Introduction

For your safety in using the CD2000

Warnings and caution signs, illustrated below, are posted throughout this manual as well as on the CD2000. They show safe and correct ways to handle the main unit to prevent personal injury to you, others and to avoid property damage. Before reading through the manual, take time to read through and learn the important information listed in this section.

This "WARNING" sign indicates a situation in which incorrect

Warning

Caution

Please read all materials such as manuals and warranties that have come with the main unit. Eclipse will not be liability for unsatisfactory main unit performance due to failure to follow these

instructions.

WARNING

● Do not modify this system for use other than that specified herein. Also, do not deviate from the installation procedures described herein; Eclipse will not be held liable for damages including, but not limited to serious injury, death or property damage resulting from installations that enable unintended operation.

● This main unit requires 12V DC and should only be installed in a vehicle with a 12V negative ground electrical system. Any other installation may cause a fire or other severe damage to the main unit and the vehicle.

● Some main unit uses batteries. Never install main unit where young children can get access to batteries. If a battery is swallowed, seek medical attention immediately.

● When the vehicle is in motion, never take your eyes off the road to make adjustments to the main unit. You must pay attention to the road to avoid accidents, do not let the operation or adjustment of the main unit distract you from proper vehicle operation.

● The driver should not look at the screen while driving. Accidents may result if you are not paying attention to the forward direction.

● Do not put foreign objects in the loading slot of disc. Fires or shocks may result.

● Do not disassemble or alter this main unit. Accidents, fires or shocks may result.

● Do not let water, dust or foreign objects enter the internal parts of this main unit. Smoke,

fires or shocks may result.

● Pay attention to the location of the remote control. Traffic accidents or problems with driving may result if the remote control makes its way under the foot pedals etc. When the vehicle is in motion (Example: during stops, going around corners).

● Do not use when the main unit is malfunctioning (the screen is not lit or no sound comes out). Accidents, fires or shocks may result.

handling or disregard of this sign may result in death or serious personal injury.

This "CAUTION" sign indicates a situation in which incorrect handling or disregard of this sign may result in personal injury or may result solely in damage to property.

For your safety in using the CD2000

WARNING

● Always replace fuses with fuses of identical capacity and characteristics. Never use a higher capacity fuse than the original. Using the wrong type of fuse may cause a fire or severe damage.

● If foreign objects or water enters the main unit, smoke comes out, or there is a strange odor, stop using it immediately, and contact your dealer. Accidents, fires, or shocks may result if you continue to use it in these conditions.

● The driver should not change the CD while driving. As accidents may result if you are not paying attention to the forward direction, first stop the car at a safe location and then proceed.

● Plastic bags and wrappings may cause suffocation and death. Keep away from babies and children. Never put bag over your head or mouth.

CAUTION

● When changing the installation location for this main unit, please consult the dealer where you bought it for safety reasons. Expertise is necessary for removal and installation.

● Keep volume to a reasonable level so that you can hear sounds from outside the vehicle, including warning sounds, voices, and sirens. Failure to do so may cause an accident.

● Be careful that hands and fingers are not pinched when adjusting the tilting angle or closing display. Injuries may result.

● Do not put your hands or fingers into the loading slot of disc. Injuries may result.

● Do not touch the heat dissipating part of the amp. Burns may result from the heat of this

part.

● Do not recharge dry cell batteries. Dry cell batteries may rupture, resulting in injuries.

● Do not use batteries other than those specified. Also, do not mix old and new batteries.

Injuries or pollution to the surroundings may result from battery ruptures and leakage.

● When inserting batteries into the main unit, be careful with the polarity (positive/negative), and insert them as indicated. If the battery polarities are incorrect, injuries and pollution to the surroundings may result from battery ruptures and leakage.

● Replace used batteries as soon as possible; they may leak and damage main unit. Battery leakage can burn your skin or your eyes. Wash hands after handling.

● If alkaline solution from alkaline dry cell batteries makes contact with your skin or clothes, flush with clean water. If any of the solution gets in your eyes, also flush clean with water and then seek medical attention.

● When disposing of lithium dry cell batteries, affix insulating tape to the positive and negative terminals, and after they are insulated, dispose of them according to the "Local municipal ordinances". Shorts, fires and ruptures may result from disposal when coming contact with other electrically conductive objects such as metal parts, etc.

● Do not short, disassemble or heat the batteries, or place them in fire or water. Fire and injuries may result from battery rupture and leakage.

● Store the remote control in a place away from direct sunlight, high temperatures, and high moisture levels. The case may change shape, and the batteries may rupture and leak.

● Do not use this main unit except for in-vehicle use. Shocks or injuries may result.

Introduction

CAUTION

● Take notice of the volume position prior to turning ON the power. Hearing damage may result if very loud noise is emitted when the power is turned ON.

● Do not operate under abnormal conditions such as when the sound is broken or distorted. Fires may result.

● This main unit uses invisible laser light. Do not disassemble or alter this equipment. If trouble occurs, contact the dealer where you bought the equipment. Altering this equipment may cause exposure to laser emissions (worsening eyesight), or result in accidents, fires or shocks.

● If the main unit is dropped or the cosmetics appear broken, turn off the power to the main unit and contact your dealer. If used in this condition, fires or shocks may result.
