQ#4 PCI_REQ#5 PCI_REQ#6

PCI_INTA# PCI_INTB# PCI_INTC# PCI_INTD# PCI_INTE# PCI_INTF# PCI_INTG# PCI_INTH#

U2A

E1

PAR

C3

DEVSEL#

G6

PCICLK

R2

PCIRST#

R5

PLTRST#

A3

IRDY#

P6

PME#

G5

SERR#

J1

STOP#

C5

PLOCK#

J2

TRDY#

E3

PERR#

J3

FRAME#

C1

GNT[0]#

B6

GNT[1]#

F1

GNT[2]#

C8

GNT[3]#

E7

GNT[4]#/GPO[48]

F6

GNT[5]#/GPO[17]

D8

GNT[6]#/GPO[16]

L5

REQ[0]#

B5

REQ[1]#

M5

REQ[2]#

B8

REQ[3]#

F7

REQ[4]#/GPI[40]

E8

REQ[5]#/GPI[1]

B7

REQ[6]#/GPI[0]

N2

PIRQ[A]#

L2

PIRQ[B]#

M1

PIRQ[C]#

L3

PIRQ[D]#

D9

PIRQ[E]#/GPI[2]

C7

PIRQ[F]#/GPI[3]

C6

PIRQ[G]#/GPI[4]

M3

PIRQ[H]#/GPI[5]

NH82801FBM

S_ACZ_SDOUT S_ACZ_SYNC S_ACZ_RST# S_ACZ_BITCLK

AD[0] AD[1] AD[2] AD[3] AD[4] AD[5] AD[6] AD[7] AD[8]

AD[9] AD[10] AD[11] AD[12] AD[13] AD[14] AD[15] AD[16] AD[17] AD[18] AD[19] AD[20] AD[21] AD[22] AD[23] AD[24] AD[25] AD[26] AD[27] AD[28] AD[29] AD[30] AD[31]

C/BE[3]# C/BE[2]# C/BE[1]# C/BE[0]#

1 2

33OHM

3 4

33OHM

5 6

33OHM

7 8

33OHM

E2 E5 C2 F5 F3 E9 F2 D6 E6 D3 A2 D2 D5 H3 B4 J5 K2 K5 D4 L6 G3 H4 H2 H5 B3 M6 B2 K6 K3 A5 L1 K4

G2 G4 H6 J6

SRN10A SRN10B SRN10C SRN10D

12

SC56 22PF/25V

PCI_DEVSEL# PCI_IRDY# PCI_SERR# PCI_STOP# PCI_PLOCK# PCI_TRDY# PCI_PERR# PCI_FRAME#

PCI_INTA# PCI_INTB# PCI_INTC# PCI_INTD# PCI_INTE# PCI_INTF# PCI_INTG# PCI_INTH#

PCI_REQ#0 PCI_REQ#1 PCI_REQ#2 PCI_REQ#3 PCI_REQ#4 PCI_REQ#5 PCI_REQ#6 PCI_PME#

CARD_READER_EN#

3GLAN_OFF

SR35 10KOhm /X SR27 4.7KOhm /X

S_GNT#5

SR25 4.7KOhm /X

S_GNT#6

SR26 4.7KOhm /X

S_RI# SYS_RESET# PM_BATLOW# PCIE_WAKE#

S_MCHSYNC# THRM_ALERT# INT_SERIRQ S_CLKRUN#

KBC_SCI# EXTSMI# S_SMBALERT# PM_PWRBTN#

MINICARD_EN

A_Z_SDOUT 33 A_Z_SYNC 33 A_Z_RST# 33 A_Z_BITCLK 33

+3VS

10KOhm 10KOhm 10KOhm 10KOhm 10KOhm 10KOhm 10KOhm 10KOhm

1 2

10KOhm

5 6

10KOhm

7 8

10KOhm

3 4

10KOhm

7 8

10KOhm

5 6

10KOhm

3 4

10KOhm

1 2

10KOhm

1 2

10KOhm

5 6

10KOhm

3 4

10KOhm

7 8

10KOhm

1 2

/X

SRN2B SRN2A SRN6B SRN3B SRN7B SRN3C SRN2C SRN3D

SRN4A SRN3A SRN4C SRN4D SRN7C SRN5C SRN5B SRN4B

SRN6C SRN5A SRN6D SRN7A SRN6A SRN2D SRN5D SRN7D

SRN12A SRN12C SRN12D SRN12B

SRN13D SRN13C SRN13B SRN13A

SRN14A SRN14C SRN14B SRN14D

+3VSUS

+3VS

+3VSUS

GND

3 4 1 2 3 4 3 4 3 4 5 6 5 6 7 8

1 2 1 2 5 6 7 8 5 6 5 6 3 4 3 4

5 6 1 2 7 8 1 2 1 2 7 8 7 8 7 8

SR32 10KOhm /X

1 2 1 2 1 2 1 2

SR40 4.7KOhm

+3VSUS

GND

U5

+VCCP

A A

3 4

1 2

H_FERR#7

H_THERMTRIP#7,9

5

SRN15B 56Ohm SRN15A 56Ohm

NH82801FBM

7 8

56Ohm

5 6

56Ohm

SRN15D SRN15C

WAKE#

PWROK

H_FERR#_R H_THERMTRIP#_R

AA1

PM_PWROK

4

PCIE_WAKE# 24,25,26 PM_PWROK 9,36

SC58 0.1UF/16V

1 2

/X

GND

+3VS

3

SR41

1 2

10KOhm

/X

SR42

1 2

10KOhm

/X

S_GPI12

S_GPI7

3

SQ3

2N7002

/X

SD5

BAT54AW

/X

D

S

GND

1 2

32

3

1

G

2

LID_EC# 23,36

THRO_CPU 36

2

GND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Title :

Engineer:

1

ICH6-M_Azalia_GPIO

Hauld_Zhou

14 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

U2C

AD13

DD[15]

AG15

DD[14]

AE15

DD[13]

AC13

DD[12]

AB13

DD[11]

AB12

DD[10]

AF13

DD[9]

IDE_IORDY

+3VS

12

PCBA

SR46 10KOhm

/X

1 2

GND

SR45

10KOhm

1%

AE13 AB11 AD11 AC11 AE14 AD12 AF14 AF15 AD14

AB15 AB14 AE16 AC14 AF16

AC16 AB17 AC17

AD16 AE17

AB16

DD[8] DD[7] DD[6] DD[5] DD[4] DD[3] DD[2] DD[1] DD[0]

DDACK# DDREQ DIOR# DIOW# IORDY

DA[0] DA[1] DA[2]

DCS1# DCS3#

IDEIRQ

NH82801FBM

PM_RSMRST#

D D

+3VS

C C

+3VS

SR1

10KOhm

1%

SRN9D

10KOhm

12

IDE_IRQ

78

900SD 1.0G

SR48 10KOhm

/X

MEM_DET1

SR49

10KOhm

1%

12

SX1

SIDE

32.768KHZ

12

5

SR47

12

10KOhm

1%

+3VS

SR5 10KOhm

/X

MEM_DET0 RTCRST#

1 2 12

SR6

10KOhm

1%

GND

RTC_X1

12

1

2

SR15 10MOhm

RTC_X2

SIMCARD_IN#

B B

A A

+3VS

GND

SC9 15PF/50V

GND

SC11 15PF/50V

1 2 12

3

SATA[0]RXN SATA[0]RXP

SATA[0]TXN

SATA[0]TXP SATA[1]RXN/RESERVED SATA[1]RXP/RESERVED SATA[1]TXN/RESERVED

SATA[1]TXP/RESERVED

SATA[2]RXN SATA[2]RXP

SATA[2]TXN

SATA[2]TXP SATA[3]RXN/RESERVED SATA[3]RXP/RESERVED SATA[3]TXN/RESERVED

SATA[3]TXP/RESERVED

SATA_CLKN SATA_CLKP

SATARBIAS#

SATARBIAS

LINKALERT#

SATA[0]GP/GPI[26] SATA[1]GP/GPI[29] SATA[2]GP/GPI[30] SATA[3]GP/GPI[31]

INTRUDER#

AE3 AD3 AG2 AF2 AC5 AD5 AF4 AG4 AD7 AC7 AF6 AG6 AC9 AD9

GND

AF8 AG8

AC2 AC1

AG11 AF11

Y4

SMBCLK

W5

SMBDATA

S_LINKALERT#

Y5

S_SMLINK0

W4

SMLINK[0] SMLINK[1]

SATALED#

RSMRST#

RTCX1

RTCX2

RTCRST#

INTVRMEN

SPKR

SC10 0.1UF/16V

1 2

S_SMB_CLK S_SMB_DATA SMB_CLK SMB_DATA

4

U6

AC19 AF17 AE18 AF18 AG18 AA3

Y3

Y1

Y2

AA2

AA5

F8

/X

S_SMLINK1

MEM_DET0 PCBA MEM_DET1 S_INTRUDER#

RTC_X1

RTC_X2

S_INTVRMEN

SB_SPKR

S_SATA_RXN0 28 S_SATA_RXP0 28 S_SATA_TXN0 28 S_SATA_TXP0 28

S_SATARBIAS

SB_SPKR

GND

3 4

4.7KOhm

1 2

4.7KOhm

5 6

4.7KOhm

7 8

4.7KOhm

CLK_SATA_ICH# 6 CLK_SATA_ICH 6

CLK_SATA_ICH# CLK_SATA_ICH

SR44

24.9Ohm

1%

1 2

GND

S_SMB_CLK 6 S_SMB_DATA 6

+3VSUS

10KOhm 10KOhm 10KOhm

SIMCARD_IN# 24

1 2

PM_RSMRST# 36

1 2

4.7KOhm

+3VSUS

+3VS

SRN9C SRN9B SRN9A

12

/X

5 6 3 4 1 2

SR7 1MOhm

SR11 330KOhm

SR13

SRN8B SRN8A SRN8C SRN8D

SC61 10PF/50V

12

+VCC_RTC

+3VS

/X

12

/X

PCIE_RXN124 PCIE_RXP124

PCIE_TXN124

PCIE_TXP124 X_L1X1_RXN26 X_L1X1_RXP26

X_L1X1_TXN26

X_L1X1_TXP26 PCIE_RXN325 PCIE_RXP325

PCIE_TXN325

PCIE_TXP325

S_SMB_CLK

S_SMB_DATA

3

GND

SC62 10PF/50V

PCIE 1

PCIE 3 PCIE 4

1 2 1 2

SC1 0.1UF/16V

1 2

SC3 0.1UF/16V

1 2

+1.5VS

SR4 24.9Ohm

CLK_PCIE_ICH CLK_PCIE_ICH#

+5VS

2

6 1

SQ1A

+5VS

UM6K1N

5

3 4

SQ1B UM6K1N

DMI_TXN[3:0] 9 DMI_TXP[3:0] 9 DMI_RXN[3:0] 9 DMI_RXP[3:0] 9 U_USB3+ 30

WIMAX LANPCIE 2 WLAN NC

C2130.1UF/16V /WIMAX C214 0.1UF/16V /WIMAX

SC2 0.1UF/16V

1 2

SC4 0.1UF/16V

1 2

CLK_PCIE_ICH#6 CLK_PCIE_ICH6

BAT

SIDE1

SIDE2

WTOB_CON_2P

1%

SC5 10PF/50V SC6 10PF/50V

1 2

SMB_CLK 7,25

SMB_DATA 7,25

3 1 2 4

DMI_RXN0 DMI_RXP0 DMI_TXN0 DMI_TXP0 DMI_RXN1 DMI_RXP1 DMI_TXN1 DMI_TXP1 DMI_RXN2 DMI_RXP2 DMI_TXN2 DMI_TXP2 DMI_RXN3 DMI_RXP3 DMI_TXN3 DMI_TXP3

PCIE_TXN1_C PCIE_TXP1_C

PCIE_TXN2_C PCIE_TXP2_C

PCIE_TXN3_C PCIE_TXP3_C

S_DMI_COMP

12

/X

12

/X

+VCC_BAT

GND

1 2

T25

T24 R27 R26

V25

V24 U27 U26

Y25

Y24 W27 W26

AB24 AB23 AA27 AA26

H25 H24 G27 G26

K25

K24

J27

J26 M25 M24

L27

L26

P24

P23 N27 N26

GND

F24

F23

GND

AD25 AC25

SR12

1KOhm

+VCC_BAT_R

2

U2B

DMI[0]RXN DMI[0]RXP DMI[0]TXN DMI[0]TXP DMI[1]RXN DMI[1]RXP DMI[1]TXN DMI[1]TXP DMI[2]RXN DMI[2]RXP DMI[2]TXN DMI[2]TXP DMI[3]RXN DMI[3]RXP DMI[3]TXN DMI[3]TXP

PERn[1] PERp[1] PETn[1] PETp[1] PERn[2] PERp[2] PETn[2] PETp[2] PERn[3] PERp[3] PETn[3] PETp[3] PERn[4] PERp[4] PETn[4] PETp[4]

DMI_ZCOMP DMI_IRCOMP

DMI_CLKN DMI_CLKP

NH82801FBM

+3VA

2 1

C21

USBP[0]N

D21

USBP[0]P

A20

USBP[1]N

B20

USBP[1]P

D19

USBP[2]N

C19

USBP[2]P

A18

USBP[3]N

B18

USBP[3]P

E17

USBP[4]N

D17

USBP[4]P

B16

USBP[5]N

A16

USBP[5]P

C15

USBP[6]N

D15

USBP[6]P

A14

USBP[7]N

B14

USBP[7]P

C27

OC[0]#

B27

OC[1]#

B26

OC[2]#

C26

OC[3]#

OC[4]#/GPI[9] OC[5]#/GPI[10] OC[6]#/GPI[14] OC[7]#/GPI[15]

USBRBIAS#

3

SD1 BAT54CW

Default Group-A7V8X MX

ASUSTek Computer INC.

Date: Sheet

C23 D23 C25 C24

B22

USBRBIAS

A22

A27

CLK48

+VCC_RTC

SR9

1 2

12

SC7 1UF/16V

RTCRST# RC delay 18~25ms

GND

Size Project Name

A3

100KOHM

900SD_MB

U_USB1- 30 U_USB1+ 30 U_USB2- 30 U_USB2+ 30 U_USB3- 30

U_CARD- 31 U_CARD+ 31 U_3G- 24 U_3G+ 24

U_CAM- 32 U_CAM+ 32

USB_OC#4 USB_OC#5 USB_OC#6 USB_OC#7

S_USBRBIAS

USB_OC#4 USB_OC#5 USB_OC#6 USB_OC#7

SR2 22.6Ohm

CLK_48M_USB 6

USB 0 USB 1 USB Conn

USB Conn

USB 2

USB Conn

USB 3

Card Reader

USB 4

3G

USB 5

NC

USB 6 USB 7NCCamera

12

SC8 1UF/16V

GND

Title :

Engineer:

1

USB_OC#01 30 USB_OC#23 30

1 2

1 2 3 4 5 6 7 8

10KOhm 10KOhm 10KOhm 10KOhm

RTCRST#

12

SGL_JUMP

Place Near Open Door

GND

CLRTC

1%

SRN1A SRN1B SRN1C SRN1D

ICH6-M_USB_PCIE_IDE

Hauld_Zhou

15 51Monday, November 10, 2008

of

GND +3VSUS

Rev

R1.0G

5

+3VS

1

2

SD2

SR31

10Ohm

GND

+3VSUS

1

GND

3 12

SC17 1UF/16V

/CAP/X

2

3 12

SC24 1UF/16V

/CAP/X

+VCCP

1

BAT54CW

+5VS_REF

GND

SD3 BAT54CW

+5VSUS_REF

GND

2

SD4 BAT54CW

3

5

12

SC18

0.1UF/16V

12

SC25

0.1UF/16V

+5VS

SR18

1 2

D D

C C

B B

A A

+5VSUS

10Ohm

r0603_h24

1 2

10Ohm

r0603_h24

+1.5VS

1 2

SR19

+1.5VS

+2.5VS

SL2

21

70Ohm/100Mhz

SR17 0Ohm

1 2

+1.5VS +1.5VS_DMIPLL

GND

+1.5VS_SPCIE

GND

12

SC22 10uF/10V

/CAP/X

12

SC32 10uF/10V

12

SC40 10uF/10V

/CAP/X

SL1

120Ohm/100Mhz

+1.5VS

12

SC50

0.1UF/16V

GND

630 mA

12

SC33

0.1UF/16V

12

SC41

0.1UF/16V

+2.5VS_SB

12

SC15

0.1UF/16V

/CAP/X

21

GND

+1.5VS

GND

+1.5VS

GND

12

SC23

12

SC38

0.1UF/16V

12

SC34

0.1UF/16V

12

SC20

0.1UF/16V

/CAP/X

4

+5VS_REF

+5VSUS_REF

12

SC16

0.1UF/16V

/CAP/X

GNDGND

0.01UF/16V

SATA

4

3

GND

12

SC28

0.1UF/16V

/CAP/X

12

SC27

0.1UF/16V

/CAP/X

12

SC60

0.1UF/16V

/CAP/X

PCI

12

SC37

0.1UF/16V

/CAP/X

40 mA

12

SC46

0.1UF/16V

12

SC63 10UF/6.3V

/X c0805_h37

+1.5VS

GND +1.5VS

GND

+3VS

GND +3VS

GND

SHORTPIN

+3VSUS

GND

20 mA

12

SC14 10uF/10V

12

SC48 10uF/10V

/CAP/X

12

SC31 1UF/16V

/CAP/X

12

SC39 1UF/16V

/CAP/X

+3VSUS

12

SC47 10uF/10V

/CAP/X

SC52

0.1UF/16V

http://hobi-elektronika.net

U2E

AA18 AB18

AC27

AE1

AA22 AA23 AA24 AA25 AB25 AB26 AB27

G22 G23 G24 G25 H21 H22

M21 M22 N21 N22 N23 N24 N25

R21 R22

U21 U22

W21 W22

AA6 AB4 AB5 AB6 AC4 AD4 AE4 AE5 AG5 AF5 AA7 AA8 AA9 AB8 AC8 AD8 AE8 AE9 AF9 AG9

A25

F25 F26 F27

K21 K22 L21 L22

P21 P25 P26 P27

T21 T22

V21 V22

Y21 Y22

F21

J21 J22

A8

V5REF1 V5REF2

Vcc2_5_1

P7

Vcc2_5_2

V5REF_Sus

VccDMIPLL VccSATAPLL VccUSBPLL Vcc1_5_B_1

Vcc1_5_B_2 Vcc1_5_B_3 Vcc1_5_B_4 Vcc1_5_B_5 Vcc1_5_B_6 Vcc1_5_B_7 Vcc1_5_B_8 Vcc1_5_B_9 Vcc1_5_B_10 Vcc1_5_B_11 Vcc1_5_B_12 Vcc1_5_B_13 Vcc1_5_B_14 Vcc1_5_B_15 Vcc1_5_B_16 Vcc1_5_B_17 Vcc1_5_B_18 Vcc1_5_B_19 Vcc1_5_B_20 Vcc1_5_B_21 Vcc1_5_B_22 Vcc1_5_B_23 Vcc1_5_B_24 Vcc1_5_B_25 Vcc1_5_B_26 Vcc1_5_B_27 Vcc1_5_B_28 Vcc1_5_B_29 Vcc1_5_B_30 Vcc1_5_B_31 Vcc1_5_B_32 Vcc1_5_B_33 Vcc1_5_B_34 Vcc1_5_B_35 Vcc1_5_B_36 Vcc1_5_B_37 Vcc1_5_B_38 Vcc1_5_B_39 Vcc1_5_B_40 Vcc1_5_B_41 Vcc1_5_B_42 Vcc1_5_B_43 Vcc1_5_B_44 Vcc1_5_B_45

Vcc1_5_A_1 Vcc1_5_A_2 Vcc1_5_A_3 Vcc1_5_A_4 Vcc1_5_A_5 Vcc1_5_A_6 Vcc1_5_A_7 Vcc1_5_A_8 Vcc1_5_A_9 Vcc1_5_A_10 Vcc1_5_A_11 Vcc1_5_A_12 Vcc1_5_A_13 Vcc1_5_A_14 Vcc1_5_A_15 Vcc1_5_A_16 Vcc1_5_A_17 Vcc1_5_A_18 Vcc1_5_A_19 Vcc1_5_A_20

NH82801FBM

Vcc1_5_A_21 Vcc1_5_A_22 Vcc1_5_A_23 Vcc1_5_A_24 Vcc1_5_A_25 Vcc1_5_A_26 Vcc1_5_A_27 Vcc1_5_A_28 Vcc1_5_A_29 Vcc1_5_A_30 Vcc1_5_A_31 Vcc1_5_A_32 Vcc1_5_A_33 Vcc1_5_A_34 Vcc1_5_A_35 Vcc1_5_A_36 Vcc1_5_A_37 Vcc1_5_A_38 Vcc1_5_A_39 Vcc1_5_A_40 Vcc1_5_A_41 Vcc1_5_A_42 Vcc1_5_A_43 Vcc1_5_A_44 Vcc1_5_A_45 Vcc1_5_A_46 Vcc1_5_A_47 Vcc1_5_A_48 Vcc1_5_A_49 Vcc1_5_A_50 Vcc1_5_A_51 Vcc1_5_A_52

