ebm-papst 8452/2GHHP Data Sheet

8452 /2GHHP

Nominal data

Type 8452 /2GHHP

Nominal voltage VDC 12

Nominal voltage range VDC 10.8 .. 13.2

DC axial compact fan

Speed (rpm) min-14400

Power consumption W 3.5

Min. ambient temperature °C -20

Max. ambient temperature °C 60

Air flow m3/h 83

Sound power level B 5.5

Sound pressure level dB(A) 42

ml = Max. load · me = Max. efficiency · fa = Free air · cs = Customer specification · ce = Customer equipment
Subject to change

ENU (Web) · Approved 2016-06-22 · Page 1 / 4

· · · · · ·

8452 /2GHHP

DC axial compact fan

Technical description

Housing material Glass-fiber reinforced PBT plastic

Impeller material Glass-fiber reinforced PA plastic

Weight 0.105 kg

Dimensions 80 x 80 x 25 mm

Airflow direction Exhaust over struts

Direction of rotation Counterclockwise, viewed toward rotor

Storage Extremely quiet Sintec sleeve bearings.

Service life L10 at 40 °C 65000 h

Service life L10 at maximum
temperature

Cable Leads AWG 24, TR 64, stripped and tin-plated.

Motor protection Protection against reverse polarity and blocked rotor.

Option Possible custom designs:

40000 h

Speed signal
Go / No-go alarm
Alarm with speed limit
External temperature sensor
Internal temperature sensor
PWM control input
Analog control input
Moisture protection

ENU (Web) · Approved 2016-06-22 · Page 2 / 4

· · · · · ·
