Eclipse - Fujitsu Ten CD8051 User Manual
OWNER'S MANUAL
We appreciate your purchase of this tuner.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
ESN E8 CD Tuner with
CDC/E-COM/DSP Control and NOB Remote
MODEL CD8051
DISC
BAND MODE
MUTE
ILLUMI
PWRE-COM
TRACK
TUNE SEEK
P
U
S
H
-
M
O
D
E
2
For your safety in using the
CD8051
Warnings and caution signs, illustrated below, are posted
throughout this manual as well as on the CD8051. They show
safe and correct ways to handle the product so as to prevent
personal injury to you and others and avoid damage to property.
Before reading through the manual, take time to read through
and learn the important information listed in this section.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in death or serious personal
injury.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in personal injury or may result
solely in damage to property.
•
Do not modify this system for use other than that specified
herein. Also, do not deviate from the installation procedures
described herein; Eclipse will not be held liable for damages
including, but not limited to serious injury, death or property
damage resulting from installations that enable unintended
operation.
•
This unit is intended for operation in DC 12-volt, negativegrounded vehicles only. Never use it in 24-volt vehicles such
as heavy trucks or diesel cars with cold-region specifications.
•
Do not change CDs while driving. Doing so may result in an
accident.
Warning
Caution
Warning
3
•
Do not place the vinyl storage bag over a person. It may
cause a serious accident or death by suffocation.
•
Do not adjust the controls while driving the car. To adjust the
controls, stop the car in a safe location.
•
To prevent accidents, store batteries for the remote control
out of the reach of small children. In case a child swallows a
battery, consult a physician immediately.
•
Do not disassemble or rebuild this product. Doing so may
cause an accident, fire or electrical shock.
•
When it is necessary to replace the fuse, always use a fuse of
the correct rating (number of amperes). Use of fuses with
higher amperage ratings may cause a fire.
•
Do not operate the product in a malfunctioning condition, for
instance, when the audio does not play. Doing so may result
in an accident, fire or electrical shock.
•
If an abnormal situation occurs, such as foreign matter
entering or liquid splashing on the product, or smoke or a
strange odor emitting from the unit, shut off the product
immediately and consult the dealer from whom you purchased
it. Continued operation may cause an accident, fire or
electrical shock.
•
Do not install this product in locations where it may obstruct
the driver's view, or where it may endanger passengers in the
vehicle. Otherwise, an accident or injury may result.
•
Do not install this product in locations where it may interfere
with the operation of the steering wheel, shift lever, brake
pedal, etc. Otherwise, an accident or injury may result.
•
When installing this product, never use existing nuts or bolts
that secure parts of the fuel tank, or the steering or braking
systems. Otherwise improper steering or braking or a fire may
result.
Warning
4
•
To prevent a short circuit from occurring, disconnect the
battery's negative terminal before installing this product.
Otherwise, an electric shock or injury may result.
•
When using an existing nut and/or bolt from the vehicle to
ground this product, do not use any that secure parts of the
steering or braking systems. Otherwise, an accident may
result.
•
Bundle cables and harnesses with electrical tape or wire ties
to prevent them from interfering with moving parts. If they
should entangle the steering wheel, shift lever or brake pedal,
an accident may result.
•
Never supply power to another electrical appliance by splicing
or tapping into this product's power lead (wire). Otherwise, the
current capacity of the wire will be exceeded, resulting in a fire
or electric shock.
•
Never attempt to disassemble or modify the product.
Otherwise, an accident, fire or electric shock may result.
•
When installing the product into a vehicle with a passenger
side air bag, do not secure it to the air bag's cover or in places
where it may impede air bag deployment. Otherwise, proper
air bag operation may not be ensured in the event of an
accident, causing injury or death.
•
When making holes using a drill or similar tool, be sure to wear
protective eyewear. Otherwise, an injury such as loss of
eyesight may result.
•
Exposed wires must be insulated with electrical tape.
Otherwise, a short circuit, fire, or electric shock may result.
Warning
5
•
Play the audio at a moderate volume level that permits you to hear
sounds from outside the car. Driving without being able to hear
outside sounds may result in an accident.
•
Keep foreign objects out of the disc slot. They may cause fire or
electrical shock. Another possibility is that discs may be damaged
or become stuck.
•
Do not stick your fingers or hands into the disc slot. Doing so
may cause personal injury.
