OWNER'SMANUAL
We appreciate your purchase of this receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
ESN E8 High-Power "Pro Customize" CD/MS Receiver with
MP3/WMA Decoder and Remote
CD8455
For your safety in using the
CD8455
Warnings and caution signs, illustrated below, are posted throughout this manual as
well as on the CD8455. They show safe and correct ways to handle the product so
as to prevent personal injury to you, others and to avoid property damage.
Before reading through the manual, take time to read through and learn the
important information listed in this section.
This sign indicates a situation in which incorrect
Warning
Caution
handling or disregard of this sign might result in
death or serious personal injury.
This sign indicates a situation in which incorrect
handling or disregard of this sign might result in
personal injury or may result solely in damage to
property.
2
Warning
● Do not modify this system for use other than that specified
herein. Also, do not deviate from the installation procedures
described herein; Eclipse will not be held liable for damages
including, but not limited to serious injury, death or property
damage resulting from installations that enable unintended
operation.
● This equipment requires 12V DC and should only be installed in a
vehicle with a 12V negative ground electrical system. Any other
installation may cause a fire or other severe damage to the
equipment and the vehicle.
● Never install this equipment where it will interfere with safe
operation of the vehicle. Never block the drivers’ view. Do not
install equipment where it may interfere with operation of the
brakes, the steering or any safety equipment, including seat belts
and air bags.
● Before drilling holes in a vehicle for installation, you must confirm
the locations of pipes, tanks, electrical wiring, and other vehicle
systems and components to ensure that there will be no
interference or contact. In addition, you must also apply rust
prevention and leak prevention measures at the drilling area.
Otherwise, fire or electric shock could occur.
● When installing equipment do not remove or alter existing vehicle
fasteners, including nuts, bolts, screws, clips, and fittings. Never
detach, move or alter existing vehicle wiring, including electrical
grounds and straps. Alteration of existing vehicle components
may make vehicle unsafe to operate.
● Before installation, remove the negative (-) battery terminal to
prevent shocks, electrical arcing, fires, and damage to vehicle
wiring and the equipment you are installing.
● Secure wiring with tape or plastic ties so that wires do not
interfere with vehicle operation, including brake pedal, gear
shifter and steering. Position wires so that they will not be
rubbed, abraded, or damaged by moving vehicle components,
including power seats.
3
Warning
● To avoid equipment and vehicle damage, including fire, never
supply power to installed equipment in a way which will overload
the capacity of an existing vehicle circuit. Never leave a power
supply wire or connection uninsulated. Always install supplied
fuses, circuit breakers, and relays.
●
Air bags are vital safety equipment. Never install equipment in a way
which will alter air bag wiring or interfere with air bag deployment.
Air bags must function properly in the event of an accident.
● When installation is complete, test all vehicle electrical systems
for proper operation, including lights, horn, brake lights, and
emergency flashers.
● For your protection, never use a power drill without safety
glasses or goggles. Debris or broken drill bits may cause severe
eye injuries, including blindness.
● Use electrical tape to insulate the ends of all wires, even if not
used. Proper insulation prevents arcs, shocks and fires.
● Some equipment uses batteries. Never install equipment where
young children can get access to batteries. If a battery is
swallowed, seek medical attention immediately.
● When vehicle is moving, never take your eyes off the road to
make adjustments to the equipment. You must pay attention to
the road to avoid accidents, do not let the operation or adjustment
of the equipment distract you from proper vehicle operation.
● The driver should not look at the screen while driving. Accidents
may result if you are not paying attention to the forward direction.
● Do not put foreign objects in the loading slot of Memory Stick or
disc. Fires or shocks may result.
● Do not disassemble or alter this equipment. Accidents, fires or
shocks may result.
● Do not let water or foreign objects enter the internal parts of this
equipment. Smoke, fires or shocks may result.
● Pay attention to where the remote control is left. Traffic accidents
or problems with driving may result if the remote control makes
its way under the foot pedals etc. when the vehicle is stopped or
when it goes around a corner.
4
Warning
● Do not use when it is broken (the screen is not lit or no sound
comes out). Accidents, fires or shocks may result.
●
Always replace fuses with fuses of identical capacity and
characteristics. Never use a higher capacity fuse than the original.
Using the wrong type of fuse may cause a fire or severe damage.
● If foreign objects or water enters the equipment, smoke comes
out, or there is a strange odor, stop using it immediately, and
contact your dealer. Accidents, fires, or shocks may result if you
continue to use it in these conditions.
●
The driver should not change the Memory Stick or CD while driving.
As accidents may result if you are not paying attention to the forward
direction, first stop the car at a safe location and then proceed.
● Plastic bags and wrappings may cause suffocation and death.
