SS-989E

2 In 1 SMD Hot Air Rework Station

• Quiet operation & ESD safe design

• Closed circuit sensor design

• Microprocessor-controlled with Calibration function features accurate temperature control

and easy to repair

• Alumina Ceramic Soldering iron heating element features high power, fast warm up

• Silicone handpiece cord wire heat-resistant up to 200°C

• Comes with AWG 20 (0.5mm²) UL Certied Wires.

• Individual function start saves energy

• Auto cool-off process to prolong the life of heating element

• Interchangeable and applicable to most of branded hot air nozzles and tips

2X Lifetime

Heat Fast , 36sec 300°C

Smart Microprocessor controlled

Auto Cooling System

UL certied wires

SOLDERING / ASSEMBLY

SMD rework Soldering work

Specication

Model No. SS-989E
Power Consumption 700W
Soldering Power 60W

Soldering Iron Temperature Range 200˚C ~ 480˚C (392˚C ~ 896˚F)

Hot Air Temperature Range room temperature ~ 480˚C (896˚F)
Heating Element Alumin ceramic heating element
Hot Air Heating Element Metal Heating Core
Pump/Motor Type Diaphragm Pump

Air Capacity 24L/min (max)

Equipment noise 45dB

Temperature Display LED

Power Input AC110-120V, 60Hz

Standard Plug

Dimensions 255(L)x190(W)x140(H)mm
Weight 4200g

Accessories

Soldering Iron (60W) 9SS-900N-SI(AC24V/60W) x 1pcs

Hot Air Gun

Soldering Stand 1pcs

Nozzle

Individual packing Color Box

9SS-900NE-HG
(AC110V~120V)

9SS-900-A1 (Ø2.3mm) x 1pcs
9SS-900-A2 (Ø6.4mm) x 1pcs
9SS-900-A3 (Ø8.8mm) x 1pcs

Connectorized design for
quick change heater

Soldering stand

All in one PCB design Hight quality assembly

Replacement Tips:

Please refer to 5SI-216N series Soldering tip on page.87

Replacement Accessories:

Soldering Iron: 9SS-900N-SI
Hot Air Gun:9SS-900NE-HG(AC110~120V)
Soldering Iron Heater: 9SS-900N-HT
Hot Air Gun Heater: 5SS-989NE-H(AC 110~120V)

IC Package Model No.

Single

QFP

(Quad Flat Pack)

A

C

B

D

SOP

(Small Qutline Package)

O

A

B

PLCC

(Plastic Leaded Chip Carrier)

A

C

B

D

IC (mm)

10x10
14x14

17.5x17.5
14x20
28x28

4.4x10

5.6x13

7.5x15

7.5x18

17.5x17.5
20x20
25x25
30x30

9SS-900-A1
9SS-900-A2
9SS-900-A3

9SS-900-B
9SS-900-C
9SS-900-D
9SS-900-E
9SS-900-F
9SS-900-H

9SS-900-I
9SS-900-J
9SS-900-K
9SS-900-L
9SS-900-M
9SS-900-N
9SS-900-O

83

SS-969E

Brushless motor
Microprocessor-controlled
Auto-sleep and work mode

UL certied wires

Durable metal case

SMD Rework Station

• Microprocessor-controlled with closed circuit sensor
design, provide high power and quick warm up times.

• Adjustable air ow, air volume and temperature to meet
variety applications.

• Handle with sensor design provides real-time operating.

• Brushless motor design, quiet in operation, equipment

noise less than 45dB.

• Auto cool-off process to prolong the life of heating ele

-

ment.

• Silicone Handpiece cord wire heat-resistant up to 200°C.

AWG 20 (0.5mm²) UL Certied Wires.

•

• Metal case with painting makes more durable.

Specication

Model No SS-969E

SOLDERING / ASSEMBLY

Standard nozzles x 3 pcs

SS-331E

LCD Desoldering Station

SMD rework

High quality assembly

Additional ground contact

Power Consumption 700W

Temperature Range 100~450˚C(212~842˚F)
Heating Element Metal Heating Core
Equipment Noise <45dB

Temperature Display LED

Air Volume 120L / min (Max.)

