English L10

Congratulations!

You’ve just purchased a new
Eccotemp L10 portable tankless
water heater. This will open a
world of enjoyment to going
tankless.

We highly suggest you take the
time to read through all of the
safety and installation procedures
in this manual, before attempting
to install your new water heater.

Should you have any questions,
please feel free to visit our
helpdesk located at www.
eccotemp.com for further
information.

General Safety ....................................1-5

Features and Benets ...................5-6

Care and Maintenance ..................7-9

Getting Started .................................10

Use and Starting ..........................11-12

Troubleshooting Guide ...........13-14

Product Comparison ........................15

Warranty Information ......................16

FOR YOUR RECORDS

Write the model and serial numbers here:
#_______________________________

#_______________________________

You can nd them on a label on the appliance

and/or packaging.

Staple sales slip or canceled check here.

Proof of the original purchase date is needed to
obtain service under the warranty.

READ THIS MANUAL

Inside you will nd many helpful hints on how to

use and maintain your water heater properly. A
little preventive care on your part can save you time
and money over the life of your water heater. You’ll

nd many answers to common problems in the

Troubleshooting Guide. If you review the chart of

Troubleshooting Tips rst you may not need to call

for service.

READ THE SAFETY INFORMATION

Your safety and the safety of others are very
important. There are many important safety messages
in this manual and on your appliance. Always read
and obey all safety messages.
This is the safety alert symbol. Recognize
this symbol as an indication of Important Safety
Information! This symbol alerts you
to potential hazards that can kill or hurt
you and others.

All safety messages will follow the safety alert
symbol and the words: “DANGER”, “WARNING”,
“CAUTION” or “NOTICE”.

These words mean:

DANGER - An imminently hazardous
situation that will result in death or serious injury.

WARNING - A potentially hazardous
situation that could result in death or serious
injury and/or damage to property.

CAUTION - A potentially hazardous situation
that may result in minor or moderate injury.

NOTICE: Attention is called to observe

a specied procedure or maintain a
specic condition.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

2 3

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

IMPORTANT SAFETY INFORMATION READ ALL
INSTRUCTIONS BEFORE USING

Be sure to read and understand the entire Use and Care Manual before attempting to install or
operate this water heater. It may save you time and money. Pay particular attention to the Safety
Instructions. Failure to follow these warnings could result in serious bodily injury or death. Should
you have problems understanding the instructions in this manual, or have any questions, STOP,

and get help from a qualied service technician, or the local gas utility.

DANGER!

PROPERLY INSTALL WATER HEATER

Failure to properly install the water heater outdoors as outlined in the Installation
Instructions in this manual can result in unsafe operation of the water heater. To

avoid the risk of re, explosion, or asphyxiation from carbon monoxide, never

operate this water heater unless it is installed properly and has an adequate

air supply for proper operation. Be sure to inspect the ue terminal for proper

installation at initial start-up; and at least annually thereafter. Refer to the Care

and Cleaning section of this manual for more information regarding ue terminal

inspection.

WARNING!

Gasoline, as well as other ammable materials and liquids (adhesives, solvents,
paint thinners etc.), and the vapors they produce are extremely dangerous. DO NOT
handle, use or store gasoline or other ammable or combustible materials any where

near or in the vicinity of a water heater or any other appliance. Be sure to read and
follow the labels on the water heater, as well as the warnings printed in this manual.
Failure to do so can result in property damage, bodily injury or death.

English L10

Vapors from ammable
liquids will explode and catch re

causing death or severe burns.

Do not use or store ammable

products
such as gasoline, solvents or adhesives
In the same room or area near the
water heater.

Keep ammable products :

1. Far away from heater

2. In approved containers

3. Tightly closed

4. Out of children‘s reach

Installation:

Do not Install water heater where ammable products will be stored or
used unless the main burner ame Is at least 18” above the oor. This will

reduce, but

not eliminate, the risk of vapors being ignited by the main burner ame.

