Echo PPF-210 User Manual

OPTIONAL ATTACHMENTS & A CCESSORIES

Accessories

99946400010 3 Foot Extension

PARTS CATALOG

Guide Bars

1080373301 Guide Bar - 8" (.050" Ga) 1100373901 Guide Bar - 10" (.043" Ga) 1101373901 Guide Bar - 10" (.050" Ga) 1102373901 Guide Bar - 10" (.050" Ga) -- Intenz

Sawing Chains

1907039 Sawing Chain - 10" (.043" Ga) -- Micro-Lite 1917033 Sawing Chain - 8" (.050" Ga) -- Low Profile 1917039 Sawing Chain - 10" (.050" Ga) -- Low Profile

PPF-210 Power Pruner

21.2cc

MODEL:SERIAL NUMBERS

PPF-210: S/N: 05001001 - 05999999

ECHO, INCORPORATED

400 Oakwood Road Lake Zurich, Illinois 60047 USA

WWW.ECHO-USA.COM

99922203488_210/05

Table of Contents Part Number Index

Table of Contents

Click Any Diagram Desciption Below To Veiw That Diagram.

PPF-210 S/N: 05001001 - 05999999

Cylinder Cover.................................................................................................................................................................4

Fuel System.....................................................................................................................................................................6

Starter...............................................................................................................................................................................8

Fancase, Clutch.............................................................................................................................................................10

Intake..............................................................................................................................................................................12

Carburetor -- RB-K66B S/N: 05001001 - 05010614......................................................................................................14

Carburetor -- RB-K70 S/N: 05010615 - 05999999........................................................................................................16

Exhaust...........................................................................................................................................................................18

Ignition............................................................................................................................................................................20

Engine, Short Block -- SB1065.....................................................................................................................................22

Guide Bar, Sawing Chain, Guide Bar Cover................................................................................................................24

Gear Case, Auto-Oiler...................................................................................................................................................26

Main Pipe Assembly, Driveshaft...................................................................................................................................28

Control Handle,Throttle Cable, Ignition Switch..........................................................................................................30

Shoulder Strap...............................................................................................................................................................32

Labels.............................................................................................................................................................................34

Gasket Kit.......................................................................................................................................................................36

Tools...............................................................................................................................................................................38

Part Number Index.........................................................................................................................................................40

Part Description Index..................................................................................................................................................41

99922203488_210/05 - 2 - REVISED 03/06/08

This Page Intentionally Left Blank

- 3 -

Table of Contents Part Number Index

PPF-210 Power Pruner Cylinder Cover

99922203488_210/05 - 4 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Cylinder Cover

REMARKSDESCRIPTIONQTYPART NUMBERITEM COVER, CYLINDER1A1600001921 SCREW 4X122900238040122 GUARD, TOP1159912445303 SCREW 5X161900253050164 SCREW 4X162900163040165

99922203488_210/05 - 5 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Fuel System

99922203488_210/05 - 6 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Fuel System

REMARKSDESCRIPTIONQTYPART NUMBERITEM TANK, FUEL1A3500002201 WASHER 52900603000052 SCREW 5X202900238050203

INCLUDES ITEMS 5-6CAP ASY1131004555304 CONNECTOR, FUEL CAP1131051560305 GASKET, FUEL TANK CAP1131016558306 GROMMET1V1370000307 FILTER, FUEL1131205073208 CLIP1132013098209

REPOWER BULK OPTION: 90014PIPE, FUEL - 3X5X180mm1V47100119010

REPOWER BULK OPTION: 90014PIPE, VENT - 3X5X70mm1V47100120011 VENT ASY1A35600003012

REPOWER BULK OPTION: 90017PIPE, RETURN - 3X6X80mm11320125603013 STAND13051104203014 SCREW 4X2029001620402015 EYE PLATE1V15000164016 SCREW 4X1629001630401617

99922203488_210/05 - 7 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Starter

99922203488_210/05 - 8 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Starter