Keep away from babies and children. Never put bag over your
head or mouth.
5
Caution
● Wiring and installing this equipment requires expertise and
experience. Professional installation is recommended. Consult
with your dealer or a professional installer. Incorrect wiring may
damage the equipment or interfere with safe vehicle operation.
● Use only the accessory parts as specified. Using other parts may
cause damage to the equipment or cause parts to fall or fly off the
equipment.
● Do not install the unit in places where it may get dew
condensation on (around the air conditioning hose, etc.), come in
contact with water, or in condition of high moisture, dust or oily
smoke. If water, moisture, dust or oily smoke enters this unit,
smoke, fires or malfunctions may result.
● Avoid installing in places where it cannot be fastened securely or
where there are strong vibrations. Also, if you installed the unit
with double-sided tape, first wipe away dirt and wax from the
installation area. Otherwise, the unit may come loose due to
vibration while driving, causing problems for driving and
resulting in traffic accidents or injuries.
● Do not install in places with direct sunlight or where it will be hit
directly by hot air from the heater. This may increase the
temperature of the interior of this equipment, resulting in fires
and malfunctions.
● Do not block the fan, heat sink or vents of this unit. When fan,
heat sink or vent is blocked, the interior overheats, and fires may
result.
● Connect as specified in the installation manual. If not connected
normally, fires or accidents may result.
● When installing in vehicles equipped with air bags, check the
manufacturer's cautions regarding operation before operating.
Airbags may not operate properly.
● Carry out the wiring such that cords are not pinched by movable
parts such as seat rails, and screw parts of the vehicle body.
Accidents, fires and shocks may result from disconnection and
electrical shorts.
● Carry out the wiring such that the cord does not make contact
with metal parts. The cord maybe be damaged by contact with
metal parts, resulting in fire and shocks.
6
Caution
● Avoid hot surfaces when wiring equipment. High temperatures
may damage wiring, causing shorts, arcing and fires.
● When changing the installation location for this equipment,
please consult the dealer where you bought it for safety reasons.
Expertise is necessary for removal and installation.
● Keep volume to a reasonable level so that you can hear sounds
from outside the vehicle, including warning sounds, voices, and
sirens. Failure to do so may cause an accident.
● Be careful that hands and fingers are not pinched when adjusting
the tilting angle or closing display. Injuries may result.
● Do not put your hands or fingers into the loading slot of Memory
Stick or disc. Injuries may result.
● Do not touch the heat dissipating part of the amp. Burns may
result from the heat of this part.
● Do not recharge dry batteries. Dry batteries may rupture,
resulting in injuries.
● Do not use batteries other than those specified. Also, do not mix
old and new batteries. Injuries or pollution to the surroundings
may result from battery ruptures and leakage.
● When inserting batteries into the equipment, be careful with the
polarity (positive/negative), and insert them as indicated. If the
battery polarities are incorrect, injuries and pollution to the
surroundings may result from battery ruptures and leakage.
● Replace used batteries as soon as possible; they may leak and
damage equipment. Battery leakage can burn your skin or your
eyes. Wash hands after handling.
● If alkaline solution from alkaline dry batteries makes contact with
your skin or clothes, flush with clean water. If any of the solution
gets in your eyes, also flush clean with water and then seek
medical attention.
● When disposing of lithium dry batteries, affix insulating tape to
the positive and negative terminals, and after they are insulated,
dispose of them according to the "Local municipal ordinances".
Shorts, fires and ruptures may result from disposal when coming
contact with other electrically conductive objects such as metal
parts, etc.
7
Caution
● Do not short, disassemble or heat the batteries, or place them in
fire or water. Fire and injuries may result from battery rupture and
leakage.
● Store the remote control in a place away from direct sunlight, high
temperatures, and high moisture levels. The case may change
shape, and the batteries may rupture and leak.
● Do not use this equipment except for in-vehicle use. Shocks or
injuries may result.
● Be careful of the position of the volume when turning the power
source ON. Hearing damage may result if very loud noise is
emitted when the power is turned ON.
● Do not operate under abnormal conditions such as when the
sound is broken or distorted. Fires may result.
● This equipment uses invisible laser light. Do not disassemble or
alter this equipment. If trouble occurs, contact the dealer where
you bought the equipment.
Altering this equipment may cause exposure to laser emissions
(worsening eyesight), or result in accidents, fires or shocks.
● If the equipment is dropped or the cosmetics appear broken, turn
off the power to the main unit and contact your dealer. If used in
this condition, fires or shocks may result.