V_CPU_IO_1 V_CPU_IO_2 V_CPU_IO_3

VccLAN3_3/VccSus3_3_1 VccLAN3_3/VccSus3_3_2 VccLAN3_3/VccSus3_3_3 VccLAN3_3/VccSus3_3_4

VccSus3_3_1 VccSus3_3_2 VccSus3_3_3 VccSus3_3_4 VccSus3_3_5 VccSus3_3_6 VccSus3_3_7 VccSus3_3_8

VccSus3_3_9 VccSus3_3_10 VccSus3_3_11 VccSus3_3_12 VccSus3_3_13 VccSus3_3_14 VccSus3_3_15 VccSus3_3_16 VccSus3_3_17 VccSus3_3_18 VccSus3_3_19 VccSus3_3_20

VccSus1_5_1

VccSus1_5_2

VccSus1_5_3

VccLAN1_5/VccSus1_5_1 VccLAN1_5/VccSus1_5_2

Vcc3_3_1 Vcc3_3_2 Vcc3_3_3 Vcc3_3_4 Vcc3_3_5 Vcc3_3_6 Vcc3_3_7 Vcc3_3_8

Vcc3_3_9 Vcc3_3_10 Vcc3_3_11 Vcc3_3_12 Vcc3_3_13 Vcc3_3_14 Vcc3_3_15 Vcc3_3_16 Vcc3_3_17 Vcc3_3_18 Vcc3_3_19 Vcc3_3_20 Vcc3_3_21 Vcc3_3_22

VccRTC

AA19 AA20 AA21 L11 L12 L14 L16 L17 M11 M17 P11 P17 T11 T17 U11 U12 U14 U16 U17 G8 D24 D25 D26 D27 E20 E21 E22 E23 E24 F20 G20 F9

AB22 AD26 AG23

AA12 AA14 AA15 AA17 AC15 AD17 AG13 AG16 AG19 A6 B1 E4 H1 H7 J7 L4 L7 M7 P1 E26 AA10 AG10

A13 F14 G13 G14 A11 U4 V1 V7 W2 Y7 A17 B17 C16 C17 D16 E16 F15 F16 F18 G15 G16 G17 G18 A24

AB3 R7 U7 G19 G10 G11

12

1900 mA

12

GND

12

340 mA

12

+3VSUS_SLAN

12

GND

12

+VCC_RTC

+1.5VS_SLAN

20 mA

12

3

GND

SC12

0.1UF/16V

SC19

0.1UF/16V

14 mA

SC26

0.1UF/16V

SC35

0.1UF/16V

/CAP/X

SC29

0.1UF/16V

/CAP/X

SC42

0.1UF/16V

/CAP/X

SC44

0.1UF/16V

12

SC51

0.1UF/16V

GND

SC54

0.1UF/16V

/CAP/X

+VCCP

JP5

CORE

12

SC13

0.1UF/16V

USB

12

SC49

0.1UF/16V

IDE

12

SC36

0.1UF/16V

/CAP/X

12

SC30

0.1UF/16V

/CAP/X

1 2

12

SC45

0.1UF/16V

30 mA

+1.5VSUS

12

SC53

0.1UF/16V

GND

2

U2F

A1

Vss1

A12

Vss2

A15

+1.5VS

12

NC63 10uF/10V

/CAP/X

GND

+3VS

12

SC59 10uF/10V

/CAP/X

GND

LAN

GND GND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

2

Date: Sheet

Vss3

A19

Vss4

A21

Vss5

A23

Vss6

A26

Vss7

A4

Vss8

A7

Vss9

A9

Vss10

AA11

Vss11

AA13

Vss12

AA16

Vss13

AA4

Vss14

AB1

Vss15

AB10

Vss16

AB19

Vss17

AB2

Vss18

AB7

Vss19

AB9

Vss20

AC10

Vss21

AC12

Vss22

AC22

Vss23

AC23

Vss24

AC24

Vss25

AC26

Vss26

AC3

Vss27

AC6

Vss28

AD1

Vss29

AD10

Vss30

AD15

Vss31

AD18

Vss32

AD2

Vss33

AD24

Vss34

AD6

Vss35

AE10

Vss36

AE11

Vss37

AE12

Vss38

AE2

Vss39

AE21

Vss40

AE25

Vss41

AE6

Vss42

AE7

Vss43

AF1

Vss44

AF12

Vss45

AF26

Vss46

AF3

Vss47

AF7

Vss48

AG1

Vss49

AG12

Vss50

AG14

Vss51

AG17

Vss52

AG20

Vss53

AG22

Vss54

AG3

Vss55

AG7

Vss56

B13

Vss57

B15

Vss58

B19

Vss59

B21

Vss60

B23

Vss61

B25

Vss62

C14

Vss63

C18

Vss64

C20

Vss65

C22

Vss66

C4

Vss67

D1

Vss68

D10

Vss69

D13

Vss70

D14

Vss71

D18

Vss72

D20

Vss73

D22

Vss74

D7

Vss75

E14

Vss76

E15

Vss77

E18

Vss78

E19

Vss79

E25

Vss80

F17

Vss81

F19

Vss82

F22

Vss83

F4

Vss84

G1

Vss85

G12

Vss86

NH82801FBM

900SD_MB

1

Vss87 Vss88 Vss89 Vss90 Vss91 Vss92 Vss93 Vss94 Vss95 Vss96 Vss97 Vss98

Vss99 Vss100 Vss101 Vss102 Vss103 Vss104 Vss105 Vss106 Vss107 Vss108 Vss109 Vss110 Vss111 Vss112 Vss113 Vss114 Vss115 Vss116 Vss117 Vss118 Vss119 Vss120 Vss121 Vss122 Vss123 Vss124 Vss125 Vss126 Vss127 Vss128 Vss129 Vss130 Vss131 Vss132 Vss133 Vss134 Vss135 Vss136 Vss137 Vss138 Vss139 Vss140 Vss141 Vss142 Vss143 Vss144 Vss145 Vss146 Vss147 Vss148 Vss149 Vss150 Vss151 Vss152 Vss153 Vss154 Vss155 Vss156 Vss157 Vss158 Vss159 Vss160 Vss161 Vss162 Vss163 Vss164 Vss165 Vss166 Vss167 Vss168 Vss169 Vss170 Vss171 Vss172

Title :

Engineer:

1

G21 G7 G9 H23 H26 H27 J23 J24 J25 J4 K1 K23 K26 K27 K7 L13 L15 L23 L24 L25 M12 M13 M14 M15 M16 M23 M26 M27 M4 N1 N11 N12 N13 N14 N15 N16 N17 N7 P12 P13 P14 P15 P16 P22 R11 R12 R13 R14 R15 R16 R17 R23 R24 R25 R4 T1 T12 T13 T14 T15 T16 T23 T26 T27 T7 U13 U15 U23 U24 U25 V23 V26 V27 V4 W1 W23 W25 W7 Y23 Y26 Y27 Y6 W24 E27 B24 AF10

ICH6-M_PWR_GND

Kell_Huang

16 51Monday, November 10, 2008

Rev

R1.0G

of

5

A

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8

DDR_VREF

MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#0 MA_DQS0

GND

D D

12

MC62

0.1UF/16V

GND GND

C C

U34

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

MA_BA0

G2

MA_BA1

G3

MA_BA2 MA_BA2

G1 F7

G7 F3 G8 F2 F9

E8 F8

MA_DQ0

C8

MA_DQ1

C2

MA_DQ2

D7

MA_DQ3

D3

MA_DQ4

D1

MA_DQ5

D9

MA_DQ6

B1

MA_DQ7 MA_DM0

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

4

MA_RAS# 10,18,19,20,21 MA_CAS# 10,18,19,20,21 MA_WE# 10,18,19,20,21 MA_CS#1 9,18,21 MA_CKE1 9,18,21 MA_ODT1 9,18,21

MCLK_DDR0 9,19 MCLK_DDR0# 9,19

+1.8V

3

http://hobi-elektronika.net

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

DDR_VREF

MA_DQS#1 MA_DQS1

U35

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1

MA_RAS# MA_CAS# MA_WE# MA_CS#1 MA_CKE1 MA_ODT1

MCLK_DDR0 MCLK_DDR0#

MA_DQ8 MA_DQ9 MA_DQ10 MA_DQ11 MA_DQ12 MA_DQ13 MA_DQ14 MA_DQ15 MA_DM1

+1.8V

2

MA_DQ[31:0] 10,19 MA_DQS[3:0] 10,19 MA_DQS#[3:0] 10,19 MA_DM[3:0] 10,19 MA_MA[13:0] 10,18,19,20,21 MA_BA[2:0] 10,18,19,20,21 DDR_VREF 18,19,20

12

MC2 10uF/10V

/X

12

MC7 10uF/10V

for U34 & U35

12

MC3 1UF/16V

MC4 1UF/16V

for U36 & U37

12

MC8 1UF/16V

MC9 1UF/16V

12

MC5

0.1UF/16V

12

MC10

0.1UF/16V

12

GND

12

GND

+1.8V

MC6

0.1UF/16V

MC11

0.1UF/16V

1

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

B B

MA_DQS#2 MA_DQS2

GND

12

MC63

0.1UF/16V

U36

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

MA_BA0

G2

MA_BA1

G3 G1

MA_RAS#

F7

MA_CAS#

G7

MA_WE#

F3

MA_CS#1

G8

MA_CKE1

F2

MA_ODT1

F9

MCLK_DDR0

E8

CK

MCLK_DDR0#

F8

MA_DQ16

C8

MA_DQ17

C2

MA_DQ18

D7

MA_DQ19

D3

MA_DQ20

D1

MA_DQ21

D9

MA_DQ22

B1

MA_DQ23 MA_DM2

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA

_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

DDR_VREFDDR_VREF

MA_DQS#3 MA_DQS3

GND

4

U37

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

3

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1 MA_BA2MA_BA2

MA_RAS# MA_CAS# MA_WE# MA_CS#1 MA_CKE1 MA_ODT1

MCLK_DDR0 MCLK_DDR0#

MA_DQ24 MA_DQ25 MA_DQ26 MA_DQ27 MA_DQ28 MA_DQ29 MA_DQ30 MA_DQ31 MA_DM3

+1.8V+1.8V

Default Group-A7V8X MX

Title :

ASUSTek COMPUTER INC

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

2

Onboard_DRAM_1

1

Fehling_wang

17 51Monday, November 10, 2008

of

Rev

R1.0G

A

5

A

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10

DDR_VREF

MA_MA11 MA_MA12 MA_MA13

MA_DQS#4 MA_DQS4

GND

D D

12

MC64

0.1UF/16V

GND

U38

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

MA_BA0

G2

MA_BA1

G3

MA_BA2

G1 F7

G7 F3 G8 F2 F9

E8 F8

MA_DQ32

C8

MA_DQ33

C2

MA_DQ34

D7

MA_DQ35

D3 D1

MA_DQ37

D9

MA_DQ38

B1

MA_DQ39 MA_DM4

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

4

MA_RAS# 10,17,19,20,21 MA_CAS# 10,17,19,20,21 MA_WE# 10,17,19,20,21 MA_CS#1 9,17,21 MA_CKE1 9,17,21 MA_ODT1 9,17,21

MCLK_DDR1 9,20 MCLK_DDR1# 9,20

+1.8V

MA_MA0

DDR_VREF

MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#5 MA_DQS5

GND

http://hobi-elektronika.net

U39

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

3

RAS# CAS#

WE#

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

BA0 BA1

NC3

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

MA_BA0

G2

MA_BA1

G3

MA_BA2

G1

MA_RAS#

F7

MA_CAS#

G7

MA_WE#

F3

MA_CS#1

G8

MA_CKE1

F2

MA_ODT1

F9

MCLK_DDR1

E8

CK

MCLK_DDR1#

F8

MA_DQ40

C8

MA_DQ41

C2

MA_DQ42

D7

MA_DQ43

D3

MA_DQ44

D1

MA_DQ45MA_DQ36

D9

MA_DQ46

B1

MA_DQ47 MA_DM5

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

+1.8V

2

MA_DQ[63:32] 10,20 MA_DQS[7:4] 10,20 MA_DQS#[7:4] 10,20 MA_DM[7:4] 10,20 MA_MA[13:0] 10,17,19,20,21 MA_BA[2:0] 10,17,19,20,21 DDR_VREF 17,19,20

MC50 10uF/10V

for U38 & U39

12

MC51

MC52

1UF/16V

12

MC53

0.1UF/16V

+1.8V

12

MC54

0.1UF/16V

1

C C

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_CS#1 MA_MA8 MA_MA9

MA_MA11 MA_MA12 MA_MA13

B B

DDR_VREF

MA_DQS#6 MA_DQS6

GND

12

MC65

0.1UF/16V

U40

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1 MA_BA2

MA_RAS# MA_CAS# MA_WE#

MA_CKE1 MA_ODT1

MCLK_DDR1 MCLK_DDR1#

MA_DQ48 MA_DQ49 MA_DQ50 MA_DQ51 MA_DQ52 MA_DQ53 MA_DQ54 MA_DQ55 MA_DM6

+1.8V

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_RAS# MA

_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11MA_MA10 MA_MA12 MA_MA13

DDR_VREF

MA_DQS#7 MA_DQS7

GND

U41

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

BA0 BA1

CK

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1 MA_BA2

MA_CAS# MA_WE# MA_CS#1 MA_CKE1 MA_ODT1

MCLK_DDR1 MCLK_DDR1#

MA_DQ56 MA_DQ57 MA_DQ58 MA_DQ59 MA_DQ60 MA_DQ61 MA_DQ62 MA_DQ63 MA_DM7

+1.8V

12

MC55 10uF/10V

/X

for U40 & U41

12

MC56 1UF/16V

MC57 1UF/16V

12

MC58

0.1UF/16V

GND

12

MC59

0.1UF/16V

A

Default Group-A7V8X MX

Title :

ASUSTek COMPUTER INC

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

Onboard_DRAM_2

1

Fehling_wang

18 51Monday, November 10, 2008

of

Rev

R1.0G

5

A

4

3

2

1

http://hobi-elektronika.net

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5

DDR_VREF

MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#0 MA_DQS0

D D

12

MC14

0.1UF/16V

C C

GND GND

U42

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

MA_BA0

G2

MA_BA1

G3

MA_BA2 MA_BA2

G1 F7

G7 F3 G8 F2 F9

E8 F8

MA_DQ1

C8

MA_DQ0

C2

MA_DQ3

D7

MA_DQ2

D3

MA_DQ5

D1

MA_DQ4

D9

MA_DQ7

B1

MA_DQ6 MA_DM0

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_RAS# 10,17,18,20,21 MA_CAS# 10,17,18,20,21 MA_WE# 10,17,18,20,21 MA_CS#0 9,20,21 MA_CKE0 9,20,21 MA_ODT0 9,20,21

MCLK_DDR0 9,17 MCLK_DDR0# 9,17

+1.8V +1.8V

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_RAS# MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

DDR_VREF

MA_DQS#1 MA_DQS1

GND

U43

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1

MA_CAS# MA_WE# MA_CS#0 MA_CKE0 MA_ODT0

MCLK_DDR0 MCLK_DDR0#

MA_DQ9 MA_DQ8 MA_DQ11 MA_DQ10 MA_DQ13 MA_DQ12 MA_DQ15 MA_DQ14 MA_DM1

+1.8V

12

MC15 10uF/10V

/X

MA_DQ[31:0] 10,17 MA_DQS[3:0] 10,17 MA_DQS#[3:0] 10,17 MA_DM[3:0] 10,17 MA_MA[13:0] 10,17,18,20,21 MA_BA[2:0] 10,17,18,20,21 DDR_VREF 17,18,20

for U42 & U43

12

MC16 1UF/16V

MC17 1UF/16V

12

MC18

0.1UF/16V

GND

12

MC19

0.1UF/16V

MC20 10uF/10V

12

MC45

3.3pF/50V

for U44 & U45

12

MC21 1UF/16V

MCLK_DDR0

MR7 200Ohm

1%

MCLK_DDR0#

1 2

Default Group-A7V8X MX

ASUSTek COMPUTER INC

Size Project Name

A3

Date: Sheet

12

MC22 1UF/16V

12

MC23

0.1UF/16V

GND

MR8 200Ohm

1%

1 2

900SD_MB

12

MC24

0.1UF/16V

Title :

Engineer:

Onboard_DRAM_2

1

Fehling_wang

19 51Monday, November 10, 2008

of

Rev

R1.0G

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12

DDR_VREF

MA_MA13

MA_DQS#2 MA_DQS2

GND

B B

12

MC66

0.1UF/16V

GND

U44

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

5

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

MA_BA0

G2

MA_BA1

G3 G1

MA_RAS#

F7

MA_CAS#

G7

MA_WE#

F3

MA_CS#0

G8

MA_CKE0

F2

MA_ODT0

F9

MCLK_DDR0

E8

CK

MCLK_DDR0#

F8

MA_DQ17

C8

MA_DQ16

C2

MA_DQ19

D7

MA_DQ18

D3

MA_DQ21

D1

MA_DQ20

D9

MA_DQ23

B1

MA_DQ22 MA_DM2

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

+1.8V

DDR_VREF

4

_MA0

MA MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#3 MA_DQS3

GND

U45

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

CK

3

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1 MA_BA2MA_BA2

MA_RAS# MA_CAS# MA_WE# MA_CS#0 MA_CKE0 MA_ODT0

MCLK_DDR0 MCLK_DDR0#

MA_DQ25 MA_DQ24 MA_DQ27 MA_DQ26 MA_DQ29 MA_DQ28 MA_DQ31 MA_DQ30 MA_DM3

+1.8V

12

2

A

5

A

4

3

2

1

http://hobi-elektronika.net

U47

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

U49

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

NU/RDQS#

VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

DDR_VREF

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#5 MA_DQS5

GND

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4

MA_MA6 MA_MA7MA_MA6 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

MA_DQS#7 MA_DQS7

GND

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4

D D

12

MC67

C C

0.1UF/16V

MA_MA5 MA_MA6 MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

DDR_VREF

MA_DQS#4 MA_DQS4

GNDGND

MA_MA0 MA_MA1 MA_MA2 MA_MA3 MA_MA4 MA_MA5 MA_MA5

MA_MA7 MA_MA8 MA_MA9 MA_MA10 MA_MA11 MA_MA12 MA_MA13

B B

DDR_VREF

MA_DQS#6 MA_DQS6

GND

12

MC68

0.1UF/16V

U46

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

U48

H8

A0

H3

A1

H7

A2

J2

A3

J8

A4

J3

A5

J7

A6

K2

A7

K8

A8

K3

A9

H2

A10

K7

A11

L2

A12

L8

A13

L3

NC1

L7

NC2

A3

VSS1

K9

VSS2

E3

VSS3

J1

VSS4

B8 B9

VSSQ1 DQ7

B2 B3

VSSQ2 DM/RDQS

A7

VSSQ3

D2

VSSQ4

D8

VSSQ5

E7

VSSDL

E2

VREF

A8

DQS#

B7

DQS

HY5PS12821CFP_Y5

BA0 BA1 NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

BA0 BA1 NC3

RAS#

CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

NU/RDQS#

VDD1 VDD2 VDD3

VDD4 VDDQ1 VDDQ2 VDDQ3 VDDQ4 VDDQ5

VDDL

MA_BA0

G2

MA_BA1

G3

MA_BA2

G1 F7

G7 F3 G8 F2 F9

E8

CK

F8

MA_DQ33

C8

MA_DQ32

C2

MA_DQ35

D7

MA_DQ34

D3

MA_DQ37

D1

MA_DQ36

D9

MA_DQ39

B1

MA_DQ38 MA_DM4

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0

G2

MA_BA1

G3

MA_BA2

G1

MA_RAS#

F7

MA_CAS#

G7

MA_WE#

F3

MA_CS#0

G8

MA_CKE0

F2

MA_ODT0

F9

MCLK_DDR1

E8

CK

MCLK_DDR1#

F8

MA_DQ49

C8

MA_DQ48

C2

MA_DQ51

D7

MA_DQ50

D3

MA_DQ53

D1

MA_DQ52

D9

MA_DQ55

B1

MA_DQ54 MA_DM6

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_RAS# 10,17,18,19,21 MA_CAS# 10,17,18,19,21 MA_WE# 10,17,18,19,21 MA_CS#0 9,19,21 MA_CKE0 9,19,21 MA_ODT0 9,19,21

