Ecomist 6 Instructions for use
Your Ecomist 6 kit contains
• 1 Ecomist Electronic Aerosol Dispenser
• 4 AA type Alkaline batteries
• Screw for installation of dispenser onto plaster board.
• Instructions
Aerosol can of choice sold separately.
Installation
Where to install
Do:
• Install in a location where air currents will circulate the
aerosol spray to areas where it is most required.
• Mount dispenser about 2 meters above the oor preferably
where there is a clear area between the dispenser and
the oor.
Don’t:
• Install near or next to an open window or extractor fan as
aerosol spray will be lost.
Caution: Do not install over appliances or furniture, e.g.
Refrigerators, items made of plastic or polished surfaces.
Mounting Dispenser
• Fit screw to wall, do not screw all the way in but leave a gap
of approx 8mm between screw head and wall.
• To hang, slot screw head into slot on wall mounting bracket in
the back of the dispenser.
Batteries
Alkaline batteries must be used to ensure correct & long life
operation of dispenser.
• Make sure power switch is in OFF position.
• Install the 4 Alkaline type AA batteries. Ensure that the
battery polarities are correct as shown in dispenser.
Aerosol Can
• Turn the dispenser OFF.
• Remove old aerosol can by unscrewing anticlockwise.
• Remove spray nozzle from the top of the new aerosol can.
• Screw the can into the solenoid valve clockwise until nger
tight ensuring a complete seal. Do not over-tighten.
• Face the dispenser away from you and turn the power switch
ON, the dispenser will spray once.
Caution: If accidentally sprayed in eyes ush immediately
with water.
Dispenser Program Settings
• Dispenser is set to factory settings of 7 min and 60mg.
• To adjust amount dispensed, turn the knob
anti-clockwise to decrease and clockwise to
increase.
• Frequency can be adjusted using the switch
between 1 min (recommended for outdoors) and
7 min (recommended for indoors).
Outdoor Operation
• Place unit in an up breeze location. Be aware that dispenser
effectiveness may be reduced as breeze increases.
• Switch unit onto 1 min setting and turn on. It is suggested
to start dispenser 10 mins before you wish to use the area to
clear it of insects.
Caution: Aerosol contains ammable gas, DO NOT use close
to naked ames. Keep dispenser dry. Keep dispenser away
from children.
Dispenser Quantity
90mg
High
30mg
Low
ON
OFF
1 MIN 7 MIN
Remote
ON/OFF Switch
Remote screw terminal
Dispense time
adjustment switch
Dispense quantity
adjustment
Enlarged diagram of circuit board
ON
OFF
1 MIN 7 MIN
Dispenser Quantity
90mg
High
30mg
Low
Circuit Board
Insert can in here and
screw clockwise to
tighten
Wall mounting bracket
Solenoid Valve
E6 Dispenser
Instruction Booklet
For future reference, keep this
booklet inside your dispenser
Remote Operation
• Remote control of the dispenser
is possible by wiring a remote
switch to the REMOTE screw
terminal on the circuit board.
General
Insect control
• It is recommended that dispensers for insect control are
run for 24hrs per day to be most effective. This will create a
repellent effect, helping to keep insects out, with fewer dying
indoors.
• Changes in air current, size/layout of area, temperature and
humidity all affect the efciency of the dispenser. Alterations
to frequency and dispensed quantity may be required to
match local conditions.
Seasonal Operation
• At the end of the summer season ying insects may not
be so prolic. However, insects such as ants, eas, silver sh
and cockroaches can be year round pests. We recommend
continued use of your Ecomist dispenser with natural
Pyrethrins insect killer throughout the year. Alternatively
buildings can be fragranced using other Ecomist products
such as:
Ecomist Odour Neutraliser
Ecomist Fragrances
Ecomist Mood Makers
For more information contact your local Ecomist distributor
or visit our website:
New Zealand: www.ecomistsystems.com
Australia: www.ecomist.com.au
Remote Switch
For Enquiries call:
NZ – 0800 75 75 78
AUS – 1800 243 500