8
Table of Contents
Operating precautions.............................................................................. 16
Names of controls and parts.................................................................... 23
ESN security operating precedure .......................................................... 24
Basic operation ......................................................................................... 41
How to operate the CD player .................................................................. 72
How to operate the MP3/WMA player ...................................................... 84
How to operate the Memory Stick player ................................................ 93
How to operate the tuner........................................................................ 106
How to operate the Sound Adjustment Mode ...................................... 119
How to operate the AREA SHOT function (U.S.A. only) ...................... 173
How to use the remote control .............................................................. 184
How to operate the receiver with an optional CD changer connected
How to operate the tuner with an optional HD RADIO tuner
connected (U.S.A. only)... 196
How to operate the tuner with an optional SIRIUS satellite radio tuner
connected (U.S.A. only)... 203
Others....................................................................................................... 209
.... 192
I
II
III
IV
V
VI
VII
VIII
IX
X
XI
XII
XIII
XIV
XV
If you have a question: ........................................................................... 213
Specifications.......................................................................................... 218
Before installlation.................................................................................. 220
Mounting instruction .............................................................................. 221
How to contact customer service .......................................................... 234
9
XVI
XVII
XVIII
XIX
XX
Table of Contents
Operating precautions......................................................................... 16
Notes on operation........................................................................................................16
About compact discs .....................................................................................................17
About cleaning a CD .....................................................................................................19
About Memory Sticks ....................................................................................................20
About cleaning the Memory Sticks................................................................................22
Names of controls and parts .............................................................. 23
ESN security operating procedure ..................................................... 24
About ESN ....................................................................................................................24
How to switch the security type (Key CD security/Memory Stick security) ................... 25
How to operate the ESN (Key CD) security ..................................................................26
How to program the Key CD................................................................................... 26
How to cancel the Key CD......................................................................................27
How to change the Key CD ....................................................................................28
How to resume normal operation (ESN security lock out)......................................28
What happens if an incorrect CD is inserted? ........................................................29
How to operate the ESN (Memory Stick) security......................................................... 30
How to record a security code ................................................................................30
How to cancel the Memory Stick security...............................................................32
How to change the Memory Stick ........................................................................... 34
How to resume normal operation (ESN security lock out)......................................35
What happens if a Memory Stick or security code is incorrect? .............................37
How to operate the ACC security.................................................................................. 38
How to turn the security indicator on/off........................................................................39
How to read the Electronic Serial Number ....................................................................40
Basic operation .................................................................................... 41
Turning the power on and off ........................................................................................41
Listening to CD ............................................................................................................. 42
Listening to MG Memory Stick ......................................................................................43
Listening to the tuner ....................................................................................................44
Adjusting audio volume .................................................................................................45
Switching audio control modes ..................................................................................... 46
VOL (VOLUME) Mode............................................................................................ 46
BASS Mode ............................................................................................................ 46
MID (MIDDLE) Mode ..............................................................................................47
TREB (TREBLE) Mode...........................................................................................47
BAL (BALANCE) Mode...........................................................................................47
FAD (FADER) Mode............................................................................................... 47
NON-F (NON-FADER) Mode..................................................................................47
SVC (Source Volume Control) Mode......................................................................48
10
Enabling the loudness control....................................................................................... 49
Making changes with Display Adjustment Mode ...........................................................50
Switching the motion picture...................................................................................51
Switching the brightness.........................................................................................52
Changing illumination color.....................................................................................53
Disabling the display...............................................................................................54
Importing DISP screens.......................................................................................... 55
Displaying Amplifier Status (E-AMP DISP).............................................................58
Making changes with Function Mode............................................................................59
Disabling the guide tone feature (for button operation) ..........................................61
Clock display on/off.................................................................................................62
Setting the time.......................................................................................................63
Switching demonstration screen display................................................................. 64
Setting the steering switch function (U.S.A. only)...................................................65
Others ........................................................................................................................... 69
Operation assist function ........................................................................................ 69
Displaying a memo.................................................................................................70
Setting a memo.......................................................................................................70
Deleting a memo.....................................................................................................71
How to operate the CD player ............................................................. 72
Listening to CDs............................................................................................................72
Advancing to the next track or returning to the beginning of the track being played ....73
Fast Forward/Rewind....................................................................................................73
Playing the beginning of tracks (SCAN)........................................................................73
Repeating the same track (REPEAT) ...........................................................................74
Playing tracks in random order (RANDOM)..................................................................74
Switching a CD to pause / play .....................................................................................75
Ejecting the disc............................................................................................................75
Creating a title for a CD ................................................................................................ 76
Changing a previously set title ......................................................................................78
Deleting a previously created title.................................................................................80