MCLK_DDR1 9,18 MCLK_DDR1# 9,18

+1.8V

CK

BA0 BA1

NC3

RAS# CAS#

WE#

CS# CKE ODT

CK# DQ0

DQ1 DQ2 DQ3 DQ4 DQ5 DQ6

VDD1 VDD2 VDD3 VDD4

VDDL

CK

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

G2 G3 G1

F7 G7 F3 G8 F2 F9

E8 F8

C8 C2 D7 D3 D1 D9 B1

A2 H9

L1 E9 A1 A9 C1 C3 C7 C9 E1

MA_BA0 MA_BA1 MA_BA2

MA_RAS# MA_CAS# MA_WE# MA_CS#0 MA_CKE0 MA_ODT0

MCLK_DDR1 MCLK_DDR1#

MA_DQ41 MA_DQ40 MA_DQ43 MA_DQ42 MA_DQ45 MA_DQ44 MA_DQ47 MA_DQ46 MA_DM5

MA_BA0

A_BA1

M MA_BA2

MA_RAS# MA_CAS# MA_WE# MA_CS#0 MA_CKE0 MA_ODT0

MCLK_DDR1 MCLK_DDR1#

MA_DQ57 MA_DQ56 MA_DQ59 MA_DQ58 MA_DQ61 MA_DQ60 MA_DQ63 MA_DQ62 MA_DM7

+1.8V

12

+1.8V

12

+1.8V

1 2

GND

MC35 10uF/10V

MC40 10uF/10V

/X

MC47

3.3pF/50V

MR11 1KOhm

1%

DDR_VREF

MR12 1KOhm

1%

GND

MA_DQ[63:32] 10,18 MA_DQS[7:4] 10,18 MA_DQS#[7:4] 10,18 MA_DM[7:4] 10,18 MA_MA[13:0] 10,17,18,19,21 MA_BA[2:0] 10,17,18,19,21 DDR_VREF 17,18,19

for U46 & U47

12

MC36

MC37

1UF/16V

for U48 & U49

12

MC41

MC42

1UF/16V

MCLK_DDR1

MR9 200Ohm

1%

MCLK_DDR1#

1 2

12

MC48

0.1UF/16V

/CAP/X

1 2

12

MR10 200Ohm

1%

MC38

0.1UF/16V

MC43

0.1UF/16V

GND

12

MC39

0.1UF/16V

12

MC44

0.1UF/16V

A

Default Group-A7V8X MX

Title :

ASUSTek COMPUTER INC

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

Onboard_DRAM_1

1

Fehling_wang

20 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

D D

MA_MA[13:0] 10,17,18,19,20 MA_BA[2:0] 10,17,18,19,20

+VTTDDR

MRN4A MRN4B MRN4C MRN4D

MRN1A MRN1B MRN1C MRN1D MRN1E MRN1F MRN1G MRN1H

MRN2A MRN2B MRN2C MRN2D MRN2E MRN2F MRN2G MRN2H

MRN3A MRN3B MRN3C MRN3D MRN3E MRN3F MRN3G MRN3H

MC33

1 2

1UF/16V

MC32

1 2

1UF/16V

MC29

1 2

0.1UF/16V MC30

1 2

0.1UF/16V MC31

1 2

0.1UF/16V MC26

1 2

0.1UF/16V

MA_CKE19,17,18

C C

B B

MA_CKE09,19,20

MA_ODT19,17,18 MA_WE#10,17,18,19,20 MA_CAS#10,17,18,19,20

MA_ODT09,19,20 MA_CS#19,17,18

MA_CS#09,19,20 MA_RAS#10,17,18,19,20

MA_MA12 MA_MA11 MA_MA7 MA_MA6 MA_MA8 MA_MA5

MA_BA1

MA_MA13

MA_BA0

MA_MA4 MA_MA2 MA_MA0 MA_MA3 MA_MA1 MA_MA10

MA_BA2 MA_MA9

1 16

56OHM

2 15

56OHM

3 14

56OHM

4 13

56OHM

5 12

56OHM

6 11

56OHM

7 10

56OHM

8 9

56OHM

1 16

56OHM

2 15

56OHM

3 14

56OHM

4 13

56OHM

5 12

56OHM

6 11

56OHM

7 10

56OHM

8 9

56OHM

1 16

56OHM

2 15

56OHM

3 14

56OHM

4 13

56OHM

5 12

56OHM

6 11

56OHM

7 10

56OHM

8 9

56OHM

1 2

56Ohm

3 4

56Ohm

5 6

56Ohm

7 8

56Ohm

GND

A A

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

DDR2_Termination

Kell_Huang

1

21 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

R215

0Ohm

R217

0Ohm

R219

0Ohm

61

34

CRT_RED_R

GND

CRT_GREEN_R

GND

CRT_BLUE_R

GND

CRT_HSYNC_LS

CRT_VSYNC_LS

DDC_DATA_R

GND

1 2

RN1A

RN1C

RN1B

R216

150Ohm

R218

150Ohm

R220

150Ohm

RN1D

1 2

r0603_h24

1 2

r0603_h24

1 2

r0603_h24

2

Q1A UM6K1N

5

Q1B UM6K1N

CRT_RED11

D D

CRT_GREEN11

CRT_BLUE11

C C

+5VS_CRT

1 2

4.7KOhm

B B

A A

+3VS

5 6

4.7KOhm

DDC_DATA11

+5VS_CRT

3 4

4.7KOhm

+3VS

7 8

4.7KOhm

DDC_CLK11 CRT_VSYNC11

5

12

C3 22PF/25V

12

C6 22PF/25V

12

C9 22PF/25V

L44

0.082UH

L45

0.082UH

L46

0.082UH

R5

1 2

39Ohm

R6

1 2

39Ohm

R7

1 2

0Ohm

r0603_h24

R8

1 2

0Ohm

r0603_h24

21

GND

12

GND

12

GND

4

CRT_RED_CON

12

C4

5PF/50V

GND

CRT_GREEN_CON

12

C7

5PF/50V

GND

CRT_BLUE_CON

12

C10

5PF/50V

GND

CRT_HSYNC_CON

12

C11 22PF/25V

CRT_VSYNC_CON

12

C12 22PF/25V

DDC_DATA_CON

C13 47PF/50V

/X

DDC_CLK_CON

C14 47PF/50V

/X

+5VS_CRT

1

7

+3VS

OE1#

OE2#

GND

8

VCC

GND

4

6 1 7 2 8 3 9 4

10

5

3

2B

6

1B

LVC2G125DCUR

CRT_RED_CON CRT_GREEN_CON CRT_BLUE_CON

GND

U25

CRT_HSYNC11

3

2

1A

5

2A

+5VS_CRT

12

C1

0.1UF/16V

GND

1617

VGA

11 12 13 14 15

D_SUB_15P

CRT_VSYNC_LS

CRT_HSYNC_LSDDC_CLK_R

R1

1 2

0Ohm

r0805_h24

DDC_DATA_CON CRT_HSYNC_CON CRT_VSYNC_CON DDC_CLK_CON

+3VS

GND

2

12

C132

0.1UF/16V

F1

1 2

1.5A/6V

Default Group-A7V8X MX

ASUSTek Computer INC.

Date: Sheet

+5VS_CRT_F+5VS_CRT_R

12

GND

+2.5VS

2 1

GND +2.5VS

2 1

GND +2.5VS

2 1

GND +3VS

2 1

GND +3VS

2 1

GND +5VS_CRT

2 1

GND

+5VS_CRT

2 1

GND

Size Project Name

A3

D30

PMEG4010EH

C85

0.1UF/16V

/CAP/X

BAV99W_L

/X

BAV99W_L

/X

BAV99W_L

/X

BAV99W_L

/X

D1

D2

D3

D4

D5

D6

D7

07G004214010

CRT_RED

3

CRT_GREEN

3

CRT_BLUE

3

CRT_HSYNC_CON

3

CRT_VSYNC_CON

3

DDC_DATA_CON

3

DDC_CLK_CON

3

Engineer:

900SD_MB

+5VS

12

Title :

1

Onboard VGA

Kell_Huang

22 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

+3V_LCD

+3VS

12

GND

G_DDC_CLK_C G_DDC_DATA_C

G_DATAN0_C G_DATAP0_C G_DATAN1_C G_DATAP1_C

G_DATAN2_C G_DATAP2_C G_CLKN_C G_CLKP_C

1 2

GD1BAT54AW

1 2

GD2BAT54AW /X

GC1

2 1

4 5 6

10PF/50V

/X

3

GD3 BAV99W_L

U24

VSS2 VSS3 PRG

ME268-001L

GND

BLEN

/X/LCD

VSS1

VDD

LCD_CON

21

NP_NC1

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

22

NP_NC2

WTOB_CON_20P

GR3

1 2

10KOhm

1%

LID_EC#

3

Q

2 1

SIDE1 GND1

GND2 SIDE2

23 24

25 26

+3VS

GR4

100KOHM

GND

/X/LCD

12

+3VA

12

GC3

0.1UF/16V

+3VS

Close to LCD Connector

G_LVDD_EN11

12

GPC50.1UF/16V

100KOHM

12

GPC10

0.1UF/16V

/X/LCD

GPR41MOhm

+5VS

GPQ3 AP2307GN

2 3

S

2

1

12

GPR6

1 2

32

3

D

1

G

S

2

GND

BLEN

G

D

3

GPQ4 2N7002

1 2

GND

GPQ1 AP2307GN

2 3

2

GPR11MOhm

12

GPC30.1UF/16V

GPR2

100KOHM

1

+3V_LCD

12

GPC6

0.1UF/16V

+5V_LCD

D

S

3

G

1

1 2 32

3

D

1

G

S

2

GND

12

GPC1

0.1UF/16V

GPQ2 2N7002

12

GND

Close to LCD Connector

+5VS

+5VS +3V_LCD

G_LVDD_EN

12

GPC7

1UF/16V

c0603

/X/LCD

GND

GPC2 10uF/10V

c0805

1 2

12

GND

GPR5 10Ohm

/X/LCD

CNTL

GPC8

0.1UF/16V

/X/LCD

GPU1B

10

GND3

11

GND4

12

GND5

13

GND6

UP7704U8

GND2 GND1

VOUT

/X/LCD

FB

GND

GPU1A

1

POK

2

EN

3

VIN

4 5

CNTL NC

UP7704U8

/X/LCD

GPR3

31.6KOhm

/X/LCD

9 8 7 6

+3V_LCD

1 2

FB

1 2

GNDGND

12

GC2 1UF/16V

c0603

D D

G_DDC_CLK11

G_DDC_DATA11

For RF Advise

G_DATAN011 G_DATAP011 G_DATAN111 G_DATAP111

G_DATAN211 G_DATAP211 G_CLKN11 G_CLKP11

C C

for EMI

BLEN

GND

1 2

EC110

0.1UF/16V

/EMI/X

+5V_LCD

/X

GND

GR1 0Ohm

1 2

GR2 0Ohm

1 2

GR5 0Ohm

1 2

GR6 0Ohm

1 2

GR7 0Ohm

1 2

GR8 0Ohm

1 2

GR9 0Ohm

1 2

GR10 0Ohm

1 2

GR11 0Ohm

1 2

GR12 0Ohm

1 2

G_NBL_CTRL11

G_NBL_EN11 G_BACKOFF#36

LID_EC#14,36 PM_SUSB#14,36

LID#

G_DDC_CLK_C

B B

G_DDC_DATA_C G_CLKP_C G_CLKN_C G_DATAP2_C G_DATAN2_C G_DATAP1_C G_DATAN1_C G_DATAP0_C G_DATAN0_C

GC4 10PF/50V

12

GC5 10PF/50V GC6 10PF/50V GC7 10PF/50V GC8 10PF/50V GC9 10PF/50V GC10 10PF/50V GC11 10PF/50V GC12 10PF/50V GC13 10PF/50V

/X

12

/X

12

/X

12

/X

12

/X

12

/X

12

/X

12

/X

12

/X

12

/X

GND

+3VA

GND GND

GPC4

1000PF/50V

/X/LCD

GPR7 10KOhm

/X/LCD

0.1 B Beta

1 2

12

GPC9 10UF/6.3V

c0805 /X/LCD

X5R

GND

For RF Advise(Close to LCD_CON )

A A

Default Group-A7V8X MX

Title :

LCD-CON for 10inch

ASUSTek Computer Inc.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

1

SUSAN_SHI

23 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

WR1 0Ohm

1 2

U_3G+15

WC5

10UF/10V

12

/3G_DTV

U_3G-15

10UF/10V

PCIE_RXN115 PCIE_RXP115

PCIE_TXN115 PCIE_TXP115

+3VS

12

WC6

0.1UF/16V

/3G_DTV

GND

WR7 0Ohm

1 2

WR20: For 3.5G/WIMAX: 0ohm For GPS: 100Kohm

D D

+3VS +1.5VS +3VSUS

12

WC3

C C

B B

12

WC4

10UF/10V

/3G_DTV

GND GND GND

PCIE_WAKE#14,25,26

3G_MIC33,34

3G_R_A33

CLK_PCIE_3GCARD#6 CLK_PCIE_3GCARD6

WR2 0Ohm

+1.5VS

12

WC7

0.1UF/16V

/3G_DTV

GND

/WIMAX

WR8 0Ohm

1 2

WR9 0Ohm

1 2

WR14 0Ohm

1 2

WR15 0Ohm

1 2

WR21 0Ohm

1 2

+3VSUS

GND

14

12

WC8

0.1UF/16V

/3G_DTV

1 2

23

WL1

/WIMAX

WR20 0Ohm

/3.5G/WIMAX

/3G_DTV

90Ohm/100Mhz

/X

/3G_DTV

+3VS_3G

1 2

GND

http://hobi-elektronika.net

USBPP5

USBPN5

3.3V_1 GND7

1.5V_1

UIM_PWR

UIM_DATA

UIM_CLK UIM_VPP

GND8

PERST#

+3.3Vaux

GND9

1.5V_2

SMB_CLK

GND10

USB_D-

USB_D+

GND11

1.5V_3

GND12

3.3V_2

NP_NC2 NP_NC1

H23

2 4 6 8 10 12 14 16

18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52

56 55

U5F-M-EXPREE

13G021050010

/3G_DTV

+3VS_3G

+1.5VS

GND

+3VSUS

WR6

0Ohm

/WIMAX/X

1 2

USIM_PWR USIM_DATA USIM_CLK USIM_RESET

3GLAN_OFF# 3G_PERST#

USBPN5 USBPP5

LED_3GLAN#

WR10 0Ohm

1 2

1

T204TPC26T

/3.5G/X

1 2

WR12 0Ohm

/X

+3VSUS

GND

H22

3GCARD

1

WAKE#

3

Reserved1

5

Reserved2

7

CLKREQ#

9

GND1

11

REFCLK-

13

REFCLK+

15

GND2

17

Reserved/UIM_C8

19

Reserved/UIM_C4

21

GND3

23

PERn0

25

PERp0

27

GND4

29

GND5

31

PETn0

33

PETp0

35

GND6

37

Reserved3

39

Reserved4

41

Reserved5

43

Reserved6

45

Reserved7

47

Reserved8

49

Reserved9

51

Reserved10

53

GND13

54

GND14

MINI_PCI_LATCH_52P

/3.5G

U5F-M-EXPREE

13G021050010

/3G_DTV

GND GND

UIM_RESET

W_DISABLE#

SMB_DATA

LED_WWAN#

LED_WLAN# LED_WPAN#

CAP Near SIM Socket

USIM_PWR

12

WC1

33PF/50V

/3.5G

GND

USIM_RESET

12

WC2

33PF/50V

/3.5G

GND

USIM_CLK

12

WC9

33PF/50V

/3.5G

GND

USIM_DATA

12

WC10

33PF/50V

/3.5G

GND

PLT_RST# 9,14,25,26

USIM_PWR 43

USIM

C1

C5

C2

C6

C3

C7

CD1

CD2 9

CD2 SIDE1

SIM_CON_8P

12G2530006P1

/3.5G

WR3 10KOhm1%

/3.5G

1 2

SIDE2

NP_NC1

NP_NC2

SIMCARD_IN# 15

10 11

12

GND

3GCARD use 12G03010052L

+3VS +3VS_3G

EL1

21

70Ohm/100Mhz

/3G_DTV

3GLAN_OFF#

32

3

WQ1

D

2N7002

S

GND

2

/3G_DTV

1

G

3GLAN_OFF 14

2

A A

5

4

3

12

WC12

10UF/10V

1025

12

+

/X

GNDGND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

12

WC11 47UF/6.3V

/3G_DTV

33PF/50V

/3G_DTV

GND GND GND

900SD_MB

EC108

12

EC109 22PF/50V

/3G_DTV

Title :

Engineer:

1

12

EC107

10UF/10V

/X

3G Module

Hauld Zhou

Rev

24 51Monday, November 10, 2008

R1.0G

of

5

D D

R203 0Ohm

PCIE_WAKE#14,24,26

C C

CLK_PCIE_MINICARD CLK_PCIE_MINICARD#

C22 10PF/50V C24 10PF/50V

1 2

CLKREQ#_MINICARD6

CLK_PCIE_MINICARD#6 CLK_PCIE_MINICARD6

PCIE_RXN315 PCIE_RXP315

PCIE_TXN315 PCIE_TXP315

12

/X

12

/X

GND

/X

PCIE_WAKE#_R

4

WLAN

1

WAKE#

3

Reserved1

5

Reserved2

7

CLKREQ#

9

GND1

11

REFCLK-

13

REFCLK+

15

GND2

17

Reserved/UIM_C8

19

Reserved/UIM_C4

21

GND3

23

PERn0

25

PERp0

27

GND4

29

GND5

31

PETn0

33

PETp0

35

GND6

37

Reserved3

39

Reserved4

41

Reserved5

43

Reserved6

45

Reserved7

47

Reserved8

49

Reserved9

51

Reserved10

53

GND13

54

GND14

MINI_PCI_LATCH_52P

3

http://hobi-elektronika.net

+3VS_MiniCard

3.3V_1 GND7

1.5V_1

UIM_PWR

UIM_DATA

UIM_CLK

UIM_RESET

UIM_VPP

GND8

W_DISABLE#

PERST#

+3.3Vaux

GND9

1.5V_2

SMB_CLK

SMB_DATA

GND10

USB_D-

USB_D+

GND11

LED_WWAN#

LED_WLAN#

LED_WPAN#

1.5V_3

GND12

3.3V_2

NP_NC2 NP_NC1

GNDGND

+1.5VS_MiniCard

+3VAUX_WLAN

R227 0Ohm

R228 0Ohm R229 0Ohm

LED_WLAN#

SMB_CLK SMB_DATA

1 2

1 2 1 2

1

C25 10PF/50V C26 10PF/50V

WLAN_RST#

For RF Advise

T144TPC26T

12

/X

12

/X

GND

2 4 6 8 10 12 14 16

18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50 52

56 55

250 mA

+3VAUX_WLAN

12

SMB_CLK 7,15 SMB_DATA 7,15

12

R209

4.7KOhm

1%

R221 0Ohm

MRST#

12

C209

2.2UF/16V

c0603

GND GNDGND

R12 0Ohm

1 2

/X

r0603_h24

R11 0Ohm

1 2

12

C23

0.1UF/16V

r0603_h24

C140 1UF/16V

GND

MINICARD_EN14

Low : Disable Minicard Power High-Z : Enable Minicard Power

1 2

WU2

5

RST/OUT

CD

VCC/VDD

RN5VD27CA

/X

2

GNDNC

12

C15 10uF/10V

/X

+3VS_MiniCard

N/A

1

+3VS_MiniCard

2 34

GND

R210 200Ohm /X

1 2

PLT_RST#9,14,24,26

+3VSUS

12

C16

0.1UF/16V

/X

R211 10KOhm

+3VSUS

PMBS3904

/X

+3VS_MiniCard

12

C17

0.1UF/16V

PRN500C 100KOhm

5 6

Q58

1

+3VS_MiniCard+3VS_MiniCard

12

C208

0.1UF/16V

/X

GND

WLAN_RST#

12

3

C

B

1

E 2

1 2

AP2307GN

/X

Q61

1

750 mA

D

3

1

G

GND

G

1

MINICard_SWGATE_15MIL

12

32

3

D

S

2

C210

0.1UF/16V

/X

R225 0Ohm

r0603_h24 /X

S

23

2

PRN500A

1 2

100KOhm

C211

1 2

0.1UF/16V

R212

10KOhm

1%

Q62

2N7002

+3VS

12

C19

0.1UF/16V

/X

375 mA

12

C20

0.1UF/16V

/X

GND

MINICARD_EN

R226

0Ohm

r0603_h24

Default

D

S

/X

23

2

3

G

Q63

1

AP2307GN

1

/X

0627

PRN500D

7 8

MINI_SW_GATE_15MIL_1.5V

100KOhm

C212

1 2

0.1UF/16V

/X

R213 10KOhm

/X

1 2 32

3

D

Q64

1

2N7002

1

G

/X

S

2

GND

+3VSUS

3 4

PRN500B

100KOhm

1 2

12

C21

0.1UF/16V

/X

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

+1.5VS

WLAN

Kell_Huang

25 51Monday, November 10, 2008

+1.5VS

of

Rev

R1.0G

+1.5VS_MiniCard

PLT_RST#

B B

H1

U5F-M-EXPREE

H2

U5F-M-EXPREE

GNDGND GND

12

C27

0.1UF/16V

/X

12

C18 10uF/10V

/X

MINI CARD NUT(1.6mm) *2

A A

5

4

3

2

5

4

3

2

1

http://hobi-elektronika.net

+3VSUS

D D

C C

B B

A A

12

LC2 10uF/10V

c0805

12

10uF/10V

c0805

+1.2VSUS_LAN

LAN_+1.2VSUS_CTR

12

LC29

10uF/10V

c0805

/X/AR8113

GND

+1.2VSUS_LAN

If not overclocking, LL3.LC32.LC24 stuffed and LL4,LC22,LC23 removed. If overclocking LL3.LC32.LC24 Removed . LL4,LC22,LC23 stuffed

12

LC37

1UF/16V

c0603

/X/AR8113

LC34

GND

1 2

0Ohm

12

LR11

0Ohm

/X/AR8113 r0603_h24

1 2

1.1G

12

LC30

0.1UF/16V

/X/AR8113

1 2

LR19

5

12

LC1

0.1UF/16V

GND

LC31

0.1UF/16V

LR5

1 2

330Ohm

LR18

0Ohm

12

LC33

0.1UF/16V

+1.2VSUS_LAN

12

LC11

0.1UF/16V

LR4

10KOhm

1 2

LAN_1.2VG

LL4

120Ohm/100Mhz

/X/AR8113

l0603

1%

MW772M3L

LAN_DVDDL

GND

21

12

+3VSUS

B

1

12

LC17

0.1UF/16V

12

LC3

0.1UF/16V

LC12

0.1UF/16V

3 E

LQ1

C 2

LC22 1UF/16V

c0603

/X/AR8113

L_AVDDLVCO2

12

LC6

0.1UF/16V

GND

12

LC38 10UF/6.3V

/X

12

LC18

0.1UF/16V

L_AVDDLVCO1

12

GND

+2.5VSUS_LAN

12

LC4

0.1UF/16V

12

GND

+1.2VSUS_LAN

12

LC8 1UF/16V

c0603

GNDGND

LC14

0.1UF/16V

LC13

0.1UF/16V

For RF Advise

12

LC19

0.1UF/16V

/X/AR8113

To pin11

12

LC23 1000PF/16V

/X/AR8113

To pin42

12

GND

LC32

LC24

0.1UF/16V

/X

12

LC5 10uF/10V

c0805

GND

0.22UF/10V

/AR8113

4

LX1_XTALIN

AR8113 internal integrated 1.8V(PIN1) and 2.5V(PIN6) regulator!