Read and follow water heater warnings and Instructions. If owners manual is
missing, contact the retailer or manufacturer.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Water heater has a main burner ame.
The main burner ame

1. Can come on at any time and

2. Will ignite ammable vapors.

Vapors:

1. Cannot be seen

2. Are heavier than air

3. Go a long way on the oor

4. Can be carried from other rooms

to the main burner ame by air

currents.

English L10

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

DANGER!

NATURAL GAS AND LIQUEFIED PETROLEUM MODELS

Both liquid propane (LP) and natural gas (NG) have an odorant added to aid in

detecting a gas leak. Some people may not physically be able to smell or recognize
this odorant. If you are unsure or unfamiliar with the smell of liquid propane or

natural gas, ask the gas supplier. Other conditions, such as “odorant fade,” which
causes the odorant to diminish in intensity, can also hide or camouage a gas leak.

Always check with commercial leak detector or soapy water.

• Gas detectors are recommended in liquid propane and natural gas
applications and their installation should be in accordance with the
detector manufacturer’s recommendations and/or local laws, rules,
regulations or customs.

• Water heaters utilizing liquid propane gas are dierent from natural gas
models. A natural gas water heater will not function safely on liquid propane
gas and vice versa.

• No attempt should ever be made to convert the water heater from
natural gas to lliquid propane gas. To avoid possible equipment damage,

personal injury or re, do not connect the water heater to a fuel type not

in accordance with the portable tankless water heater data plate; propane
for propane portable tankless water heaters and natural gas for natural gas
portable tankless water heaters. These portable tankless water heaters are not

certied for any other fuel type.

• Liquid propane appliances should not be installed below grade (for example,
in a basement) if such installation is prohibited by federal, state and/or local
laws, rules, regulations or customs.

• Propane or liquid propane gas must be used with great caution. It is heavier

than air and will collect rst in lower areas making it hard to detect at nose

level.

• Before attempting to light the water heater, make sure to look and smell

for gas leaks. Use a soapy solution to check all gas ttings and connections.

Bubbling at a connection indicates a leak that must be corrected. When

smelling to detect a gas leak, be sure to sni near the oor also.

• It is recommended that more than one method, such as soapy solution, gas
detectors, etc., be used to detect leaks in gas applications.

Notice: If a gas leak is present or suspected:

• DO NOT attempt to nd the cause yourself.

• DO NOT try to light your water heater.

• DO NOT touch any electrical switch.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

4 5

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

ADDITIONAL WARNINGS

1. Do not leave unattended.

2. The exhaust gas and top of the portable
tankless water heater is HOT! Do not place
hands or any foreign object near the top of the
heater.

3. Do not use in high wind conditions.

4. If the smell of gas is detected, turn o the gas

valve at the tank immediately! Do not use ame

for leak detection.

5. Use only liquid propane.

6. Use only outdoors.

7. Do not over tighten the gas regulator
connection to the portable tankless water
heater with a wrench. This may cause a crack in
the gas regulator.

English L10

The Purpose and Benets the L10

The Eccotemp L10 is a liquid propane red water heater capable of delivering 2 to 2.65 gallons

of hot water almost anywhere. The portable tankless water heater has standard 1/2”NPT pipe

ttings and an adapter for using a standard garden hose for inlet water supply.

The L10 is not a toy. People around the world use similar portable tankless water heaters to
heat their water for recreational use, safely, and reliably.

Gas is supplied from a standard 20 pound propane cylinder (not included) such as used with
outdoor grills. A regulator with hose is included with the heater.

The portable tankless water heater includes a stainless steel rain cap that helps protects it for
outdoor usage.

Ignition is automatic and powered by 2 “D” cell batteries (not included). Burners come on

when water ows, and o when the water is shut o. No pilot light.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Fuel Type

Model

Activation Flow Rate

BTU/h

Related gas pressure

Ignition

Protections

Dimensions

Pipe ttings

LPG (Liquid Propane Gas)

L10

25 PSI

75,000

0.4 PSI

Electric Pulse, D cell Battery Powered
(No electrical connection required)

Auto-cut o water control, automatic ignition, anti-dry
combustion protection, over-pressure overheating and ameout

protection

15” x 6.5” x 35”

1/2 “ NPT, incoming/outgoing water & 3/8” compression tting gas

TECHNICAL SPECIFICATIONS - PORTABLE

Gas Setting

Highest

Lowest

TEMPERATURE INCREASE PER GPM

MODEL

L10
Portable

Functions and Features

English L10

• Water controlled automatic ignition: Water pressure between 20-80 PSI and 0.75-1.0 GPM
opens the ignition circuit for easy and convenient operation.

