Installation Guide
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
RV-MM7
7.0” Factory Mount Mirror Monitor
Introduction
Thank you for purchasing your EchoMaster Pro automotive monitor.
EchoMaster Pro mirror monitors are designed to improve safety by providing
high quality images from camera inputs. This may help to improve vehicle
maneuvering capabilities by displaying blind spots or areas not normally
visible to the driver.
Please ensure you read and understand all aspects of this manual before
tting or using your EchoMaster mirror monitor.
Box Contents Key Features
u Dual video inputs
u Reverse trigger input
u Remote control included
u Auto-dimming display
u Install/User Guide
u Mirror Monitor
u Main Harness
u Cable Management
Page 3
3
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
Installation Guide
RV-MM7
7.0” Factory Mount Mirror Monitor
Fitting Instructions
The RV-MM7 will replace your factory tted rearview mirror.
Remove the original mirror from the vehicle and replace with the RV-MM7.
Once the unit is in place, run the connections cable across the headliner of
the vehicle and down the A pillar.
Please ensure that you do not impede the operation of any airbags that may
be located in the A pillar of the vehicle. Any cable passing these airbags
should be run behind the airbag and not in front of it.
Once the cable has been routed down to the dashboard, connect the camera
inputs and power connections as shown in the wiring diagram section of this
manual.
Operating Instructions
The vehicle ignition is required to be on for the unit to operate.
The unit will only turn on when a video signal is present.
To turn it on or off, press the Power button.
IR Sensor for remote
Hue +
Menu
Hue -
Switch between AV1 / AV2
Power on/off
Page 4
4
Installation Guide
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
Operating Instructions (continued)
Power on/off
Switch between video sources AV1/AV2
Increase brightness, contrast, color, etc
Mode Select
Decrease brightness, contrast, color, etc
Menu Options
Wiring Diagram
+12V Ignition
GND
V1
V 2
Reverse Camera Input
Video Input
(Black)
Reverse Trigger
(Green)
(Red)
Filter &
Fuse Box
IN
OUT
RV-MM7
7.0” Factory Mount Mirror Monitor
Page 5
5
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
Installation Guide
Dimensions (mm)
RV-MM7
7.0” Factory Mount Mirror Monitor
Page 6
6
Installation Guide
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
RV-MM7
Screen Size 7.0"
Aspect Ratio Wide angle
Power Supply 9-15V DC
Resolution (RGB) 800 x 480
Luminance 400
Contrast 350:1
TV Format NTSC/PAL
OSD Languages Multi
Video Inputs 2
Audio Inputs 0
Trigg ers 1
Current Draw 254mA
Operating Temperature 20°C - 65°C
IP Rating N/A
Dimensions (mm) (L) 250.20 x (W) 108.30 x (D) 30.20
Connection Type Power/RCA
Specication
RV-MM7
7.0” Factory Mount Mirror Monitor
Page 7
7
email - support@aampglobal.com (US)
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
email - technical.eu@aampglobal.com (Europe)
Installation Guide
RV-MM7
7.0” Factory Mount Mirror Monitor
