OWNER'S MANUAL
We appreciate your purchase of this receiver.
Please read through this manual for correct operation.
We suggest that after reading it you keep this manual
in a safe place for future reference.
ESN E3 High-Power CD Receiver with
MP3 Decorder
MODEL CD3403
For your safety in using the
CD3403
Warnings and caution signs, illustrated below, are posted
throughout this manual as well as on the CD3403. They show safe
and correct ways to handle the product so as to prevent personal
injury to you and others and avoid damage to property.
Before reading through the manual, take time to read through and
learn the important information listed in this section.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in death or serious personal injury.
This sign indicates a situation in which
incorrect handling through disregard of a sign
might result in personal injury or may result
solely in damage to property.
• Do not modify this system for use other than that specified
herein. Also, do not deviate from the installation procedures
described herein; Eclipse will not be held liable for damages
including, but not limited to serious injury, death or property
damage resulting from installations that enable unintended
operation.
• This unit is intended for operation in DC 12-volt, negativegrounded vehicles only. Never use it in 24-volt vehicles such as
heavy trucks or diesel cars with cold-region specifications.
• Do not change CDs while driving. Doing so may result in an
accident.
Warning
Caution
Warning
2
3
• Do not place the vinyl storage bag over a person. It may cause
a serious accident or death by suffocation.
• Do not adjust the controls while driving the car. To adjust the
controls, stop the car in a safe location.
• To prevent accidents, store batteries for the remote control out
of the reach of small children. In case a child swallows a
battery, consult a physician immediately.
• Do not disassemble or rebuild this product. Doing so may
cause an accident, fire or electrical shock.
• When it is necessary to replace the fuse, always use a fuse of
the correct rating (number of amperes). Use of fuses with
higher amperage ratings may cause a fire.
• Do not operate the product in a malfunctioning condition, for
instance, when the audio does not play. Doing so may result in
an accident, fire or electrical shock.
• If an abnormal situation occurs, such as foreign matter entering
or liquid splashing on the product, or smoke or a strange odor
emitting from the unit, shut off the product immediately and
consult the dealer from whom you purchased it. Continued
operation may cause an accident, fire or electrical shock.
• Do not install this product in locations where it may obstruct the
driver's view, or where it may endanger passengers in the
vehicle. Otherwise, an accident or injury may result.
• Do not install this product in locations where it may interfere
with the operation of the steering wheel, shift lever, brake
pedal, etc. Otherwise, an accident or injury may result.
• When installing this product, never use existing nuts or bolts
that secure parts of the fuel tank, or the steering or braking
systems. Otherwise improper steering or braking or a fire may
result.
Warning
4
• To prevent a short circuit from occurring, disconnect the
battery's negative terminal before installing this product.
Otherwise, an electric shock or injury may result.
• When using an existing nut and/or bolt from the vehicle to
ground this product, do not use any that secure parts of the
steering or braking systems. Otherwise, an accident may result.
• Bundle cables and harnesses with electrical tape or wire ties to
prevent them from interfering with moving parts. If they should
entangle the steering wheel, shift lever or brake pedal, an
accident may result.
• Never supply power to another electrical appliance by splicing
or tapping into this product's power lead (wire). Otherwise, the
current capacity of the wire will be exceeded, resulting in a fire
or electric shock.
• Never attempt to disassemble or modify the product.
Otherwise, an accident, fire or electric shock may result.
• When installing the product into a vehicle with a passenger
side air bag, do not secure it to the air bag's cover or in places
where it may impede air bag deployment. Otherwise, proper air
bag operation may not be ensured in the event of an accident,
causing injury or death.
• When making holes using a drill or similar tool, be sure to wear
protective eyewear. Otherwise, an injury such as loss of
eyesight may result.
• Exposed wires must be insulated with electrical tape.
Otherwise, a short circuit, fire, or electric shock may result.
Warning
5
• Play the audio at a moderate volume level that permits you to
hear sounds from outside the car. Driving without being able to
hear outside sounds may result in an accident.
• Keep foreign objects out of the disc slot. They may cause fire
or electrical shock. Another possibility is that discs may be
damaged or become stuck.
• Do not stick your fingers or hands into the disc slot. Doing so
may cause personal injury.
• This product must be operated only as on-board equipment, or
it may cause electrical shock or injury.
• Do not play distorted sounds for long periods of time;
the speakers may overheat and cause a fire.
• This product uses an invisible laser light. In case a problem
develops, be sure to consult the dealer from whom you
purchased the product. Do not disassemble or rebuild the unit;
rebuilding it may expose you and others to a dangerous laser
emission (which would damage eyesight) or cause an
accident.
• Never use batteries other than those specified. Do not mix new
and old cells. Doing so may cause a fire or personal injury due
to a battery explosion or chemical leaks.
• Pay attention to the (+) and (-) polarity of the battery when
installing them in the product. Incorrect installation may cause
personal injury or product damage spoilage due to a battery
explosion or chemical leakage.
• For best results, this product should be installed by a
professional installer.
Contact the dealer whom you purchased the product for an
appointment.
• When installing this product, be sure to use the supplied
mounting hardware. If parts other than those supplied are
used, the unit may be damaged internally, or may not be held
in place securely and become dislodged.
Caution
6
• Avoid installing this product in places where it may get wet,
such as near windows, or in places that are moist or dusty.
Presence of liquid, moisture or dust inside this product can
cause short circuiting, resulting in smoke or fire.
• Do not install this product in locations where it cannot be
fastened securely, such as places subject to frequent vibration.
Otherwise, it may become dislodged and cause an accident or
injury.
• Do not block this product's vent or heat sink. If either is
blocked, excessive heat build-up may occur and cause a fire.
• If this product is not connected properly, a short circuit, fire or
accident may occur.
• When routing cables, use care so that they do not contact
sharp metal parts such as brackets or screw tips. Otherwise, a
short circuit, electric shock, fire or accident may result.
• Do not obstruct the vent on this product. If blocked, excessive
heat build-up may occur and cause a fire.