• Auto-cut-o protection: The auto-cut-o protection will shut the gas supply o immediately
in the event of ameout to reduce the risk of gas leakage.

• Energy savings: 85%.

• Removable drain valve to avoid water pipe and regulator damage caused by freezing water*.

• Anti-dry combustion protection: The portable tankless water heater will shut o the gas
supply in the event water stops owing through the portable tankless water heater.

*Read the maintenance section on draining the portable tankless water heater entirely to avoid
freeze issues.

1.5 GPM

96 °

34 °

*Temperature increases listed are based on use of the water heater under optimal conditions.

Variable factors such as incorrect or imperfect installations and varying incoming water

temperatures may yield dierent results.

2.0 GPM

48 °

17 °

2.5 GPM

32 °

11 °

3.0 GPM

25 °

9 °

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

6 7

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Construction and Parts for the L10

English L10

Flame sensor pin

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

English L10

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483 Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Care and Maintenance

6 MONTH CLEANING ROUTINE

To prevent water scale, lime or rust deposit buildup and ensure

your Eccotemp tankless water heater is running as eciently as

possible it is highly recommended that you clean your Eccotemp
tankless water heater every 6 months. To do this we recommend
that you use our Eccotemp EZ-Flush System Descaler Kit. For more
information and to purchase please visit us at www.eccotemp.com
or call 1-866-356-1992.

DANGER:
Before
disconnecting the
water supply, make
certain no one will
be exposed to the
danger of the hot
water released by
disconnecting. The
water may be hot
enough to create a
scald hazard. The
water should be
released into a
suitable drain to
prevent injury or
property damage.

DANGER:
Hotter
water increases the
potential for hot
water scalds.

DANGER:
Failure to perform
the recommended
routine preventative
maintenance can
harm the proper
operation of this
water heater, which
can cause carbon
monoxide dangers,
excessive hot water
temperatures and
other potentially
hazardous
conditions.

Properly maintained, your water heater will provide years of dependable
trouble-free service. It is recommended that a periodic inspection of the

burner, water lter and top exhaust should be made by service personnel
qualied in gas appliance repair.

It is suggested that a routine preventive maintenance program be
established and followed by the user.

Inspect the area around the water heater to ensure a safe operating
environment. Keep water heater area clear and free from combustible

materials, gasoline, and other ammable vapors and liquids. Ensure the unit

has not been damaged. If damage or denting is present, contact a service
personnel to verify proper operation.

Check for any abnormal sounds during normal operation of the water heater.

All piping should be checked for gas and/or water leaks. Refer to page 2 of
this manual for instructions on leak testing.

The air intake and cold water supply lters should be cleaned monthly.
Refer to the “Housekeeping” section for

further information.

DO NOT operate the water heater if you feel something is wrong with the unit.

DO NOT allow children to operate or otherwise handle the unit.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

8 9

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Housekeeping

HOW TO CLEAN THE WATER FILTER:

1. Make sure the unit is OFF

2. Disconnect the water supply from the water heater.

3. Locate the lter at the end of the water inlet pipe and gently remove with a
screw driver.

4. Rinse the lter in a sink or with a hose to remove any debris

5. Return the lter by gently inserting back into the end of the water inlet pipe.

6. Reconnect the water supply and turn ON the water heater.

Before performing any Housekeeping tasks to this water heater, be sure to turn the unit o and

disconnect the water supply.

Vacuum around the water heater for dust, dirt and lint on a regular basis. Clean the water heater and

front panel by using a damp soft cloth with a few drops of mild detergent and gently wiping the

surfaces of the unit. Wipe any remaining moisture with a dry soft cloth.