Changing the number of CD titles................................................................................. 81
Displaying CD text ........................................................................................................83
How to operate the MP3/WMA player................................................. 84
About MP3/WMA .......................................................................................................... 84
What is MP3/WMA?................................................................................................84
Playable MP3 file standards ...................................................................................84
Playable WMA file standards..................................................................................84
ID3/WMA tags.........................................................................................................85
Media...................................................................................................................... 85
Format of discs....................................................................................................... 86
File names ..............................................................................................................87
Multi-sessions......................................................................................................... 87
Playing MP3/WMA.................................................................................................. 87
11
MP3/WMA playing time display .............................................................................. 87
Display order of MP3/WMA file/folder names......................................................... 87
Listening to MP3/WMA file............................................................................................88
Advancing to the next track (file) or returning to the beginning of the track (file)
being played.................................................................................................................. 89
Skipping to the next or previous folder..........................................................................89
Fast Forward/Rewind....................................................................................................89
Return to the root directory of the CD ........................................................................... 89
Playing the beginning of files (SCAN) ........................................................................... 90
Repeating the same file (REPEAT) .............................................................................. 90
Playing files in random order (RANDOM) ..................................................................... 91
Displaying title...............................................................................................................92
How to operate the Memory Stick player........................................... 93
Listening to MG Memory Stick ......................................................................................93
Advancing to the next track or returning to the beginning of the track being played ....94
Fast Forward/Rewind....................................................................................................94
Playing the beginning of tracks (SCAN)........................................................................94
Repeating the same track (REPEAT) ...........................................................................95
Playing tracks in random order (RANDOM)..................................................................95
Ejecting the Memory Stick ............................................................................................96
Recording on Memory Stick.......................................................................................... 97
Selecting tracks to be recorded .................................................................................... 99
Setting sound quality...................................................................................................100
Deleting recorded file ..................................................................................................102
Formatting MG Memory Stick (quick format) ..............................................................104
How to operate the tuner................................................................... 106
Tuning to a station ......................................................................................................106
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................................................107
Manually setting stations into memory ........................................................................ 108
Preset station scan .....................................................................................................109
Setting a station name ................................................................................................110
Deleting a station name ..............................................................................................112
Changing the number of bands................................................................................... 113
Changing the reception sensitivity for automatic scanning ......................................... 115
Changing the radio band location ...............................................................................116
FM reception characteristics .......................................................................................117
FM reception differs from AM ...............................................................................117
Fading out.............................................................................................................117
Reception area of FM broadcasts.........................................................................118
Multipath...............................................................................................................118
12
How to operate the Sound Adjustment Mode ................................. 119
About Sound Adjustment Mode .................................................................................. 119
SRS Circle Surround II (CS II) ..............................................................................120
Parametric equalizer............................................................................................. 120
Time Alignment.....................................................................................................122
Crossover ............................................................................................................. 123
Multi-harmonizer...................................................................................................125
Non-fader phase ...................................................................................................125
Non-Fader output.................................................................................................. 125
Speaker layout......................................................................................................125
E-iSERV sound effect customizations ..................................................................125
Operations during Normal Mode................................................................................. 128
SRS Circle Surround II (CS II) ..............................................................................129
Parametric equalizer adjustment (PEQ) ...............................................................130
Selecting an equalizer mode from memory .......................................................... 132
Measuring/display frequency characteristic..........................................................133
Simplified time alignment settings (Time Alignment) ............................................136
Crossover adjustment (X-Over)............................................................................142
Multi-harmonizer settings (Harmonizer)................................................................143
Non-fader phase selection (NON-F Phase).......................................................... 144
Non-Fader Output.................................................................................................145
Importing Sound Data...........................................................................................146
Operations during Pro Mode.......................................................................................148
Parametric equalizer adjustment (PEQ) ...............................................................150
Selecting an equalizer mode from memory .......................................................... 157
Measuring/display frequency characteristic..........................................................158
Time alignment adjustment (Time Alignment) ......................................................161
Crossover adjustment (X-Over)............................................................................163
Multi-harmonizer settings (Harmonizer)................................................................166
Non-fader phase selection (NON-F Phase).......................................................... 167
Non-Fader Output.................................................................................................168
Speaker layout......................................................................................................169
Importing Sound Data...........................................................................................170
Custom Mode .......................................................................................................172
How to operate the AREA SHOT function (U.S.A. only) ................. 173
About the AREA SHOT ...............................................................................................173
To use the AREA SHOT function .........................................................................174