Caution
7
Table of Contents
Operating precautions ............................................. 10
Notes on operation ..................................................................... 10
About compact discs .................................................................. 11
About cleaning a CD .................................................................. 13
Names of controls and parts .................................. 14
ESN (Key CD) security operating procedure ........ 15
How to program the Key CD ...................................................... 15
How to cancel the Key CD ......................................................... 16
How to change the Key CD ........................................................ 17
How to resume normal operation (ESN security lock out) ........ 17
What happens if an incorrect CD is inserted? ............................ 18
How to turn the security indicator on/off ..................................... 19
How to read the Electronic Serial Number ................................. 19
Basic operation ........................................................ 20
Turning the power on and off ..................................................... 20
Listening to a CD ........................................................................ 21
Listening to the tuner .................................................................. 22
Adjusting audio volume .............................................................. 22
Switching audio control modes ................................................... 23
Enabling the loudness control .................................................... 24
Making changes with Function Mode ......................................... 25
How to operate the CD player ................................. 27
Listening to CDs ......................................................................... 27
Advancing to the next track or returning to the beginning of the
track being played ...................................................................... 28
Fast Forward/Rewind ................................................................. 28
Playing the beginning of tracks (SCAN) ..................................... 28
Repeating the same track (REPEAT) ......................................... 29
Playing tracks in random order (RANDOM) ............................... 29
Ejecting the disc ......................................................................... 30
Displaying CD TEXT .................................................................. 30
8
How to operate the MP3 player ............................... 31
About MP3 .................................................................................. 31
Listening to MP3 file ................................................................... 34
Advancing to the next track (file) or
returning to the beginning of the track (file) being played .......... 35
Fast Forward/Rewind ................................................................. 35
Skipping to the next or previous folder ....................................... 35
Return to the root directory of the CD ........................................ 35
Playing the beginning of files (SCAN) ......................................... 36
Repeating the same file (REPEAT) ............................................ 36
Playing files in random order (RANDOM) .................................. 37
Displaying title ............................................................................ 37
How to operate the tuner ........................................ 38
Tuning to a station ...................................................................... 38
Entering stations into memory automatically
(The automatic preset mode: ASM) .......................................... 39
Manually setting stations into memory ....................................... 40
Preset station scan ..................................................................... 41
Switching the display .................................................................. 41
FM reception characteristics ...................................................... 42
How to use an optional Card remote control ........ 44
Precautions in use of the remote control .................................... 44
Cleaning the remote control ....................................................... 44
Turning the power on/off ............................................................ 45
Adjusting the audio volume ........................................................ 45
Switching playback modes ......................................................... 46
How to play the tuner ................................................................. 46
How to play CDs ......................................................................... 47
Replacing the battery ................................................................. 49
How to use an optional NOB remote control ........ 50
Turning the power on/off ............................................................ 50
Adjusting the audio volume ........................................................ 50
Switching playback modes ......................................................... 51
How to play the tuner ................................................................. 51
How to play CDs ......................................................................... 52
Replacing the battery ................................................................. 54
9
If you have a question: ............................................ 56
Displayed information (for troubleshooting) ................................ 57
Specifications ........................................................... 60
Before installation ................................................... 61
Components ............................................................................... 61
Installation angle ........................................................................ 62
Mounting instruction ............................................... 63
Mounting the main unit ............................................................... 63
Names of lead wires and destinations ........................................ 65
System ....................................................................................... 66
10
Operating precautions
<Your CD3403 will perform well over a long period of time through correct
handling and care.>
• For your safety, play only at volume levels that allow outside sounds to be
heard.
• We recommend using with this player a disc with
the logo shown to the left.
• You can play music CDs(CD-R/CD-RW) on this
player. Be sure to use discs that have been
properly processed.
Depending on the editing equipment used, some
discs may not play properly.
• Do not insert anything other than a CD into the
disc slot.
Do not insert any foreign objects, such as coins or
credit cards, into the disc slot. Be especially
watchful of children’s mischief in this regard.
• Avoid severe mechanical shock.
When the player is subjected to severe vibration
while traveling over a rough surface, playback
may be intermittent. When a situation like this
occurs, resume playback after returning to a
smoother road.
• About dew condensation.
In cold or rainy weather, just as the interior glass
surface gets fogged, dew (water condensation)
may also settle on the deck. When this occurs,
disc playback may become intermittent or
impossible. Dehumidify the air in the vehicle for a
while before resuming playback.
• Cleaning the disc slot.
The disc slot tends to get dusty. Clean it
occasionally to prevent accumulated dust from
scratching the discs.
Notes on operation
Operating precautions
11
Operating precautions
• The signal recorded on a compact disc is read by a laser beam, so
nothing touches the disc surface. A scratch on the recorded surface or a
badly warped disc may cause deteriorated sound quality or intermittent
playback. Observe the following precautions to ensure high quality sound
performance:
• Do not leave an ejected disc in the disc slot
for very long; the disc may warp. Discs
should be stored in their cases and kept
away from high temperature and humidity.
• Do not stick a piece of paper or tape on, nor
write on or scratch either side of a disc.
• Discs spin at a high speed inside the deck.
Keep cracked or warped discs out of the
player to avoid damaging it.
• Avoid touching the recorded surface when
handling a disc; handle discs by their edges.
About compact discs
12
Operating precautions
About CD accessories
• Do not use accessories
(stabilizers, protective seals, laser
lens cleaners, etc.) sold for
“improving sound performance”
or “protecting CDs.” The changes
in CD thickness or outside
dimensions made by these
accessories may cause problems
in the player.
About brand new CDs
• You may notice that some brand
new discs are rough around the
center hole or outside edge.
Remove the rough edges with
the side of a ballpoint pen, etc.
Rough edges may prevent
proper loading in the deck.
Flakes from the rough edges
may also stick to the recorded
surface and interfere with
playback.
Rough Edges
Ballpoint
pen
Flakes
Recorded surface
Rough
Edges
• Please be sure NOT to attach any
ring-shape protector (or other
accessory) to your discs. Those
protectors are commercially
available and said to protect disc
and to improve sound quality
(and antivibration effect), but they
can do more harm than good in
regular uses. The most common
problems are Insert/Eject related
problems and "No playback"
problems due to the protector
ring that came off in the disc
mechanism.
13
Operating precautions
About borrowed CDs
• Do not use a CD with glue or
remnants of adhesive tape or
labels. They may cause the CD
to get stuck inside or damage
the deck.
How to remove CDs
• When removing the ejected disc,
pull it straight out along the slot.
Pressing downward in the
process may scratch the
recorded surface of the disc.
OKAY
NO GOOD
About irregularly-shaped CDs
• Specially-shaped CDs, like
heart-shaped or octagonal CDs,
cannot be played. Do not
attempt to play them, even with
an adapter, since they may
damage the player.
• Use a commercially available compact disc
cleaner to clean a CD, wiping lightly from the
center to the edge.
• Do not use benzine, thinner, LP record spray
or other cleaners on CDs. They may damage
a CD’s finish.
XXXX
XXXX
XXXX
About cleaning a CD
14
Names of controls and parts
Names of controls and parts
Switches disc modes and switches.
Ejects compact disc.
Selects radio preset channels and performs disc mode
functions.
Inserts compact discs.
Switches screen display.
Automatically finds radio reception and fast forward/rewind.
Selects radio stations and CD tracks.
Returns to previous screen.
Turns function mode ON/OFF.
Resets deck functions to default settings.
Turns deck power ON/OFF.
Switches to radio mode and switches radio bands.
Adjusts volume and performs other functions.
[DISC] button
[ (EJECT) ] button
Buttons [1] to [6]
Disc slot
[DISP] button
[SEEK /FAST ] button
[SEL] button
[RTN] button
[FUNC] button
[RESET] button
[PWR] button
[FM AM] button
[AUDIO CONTROL] button
①② ④ ⑤⑥③
⑫⑪ ⑩⑨⑧⑥
⑦
⑬
③
15
ESN (Key CD) security operating procedure
How to program the Key CD
Check that the Power is OFF.
1
Press and hold button [6], then the [FUNC] button, and
hold both for more than one second.
2
A [SEC] message appears, then in two seconds it will change
to [DISC].
The CD3403 is now ready to accept your Key CD in the CD
slot.
Insert the CD into the slot.
3
A [SEC] message appears, then the Key CD is ejected.
•If there is a problem with the inserted CD, an [ERR] message
will appear for two seconds and the CD will be ejected. Reinsert
the ejected CD.
•If a CD causes the [ERR] message to appear twice in a row, try
another CD.
•The Security indicator will flash whenever the vehicle’s ignition
is switched off.