To ensure sucient ventilation and combustion air supply, proper clearances must be maintained. The

water lters should be cleaned on a monthly basis.

STORAGE

When not in use your portable tankless water heater should be stored away in a climate controlled area.

WARNING: Item should not be left or stored in freezing conditions. Internal damage can occur.

English L10

Upon completion of use prepare your water heater for storage.

1. Turn OFF water and gas supply and then disconnect from water heater.

2. Open the drain valve (ribbed cylindrical stem next to the water input valve) to ensure draining of

water.

3. Remove the lter at the end of the water inlet pipe and clean. Return lter after cleaning. (see
Housekeeping section above for instructions)

4. Store water heater in a climate controlled area.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Getting Started

English L10

1. 1. Check box for damage. Damages caused in shipment must be reported immediately.

2. 2. Make sure you have all the parts.

Please note: Included parts and accessories may vary depending on country and
regulations.

qty. 1 -

Water heater

qty. 1 -

Hardware pack

qty. 1 -

Rain cap

qty. 1 - 1/2” NPT to

garden hose adapter

qty. 1 - Gas hose

and regulator

3. 3. Install the rain cap to the top of the ue vent. The rain cap should t securely. It is
recommended that a beaded layer of high temperature sealant be used around the

perimeter of the seal between the rain cap and the ue vent.

4. 4. If using a standard garden hose, attach the 1/2” NPT to garden hose adapter to the

tting marked “Water Input”. Use Sealant tape or other approved sealing method on the
threads for a secure, water tight t. Check to make sure the screen inside the water inlet is

in place and clean. Then attach your water input/garden hose.

5. 5. Install gas supply line and regulator to the portable tankless water heater by using 2

wrenches, one on the compression tting already attached to the water heater and the

other on the gas line. DO NOT OVER TIGHTEN. OVER TIGHTING MAY CRACK THE GAS
REGULATOR CAUSING A GAS LEAK! Check for any gas smell before ignition! Make sure gas
connection is secured.

WARNING!

GAS HOSE ADAPTER

THE L5, L7,& L10 PORTABLE TANKLESS WATER HEATERS HAVE A 1/2’’ TO 3/8” ADAPTER

PLEASE ENSURE THE ADAPETER IS CORRECTLY INSTALLED WITH THREAD SEALANT. A

ALREADY ATTACHED TO THE GAS INLET ON THE WATER HEATER.

SPOOL OF SEALANT TAPE IS INCLUDED WITH THE WATER HEATER.

MULTIPLE WRAPS OF SEALANT TAPE MAY BE

NECESSARY TO ASSURE COMPLETE SEAL.

AL WAYS CHECK FOR GAS LEAKS BEFORE USING HEATER.

6. Attach the water output to the tting marked “Water Outlet”. Do not over tighten.

7. Install two “D” cell batteries in the compartment on the bottom left of the heater. Check
that batteries are facing the correct direction.

8. Use the top tab on the portable tankless water heater to suspend from a mounted screw
capable of holding 30 pounds. Place at a comfortable height without putting stress on the
gas hose.

9. Attach gas regulator with hose to the LP tank. Use hand pressure only on the plastic
connector. LEAVE GAS TANK VALVE IN THE “OFF” POSITION.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

10 11

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Before going to the USE section:

Check around area for ammables, especially gasoline or other vapors which may ignite. The

exhaust and top of the portable tankless water heater will get HOT! Make sure there are no
foreign objects around the portable tankless water heater or have fallen into the top.

Use and Starting

Warning: This model is intended for recreational & portable use only. This
model CANNOT be permanently mounted or plumbed in any way.

1. Turn on incoming water supply. Ensure that you have adequate water
pressure of between 40-5O PSI.

2. Turn your water output device to its “o” position.

3. Turn the gas valve on the cylinder all the way open.

4. IF THE SMELL OF GAS IS DETECTED, TURN OFF THE GAS VALVE
IMMEDIATELY!!

5. Set the water regulator knob on the face of the portable tankless water
heater to its highest setting.

6. Set the gas regulator knob on the face of the portable tankless water
heater to its minimum setting.

English L10

7. Turn on your water output device to the “on” position and adjust to the

desired water ow.