•
This product must be operated only as on-board equipment, or it
may cause electrical shock or injury.
•
Do not play distorted sounds for long periods of time;
the speakers may overheat and cause a fire.
•
Never use batteries other than those specified. Do not mix new
and old cells. Doing so may cause a fire or personal injury due to
a battery explosion or chemical leaks.
•
Pay attention to the (+) and (-) polarity of the battery when
installing them in the product. Incorrect installation may cause
personal injury or product damage spoilage due to a battery
explosion or chemical leakage.
•
For best results, this product should be installed by a professional
installer.
Contact the dealer whom you purchased the product for an
appointment.
•
When installing this product, be sure to use the supplied mounting
hardware. If parts other than those supplied are used, the unit
may be damaged internally, or may not be held in place securely
and become dislodged.
Caution
6
•
Avoid installing this product in places where it may get wet,
such as near windows, or in places that are moist or dusty.
Presence of liquid, moisture or dust inside this product can
cause short circuiting, resulting in smoke or fire.
•
Do not install this product in locations where it cannot be
fastened securely, such as places subject to frequent
vibration. Otherwise, it may become dislodged and cause an
accident or injury.
•
Do not block this product's vent or heat sink. If either is
blocked, excessive heat build-up may occur and cause a fire.
•
If this product is not connected properly, a short circuit, fire or
accident may occur.
•
When routing cables, use care so that they do not contact
sharp metal parts such as brackets or screw tips. Otherwise,
a short circuit, electric shock, fire or accident may result.
•
Do not obstruct the vent on this product. If blocked, excessive
heat build-up may occur and cause a fire.
Caution
7
Table of Contents
Operating precautions .............................................. 10
Notes on operation ...................................................................... 10
About compact discs .................................................................. 12
About cleaning a CD ................................................................... 15
Names of controls and parts .................................... 16
ESN (Key CD) security operating procedure ........... 17
How to program the Key CD ....................................................... 17
How to cancel the Key CD .......................................................... 18
How to change the Key CD ......................................................... 19
How to resume normal operation (ESN security lock out) .......... 20
What happens if an incorrect CD is inserted? .............................. 21
How to turn the security indicator on/off ...................................... 22
How to read the Electronic Serial Number ................................... 23
Basic operation ......................................................... 24
Turning the power on and off ...................................................... 24
Listening to a CD ......................................................................... 24
Listening to the tuner ................................................................... 25
Adjusting audio volume ............................................................... 26
Displaying the clock ..................................................................... 26
Others ......................................................................................... 27
How to operate the CD player .................................. 36
Listening to CDs .......................................................................... 36
Advancing to the next track or returning to the beginning of the
track being played ....................................................................... 37
Playing the beginning of tracks (SCAN) ........................................ 37
Repeating the same track (REPEAT) ............................................ 38
Playing tracks in random order (RANDOM) .................................. 38
Switching a CD to pause / play ................................................... 38
Ejecting the disc .......................................................................... 39
Creating a title for a CD ............................................................... 40
Changing a previously set title ..................................................... 42
Deleting a previously created title ................................................. 43
Changing the number of CD titles ................................................ 44
Displaying CD text ....................................................................... 45
8
How to operate the tuner .......................................... 46
Tuning to a station ....................................................................... 46
Entering stations into memory automatically
(The automatic preset mode: ASM) ............................................ 47
Manually setting stations into memory ......................................... 48
Preset station scan ...................................................................... 49
Setting a station name ................................................................. 50
Deleting a station name ............................................................... 52
Setting a band category .............................................................. 53
Deleting a band category ............................................................. 55
Changing the number of bands ................................................... 56
FM reception characteristics ........................................................ 57
How to use the NOB remote control ........................ 60
Precautions in use of the remote control ...................................... 60
Cleaning the remote control ........................................................ 60
Turning the power on/off ............................................................. 61
Adjusting the audio volume .......................................................... 61
Switching playback modes .......................................................... 62
How to play the tuner .................................................................. 62
How to play CDs ......................................................................... 63
Illuminating the NOB remote control ............................................ 64
Enabling the optional E-COM feature ........................................... 64
Switching the remote control settings .......................................... 65
Replacing the battery .................................................................. 66
How to use an optional Card remote control .......... 68
Turning the power on/off ............................................................. 68
Adjusting the audio volume .......................................................... 68
Switching playback modes .......................................................... 69
How to play the tuner .................................................................. 69
How to play CDs ......................................................................... 70
Switching the remote control settings .......................................... 72
Replacing the battery .................................................................. 73
How to operate the receiver with an
optional CD changer connected .............................. 74
Basic operation ........................................................................... 74
9
How to operate the receiver with an optional
DSP/EQ unit or Digital Sound Processor connected ...