ESN (Key CD) security operating procedure
[FUNC] button
Button [6]
ATTENTION
16
ESN (Key CD) security operating procedure
How to cancel the Key CD
Turn OFF the Power.
1
Press and hold button [6], then the [FUNC] button, and
hold both for more than one second.
2
A [SEC] message appears, then in two seconds it will change
to [DISC].
The CD3403 is now ready to accept your Key CD in the CD
slot.
Insert your Key CD into the slot.
3
A [CANCEL] message appears, then the Key CD is ejected.
The Key CD is cancelled.
•This process cancels the protection for the ESN deck.
•If power to the ESN deck is disconnected, then
reconnected, a Key CD will not need to be inserted in order
to return the unit to normal operation.
•Inserting a CD other than the Key CD will not cancel the
protection. Instead, the normal CD playback mode will
activate.
[FUNC] button
Button [6]
ATTENTION
17
ESN (Key CD) security operating procedure
How to change the Key CD
First, cancel the existing Key CD.
1
Refer to “How to cancel the Key CD.”
Next, program a new Key CD.
2
Refer to “How to program the Key CD.”
How to resume normal operation
(ESN security lock out)
If power is disconnected while ESN security is active (a Key CD was
programmed), operation is disabled until power is restored and the
unit unlocked. Follow this procedure to resume normal operation.
When the power is turned on after disconnecting the
battery power, a [SEC] message will appear for two
seconds. Thereafter, the message changes to [DISC]
and the CD3403 is ready to accept your Key CD into the
slot.
1
Insert your Key CD.
2
If the correct CD is inserted, an [OK] message will appear for
two seconds and the CD will begin playing.
•If an incorrect CD is inserted, an [ERR] message will appear
for two seconds, after which the CD will be ejected.
•You must use the same CD used for Key CD programming;
a duplicate CD may not work properly.
ATTENTION
18
ESN (Key CD) security operating procedure
What happens if an incorrect CD is
inserted?
An [ERR] message will be appear, then change to a
flashing [DISC], then the CD will be ejected.
1
You will have five uninterrupted attempts to insert the correct
CD.
Press the [FUNC] button.
4
You will have five more attempts the correct disc.
After the 5th incorrect attempt, the display reads [HELP].
2
If [HELP] appears on the screen, press button [6], then
the [FUNC] button, and hold them for five seconds.
3
Number of errors: Numbers indicated the number of errors that
occurred.
O Note O
If after 10 tries the correct Key CD is not inserted, the display
reads [CALL800]; the unit must be returned to Eclipse to be
reset. In this case, please contact your Eclipse dealer for
assistance or call Eclipse directly at (800) 233-2216.
Button [6]
[FUNC] button
Your key CD can be easily forgotten. Write the
album name in a reminder note (See Page 69).
ATTENTION
19
ESN (Key CD) security operating procedure
How to turn the security indicator on/off
With the power OFF, press button [2], then the [FUNC]
button and hold both for more than one second.
1
[IND. FLASH] or [IND. -----] appears on the display.
2
[IND. FLASH] means the security indicator will flash when the
vehicle’s ignition is off, and [IND. -----] means it will not. Repeat
the above steps to reactivate the flash mode.
Once ESN security is activated, the indicator flashes whenever the
vehicle’s ignition is turned off, warning potential thieves that the unit
is protected. However, if you do not want this visible deterrent, it may
be turned off.
How to read the Electronic Serial Number
Turn OFF the Power.
1
Press button [4], then the [FUNC] button, and hold both
for more than one second.
2
[ESN] appears on the display, followed by an eight-digit
number; this number is your electronic serial number (ESN).
You may use this number to identify your Eclipse CD3403 in
the event it is recovered after being stolen.
Button [2]
[FUNC] button
Button [4]
20
Basic operation
Turning the power on and off.
When the power is turned on, the state used when the power was
turned off such as CD and tuner playing is restored.
When the vehicle has no ACC position on the ignition switch, care is
needed when turning off the deck. Follow Step 2 or Step 3 when
turning off the power.
Turning the power on and off
When power is OFF, press [PWR] button.
1
The power will come ON.
When power is ON, press the [PWR] button for less than
two seconds.
2
The power will go OFF and the deck will be in Standby.
When power is ON, press the [PWR] button for more
than two seconds.
3
The power will go completely OFF.
This section covers basic operating procedures. For additional
details, please refer to the sections on specific functions.
If a car is not equipped with an ACC position (for example, a
European car), keep the [PWR] button depressed for more than
two seconds.
Basic operation
[PWR] button
ATTENTION
21
Basic operation
Listening to a CD
Insert a CD into the disc slot, label side up.
1
The CD will start playing.
When a CD is already loaded, press the [DISC] button to switch
to the CD mode.
[DISC] button
ATTENTION
22
Basic operation
Listening to the tuner
Press the [FM AM] button.
1
This will turn the tuner on.
Press the [FM AM] button to switch to the desired FM or
AM bands.
2
Radio bands will switch from FM1 ➔ FM2 ➔ FM3 ➔ AM in
order each time the button is pressed.
Turn the [SEL] button to the left or right to tune to a
station.
3
Turn to the right: Turnes to higher frequencies.
Turn to the leftt: Turnes to lower frequencies.
Press the [SEEK /FAST ] button to start the automatic
station search.
4
[SEEK ] button: Starts searching toward higher frequencies.
[FAST ] button: Starts searching toward lower frequencies
If stations have been stored in memory, pressing a button
from [1] to [6] will directly select a station. (Refer to the section
“Manually setting stations into memory” on page 40)
[SEEK ] button
[AUDIO CONTROL] button
[FM AM] button
[FAST ] button
[SEL]
button
Adjusting audio volume
Turn the [AUDIO CONTROL] button to the left or right.
1
Turn to the right: Increases the volume.
Turn to the left: Decreases the volume.
Do not adjust the volume or other controls while driving the
vehicle. Do so only while parked in a safe location.
Buttons [1] to [6]
ATTENTION
Warning
23
Basic operation
Various audio control modes may be fine-tuned using this
procedure.
Modes will switch in the order shown below each time the
button is pressed.
Switching audio control modes
Press the [AUDIO CONTROL] button for less than one
second to select the item to be adjusted.
1
[AUDIO CONTROL] button
VOL BASS TREB BAL FAD
Adjusts volume.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Increases the volume.
Turn to the left: Decreases the volume.
Adjusts treble level.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Emphasizes high sounds.
Turn to the left: Softens high sounds.
Adjusts bass level.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Emphasizes low sounds.
Turn to the left: Softens low sounds.
VOL (VOLUME) Mode
BASS Mode
TREB (TREBLE) Mode
24
Basic operation
Adjusts left/right speaker balance.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Emphasizes right speakers.
Turn to the left: Emphasizes left speakers.
Adjusts front/rear speaker balance.
Turn the [AUDIO CONTROL] button to the left or right.
Turn to the right: Emphasizes front speakers.
Turn to the left: Emphasizes rear speakers.
BAL (BALANCE) Mode
FAD (FADER) Mode
The loudness control may be turned on to emphasize low and high
frequencies at low volume levels.
Loudness compensates for the apparent weadness of low and high
frequencies at low volume by boosting the bass and treble levels.
Enabling the loudness control
Press and hold the [AUDIO CONTROL] button until the
[LOUD ON] display appears on the screen.
