Ecocom ECAS01 User Manual

Copyright © 2018 ShenZhen EcoCom, Inc. All rights reserved.
Customer Support: [e-mail]

Table of contents

Safety information 3

Warranty 4

Before starting 5

Main features 5
Specifications 5
Product details 6
Package contents 6

Installing your headset 7

Using the clamp 7
Using the glued surface mounting adapter 7
Installing the speakers 8

Using your headset 9

Jog dial functions 9
Multi-function button functions 9
Charging the headset 9
Turning on your headset 10

2

Turning off your headset 10
Adjusting the volume 10
LCD display 10
Pairing your headset with other Bluetooth

devices
Using phone functions 11
Listening to music 12
Listening to FM radio 12
Having intercom conversations 13
Using intercom functions 13

11

Managing your headset 14

Factory reset 14
Fault reset 14

Certification 15

Safety information

Read the following safety information to properly use the product.

Safety symbols in this guide

WARNING

CAUTION

WARNING

• High volume use of the product for a long period of time may cause damage to your hearing or even your eardrums.

• Careless use of the product while driving is dangerous to yourself and others and may result in serious injury, death or

property damage. You must adhere to all safety precautions in all documents that came with this product. This will help
minimize risks that may occur while riding and using this product.

• In places where wireless communication is restricted, such as hospitals or aboard airplanes, turn the power off. In places
where wireless communication is restricted, electromagnetic waves may cause disruptions, hazardous conditions, or
accidents.

• Before riding, attach the product to the helmet, and double-check that it is securely affixed. Detachment of the product
while riding can cause damage to the product and could result in a serious accident.

• Do not expose the product to direct sunlight for an extended period of time. Doing so can cause damage to the product
and produce enough heat to cause burns.

• Do not use or store this product inside motor vehicles in hot weather. It may result in the battery generating heat, rupturing,
or igniting.

• Do not persist in charging the battery if it does not fully recharge within the designated charging time. Doing so may result
the battery becoming hot, exploding, or igniting.

Indicates a potential hazard which, if not avoided, may result in injury or death.

Indicates a potential hazard which, if not avoided, may result in minor injury or property damage.

3

• Do not leave the product next to or near open flames. Do not attempt to dispose of the product in a fire. It may result in the
battery exploding or igniting which could cause serious injury.

• Never attempt to charge a battery with a charger that is faulty or has been physically damaged. It may cause an explosion
or other sorts of accidents.

• When making use of the product, use good judgment. Never use this product while under the influence of alcohol or drugs.
Do not attempt to use this product while tired or sleepy.

CAUTION

• If the product emits an unusual smell, feels hot, or appears abnormal in any other way during use or while charging, stop
using the product immediately. It may become damaged, explode, or result in a fire. Contact your retailer if any of these
issues are observed.

• Do not attempt to use this product in an atmosphere conducive to explosions. If you are in a location that gives you
concern that an explosion could occur, turn off the power and heed any regulations, instructions, and signs in the area.

• Do not dispose of the product with normal household waste. The built-in battery should not to be disposed of through the
normal public waste system and requires separate and specialized collection. When disposing the product, be sure to
follow all local regulations and safety standards.

Warranty

EcoCom guarantees the product quality based on the technical specification stated in the product manual, and data
regarding product warranty. Here, product warranty extends to the product only. EcoCom will not be liable for any loss,
damage of human life, or loss of property which may result from using the product beyond defective parts or flaws that occur
due to problems in manufacture.

EcoCom guarantees free-of-charge replacements of defective parts of the product or flaws that may have occurred due to
problems in manufacture for a period of 1 years from the date of initial purchase.

4

Before starting

Congratulations on choosing EcoCom. We strive to provide the best product to our customers. We hope
you enjoy our product while safely driving your motorcycle.

Main features

•

Bluetooth 3.0

•

Long lasting talk time (8 hours)

•

Crystal clear natural sound

•

Jog dial operation

•

Bluetooth Handsfree for Bluetooth mobile
phones

•

Bluetooth stereo headset for Bluetooth audio
devices

•

Bluetooth one-to-one intercom of up to
1 kilometer in open terrain

•

Cutting-edge noise control

•

FM radio tuner

Specifications

Item Specification

Talking Time 8 hours

Bluetooth
Profile

Intercom 1:1 Intercom

FM Radio

Charging Time

Dimensions 76 mm x 41 mm x 27 mm

Weight 39 g

HSP, HFP, A2DP, AVRCP

76.0 ~ 108.0 MHz
(Worldwide)

About 2.5 hours
(Lithium polymer battery)

5

Before starting

Product details

Speaker

Multi-function

button

Status LCD

Headset and
charger port

6

Jog dial

Speaker

Microphone

Package contents

Contents Qty

EcoCom 1

Speakers and Microphone 1

Microphone Sponges 2

Hook and Loop Fasteners for
Speakers

Clamp 1

Glued Surface Mounting Adapter 1

USB cable 1

2

Installing your headset

Before installing the headset, you need to choose between the clamp and the glued surface mounting
adapter. To install the headset to the helmet, follow the steps below:

