Evolv & Glider
Perfect Fit Guide
Proper positioning is needed to achieve optimum standing posture.
step one - measure
Before transfering into the stander,
measure for approximate (A) seat
depth and seat to (B) foot plate settings
step two - seat depth
Use the above measurement (A) to
adjust the seat depth on the stander.
To adjust seat depth, loosen the knob
under the seat (C). Depress the snap
button on the adjustment tube while
moving the back (D). Tighten the knob
after adjusting.
For the Evolv: Use measurement “A”
and measure from the front of the
seat to the back. Adjust the seat depth
until the proper measurement has
been reached.
For the Glider: Use measurement “A”
and measure from the center of the
kneepad to the back. Adjust the seat
depth until the proper measurement
has been reached.
step three - back angle
After achieving your desired seat
depth, rotate the back angle (E) adjustment knob so the (F) seat/back angle
indicator is in the green area prior to
standing.
(A)
(C)
(B)
(D)
(F) (E)
Note: Repeat steps 2 and 3 for each
color adjustment.
These adjustments are only to be made while the unit is in the seated position.
over . . .
444
www.easystand.com 800•342•8968
™
Evolv & Glider
Perfect Fit Guide
Proper positioning is needed to achieve optimum standing posture.
step four - footplates
Use the above (B) measurement to
adjust the foot plate height. Loosen
the (G) ratchet handles on the foot
plates to adjust height and
plantar/dorsi. Tighten ratchet handles after positioning. The knees
should be slightly lower than the hip
(H).
step five - Evolv positioning
If you have a Glider, skip to step six.
Position the user’s hips as close as
possible to (I) stander’s hip pivot. To
determine correct positioning, only
two fingers should fit between the
front of the seat and the back of the
knee (J).
step six - kneepad
For the Evolv: Adjust the (K)
kneepad so it fits comfortably up to
the knees.
For the Glider: Slide into kneepads
(L) and secure the calf straps behind
the knees.
(G) (H)
(I) (J)
(K) (L)
Caution: These adjustments are only to be made
!
while the unit is in the seated position.
Inspect your standing frame periodically to assure that it is in safe operating condition.
www.easystand.com 800•342•8968
Printed in the USA. © 2011 Altimate Medical, Inc. FORM EVPFG 0811