1
[AUDIO CONTROL] button
To disable the loudness feature, repeat the above procedure to
display the [LOUD OFF] indication.
ATTENTION
25
Basic operation
A variety of settings can be changed.
The function mode is activated.
Setting items will be displayed in the following order when the
[SEL] button is turned to the right.
Making changes with Function Mode
Press the [FUNC] button.
1
Turn [SEL] button in either direction to display setting
items for selection.
2
[SEL]
button
[FUNC] button [RTN] button
The receiver is set at the factory to emit a beep tone in
response to button operation. The guide tone feature may be
disabled in the following procedure:
Turn [SEL] button to select GUIDE TONE.
Press the [SEL] button.
The Guide Tone Mode will be switched ON/OFF.
Turn [SEL] button to select ON or OFF.
Press the [RTN] button.
At this time, other adjustments can also be made in
Function Mode.
Press the [FUNC] button to exit Function Mode.
54321
Disabling the guide tone feature (for button operation)
GUIDE TONE CLOCK ADJ
26
Basic operation
This receiver uses the 12-hour display notation.
Turn [SEL] button to select CLOCK ADJ.
Press the [SEL] button.
The clock adjustment mode is activated.
Turn [SEL] button to display the item to be selected for
adjustment.
Hours, minutes or exact hour will be switched each time the
button is turned.
Press the [SEEK /FAST ] button.
[SEEK ] button: Turns the time forward.
[FAST ] button: Turns the time back.
To set the clock to 0 minutes, 0 seconds (an exact hour),
press the [SEEK /FAST ] button.
For example:
At 3:29: Pressing the [SEEK /FAST ] button returns to 3:00.
At 3:30: Pressing the [SEEK /FAST ] button advance to 4:00.
Press the [RTN] button.
At this time, other adjustments can also be made in
Function Mode.
Press the [FUNC] button to exit Function Mode.
654
3
2
1
[SEL]
button
[SEEK ] button
[FAST ]
button
Setting the Time
[FUNC] button [RTN] button
27
How to operate the CD player
Listening to CDs
Press the [DISC] button.
1
First press the [DISC] button to switch to the disc mode. It is
assumed here that a CD has already been loaded into the unit.
This starts CD play.
Playback may be intermittent when there is a scratch on a CD or
when the recorded side is dirty.
How to operate the CD player
[DISC] button
Caution
28
How to operate the CD player
Advancing to the next track or returning to
the beginning of the track being played
Turn the [SEL] button to the left or right.
1
Turn to the right: Advances to the next track.
Turn to the left: Returns to the beginning of the track being
played. (Repeat turning for previous tracks.)
Playing the beginning of tracks (SCAN)
Press button [4].
1
Pressing the button causes the player to move up to the next
track and play it for 10 seconds, then move up to the next track
and play it for 10 seconds, and so on until the button is
pressed again.
•To continue playing a desired track, press the button again to
stop scanning.
•After the entire disc is scanned once, ordinary playback starts
from the point where scanning started.
Fast forward or rewind the song currently being played.
[SEEK ] button: Fast forward.
[FAST ] button: Rewind.
Fast Forward/Rewind
Press and hold the [SEEK ] or [FAST ] button.
1
[SEEK ] button
[FAST ] button
[SEL]
button
Button [4]
ATTENTION
29
How to operate the CD player
Repeating the same track (REPEAT)
Press button [5] to repeat the track being played.
1
To cancel, press button [5] again.
Playing tracks in random order (RANDOM)
Press button [6] to play the tracks in random order.
1
To cancel, press button [6] again.
•Doing random playback, press button [5] to repeat the track
being played. To cancel repeat play (go back to random play),
press button [5] again.
During playback a particular track: The track being played is
played repeatedly.
During searching: The following track is played repeatedly.
•Occasionally the same track happens to be played (selected)
two or more times in a row; this is normal operation and is no
sign of a problem.
•When any of the functions - “Playing the beginning of tracks,”
“Repeating the same track” and “Playing tracks in random
order” - is selected, a message such as [SCAN], [REPEAT] or
[RANDOM] appears on the display to verify the current function.
Buttons [5] and [6]
ATTENTION
30
How to operate the CD player
Ejecting the disc
Press the [ (EJECT)] button.
1
Disc is ejected.
[ (EJECT)] button [DISP] button
Displaying CD TEXT
Press the [DISP] button.
1
Each time the button is pressed, the following will be displayed
in order.
Elapsed time ➔ Disc title/Track title* ➔ Clock
*: The display are shows a maximum of 10 characters and then scrolls
to display the remaining characters.
After the disc title is displayed, the track title will be displayed by
scrolling. After the track title is scrolled the display will be fixed.
Only the built-in CD player supports CD TEXT. If the CD came with a
logo shown below, it is recorded with a disc title and track titles.
These information will be displayed during playback.
31
How to operate the MP3 player
How to operate the MP3 player
About MP3
MP3 (MPEG Audio Layer III) is a standard format for audio compression
technology. By using MP3, a file can be compressed to one-tenth the size
of the original.
This deck has limitations on MP3 file standards and recorded media and
formats that can be used.
MP3 files have an "ID3 Tag" that allows input of information so that data
such as song title and artist can be saved.
This deck supports ID3v.1.0 and ID3v.1.1 tags.
What is MP3?
Playable MP3 file standards
ID3 tags
The making of MP3 files by recording from sources such as
broadcasts, records, recordings, videos and live performances
without permission from the copyright holder for uses other than
personal enjoyment is prohibited.
• Supported standards: MPEG-1 Audio Layer III
MPEG-2 Audio Layer III
MPEG-2.5 Audio Layer III
• Supported sampling frequencies: 32, 44.1, 48 (kHz)
• Supported bit rate: 8, 16, 24, 32, 40, 48, 56, 64, 80, 96, 112, 128, 160,
192, 224, 256, 288, 320 (kbps)
* Supports VBR.
* Does not support free format.
• Supported channel modes: stereo, joint stereo, dual channel, monaural
ATTENTION
32
How to operate the MP3 player
Media capable of playing MP3 includes CD-ROM, CD-R and CD-RW discs.
Compared to CD-ROM media commonly used for music discs, CD-R discs
are fragile in high temperature/high humidity environments and one section
of the CD-R may become incapable of playback. Fingerprints or scratches
on the disc may prevent playback or cause skipping during playback.
Sections of a CD-R may deteriorate if left inside a vehicle for long periods of
time. It is also recommended that CD-R discs be kept in a light-blocking
case because the discs are vulnerable to ultra-violet light.
Media
Format of discs
The format of discs to be used must be ISO9660 Level 1 or Level 2.
Control items for this standard are as follows:
• Maximum directory layers: 8 layers
• Maximum characters for folder names/file names: 40 (including "." and 3
letter file extension)
• Allowable characters for folder names/file names:
A~Z, 0~9, _ (underscore)
• Number of files/folders possible on a single disc: 512
• Total number of folders possible on a single disc: 255
• Maximum folders this deck can recognize: 255*
*: A root directory is counted as one folder.
F2
Root Directory (F1)
F158
Folder 2
Folder 158
Folder 159
F255
Folder 255
001.mp3
002.mp3
003.mp3
004.txt
005.mp3
001.mp3
002.mp3
F159
[Configuration example for CD supporting MP3]
Number of files/folders possible on a single
disc is 512.