Map data...............................................................................................................175
GPS (Global Positioning System).........................................................................175
Reading the AREA SHOT data ...................................................................................176
Changing the AREA SHOT mode ...............................................................................178
Using the AREA SHOT mode .....................................................................................179
AREA SHOT Screen Configuration ......................................................................179
Switching between guidance points...................................................................... 180
Re-scrolling through text information ....................................................................181
13
Changing AREA SHOT screens ...........................................................................182
Display Arrows......................................................................................................183
How to use the remote control ......................................................... 184
Precautions in use of the remote control ....................................................................184
Cleaning the remote control ........................................................................................ 184
Turning the power on/off .............................................................................................185
Adjusting the audio volume .........................................................................................185
Muting the volume ................................................................................................185
Switching playback modes.......................................................................................... 186
How to play the tuner ..................................................................................................186
Selecting the FM/AM band ................................................................................... 186
Selecting a station (manually or automatically) ....................................................187
Selecting preset stations....................................................................................... 187
How to play CDs ......................................................................................................... 187
Switching disc modes ...........................................................................................187
Advancing to the next track or returning to the beginning of the track being
played ...................................................................................................................188
Skipping to the next or previous disc....................................................................188
How to play MP3/WMA ...............................................................................................189
Switching disc modes ...........................................................................................189
Advancing to the next file or returning to the beginning of the file being played...189
Skipping to the next or previous folder .................................................................189
Replacing the battery..................................................................................................190
How to operate the receiver with an optional CD changer
connected ........................................................................................... 192
Switching the input channel ........................................................................................192
Listening to a CD ........................................................................................................192
Advancing to the next track or returning to the beginning of the track being played ..192
Fast Forward/Rewind..................................................................................................193
Playing the beginning of tracks (SCAN)......................................................................193
Repeating the same track (REPEAT) .........................................................................194
Playing tracks in random order (RANDOM)................................................................194
Skipping to the next or previous CD ...........................................................................195
Specifying a CD to play...............................................................................................195
How to operate the tuner with an optional HD Radio tuner
connected (U.S.A. only)..................................................................... 196
About HD Radio .......................................................................................................... 196
Tuning to a station ......................................................................................................197
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................................................198
Manually setting stations into memory ........................................................................ 199
Preset station scan .....................................................................................................200
14
Switching between displays when receiving HD Radio............................................... 201
HD Radio reception settings .......................................................................................201
How to operate the tuner with an optional SIRIUS satellite
radio tuner connected (U.S.A. only)................................................. 203
About SIRIUS satellite radio ....................................................................................... 203
Selecting the radio mode ............................................................................................204
Selecting a channel..................................................................................................... 204
Category selection ......................................................................................................205
Direct Channel selection .............................................................................................205
Manually setting channels into memory ...................................................................... 207
Preset channel scan ................................................................................................... 208
Switching displays when using the SIRIUS satellite radio ..........................................208
Others ................................................................................................. 209
Connecting portable audio players to the AUX jack.................................................... 209
Switching the external input method (analog/digital) ............................................210
Changing auxiliary input sensitivity....................................................................... 211
User Registration Key display..................................................................................... 212
If you have a question: ...................................................................... 213
Displayed information (for troubleshooting) ................................................................214
Specifications..................................................................................... 218
Before installation.............................................................................. 220
Components................................................................................................................ 220
Installation angle .........................................................................................................220
Mounting instruction ......................................................................... 221
Mounting the main unit................................................................................................ 221
Names of lead wires and destinations .......................................................................224
Measuring the frequency characteristics inside the passenger compartment ............226
System ........................................................................................................................ 227
How to contact customer service..................................................... 234
15
Operating precautions
ATE
AGIC
TICK
EMORY
Operating precautions
<Your CD8455 will perform well over a long period of time through correct handling
and care.>
Notes on operation
● For your safety, play only at volume levels that allow outside sounds to be heard.
● We recommend using with this player a disc with the
logo shown to the left.
● You can play music CDs(CD-R/CD-RW) on this player.
Be sure to use discs that have been properly processed.
Depending on the editing equipment used, some discs
TEXT
may not play properly.
● Do not insert anything other than a CD and a Memory
Stick into the head unit.
ATE
TICK
S
EMORY
M
AGIC
M
G
Do not insert any foreign objects, such as coins or credit
cards, into the disc slot. Be especially watchful of
children’s mischief in this regard.
● Avoid severe mechanical shock.
When the player is subjected to severe vibration while
traveling over a rough surface, playback may be
intermittent. When a situation like this occurs, resume
playback after returning to a smoother road.
● About dew condensation.
In cold or rainy weather, just as the interior glass surface
gets fogged, dew (water condensation) may also settle
on the deck. When this occurs, disc playback may
become intermittent or impossible. Dehumidify the air in
the vehicle for a while before resuming playback.
16
Operating precautions
ATE
AGIC
TICK
EMORY
ATE
AGIC
TICK
EMORY
● Cleaning the disc slot.
ATE
TICK
S
EMORY
M
AGIC
M
G
The disc slot tends to get dusty. Clean it occasionally to
prevent accumulated dust from scratching the discs.