8. There will be a series of audible clicks and the burner will ignite. Should

the burner not ignite after 5 seconds, shut o and go to the “Trouble

Shooting” section.

9. Upon completion of use or storage, open the drain valve (ribbed
cylindrical stem next to the water input valve) to ensure draining of water.

10. Turn o your gas supply.

11. WARNING: If the outside temperature is around or below freezing (32
degrees F, 0 degrees C), ensure that the drain valve is opened and water
drained from the portable tankless water heater after each use to avoid
internal damage to the water regulator. You will also need to unhook
the outgoing water line to ensure that any water in the heat exchanger is
drained. Failure to properly drain your portable tankless water heater will
cause water damage which may or may not be reparable. Please check
the warranty information found on our website at www.eccotemp.com
for more information on freezing issues.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

English L10

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Adjustment

The temperature of the outgoing water is dependent on the temperature of the incoming water
balanced with the amount of heat applied. Use extreme caution in setting the outlet water
temperature.

1. With the water regulator set to high, and the gas regulator set to low,

feel the outgoing water. This is the lowest setting available.

2. To initially raise the outgoing temperature, slowly turn the gas valve

towards maximum. Adjust slowly and check the temperature often.
There will be a slight delay between increasing the gas supply and
the increase in water temperature.

3. Should the outlet water temperature need to be higher, slowly

reduce the water ow regulator until desired temperature is reached.

(Warning: Do not alter or change this water heater’s original temperature
sensor)

WARNING: THE PORTABLE TANKLESS
WATER HEATER IS CAPABLE OF PRODUCING
SCALDING WATER TEMPERATURES!

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

12 13

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

DO NOT RETURN TO STORE

Please visit our Helpdesk at www.eccotemp.com or contact us via email at
[e-mail] if you encounter a problem!

Troubleshooting

Portable tankless water heater will not start – there are no audible clicks at startup:

a. The rst thing to check is to ensure that the incoming water on the “right” side of the portable

tankless water heater. If the incoming and outgoing are reversed, the portable tankless water heater
will not work. The incoming is on the far right and the outgoing is in the middle.

b. Check to make sure you have freshly charged batteries and they are installed in the correct
position.

c. Number one reason that the portable tankless water heater does not ignite is that there is not

enough water pressure. You need a minimum of 0.25-10 PSI, sustained. Municipal water should
supply enough water pressure. Most 12/18/120/240 pumps well as long as they are capable of
delivering pressure of 0.25-10 PSI or greater.

ADJUSTMENT: Looking up at the bottom of the portable tankless water heater, you will see two
“slits” in the case where the front and back come together. Locate the water regulator where you
will see two Phillips head screws. Take the screw that is furthest on the right (larger screw) in about

a ¼ or ½ turn. This will enable the portable tankless water heater to operate on a lower water

pressure by restricting ow.

NOTE: Before attempting to remove the cover, call technical support at 866.356.1992

d. A wire has become disconnected inside the portable tankless water heater during shipping. Make

sure the gas is OFF. The front cover is held by six screws, four on top, two on bottom. The knobs pull
o. All the wiring is done with push together plastic connectors. They are all visible without further

dismantling of the portable tankless water heater. It should be obvious when a wire has become
disconnected.

e. It is possible that some debris or epoxy might have entered the water regulator. Check to see if
the lter screen on the water inlet is clear of debris. You can also reverse the hookup by taking your
water source and hooking it up to the water outlet side and back ushing the system.

f. Propane gas cylinders sometimes are contaminated with air, especially new tanks upon their rst
lling. Cycle the portable tankless water heater turning o and on your output ow or similar. Does

not include a shower head.

Should a portable tankless water heater fail to light or stay lit after 10 cycles, please visit our
helpdesk located at www.eccotemp.com for additional troubleshooting steps.