REMARKSDESCRIPTIONQTYPART NUMBERITEM

INCLUDES ITEMS 2-3STARTER PAWL ASY1177202443311 SPRING, RETURN1177234420302 PAWL, STARTER1177218443303

INCLUDES ITEMS 5-11STARTER ASY1177200420334 SCREW1177236443305 DRUM, STARTER1177215443306

REPOWER BULK OPTION: 99944440000ROPE, STARTER - 3X1000mm1177226101207 GUIDE, ROPE1177227420308 GRIP, STARTER1177228065309 SPRING, REWIND11772204203010 CASE, STARTER11772324203011 SCREW 4X1649001630401612

99922203488_210/05 - 9 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Fancase, Clutch

99922203488_210/05 - 10 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Fancase, Clutch

REMARKSDESCRIPTIONQTYPART NUMBERITEM COVER, FAN1101511446301 SCREW 5X251900162050252 SPRING WASHER 51900605000053 WASHER 51900600000054 STOPPER1175053049205 CIRCLIP 121900701000126 BEARING, BALL 62011900814062017 CIRCLIP 321900702000328 DRUM, CLUTCH1175005420309 CLUTCH ASY11750005683010

99922203488_210/05 - 11 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Intake

99922203488_210/05 - 12 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Intake

REMARKSDESCRIPTIONQTYPART NUMBERITEM WING BOLT1210417527301 LID, AIR CLEANER - GRAY1130313065632 LID, AIR CLEANER - BLACK1130313058633

1130310541304

FILTER, AIR PLATE, PREVENT1129011527305 SCREW 5X652900220050656 CASE, AIR CLEANER - GRAY1P0210009917 CASE, AIR CLEANER - BLACK1P0210044808 LABEL - CHOKE1890121527309

11300101341012

GASKET, INTAKE INSULATOR, INTAKE11300174433013 SCREW 5X2029002380502014 NUT 529005000000515

11300104203216

SHIELD, CYLINDER

1: Also Included In REPOWER TUNE-UP KIT 2: Also Included In GASKET KIT

CANADA MODELSLABEL - CHOKE18901215273010

See Carburetor Diagram For Additional InformationCARBURETOR1------------------11

Footnotes

99922203488_210/05 - 13 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Carburetor -- RB-K66B S/N: 05001001 - 05010614

99922203488_210/05 - 14 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Carburetor -- RB-K66B S/N: 05001001 - 05010614

REMARKSDESCRIPTIONQTYPART NUMBERITEM CARBURETOR -- RB-K66B1A021000382 ROTOR COVER ASY1P0050006901 NUT, CABLE1P0050001202 SCREW, ROTOR COVER ASY3125344139313 SCREW, CABLE ADJUST1P0050007004 SWIVEL1P0050001805 E-RING1P0050001906 SCREW, THROTTLE ADJUST1P0050001007 O-RING1P0050002808

NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------9 PLUG KIT1P00500037010 JET1P00500057011 PURGE BASE ASY1P00500093012 SCREW, PURGE BASE ASY1P00500027013 BULB, PURGE11253810866014 RETAINER, PURGE BULB1P00500025015 SCREW, PURGE BULB RETAINER41253106183016 COVER, DIAPHRAGM11253425213017 SCREW, DIAPHRAGM COVER21253445213018 SCREW, METERING LEVER PIN11253394203019

INCLUDES ITEMS 21-30REPAIR KIT1P00500095020 ROLLER, GUIDE1P00500100021 PIN, METERING LEVER1------------------22 VALVE, INLET NEEDLE1------------------23 LEVER, METERING1------------------24 SPRING, METERING LEVER1------------------25 STRAINER1------------------26 DIAPHRAGM, PUMP1------------------27 GASKET, PUMP1------------------28 GASKET, METERING1------------------29 DIAPHRAGM, METERING1------------------30

INCLUDES ITEMS 32-35DIAPHRAGM/GASKET KIT1P00500055031 DIAPHRAGM, PUMP1------------------32 GASKET, PUMP1------------------33 GASKET, METERING1------------------34 DIAPHRAGM, METERING1------------------35

99922203488_210/05 - 15 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Carburetor -- RB-K70 S/N: 05010615 - 05999999

99922203488_210/05 - 16 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Carburetor -- RB-K70 S/N: 05010615 - 05999999