● With the front panel open, many functions will not
operate, therefore, the front panel will need to be closed
during operation.
About compact discs
● The signal recorded on a compact disc is read by a laser beam, so nothing
touches the disc surface. A scratch on the recorded surface or a badly warped
disc may cause deteriorated sound quality or intermittent playback. Observe the
following precautions to ensure high quality sound performance:
● Do not leave an ejected disc in the disc slot for very long;
ATE
TICK
S
EMORY
M
AGIC
M
G
the disc may warp. Discs should be stored in their cases
and kept away from high temperature and humidity.
I
● Do not stick a piece of paper or tape. Do not write on or
scratch either side of a disc.
● Discs spin at a high speed inside the deck. Keep
cracked or warped discs out of the player to avoid
damage it.
● Avoid touching the recorded surface when handling a
disc; handle discs by their edges.
17
Operating precautions
About brand new CDs
● You may notice that some brand new
discs are rough around the center
hole or outside edge. Remove the
rough edges with the side of a
ballpoint pen, etc. Rough edges may
prevent proper loading in the deck.
Flakes from the rough edges may
also stick to the recorded surface and
interfere with playback.
Rough Edges
Ballpoint
pen
Rough
Edges
Flakes
About CD accessories
● Do not use accessories
(stabilizers, protective seals, laser
lens cleaners, etc.) sold for
"improving sound performance" or
"protecting CDs." The changes in CD
thickness or outside dimensions
made by these accessories may
cause problems in the player.
●
Please be sure NOT to attach any ringshape protector (or other accessory) to
your discs. Those protectors are
commercially available and said to
protect disc and to improve sound
quality (and antivibration effect), but
they can do more harm than good in
regular uses. The most common
problems are disc insertion, disc
ejections, and won't play problems due
to the protector ring that came off in the
disc mechanism.
Recorded surface
18
Operating precautions
Y
About borrowed CDs
● Do not use a CD with glue or remnants
of adhesive tape or labels. They may
cause the CD to get stuck inside or
damage the deck.
How to remove CDs
● When removing the ejected disc, pull
it straight out along the slot. Pressing
downward in the process may scratch
the recorded surface of the disc.
OKA
NO GOOD
About irregularly-shaped CDs
● Specially-shaped CDs, like heartshaped or octagonal CDs, cannot be
played. Do not attempt to play them,
even with an adapter, since they may
damage the player.
I
About cleaning a CD
● Use a commercially available compact disc cleaner to
● Do not use benzine, thinner, LP record spray or other
XXXX
XXXX
XXXX
clean a CD, wiping gently from the center to the edge.
cleaners on CDs. They may damage a CD’s finish.
19
Operating precautions
About Memory Sticks
● Do not store Memory Sticks in places that are subject to
● In order to protect the player, the player's functions will
● If using a Memory Stick Duo, you will need to use it with
● Only Memory Sticks with a capacity of up to 128 MB can
● Memory Stick PRO types of Memory Stick cannot be
● If MG Memory Stick is not being used for prolonged time,
● MG Memory Sticks bearing one of the marks at the left
● Memory Sticks bearing one of the marks at left can be
● If the write protection switch on a MG Memory Stick or
● Do not remove a MG Memory Stick while it is being
● Please format the MG Memory Stick on this deck. A MG
● When a Memory Stick is formatted, all data on that
static electricity and electrical interference, otherwise the
data they contain may become corrupted.
be stopped automatically if a problem occurs. If the
player cannot be operated even after following the
instructions that appear on the screen, the unit is
malfunctioning, and you should ask the place of
purchase for further advice.
a Memory Stick Duo adapter.
be used in the unit.
used.
remove it from the unit.
can be used.
used for writing and reading data other than music data.
MagicGate Memory Stick and Memory Stick are
trademarks of Sony Corporation.
Memory Stick is at the lock position, audio recordings
and other data cannot be saved onto it.
accessed for playback or recording, otherwise the data
on the MG Memory Stick may become corrupted. If the
data becomes corrupted, it can no longer be retrieved.
Memory Stick formatted by another deck may not be
playback or record data.
Memory Stick will be erased. (Includes Memory Stick
security recorded data and sound quality data)
20
Operating precautions
● MG Memory Stick supplied is not formatted. MG Memory
Stick must be formatted prior to use. Refer to
"Formatting MG Memory Stick (quick format)" on page
104 for instructions on formatting MG Memory Sticks.
● It may not be possible to use MG Memory Sticks that
have just been purchased. If this happens, use the unit
to format the MG Memory Stick. Refer to "Formatting MG
Memory Stick (quick format)" on page 104 for
instructions on formatting MG Memory Sticks.