Files aside from MP3 files (Example: 004.txt)
also count as single files.
33
How to operate the MP3 player
Only files with the MP3 file extension ".mp3" can be recognized as MP3 and
played. Be sure to save MP3 files with the ".mp3" file extension. The "MP"
letters of the file extension will be recognized whether entered as
uppercase letters or lowercase letters.
Multi-sessions are supported, and playing of CD-R and CD-RW discs with
annotated MP3 files is possible. However, when "Track at once" has been
written, close the session or process the warning message. Standardize the
format of each session without changing the format.
When a disc with recorded MP3 files is inserted, the deck first checks all the
files on the disc. No sound is output while the deck is checking the files on
the disc. It is recommended that the disc be recorded without files other
than MP3 files and without unnecessary folders in order to speed up the
checking of disc files by the deck.
It is possible that playing time will not be correct, depending on the writing
condition of the MP3 file.
* It is possible that playing time will not be correct when VBR Fast Up/Down
is operated.
Names of MP3 folders and files within the same level are displayed in the
following order.
1. MP3 folders displayed first, by ascending order of numbers, letters.
2. Files displayed next, by ascending order of numbers, letters.
If the ".mp3" file extension is attached to a file other than an
MP3 file, that file will be mistakenly recognized by the deck as
an MP3 file and played, resulting in loud noise output that can
damage the speakers. Be sure to avoid attaching the ".mp3" file
extension to files that are not MP3 files.
File names
Playing MP3
MP3 playing time display
Multi-sessions
Display order of MP3 file/folder names
Caution
34
How to operate the MP3 player
Listening to MP3 file
Press the [DISC] button.
1
This starts MP3 file play.
Playback may be intermittent when there is a scratch on a CD or
when the recorded side is dirty.
Note
When music data recorded in the normal way (CD-DA) is
present on the same disc with MP3 music files, the normally
recorded music data will be played. To listen to the MP3 music
files, press button [3].
Button [3]
[DISC] button
Caution
35
How to operate the MP3 player
Advancing to the next track (file) or returning to
the beginning of the track (file) being played
Turn the [SEL] button to the left or right.
1
Turn to the right: Advances to the next track (file).
Turn to the left: Returns to the beginning of the track (file)
being played.
Repeat turning for previous tracks (files).
Skipping to the next or previous folder
Press button [1] or [2].
1
Button [1] : Selects the next folder.
Button [2] : Selects the next lower folder.
Fast forward or rewind the song currently being played.
[SEEK ] button : Fast forward.
[FAST ] button : Rewind.
Fast Forward /Rewind
In the root directory, when a file cannot replay, the system will
return to the first file that can perform a replay. (In the
configuration example, the file is returning to 001.mp3. See
page 32.)
Return to the root directory of the CD
Press and hold the [SEEK ] or [FAST ] button.
1
[SEEK ] button
[RTN] button
Buttons [1] and [2]
[FAST ]
button
[SEL]
button
Press the [RTN] button.
1
36
How to operate the MP3 player
Press the button briefly to play just the first 10 seconds of each
song for all the files in the current folder being played.
Pressing the button until [ALL SCAN] is displayed will play just
the first 10 seconds of the first song in each folder.
Playing the beginning of files (SCAN)
Press button [4].
1
Press the button briefly to repeat the file being played.
Pressing the button until [ALL REPEAT] is displayed will repeat
all the files in the current folder being played.
To cancel, press button [5] again.
Repeating the same file (REPEAT)
Press button [5].
1
•To coutinue playing a desired track, press the button again to
stop scanning.
•After the entire disc is scanned once, ordinary playback starts
from the point where scanning started.
Buttons [4] and [5]
ATTENTION
37
How to operate the MP3 player
•Occasionally the same file happens to be played (selected) two
or more times in a row; this is normal operation and is no sign of
a problem.
•Doing random playback, press button [5] to repeat the file
being played. To cancel repeat play (go back to random play),
press button [5] again.
During playback a particular file: The file being played is played
repeatedly.
During searching: The following file is played repeatedly.
Press the button briefly to randomly play the files in the current
folder being played.
Pressing the button until [ALL RANDOM] is displayed will
randomly play the files in all the folders.
To cancel, press button [6] again.
Playing files in random order (RANDOM)
Press button [6].
1
Each time the button is pressed the following will be displayed
in order.
Elapsed Time ➔ Folder Name/File Name* ➔ Tag ➔ Clock
*: The display area shows a maximum of 10 characters and
then scrolls to display the remaining characters.
After the folder name is displayed, the file name will be
displayed by scrolling. After the file name is scrolled, the
display will be fixed.
Displaying title
Press the [DISP] button.
1
[DISP] buttonButtons [5] and [6]
ATTENTION
38
How to operate the tuner
Tuning to a station
Radio bands will switch from FM1 ➔ FM2 ➔ FM3 ➔ AM in
order each time the button is pressed.
First, press the [FM AM] button to start tuner operation.
There are automatic and manual methods for setting stations in
memory. The receiver will accept up to 24 stations in memory: six in
AM and 18 in FM (6 each for FM1, FM2 and FM3.) (Initial setting)
Press the [FM AM] button to switch to the desired FM or
AM bands.
1
How to operate the tuner
Turn the [SEL] button to the left or right to tune to a
station.
2
Turn to the right: Tunes to higher frequencies.
Turn to the left: Tunes to lower frequencies.
Press the [SEEK /FAST ] button to start the automatic
station search.
3
[SEEK ] button: Starts searching toward higher frequencies.
[FAST ] button: Starts searching toward lower frequencies.
At times, it may be difficult to maintain optimum reception
because the antenna affixed to your vehicle is in motion
constantly (relative to the broadcast antenna), encountering
continuous variation in the received radio signals’ strength. Other
factors affecting reception include interference from natural
obstacles, sign posts, etc.
[SEEK ] button
[SEL]
button
[FM AM] button
[FAST ] button
ATTENTION
39
How to operate the tuner
Press the [SEL] button for more than two seconds until a
beep is heard.
2
The automatic preset mode starts.
The [ASM ON] indicator on the screen flashes, and stations are
automatically entered in memory under buttons [1] to [6].
These buttons are called preset buttons.
•Press any numbered button to select the station whose
frequency is indicated right above the button.
•When a new station is set in memory, the station previously set
in memory will be deleted.
•If there are fewer than six receivable stations, the stations set in
the remaining buttons will be retained.
Press the [FM AM] button to switch to the desired FM or
AM bands.
1
Entering stations into memory automatically
(The automatic preset mode: ASM)
Radio bands will switch from FM1 ➔ FM2 ➔ FM3 ➔ AM in
order each time the button is pressed.
[FM AM] button
[SEL]
button
Buttons [1] to [6]
ATTENTION
40
How to operate the tuner
Manually setting stations into memory
Press the [FM AM] button to switch between FM and AM.
1
Turn the [SEL] button to the right or left to tune to the
station to be entered in memory.
2
This section covers the setting of stations in memory under the
numbered buttons.
Select any button, from [1] to [6], and press it for more
than two seconds.
3
The tuned station is now memorized and set in the button
selected. Repeat the procedure to set additional manually
tuned stations in memory, in turn, for buttons [1] to [6]. These
buttons are called the preset buttons.