REMARKSDESCRIPTIONQTYPART NUMBERITEM CARBURETOR -- RB-K701A021000720 ROTOR COVER ASY1P0050012301 NUT, CABLE1P0050001202 SCREW, ROTOR COVER ASY3125344139313 SCREW, CABLE ADJUST1P0050007004 SWIVEL1P0050012405 E-RING1P0050001906 SCREW, THROTTLE ADJUST1P0050001007 O-RING1P0050002808

NOT AVAILABLE SEPARATELYBODY, CARBURETOR1------------------9 PLUG1P00500127010 NEEDLE - HIGH SPEED1P00500126011 PURGE BASE ASY1P00500093012 SCREW, PURGE BASE ASY1P00500027013 BULB, PURGE11253810866014 RETAINER, PURGE BULB1P00500025015 SCREW, PURGE BULB RETAINER41253106183016 COVER, DIAPHRAGM11253425213017 SCREW, DIAPHRAGM COVER21253445213018 SCREW, METERING LEVER PIN11253394203019

99922203488_210/05 - 17 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Exhaust

99922203488_210/05 - 18 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Exhaust

REMARKSDESCRIPTIONQTYPART NUMBERITEM

1V1040004201

1A3130003507

1: Also Included In GASKET KIT

SHIELD, EXHAUST MUFFLER1145806420302 SCREEN, MUFFLER1145862406303 SCREW 5X552900105050554 WASHER2900600000055 GASKET, EXHAUST1145866420316

GUIDE, EXHAUST SCREW 4X103900242040108

Footnotes

99922203488_210/05 - 19 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Ignition

99922203488_210/05 - 20 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Ignition

REMARKSDESCRIPTIONQTYPART NUMBERITEM COIL, IGNITION1A4110001301 SCREW 4X202900162040202 GROMMET1150112443303 TUBE, INSULATOR1156110549304 CAP, SPARK PLUG1159012016205 TERMINAL, SPARK PLUG CAP1159011034326

1159010198307

SPARK PLUG -- BPM-8Y

1A4250000008

SPARK PLUG -- BPMR-8Y FLYWHEEL1A4090001609 LEAD, GROUND1V48500029010

1: Also Included In REPOWER TUNE-UP KIT

Footnotes

CANADA MODELS

99922203488_210/05 - 21 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Engine, Short Block -- SB1065

99922203488_210/05 - 22 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Engine, Short Block -- SB1065

REMARKSDESCRIPTIONQTYPART NUMBERITEM

INCLUDES ITEM 2-17SHORT BLOCK1SB10651 CYLINDER1A1300004302 SCREW 5X222900162050223

1V1000000804

11002045213112

1: Also Included In GASKET KIT

GASKET, CYLINDER

RING, PISTON2A1010000006 PIN, PISTON1100013115207 CIRCLIP, PISTON PIN2100015046308 SPACER, PISTON PIN2100014115209

BEARING, NEEDLE1V55300001011 CRANKCASE KIT

OIL SEAL21002124203113 DOWEL PIN2V62200002014 BEARING, BALL - 62012940353620115 GASKET, CRANKCASE11002424203016 SCREW 5X2839001620502817

INCLUDES ITEMS 6-9PISTON KIT1P0210011015

INCLUDES ITEM 11CRANKSHAFT ASY1A01100010110

INCLUDES ITEMS 13-17

Footnotes

99922203488_210/05 - 23 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Guide Bar, Sawing Chain, Guide Bar Cover

99922203488_210/05 - 24 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Guide Bar, Sawing Chain, Guide Bar Cover

REMARKSDESCRIPTIONQTYPART NUMBERITEM

111023739011

GUIDE BAR - 10" -- Intenz

119170392

Profile COVER, GUIDE BAR1X4900000603

Footnotes

1: .043" & .050" Gauge Chains & Guide Bars are NOT Interchangeable

GAUGE: .050"

GAUGE: .050"SAWING CHAIN (91VS) - 10" -- Low

99922203488_210/05 - 25 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Gear Case, Auto-Oiler

