ebm-papst 5218NH Data Sheet

5218 NH

Nominal data

Type 5218 NH

Nominal voltage VDC 48

Nominal voltage range VDC 36 .. 56

DC axial compact fan

Speed (rpm) min-13650

Power consumption W 9.6

Min. ambient temperature °C -20

Max. ambient temperature °C 55

Air flow m3/h 252

Sound power level B 6.0

Sound pressure level dB(A) 51

ml = Max. load · me = Max. efficiency · fa = Free air · cs = Customer specification · ce = Customer equipment
Subject to change

ENU (Web) · Approved 2016-06-22 · Page 1 / 4

· · · · · ·

5218 NH

DC axial compact fan

Technical description

General description Power consumption when wide open; these values may be considerably higher at the

operating point.

Housing material Glass-fiber reinforced PBT plastic

Impeller material Glass-fiber reinforced PA plastic

Weight 0.310 kg

Dimensions 127 x 127 x 38 mm

Airflow direction Exhaust over struts

Direction of rotation Counterclockwise, viewed toward rotor

Storage Ball bearing

Service life L10 at 40 °C 45000 h

Service life L10 at maximum
temperature

Cable Leads AWG 22, TR 64, stripped and tin-plated.

Motor protection Protection against reverse polarity and blocked rotor.

Locked-rotor protection With electronic locked-rotor and overload protection

Approval VDE, CSA, UL, CE

Option Speed signal

32500 h

ENU (Web) · Approved 2016-06-22 · Page 2 / 4

· · · · · ·
