ebm-papst 612JH Data Sheet

612 JH

Nominal data

Type 612 JH

Nominal voltage VDC 12

Nominal voltage range VDC 7 .. 13.6

DC axial compact fan

Speed (rpm) min-111700

Power consumption W 7.7

Min. ambient temperature °C -20

Max. ambient temperature °C 70

Air flow m3/h 70

Sound power level B 6.4

Sound pressure level dB(A) 53

ml = Max. load · me = Max. efficiency · fa = Free air · cs = Customer specification · ce = Customer equipment
Subject to change

ENU (Web) · Approved 2016-06-22 · Page 1 / 4

· · · · · ·

612 JH

DC axial compact fan

Technical description

Housing material Glass-fiber reinforced PBT plastic

Impeller material Glass-fiber reinforced PA plastic

Weight 0.100 kg

Dimensions 60 x 60 x 32 mm

Airflow direction Exhaust over struts

Direction of rotation Clockwise, viewed toward rotor

Storage Ball bearing

Service life L10 at 40 °C 57500 h

Service life L10 at maximum
temperature

Cable Leads AWG 24, TR 64, stripped and tin-plated.

Motor protection Protection against reverse polarity and blocked rotor.

Locked-rotor protection With electronic locked-rotor and overload protection

Approval CE

Option Possible custom designs:

27500 h

Speed signal
Go / No-go alarm
Alarm with speed limit
External temperature sensor
PWM control input
Analog control input
Moisture protection