PLT_RST#9,14,24,25

PCIE_WAKE#14,24,25

+2.5VSUS_LAN

LR9 10MOhm /X/AR8113

1 2

LX1

12

25Mhz

12

LC15 27PF/50V

GND

+3VSUS

LR1

4.7KOhm

/X/AR8113

LR20 0Ohm

1 2

12

LC9

1UF/16V

c0603

1000PF/50V

GND

1 2

LC10

X7R

LX1_XTALOUT

12

LC16 27PF/50V

12

1 2

GND

+1.2VSUS_LAN

L_MDI_0+27 L_MDI_0-27

L_MDI_1+27 L_MDI_1-27

GND

3

1 2 3 4

+L_1.8VSUS

12

LC7 1UF/16V

GND

+3VSUS

LAN_+1.2VSUS_CTR

LAN_VBG1P18

LX1_XTALOUT

LX1_XTALIN L_AVDDLVCO1

LAN_RBIAS

LR8

2.37KOHM 1%

LC20

0.1UF/16V

LAN_MDI_0_R

12

LC21

LAN_MDI_1_R

12

0.1UF/16V

Close to LU1

LU2

8

A0

VCC

7

A1

WP

6

A2

SCL

5

GND

SDA

AT24C08BN-SH-T

LR3 10KOhm

1%

GND

LU1

1

VDD18O

2

VDD3

3

RESET_L

4

WAKE_L

5

VDDLO

6

VDDHO

7

VBG1P18

8

AVDD1

9

XTLO

10

XTLI

11

AVDD_REG

12

RBIAS

AR8113-AL1E

LR10 49.9Ohm 1%

1 2

LR12 49.9Ohm 1%

1 2

LR13 49.9Ohm 1%

1 2

LR14 49.9Ohm 1%

1 2

12

LT1

+3VSUS

LRN3A

10KOhm

GNDGND

LAN_DVDDL

1

LED_10_100

GND

LED_10_100_L

TRXP0

1314151617181920212223

1 2

LAN_LED_ACT

RX_N

VDDL2

VDDL3

LED_ACT_L

TRXN0

DVDD1

AVDD2

TRXP1

10KOhm

3 4

C_PCIE_L2_C

L_AVDDLVCO2

RX_P

AVDD6

TRXN1

DVDD2

LRN3B

LAN_EECLK LAN_EEDATA

C_PCIE_L2#_C

X_L1X1_RXP_C

X_L1X1_RXN_C

37383940414243444546474849

TX_P

TX_N

AVDD5

REFCLKP

REFCLKN

TEST_RST_L

TESTMODE

TWSI_DATA

TWSI_CLK

LED_DUPLEX_L

CLKREQN

NC1

NC2

AVDD3

NC3

NC4

24

L_MDI_0+

L_MDI_0-

L_MDI_1+

L_MDI_1-

2

AVDD4

SMDATA

VDDL4 SMCLK

VDDL1

DVDD3

LRN3C

10KOhm

L1CX1 0.1UF/16V

36 35 34 33 32 31 30 29 28 27 26 25

56

X_L1X1_TXN 15 X_L1X1_TXP 15

12

L1CX2 0.1UF/16V

12

L1CX3 0.1UF/16V

12

L1CX4 0.1UF/16V

12

LAN_EEDATA LAN_EECLK

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

C_PCIE_LAN 6

C_PCIE_LAN# 6

X_L1X1_RXP 15

X_L1X1_RXN 15

+1.2VSUS_LAN

GND

LAN_SMB_DATA

LAN_DVDDL

C_REQ#_LAN 6

+2.5VSUS_LAN

PIN26:CLKREQn for next generation. AR8113-AL1E no have this function . is NC PIN!

900SD_MB

Title :

Engineer:

1

+3VSUS

LRN3D

7 8

LAN_8113

Hauld_Zhou

26 51Monday, November 10, 2008

10KOhm

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

D D

C C

B B

A A

DELETE MODEM

+L_1.8VSUS

LR15

0Ohm

1 2

r0603_h24

LAN_1.8VSUS_RDCT

LC25

0.1UF/16V

c0603 /X/AR8113

12

GND

12

LC26

0.1UF/16V

U9

L_MDI_1+26 L_MDI_1-26

L_MDI_0+26 L_MDI_0-26

1

RD+

2

RD-

3

RDCT

6

PTCT/TDCT

7

TD+

8

TD-

4

NC1

5

NC2

LFE8423

RX+

RXCT

TXCT

TX+

NC3 NC4

LAN_RXP

16

LAN_RXN

15

RX-

LAN_RXCT

14

LAN_TXCT

11

LAN_TXP

10

LAN_TXN FGND

9

TX-

12 13

1 2 1 2

1000PF/2KV

c1206_h75

/X/AR8113

LC27

LR1675OHM 1%

LR1775OHM 1%

12

GND

LC28 1500PF/50V

LR2 0Ohm

/X/AR8113 r0603_h24

1 2

FGND

LR675OHM 1%

1 2

LR775OHM 1%

LAN_CON78 LAN_RXN

LAN_CON45 LAN_RXP

LAN_TXN LAN_TXP

LAN

8

P_GND2

7

NP_NC2

6

5

4

3

2

NP_NC1

2

1

P_GND1

1

MODULAR_JACK_8P

10 12

11 9

GND

Default Group-A7V8X MX

1

RJ45

Hauld_Zhou

27 51Monday, November 10, 2008

Rev

R1.0G

of

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

A

SC64 0.01UF/16V

S_SATA_TXP015 S_SATA_TXN015 S_SATA_RXN015 S_SATA_RXP015

+1.8V_FLASH +1.8V_FLASH

+3V_FLASH

D D

FU1

DV18_7

E6

DV18_8

A10

DV18_9

H9

GND1

G9

GND2

G8

GND3

G7

GND4

F9

GND5

F8

GND6

F7

GND7

B10

T196 TPC26T

F_GPIO2

1

F_GPIO3

T197

1

F_GPIO4

TPC26T

F_GPIO5

C C

T198 TPC26T

F_RST# FLASH_LED

1

GND

B B

A6 B6 B7 B8 B9 C7 C8 C9 A9 A8 A7

K11

H10

D9 B5

C5 C6 D8 D6 D7

F2_D0 F2_D1 F2_D2 F2_D3 F2_D4 F2_D5 F2_D6 F2_D7

F2_ALE F2_CLE F2_WE# F2_RE#

GND8 GPIO0 GPIO1 GPIO2/UAI GPIO3/UAO GPIO4/Load USB GPIO5/Load Flash GPIO6 GPIO7 GPIO8 GPIO9 GPIO10 GPIO12 GPIO14 TMEn MODE0 MODE1 MODE2 MODE3 RSTn HDDA PHYRDY

JMF601B

1 2

SC65 0.01UF/16V

1 2

FC1 0.01UF/16V

1 2

FC2 0.01UF/16V

E8

DV18_1

E9

DV18_2

E10

DV18_3

F6

DV18_4

G10

G11

DV18_5

1 2

DV18_6

G6A5G5

F5E7C10

PV33_2

PV33_1

TPC26T

H6

PV33_4

PV33_3

T195

D5

E5

PV33_5

PV33_6

H7

H8

PV33_7

PV33_8

1

L_SATA_RXN0

L_SATA_RXP0

REG_CTRL

D10

C12

PV33_9

ASTXP0

REG_CTRL

Flash Ch2 Flash Ch0

F2REn

BK8n

BK9n

BK10n

BK11n

F2CLE

F2ALE

F2WEn

F2_D7

F2_D6

F2_D5

F2_D4

F2_D3

F2_D2

F2_D1

F2_D0

A4C4B3C3B4

C2A3C1

E2

D1D2D3D4E3E1E4

D12

F11

ASTXN0

SATA

F0_D0

J2

ASG18_2

F0_D1

L_SATA_TXP0

L_SATA_TXN0

E12

D11

B12

ASV18

ASRXN0

ASG18_1

F0_D4

F0_D3

F0_D2

F10

F12

ASRXP0

ASREXT0

F0_D6

F0_D5

4

E11

ASG33

F0_D7

G3H3H2H1J1K2K1

G12

ASV33

F0ALE

H12

XTALO

F0CLE

H4G2G4

3

http://hobi-elektronika.net

F_REXT F_XTALOUT F_XTALIN

J12

K12

J11

H11

XTALI

AVDDH

AGNDH1

AGNDH2

USB

Flash Ch1 Flash Ch3

F0REn

BK0n

BK1n

F0WEn

F4F3F2G1F1

L12

DP

BK2n

L11

M6

DM

BK3n

F_VBUS

VBUS

BK15n BK14n BK13n BK12n F3REn

F3WEn

F3CLE F3ALE F3_D7 F3_D6 F3_D5 F3_D4 F3_D3 F3_D2 F3_D1 F3_D0

BK7n BK6n BK5n BK4n

F1REn

F1WEn

F1CLE F1ALE F1_D7 F1_D6 F1_D5 F1_D4 F1_D3 F1_D2 F1_D1 F1_D0

K10 J10 J9 J8 M7 L10 M10 M9 L9 K9 K8 J7 K7 L8 M8 L7 J5 L6 H5 K6 J6 J3 K5 J4 K4 K3 L5 M5 M4 L4 M3 L3

F_BK#3 F_BK#2 F_BK#1 F_BK#0

F0_RE# F0_WE# F0_CLE F0_ALE

F0_D7 F0_D6 F0_D5 F0_D4 F0_D3 F0_D2 F0_D1 F0_D0

+3V_FLASH

F3_RE# F3_WE# F3_CLE F3_ALE F3_D7 F3_D6 F3_D5 F3_D4 F3_D3 F3_D2 F3_D1 F3_D0

F1_RE# F1_WE# F1_CLE F1_ALE F1_D7 F1_D6 F1_D5 F1_D4 F1_D3 F1_D2 F1_D1 F1_D0

GND

F_VBUS

FR3 4.7KOhm /X

F_GPIO5 F_GPIO4

FR4 4.7KOhm

F_GPIO5

FR34 4.7KOhm1%

F_GPIO4

FR35 4.7KOhm

FR36

100KOHM

1 2 1 2

1%

F0_D[7:0] 29 F1_D[7:0] 29 F2_D[7:0] 29 F3_D[7:0] 29

F0_WE# 29 F0_RE# 29 F0_CLE 29 F0_ALE 29

F1_WE# 29 F1_RE# 29 F1_CLE 29 F1_ALE 29

F2_WE# 29 F2_RE# 29 F2_CLE 29 F2_ALE 29

F3_WE# 29 F3_RE# 29 F3_CLE 29 F3_ALE 29

F_BK#0 29 F_BK#1 29 F_BK#2 29 F_BK#3 29

FLASH_LED 40

12

/X

12 12

GND

+3V_FLASH

GPIO5 GPIO4

L

GND

2

+3V_FLASH

12

FC7 10uF/10V

/X

GND

+1.8V_FLASH

12

FC15 10uF/10V

/X

GND

+3VS

FR1

1 2

12

FC19

0Ohm

r0603_h24

10uF/10V

/X

GND

+1.8V_HD +1.8V_FLASH

FR2

1 2

12

FC4

0Ohm

r0603_h24

10uF/10V

/X

GND

MODE

L Load F/W code from Flash,

SATA I mode

Load F/W code from SATAH

H

FC8

0.1UF/16V

FC16

0.1UF/16V

12

FC9

0.1UF/16V

12

FC17

0.1UF/16V

+3V_FLASH

12

FC20 10uF/10V

/X

GND

12

FC11 10uF/10V

/X

GND

12

FC10

0.1UF/16V

12

FC18

0.1UF/16V

12

FC5

0.1UF/16V

12

FC12

0.1UF/16V

1

RESET

+3V_FLASH

FR7,FC21 close to

FR6

100KOHM

1 2

F_RST#

12

FC24 1UF/16V

5

FU1

F_REXT

12

FR7

FC21

12KOhm

1 2

22PF/25V

4

FR5 1MOhm

1 2

FX1 30Mhz

F_XTALOUT

1 3

12

FC22 18PF/50V

F_XTALIN

12

2

4

GNDGNDGND GNDGND

3

FC23 18PF/50V

Default Group-A7V8X MX

Title :

ASUSTek COMPUTER INC

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

2

Flash_ctrl_JMF601

Fehling_wang

1

Rev

28 51Monday, November 10, 2008

R1.0G

of

A

5

A

F0_D[7:0] 28 F1_D[7:0] 28 F2_D[7:0] 28 F3_D[7:0] 28

D D

4

3

http://hobi-elektronika.net

F0_WE# 28 F0_RE# 28

F0_ALE 28 F1_CLE 28

F1_ALE 28 F1_WE# 28 F1_RE# 28

F2_WE# 28 F2_RE# 28 F2_CLE 28F0_CLE 28 F2_ALE 28

F3_WE# 28 F3_RE# 28 F3_CLE 28 F3_ALE 28

F_BK#0 28 F_BK#1 28 F_BK#2 28 F_BK#3 28

F_RB#3 F_RB#2 F_RB#1 F_RB#0

2

1 2

4.7KOhm

3 4

4.7KOhm

5 6

4.7KOhm

7 8

4.7KOhm

FRN1A FRN1B FRN1C FRN1D

+3V_FLASH

/X /X /X /X

F0_WP# F3_WE# F0_WE# F3_WP#

F2_WP# F2_WE# F1_WE# F1_WP#

1

7 8

4.7KOhm

7 8

4.7KOhm

5 6

4.7KOhm

3 4

4.7KOhm

3 4

4.7KOhm

1 2

4.7KOhm

1 2

4.7KOhm

5 6

4.7KOhm

FRN3D FRN2D FRN3C FRN3B

FRN2B FRN2A FRN3A FRN2C

+3V_FLASH

F_RB#3 F_RB#2

F_RB#1

F_RB#0 F2_RE# F_BK#0 F_BK#1

F_BK#2

F_BK#3 F2_CLE F2_ALE F2_WE# F2_WP#

F_RB#3

F_RB#2

F_RB#1 F_RB#0 F3_RE# F_BK#0 F_BK#1

F_BK#2 F_BK#3

F3_CLE F3_ALE F3_WE# F3_WP#

12

+3V_FLASH

FC28

0.1UF/16V

/X

FC36

0.1UF/16V

/X

FU3

1

NC0

2

NC1

3

NC2

4

NC3

5

NC4

6

NC5

7

R/B#

8

RE#

9

CE#

10

NC6

11

NC7

12

Vcc0

13

Vss0

14

NC8

15

NC9

16

CLE

17

ALE

18

WE#

19

WP#

20

NC10

21

NC11

22

NC12

23

NC13

24 25

NC14 NC15

K9GAG08U0M-PCB0

FU7

1

NC0

2

NC1

3

NC2

4

NC3

5

NC4

6

NC5

7

R/B#

8

RE#

9

CE#

10

NC6

11

NC7

12

Vcc0

13

Vss0

14

NC8

15

NC9

16

CLE

17

ALE

18

WE#

19

WP#

20

NC10

21

NC11

22

NC12

23

NC13

24 25

NC14 NC15

K9GAG08U0M-PCB0

GND GND

1-31-1

1-4

3

NC28 NC27 NC26 NC25

I/O7 I/O6 I/O5

I/O4 NC24 NC23 NC22

Vcc1

Vss1 NC21 NC20 NC19

I/O3 I/O2 I/O1

I/O0 NC18 NC17 NC16

NC28 NC27 NC26 NC25

I/O7

I/O6

I/O5

I/O4 NC24 NC23 NC22

Vcc1

Vss1 NC21 NC20 NC19

I/O3 I/O2 I/O1

I/O0 NC18 NC17 NC16

48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26

GNDGND

F2_D7 F2_D6 F2_D5 F2_D4

PSL#2 PRE2

F2_D3 F2_D2 F2_D1 F2_D0

+3V_FLASH

F3_D7 F3_D6 F3_D5 F3_D4

PSL#3 PRE3

F3_D3 F3_D2 F3_D1 F3_D0

1 2

FR19 0Ohm

/TOSH

FR23 0Ohm

/TOSH

FR27 0Ohm

/TOSH

FR31 0Ohm

/TOSH

Default Group-A7V8X MX

Title :