Portable tankless water heaters starts, then shuts o:

a. If the Rain cap is blocked, or not long enough, the portable tankless water heater will shut o after

a few minutes.

b. The portable tankless water heater requires a minimum of about 0.75 gallons per minute (2 liters)
and a minimum of about 20 PSI / 1.38 bar. Note: water pressure is at the lower end of operating
parameters. You will need a sustained water pressure of approximately 40-60 PSI / 2.7-4.1 bar for
adequate use if you are using a 12/18/120/240 volt pump. See ADJUSTMENT in previous section

above.

English L10

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Troubleshooting Continued...

English L10

c. Out of, or low on gas. Propane gas cylinders sometimes are contaminated with air, especially new

tanks upon their rst lling. Cycle the portable tankless water heater on and o by using the shower
head switch several times (5) to purge the air from the gas. If this doesn’t clear the air then the tank

must be purged.

d. One of the ignition sensors is bent and/or too close to the burner. Look to ensure that the

ignition pins and the heat sensor are completely vertical and they do a 90 degree to the back of the

box. If they are not straight (i.e. a 45 degree angle) then you can straighten them with pliers.

e. The thermocouple is either too high or too low to complete the circuit. Check to ensure that the

thermocouple is ush with the hole in the heat exchanger.

f. The gas sensor wire (looks like a black ground wire on the gas regulator) ange might have come

loose or is no longer connected.

g. There is a faulty heat sensor. This is usually diagnosed by taking the front case o of the portable

tankless water heater and let it run. If it continues to operate, then one of the sensors and/or the

wire harness needs to be replaced. This may also be caused by insucient clearance on the back of

the portable tankless water heater where the majority of air intake is.

h. The valve on the propane tank should be all the way “Open”.

i. Freshly charged batteries are required for ignition spark. Make sure batteries are aligned in the

proper polarity (+/-).

The water does not get hot enough:

a. You are operating the portable tankless water heater above 4,000 feet / 1,000 meters. We only
recommend using it below elevations of 4,000 to 5,500 feet.

b. Look into the viewer panes (middle horizontal windows on the front cover) to see if there is a
blue ame. If the ame is yellow there could be a cracked gas regulator. Do Not Attempt to use the

portable tankless water heater and call Eccotemp directly at 866.356.1992.

Water is owing, but there is no hot water coming out:

a. Ensure that you have the incoming water supply and the outgoing water supply hooked up

properly. Your water supply should be attached to your incoming connection (located on the
far right) and the shower head should be attached to the outgoing water (located as the center

connection).

b. Ensure that you have adequate water pressure of at least 20 PSI / 1.38 bar, sustained.

c. Ensure that you have adequate gas in your propane bottle and that the LP regulator is threaded all

of the way on to the portable tankless water heater.

d. Fresh batteries are required for ignition spark. Make sure batteries are aligned in the proper

polarity (+/-).

If you are still having troubles or are on a modied water system, please visit our helpdesk located at

www.eccotemp.com for additional troubleshooting steps.

The portable tankless water heater does nothing:

a. Ensure that you have your water source hooked up to the water inlet side (far right connection)
and the shower handle is hooked up on the water outlet side (middle connection).

b. Ensure that you have an adequate supply of propane.

c. Ensure that you have freshly charged batteries.

If you are still having troubles or are on a modied water system, please call techincal support at

