ebm-papst 7218N Data Sheet

7218 N

Nominal data

Type 7218 N

Nominal voltage VDC 48

Nominal voltage range VDC 24 .. 60

DC axial compact fan

Speed (rpm) min-13050

Power consumption W 12.0

Min. ambient temperature °C -25

Max. ambient temperature °C 72

Air flow m3/h 360

Sound power level B 6.2

Sound pressure level dB(A) 53

ml = Max. load · me = Max. efficiency · fa = Free air · cs = Customer specification · ce = Customer equipment
Subject to change

ENU (Web) · Approved 2016-06-22 · Page 1 / 4

· · · · · ·

7218 N

DC axial compact fan

Technical description

General description * Power consumption when wide open; these values may be considerably higher at the

operating point.

Impeller material Glass-fiber reinforced PA plastic

Weight 0.725 kg

Dimensions Ø 150 x 55 mm

Housing material Die-cast aluminum

Airflow direction Exhaust over struts

Direction of rotation Counterclockwise, viewed toward rotor

Storage Ball bearing

Service life L10 at 40 °C 80000 h

Service life L10 at maximum
temperature

Cable Leads AWG 22, TR 64, stripped and tin-plated.

Motor protection Protection against reverse polarity and blocked rotor.

Locked-rotor protection Electronic locked-rotor protection

Approval VDE, CSA, UL, CE

Option Vario-Pro fan

37500 h