On Board NAND Flash

1

Fehling_wang

29 51Monday, November 10, 2008

of

Rev

R1.0G

ASUSTek COMPUTER INC

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

2

+3V_FLASH +3V_FLASH

F_RB#3

F_RB#2 F_RB#1 F_RB#0 F0_RE# F_BK#0 F_BK#1

F_BK#2

F_BK#3 F0_CLE F0_ALE

C C

F0_WE# F0_WP#

+3V_FLASH

F_RB#3

F_RB#2 F_RB#1 F_RB#0 F1_RE# F_BK#0 F_BK#1

B B

F_BK#2

F_BK#3 F1_CLE F1_ALE F1_WE# F1_WP#

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

GND

1

2

3

4

5

6

7

8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

+3V_FLASH

12

FC25

0.1UF/16V

/X

GND +3V_FLASH

FC33

12

0.1UF/16V

/X

GND

FU2

NC0

NC28

NC1

NC27

NC2

NC26

NC3

NC25

NC4

I/O7

NC5

I/O6

R/B#

I/O5

RE#

I/O4

CE#

NC24

NC6

NC23

NC7

NC22

Vcc0

Vcc1

Vss0

Vss1

NC8

NC21

NC9

NC20

CLE

NC19

ALE

I/O3

WE#

I/O2

WP#

I/O1

NC10

I/O0

NC11

NC18

NC12

NC17

NC13

NC16

NC14 NC15

K9GAG08U0M-PCB0

1-2

FU6

NC0

NC28

NC1

NC27

NC2

NC26

NC3

NC25

NC4

I/O7

NC5

I/O6

R/B#

I/O5

RE#

I/O4

CE#

NC24

NC6

NC23

NC7

NC22

Vcc0

Vcc1

Vss0

Vss1

NC8

NC21

NC9

NC20

CLE

NC19

ALE

I/O3

WE#

I/O2

WP#

I/O1

NC10

I/O0

NC11

NC18

NC12

NC17

NC13

NC16

NC14 NC15

K9GAG08U0M-PCB0

12

FC26

0.1UF/16V

/X

12

FC34

0.1UF/16V

/X

5

+3V_FLASH

48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26

GND

+3V_FLASH

48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26

GNDGND

F0_D7 F0_D6 F0_D5 F0_D4

PSL#0 PRE0

F0_D3 F0_D2 F0_D1 F0_D0

F1_D7 F1_D6 F1_D5 F1_D4

PSL#1 PRE1

F1_D3 F1_D2 F1_D1 F1_D0

1 2

FR18 0Ohm

/TOSH

FR22 0Ohm

/TOSH

FR26 0Ohm

/TOSH

FR30 0Ohm

/TOSH

+3V_FLASH

12

FC27

0.1UF/16V

/X

GND +3V_FLASH

12

FC35

0.1UF/16V

/X

GND

4

A

5

4

3

2

1

http://hobi-elektronika.net

D D

+5V_USB +5VSUS_USB12

U_USB1+15 U_USB1-15

U_USB2+15

C C

B B

A A

U_USB2-15 U_USB3+15

U_USB3-15

+5VSUS_USB34_CON

5

U_USB3-

4

+5VSUS_USB12_CON

2 1

BAV99W_L

/X

2 1

BAV99W_L

/X

GND

D9

5

6

IP4220CZ6

/X

D10

D11

3

U_USB1+

U_USB1-

34

2

1

U_USB2-U_USB2+

GND

U_USB3+

3

USB_OC#0115

USB_OC#2315

F2

1 2

1.5A/6V

F3

1 2

1.5A/6V

70Ohm/100Mhz

12

R17

4.7KOhm

1%

R19

10KOhm

1%

1 2

GND

+5VSUS_USB34 +5VSUS_USB34_CON+5V_USB

70Ohm/100Mhz

12

R23

4.7KOhm

1%

R25

10KOhm

1%

1 2

GND

L10

L12

+5VSUS_USB12_CON

21

c3528

+5VSUS_USB34_CON

2

12

GND

12

GND

12

GND

+

CE2 47UF/6.3V

+

CE3 100UF/6.3V

+

CE4 47UF/6.3V

USB2

P_GND2

1

U_USB1-

12

U_USB1+

C34

0.1UF/16V

U_USB2U_USB2+

C35

0.1UF/16V

U_USB3U_USB3+

C36

0.1UF/16V

Default Group-A7V8X MX

GND

1

2

3

4 5

4GND1

P_GND1

USB_CON_1X4P

USB3

P_GND2

1

GND2

2

3

4 5

4 GND1

P_GND1

USB_CON_1X4P

USB4

P_GND2

1

2

3

4 5

4GND1

P_GND1

USB_CON_1X4P

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

GND2

1

8 6

7

8 6

7

GNDGND

8 6

7

USB Port

Kell_Huang

GND

30 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

D D

+3VS_SD

CLK_48M_CR6

RR8 0Ohm

1 2

/X/AU6336

GND

C C

VCC18

RC1

0.1UF/16V

12

PIN 27: 1: 48MHZ FROM PIN25(Default) 0: 12MHZ FROM PIN6

SDCLK SDDATA0

SDCLK SDCLK_R

RR5 0Ohm

1 2

RR6

100KOHM

/X/AU6336

1 2

12

RC8 10PF/50V

/X/AU6336

+3VS_SD

12

RC9 1UF/16V

c0603

SDDATA2 SDDATA3 SDCMD

SDDATA0 SDDATA1

GND

9 1 2 3 4 5 6 7 8

CARD_READER

9 1 2 3 4 5 6 7 8

SD_SOCKET_9P

P_GND2 P_GND1

14 13 12

12

11

10

GND

SDWP# SDCD#

GND

12

RC10 10PF/50V

/X/AU6336

GND

RR1

1 2

12

RC11 10PF/50V

/X/AU6336

100KOHM

/X/AU6336

+3VS_CR

R_REXT

U_CARD+15 U_CARD-15

12

RR2

330Ohm

1%

B B

A A

GND

5

GND

12

CY1 CY2

RC2 1UF/16V

c0603

GND

RU1

1

REXT

2

VD33P

3

DP

4

DM

5

VS33P

6

XI

7

XO

+3VS_CR

12

RC12

0.1UF/16V

GND

29

GND

VDD

SDCLK

CLKSEL

EXTCLK

SDDATA0

VDDU

VDDHM

TRIST

SDDATA7

SDDATA6

891011121314

12

RC3 1UF/16V

c0603

GND

22232425262728

SDDATA3

SDDATA4

SDDATA5

SDDATA2 SDDATA1

SD_V33

SDCDN

VDD33C

12

RC4

4.7UF/6.3V

/X/AU6336

c0603

4

21 20

CLED

19 18

SDWP

17 16

SDCMD

15

AU6336-C52-MIF

+3VS_CR

12

GND

RC13

0.1UF/16V

SDDATA3 SDDATA2

SDWP# SDDATA1 SDCMD

SDCD#

+3VS_SD

CARD_READER_EN#14

GND

/X/AU6336

RR4 1MOhm

CY1 CY2

1 2

12

RC6 18PF/50V

/X/AU6336

3

RX1

12Mhz

/X/AU6336

RR3

1 2

10KOhm

1%

RC

12

GNDGND

GND

RC7 18PF/50V

/X/AU6336

0.1UF/16V

RQ1GATE

RC5

+3VS

GND

12

RQ1

2 3

S

2

1

D

3

AP2301GN

G

2

+3VS_CR

1

RT2

RT1

1

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

Card Reader_AU6336

Hauld_Zhou

1

Rev

31 51Monday, November 10, 2008

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

D D

R55 0Ohm

1 2

U_CAM+15

U_CAM-15

C C

R56 0Ohm

1 2

/CAMERA

USBPP7

L21 90Ohm/100Mhz

/CAMERA/X

1 4

2 3

USBPN7

/CAMERA

+5VS

R204 100KOHM

1 2

C207

0.1UF/16V

/CAMERA

R224 0Ohm /X

1 2

Q59 AP2307GN /CAMERA

2 3

S

2

/CAMERA

Q60

2N7002

/CAMERA

D

S

GND

G

1

1 2 32

3

2

D

3

R206

10KOhm

1%

/CAMERA

1

G

L22

21

120Ohm/100Mhz

/CAMERA

+5VS_CAMERA

12

C57 10uF/10V

/CAMERA

GND

CAMERA_EN 14

12

C58

0.1UF/16V

/CAMERA

CAMERA

1 5

USBPN7 USBPP7

GND GND

USBPN7

USBPP7

1SIDE1

2

3

4

WtoB_CON_4P

/CAMERA

C219 10PF/50V

C220 10PF/50V

SIDE2

6

12

/X

12

/X

GND

For RF Advise

B B

A A

Default Group-A7V8X MX

1

Camera Conn

Kell_Huang

32 51Monday, November 10, 2008

of

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

Vout=0.8*(1+(49.9K/10.2K))

+5VS

12

APC10

D D

10UF/16V

/X/ALC269 c0805

C C

12

ACE1

+

100UF/6.3V

c7343d_h87 /X/ALC269

GND

B B

APU1

1

SHDN#

2

GND

3 4

IN OUT

APL5315BI-TRL

900SD R1.0G

GND

AL2

21

120Ohm/100Mhz

l0603

Place next to pin 39

SET

+5VS_PVDD+5VS

12

APC12

0.1UF/16V

5

10.2KOHM

P_5VASET

APR2

1%

r0603

APC1

1 2

1000PF/50V

/X/ALC269 X7R

1 2

APR1

49.9KOHM

1%

1 2

GND GND A_GND

Place next to pin 46

APC13 10uF/10V

c0805

12

APC14

0.1UF/16V

12

P_GND

12

APC11 1UF/16V

c0603 /X/ALC269

4

http://hobi-elektronika.net

12

10uF/10V

c0805

12

APC6

+

ACE2 47UF/6.3V

c3528 /X

APT1 TPC26T

1

12

+5V_A

12

APC15 10UF/16V

/X/ALC269 c0805 X5R

Surges of PVDD >7V duration 0.1ms when class D amplifier is working may damage the amplifier, 10uF tantalum capacitors are required at PVDD1 and PVDD2 to uppress the surge.

12

APC7

0.1UF/16V

/X/ALC269

APC8 10UF/16V

/X/ALC269 X5R c0805

Place next to pin 38

A_Z_SDOUT14 A_Z_BITCLK14 A_Z_SDIN014 A_Z_SYNC14 A_Z_RST#14

H L

A_OP_SD#36

12

APC9

0.1UF/16V

speaker AMP.A_PD#

power down power up

A_Z_RST#

3

AC5

0.1UF/16V

12

AC6 10UF/16V

c0805 X5R /X/ALC269

12

Place next to pin 25

+3VS_DVDD

A_PD#

AR133Ohm

1 2

AD1

GND

12

EC167

0.1UF/16V

/ALC269

3

BAT54AW

sot323

12

GND

A_JD_HP34 A_JD_MIC134

A_PD#

A_Z_SDIN0_R

A_PCBEEP

1

APT2 TPC26T

AC33 22PF/25V

/X/ALC269

P_GND

AU1A

1

DVDD

2

GPIO0/DMIC_DATA

3

GPIO1/DMIC_CLK

4

PD#

5

SDATA_OUT

6

BCLK

7

DVSS

8

SDATA_IN

9

DVDD_IO

10

SYNC

11

RESET#

12

PCBEEP

ALC269Q-GR

AR7 39.2KOhm 1%

1 2 1 2

AR8 20KOHM 1%

2

+5VS_PVDD

4847464544434241403938

49

GND

PVSS2

PVSS1

PVDD2

SPDIFO

SPK_OUT_R-

SPK_OUT_R+

EAPD/SPDIFO2

SenseA

LINE2_L

LINE2_R

MIC2_L

MIC2_R

SenseB

JDREF

1314151617181920212223

A_JDREF

A_SENSEA

AR5 20KOHM

1%

1 2

A_GND

37

AVSS2

PVDD1

AVDD2

SPK_OUT_L-

SPK_OUT_L+

MONO_OUT

MIC1_L

MIC1_R

LINE1_L

LINE1_R

24

+5VS_PVDD +5V_A

A_GND

CBP CBN

CPVEE

HPOUT_R

HPOUT_L

CPVREF

MIC1_VREFO_R

MIC2_VREFO

MIC1_VREFO_L

VREF

AVSS1

AVDD1

A_MIC1_R 34 A_MIC1_L 34

A_MIC2AMP_R 35 A_MIC2AMP_L 35

A_SPK_R+_R 34 A_SPK_R-_R 34 A_SPK_L-_R 34 A_SPK_L+_R 34

A_CBP

36

A_CBN

35

A_CPVEE

34 33 32 31 30 29 28 27 26 25

AC106 1UF/16V AC107 1UF/16V

AC108

1 2

12

1 2 1 2

1UF/16V

/3.5G/X

AC1

2.2UF/16V

c0805 X7R

A_VREF

AC2

2.2UF/16V

c0805 X7R

+5V_A

/3.5G/X /3.5G/X

1

A_HP_R 34 A_HP_L 34

A_BIAS_MIC1_R 34 A_BIAS_MIC2 35 A_BIAS_MIC1_L 34

12

AC3

0.1UF/16V

12

A_GND

AC4 10UF/16V

c0805 X5R /X/ALC269

Place next to pin 27

3G_R_A 24

3G_MIC 24,34

R1.0G

AU1B

50

GND1

51

GND2

52

47

463948

1

+3VS

AL1

120Ohm/100Mhz

l0603

A A

+3VS_DVDD

21

12

APC2

0.1UF/16V

Place next to pin 1

5

12

GND

APC3 10uF/10V

c0805

/X/ALC269

12

APC4

0.1UF/16V

12

APC5 10UF/16V

/X/ALC269 c0805 X5R

Place next to pin 9

4

3

Digital plane 2 3 power

10 11 12

Analog

14

15

13

plane

22

38

37

36 35 34

27 26 25

Default Group-A7V8X MX

24

23

2

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

P_GND

Engineer:

53 54 55 56 57 58

Title :

1

GND3 GND4 GND5 GND6 GND7 GND8 GND9

ALC269Q-GR

ALC269-1

Jeff_Li

33 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

MIC1

http://hobi-elektronika.net

Internal MIC

D D

MIC

4

SIDE2

2

1

3

SIDE1

WTOB_CON_2P

A_MIC2_L_D

GND

AL5 120Ohm/100Mhz

12

AC8 100PF/50V

/X/ALC269/EMI

21

l0603

A_MIC2_L_C 35

Stereo MIC mount 100PF C

GND

For Layout

C C

SPEAKER

Demodulation Filter Placement near Audio Codec

A_SPK_L+_R33

A_SPK_L-_R33 A_SPK_R+_R33

A_SPK_R-_R33

AR108

1 2

0Ohm

r0603_h24

AR109 0Ohm r0603_h24

1 2 1 2

AR110 0Ohm

r0603_h24

AR111

1 2

0Ohm

r0603_h24

A_SPK_L+

A_SPK_L-

P_GND

AC102 2200PF/50V

1 2

/X/ALC269/EMI

AC104 2200PF/50V

1 2

/X/ALC269/EMI

A_SPK_L+

12

AC9 2200PF/50V

c0402 /ALC269/EMI

12

AC11 2200PF/50V

c0402 /ALC269/EMI

A_SPK_LA_SPK_R+

12

AC12 2200PF/50V

c0402 /ALC269/EMI

12

AC14 2200PF/50V

c0402 /ALC269/EMI

A_SPK_R-

AC103 2200PF/50V

A_SPK_R+

A_SPK_R-

GND GND

12

AC10

1UF/16V

/X/ALC269/EMI c0603

12

AC13

1UF/16V

/X/ALC269/EMI c0603

1 2

/X/ALC269/EMI

AC105 2200PF/50V

1 2

/X/ALC269/EMI

SPEAKER

4

SIDE2

3

2

1 5

1SIDE1

WtoB_CON_4P

6

GND

3

HP

/X/ALC269/EMI

A_JD_HP33

AR23

1 2

0Ohm

LINE_OUT

8

7

5

4

3

6

2

1

PHONE_JACK_6P

12

A_GND

12

A_JD_HP_LA_MIC1_R_R A_HP_R_L

A_HP_L_L

AC16 100PF/50V

/ALC269/EMI

Default Group-A7V8X MX

12

AC17 100PF/50V

/ALC269/EMI

A_GND

AR24, AR25 can use

0.1UF 11G233310432320 for EMI

AR17 75Ohm r0603_h24

A_HP_R33 A_HP_L33

1 2 1 2

AR18 75Ohm

r0603_h24

1 2

A_HP_R_RA_MIC1_L_C A_HP_L_R

AR24

0Ohm

A_GNDA_GND GND

AL7 120Ohm/100Mhz

21 21

AL8 120Ohm/100Mhz

l0603

100PF/50V

/ALC269/EMI

1 2

0Ohm

GND

l0603

AC15

AR25

Title :

ASUSTek Computer INC.

Size Project Name

A3

2

Date: Sheet

900SD_MB

Engineer:

Shell

1

NP_NC2 NP_NC1

10 9

ALC269-2(IO)

Jeff_Li

34 51Monday, November 10, 2008

of

Rev

R1.0G

A_JD_MIC133 A_BIAS_MIC1_L33 A_BIAS_MIC1_R33

AR20

AR19

1%

1 2

AR106 100KOHM

/3.5G/X

AR107 100KOHM

/3.5G/X

4.7KOhm

1%

AL10

AL11

120Ohm/100Mhz

l0603

100PF/50V

/ALC269/EMI

AC109 1UF/16V /3.5G/X

1 2

12

1 2

12

AC111 1UF/16V /3.5G/X

120Ohm/100Mhz

21

l0603

21

12

AC20

A_MIC1_L_C A_MIC1_R_C3G_MIC

A_JD_MIC1_L A_MIC1_R_LA_MIC1_R_C A_MIC1_L_LA_MIC1_L_R

12

AC21 100PF/50V

/ALC269/EMI

4

12

P_GND

AC22 100PF/50V

/ALC269/EMI

A_GND

AC18 4.7UF/16V

X5R

c0805

A_MIC1_R33

B B

A_MIC1_L33

A A

3G_MIC24,33

1 2 1 2

AC19

4.7UF/16V

c0805 X5R

4.7UF~10UF X5R or DIP

AC110

1 2

1UF/16V

/3.5G/X

4.7KOhm AR211KOhm

1 2 1 2

AR22 1KOhm

R1.0G

5

MIC_JACK

8

7

5

4

3

6

2

1

PHONE_JACK_6P

AR43 0Ohm /X/ALC269/EMI

1 2

AR44 0Ohm

1 2

AR6 0Ohm

1 2

NP_NC2 NP_NC1

Shell

GND

10 9

5

4

3

2

1

http://hobi-elektronika.net

D D

+5V_A

AC24 1UF/16V

/ALC269

c0603

X7R

AC25 1UF/16V

c0603

AR33

4.7KOhm

/358/ALC269

1 2

A_BIAS_MIC2_L_R

AR36 0Ohm

/358/ALC269

1 2

12

X7R

AC26 150PF/50V

AR30 47KOHM

1 2

/358/ALC269

A_MIC2_L

AR37

4.7KOhm

/X/ALC269

1 2

/358/ALC269

12

A_GND

AU2

1

VOUT1 VIN1-

VOUT2 VIN1+ GND VIN2+

LMV358IDR

/358/ALC269

VCC

VIN2-

2 3 4 5

AR101

560OHM

/BJT/ALC269

1 2

AQ1

3

1

12

B

AC101

1UF/16V

c0603 /BJT/ALC269

3

MMBT1815L

C

/X/BJT/ALC269

B

1

E

2

AR103

49.9Ohm

/BJT/ALC269

1 2

AR105

49.9Ohm

/BJT/ALC269

1 2

AQ2

PMBS3904

/BJT/ALC269

+5V_A

8 7 6

A_GND

AR100

1 2

AR104

1 2

100KOHM

/BJT/ALC269

AC100 1UF/16V

/BJT/ALC269 c0603

100KOHM

/BJT/ALC269

A_MIC2AMP_R33

A_MIC2AMP_L33

C C

+5V_A

AR29

4.7KOhm

/X/ALC269

1 2

A_MIC2_L_C34

B B

A_BIAS_MIC233

A_BIAS_MIC2

AC29 1UF/16V

/358/ALC269 c0603 X7R

1.1G

12

A_MIC2_L_R

12

AC31

0.1UF/16V

/X/ALC269

AC34

12

1UF/16V

c0603 /X/ALC269

AR35

4.7KOhm

/358/ALC269

1 2

A_BIAS_MIC2

12

AR102

4.7KOhm

1% /BJT/ALC269

A_MIC2_L_C

12

A_GNDA_GND

A A

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

ALC269-3(MIC AMP)

Jeff_Li

1

35 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

+3VA

12

KC1 10uF/10V

D D

C C

B B

GND

INT_SERIRQ14 LPC_FRAME#14,37 CLK_PCI_EC6

CHARGE0_LED#40

KSO[15:0]38

EC_PIN8138 EC_PIN8238

KSI[7:0]38

R1.0G

SMB2_CLK39

SMB2_DATA39

A A

CHARGE1_LED#40 PWR_LED_UP40

12

KC2

0.1UF/16V

/X

RC_IN#14 KBC_SCI#14 A20GATE14

PCI_RST#14

T200TPC26T T201TPC26T T202TPC26T T203TPC26T

TP_CLK38 TP_DATA38

EXTSMI#14

LID_EC#14,23

T175 TPC26T T105 TPC26T

PWR_SW#37 AC_OK45

BAT_IN45

T169 TPC26T

T111 TPC26T T103 TPC26T

5

12

KC3

0.1UF/16V

/X

LPC_AD[3:0] 14,37

LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3

EC_RST#

KSO0 KSO1 KSO2 KSO3 KSO4 KSO5 KSO6 KSO7 KSO8 KSO9 KSO10 KSO11 KSO12 KSO13 KSO14 KSO15

KSI0 KSI1 KSI2 KSI3 KSI4 KSI5 KSI6 KSI7

LCD_SCL

1

LCD_SDA

1

LCD_CSB

1

LVDD_EN

1

Thermal Sensor

NC_GPIO0C

1

DISTP_SW#

1

EC_RSMRST#

CLRTC_EC BATSEL_3S

1

PWR4G_SW#

1

INTERNET#

1

12

KC4

0.1UF/16V

SMB1_CLK SMB1_DATA

12

3

4 12 38 10

8

7

5

2 20

1 13

37

39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 81 82 55 56 57 58 59 60 61 62