If the vehicle’s battery is disconnected (for repairs to the
vehicle or for removing the receiver), all stations in memory will
be lost. In such a case, set stations in memory again.
[FM AM] button
Buttons [1] to [6]
[SEL]
button
Caution
41
How to operate the tuner
Preset station scan
Press the [SEL] button for less than one second.
1
[P SCAN] will appear at the top of the display, and stations
stored under preset buttons [1] through [6] will be played for
five seconds each.
To stop the preset scan mode at a desired station, press
the [SEL] button again.
2
The receiver will stay tuned to the desired station.
This function enables reception of all the stations in the preset
buttons for five seconds each.
[DISP] button
Switching the display
Press the [DISP] button.
1
Each press of the button switches the display the clock and
current frequency.
Buttons [1] to [6]
[SEL]
button
42
How to operate the tuner
FM reception characteristics
A characteristic of transmitted signals is that lower frequencies
travel further. FM frequencies are much higher than AM’s
(similar to a ray of light): they won’t bend but they will reflect.
Often, they will be interrupted by tall buildings, mountains, etc.,
taking direct and indirect paths to your vehicle’s antenna. The
distance at which FM stations can be received satisfactorily is
usually not nearly as far as that which AM stations can be
received.
In weak signal or “fringe” reception areas, FM stations may
fade out completely, or fade in and out. When driving in weak
signal areas, such as near hills, through valleys or tunnels,
among tall buildings, etc., you may encounter unusual noise
interference. THIS IS NOT A TUNER PROBLEM. In this case,
you can only wait until you are in a better reception area, tune
to a stronger station, or reduce the treble level.
In general, FM has much better tonal quality than AM. However, FM
and FM stereo reception encounter several characteristic problems
not encountered with AM. FM is more difficult to receive than AM in a
moving vehicle. The following are explanatory notes on what to
expect from FM reception and on how to get satisfactory
performance.
Ionosphere Ionosphere
AM Radio Waves FM Radio Waves
FM RECEPTION DIFFERS FROM AM
FADING OUT
43
How to operate the tuner
A home receiver can catch weak FM stereo signals through the
use of a tall, directional or ultra-sensitive antenna. In a moving
vehicle, the area for good reception is limited because of
varying conditions encountered while driving, including the
types and heights of broadcast antenna structures, signal
strength, engine noise, etc. For best reception with manual
antenna, extend the antenna mast as far as possible.
Reception quality varies depending on the power of the FM
station, natural and artificial barriers,weather conditions, etc.
Transmitting Antenna 100 Meters High
Effective Radiation Power 1kW
FM Stereo Auto Radio 20 km
FM Monaural Auto Radio 50 km
Home FM Stereo Receiver 100 km
RECEPTION AREA OF FM BROADCASTS
The reflection characteristics of FM waves cause another
problem called multipath–FM wave signals reflecting off of
buildings, mountains, etc. When the antenna receives direct
and reflected waves at the same time, distortion of sound in the
treble range often occurs, such as static or harsh-sounding
voices. THIS IS NOT A TUNER PROBLEM. Only moving to
another area with a clearer signal path can remedy the
situation.
REFLECTED
WAVE
REFLECTED
WAVE
DIRECT
WAVE
MULTIPATH
44
How to use an optional Card remote control
Cleaning the remote control
Precautions in use of the remote control
• Be careful when handling the control, especially because it is
small and light. Dropping or striking it hard may damage it,
wear out the battery or cause a malfunction.
• Keep the remote control free of moisture, dust and water. Do
not subject it to shock.
• Do not place the remote control unit where it will get hot, such
as on the dashboard or near a heater vent. Allowing the
remote control unit to overheat may warp its case or cause
other problems.
• Do not operate the remote control unit while driving because
doing so could cause an accident.
• When using the remote control, point it directly at the remote
control light receptor.
• The light receptor may not operate correctly if it is exposed to
bright light such as direct sunlight.
• Be sure to press the [PWR] button on the main unit for more
than two seconds to shut it down before leaving the car, or the
car battery may be run down. When the main unit is shut down,
the remote control will not work.
• Remove the batteries from the remote control unit whenever it
is not to be used for a long time.
• Use a dry cloth to keep the unit clean. If the remote control
unit gets extremely dirty, clean it with a cloth moistened in
dilute liquid detergent. Do not use alcohol or thinner; these
compounds may damage the finish.
• In no event should benzine or thinner be used. These
substances will damage the case or finish.
How to use an optional Card remote control
45
How to use an optional Card remote control
[PWR]
button
[MUTE]
button
[+] button
[
-
] button
Remote-control
light receptor
Turning the power on/off
Press the [PWR] button.
1
The power turns on or off each time the button is pressed.
When the power is turned on, the state used when the power was
turned off such as CD and tuner playing is restored.
When the main unit is shut down, the remote control will not work.
Adjusting the audio volume
Press the [+] or [-] button.
1
[+] button: Increases the volume.
[
-
] button: Decreases the volume.
Cutting the volume instantly (muting)
Press the [MUTE] button to cut the volume or restore it
instantly.
ATTENTION
46
How to use an optional Card remote control
[MODE] button
[BAND] button
Switching playback modes
Press the [MODE] button.
1
Press the button to switch modes in the following sequence:
Tuner Disc
How to play the tuner
Selecting the FM/AM band
Press the [BAND] button.
Each press will switch tuner modes from FM1
➔ FM2 ➔
FM3 ➔ AM.
1
Select the tuner mode first.
47
How to use an optional Card remote control
[BAND] button
[ PRESET CH ] buttons
[ TUNE•SEEK ] buttons
Selecting a station (manually or automatically)
Press the [ TUNE•SEEK ] button.
[ ] button: Tunes to higher frequency stations.
[ ] button: Tunes to lower frequency stations.
1
A short tap of the button will allow manual station tuning.
Pressing for more than one second will start automatic tuning.
Selecting preset stations
Press the [ PRESET CH ] button.
[ ] button: Select the next higher number preset button.
[ ] button: Select the next lower number preset button.
1
Switching disc mode
Press the [BAND] button.
1
A total of six stations may be selected (preset tuning) out of
those already set in memory through the main unit. (Refer to
“Manually setting stations into memory,” page 40.)
How to play CDs
Select the disc mode first.
48
How to use an optional Card remote control
[ TRACK•APS ] buttons
Press the [ TRACK•APS ] button.
[ ] button: Skips to the next track.
[ ] button: Returns to the beginning of the track being
played. (Press repeatedly to move to previous
tracks.)
1
Hold the [ ] button down to fast forward, or the [ ] button to
rewind through the track being played.
Advancing to the next track or returning to
the beginning of the track being played
ATTENTION
49
How to use an optional Card remote control
Replacing the battery
On the back of the remote control, while pressing the
locking knob on the battery slot cover toward your right,
pull out the battery carrier with your fingernail.
1
Use one CR2025 battery.
Unlock
Remove the old battery, then place the new one in the
carrier with the (+) mark facing up.
2
Push in the carrier until it snaps into place.
3
Be extremely careful not to swallow the battery.
To prevent accidents, store batteries out of the reach of
children. If a child has swallowed one, consult a doctor
immediately.
Warning
Caution
50
How to use an optional NOB remote control
Cutting the volume instantly (muting)
Press the [MUTE] button to cut the volume or restore it
instantly.