Using the clamp

1. Insert the main
module into the
clamp using the two
connecting slots on
the back.

2. Insert the headset
into the helmet using
the clamp.

Using the glued surface mounting adapter

1. Insert the main
module into the glued
surface mounting
adapter using the two
connecting slots on
the back.

2. Remove the cover of
the adhesive sticker
on the back to glue
the headset on to the
helmet.

3. Attach the headset
on the left side of the
helmet.

7

Installing your headset

Installing the speakers

If you want to install speakers into the headset, follow the steps below:

1. Remove the cover of
the adhesive sticker
of the hook and
loop fasteners for
speakers.

2. Place the sticker on
the helmet.

8

3. Place the speaker on
the hook and loop
fasteners.

4. Insert the speaker
plug into the headset.

Using your headset

Jog dial functions Multi-function button functions

•

Increase/Decrease
Volume

•

Track Forward/Back

•

Scan Radio Stations

•

Play/Pause Music

•

Reject an Incoming
Phone Call

•

Intercom Pairing Mode

Press and Hold

Tap/

Rotate/
Rotate
while
Pressing

Charging the headset

3

2

1

It takes about 2.5 hours to be completely charged.

•

Answer/End a Phone
Call

•

FM Radio On/Off

•

Phone Pairing Mode

Charging Status LCD

Charging Fully charged

Tap/

Press and Hold

9

Using your headset

Turning on your headset

Press and hold the Multi-function button and Jog
dial for 1 second.

Adjusting the volume

•

To increase, rotate the Jog dial
counterclockwise.

•

To decrease, rotate the Jog dial clockwise.

10

Turning off your headset

Tap the Multi-function button and Jog dial.

LCD display

Battery Indicator

Pairing

Status

Active

Function

Volume Bar

Using your headset

Pairing your headset with other Bluetooth
devices

The EcoCom can pair with multiple Bluetooth
devices, such as a mobile phone or an MP3.

1. Press and hold the Multi-function button for
5 seconds. The headset enters into Mobile
phone pairing.

2. On your Bluetooth device, search for EcoCom.

3. Select EcoCom from the search results and
enter the password to be paired (0000). Some
Bluetooth devices may not ask for a PIN.

(phone pairing)

Using phone functions

•

To answer/end the call, tap the Multi-function
button or Jog dial.

•

To reject an incoming call, press and hold the
Jog dial for 2 seconds.

•

To redial the last number called, press and hold
the Jog dial for 3 seconds.

(incoming call) (make a call) (conversation)

11

Using your headset

Listening to music

•

To start/pause music, press and hold the Jog
dial for 1 second.

•

To track forward, rotate while pressing the Jog
dial counterclockwise.

•

To track back, rotate while pressing the Jog dial
clockwise.

12

Listening to FM radio

•

To start/stop the FM radio, press and hold the
Multi-function button for 1 second.

•

To seek up the radio channel, rotate while
pressing the Jog dial counterclockwise.

•

To seek down the radio channel, rotate while
pressing the Jog dial clockwise.

Using your headset

Having intercom conversations

Your EcoCom can only have an intercom
conversation with other EcoCom headset.

The EcoCom can be paired with up to three other
headsets for Bluetooth intercom conversation.

1. Press and hold the Jog dial for 5 seconds. The
headset enters into Intercom pairing.

2. Any one of the two headset users must tap the
Jog dial.

(intercom pairing)

Using intercom functions

You can start/end intercom conversation.

•

To start an intercom connection with the first
user, tap the Multi-function button, and to make
a connection with a second user, double tap the
Multi-function button. For the third user, triple
tap the Multi-function button.

•

To end the intercom conversation, tap the Multi­function button.

(conversation

intercom friend A)

13

Managing your headset

Factory reset

You can reset the EcoCom to the factory default
settings.

1. Press and hold the Multi-function button for
12 seconds.

2. Tap the Jog dial to confirm the reset.
The EcoCom will automatically restores the
default settings and turns off.

14

Fault reset

If the EcoCom is not working properly for any
reason, connect it to a USB cable.

The EcoCom will automatically be turned off and a
fault reset will occur.

Certification

FCC Compliance Statement

This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,

including interference that may cause undesired
operation.

This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment on and off, the user is
encouraged to try to correct the interference by one or more
of the following measures:

• Reorient or relocate the receiving antennae

• Increase the separation between the equipment and the

receiver

• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician
for help.

FCC Caution

Any changes or modifications to the equipment not
expressly approved by the party responsible for compliance
could void user’s authority to operate the equipment.

CE Declaration of Conformity

This product is CE marked according to the provisions
of the R&TTE Directive (2014/53/EU). Hereby, EcoCom
declares that this product is in compliance with Directive
2014/53/EU. For further information, please consult
www.ecocom.com. Please note that this product uses radio
frequency bands not harmonized within EU. Within the EU
this product is intended to be used in Austria, Belgium,
Denmark, Finland , France, Germany, Greece, Ireland, Italy,
Luxembourg, The Netherlands, Portugal, Spain, Sweden,
United Kingdom and within EFTA in Iceland, Norway and
Switzerland.

Industry Canada Statement

This device complies with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two
conditions:

(1) This device may not cause interference.
(2) This device must accept any interference, including

interference that may cause undesired operation of the
device.

15
