Eclipse - Fujitsu Ten AVN8826 User Manual

English English English English English EnglishEnglish

Be sure to read this installation manual thoroughly before carrying out installation and making connections. If installation methods or non-standard parts that are not specified in this installation manual are used, accidents or injury may result. Professional installation is recommended, contact the place of purchase to schedule an appointment. After reading the owner's manual and the installation manual thoroughly, keep them in a safe place for later reference. To dealers:

Give this installation manual to the customer after installation and connections have been completed.

Contents

Components

Before

installation

Installation

Connections

For your safety in using the AVN8826 3

Names and functions of terminals 4

Installing the GPS antenna 9

HDD Navigation System with 7 "Wide TFT Display and DVD/MS Multi-Source Receiver

INSTALLATION MANUAL

System connection example 8

MODEL

Installing the main unit 11

Connecting the vehicle speed pulse, parking brake, and reverse cables (wires)

-2-

English English English English English English English

GPS antenna components

GPS antenna

x 1

Waterproof cushion

x 1

Earth plate

x 1

Body protective sheet

x 1

Interconnecting cable

(Speed pulse, parking,

reverse,video, etc)

(20P) x 1

Main unit

x 1

When installing the main unit, some vehicle models may require the use of items that need to be obtained separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting bracket.

Tip

Interconnecting cable

(Power and speaker connector)

(16P) x 1

Main unit components

Interconnecting cable

(E-lan etc)

(16P) x 1

Wiring components

Cable tie

x 4

Harness affixing tape

x 3

Mounting sleeve

x 1

Antenna cable

x 1

Bezel

x 1

Side bracket

x 2

Clamp

(for GPS antenna) x 3

Case

(For detachable panel) x 1

Splicing connector

x 3

Flat head screw

(M4x6) x 4

Thin flat screw

(M4x5) x 4

Pan screw with washer

(Blue:M4x3) x 4

Components

Check that all of the following components are present

-3-

English English English English English EnglishEnglish

Warnings and caution signs, illustrated bellow, are posted throughout this manual as well as on the AVN8826. They show safe and correct ways to handle the product so as to prevent personal injury to you and others and avoid damage to property. Before reading through the manual, take time to read through and learn the important information listed in this section.

This sign indicates a situation in which incorrect handling through disregard of a sign might result in death or serious personal injury.

This sign indicates a situation in which incorrect handling through disregard of a sign might result in personal injury or may result solely in damage to property.

This section contains information that can help to prevent problems and damage to the unit, and also contain other useful information.

Tip

••

When making holes (example: drilling), be sure to wear protective eyewear. Otherwise, an injury such as loss of eyesight may result.

••

Exposed wires must be insulated with electrical tape. Otherwise, a short circuit, fire, or electric shock may result.

••

Do not modify this system for use other than that specified herein. Also, do not deviate from the installation procedures described herein; Fujitsu ten will not be held liable for damages including, but not limited to serious injury, death, or property damage resulting from installations that enable unintended operation.

••

This unit is intended for operation in 12volt DC, negativegrounded vehicles only. Never use it in 24-volt vehicles such as heavy trucks or diesel vehicle with cold-region specifications.

••

Do not place the vinyl storage bag over a person's head. It may cause a serious accident or death by suffocation.

••

Do not disassemble or rebuild this product. Doing so may cause an accident, fire, or electrical shock.

••

When it is necessary to replace the fuse, always use a fuse of the correct rating (number of amperes). Use of fuses with higher amperage ratings may cause a fire.

••

Do not operate the product in a malfunctioning condition, for instance, when the audio does not play. Doing so may result in an accident, fire, or electrical shock.

••

If an abnormal situation occurs, such as foreign matter entering or liquid splashing on the product, or smoke or a strange odour emitting from the unit, shut off the product immediately and consult the dealer from whom you purchased it. Continued operation may cause an accident, fire, or electrical shock.