● Some recordings and other data may not be played back
or written/read, depending on the device that was used
to save the data.
● Do not use Memory Sticks with labels that are peeling off
or that have name tags (labels) attached.
● Store Memory Sticks in places away from direct sunlight
and high humidity, otherwise the Memory Sticks may
become unusable.
I
NO GOOD
● Place Memory Sticks in their protective cases during
transportation and storage.
● Do not touch the terminals with your hands or with
metallic objects.
● When removing the ejected Memory Stick, pull it straight
out along the slot. Pressing downward in the process
may scratch the recorded surface of the Memory Stick.
OKAY
21
Operating precautions
About cleaning the Memory Sticks
● In order to maintain good audio performance from
Memory Sticks, periodically wipe the cartridge clean of
any dust and other contamination with a dry cloth.
22
Names of controls and parts
ATE
AGIC
TICK
EMORY
Front view
With the front open
Names of controls and parts
II
TICK
S
EMORY
M
ATE
AGIC
M
G
Never place an object or rest your hands or the like on the front panel.
[CD ] button
Opens/closes front panel and ejects CD.
[AUDIO CONTROL] button Adjusts volume and performs other functions.
[DISC MS] button
Switches disc modes, Memory Stick mode and switches to AUX mode.
[OPEN] button Opens/closes front panel.
[SOUND] button Turns the sound adjustment mode ON/OFF.
[FUNC] button Turns function mode ON/OFF.
[SEL] button Selects radio stations and CD tracks.
[/] button
Automatically finds radio reception or to fast forward/rewind.
[RTN] button Returns to previous screen.
[RESET] button
[DISP] button
Reset deck functions to default settings.
Turns the display adjustment mode ON/OFF and switches screen
display. Displays User Registration Key.
Buttons [1] to [6] Selects radio preset channels and performs disc mode functions.
[FM AM] button Switches to radio mode and switches radio bands.
[PWR] button Turns deck power ON/OFF.
[MUTE] button* Activates and deactivates mute.
Disc slot Inserts compact discs.
Memory Stick slot Inserts and ejects Memory Stick.
*: Double function button ➞ "MUTE" & "AREA SHOT" functions
23
ESN security operating procedure
ESN security operating procedure
About ESN
This deck is equipped with ESN (ECLIPSE Security Network). A preregistered music CD (Key CD), four-digit security code, or a Memory Stick
on which all unit functions will not operate, even by turning the ignition
switch to the ACC or ON position or reconnecting the battery after turning
the ignition switch off or disconnecting the battery during maintenance.
ESN can be set or cancelled using any of the following methods:
• Key CD security (See page 26)
You can record a specific CD that you have as a "key CD" with the deck,
and this CD can then be used to set and cancel the security settings.
• Memory Stick security (See page 30)
You can record a Memory Stick and a secret code (security code) with the
deck, and this Memory Stick or secret code (security code) can then be
matched with the deck to set and cancel the security settings.
• ACC security (See page 38)
This method can only be used when Memory Stick security has already
been set. When ACC security is set, button operations are disabled when
the ignition switch is turned to OFF and then back to ACC.
24
ESN security operating procedure
[FUNC] button
Button [3]
How to switch the security type (Key CD security/
Memory Stick security)
You can switch the type of security being used (Key CD security or
Memory Stick security). The initial setting is for Key CD security to be
used.
Check that the unit is in standby.
Press and hold the [FUNC] button, then button [3], and
hold both for the more than two seconds.
Security type will switch from Key CD security (DISC SEC) ↔
Memory Stick security (MS SEC) in order each time the button is
pressed.
If a security is activated, switching the security type is not available.
III
25
ESN security operating procedure
[CD ] button
[FUNC] button[OPEN] button
Button [6]
How to operate the ESN (Key CD) security
How to program the Key CD
Check that the unit is in standby.
Press and hold the [FUNC] button, then button [6],
and hold both for more than one second.
A [SEC] message appears, in two seconds it will change to
[DISC].
● If a CD has already been inserted, a [SEC] message appears,
and then the front panel opens and the CD is ejected.
● If a security is activated, programming the Key CD is not
available.
Press the [OPEN] or [CD ] button.
The front panel opens; The CD8455 is now ready for your Key
CD in the CD slot.
Insert the CD into the slot.
A [SEC] message appears, then the Key CD is ejected.
Press the [OPEN] or [CD ] button.
The front panel closes.
26
● If there is a problem with the inserted CD, an [ERR] message
will appear for two seconds and the CD will be ejected. Reinsert
the ejected CD.
● If a CD causes the [ERR] message to appear twice in a row, a
[CHANGE] message will appear for two seconds. Try another
CD.
●
Copy Protected CD and MP3/WMA CD-ROM cannot be programmed
for Key CD security.