99922203488_210/05 - 26 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Gear Case, Auto-Oiler

REMARKSDESCRIPTIONQTYPART NUMBERITEM

INCLUDES ITEMS 2-43AUTO OILER/GEAR CASE ASY1900841 GUARD, SPROCKET1C3000000012 NUT 62433019039333 RING1V5830000104 WASHER2175014391315 SPROCKET, DRIVE1C5800000706

INCLUDES ITEMS 8-14AUTO-OILER ASY1437002391307 CLIP1123127150308 SPRING, ADJUSTER1437015373309 WASHER14370293733010 ADJUSTER, OILER14370163913011 SPRING, PLUNGER14370193833012 PLUNGER ASY14370243733013 CAP, OIL PUMP14370623733014 PIPE, OIL OUTLET1V47000018015 PAD, FOAM14372443913016

REPOWER BULK OPTION: 90015PIPE, OIL - 3X6X115mm11301101433017 GROMMET11321150146118 STRAINER, OIL14362050283219 SCREW 5X1029001090501020 GEAR, WORM14370633833021 CASE, GEAR - UPPER1C53100001022 SCREW 5X2589001090502523

INCLUDES ITEM 25CASE, GEAR - LOWER1C05100011024 SCREW 5X1019001090501025 STUD BOLT 62V22400000026 SCREW 5X1019001090501027 WASHER19006000000528 CIRCLIP 1219007060001229 BEARING, BALL 60014940420600130

Use BEVEL GEAR KIT P021009730GEAR, BEVEL1V65100003231 CIRCLIP 1219007060001232 SHAFT, GEAR1C53400018033

Use BEVEL GEAR KIT P021009730GEAR, BEVEL1V65100011134 TANK, OIL1C20000000035 SCREW 5X162911090501636 SCREW 5X2519001090502537 WASHER39006030000538 SPACER21310452823039 COLLAR 61V35400001040 VENT ASY11313140632041 OIL CAP ASY1P02100095142 LABEL - ECHO1X50200031043

14330163913144

SCREW, ADJUSMENT

14330140393145

TENSIONER

Not Included In 90084 OILER/GEAR CASE ASY

Footnotes

1: For Use With Standard Guide Bar (INTENZ Guide Bar Not Used)

99922203488_210/05 - 27 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Main Pipe Assembly, Driveshaft

99922203488_210/05 - 28 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Main Pipe Assembly, Driveshaft

REMARKSDESCRIPTIONQTYPART NUMBERITEM

INCLUDES ITEMS 2-4MAIN PIPE ASY1610609246611 GRIP, FRONT1351311220602 RING, EXTERNAL TOOTH1900038001003 LINER1610217220604 DRIVESHAFT - FLEXIBLE1610013220605

99922203488_210/05 - 29 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Control Handle,Throttle Cable, Ignition Switch

99922203488_210/05 - 30 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Control Handle,Throttle Cable, Ignition Switch

REMARKSDESCRIPTIONQTYPART NUMBERITEM

INCLUDES ITEMS 2-4CONTROL HANDLE KIT1178003521301 SCREW 5X351900242050352 SCREW 5X251900242050253 NUT 52900500000054

INCLUDES ITEM 6BAND ASY1301200294305 SCREW 5X141900242050146 TRIGGER, THROTTLE1178010521307 CABLE, THROTTLE1V4300006718 TUBE, VINYL1178127503309 SPRING, THROTTLE RETURN11780434223010 LOCKOUT, THROTTLE11780125273011 LEVER, THROTTLE LOCKOUT11780905263212 SPRING, THROTTLE LOCKOUT11780135263013

INCLUDES ITEMS 15-17SWITCH, IGNITION11634015563114 SCREW 3X101915450301015 KNOB, SWITCH11634104923116 LABEL, SWITCH18901571233017 GRIP, HANDLE13512135213018

INCLUDES ITEMS 20-21CLAMP KIT16102725213019 SCREW 5X2819002420502820 NUT 519005000000521

99922203488_210/05 - 31 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Shoulder Strap

99922203488_210/05 - 32 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Shoulder Strap