••

Do not install this product in locations where it may obstruct the driver's view, or where it may endanger passengers in the vehicle. Otherwise, an accident or injury may result.

••

Do not install this product in locations where it may interfere with the operation of the steering wheel, shift lever, brake pedal, etc. Otherwise, an accident or injury may result.

••

To prevent damage to the vehicle, confirm the locations of hoses, electrical wiring, and the fuel tank prior to drilling holes to install this product. Also, take precautions so that the product does not interfere, nor come in contact with them. Otherwise, a fire may result.

••

When installing this product, never use the existing nuts or bolts that secure parts of the fuel tank, or the steering, or braking systems. Otherwise, improper steering, or braking or a fire may result.

••

To prevent a short circuit from occurring, disconnect the battery's negative terminal before installing this product. Otherwise, an electric shock or injury may result.

••

When using an existing nut and/or bolt from the vehicle to earth this product, do not use any that secure parts of the steering or braking systems. Otherwise, an accident may result.

••

Bundle cables and harnesses with electrical tape or wire ties to prevent them from interfering with moving parts. If they should entangle with the steering wheel, shift lever, or brake pedal, an accident may result.

••

Never supply power to another electrical appliance by splicing or tapping into this product's power lead (wire). Otherwise, the current capacity of the wire will be exceeded, resulting in a fire or electric shock.

••

Never attempt to disassemble or modify the product. Otherwise, an accident, fire, or electric shock may result.

••

When installing the product into a vehicle with a passenger side air bag, do not secure it to the air bag's cover or in places where it may impede air bag deployment. Otherwise, proper air bag operation may not be ensured in the event of an accident, causing injury or death.

FFor y

or y

our saf

ety in using the A

VN8826

••

When routing cables, use precautions to prevent contact of sharp metal parts such as brackets or screw tips. Otherwise, a short circuit, electric shock, fire, or accident may result.

••

Play the audio at a moderate volume level that permits you to hear sounds from outside the vehicle. Driving without being able to hear outside sounds may result in an accident.

••

This product must be operated only as on-board equipment, or it may cause electrical shock or injury.

••

Do not play distorted sounds for long periods of time; the speakers may overheat and cause a fire.

••

For best results, this product should be installed by a professional installer. Contact the dealer whom you purchased the product for an appointment.

••

When installing this product, be sure to use the supplied mounting hardware. If parts other than those supplied are used, the unit may be damaged internally, or may not be held in place securely and become dislodged.

••

Avoid installing this product in places where it may get wet, such as near windows, or in places that are moist or dusty. Presence of liquid, moisture, or dust inside this product can cause short circuiting resulting in smoke or fire.

••

If this product is not connected properly, a short circuit, fire, or accident may occur.

English English English English English English English

-4-

••

Never cut the insulation on the power cable or use it to power any other equipment. If the rated current capacity of the power cable is exceeded, fire and electric shocks may result.

••

The cables should be secured with tape or a similar securing method to prevent any obstructions while driving. If they get wound or entangled around components such as the steering wheel, shifting lever, or brake pedal, accidents may result.

••

If removing the end of the cord to connect to another cord, be sure to wrap PVC tape or a similar wire insulating method around the connection to insulate it. If the connection is not insulated, fire or accidents may result.

••

Refer to page 5 for details on the wire colours and connection points for interconnecting cables , and and

Tip

20P

GPS ANTENNA

ANTENNA PLUG

MAIN UNIT

16P

INTERCONNECTING CABLE (E-lan etc)

INTERCONNECTING CABLE (Speed pulse, parking, reverse,video, etc)

INTERCONNECTING CABLE

(Power and speaker connector)

16P

ANTENNA CABLE

Tip*1

••

The positions of the B+ and ACC pins on the connector may

vary depending on the vehicle. In such cases, replace the end

of the connector. Ask your dealer for details on connector pin

positions.

Tip*1

TO VEHICLE-SIDE CONNECTOR

Names and functions of ter

minals

13P

••

Installation is not possible for vehicles without ACC.