36 91 93

83 84 85 86 87 88

77 78 79 80

6 14 15 16 17 18 19 32 73 74 75 76 89

90 92 95

121

KC6

KC5

0.1UF/16V

/X

U11

SERIRQ LFRAME# PCICLK GPIO1D/CLKRUN# LAD0 LAD1 LAD2 LAD3 GPIO01/KBRST# GPIO0E/SCI# GPIO00/GA20 GPIO05/PCIRST#

ECRST#

GPIO20/KSO0/TP_TEST GPIO21/KSO1/TP_PLL GPIO22/KSO2 GPIO23/KSO3/TP_ISP GPIO24/KSO4 GPIO25/KSO5 GPIO26/KSO6 GPIO27/KSO7 GPIO28/KSO8 GPIO29/KSO9 GPIO2A/KSO10 GPIO2B/KSO11 GPIO2C/KSO12 GPIO2D/KSO13 GPIO2E/KSO14 GPIO2F/KSO15/E51_RX(ISP) GPIO48/KSO16 GPIO49/KSO17 GPIO30/KSI0/E51_TX(ISP) GPIO31/KSI1 GPIO32/KSI2 GPIO33/KSI3 GPIO34/KSI4 GPIO35/KSI5 GPIO36/KSI6 GPIO37/KSI7

GPIO1A/NUMLED# GPIO53/E51TMR1/CAPSLED# GPIO55/E51INT0/SCRLED#

GPIO4A/PSCLK1/P80_CLK GPIO4B/PSDAT1/P80_DAT GPIO4C/PSCLK2 GPIO4D/PSDAT2 GPIO4E/PSCLK3 GPIO4F/PSDAT3

GPIO44/SCL1 GPIO45/SDA1 GPIO46/SCL2 GPIO47/SDA2

GPIO04 GPIO07/GPWU GPIO08 GPIO0A/GPWU GPIO0B/ESB_CLK GPIO0C/ESB_DAT GPIO0D GPIO18 GPIO40 GPIO41 GPI42 GPI43 GPIO50/SELIO#

GPIO52/E51CS# GPIO54/E51TMR0/WDT_LED# GPIO56/E51INT1 GPIO57/XCLK32K

KB3310QF

12

KC7

0.1UF/16V

/X

LPC I/F

Key Matrix Scan

LED

PS2 I/F

SM BUS

GPIO

UART

GPIO59/SPICLKI/TEST_CLK

12

KC8

0.1UF/16V

VCC1 VCC2 VCC3

VCC

VCC4 VCC5 VCC6

AVCC

AVCC/AGND

AGND

GND1 GND2

GND

GND3 GND4 GND5

GPI38/AD0 GPI39/AD1

ADC

GPI3A/AD2 GPI3B/AD3

GPIO0F/PWM0 GPIO10/PWM1

PWM

GPIO11/PWM2

/

GPIO19/PWM3

FAN

GPIO12/FANPWM1 GPIO13/FANPWM2

GPIO14/FANFB1 GPIO15/FANFB2

GPO3C GPO3D

GPO

GPO3E GPO3F

GPXIOA00/SDICS# GPXIOA01/SDICLK

GPXIOA02/SDIDO

GPXIOA03

XIOA

GPXIOA04 GPXIOA05 GPXIOA06 GPXIOA07 GPXIOA08 GPXIOA09 GPXIOA10 GPXIOA11

GPXIOD0/SDIDI

GPXIOD1 GPXIOD2 GPXIOD3

XIOD

GPXIOD4 GPXIOD5 GPXIOD6 GPXIOD7

RD#/SPIDI

SPI

WR#/SPIDO

I/F

GPIO58/SPICLK

SELMEM#/SPICS#

GPIO16/E51_TX

GPIO17/E51_RX

XCLKI

XCLK

XCLKO

4

V18R

9 22 33 96 111 125

67 69

11 24 35 94 113

63 64 65 66

21 23 25 34

26 27 28 29

68 70 71 72

97 98 99 100 101 102 103 104 105 106 107 108

109 110 112 114 115 116 117 118

119 120 126 128

30 31

127

122 123

124

+3VA

GND

BATSEL_4P# MAIL_LED#

FAN1_PWM FAN1_TACH

CLK_PWRSAVE#

SPI_MODE#

EC_PWROK

BAT_LEARN

BATSEL_2P# THRO_CPU

SPI_CLK_R

E51_TX E51_RX

NC_GPIO59

K_XCLKI K_XCLKO

K_V18R

KL1

120Ohm/100Mhz

21

l0603

+3VA_AEC

BAT_ICHG 45 BAT_CONFIG 41,45 BAT_SENSE 45 BAT_TS 41,45

PM_PWRBTN# 14

FAN0_TACH 39

DOC 6 G_BACKOFF# 23

PM_BATLOW# 14

SUSC_ON 49 VSUS_ON 47 CPU_VRON 50 SUSB_ON 47,51

+1.8V_UP 49

CHG_EN# 45 PRECHG 45 SPI_WP# 37 A_OP_SD# 33

+1.8V_DOWN# 49

THRO_CPU 14 PM_SUSB# 14,23 PM_SUSC# 14 VRM_PWRGD 14,46 VSUS_GD 47 BATSEL_LiFe 47

1 2

T193TPC26T T194TPC26T

T183TPC26T

1 2

T205TPC26T

T90TPC26T T91TPC26T

T92TPC26T

1 1

R28 0Ohm

1 1

1

KC13 1UF/16V

12

KC18 10uF/10V

GND

12

GND

KC10

+3VA_AEC+3VA

12

KC19

0.1UF/16V

GND

FAN0_PWM 39

1

SPI_DO 37 SPI_DI 37 SPI_CLK 37 SPI_CS# 37

22PF/25V

/X

3

T206TPC26T

T207TPC26T

R1.0G

T96TPC26T

For RF Advise

+3VA

KR7

100KOHM

1 2

KR13 0Ohm

KC11 1UF/16V

1 2

GND

VSUS_GD EC_RSMRST#

VSUS_GD

EC_PWROK

SPI_WP#

1 2

5

06G043114010

KC17 22PF/25V

U33

RST/OUT

CD

VCC/VDD

RN5VD27CA

/X

KD1

1 2

BAT54AW

KD2

1 2

BAT54AW

N/A

1 2 34

GNDNC

3

12

/X

GND

+3VSUS

1 2

+3VS

1 2

GND

EC_RST#

KR10

10KOhm

1%

KR11

10KOhm

1%

2

+3VA

12

KC15

0.1UF/16V

/CAP/X

GND

PM_RSMRST# 15

PM_PWROK 9,14

SMB1_CLK SMB1_DATA

SMB2_CLK SMB2_DATA TP_CLK TP_DATA

BAT_IN AC_OK PM_SUSC# PM_SUSB#

CLRTC_EC

BAT_IN

EC_RST#

PCI_RST#

SPI_MODE#

SUSC_ON

VSUS_ON

GND

Default Group-A7V8X MX

EC36 0.1UF/16V

EC37 0.1UF/16V

15PF/50V

3

15PF/50V

7 8

10KOhm

5 6

10KOhm

7 8

10KOhm

5 6

10KOhm

3 4

10KOhm

1 2

10KOhm

5 6

100KOhm

7 8

100KOhm

1 2

100KOhm

3 4

100KOhm

R181 100KOHM

KR4 47KOHM KC16 0.1UF/16V

KR6 KC14 0.1UF/16V

KC9

12

KX1

SIDE

32.768KHZ

KC12

12

1 2

KR9 4.7KOhm

1 2 1 2

/X

10KOhm 1%

1 2

/X

R111 4.7KOhm 1%

1 2

/X

1 2

/X

1

2

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

+3VA

KRN7D KRN7C

+3VS

KRN6D KRN6C KRN6B KRN6A

+3VA

KRN2C KRN2D KRN2A KRN2B

GND

+3VA

/X

GND

+3VA

/X

12

GND

K_XCLKI

12

KR5 10MOhm

/X

K_XCLKO

EC_ENE KB3310

Kell_Huang

36 51Monday, November 10, 2008

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

D D

+3VA

R75

100KOHM

GND

1 2

12

C79

0.1UF/16V

/X

PWR_SW# 36

PWRBTN#

C C

R76 33Ohm

1 2

EC141

12

0.1UF/16V

/X

GND

PWRBTN#

SW1

1

132

3

TACT_SWITCH_5P

2 4

4

5

GND

10.23 For EMI

B B

For Debug

LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3

+3VS

DEBUG_CON

1

SIDE2

2

3

4

5

6

7

8

9

10

11

12 13

12 SIDE1

FPC_CON_12P

N/A

4

+3VS

12

C81

0.1UF/16V

/LPC_DEBUG

GND

SPI_WP# SPI_HOLD#

SPI_CS#36 SPI_DO36 SPI_WP#36

3

GND

1 2

10KOhm

3 4

10KOhm

U18

1

CE#

2

SO

HOLD#

3

WP#

4 5

VSS SI

SST25VF040B-50-4C

/SPI

VDD SCK

14

GNDGND +3VA

KRN7A KRN7B

8 7 6

+3VA

SPI_HOLD#

+3VA

12

C82

0.1UF/16V

/SPI

GND

SPI_CLK 36 SPI_DI 36

2

LPC_AD[3:0] 14,36

LPC_FRAME#14,36

CLK_PCI_DEBUG6

A A

5

SPI_CS#

C215 22PF/25V

SPI_DO

C216 22PF/25V

SPI_CLK

C217 22PF/25V

SPI_DI

C218 22PF/25V

For RF Advise

12

/X/SPI

12

/X/SPI

12

/X/SPI

12

/X/SPI

GND

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

900SD_MB

Engineer:

1

Switch_SPI ROM

Kell_Huang

37 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

TP_DATA TP_CLK

For Touch-Pad

D D

C C

+5VS +5VS_TP

B B

TP_L

SW2

1

123

2

TACT_SWITCH_5P

TP_R

SW3

1

123

2

TACT_SWITCH_5P

L26

120Ohm/100Mhz

21

3 4

4

5

GND

3 4

4

5

GND

TP_CLK36 TP_DATA36

TP_L

12

EC40

0.1UF/16V

For Keyboard

KB

29

SIDE1

1

2

3

4

5

5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

SIDE2

FPC_CON_28P

6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 30

GND

12

C77

0.1UF/16V

KSO15 KSI0 KSO3

1 1 1

T188TPC26T T189TPC26T T190TPC26T

+5VS_TP

TOUCH_PAD

TP_R

12

EC41

0.1UF/16V

GND GND GND

1 2

21SIDE1

3

4

5

6

7

8

9

10

11

12

FPC_CON_12P

SIDE2

13

TP_L

14

GND

10.23 For EMI

10.24

KSO0 KSI0 KSO1 KSO2 KSI1 KSO3 KSI2 KSO4 KSI3 KSO5 KSI4 KSI5 KSO6

GND

KSI6 KSI7 KSO7 KSO8 KSO9 KSO10 KSO11 KSO12 KSO1 KSO13 KSO14 KSO3 KSO15

+3VA

GND

ER3 100KOhm

1 2

ER4

1KOhm

EC_PIN82 36 EC_PIN81 36

12

EC142

0.1UF/16V

KSO0 KSI0 KSO1

KSO3 KSI2 KSO4

KSI4 KSI5

KSO7 KSO8 KSO9

KSO12 KSO13 KSO14

KSO[15:0] 36 KSI[7:0] 36

D14

5 6

PACDN045YB6

/X

D15

5 6

PACDN045YB6

/X

D16

5 6

PACDN045YB6

/X

D17

5 6

PACDN045YB6

/X

D18

5 6

PACDN045YB6

/X

GND

KSO2

34 2

KSI1

1

GND

KSI3

34 2

KSO5

1

GND

KSI6

34 2

KSI7KSO6

1

GND

KSO10

34 2

KSO11

1

GND

KSO15

34 2 1

GND

12

EC113

KSI0 KSI1 KSI2 KSI3 KSI4 KSI5 KSI6 KSI7 KSO0 KSO1 KSO2 KSO3 KSO4 KSO5 KSO6 KSO7 KSO8 KSO9 KSO10 KSO11 KSO12 KSO13 KSO14 KSO15

For RF Advise

12

EC114

1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2 1 2

33PF/50V

GNDGND

/X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X /X

33PF/50V

EC115 33PF/50V EC116 33PF/50V EC117 33PF/50V EC118 33PF/50V EC119 33PF/50V EC120 33PF/50V EC121 33PF/50V EC122 33PF/50V EC123 33PF/50V EC124 33PF/50V EC125 33PF/50V EC126 33PF/50V EC127 33PF/50V EC128 33PF/50V EC129 33PF/50V EC130 33PF/50V EC131 33PF/50V EC132 33PF/50V EC133 33PF/50V EC134 33PF/50V EC135 33PF/50V EC136 33PF/50V EC137 33PF/50V EC138 33PF/50V

GND

TP1

A A

EC42 0.1UF/16V

1 2

EC43 0.1UF/16V

1 2

5

TP_GNDGND

TP_GND

1

SPRING_PAD

13G02D001030

TP2

1

SPRING_PAD

13G02D001030

4

Default Group-A7V8X MX

1

KB_Touch Pad

Kell_Huang

38 51Monday, November 10, 2008

of

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

3

2

Date: Sheet

900SD_MB

Engineer:

5

4

3

2

1

http://hobi-elektronika.net

+3VS_THRM

SMB2_CLK

C133 10PF/50V

D D

SMB2_DATA

SMB2_CLK36

HT2

1

12

H_ALERT#

/X

12

/X

C134 10PF/50V

GND

U19

8

SCLK

7

SDATA

6

ALERT#/THERM2#

ADT7461ARMZ

+3VS_THRM

1

VDD

2

D+

3

D-

THERM#GND

PM_THERM#

45

GND

12

C83

0.1UF/16V

H_THERMDA 7SMB2_DATA36 H_THERMDC 7

1

HT1

R81 200Ohm

1 2

R118 200Ohm

1 2

+3VS

1% 1% /X

H_THERMDA

H_THERMDC

+3VA

12

C84 1000PF/50V

U19 use 06G023048021

C C

+5VS

RN9B

4.7KOhm

B B

A A

5

FAN0_TACH36

1 2

GND

+3VA

7 8

FAN0_PWM36

4

R142

18.2KOhm

1%

RN9D

4.7KOhm

RN9A

4.7KOhm

+5VS

RN9C

4.7KOhm

5 6

3

C

B

1

Q5 PMBS3904

E 2

12

GND

FAN_PWM

3 4

12

C152 100PF/50V

/X

FAN_TACH

GND

+5VS

GND

12

C151 100PF/50V

/X

FAN

1 5 2 3 4

WtoB_CON_4P

3

1SIDE1 2 3

SIDE2

4

6

GND

+5VS

GND

12

C150 10uF/10V

12

C149

0.1UF/16V

Default Group-A7V8X MX

Thermal Sensor_FAN

Title :

ASUSTek Computer INC.

Size Project Name

A3

2

Date: Sheet

900SD_MB

Engineer:

1

Kell_Huang

39 51Monday, November 10, 2008

of

Rev

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

for POWER LED for FLASH LED for WLAN LED

D D

R175

PWR_LED_UP36

1 2

100Ohm

1%

LED1

+

1 2

GREEN

R177

FLASH_LED28

GND GND

1 2

100Ohm

1%

LED3

+

1 2

GREEN

+3VS

R1.0G

R86

1 2

330Ohm

WLAN_LED14

LED4

+

1 2

BLUE

WLAN_LED-

32

3

D

Q34

1

2N7002

1

G

S

2

GND

C C

+3VSUS

B B

A A

for CHARGE LED

LED2

ORANGE

+

4 1

GREEN

GREEN/ORANGE

07G015700738

1 2

23

330Ohm

1 2

330Ohm

R176

R207

CHARGE1_LED# 36

CHARGE0_LED# 36

Default Group-A7V8X MX

1

LED

Hauld_Zhou

40 51Monday, November 10, 2008

Rev

R1.0G

of

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

DC IN

DC_PWR

4

P_GND1

5

P_GND2

D D

C C

6

NP_NC

DC_PWR_JACK_3P

4

DC_JACK_IN

http://hobi-elektronika.net

12

C86

0.1UF/25V

c0603

T128TPC26T T129TPC26T T130TPC26T

T132TPC26T T133TPC26T T134TPC26T T135TPC26T

L28

21

150Ohm/100Mhz

L27

21

150Ohm/100Mhz

1 1 1

1

2

3

1 1 1 1

DCIN_GND

1 2

3

D20 SS0540

12

C87 10UF/25V

c1210_rd9

12

C88 1UF/25V

c0805_h57

A/D_DOCK_IN

12

C89

0.1UF/25V

c0603

GND

2

1

BAT IN

BAT

BC4

0.1UF/25V

c0603

BT9TPC26T BT10TPC26T BT11TPC26T BT12TPC26T

BC1 100PF/50V

12

BD4

12

BC8 100PF/50V

V0402MHS03

/X

12

V0402MHS03

/X

12

BD2

V0402MHS03

/X

1 2

BC9

0.1UF/25V

c0603

12

BD3

BC5

0.1UF/25V

1 2

c0603

GND

BT14TPC26T BT15TPC26T BT16TPC26T BT17TPC26T

V0402MHS03

/X

GND

BL6 120Ohm/100Mhz

BL4 120Ohm/100Mhz BL3 120Ohm/100Mhz

BL5 120Ohm/100Mhz

12

BD5

21

21 21

21

BAT_IN# 45,47

BAT_ID 45 BAT_TS 36,45

BAT_CONFIG 36,45

R1.0G

Default Group-A7V8X MX

1

PWR Jack

Kell_Huang

41 51Monday, November 10, 2008

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet of

4

3

2

900SD_MB

Engineer:

1

GND

1 1 1

1 2

1 1 1 1

BATT_CON

10

P_GND1

1

2

3

4

5

B B

A A

5 6 7 8 9

P_GND2

BATT_CON_9P

6 7 8 9

11

5

4

3

2

1

http://hobi-elektronika.net

H5

1

NP_NC

2

GND1

3

D D

GND GND

C C

GND GND

B B

GND GND

GND2

H7

1

NP_NC

2

GND1

3

GND2

C236D87N

H10

1

NP_NC

2

GND1

3

GND2

C236D87N

H11

1

NP_NC

2

GND1

3

GND2

C236D87N

H14

1

NP_NC

2

GND1

3

GND2

C236D87N

H16

1

NP_NC

2

GND1

3

GND2

C236D87N

GND4 GND3

C236D87N

GND4 GND3

5 4

GNDGND

5 4

GND GND

H6

1

NP_NC

2

GND1

3

GND2

H9

1

NP_NC

2

GND1

3

GND2

C236D87N

1

NP_NC

2

GND1

3

GND2

H15

1

NP_NC

2

GND1

3

GND2

C236D87N

GND4 GND3

C236D87N

GND4 GND3

H13

GND4 GND3

C236D87N

GND4 GND3

5 4

H20

1

SCREW_HOLE

5 4

GND 5 4

H17

1

NP_NC

2

GND1

3

A A

A_GND A_GND GNDGND

GND2

5

GND4 GND3

C236D87N

5 4

GND GND

H18

1

NP_NC

2

GND1

3

GND2

GND4 GND3

C236D87N

5 4

4

H21

1

NP_NC

2

GND1

3

GND2

GND4 GND3

C236D87N

5 4

Default Group-A7V8X MX

1

Srew Hole

Kell_Huang

42 51Monday, November 10, 2008

Rev

R1.0G

of

Title :

ASUSTek Computer INC.