REMARKSDESCRIPTIONQTYPART NUMBERITEM STRAP, SHOULDER1301000220601

INCLUDES ITEMS 3-4SHOULDER STRAP MOUNT KIT1300605220602 SCREW1900053002003 LOCKNUT1900031501004

99922203488_210/05 - 33 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Labels

99922203488_210/05 - 34 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Labels

REMARKSDESCRIPTIONQTYPART NUMBERITEM LABEL - SPARK PLUG -- BPM-8Y1X5320006711

CANADA MODELSLABEL - SPARK PLUG -- BPMR-8Y1X5320007202 LABEL - CAUTION1890160226603 LABEL - CHOKE1890121527304

CANADA MODELSLABEL - CHOKE1890332527305 LABEL - ECHO2X5020003106 LABEL - CAUTION -- HOT1890160063617 LABEL - MODEL -- PPF-2101X5030010208 LABEL - MODEL -- PPF-2111X5030013709

99922203488_210/05 - 35 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Gasket Kit

99922203488_210/05 - 36 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Gasket Kit

REMARKSDESCRIPTIONQTYPART NUMBERITEM GASKET KIT1P0210042701

99922203488_210/05 - 37 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Tools

99922203488_210/05 - 38 - REVISED 03/06/08

Table of Contents Part Number Index

PPF-210 Power Pruner Tools

REMARKSDESCRIPTIONQTYPART NUMBERITEM SOCKET WRENCH/SCREWDRIVER --

1895410106301

17X19mm SOCKET WRENCH/SCREWDRIVER --

1X6020000202

17X19mm SOCKET WRENCH/SCREWDRIVER --

1895410391313

10X19mm SOCKET WRENCH/SCREWDRIVER --

1895410069604

13X19mm SOCKET WRENCH -- 17X14.5mm1X6020000315 LOCKING BAR -- 5X120mm1897518011316 OPEN END WRENCH-- 8X10mm1895112003307 OPEN END WRENCH-- 17X19mm1895122209608 OPEN END WRENCH-- 10mm1895015052609 HEX BAR -- 10mm18954122096010 HEX KEY -- 3mm18956120343011 HEX KEY -- 4mm18956100013012 HEX KEY -- 5mm18956110033013 L-WRENCH -- 3mm TORX1X60500005014 SCREWDRIVER -- SLOTTED18958110013015 SCREWDRIVER -- PHILLIPS18958120393016

99922203488_210/05 - 39 - REVISED 03/06/08

Table of Contents Part Number Index

Part Number Index

Click The Page Number After Any Part Number To Veiw The Diagram Containing That Part.

PagePart Number

13, 15, 17------------------ .............

2310001311520 ............

2310001411520 ............

2310001504630 ............

2310020452131 ............

2310021242031 ............

2310024242030 ............

1110151144630 ............

251102373901 ..............

2712312715030 ............

15, 1712531061830 ............

15, 1712533942030 ............

15, 1712534252130 ............

15, 1712534413931 ............

15, 1712534452130 ............

15, 1712538108660 ............

1312901152730 ............

1313001013410 ............

1313001042032 ............

1313001744330 ............

2713011014330 ............

1313031054130 ............

1313031305863 ............

1313031306563 ............

713100455530 ............

713101655830 ............

2713104528230 ............

713105156030 ............

713120507320 ............

2713131406320 ............

713201256030 ............

713201309820 ............

2713211501461 ............

1914580642030 ............

1914586240630 ............

1914586642031 ............

2115011244330 ............

2115611054930 ............

2115901019830 ............

2115901103432 ............

2115901201620 ............

515991244530 ............

3116340155631 ............

3116341049231 ............

1117500056830 ............

1117500542030 ............

2717501439131 ............

1117505304920 ............

917720042033 ............

917720244331 ............

917721544330 ............

917721844330 ............

917722042030 ............

917722610120 ............

917722742030 ............

917722806530 ............

917723242030 ............

917723442030 ............

917723644330 ............

3117800352130 ............

3117801052130 ............

3117801252730 ............

3117801352630 ............

3117804342230 ............

3117809052632 ............

3117812750330 ............

251917039 ....................