● The Security indicator will flash whenever the vehicle's ignition
is switched off.
How to cancel the Key CD
Check that the unit is in standby.
Press and hold the [FUNC] button, then button [6],
and hold both for more than one second.
A [SEC] message appears, then in two seconds it will change
to [DISC].
Press the [OPEN] or [CD ] button.
The front panel opens; The CD8455 is now ready for your Key
CD in the CD slot.
ESN security operating procedure
III
If a CD has already been inserted, a [SEC] message appears, and
then the front panel opens and the CD is ejected.
Insert your Key CD into the slot.
A [CANCEL] message appears, then the Key CD is ejected.
The Key CD is cancelled.
● This process cancels the protection for ESN deck.
● If power to the ESN deck is disconnected, then reconnected, a
Key CD will not need to be inserted in order to return the unit to
normal operation.
● Inserting a CD other than the Key CD will not cancel the
protection. Instead, the display [ERR] for two seconds, then the
normal CD playback mode will activate.
Press the [OPEN] or [CD ] button.
The front panel closes.
27
ESN security operating procedure
[CD ] button
[OPEN] button
[FUNC] button
Button [6]
How to change the Key CD
First, cancel the existing Key CD.
Refer to "How to cancel the key CD".
Next, program a new Key CD.
Refer to "How to program the Key CD".
How to resume normal operation (ESN security lock out)
If power is disconnected while ESN security is active (a Key CD was
programmed), operation is disabled until power is restored and the
unit unlocked. Follow this procedure to resume normal operation.
When the power is turned on after disconnecting the
battery power, a [SEC] message will appear for two
seconds. Thereafter, message changes to [DISC]
and the press the [OPEN] or [CD ] button, then the
CD8455 is ready to accept your Key CD into the slot.
Insert your Key CD.
If the correct CD is inserted, an [OK] message will appear for
two seconds and the CD will begin playing.
● If the incorrect CD is inserted, an [ERR_] ("ERR" and error
number) message will appear for two seconds, after which the
CD will be ejected.
● If [ERR5] (the 5th time an error has occurred) appears, [HELP] will
appear, after which the CD will be ejected. When [HELP] appears,
carry out the operations for an ESN security lock out by following
the procedure in "What happens if an incorrect CD is inserted?" on
page 29.
● You must be use the same CD used for Key CD programming; a
duplicate CD may not work properly.
28
What happens if an incorrect CD is inserted?
After the 5th incorrect attempt, the display reads
[HELP] for five seconds.
After the [HELP] message will appear for five seconds, serial
number will appear.
Press the [OPEN] or [CD ] button to close the front
panel.
ESN security operating procedure
Press the [FUNC] button, then button [6], and hold
them for five seconds.
After the [SEC] message will appear for two seconds, rolling
code (six digit) will appear.
Press the [FUNC] button.
A [DISC] message appears.
You will have five more attempts the to insert correct disc.
Insert the key CD into the slot.
If the correct CD is inserted, an [OK] message will appear for
two seconds and the CD will be ejected.
● If an incorrect CD is inserted, an [ERR_] ("ERR" and error
number) message will appear for two seconds, after which the
CD will be ejected.
● This process cancels the protection for ESN deck.
● Note ●
If after 5 tries the correct Key CD is not inserted, the display reads
[CALL800]; the unit must be returned to Eclipse to be reset. In this
case, please contact your Eclipse dealer for assistance. For
country-specific customer service information, refer to "How to
contact customer service" on page 234.
III
Your Key CD can be easily forgotten. Write the album name in a
reminder note (See page 237).
29
ESN security operating proced ure
[FUNC] button
Buttons [1] to [4]
Button [6]
How to operate the ESN (Memory Stick) security
How to record a security code
Check that the unit is in standby.
Press and hold the [FUNC] button, then button [6],
and hold both for more than one second.
A [SEC] message appears, in two seconds it will change to
[MS].
● If a Memory Stick has already been inserted, a [MS EJECT]
message appears. In this case, eject the Memory Stick and insert
again. (Refer to "Ejecting the Memory Stick" on page 96 for details
on ejection of the Memory Stick.)
● If the security is already activated, recording the security code
function is not available.
Insert the Memory Stick into the slot.
A [- - - -] (security code input display) appears.
(Refer to "Listening to MG Memory Stick" on page 43 for
details on insertion of the Memory Stick.)
Input a security code by pressing buttons [1] to [4].
Enter a four-digit security code using digits 0 to 9, A to F. The
number (shown on the display) changes in ascending order
between 0 and 9, A and F each time the button is pressed.
Each button number (1 to 4) corresponds to each digit (first to
fourth) of the security code.
30
Loading...
