GAS/OIL
RATIO
50:1
Operator’s Manual
800 Watt
Inverter Generator
SN
Get parts online at
www.getearthquake.com
Product #: IG800W
P/N: OMIG800W
ECN: 10526
REV3: 07/11/14
© 2014 Ardisam, Inc.
All Rights Reserved
Operator’s Manual
PORTA-0013R1
800 Watt Inverter Generator
INTRODUCTION
Congratulations on your investment in quality. Thank you for purchasing an IG800W Inverter Generator from Earthquake. We have
worked to ensure that the IG800W meets the highest standards for usability and durability. With proper care, your generator will
provide many years of service.
Please read this entire manual before use. Earthquake reserves the right to change, alter or improve the product and this
document at any time without prior notice.
CONTENTS
Registration .................................................................................................................................................................................................................................... 2
Warnings & Safety Precautions ............................................................................................................................................................................................ 3-7
Safety Decals .............................................................................................................................................................................................................................8--9
Features & Controls ............................................................................................................................................................................................................. 10-11
Specications ...............................................................................................................................................................................................................................12
Pre-Operation Check .................................................................................................................................................................................................................12
Operation ............................................................................................................................................................................................................................... 13-14
Maintenance ......................................................................................................................................................................................................................... 14-17
Transport & Storage ...................................................................................................................................................................................................................18
Troubleshooting & Repair ................................................................................................................................................................................................18-19
Electrical Wire Diagram ............................................................................................................................................................................................................20
Illustrated Parts Breakdown.............................................................................................................................................................................................21-23
Warranty ................................................................................................................................................................................................................................. 25-27
Federal Emissions Information
Earthquake warrants to the retail purchaser, that this small, o-road engine was designed, built and equipped to conform at the
time of initial sale to all applicable regulations of the U.S. Environmental Protection Agency (EPA).
Registration and Service
Record the model number and serial number in the space provided for easy
reference when ordering parts or requesting technical support. Excluding
emissions-related warranty items, the warranty is valid only if the completed
registration is received by Ardisam within 30 days of purchase. (SEE WARRANTY
SECTION FOR MORE INFORMATION.) You can register your warranty online
by visiting www.GetEarthquake.com, or by mailing it to: Ardisam, 1160 Eighth
Avenue, Cumberland, WI 54829. For additional information, call Earthquake
customer service at (800) 345-6007 Mondays through Fridays from 8 a.m. to 5 p.m.
CST.
SERIAL NUMBER
LOCATION
ARDISAM, INC.
1160 8th Avenue | Cumberland, WI 54829 | USA
Serial No.
(dBA): 58
WA
16044
Model: IG800W Year: 2013
Type: Inverter Generator
Max. AC Output: 800 W
Mass: 9.5 kg L
OWNERSHIP RECORDS
Owner’s Name:
Owner’s Address:
City: State/Province: Zip Code/Postal Code:
Model Number: Serial Number:
Date of Purchase:
Notes:
Read and keep this manual for future reference. This manual contains important information on SAFETY, ASSEMBLY, OPERATION,
AND MAINTENANCE. The owner must be certain that all the product information is included with the unit. This information
includes the MANUAL, the REPLACEMENT PARTS and the WARRANTIES. This information must be included to make sure state laws
and other laws are followed. This manual should remain with the product even if it is resold.
2
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
WARNINGS & SAFETY PRECAUTIONS
Operator’s Manual
800 Watt Inverter Generator
Owner’s Responsibility
Accurate assembly and safe and eective use of the machine is
the owner’s responsibility.
• Read and follow all safety instructions.
• Carefully follow the pre-operation check instructions.
• Maintain the machine according to directions and
schedule included in this Earthquake operator’s
manual.
• Ensure that anyone who uses the machine is familiar
with all controls and safety precautions.
Special Messages
Your manual contains special messages to bring attention to
potential safety concerns, machine damage as well as helpful
operating and servicing information. Please read all the
information carefully to avoid injury and machine damage.
