Page 1
Date 2022-04-27
Akku Vision – Specification EBV E-Bike Battery comp. to Bosch* Active / Performance
S. 1 / 3
Index 1.0
*Bosch is a trademark of the Robert Bosch GmbH
R
SPECIFICATIONS
FOR EBV E-BIKE BATTERY, COMPATIBLE TO
BOSCH* ACTIVE (PLUS) / PERFORMANCE (CX) DRIVE SYSTEM WITH 36 V
Power information
15 Ah / 540 Wh Downtube Battery
312 x 94 x 80 mm
Page 2
Date 2022-04-27
Akku Vision – Specification EBV E-Bike Battery comp. to Bosch* Active / Performance
S. 2 / 3
Index 1.0
*Bosch is a trademark of the Robert Bosch GmbH
Akku Vision GmbH
R
CONTENT
Technical information ................................................................................................................................................... 3
Charging ........................................................................................................................................................................ 3
Discharging ................................................................................................................................................................... 3
Intelligent eBV Battery Management System (BMS), Gen. 3 ....................................................................................... 3
Industriestraße-West 6
D-63808 Haibach
Phone: +49 (0) 6021 3289288
Email: info@akkuvision.de
Web: www.akkuvision.de
E-Bike Vision is a trademark of the Akku Vision GmbH
Page 3
Date 2022-04-27
Akku Vision – Specification EBV E-Bike Battery comp. to Bosch* Active / Performance
S. 3 / 3
Index 1.0
*Bosch is a trademark of the Robert Bosch GmbH
Mounting
Downtube
Technical information
Li-Ionen battery 15 Ah / 540 Wh
Nominal voltage 36 V
Nominal capacity 15 Ah
Energy 540 Wh
Cell Configuration 10 Series 3 Parallel
Dimensions 312 x 94 x 80 mm
Weight 2800 g
Charging
• ConstantCurrent / ConstantVoltage
• Max. 8 A charge current
Discharging
• 15 A continuous discharge current
• 24 A for 3 s
• 30 A for 200 ms
Intelligent eBV Battery Management System (BMS), Gen. 3
Safety Features
• Control of cell and BMS temperature
• Single cell voltage monitoring
• Passive cell balancing
• Battery pack voltage monitoring
o over voltage protection (cells & pack)
o deep discharge protection (cells & pack)
• Battery pack current monitoring
o for charging
o for discharging
o short-circuit protection
Communication port
• CAN Bus (Bosch Active / Performance compatible)
• Compatible with Bosch Diagnostic Tool
• Integrated Bluetooth Chip for firmware updates
SoC (State of Charge) Display
• 5 LEDs and communication to HMI