77
How to operate the DSP functions .............................................. 77
How to operate the EQ functions ................................................ 81
How to operate the Digital Sound Processor ............................... 84
If you have a question: .............................................. 92
Displayed information (for troubleshooting) ................................ 93
Specifications ............................................................ 96
Before installation ..................................................... 97
Components ............................................................................... 97
Mounting instruction ................................................. 98
Mounting the main unit ................................................................ 98
Names of lead wires and destinations ....................................... 100
System ...................................................................................... 101
Operating precautions
<Your CD8051 will perform well over a long period of time through correct
handling and care.>
• For your safety, play only at volume levels that allow outside sounds to
be heard.
•Use only audio compact discs.
This player can only play compact discs
bearing the logo shown to the left.
• It may not be possible to play back some
tracks on CD-Rs.
• It may not be possible to play back CD-Rs
with certain characteristics, or CD-Rs which
are scratched, dirty, or which have been left
inside a vehicle for long periods.
• CDs cannot be played back until all
sessions recorded on the CD-R have been
closed.
• CD-RW discs cannot be played back.
• Do not insert anything other than a CD into
the disc slot.
Do not insert any foreign objects, such as
coins or credit cards, into the disc slot. Be
especially watchful of children’s mischief in
this regard.
•Avoid severe mechanical shock.
When the player is subjected to severe
vibration while traveling over a rough
surface, playback may be intermittent.
When a situation like this occurs, resume
playback after returning to a smoother
road.
Notes on operation
Operating precautions
10
• About dew condensation.
In cold or rainy weather, just as the interior
glass surface gets fogged, dew (water
condensation) may also settle on the deck.
When this occurs, disc playback may
become intermittent or impossible.
Dehumidify the air in the vehicle for a while
before resuming playback.
• Cleaning the disc slot.
The disc slot tends to get dusty. Clean it
occasionally to prevent accumulated dust
from scratching the discs.
11
Operating precautions
Operating precautions
12
• The signal recorded on a compact disc is read by a laser beam, so
nothing touches the disc surface. A scratch on the recorded surface or
a badly warped disc may cause deteriorated sound quality or
intermittent playback. Observe the following precautions to ensure high
quality sound performance:
• Do not leave an ejected disc in the disc
slot for very long; the disc may warp.
Discs should be stored in their cases and
kept away from high temperature and
humidity.
• Do not stick a piece of paper or tape on,
nor write on or scratch either side of a
disc.
• Discs spin at a high speed inside the
deck. Keep cracked or warped discs out
of the player to avoid damaging it.
• Avoid touching the recorded surface when
handling a disc; handle discs by their
edges.
About compact discs
13
Operating precautions
About CD accessories
• Do not use accessories
(stabilizers, protective seals, laser
lens cleaners, etc.) sold for
“improving sound performance”
or “protecting CDs.” The
changes in CD thickness or
outside dimensions made by
these accessories may cause
problems in the player.
About brand new CDs
• You may notice that some brand
new discs are rough around the
center hole or outside edge.
Remove the rough edges with
the side of a ballpoint pen, etc.
Rough edges may prevent
proper loading in the deck.
Flakes from the rough edges
may also stick to the recorded
surface and interfere with
playback.
Rough Edges
Ballpoint
pen
Flakes
Recorded surface
Rough
Edges
• Please be sure NOT to attach any
ring-shape protector (or other
accessory) to your discs. Those
protectors are commercially
available and said to protect disc
and to improve sound quality
(and antivibration effect), but they
can do more harm than good in
regular uses. The most common
problems are Insert/Eject related
problems and "No playback"
problems due to the protectorring
that came off in the disc
mechanism.
Operating precautions
14
About borrowed CDs
• Do not use a CD with glue or
remnants of adhesive tape or
labels. They may cause the CD
to get stuck inside or damage
the deck.
How to remove CDs
• When removing the ejected disc,
pull it straight out along the slot.