NOTE: General information is given throughout the
manual that may help the operator in the
operation or service of the machine.
THIS SYMBOL POINTS OUT IMPORTANT
SAFETY INSTRUCTIONS WHICH IF NOT
FOLLOWED COULD ENDANGER YOUR
PERSONAL SAFETY OR THE SAFETY OF
YOUR EQUIPMENT. READ AND FOLLOW ALL
INSTRUCTIONS IN THIS MANUAL BEFORE
ATTEMPTING TO OPERATE THIS EQUIPMENT.
Before Operating Engine:
Please read this section carefully. Read entire operating and
maintenance instructions for this product. Failure to follow
instructions could result in serious injury or death. Operate the
machine according to the safety instructions outlined here and
inserted throughout the text. Anyone who uses this machine
must read the instructions and be familiar with the controls.
Intended Use /
Foreseeable Misuse
IMPORTANT: This is a motorized inverter generator that
processes DC energy into smooth AC power. It is a pedestrianuse product, with a gasoline-fueled internal combustion
engine to generate usable power. It shall not be used for any
other purpose.
WARNING
WARNING INDICATES A HAZARD WHICH, IF NOT
AVOIDED, COULD RESULT IN DEATH OR SERIOUS
INJURY AND/OR PROPERTY DAMAGE.
CAUTION
CAUTION INDICATES YOU CAN BE HURT OR
YOUR EQUIPMENT DAMAGED IF THE SAFETY
INSTRUCTIONS THAT FOLLOW THIS SIGNAL
WORD ARE NOT OBEYED.
IMPORTANT
INDICATES HELPFUL INFORMATION FOR PROPER
ASSEMBLY, OPERATION, OR MAINTENANCE OF
YOUR EQUIPMENT.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
ENGINE EXHAUST FROM THIS PRODUCT
CONTAINS CHEMICALS KNOWN TO THE STATE OF
CALIFORNIA TO CAUSE CANCER, BIRTH DEFECTS,
OR OTHER REPRODUCTIVE HARM.
WARNING
YOU MUST READ, UNDERSTAND AND COMPLY
WITH ALL SAFETY AND OPERATING INSTRUCTIONS
IN THIS MANUAL BEFORE ATTEMPTING TO SETUP
AND OPERATE YOUR MACHINE.
FAILURE TO COMPLY WITH ALL SAFETY AND
OPERATING INSTRUCTIONS CAN RESULT IN LOSS
OF MACHINE CONTROL, SERIOUS PERSONAL
INJURY TO YOU AND/OR BYSTANDERS, AND RISK
OF EQUIPMENT AND PROPERTY DAMAGE. THE
TRIANGLE IN THE TEXT SIGNIFIES IMPORTANT
CAUTIONS OR WARNINGS WHICH MUST BE
FOLLOWED.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 3
Operator’s Manual
800 Watt Inverter Generator
GENERAL SAFETY RULES
Read, understand, and follow all instructions on the machine
and in the manual(s). Be thoroughly familiar with the controls
and the proper use of the machine before starting.
• Use this equipment for its intended purpose only.
• Familiarize yourself with all of the safety and
operating decals on this equipment and on any of its
attachments or accessories.
• Never operate in an enclosed area, in a vehicle or
indoors even if doors and windows are open.
• Only allow responsible individuals who are familiar
with the instructions to operate the machine. Do
not allow children to operate this machine. Do not
allow adults to operate the machine without proper
instruction.
• Operate generator only on level surfaces and where it
will not be exposed to excessive moisture, dirt, dust or
corrosive vapors.
• Keep hands, feet, clothing, etc., away from drive belts,
fans and other moving parts. Never remove any fan
guard or shield while the unit is operating.
• Do not operate the machine without proper guards or
other safety protective devices in place.