DISC
BAND MODE
MUTE
ILLUMI
PWRE-COM
TRACK
TUNE SEEK
P
U
S
H
-
M
O
D
E
[PWR] button
[MUTE] button
Remote-control
light receptor
[AUDIO
CONTROL]
button
Turning the power on/off
Press the [PWR] button.
1
The power turns on or off each time the button is pressed.
When the power is turned on, the state used when the power was
turned off such as CD and tuner playing is restored.
Adjusting the audio volume
Press the [AUDIO CONTROL] button, and turn it to the
left or right.
1
Each press of the button will switch the audio control modes.
Turn to the right: Increases the volume.
Turn to the left: Decreases the volume.
When the main unit is shut down, the remote control will not work.
How to use an optional NOB remote control
ATTENTION
51
How to use an optional NOB remote control
DISC
BAND MODE
MUTE
ILLUMI
PWRE-COM
TRACK
TUNE SEEK
P
U
S
H
-
M
O
D
E
[MODE] button[BAND] button
Switching playback modes
How to play the tuner
Press the [MODE] button.
1
Press the button to switch modes in the following sequence:
Tuner Disc
Selecting the FM/AM band
Press the [BAND] button.
Each press will switch tuner modes from FM1 ➔ FM2 ➔
FM3 ➔ AM.
1
Select the tuner mode first.
52
How to use an optional NOB remote control
DISC
BAND MODE
MUTE
ILLUMI
PWRE-COM
TRACK
TUNE SEEK
P
U
S
H
-
M
O
D
E
[ TUNE•SEEK ] buttons
[ DISC ] buttons
[BAND] button
Selecting a station (manually or automatically)
A short tap of the button will allow manual station tuning.
Pressing for more than one second will start automatic tuning.
Press the [ TUNE•SEEK ] button.
[ ] button: Tunes to higher frequency stations.
[ ] button: Tunes to lower frequency stations.
1
How to play CDs
Switching disc mode
Press the [BAND] button.
1
Select the disc mode first.
Selecting preset stations
A total of six stations may be selected (preset tuning) out of
those already set in memory through the main unit. (Refer to
“Manually setting stations into memory,” page 40.)
Press the [ DISC ] button.
[ ] button: Selects the next higher number preset button.
[ ] button: Selects the next lower number preset button.
1
53
How to use an optional NOB remote control
DISC
BAND MODE
MUTE
ILLUMI
PWRE-COM
TRACK
TUNE SEEK
P
U
S
H
-
M
O
D
E
[ TRACK ] buttons
Advancing to the next track or returning to the
beginning of the track being played
Press the [ TRACK ] button.
[ ] button: Skips to the next track.
[ ] button: Returns to the beginning of the track being
played. (Press repeatedly to move to previous
tracks.)
1
Hold the [ ] button down to fast forward, or the [ ] button to
rewind through the track being played.
ATTENTION
54
How to use an optional NOB remote control
To prevent accidents, store batteries out of the reach of
children. If a child has swallowed one, consult a doctor
immediately.
Replacing the battery
Remove the back cover of the remote control unit by
gently pressing and sliding it in the direction indicated by
the arrow.
1
Use two AA-size batteries.
Install the two batteries provided into the compartment
as illustrated inside the compartment.
2
Return the back cover into place by sliding it in the
direction indicated by the arrow.
3
Warning
55
How to use an optional NOB remote control
•Be extremely careful not to swallow the battery.
•The battery life is approximately one year. If the remote
control unit does not operate correctly or if the button lamp
gets dim, replace the batteries.
•Be sure to orient the batteries correctly so that the positive
and negative poles match the diagram.
•Do not use one new battery and one old one; use two new
batteries.
•Use only two of the same kind of battery.
•If any liquid is seen leaking from the batteries, remove both
batteries and dispose of them properly. Thoroughly clean
the battery compartment with a dry cloth. Then install new
batteries.
Caution
56
If you have a question:
First check the items mentioned below before attempting to
troubleshoot problems.
If a problem occurs, for instance when the unit does not respond
to any button presses, or the display doesn't work correctly,
press the [RESET] button using a sharp tool.
Pressing the [RESET] button will delete all the entries from
memory. The settings will return to those made at the factory
prior to shipment.
If you have a question:
[RESET] button
Caution
57
If you have a question:
Information Code Table When "INFO " flashes on the indicator
Nos.3,5 are displayed.
Information Contents Explanation and remedial action to take
3 DISCS ARE DIRTY OR The loaded disc is dirty or upside down. Check
DAMAGED it for proper orientation and verify it is clean.
5
CD PLAYER FAILS
•The CD player is inoperative for some reason.
MECHANICALLY
Go through the magazine removal procedure.
•If a magazine fails to eject, have your dealer fix
the problem.
Displayed information (for troubleshooting)
The information listed in the chart below is displayed to show the
status of the CD player. Refer to the chart for the appropriate action.
58
If you have a question:
The remote
control does
not work.
No guide
tone sounds.
Frequencies
or titles set in
memory are
deleted.
Power does
not turn on.
Dead or
weak sound
Common
to all
Is the volume control up sufficiently?
ProblemMode Causes
Remedial action
to take
Refer
to page
Is the fader or balance control set far
to one side?
Other probable causes include
broken audio-signal wiring or a faulty
speaker.
Are too many electrical items
installed, causing a lack of power?
Other probable causes include a
run-down car battery, broken power
or interconnection wiring.
Has the car battery been disconnected
for repair or checked out?
Are too many electrical items
installed and causing lack of
available power?
Other probable causes include rundown car battery, broken power or
interconnection wiring.
Is the guide tone disabled?
Is the battery low?
Is the battery installed in reverse
polarity?
Is direct sunlight hitting the remote
control light receptor?
Other probable causes include a
malfunctioning remote control.
Turn up the volume control.
Readjust the fader and
balance controls to more
normal positions.
Have your dealer check
the problem.
Have your dealer check
the problem.
Have your dealer check
the problem.
Reenter them into
memory.
Have your dealer check
the problem.
Have your dealer check
the problem.
Enable the guide tone.
Replace battery.
Reinstall the battery in the
correct polarity.
Use the remote control
close to the receptor.
Have your dealer check
the problem.
22
23
39,
40
49,
54
49,
54
25
59
If you have a question:
CD
ProblemMode Causes
Remedial action
to take
Refer
to page
The disc cannot be
ejected.
The disc cannot be inserted.
The disc is ejected as soon
as it is insertaed.
Or, the disc cannot be
ejected.
The disc cannot be
changed.
Sound skips around.
Sound is intermittent.
Sound is bad in quality.
Is an extra label or seal
applied to the disc?
Are there rough edges,
deformations or
damaged areas on the
disc?
Is the disc damaged?
(scratched, warped, etc.)
Is the disc clean?
Is the player mounted at
a proper angle?
Is the player mounted
loosely?
Are you driving over a
rough surface?
If unknown
Do not apply labels or seals
to the disc.
Try inserting another disc.
Removed any burrs. Do not
use a deformed or
damaged disc.
Try another disc. Do not
play a damaged disc.
Clean the disc.
Have your
dealer
check it
out.
Avoid playback while
driving over rough surfaces.
Press the [DISC] button a
bit longer (forced Eject).
11
12
11
13
10
Mode Problem Causes Remedial action to take
Receives
no
stations,
or
receives
static
noise.