1321041752730 ............

3330060522060 ............

3330100022060 ............

3130120029430 ............

730511042030 ............

3135121352130 ............

2935131122060 ............

2743301403931 ............

2743301639131 ............

2743301903933 ............

2743620502832 ............

2743700239130 ............

2743701537330 ............

2743701639130 ............

2743701938330 ............

2743702437330 ............

2743702937330 ............

2743706237330 ............

2743706338330 ............

2743724439130 ............

2961001322060 ............

2961021722060 ............

3161027252130 ............

2961060924661 ............

13, 3589012152730 ............

3189015712330 ............

3589016006361 ............

3589016022660 ............

3589033252730 ............

3989501505260 ............

3989511200330 ............

3989512220960 ............

3989541006960 ............

3989541010630 ............

3989541039131 ............

3989541220960 ............

3989561000130 ............

3989561100330 ............

3989561203430 ............

3989581100130 ............

3989581203930 ............

3989751801131 ............

3390003150100 ............

2990003800100 ............

3390005300200 ............

1990010505055 ............

2790010905010 ............

2790010905025 ............

7, 2190016204020 ............

2390016205022 ............

1190016205025 ............

2390016205028 ............

5, 7, 990016304016 ............

1390022005065 ............

590023804012 ............

7, 1390023805020 ............

1990024204010 ............

3190024205014 ............

3190024205025 ............

3190024205028 ............

3190024205035 ............

590025305016 ............

13, 3190050000005 ............

11, 19, 2790060000005 ............

7, 2790060300005 ............

1190060500005 ............

1190070100012 ............

1190070200032 ............

2790070600012 ............

1190081406201 ............

2790084 ........................

279110905016 ..............

319154503010 ..............

239403536201 ..............

279404206001 ..............

23A011000101 ..............

15A021000382 ..............

17A021000720 ..............

23A101000000 ..............

23A130000430 ..............

5A160000192 ..............

19A313000350 ..............

7A350000220 ..............

7A356000030 ..............

21A409000160 ..............

21A411000130 ..............

21A425000000 ..............

27C051000110 ..............

27C200000000 ..............

27C300000001 ..............

27C531000010 ..............

27C534000180 ..............

27C580000070 ..............

15, 17P005000100 ..............

15, 17P005000120 ..............

15P005000180 ..............

15, 17P005000190 ..............

15, 17P005000250 ..............

15, 17P005000270 ..............

15, 17P005000280 ..............

15P005000370 ..............

15, 17P005000550 ..............

15P005000570 ..............

15P005000690 ..............

15, 17P005000700 ..............

15, 17P005000930 ..............

15, 17P005000950 ..............

15, 17P005001000 ..............

17P005001230 ..............

17P005001240 ..............

17P005001260 ..............

17P005001270 ..............

27P021000951 ..............

13P021000991 ..............

23P021001101 ..............

37P021004270 ..............

13P021004480 ..............

23SB1065 ......................

23V100000080 ..............

19V104000420 ..............

7V137000030 ..............

7V150001640 ..............

27V224000000 ..............

27V354000010 ..............

31V430000671 ..............

27V470000180 ..............

7V471001190 ..............

7V471001200 ..............

21V485000290 ..............

23V553000010 ..............

27V583000010 ..............

23V622000020 ..............

27V651000032 ..............

27V651000111 ..............

25X490000060 ..............

27, 35X502000310 ..............

35X503001020 ..............

35X503001370 ..............

35X532000671 ..............

35X532000720 ..............

39X602000020 ..............

39X602000031 ..............

39X605000050 ..............

99922203488_210/05 - 40 - REVISED 03/06/08

Table of Contents Part Number Index

Part Description Index

Click The Page Number After Any Part Desciption To Veiw The Diagram Containing That Part.