866.356.1992.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

14 15

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

PORTABLE PRODUCT COMPARISONS

English L10

L5

L5 L7

INSTALLATION OUTDOOR ONLY

BTU

Flow Rate

Portable

Power Source

Ga s Type

Venting

Water Pressure

Regulator & Hose

Temperature Control

Warr anty

Product Dimensions

SPECIFICATIONS

Package Dimensions

37, 500

Rated 1.5 GPM

Yes

2 “D” Cell Bat teri es

Liquid Propane Only

None Needed

20-80 PSI

Standard / Included

Manu al 80° - 120°F

1 Yea r

12” x 4.5” x 20 ” - 11.2 lbs

12.4” x 7.7” x 21.9” - 13.8 l bs

L7

OUTDOOR ONLY

41,000

Rated 1.6 GPM

Yes

2 “D” Cell Bat teri es

Liquid Propane Only

None Needed

20-80 PSI

Standard / Included

Manu al 50° - 125°F

2 Yea rs

13.5” x 6.5” x 19.5” - 14.7 lbs

14” x 7.7” x 25.8” - 16 lbs

L10

L10

OUTDOOR ONLY

75,000

Rated 2.65 GPM

Yes

2 “D” Cell Bat teri es

Liquid Propane Only

None Needed

25-80 PSI

Standard / Included

Manu al 80° - 1 40°F

1 Yea r

15” x 6.5” x 35” - 17.5 lbs

15.7” x 9.6” x 35.4” - 23.5 lbs

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

English L10

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483 Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

Eccotemp Systems ,LLC
Limited Warranty Information

EccoTemp hereby warrants this product to be free of material defects in materials and workmanship
when installed and operated according to EccoTemp’s installation and operating instructions. This

Limited Warranty extends to the original purchaser and subsequent owners, but only while the
product remains as the site of the original installation. This Limited Warranty terminates if moved
or reinstalled at a new location. There are no warranties, express or implied made or given other
than contained in this Limited Warranty. No agent, employee or representative of EccoTemp has any

authority to bind EccoTemp to any representation or warranty concerning the Product not contained

in this Limited Warranty.

Except as expressly set forth herein, THERE ARE NO REPRESENTATIONS OR WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING, WITHOUT LIMITATION, AS TO MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE WITH RESPECT TO ANY GOODS SOLD HEREUNDER. BUYER’S EXCLUSIVE
REMEDY IS LIMITED TO REPAIR OR REPLACEMENT OF THE GOODS SOLD, AT ECCOTEMP’S
DISCRETION. ECCOTEMP SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Item Period of Coverage

Heat Exchanger 1 year

All other parts 1 year

Free Accessories (Showerhead,hose,regulator etc) 30 days

Coverages are void if the unit is used in a hot water circulation loop, in series with a circulation
system or where an on-demand recirculation system is not incorporated.
Owner is responsible for all other costs incidental to repair such as labor, shipping, delivery and

permits. Proof of purchase required. Products repaired will be covered under this Limited Warranty

for the remainder of term of the original purchase.

This Limited Warranty becomes null and void if any of the following are determined to be a

contributing factor to the failure of the product:

1. Abuse, misuse, alteration, neglect or misapplication;

2. Improper or inadequate maintenance;

3. Inadequate water quality;

4. Installation in a corrosive or otherwise destructive environment;

5. Freeze Damage;

6. Scale buildup;

7. Incorrect gas or water pressure;

8. Acts of force Majeure

This Product is not to be used as a pool or spa heater.

Shipping Related Costs:

Within the rst 30 days of purchase, Eccotemp will cover all ground shipping costs for warranty
related issues, excluding AK, HI, Canada, and any location outside of the continental US. After the
rst 30 days of purchase, Eccotemp will cover all shipping costs to the customer for warranty related
issues, excluding AK, HI, Canada, and any location outside of the continental US. After the rst 30

days of purchase, the customer is responsible for all shipping to Eccotemp, regardless of reason or
circumstance. The method for warranty related shipping will be Ground equivalent with the provider
of Eccotemp’s choosing.

AK, HI, Canada, and any location outside of the continental US, will be responsible for all shipping
costs, regardless of reason or circumstance.

All shipments of any type of product coming to Eccotemp for any reason must have an RGA for any
repairs to be made. Please contact Eccotemp to obtain an RGA number prior to shipping anything
to Eccotemp. Failure to do so could result in loss of product. Eccotemp will not be responsible for
replacement due to loss or damage if these steps are not properly followed.

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

16 17

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

English L10

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

English L10

Phone: [phone] | Email: [e-mail] | Address: 315 - A Industrial RD Summerville, SC 29483

PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL

IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.

18 PB

THIS MANUAL AND ALL ECCOTEMP CONTENT IS SUBJECT TO CHANGE WITHOUT NOTICE.

Support: Eccotemp.com/help-desk Shop Online: Eccotemp.com/products Store Locator: Eccotemp.com/locator