Tuner
38
38
Is the antenna retracted?
Is the tuner correctly tuned to a
station?
Are you driving outside the service
area of your preset stations?
Are you operating other equipment
with a computer, or a mobile phone,
in your vehicle at the same time as
your receiver?
Other problems may include a loose
or disconnected antenna cable, a,
bad antenna cable or a bad
Extend the antenna.
Tune to a station.
Tune to a local station.
(Please note, there may
be no local stations
servicing the area where
you are currently driving.)
Avoid operating such
equipment while using
the receiver.
Have your authorized
Eclipse retailer check the
problem.
Refer
to page
60
Specifications
<GENERAL>
Power Supply 14.4V DC (11-16V)
Current Drain 3A MAX
Dimensions (W x H x D)
In-Dash Unit 7" x 2" x 6-1/8" (178 x 50 x 155mm)
Mass (weight) Approx. 1.4kg
<FM TUNER>
Frequency Range 87.75~107.9MHz (200kHz step)
Usable Sensitivity 13dBf
Frequency Response 30~15,000Hz, 3dB
Stereo Separation 38dB
<AM TUNER>
Frequency Range 530~1,710kHz (10kHz step)
Usable Sensitivity 20µV
<CD SECTION
>
Frequency Response 20~20,000Hz, 3dB
Wow & Flutter Below measurable limits
Stereo Separation 76dB
S/N Ratio (A-weighted) 90dB
Dynamic Range 89dB
Total Harmonic Distortion 0.02%
<AUDIO AMPLIFIER
>
Power Output 13W x 4 (20~20,000Hz, 0.8% THD,
4Ω) Max 40W x 4
Output Level/Impedance 2.7V (0dB) /330Ω line-out
impedance
Tone Action Bass : 10dB at 100Hz
Treble : 10dB at 10kHz
Loudness +10dB at 100Hz/+6.0dB at 10kHz
Specifications
61
Before installation
No. Item Q'ty
1 Main unit 1
2 Mounting sleeve 1
3 Side bracket 2
4 Rear bracket 1
5 Bezel 1
6 Bushing 1
7 Self-tapping screw (6 x 16 mm) 2
8 Stud bolt 1
9 Flat head screw (5 x 8 mm) 4
10 Hex-head bolt (5 x 20 mm) 2
11 Hex nut (5 mm) 2
12 Interconnecting cable 1
Components
Before installation
O Note O
Be sure to disconnect the battery negative terminal before
installing the receiver.
62
Before installation
Installation angle
In order to maintain proper functioning, install the unit within an angle
of 30 degrees from horizontal (standard). If this is not done, sound
skipping or ejection of the CD may occur.
FRONT
STANDARD
WITHIN AN ANGLE
OF 30 DEGREES
63
Mounting instruction
Mounting the main unit
Insert the mounting sleeve into the opening in the vehicle
console.
1
Use a screwdriver or the like to bend the tabs in the
mounting sleeve to secure the mounting sleeve.
2
Attach the side brackets to the main unit using flathead
screws.
3
BEND THE MOUNTING
TABS.
DASH BOARD
OR CONSOLE
MOUNTING
SLEEVE
2
MAIN UNIT1
SIDE BRACKETS [ x 2 ]
3
FLAT HEAD
SCREWS [ x 2 ]
(5 x 8mm)
9
Mounting instruction
64
Mounting instruction
Mount the stud bolt to the main unit.
4
Insert the main unit into the mounting sleeve until it locks
in place.
5
Fasten the rear of the main unit using either method [A]
or [B].
6
Install the bezel on the main unit.
7
TOPTOP
BEZEL
5
MOUNTING SLEEVE
2
STUD BOLT
8
BUSHING
METAL OF
VEHICLE
DASH BOARD
OR CONSOLE
6
Select method [A] or [B] to suit the interior configuration of the
vehicle.
[A]
TOPTOP
BEZEL
5
MOUNTING SLEEVE
2
STUD BOLT
8
REAR BRACKET
4
SELF TAPPING
SCREW (6 x 16mm)
DASH BOARD
OR CONSOLE
7
NUT (5mm)
METAL OF
VEHICLE
11
BOLT
(5 x 20mm)
10
NUT (5mm)
11
[B]
65
Mounting instruction
Names of lead wires and destinations (refer to Page 67)
No. Name Wire color Destination
1 ACC Red Connect where the power comes on
when the ignition is in the ACC
position.
2 B+ Yellow Connect where the power is
constantly available, regardless of the
ignition switch's position.
3 Ground Black Connect where good body
grounding is available.
4
Antenna power supply
Blue Connect to the automatic-antenna
control terminal of the vehicle.
5
Lamp power supply
Orange/White
Connect to where power comes on
when the headlights are turned on.
6
Control power supply
Blue/White
Connect to the control terminal for
the external amplifier, etc.
7 & 8
Line-out terminals Connect to the RCA input connectors
of an external amplifier.
9 Speaker terminals Connect them to their respective
speakaers.
10
Cellular phone mute
Pink Connect to the ground output
terminal on a mobile phone.
O Note O
To prevent unconnected leads from shorting out, insulate them
by wrapping their tips with electrical tape. Similarly, insulate the
ends of connected leads.
If an external amplifier is to be connected to the receiver, be
sure to ground its outside housing to the vehicle body (a metal
part).
66
Mounting instruction
System
67
Mounting instruction
ANTENNA PLUG
CD3403
TO BATTERY + 12V (Permanent Supply)
INTERCONNECTING CABLE
2
16P
Yellow
Blue
Orange/White
Blue/White
Black
Red
TO GROUND
3
CELLULAR PHONE
10
FRONT
8
REAR
7
12
TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
TO ACC (Power Supply)
White
White/Black
Gray
Gray/Black
Green
Green/Black
Purple
Purple/Black
Pink
1
4
5
6
1) CD3403 Receiver, used alone
68
Mounting instruction
INSULATE EACH
WIRE WITH TAPE
INSULATE EACH
WIRE WITH TAPE
TO SIGNAL INPUT OF
AUXILIARY POWER
AMPLIFIER
CD3403
16P
ANTENNA PLUG
TO BATTERY + 12V (Permanent Supply)
INTERCONNECTING CABLE
2
Yellow
Blue
Orange/White
Blue/White
Black
Red
TO GROUND
3
12
TO POWER ANTENNA RELAY (Supply)
TO HEADLIGHT SWITCH (Illumination)
TO TURN-ON LEAD OF EACH UNIT (Supply)
TO ACC (Power Supply)
White
White/Black
Gray
Gray/Black
Green
Green/Black
Purple
Purple/Black
Pink
1
4
5
6
CELLULAR PHONE
(For mute)
10
2) CD3403 + Power Amplifier
IMPORTANT
RECORD YOUR “KEY CD”
HERE…
STORE YOUR “KEY CD”
ALONG WITH YOUR
OWNER’S MANUAL IN
YOUR SOCK DRAWER.
692
DIVISION OF FUJITSU TEN CORP. OF AMERICA
19600 SOUTH VERMONT AVENUE, TORRANCE, CA 90502
(310) 327-2151
090001-1439A700
0303 (Y.O)
CUSTOMER NOTICE
Please retain this booklet and write in the serial number of your CD3403 for
identification. The serial number is labeled or stamped on the chassis.
Serial No.
Loading...
