New Types
- Preliminary
4100N Series cont.
Tubeaxial
119x119x38mm High Performance
■ New axial fan series with highest air flow and pressure performance.
■ 3-phase EC motor.
■ Electronic protection against reverse polarity, locked rotor and overloading.
■ Metal fan housing, Impeller of fiber-glass reinforced plastic PA. Fan housing with ground lug
for M4 x 9 screw (Torx).
■ Air intake over struts. Rotational direction CW looking at rotor.
■ All models with integrated PWM Speed control an /2 Tacho Signal. Other options available.
■ Electrical connection via 2 leads AWG 20, Sensor and Control leads AWG 22, UL 1007, TR 64.
Part
Number
4114N/2H7P
4114N/2H8P
4118N/2H7P
4118N/2H8P
External Capacitor with 470 μF recommended.
*36 to 72 VDC available on request.
Preliminary Data - Subject to change without notice.
Curve
1
2
1
2
CFM
294
336
294
336
@ 0
0.236
1.5 (38)
(6)
VDC
24
24
48
48
4.921
(125)
Volt.
Range
16 to 30
16 to 30
36 to 60”
36 to 60”
Power
(W)
90
120
90
120
4.126 (104.8)
4.567 (116)
Noise
76
78
76
78
dBA
1200
1000
800
600
400
aP
Noise
8.5
8.9
8.5
8.9
)OH
n
i
(
Bel
²
0.4
2.34.2
6.18.0
2
1
Temp
Ramge °C
-20 to +75
-20 to +75
-20 to +75
-20 to +75
Bearing
Type
Ball
Ball
Ball
Ball
Speed
(RPM)
9500
11000
9500
11000
Wgt.
0.94
0.94
0.94
0.94
(lbs)
4.126 (104.8)
4.685 (119)
200
0.169
(4.3)
f
p
0 50 100 150 200 250 300
•
100 200
V
300 400 500 m³/h
0.169
(4.3)
CFM