Fuse type 250V / 8A

Input Voltage AC110V~120V, 60Hz

Plug Type

Machine Size (mm) 170 x 170 x 140

Overall Package (mm) 280 x 185 x 170
Weight 1.43 kgs

Accessories

Heat Air Gun

Nozzle

Individual packing Color box

(225 x 60 x 40mm / wire length 140cm)

9SS-969-A1 x 1pcs ( ID: Ø 4.3mm )
9SS-969-A2 x 1pcs ( ID: Ø 7.4mm )
9SS-969-A3 x 1pcs ( ID: Ø 9.4mm )

E

5SS-969NE-HG

AC(110~120V)

84

High Power Vacuum Pressure
Microprocessor-controlled
Ceramic Heater for quick heat up

NEW

9

9

• Built-in high power 600mm Hg air pump, designed for lead-free
desoldering of single and multi layer PCB.

• High performance provides fast heating response.

• Microprocessor controlled, provides accurate temperature
control from 160 to 480°C.

• Provides fast heat up, fast recovery and high insulation

resistance.

• Features 20 times longer lifetime than transitional type heater

and better performance.

• Ergonomically friendly structure allows one hand operation,
more efcient and comfortable.

Specication

Voltage 100~240V AC
Power Consumption 90W

Temperature Range 160°C ~ 480°C

Control System Microprocessor

Vacuum Pump System Air Pump Motor
Vacuum Pressure >600mm Hg
Heating Element Ceramic Heater

Connecting Cord/Hose Length 105cm

Power Cord Length 1.2m

E

Ceramic heater features 20

times longer lifetime and
better performance than
tranditional type heater

Plug Type

Station Size (mm) 172 x 135 x 190
Weight (kgs) 1.6

Accessories

Individual packing Color Box

Spare tip x 3:(ø1.2(on the gun)/ø1.0/ø1.5mm)

Cleaning tool x 3 (ø0.7/ø0.9/ø1.2mm)

Filter sponge x 4 (ø20.8x1+ø16.8x3)

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

SS-611A

Heat Gun Set

• Smart overheat protection design

4002205

• Automatic cool air ow to reduce waiting time from overheating shut down
while working

• 2 temperature settings from 300°C~500°C for a variety of applications

• Dual color ergonomic grip and lightweight design provides greater comfort

• Includes 4 nozzles and 1 scraping tool with carrying case, easy to carry

and store

Included 4 Nozzles + 1 Scraper

Voltage Power

120V 60Hz

I-750W

II-1500W

Dual temperature

range

I-300ºC

II-500ºC

Case size

(mm/inch)

295x275x85

11.6" x 10.8" 3.3"

Individual packing: Color sleeve + shrink pack

Standard plug

A

Paint and varnish removal

Caution:

• For safety, after using this product for one hour, please shut-off for 10 minutes to cool down temperature

• If this product is overheating after shut-off, the protection function will be coercively booted and shut this
appliance off for 10 minutes. To prevent any overheating problem, never put the appliance down on its air
outlet nozzle. Always keep its outlet nozzle upward or put it on one of its sides.

SOLDERING / ASSEMBLY

902-458

Heat Gun with LCD Display

• Mabuchi motor provides high performance and long life.

• Large LCD display for easy monitoring.

• Air ow and temperature control system maintains constant temperature.

• Perfect for applications requiring consistent application of heating.

• Adjustable, stepless temperature range from 212°F~1202°F(100°C~650°C).

• Smart protection design switches off automatically to prevent overheating.

• 20 second automatic cool air ow prevents accidental burns and extends

the life of the heating element.

• Includes 2 extra nozzles for a wide variety of applications.

Removal of window glazing Paint removal

NEW

Voltage

120V 60Hz 1500W

Power

consumption max.

Switch-I Switch-II Switch-III Cable length Certicate Standard plug Accessories

11 CFM 122ºF

(50ºC)

11 CFM

158~1022ºF

(70~550ºC)

18 CFM

158~1022ºF

(70~550ºC)

6 Ft. c-UL A

Individual packing: Color sleeve + shrink pack

4 nozzles and

1 scraping tool

85