• See manufacturer’s instructions for proper operation
and installation of accessories. Only use accessories
approved by the manufacturer.
• Do not operate or work on this product when
fatigued or under the inuence of alcohol, drugs or
other medication which can cause drowsiness or
aect your ability to operate this machine safely.
• Do NOT operate generator in rain or snow.
• If the equipment should start to vibrate abnormally,
stop the engine (motor). Push the STOP position
on the RUN/STOP switch. Check immediately for
cause. Vibration is generally a warning of trouble. If
the noise or vibrations of the machine increase, stop
immediately and perform an inspection.
• Never leave the machine unattended when the
engine is running. Push the STOP position on the
RUN/STOP switch. Regularly inspect the machine.
Make sure parts are not damaged or loose.
• Certain parts of the generator get extremely hot
during operation. Avoid severe burns, keep clear of
the generator until it has cooled.
• Do not alter the construction of the generator or change
controls which might create an unsafe operating
condition.
• Keep all screws, nuts and bolts tight.
• Do not transport the machine from one place to
another with the engine running.
• Never use the generator or any of its parts as a step.
Stepping on the unit can stress and break parts and
may result in dangerous operating conditions from
leaking exhaust gases, fuel leakage, oil leakage, etc.
• When moving the packaged machine, always do so
with a partner.
• Check local regulations for any restrictions on the use
of this machine.
Product-Specic Safety Rules
• The generator produces dangerously high voltage
when in operation. Avoid contact with bare wires,
terminals, connections, etc., while the unit is running,
even on equipment connected to the generator.
Ensure all appropriate covers, guards and barriers are
in place before operating the generator.
• Never handle any kind of electrical cord or device
while standing in water, while barefoot or while hands
or feet are wet. DANGEROUS electrical shock may
result.
• The generator must be earth grounded in accordance
with all relevant electrical codes and standards before
operating. A 10 gauge copper wire should be used
to connect the ground terminal of the generator to
a grounding rod. A wire too thin may not provide
sucient electrical current carrying capacity to be an
adequate ground path.
• Use a ground fault circuit interrupter in any damp or
highly conductive area (such as metal decking or steel
work).
• Do not use worn, bare, frayed or otherwise damaged
electrical cord sets with the generator.
• In case of accident caused by electric shock,
immediately shut down the source of electrical power.
If this is not possible, attempt to free the victim
from the live conductor. AVOID direct contact with
the victim. Use a non-conducting implement, such
as a rope or board, to free the victim from the live
conductor. If the victim is unconscious, apply rst aid
and get immediate medical help.
4
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
PORTA-0001R1
GROUND GENERATOR WITH THE APPROPRIATE
AMOUNT OF COPPER FOR CURRENT CAPACITY.
COPPER DIAMETER
0.005 IN/AMP
800 Watt Inverter Generator
WARNING
WARNING
ENGINES GIVE OFF CARBON MONOXIDE, AN
ODORLESS, COLORLESS, POISONOUS GAS.
CARBON MONOXIDE MAY BE PRESENT EVEN IF
YOU DO NOT SMELL OR SEE ANY ENGINE EXHAUST.
BREATHING CARBON MONOXIDE CAN CAUSE
NAUSEA, FAINTING OR DEATH, IN ADDITION TO
DROWSINESS, DIZZINESS AND CONFUSION.
IF YOU EXPERIENCE ANY OF THESE SYMPTOMS,
SEEK FRESH AIR AND MEDICAL ATTENTION
IMMEDIATELY.
ENGINE SAFETY PRECAUTIONS
Warning Carbon Monoxide Poisoning
Engines give o carbon monoxide, an odorless, colorless,
poisonous gas. Carbon monoxide may be present even if you
do not smell or see any engine exhaust. Breathing carbon
monoxide can cause nausea, fainting or death, in addition
to drowsiness, dizziness and confusion. If you experience
any of these symptoms, seek fresh air and medical attention
immediately.