Pressing downward in the
process may scratch the
recorded surface of the disc.
OKAY
NO GOOD
About irregularly-shaped CDs
• Specially-shaped CDs, like
heart-shaped or octagonal CDs,
cannot be played. Do not
attempt to play them, even with
an adapter, since they may
damage the player.
15
Operating precautions
• Use a commercially available compact disc
cleaner to clean a CD, wiping lightly from
the center to the edge.
• Do not use benzine, thinner, LP record
spray or other cleaners on CDs. They may
damage a CD’s finish.
XXXX
XXXX
XXXX
About cleaning a CD
Names of controls and parts
161616
Names of controls and parts
Front view
※NOTE : Double function button "E-COM" & "MUTE" functions
Though the words "press" and "tap" are used in the text for the
operation of the [ TU ] button and [ BND ] button, the
button is actually slid in the or direction.
With the front open
Caution
Never place an object or rest your hands or the like on the
front panel.
Disc slot
[MODE] button
[CUSTOM] button
[RESET] button[AUDIO CONTROL]
button
Buttons [1] to [6]
[FUNC] button
[OPEN] button
[E-COM] button
[ BND ] button
[ TU ]
button
[SOURCE] button
17
ESN (Key CD) security operating procedure
Button [1]
ESN (Key CD) security operating
procedure
How to program the Key CD
1 .
Check that the Power is OFF.
2 .
Press and hold button [1], then the [FUNC]
button, and hold both for more than one
second.
A [SEC] message appears, then in two seconds it will
change to [DISC].
The front panel opens; the CD8051 is now ready to
accept your Key CD in the CD slot.
3 .
Insert the CD into the slot.
The front panel closes.
A [SEC] message appears, the front panel opens, then
the Key CD is ejected.
[FUNC] button
Button [1]
ESN (Key CD) security operating procedure
18
• If there is a problem with the inserted CD, an [ERR]
message will appear for two seconds and the CD will be
ejected. Reinsert the ejected CD.
• If a CD causes the [ERR] message to appear twice in a
row, a [CHANGE] message will appear for two seconds.
Try another CD.
• The Security indicator will flash whenever the vehicle’s
ignition is switched off.
How to cancel the Key CD
1 .
Turn OFF the Power.
2 .
Press and hold button [1], then the [FUNC]
button, and hold both for more than one
second.
A [SEC] message appears, then in two seconds it will
change to [DISC].
The front panel opens; the CD8051 is now ready to
accept your Key CD in the CD slot.
3 .
Insert your Key CD into the slot.
The front panel closes.
A [CANCEL] message appears, the front panel opens,
then the Key CD is ejected.
The Key CD is cancelled.
[FUNC] button
19
ESN (Key CD) security operating procedure
•
This process cancels the protection for the ESN
deck.
• If power to the ESN deck is disconnected, then
reconnected, a Key CD will not need to be inserted in
order to return the unit to normal operation.
•Inserting a CD other than the Key CD will not cancel the
protection. Instead, the display will show [ERR] for two
seconds, then the normal CD playback mode will activate.
How to change the Key CD
1 .
First, cancel the existing Key CD.
Refer to “How to cancel the Key CD.”
2 .
Next, program a new Key CD.
Refer to “How to program the Key CD.”
ESN (Key CD) security operating procedure
20
How to resume normal operation
(ESN security lock out)
If power is disconnected while ESN security is active (a Key
CD was programmed), operation is disabled until power is
restored and the unit unlocked. Follow this procedure to
resume normal operation.
1 .
When the power is turned on after
disconnecting the battery power, a [SEC]
message will appear for two seconds.
Thereafter, the message changes to [DISC]
and the CD8051 is ready to accept your Key
CD into the slot.
2 .
Insert your Key CD.
If the correct CD is inserted, an [OK] message will
appear for two seconds and the CD will begin playing.
• If an incorrect CD is inserted, an [ERR] message will
appear for two seconds, after which the CD will be
ejected.
• You must use the same CD used for Key CD
programming; a duplicate CD may not work properly.
21
ESN (Key CD) security operating procedure
What happens if an incorrect CD is
inserted?
1 .
An [ERR] message will be appear, then change
to a flashing [DISC], then the CD will be
ejected.
You will have five uninterrupted attempts to insert the
correct CD.
2 .