ADJUSTER, OILER.....27

AUTO OILER/GEAR CASE ASY.....27

AUTO-OILER ASY.....27

BAND ASY.....31

BEARING, BALL - 6201.....23

BEARING, BALL 6001.....27

BEARING, BALL 6201.....11

BEARING, NEEDLE.....23

BODY, CARBURETOR.....15, 17

BULB, PURGE.....15, 17

CABLE, THROTTLE.....31

CAP ASY.....7

CAP, OIL PUMP.....27

CAP, SPARK PLUG.....21

CARBURETOR.....13

CARBURETOR -- RB-K66B.....15

CARBURETOR -- RB-K70.....17

CASE, AIR CLEANER - BLACK.....13

CASE, AIR CLEANER - GRAY.....13

CASE, GEAR - LOWER.....27

CASE, GEAR - UPPER.....27

CASE, STARTER.....9

CIRCLIP 32.....11

CIRCLIP 12.....11, 27

CIRCLIP, PISTON PIN.....23

CLAMP KIT.....31

CLIP.....7, 27

CLUTCH ASY.....11

COIL, IGNITION.....21

COLLAR 6.....27

CONNECTOR, FUEL CAP.....7

CONTROL HANDLE KIT.....31

COVER, CYLINDER.....5

COVER, DIAPHRAGM.....15, 17

COVER, FAN.....11

COVER, GUIDE BAR.....25

CRANKCASE KIT.....23

CRANKSHAFT ASY.....23

CYLINDER.....23

DIAPHRAGM, METERING.....15, 17

DIAPHRAGM, PUMP.....15, 17

DIAPHRAGM/GASKET KIT.....15, 17

DOWEL PIN.....23

DRIVESHAFT - FLEXIBLE.....29

DRUM, CLUTCH.....11

DRUM, STARTER.....9

E-RING.....15, 17

EYE PLATE.....7

FILTER, AIR.....13

FILTER, FUEL.....7

FLYWHEEL.....21

GASKET KIT.....37

GASKET, CRANKCASE.....23

GASKET, CYLINDER.....23

GASKET, EXHAUST.....19

GASKET, FUEL TANK CAP.....7

GASKET, INTAKE.....13

GASKET, METERING.....15, 17

GASKET, PUMP.....15, 17

GEAR, BEVEL.....27

GEAR, WORM.....27

GRIP, FRONT.....29

GRIP, HANDLE.....31

GRIP, STARTER.....9

GROMMET.....7, 21, 27

GUARD, SPROCKET.....27

GUARD, TOP.....5

GUIDE BAR - 10" -- Intenz.....25

GUIDE, EXHAUST.....19

GUIDE, ROPE.....9

HEX BAR -- 10mm.....39

HEX KEY -- 3mm.....39

HEX KEY -- 4mm.....39

HEX KEY -- 5mm.....39

INSULATOR, INTAKE.....13

JET.....15

KNOB, SWITCH.....31

LABEL - CAUTION.....35

LABEL - CAUTION -- HOT.....35

LABEL - CHOKE.....13, 35

LABEL - ECHO.....27, 35

LABEL - MODEL -- PPF-210.....35

LABEL - MODEL -- PPF-211.....35

LABEL - SPARK PLUG -- BPM-8Y.....35

LABEL - SPARK PLUG -- BPMR-8Y.....35

LABEL, SWITCH.....31

LEAD, GROUND.....21

LEVER, METERING.....15, 17

LEVER, THROTTLE LOCKOUT.....31

LID, AIR CLEANER - BLACK.....13

LID, AIR CLEANER - GRAY.....13

LINER.....29

LOCKING BAR -- 5X120mm.....39

LOCKNUT.....33

LOCKOUT, THROTTLE.....31

L-WRENCH -- 3mm TORX.....39

MAIN PIPE ASY.....29

MUFFLER.....19

NEEDLE - HIGH SPEED.....17

NUT 5.....13, 31

NUT 6.....27

NUT, CABLE.....15, 17

OIL CAP ASY.....27

OIL SEAL.....23

OPEN END WRENCH-- 10mm.....39

OPEN END WRENCH-- 17X19mm.....39

OPEN END WRENCH-- 8X10mm.....39

O-RING.....15, 17

PAD, FOAM.....27

PAWL, STARTER.....9

PIN, METERING LEVER.....15, 17