Size Project Name

A3

3

2

Date: Sheet

900SD_MB

Engineer:

5

12

EC9

0.1UF/16V

+3VS

GND

12

EC44

+3VSUS

12

18PF/50V

/X

EC31

0.1UF/16V

/X

AC_BAT_SYS

12

EC6

0.1UF/16V

/X

12

EC4

0.1UF/16V

/X

EC12

0.1UF/16V

12

EC7

0.1UF/16V

/X

12

EC8

0.1UF/16V

/X

12

EC2

0.1UF/16V

/X

D D

GND

+3VS

12

GND

+5VSUS

12

EC5

0.1UF/16V

/X

EC10

0.1UF/16V

/X

12

EC19

0.1UF/16V

/X

12

4

EC45

18PF/50V

/X

12

3

http://hobi-elektronika.net

EC46

18PF/50V

/X

12

EC21

0.1UF/16V

/X

12

EC47

18PF/50V

/X

12

EC29

0.1UF/16V

/X

12

EC144

0.1UF/16V

10.23 For EMI

12

EC145

0.1UF/16V

/X

+1.8V

12

EC146

0.1UF/16V

/X

+3VS_MiniCard

12

EC69

18PF/50V

/X

GND GND

EC20

0.1UF/16V

/X

12

EC70

18PF/50V

/X

+1.8V

GND

12

EC105

0.1UF/16V

/X

2

AC_BAT_SYS

GND

12

EC103

0.1UF/16V

/X

12

EC104

0.1UF/16V

/X

1

+3VS_SD

12

EC55

18PF/50V

/X

GND

RF CAP :Default Mount

12

EC106

0.1UF/16V

/X

EC111

0.1UF/16V

1 2

/3.5G/EMI

GND GND

1 2

EC112

0.1UF/16V

/3.5G/EMI

USIM_PWR 24 USIM_PWR 24

12

GND

+3VSUS_CLK

12

GND

12

EC162

0.1UF/16V

/X

A_GND

GND

+1.5VS

12

GND

+1.8V

12

GND

EC13

0.1UF/16V

/X

EC22

0.1UF/16V

/X

GND

12

EC35

0.1UF/16V

/X

EC14

0.1UF/16V

/X

EC23

0.1UF/16V

/X

12

EC24

0.1UF/16V

/X

+5VS

GND

12

EC83

18PF/50V

/X

+2.5VS

12

GND

12

EC25

0.1UF/16V

/X

EC100

0.1UF/16V

/X

C C

B B

GND

+5VSUS_USB34_CON

12

EC87

18PF/50V

/X

GND

12

EC26

0.1UF/16V

/X

+5VS

12

EC163

0.1UF/16V

/X

10.23 For EMI

GND

12

EC88

12

EC32

0.1UF/16V

/X

18PF/50V

/X

12

EC33

0.1UF/16V

/X

+3V_LCD

12

GND

+1.8V

GND

EC84

18PF/50V

/X

12

EC151

0.1UF/16V

/X

+1.5VS_MiniCard

12

EC34

0.1UF/16V

/X

12

GND

12

EC85

18PF/50V

/X

EC158

0.1UF/16V

/X

10.23 For EMI

+3VAUX_WLAN

12

GND

12

EC159

0.1UF/16V

/X

EC86

18PF/50V

/X

12

EC160

0.1UF/16V

/X

EC72

18PF/50V

/X

EC89

18PF/50V

/X

12

EC73

18PF/50V

/X

EC90

18PF/50V

/X

12

EC74

18PF/50V

/X

EC91

18PF/50V

/X

12

EC75

18PF/50V

/X

EC92

18PF/50V

/X

12

EC76

18PF/50V

/X

EC93

18PF/50V

/X

12

EC77

18PF/50V

/X

+5VSUS_USB12_CON +VCCP

12

EC164

0.1UF/16V

/X

EC78

18PF/50V

/X

12

10.24

GND

EC79

18PF/50V

/X

12

EC80

18PF/50V

/X

12

GND

EC168

0.1UF/16V

/X

12

EC169

0.1UF/16V

/X

A A

Default Group-A7V8X MX

1

EMI

Kell_Huang

43 51Monday, November 10, 2008

Rev

R1.0G

of

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet

900SD_MB

Engineer:

5

4

3

2

1

http://hobi-elektronika.net

POWER CHARGER

D D

A/D_DOCK_IN

BATSEL_2P# PRECHG A/D_SD#

MAX8724

(Controllor)

AC_APR_UC

BAT

BATSEL_3S# CHG_EN#

CHG_PDL

AP4957GM (SWITCH)

AP4835GM

SWITCH

AC_BAT_SYS

VSUS_ON

AC_BAT_SYS

RT8205CGQW

+3VSUS

(1.428A)

(Controller)

C C

+3VA

+5VSUS

SUSB_ON

(1.332A)

UP6111AQDD

(Controller)

+1.8V

(3.456A)

SUSB_ON

AP4800AGM

(SWITCH)

UP7711U8

AP4800AGM

(SWITCH)

+5VS

VTT_DDR

(0.5A)

+3VS

APL5315BI

UP7704U8

+2.5VS

(0.1A)

+1.8V_HD

(0.2A)

SUSC_ON

B B

UP6111AQDD

(Controller)

+1.5VS

(2.184A)

SUSB_ON

UP6111AQDD

(Controller)

+VCCP(1.05V)

(6.216A)

Bead

+VCORE

VRM_PWRGD

(2.688A)

CPU_VRON

A A

Default Group-A7V8X MX

1

Power Flow

Joy_Zhou

44 51Monday, November 10, 2008

Rev

R1.0G

Title :

ASUSTek Computer INC.

Size Project Name

A3

5

4

3

2

Date: Sheet of

900SD_MB

Engineer:

5

4

3

2

1

⸔ǂ֤ϕǂㅓ⨜ᢜǂ

567

PQ1

D2

AP4957GM

P

G2

S2

PR4

12

20KOHM

1%

PQ4A

UM6K1N

PR7

7.15KOhm

P_CHG_CCI_10 P_CHG_CCV_10

PR17 10KOhm

12

10KOhm 1%

1%

1 2

12

PC12 0.01UF/25V

0.1UF/16V

BAT_ICHG36

1

61

P_CHG_ACOK#_10

2

PU1B

30

GND3

31

GND4

32

GND5

33 34

GND6 GND7

MAX8724ETI

12

PC1 1000PF/50V

/X

PJP506

/X

61

PC8654

0.01UF/16V

2

VIINP

12

PC7

0.1UF/16V

1 2

P_CHG_IINP_10

P_CHG_CSSP_10

28272625242322

29

IINP

1

GND2

DCIN

2

LDO

3

CLS

4

REF

5

CCS

6

CCI

7

CCV

SHDN#

ICHG

MAX8724ETI

891011121314

PC14

P_CHG_ICHG_10

P_AC_APR_UC_10

P_CHG_ACIN_10

12

PC16

PR23 15KOhm

1 2

P_CHG_VCC_20

PR28A 100KOhm

1 2

12

PC18

0.01UF/16V

/X

37

GND10

36

GND9

35

GND8

BAT

PR1

1 2

15mOHM

PJP505 SHORT_PIN

SHORT_PIN

1 2

12

/X

PC5 0.1UF/16V

PD2 BAT54WS

PR6 2.7Oh m

1 2

P_CHG_BST_20

P_CHG_CSSN_10

P_CHG_LGV_20

P_CHG_DHI_20P_CHG_REFIN_10

P_CHG_PHASE_20

PU1A

LX

DHI

BST

CSSP

DLOV

CSSN

DLO

PGND

CSIP

CSIN

CELLS

BATT VCTL

ACIN

ACOK#

REFIN

ICTL

GND1

P_CHG_ICTL_10

P_CHG_ACOK#_10

150KOhm

r0402

0.1UF/16V

AC_OK = 1, Adaptor is present AC_OK = 0, Adaptor is absent

34

PQ13B

UM6K1N

5

/X

12

PC8655

/X

0.01UF/16V

12

P_CHG_LG_20

21

P_CHG_PGND_20

20

P_CHG_CSIP_10

19

P_CHG_CSIN_10

18

P_CHG_CELL_10

17

P_CHG_BATT_10

16

P_CHG_VCTL_10

15

PR19

12

10 23

BAT_ID41

2S1P, R6ࢉ open 2S2P, R6ࢉ0 ohm

PQ3

2N7002

PC8 1UF/16V

c0603

AC_OK 36

1 2

1 2 32

3

D

S

2

P_CHG_DHI_20

1 2

PR13 100KOhm

PR14 56KOhm

1 2

PR2

100KOHM

PR606172 1KOhm

1

P_CHG_ACOK#_10

1

G

PJP507

SHORT_PIN

/X

MAX8724_LDO

PR9

2.2Ohm

r0603

10 23

12

MAX8724_REF

PR22 68.1KOhm 1%

12

+3VA

PR28B

100KOhm

3 4

1

TPC26T

PT21

3

BAT

PR6050 180KOhm

PT167

PT168

PT166

TPC26T

1

PD507 SX34

/X

PD516

12

1 2

12

BAT54CW

PR606170

1MOhm

1%

1

N/A

12

1 2 32

3

D

G

S

2

7 8

3

P_CHG_ACOK#_10 47

PQ6

S1

N

S2G2D2

3 4

N

AP4232GM

CELL=GND ---> 2S

MAX8724_REF

CHG_EN#36

PR30

68.1KOhm

PQ14 2N7002

100KOhm

0.01UF/16V

PR28D

PC8653

N/A

D1

7812

D1G1

P_CHG_PHASE_S

6

D2

5

P_CHG_VIN

12

PC8658 470PF/50V

2008_1014

PR606171 1Ohm

1 2

PT19 TPC26T

1

PQ9B

UM6K1N

12

PQ2

S D

1

8

2

7 356 4

G

AP4835GM

12

PC8656

PC8657

10UF/16V

PR8

1 2

21

PL1

25mOHM

6.8UH

PJP502 SHORT_PIN

/X

1 2

PJP504

12

SHORT_PIN

/X

34

PRECHG36

5

MAX8724_REF

12

PR26 68KOhm

1%

12

PR31

330KOhm

1%

BAT_SENSE36

PT169 TPC26T

1

AC_BAT_SYS

PT171

PT170

TPC26T

1

PL601 70Ohm/100Mhz

21

AC_BAT_SYS

21

PL602 70Ohm/100Mhz

PT164

PT162

PT163

PT165

TPC26T

1

12

PC8659

PJP503 SHORT_PIN

/X

UM6K1N

PQ9A

PC8660

10UF/16V

PT172TPC26T

1

PT173TPC26T

1

PT174TPC26T

1

PR18 3KOhm

61

2

Iprechg=(Victl/Vrefin)*(0.075/Rsense2)=0.208A

Victl= 0.178V(BATT=6V) Vrefin= 2.57V(BATT=6V) Vbatt = Cell * { 4V +[ 0.4 X (VCTL/REFIN) ] }

=> Vbatt = 4.2V X CELLS (when VCTL=LDO)

2S2P Vbat=8.26V Ichg=2.5A

Ichg=(Victl/Vrefin)*(0.075/Rsense2)=2.55A

Victl= 3.01V(BATT=8.26V),2.1869V(BATT=6V) Vrefin= 3.54V(BATT=8.26V),2.57V(BATT=6V)

Vbatt = Cell x{ 4V +[ 0.4 x (VCTL/REFIN) ] }=8.26 ==>Vctl= 1.149V(4.096x39/139)

Vbatt = 4.2V X CELLS (when VCTL=LDO)

2

1 2

PC6051

PR6052

0.1UF/16V 100KOhm

1 2

GND

BAT

+3VA

PR28C

100KOhm

+3VA

PR6103 680OHM

2008.11.05

1 2

PU6000

23

APL431BAC

1

GND

Iprechg=0.19226A(min)~0.2245A(max) Vbatt=8.259V(typ)~8.347V(max) Ichg(1P)=1.4651A(typ)~1.505A(max) Ichg(2P)=2.552A(typ)~2.6137A(max)

2S1P Vbat=8.26V Ichg=1.5A

Ichg=(Victl/Vrefin)*(0.075/Rsense2)=1.466A

Victl= 1.7288V(BATT=8.26V),1.2558V(BATT=6V) Vrefin= 3.54V(BATT=8.26V),2.57V(BATT=6V)

Vbatt = Cell x{ 4V +[ 0.4 x (VCTL/REFIN) ] }=8.26 ==>Vctl= 1.149V(4.096x39/139)

Vbatt = 4.2V X CELLS (when VCTL=LDO)

PT161 TPC26T

5 6

PT159 TPC26T

BAT_IN#41,47

+2.5VREF

1

+2.5VREF

PR6104

3.9KOhm

for EC

1 2

BAT_TS

BAT_TS 36,41

12

PC6101

0.1UF/16V

/X

GND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

Custom

Date: Sheet

1

+2.5VREF

PR606078

1.65KOhm

/X

1 2

1

+2.5VREF

PR606075 47KOhm

1 2

BAT_CONFIG

12

PC8050

0.01UF/16V

GND

900SD_MB

1

G

GND

Title :

Engineer:

BAT_IN 36

32

3

D

PQ600 2N7002

S

2

PT160 TPC26T

1

BAT_CONFIG 36,41

CHARGER

Joy_Zhou

Rev

R1.0G

45 51Monday, November 10, 2008

of

http://hobi-elektronika.net

D D

Ėadapter

P_CHG_VCC_20

12

P_19VDETEC_10

VLDO = 5.4V

MAX8724_LDO

PD4 BAT54WS

c0603

PC10 1UF/16V12PC11 1UF/16V

/X

12

Vacin=2.55V

PR21

1 2

P_AC_APR_UC_10

1 2

100KOHM

UM6K1N

12

PR29

100KOhm

81

D1S1D1G1

PR3

1 2

P_AC_APR_UC_10

PQ4B

5

GND

P_MAX8724_DCIN_20 P_MAX8724_LDO_20 P_CHG_CLS_10 P_MAX8724_REF_10 P_CHG_CCS_10

12

PR15

1 2 12

PC13

PC15

0.033UF/16V

12

PC17

0.1UF/16V

PQ13A

UM6K1N

P

234

34

PT15 TPC26T

PT5

PT7

PT6

PT8

TPC26T

1

A/D_DOCK_IN

1

Adapter:12V/ 36W

Vref = 4.096V

MAX8724_REF

2008.11.05

1 2

PR16

100KOhm

1%

1 2

2008.11.05

1 2

4

PC2

2200PF/50V

12

PR10

86.6KOhm

Vcls

081023

12

PC9 1UF/16V

PD5 1SS355

PR20

1 2

130KOhm

31.6KOHM

PR59

130KOhm

A/D_DOCK_IN

GND

1 2

PU10

23

APL431BAC

A/D_DOCK_IN

PR24

10KOhm

/X

1

/X

P_H431_REF

A/D_DOCK_IN

1%

PR12

/X

10KOhm

1 2

INPUT_SEL_GATE

12

PC41

/X

0.1UF/16V

GND

PR25

/X

29.4KOhm

1 2

PR27

23

2

S

1

C C

G

D

3

/X

56KOhm

PQ12

1 2

AP2301GN

/X

P_INPUT_SEL

12

PC43

PR69

/X

1UF/10V

16.5KOhm

/X

1 2

GND

H431_REF = 2.41V if input is 9.5V H431_REF = 2.66V if input is 10.5V

if current sharing =30W(2.5A), power limit =33.5W(2.75A)

R4312=100K

Input Current Iim = 2.5A [0.075V/Rsense(CHG)]*[VCLS/Vref]

Rsense(CHG)=0.025 ohm, Vref=4.096V, Vcls=3.413V

PR32

100KOhm

1

12

1

G

12

/X

PC42

/X

0.1UF/16V

GND

23

2

S

PQ44

/X

AP2301GN

D

3

PR38

/X

1 2

97.6KOhm

2008.11.05

B B

INPUT_SEL_GATE P_INPUT_SEL P_H431_REF

A/D_DOCK_IN

PC44

1 2

GND

2008-10-14

0.1UF/25V

c0603

MAX8724_LDO

A/D_DOCK_IN

12

PR6409

1 2

P_19VDETEC_10

PR6412

1MOhm

1 2

1MOhm

P_ADAIN_IN-_10

12

PC8232

GND

PR6410 22KOhm

P_ADAIN_IN+_10

12

2.2UF/16V

PC8233 1UF/16V

PU11

1

8

VCC

OUT1

2

7

OUT2

-IN1

3

6

+IN1

-IN2

4

5

VEE

+IN2

LM393DT

GND

5

PR80

22KOhm

PR79 15KOhm

1 2

GND GNDGND

A A

A/D_DOCK_IN

5

4

3

2

1

http://hobi-elektronika.net

D D

12

PC8661 10UF/6.3V

/X

c0805

GND GNDGNDGND

12

PC8662 10UF/6.3V

/X

c0805

12

PC8663 10UF/6.3V

/X

c0805

12

PC8664 10UF/6.3V

/X

c0805

12

PC28 10UF/6.3V

c0805

GND

12

PC29 10UF/6.3V

c0805

+Vcore / 7A

12

PC30 10UF/6.3V

c0805

GND GND

GNDGND

PC31 10UF/6.3V

c0805

+VCORE

12

+

PCE3 100U/2.5V

GND

12

+

PCE4

100U/2.5V

/X

2008-10-15

C C

PC8652

0.1UF/16V

/X

1 2

PR6468

0Ohm

/X

1009

PR606169

1KOhm

/X

PR606145

1 2

62KOhm

N/A

12

+3VSUS

0814

1 2

GND

1 2

100KOhm

PC711

0.1UF/16V

PR6469

34

5

UM6K1N

GND

VRM_PWRGD = 1, Vcore Power OK

VRM_PWRGD14,36

1 2

GND

+VCCP_OK6,50

B B

+VCORE

PQ8927B

+3VS

PR56 620Ohm

1 2

+VCORE

61

PQ8927A

2

UM6K1N

GND

PL5021 0Ohm /bead

1 2

PL5022 0Ohm /bead

1 2

+VCCP

A A

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet of

5

4

3

2

900SD_MB

Engineer:

Vcore

Joy_Zhou

46 51Monday, November 10, 2008

1

Rev

R1.0G

5

TPC28T

PT243

PJP614

+3VAO

D D

1 2

12

1

1MM_OPEN_5MIL

P_+5VSUS+3 VSUS_EN_10

+3VSUS

C C

12

+

PCE18

PC8615

GND

1009

100UF/6.3V

PC8619

0.22UF/25V PC8621

0.22UF/25V

12

1 2

10UF/6.3V

GND GND

+5VSUS

B B

+12VSUS

AC_BAT_SYS

PR606132A

100KOhm

A A

PR606135

SUSB_ON36,51

100KOHM

12

PC8637

0.1UF/16V

PQ8915B UM6K1N

5

12

1 2

P_3VPWR_ENR_10

34

GND GND

TPC28T

PT244

/X

AC_BAT_SYS

3

PD509 BAT54CW

0.1UF/16V

OCP=7A OCP=17A

PL5029

4.7UH

47PF/50V

+3VSUS

PC8604

1 2

PC8626

2

1 2

/X

GND

PC8614

470PF/50V

PR606112

PD512

BAT54SW

PD513

BAT54SW

+12VSUS

1

12

21

1Ohm

12

3 4

61

+3VA

Irat=3A

12

200KOHM

PR606100

PJP615

SHORT_PIN

/X

PJP617

SHORT_PIN

/X

P_+3VSUS_PHASE_SHAPE

12

P_+3VSUS_SNU_S

12

3

12

GND

Shape

PR606132B

100KOhm

PQ8915A

UM6K1N

PL5026

70Ohm/100Mhz

12

PR606101 267KOHM

GND

12

PC8618

1 2

0.1UF/16V

c0603

PC8620

1 2

0.1UF/16V

c0603

PR606125 200KOhm

PR606126

39.2KOhm

1%

PQ8913

8 7 6 5

AP4800AGM

P_3VPWR_EN_10

+3VSUS_DOWN#14

Hi : Vout = 3.3V Low : Vout = 3.1V

P_+3VSUS_IN_SHAPE

21

8

S D

123

8

S D

123

GND

P_+5VSUS_LG_20

SD

1 2 3 4

G

12

PC8631

0.01UF/16V

GND

4

PR606096

10KOhm

12

PC8601

+

PCE21

10UF/16V

15UF/25V

/X

GND GND

GND

12

PC8603

/X

0.1UF/16V

PC8607

GND

567

0.1UF/16V

N/A

PQ8908

AP4800AGM

G

4

PJP619

12

SHORT_PIN

/X

567

PQ8909

AP4800AGM

G

4

PT257

PT258

TPC26T

1

12

PC8629 1UF/16V

c0603

GND

SUSB_ON

4

3

PR606095

12

PC8611

10UF/6.3V

12

GND

54.9KOhm

12

P_+3VSUS_+5VSUS_REF_10

PC8599

0.22UF/10V

P_+5VSUS_ENTRIP_10 P_+3VSUS_ENTRIP_10

PR606099

0Ohm

P_+3VSUS_+5VSUS_TON_10

12

PR606102

/X

PR606115

0Ohm

PR606118 0Ohm

PR606120

49.9KOhm PR606164

0Ohm

PR606122 20KOhm

GND

12

GND

P_+3VSUS_FB_10

+3VAO

12

RT8205CGQW

PR606107

0Ohm

/X

P_+3VSUS_VO_30 P_+3VSUS_BOOT_20

P_+3VSUS_HG_20 P_+3VSUS_PHASE_20 P_+3VSUS_LG_20

(F=375kHZ)