After the 5thincorrect attempt, the display
reads [HELP].
3 .
If [HELP] appears on the screen, press button
[6], then the [FUNC] button, and hold them for
five seconds.
4 .
Press the [FUNC] button.
You will have five more attempts the correct disc.
Number of errors: Numbers indicated the number of errors
that occurred.
Note
If after 10 tries the correct Key CD is not inserted, the display
reads [CALL800]; the unit must be returned to Eclipse to be
reset. In this case, please contact your Eclipse dealer for
assistance or call Eclipse directly at (800) 233-2216.
Your key CD can be easily forgotten. Write the
album name in a reminder note (See Page 107).
ESN (Key CD) security operating procedure
22
How to turn the security indicator on/off
Once PIN or ESN security is activated, the indicator flashes
whenever the vehicle’s ignition is turned off, warning
potential thieves that the unit is protected. However, if you
do not want this visible deterrent, it may be turned off.
1 .
With the power OFF,
press button [2], then the
[FUNC] button and hold both for more than one
second.
2 .
[INDICATOR flash] or [INDICATOR OFF] appears
on the display.
[IND. FLASH] means the security indicator will flash
when the vehicle’s ignition is off, and [IND. -----] means
it will not. Repeat the above steps to reactivate the flash
mode.
Button [2]
[FUNC] button
23
ESN (Key CD) security operating procedure
23
How to read the Electronic Serial Number
1 .
Turn OFF the Power.
2 .
Press button [4], then the [FUNC] button, and hold
both for more than one second.
[ESN] appears on the display, followed by an eight-digit
number; this number is your electronic serial number (ESN).
You may use this number to identify your Eclipse CD8051
in the event it is recovered after being stolen.
Button [4]
[FUNC] button
Basic operation
24
[SOURCE] button
[ BND ] button
[ TU ]
button
Basic operation
This section covers basic operating procedures. For
additional details, please refer to the sections on specific
functions.
Tur ning the power on and off
When the power is turned on, the state used when the power
was turned off such as CD and tuner playing is restored.
1 .
Press the [SOURCE] button.
Pressing the button turns the power on and off.
Less than two second:
Pressing the [SOURCE] button repeatedly while
the power is turned on will switch the modes in
the order of Tuner Disc AUX PWR OFF
(Stand by).
Non-shiftable modes are skipped.
More than two second: Off
If a car is not equipped with an ACC position (for example,
a European car), keep the [SOURCE] button depressed for
more than two seconds.
Listening to a CD
1 .
Press the [OPEN] button.
The front panel opens.
2 .
Insert a CD into the disc slot, label side up.
The CD will immediately start playing.
Buttons [1] to [6]
[OPEN] button
25
Basic operation
When a CD is already loaded, press the [SOURCE] button
repeatedly to switch to the CD mode.
Listening to the tuner
1 .
Press and hold the [SOURCE] button until the
mode switches to the tuner mode.
This will turn the tuner on.
To turn the tuner off, press the [SOURCE] button either
shorter to select another mode or longer to turn the
power off.
2 .
Tap the [ BND ] button to switch to the
desired FM or AM bands.
[BND ] button: Switch the FM band.
Pressing the button repeatedly
switches the FM band in the order of
FM1 FM2
...
.
[BND ] button: Switch the AM band.
Pressing the button repeatedly
switches the AM band in the order of
AM1 AM2
...
.
It is also possible to change the numbers of FM and AM
bands in a certain combination of them (See Page 56).
3 .
Press the [ TU ] button to tune to a station.
A tap on either the [ TU ] button for less than one
second will enable manual station tuning. Hold one
button down for more than two seconds to start the
automatic station search.
[TU ] button: Starts searching toward higher
frequencies.
[TU ] button: Starts searching toward lower
frequencies.
If stations have been stored in memory, pressing a button
from [1] to [6] will directly select a station. (Refer to the
section “Manually setting stations into memory” on page 48)
Basic operation
26
[E-COM] button
[ BND ] button
[SOURCE] button
Button [6]
262626
Adjusting audio volume
1 .
Turn the [AUDIO CONTROL] button to the left
or right.
Turn to the left : Decreases the volume.
Turn to the right : Increases the volume.
Press the [E-COM] button for more than two seconds if ECOM is connected and less than two seconds if E-COM is
not connected to cut the volume or restore it instantly.
