Ecolink Intelligent Technology TLSZWAVE5 User Manual

Z-Wave Plus Toggle Light Switch Installation Instructions

Product Overview

 Z-Wave Plus™ enabled device which can be used turn a light switch on or off
 Z-Wave Plus™ enabled device which can be used sense status of a light switch

Product Specifications

 For indoor use only
 Operating frequency: 908.42 MHz
 Operating temperature: 0° – 49°C, 32° – 120°F (ambient temperature)
 Operating humidity 5-95% non-condensing
 2 AA batteries
 Battery Life: 1 year

Network Inclusion

The Z-Wave Plus Toggle Light Switch must be added to a Z-Wave Plus network prior to use. To include the device in a network both the device and the network
controller must be in inclusion mode at the same time. Refer to the instructions provided by the manufacturer of your specific controller for details on initiating
the controller’s inclusion mode.

1) Verify that the Z-Wave Plus controller you are using is compatible with the Z-Wave Plus Toggle Light Switch.

2) Locate the light switch desired to be used with the Z-Wave Plus Toggle Light Switch.

3) Put your Z-Wave Plus Controller into add (inclusion) mode.

4) Press the inclusion / exclusion button on the Z-Wave Plus Toggle Light Switch. (Figure 1)

5) The LED on the front of the unit will turn off if successful included into a network.

Network Exclusion

1) Any Z-Wave Plus Device can be removed from any Z-Wave Plus controller. Follow the directions to put your Z-Wave Plus Controller into exclusion

mode.

2) Press the inclusion / exclusion button on the Z-Wave Plus Toggle Light Switch.

Network Inclusion/Exclusion: Key Points to Remember

 Controller inclusion mode must be activated BEFORE starting sensor inclusion or exclusion mode.
 The device can only be included into one controller network at a time, and must be excluded from one network before inclusion in another
 Exclusion mode on the senor is initiated following the same exact procedure as inclusion.

© 2017 Ecolink Intelligent Technology Inc. PN TLS-ZWAVE5 R2

LED Status

The Z-Wave Plus Toggle Light Switch is equipped with a red LED. The state of the LED will change based on the state of the device.

LED Blinking - Device not included into a network.
LED On - Device In Learn mode.
LED blink - Device in lower power mode. Remote control disabled.

Battery State

The Z-Wave Plus Toggle Light Switch will alert the user when the batteries become low. While the batteries are low, the user will be unable to change

the light state remotely. The Z-Wave Plus toggle Light Switch will continue reporting the state of the switch until the batteries are completely depleted.

Factory Default

The Z-Wave Plus device is automatically factory defaulted when removed from a Z-Wave Plus network. Please use this procedure only when the network

primary controller is missing or otherwise inoperable.

Inclusion / Exclusion button

Figure 1

Installation

The package contains the following:

 Ecolink Z-Wave Plus Toggle Light Switch
 Screw for the Z-Wave Plus Toggle Light Switch
 2 AA batteries

© 2017 Ecolink Intelligent Technology Inc. PN TLS-ZWAVE5 R2