1009

PR606113

0Ohm

/X

P_+3VSUS_S KIPSEL_10P_+3VSUS_+5VSUS_REF_10

12

PR606116

0Ohm

/X

GND GND

P_SUS_SECFB_10

P_+3VSUS_+5VSUS_VIN_20

P_+3VA_+5VA_EN_10

12

PC8624 1UF/16V

+5VSUS +5VSUS_VCC

PD508 BAT54CW

+5VA

3

GND

12

PR606163 10KOhm

N/A

P_+5VSUS_FB_10

PU6012A

7 8

9 10 11 12

12

VO2 VREG3 BOOT2 UGATE2 PHASE2 LGATE2

6

ENTRIP2

EN

13

5

FB2

SKIPSEL

14

4

321

TONSEL

UGATE1

PHASE1 LGATE1

GND1

16

15

PGOOD BOOT1

GND

FB1

REF

ENTRIP1

GND2

VO1

VIN

VREG5

SECFB

17

18

12

PC8622

10UF/6.3V

12

PR606110 62KOhm

N/A

25

P_+5VSUS_VO_30

24

P_+3VSUS_+ 5VSUS_PGD_10

23

P_+5VSUS_BOOT_20

22

P_+5VSUS_HG_20

21

P_+5VSUS_PHASE_20

20

P_+5VSUS_LG_20

19

P_+3VSUS_BOOT_20

+5VA

P_CHG_ACOK#_1045

Add 0423

PL5025

Irat=3A

21

70Ohm/100Mhz

2 1

26 27 28 29

PC8609 4700PF/25V

N/A

1 2

PR606105 20KOhm

(F=300kHZ)

BAT_IN#41,45

+5VSUS

PU6012B

GND3 GND4 GND5 GND6

RT8205CGQW

0.1UF/16V

GND

PD511

1 2

BAT54WAPT

VSUS_GD36

GND

12

PC8608

PR606111 0Ohm

N/A

3

2008-10-14

1 2

100KOHM

12

PC8613

0.1UF/16V

+5VSUS

PD514

BAT54WAPT

PR606104

12

100KOhm

P_3VSUS_OV#_10 P_+3VSUS_FB_10

http://hobi-elektronika.net

PQ8925

32

2N7002

3

12

PC8598

0.1UF/16V

PC8602 10UF/16V

PR606106

6.04KOhm

1

12

PR606109 62KOhm

PC8612

0.1UF/16V

AC_BAT_SYS

FORCE_OFF#

D

1

G

S

2

GNDGND

GND

12

PR606103

10KOhm

12

N/A

12

P_3VSUS_OV_10

12

GND

12

PC8610 4700PF/25V

N/A

For LiFe Voltage under 6V, RT9022

+5VA

PD515

3

BAT54CW

/X

2008-10-14

VSUS_GD

1UF/16V

/X

PT259

PT262

TPC26T

1

Shape

2 3 4

12

3

+5VS

12

(0.3A)

PC8630 1UF/16V

c0603

GND

ShapeShape

PR606132D

100KOhm

PQ8916A

UM6K1N

PQ8914

SD

8 7 6 5

G

AP4800AGM

P_5VPWR_EN_10

PC8632

0.01UF/16V

100KOhm

UM6K1N

+5VSUS

+12VSUS

7 8

61

2

GND GND

+3VS

PR606137

1 2

10KOhm

PC8638

0.1UF/16V

/X

12

AC_BAT_SYS

5

GND

PR606132C

5 6

P_5VPWR_ENR_10

34

PQ8916B

PR606138D

7 8

100KOhm

VSUS_ON

AC_BAT_SYS

12

PR606119 100KOHM

P_+3VSUS_+ 5VSUS_ENR_10

3

12

PR606123

/X

GND

PC8627

0.1UF/16V

/X

1 2

12

PC8633

PR606138A

1 2

100KOhm

0.1UF/16V

5467

PQ8907

RJK0355DPA-00-J0

+3VA

GND

12

GND

BAT

GND GNDGND GND

5 D

G

PJP620

12

SHORT_PIN

/X

PQ8910

RJK0355DPA-00-J0

G

P_+3VA_+5VA_EN_10

32

3

D

PQ8912

1

2N7002

G

S

2

PC8625

12

/X

GND

0.033UF/16V

05.21

1

2

GND GND GND

P_BAT_IN_10

12

PC8634 1UF/16V

/X

GND

2

AC_BAT_SYS

2

12

PC8665

GND

P_+5VSUS_IN_SHAPE

876

GND GND

S

123

P_+5VSUS_PHASE_SHAPE

5467

876

5 D

S

123

PU6013

RESET#/RESET

VDD

GND

RT9818A-30GV

/X

PU6014

1

EN

VIN

2

SS

GND

3 4

VOUT FB

RT9022PE

/X

PR606134

1 2

30.9KOhm 1%

/X

PC8635

12

0.1UF/16V

05.29

2

+12VSUS

PR606138C

PR606138B 100KOhm

3 4

61

12

PC8605 10UF/16V

PJP616

SHORT_PIN

/X

PJP618

SHORT_PIN

/X

6 5

/X

PQ8928A

3

100KOhm

5 6

34

PQ8928B

5

UM6K1N

GND

12

PC8606 10UF/16V

12

PL5030

4.7UH

12

PC8616

470PF/50V

P_+5VSUS_SNU_S

12

1Ohm

PR606114

AC_BAT_SYS

VSUS_ON36

12

PR606127

4.53KOhm

/X

12

PC8628

0.1UF/16V

/X

BATSEL_LiFe = 1, 3.75V BATSEL_LiFe = 0, By BATSEL_3S

BATSEL_LiFe 36

1.25V

P_5VA_FB_10

12

PC8636

0.1UF/16V

/X

+5VSUS

UM6K1N

+5VSUS+3VSUS

PR606136 10KOhm

1% /X

GND

12

+

1009

21

12

PR606128 10KOhm

/X

12

PR606129

05.29

20KOHM

/X

0.1UF/16V

PCE20

15UF/25V

/X

PR606124

PC8666

Irat=3A

PR606121

100KOhm

12

100KOhm

PQ8920

8

1

7

2

6

S

3

5

D

G

RJK0355DPA-00-J0

12

GND

PL5027

21

70Ohm/100Mhz PL5028

21

70Ohm/100Mhz

2008-10-15

+5VSUS

12

+

PCE19 100UF/6.3V

VSUS_ON

12

5

PC8617

1 2

10UF/6.3V

GNDGND

2008-10-14

12

/X

PR606117

100KOHM

P_+5VSUS+3VSUS_EN_10

61

2

PQ8911A UM6K1N

34

PQ8911B UM6K1N

GND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A2

Date: Sheet

1

7 6 54

AC_BAT_SYS

12

/X

PC8623

1000PF/25V

900SD_MB

1

+5V_USB

TPC28T

PT245

+3VSUS

1

TPC28T

PT247

1

GND

TPC28T

+3VSUS

1

TPC28T

PT251

1

GND

TPC28T

PT253

+5VSUS

1

TPC28T

PT255

1

GND

TPC28T

PT260

+5VSUS

1

TPC28T

PT263

1

GND

Power_+5SUS&+3VSUS

Title :

Engineer:

Joy_Zhou

TPC28T

PT246

1

PT248

PT249

TPC28T

PT252

1

PT254

PT256

TPC28T

PT261

1

PT264

47 51Monday, November 10, 2008

TPC28T

PT250

1

Rev

R1.0G

of

5

4

3

2

1

http://hobi-elektronika.net

+1.8V_HD

D D

C C

B B

+VTTDDR

PT204 TPC26T PT205 TPC26T PT207 TPC26T

+3VS +5VS

PU6015A

1 2 3 4 5

UP7704U8

PC8641

1UF/16V

c0603

P_+1.8VHD_EN_10 P_+1.8VHD_Vin_40

12

GND

P_+1.8VHD_CNTL_20

12

PC8642

0.1UF/16V

c0603

+VTTDDR(0.5A)

PT203

PT201

PT202

TPC26T

1

25mil

12

+

PCE9

12

100U/2.5V

PC8102

/X

1 1 1

GND

0.1UF/16V

c0603

GND2

POK

GND1 EN VIN

VOUT CNTL NC

12

PC8647 10UF/6.3V

c0805

GND

FB

GND

9 8

P_+1.8VHD_FB_25

7

P_+1.8VHD_25

6

12

PC8648 10UF/6.3V

c0805

1000PF/50V

1 2

PC8639

PR606139

1 2

18.2KOhm

PR606140

13.3KOhm

1 2

GND

+1.8V

21

PL33

70Ohm/100Mhz

Irat=3A

P_0.9VO_VIN_20

GND

12

PC8103 1UF/16V

c0603

GNDGND GND

PU6003A

1

VIN

2

GND1

3

REFIN

VCNTL

4 5

VOUT NC1

UP7711U8

P_0.9VO_REF_10

05.21

GND2

NC3 NC2

GND

12

9 8 7 6

PC8105

0.1UF/16V

c0603

12

PC8640 10UF/6.3V

c0805

GND

+5VS

P_0.9VO_VCNTL_20

12

PC8160

c0603

0.1UF/16V

GND

05.21

GND

+1.8V

12

PR6201 10KOhm

12

PR6204

10KOhm

GND

10 11 12 13

PU6015B

GND3 GND4 GND5 GND6

UP7704U8

GND

10 11 12 13

PU6003B

GND3 GND4 GND5 GND6

UP7711U8

A A

Default Group-A7V8X MX

Title :

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet of

5

4

3

2

900SD_MB

Engineer:

1.8VHD_VTT_DDR

Joy_Zhou

1

Rev

48 51Monday, November 10, 2008

R1.0G

5

4

3

2

1

http://hobi-elektronika.net

PL29

12

PC8189

10UF/6.3V

c0805

GND

70Ohm/100Mhz

2 1

PL30

21

70Ohm/100Mhz

+1.8V

12

05.21

PC8190 10UF/6.3V

c0805

/X

AC_BAT_SYS

+1.8V

P_1.8V_EN_10mil

12

PC8100

0.1UF/16V

GND

05.21

+1.8V

P_1.8V_FB_10mil

/X

PR6372

0Ohm

+5VSUS_VCC

12

PC8191

0.1UF/16V

c0603

GND

PR6327

1.3MOhm

GND

12

PU6010A

1

VOUT

2

VCC

3

FB

4

POK

UP6111AQDD

P_1.8V_BOOT_20mil

1314151617

NC2

TON

GND1

BOOT

EN_PSM

UGATE PHASE

IMAX

PVCC

NC1

AGND

PGND

LGATE

567

8

GND

1 2

16.5KOhm

PC8192 220PF/50V

D D

PU6010B

18

GND2

19

GND3

20

GND4

21

GND5

UP6111AQDD

PJP608

SHORT_PIN

/X

12

P_1.8V_IN_S P_1.8V_IN_10mil

C C

GND

12 11 10 9

PR6332 59KOhm

/X

PR606152

12

+5VSUS_VCC

12

PR6326

2.2Ohm

r0603

P_1.8V_UG_20mil

PD16 BAT54CW

1 2

P_1.8V_PHASE_20mil P_1.8V_OC_10mil P_1.8V_VDDP_20mil

12

PC8188 1UF/16V

c0603

GND

P_1.8V_LG_20mil

P_1.8V_FBJP_10mil

3

PC8186

0.1UF/16V

12

PR6329 10KOhm 1%

12

0.1UF/16V

GND

P_1.8V_OCR_10mil

PJP519

SHORT_PIN

/X

PC8651

PJP609 SHORT_PIN

PJP518 SHORT_PIN

/X

PQ651 AP4800AGM

12

/X

12

PQ650 AP4800AGM

567

G

4

567

8

G

SD

123

4

P_1.8V_PHASE_S

PC8187

470PF/50V

8

SD

PR6331

123

r1206_h26

c0603

1Ohm

GND

12

PC8184 10UF/16V

c1206_h71_rd9

GND

P_1.8V_IN_S

1 2

GND

PL31

2.2UH

Irat=8A

12

PC8185

0.1UF/16V

PC8593 10UF/16V

c1206_h71_rd9

GND

05.21

PT238

PT237

TPC26T

1

21

12

+

PCE16

100U/2.5V

1 1

GND GND

PT239TPC26T PT240TPC26T

PR606153

130KOhm

PR606156

267KOhm

P_1.8V_OV_10mil

PQ8924A

61

UM6K1N

2

GND

34

GNDGND GND

GND

PQ8924B

UM6K1N

5

12

PC8645

0.1UF/16V

N/A

12

PC8646

0.1UF/16V

N/A

PR606154

12

10KOhm

+1.8V_UP 36

S3/S0

S5 S5

SUSC_ON36

PR606158

12

10KOhm

4

+1.8V_DOWN# 36

+1.8V_UP

H L H L

3

+1.8V_DOWN#

H H L L

+1.8V

1.8V

1.7V

NO CARE

1.65V

1 2

B B

1 2

PR606157

14KOHM

1 2

A A

5

AC_BAT_SYS

12

PR6397 100KOHM

2

34

PQ8917B

5

UM6K1N

PR606166

0Ohm

/X

12

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

2

Date: Sheet

P_1.8V_EN_10mil

61

PQ8917A UM6K1N

GNDGND

900SD_MB

Title :

Engineer:

1

+1.8V

Joy_Zhou

49

Rev

R1.0G

51Monday, November 10, 2008

of

5

4

3

2

1

http://hobi-elektronika.net

05.21

21

PL25 70Ohm/100Mhz

2 1

PL11

21

70Ohm/100Mhz

12

+

GND

TPC26T PT209

1

100U/2.5V

TPC26T

PCE10

1 1

TPC26T PT213

PT212

AC_BAT_SYS

PT211 TPC26T

1

c0805

12

PC8112

GND

10UF/6.3V

12

/X

GND

+VCCP

c0805

PC8113 10UF/6.3V

P_VCCP_EN_10mil

D D

P_VCCP_IN_S

PR6239

100KOHM

PU6004B

GND2 GND3 GND4 GND5

UP6111AQDD

+3VS

1%

1009

+VCCP_OK6,46

C C

18 19 20 21

GND

B B

PJP610

SHORT_PIN

/X

12

/X

P_VCCP_FB_10mil

12

PC8104

0.1UF/16V

GND

P_VCCP_IN_10mil

12

+5VS

+VCCP

GND

1 2

12

PC8110

0.1UF/16V

c0603

PR606160

49.9KOHM

PR6373

316KOhm

GND

P_VCCP_OV_10mil

PR6207

1.3MOhm

PU6004A

1

VOUT

2

VCC

3

FB

4

POK

UP6111AQDD

61

12

P_VCCP_BOOT_20mil

1314151617

NC2

TON

GND1

BOOT

EN_PSM

UGATE PHASE

NC1

AGND

PGND

LGATE

567

8

GND

PR6310 120KOhm 1%

1 2

PR6211 4.7KOhm 1%

PC8114 220PF/50V

PQ8923A

UM6K1N

2

12

PC8115

0.1UF/16V

N/A

IMAX

PVCC

12

+5VS

12

12 11

P_VCCP_OC_10milP_VCCP_OC_10mil

10

P_VCCP_VDDP_20mil

9

12

GND

2008-11-3

12

PR606147

10KOhm

PR6205

2.2Ohm

r0603

P_VCCP_UG_20mil

PD11

BAT54CW

1 2

P_VCCP_PHASE_20mil

PC8111 1UF/16V

c0603

P_VCCP_LG_20mil

P_VCCP_FBJP_10mil

12

3

PC8108

0.1UF/16V

12

PR6208 10KOhm 1%

PJP611 SHORT_PIN

/X

P_VCCP_OCR_10mil

PJP511 SHORT_PIN

/X

+VCCP_UP 14

PQ623 AP4800AGM

12

PQ624 AP4800AGM

567

G

4

567

G

4

8

SD

123

P_VCCP_IN_S

12

PC8106 10UF/16V

8

c1206_h71_rd9

SD

GND GND

123

P_VCCP_PHASE_S

12

PC8109 470PF/50V

c0603

P_VCCP_SNU_S

12

PR6210 1Ohm

r1206_h26

GND

PJP513

12

GND

PC8650

0.1UF/16V

SHORT_PIN

/X

GND

12

PC8107

0.1UF/16V

12

PC8594 10UF/16V

c1206_h71_rd9

05.21

PL12

2.2UH

Irat=8A

PR606161

1 2

100KOhm

PR606162

33KOhm

1 2

GND

A A

5

GND GND

PQ8923B

34

+VCCP_UP

H L H

UM6K1N

5

GND

12

PC8644

0.1UF/16V

N/A

PR606149

12

10KOhm

+VCCP_DOWN# 14

CPU_VRON36

2008-11-3

+VCCP+VCCP_DOWN#

H L L

4

0.89V

NO CARE

0.85VL

0.96VH

0.955V

0.886V

0.852V

3

AC_BAT_SYS

PT206 TPC26T

1

PR6202

12

100KOHM

2

1.05V_EN#_10mil

34

PQ8918B

5

UM6K1N

GNDGND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet

PR606167

0Ohm

/X

900SD_MB

61

2

GND

07.02

12

PQ8918A UM6K1N

Title :

Engineer:

1

VCCP

Joy_Zhou

50

Rev

R1.0G

51Monday, November 10, 2008

of

5

4

3

2

1

http://hobi-elektronika.net

+2.5V / 100mA

PR6222 22KOhm 1%

12

GND

PC8123

2.2UF/16V

PT241 TPC26T

1

PT242 TPC26T

1

+2.5VS

2

GND

P_1.5V_EN_10mil

61

PQ8919A

12

UM6K1N

GND

PC8116

0.1UF/16V

/X

+3VS

GND

12

PC8122 1UF/16V

c0603

2008-10-23

PU6006

1

EN

NC/SS/FB

2

GND

3 4

VIN VOUT

UP7714BMA5-00

P_2.5VFB_10mil

5

GND

12

PR6224 10KOhm

1%

D D

AC_BAT_SYS

SUSB_ON36,47

C C

PR6218 100KOHM

1 2

PR6219 10KOhm

15mil

12

PC8195

0.1UF/16V

34

PQ8919B

5

UM6K1N

GND

PR606168

0Ohm

/X

12

05.21

PL26 70Ohm/100Mhz

+5VS

PC8174 10UF/16V

c1206_h71_rd9

PL28

2.2UH

Irat=8A

12

P_1.5VS_IN_S

12

GND

21

GND

2

PC8175

0.1UF/16V

PT231 TPC26T

1

12

+

PCE14 100U/2.5V

1 1

12

PC8595 10UF/16V

c1206_h71_rd9

GND

05.21

PT232 TPC26T

1

12

PC8179

PC8180

10UF/6.3V

c0805

/X

PT233TPC26T PT234TPC26T

GND

Default Group-A7V8X MX

ASUSTek Computer INC.

Size Project Name

A3

Date: Sheet of

12

P_1.5V_EN_10mil

P_1.5VS_IN_S P_1.5VS_BOOT_20mil

B B

PU6009B

18

GND2

19

GND3

20

GND4

21

GND5

UP6111AQDD

GND

A A

PJP515

SHORT_PIN

/X

5

12

P_1.5VS_IN_10mil

+1.5VS

P_1.5VS_FB_10mil

PR606142

1 2

GND

+5VS

GND

15KOhm

12

PC8181

0.1UF/16V

c0603

PR6374

316KOhm

1 2

GND

PR606141

147KOhm

PQ8922 2N7002

PR6315

1.3MOhm

PU6009A

1

VOUT

2

VCC

3

FB

4

POK

UP6111AQDD

D

S

GND

12

TON

GND1

EN_PSM

NC1

AGND

PGND

567

GND

PR6320 120KOhm

PR6321 12.4KOhm 1%

PC8182 220PF/50V

32

3

1

G

2

4

1314151617

NC2

BOOT UGATE

PHASE

IMAX

PVCC

LGATE

8

1 2

0.1UF/16V

1%

12

PC8643

PR6314

12

P_1.5VS_PHASE_20mil

11

P_1.5VS_OC_10mil

10

P_1.5VS_VDDP_20mil

9

12

PC8178 1UF/16V

c0603

GND

P_1.5VS_LG_20mil

2008-11-3

12

GND

2.2Ohm

r0603

P_1.5VS_UG_20mil

PD15

BAT54CW

1 2

P_1.5VS_FBJP_10mil

PR606144

10KOhm

3

PR6317 10KOhm 1%

12

PC8176

1 2

P_1.5VS_OCR_10mil

12

P_1.5VS_DOWN

0.1UF/16V

c0603

3

PQ647 AP4800AGM

PJP612 SHORT_PIN

12

PJP613

/X

12

SHORT_PIN

/X

PQ648 AP4800AGM

+1.5VS_DOWN# 14

Hi:1.48V Low:1.415V

567

G

4

567

8

G

SD

123

4

P_1.5VS_PHASE_S

8

SD

123

GND

12

GND

12

PC8177 470PF/50V

c0603

12

PR6319 1Ohm

r1206_h26

PC8649

0.1UF/16V

12

GND

PJP516

SHORT_PIN

/X

2 1

PL27

21

70Ohm/100Mhz

+1.5VS

900SD_MB

AC_BAT_SYS

+1.5VS

Title :

Engineer:

1

1.5V_2.5V

Joy_Zhou

51 51Monday, November 10, 2008

Rev

R1.0G

ECS 900SD Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