Displaying the clock
1 .
Press the [FUNC] button.
2 .
Press the [ BND ] button repeatedly until
the clock appears on the screen.
Warning
Do not adjust the volume or other controls while driving the
vehicle. Do so only while parked in a safe location.
[MODE] button
[AUDIO CONTROL]
button
[CUSTOM] button
[FUNC] button
27
Basic operation
3 .
Press the [SOURCE] button to switch to
[CLOCK ON].
4 .
Press the [FUNC] button again.
•If the spectrum analyzer display is set to ON, priority is
given to the spectrum analyzer display (See Page 35).
•Pressing button [6] during power-off switches ON/OFF of
the clock display during power-off.
Others
Setting the clock
This receiver uses the 12-hour A.M. / P.M. display notation.
1. Press the [FUNC] button.
2. Press the [CUSTOM] button to switch to the clock
adjustment mode.
3. Press the [SOURCE] button to select the hour or
minutes to be adjusted.
The blinking one can be adjusted.
4. Press the [ BND ] button.
[BND ] button: Turns the time back.
[BND ] button: Turns the time forward.
5. Press the [CUSTOM] button again to return to the
normal mode.
To set the clock to 0 minutes, 0 seconds (an exact hour),
press the [MODE] button.
For example:
At 3:29: Pressing the [MODE] button returns to 3:00.
At 3:30: Pressing the [MODE] button advances to 4:00.
Basic operation
28
[E-COM] button
[OPEN] button
Switching audio control modes
Various audio control modes may be fine-tuned using this
procedure.
1. Press the [AUDIO CONTROL] button for less than
one second to select the item to be adjusted.
Each additional tap of the button switches in the order
of VOL, DSP*
1
, BASS (low frequencies), MID (middle
frequencies), TREB (high frequencies), CENTER*
2
,
REAR*
2
, FAD (front-rear speaker balance), BAL (left-
right speaker balance), and SUB-W (subwoofer level).
*
1
This is displayed only if DSP/EQ is connected.
*
2
This is displayed only if Digital Sound Processor is
connected.
2. Turn the [AUDIO CONTROL] button to the left or
right
It controls levels and adjust the sound to your
preference.
•When Tone Control feature is off, adjustment of BASS,
MID, and TREB will be skipped.
•When an optional DSP/EQ unit is connected, the mode
switches from Volume DSP level adjustment EQ level
adjustment. BASS, MID, TREB, FADER, BAL, may be
skipped, and it depends on the type of DSP/EQ and its
situation.
•Adjustment of BASS, MID, and TREB is set by each mode
such as CD, tuner.
[AUDIO CONTROL]
button
Buttons [1] to [5]
29
Basic operation
Enabling the loudness control
The loudness control may be turned on to emphasize low
and high frequencies at low volume levels.
Loudness compensates for the apparent weakness of low
and high frequencies at low volume by boosting the bass
and treble levels.
1. Press and hold the [AUDIO CONTROL] button until
the [LOUD ON] display appears on the screen.
To disable the loudness feature, repeat the above
procedure to display the [LOUD OFF] indication.
Enabling E-COM feature
1. Press the [E-COM] button for one second.
Pressing the button will switch the E-COM feature on or
off.
Adjustment of the front panel angle
1. Press and hold the [OPEN] button for more than
two seconds.
While holding the button, the front panel opens
regardless of the stage. The operation stops when the
limit of adjustable angles is reached.
2 . Press the [OPEN] button again for more than two
seconds.
The front panel will be completely closed.
Displaying a memo
If memos have been set, a memo recorded corresponding
to a number button [1] to [5] appears on the screen when
the number button is pressed briefly while the power of the
main unit is turned off.
Basic operation
30
[ BND ] button
[ TU ]
button
Buttons [1] to [5]
Setting a memo
1. Press and hold any number button for more than
two seconds while the power is turned off.
The state shifts to the MEMO setting mode.
2 . Press button [1] to select the character type.
Pressing the button will switch types from [ABC]
(alphabet characters) to [123] (numeric characters) and
then [!&?] (symbols).
3. Press either [ TU ] to select the position in which
to enter the character.
The character will be inserted where the cursor is
Flashing:
[TU ] button: Moves the cursor to the right.
[TU ] button: Advances the cursor to the left.
[MODE] button
Loading...