PIN, PISTON.....23

PIPE, FUEL - 3X5X180mm.....7

PIPE, OIL - 3X6X115mm.....27

PIPE, OIL OUTLET.....27

PIPE, RETURN - 3X6X80mm.....7

PIPE, VENT - 3X5X70mm.....7

PISTON KIT.....23

PLATE, PREVENT.....13

PLUG.....17

PLUG KIT.....15

PLUNGER ASY.....27

PURGE BASE ASY.....15, 17

REPAIR KIT.....15, 17

RETAINER, PURGE BULB.....15, 17

RING.....27

RING, EXTERNAL TOOTH.....29

RING, PISTON.....23

ROLLER, GUIDE.....15, 17

ROPE, STARTER - 3X1000mm.....9

ROTOR COVER ASY.....15, 17

SAWING CHAIN (91VS) - 10" -- Low Profile.....25

SCREEN, MUFFLER.....19

SCREW.....9, 33

SCREW 3X10.....31

SCREW 4X10.....19

SCREW 4X12.....5

SCREW 4X16.....5, 7, 9

SCREW 4X20.....7, 21

SCREW 5X10.....27

SCREW 5X14.....31

SCREW 5X16.....5, 27

SCREW 5X20.....7, 13

SCREW 5X22.....23

SCREW 5X25.....11, 27, 31

SCREW 5X28.....23, 31

SCREW 5X35.....31

SCREW 5X55.....19

SCREW 5X65.....13

SCREW, ADJUSMENT.....27

SCREW, CABLE ADJUST.....15, 17

SCREW, DIAPHRAGM COVER.....15, 17

99922203488_210/05 - 41 - REVISED 03/06/08

Part Description Index (continued)

SCREW, METERING LEVER PIN.....15, 17

SCREW, PURGE BASE ASY.....15, 17

SCREW, PURGE BULB RETAINER.....15, 17

SCREW, ROTOR COVER ASY.....15, 17

SCREW, THROTTLE ADJUST.....15, 17

SCREWDRIVER -- PHILLIPS.....39

SCREWDRIVER -- SLOTTED.....39

SHAFT, GEAR.....27

SHIELD, CYLINDER.....13

SHIELD, EXHAUST.....19

SHORT BLOCK.....23

SHOULDER STRAP MOUNT KIT.....33

SOCKET WRENCH -- 17X14.5mm.....39

SOCKET WRENCH/SCREWDRIVER --

10X19mm.....39

SOCKET WRENCH/SCREWDRIVER --

13X19mm.....39

SOCKET WRENCH/SCREWDRIVER --

17X19mm.....39

SPACER.....27

SPACER, PISTON PIN.....23

SPARK PLUG -- BPM-8Y.....21

SPARK PLUG -- BPMR-8Y.....21

SPRING WASHER 5.....11

SPRING, ADJUSTER.....27

SPRING, METERING LEVER.....15, 17

SPRING, PLUNGER.....27

SPRING, RETURN.....9

SPRING, REWIND.....9

SPRING, THROTTLE LOCKOUT.....31

SPRING, THROTTLE RETURN.....31

SPROCKET, DRIVE.....27

STAND.....7

STARTER ASY.....9

STARTER PAWL ASY.....9

STOPPER.....11

STRAINER.....15, 17

STRAINER, OIL.....27

STRAP, SHOULDER.....33

STUD BOLT 6.....27

SWITCH, IGNITION.....31

SWIVEL.....15, 17

Table of Contents Part Number Index

TANK, FUEL.....7

TANK, OIL.....27

TENSIONER.....27

TERMINAL, SPARK PLUG CAP.....21

TRIGGER, THROTTLE.....31

TUBE, INSULATOR.....21

TUBE, VINYL.....31

VALVE, INLET NEEDLE.....15, 17

VENT ASY.....7, 27

WASHER.....19, 27

WASHER 5.....7, 11

WING BOLT.....13

99922203488_210/05 - 42 - REVISED 03/06/08

NOTES

99922203488_210/05 - 43 - REVISED 03/06/08

ECHO, INCORPORATED

400 Oakwood Road

Lake Zurich, IL 60047 USA

WWW.ECHO-USA.COM

Echo PPF-210 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