If your product comes with a separate engine manual, be sure
to read and follow all safety and warning precautions outlined
there, in addition to any in this manual.
WARNING
USING A GENERATOR INDOORS CAN KILL YOU IN
MINUTES DUE TO CARBON MONOXIDE.
NEVER USE INSIDE A
HOME OR GARAGE.
Preventing Carbon Monoxide Poisoning
• Always start and run engine outdoors. Do not start
or run engine in an enclosed area, even if doors or
windows are open.
• Never try to ventilate engine exhaust indoors. Carbon
monoxide can reach dangerous levels very quickly.
• Never run engine outdoors where exhaust fumes may
be pulled into a building.
• Never run engine outdoors in a poorly ventilated area
where the exhaust fumes may be trapped and not
easily taken away. (Examples include: in a large hole
or areas where hills surround your working area.)
• Never run engine in an enclosed or partially enclosed
area. (Examples include: buildings that are enclosed
on one or more sides, under tents, car ports or
basements.)
• Always run the engine with the exhaust and muer
pointed in the direction away from the operator.
• Never point the exhaust muer towards anyone.
People should always be many feet away from the
operation of the engine and its attachments.
• Do not change the engine governor settings or overspeed the engine.
ONLY USE OUTSIDE, FAR
AWAY FROM WINDOWS,
DOORS AND VENTS.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 5
Gasoline Fires and Handling Fuel Safely
Use extra care in handling gasoline and other fuels. They are
ammable and vapors are explosive.
• When storing extra fuel be sure that it is in an
appropriate container and away from any re hazards.
• Prevent re and explosion caused by static electric
discharge. Use only nonmetal, portable fuel
containers approved by the Underwriter’s Laboratory
(U.L.) or the American Society for Testing & Materials
(ASTM).
• Always ll fuel tank outside in a well ventilated area.
Never ll your fuel tank with fuel indoors. (Examples
include: basement, garage, barn, shed, house, porch,
etc.) Never ll tank near appliances with pilot lights,
heaters, or other ignition sources. If the fuel has to be
drained, this should be done outdoors. The drained
fuel should be stored in a container specically
designed for fuel storage or it should be disposed of
carefully.
• Never remove the fuel cap or add fuel with the engine
running. Stop engine and allow to cool before lling.
• Never drain fuel from engine in an enclosed area.
• Always wipe up excess (spilled) fuel from engine
before starting. Clean up spilled fuel immediately.
If fuel is spilled, do not start the engine but move
product and fuel container from area. Clean up spilled
fuel and allow to evaporate and dry after wiping and
before starting.
• Allow fuel fumes/vapors to escape from the area
before starting engine.
• Test the fuel cap for proper installation before starting
and using engine.
• Always run the engine with fuel cap properly installed
on the engine.
• Never smoke while relling or draining engine fuel
tank.
• Do not store engine with fuel in fuel tank indoors. Fuel
and fuel vapors are highly explosive.
• Never pour fuel from engine fuel tank.
• Never siphon fuel by mouth to drain fuel tank.
• Always have an adult ll the fuel tank and never allow
children to ll the engine.
• Never allow an adult or anyone under the inuence of
drugs or alcohol to ll engine.
• When storing gasoline or equipment with fuel in the
tank, store away from furnaces, stoves, water heaters
or other appliances that have a pilot light or other
ignition source because they can ignite gasoline
vapors.
Operator’s Manual
800 Watt Inverter Generator
CAUTION
HOT GASES ARE A NORMAL BYPRODUCT OF A
FUNCTIONING INTERNAL COMBUSTION ENGINE.
FOLLOW ALL SAFETY INSTRUCTIONS TO PREVENT
BURNS AND FIRES.
DO NOT ALTER/MODIFY ENGINE:
NEVER ALTER OR MODIFY THE ENGINE FROM
THE FACTORY. SERIOUS INJURY OR DEATH MAY
OCCUR IF ENGINE IS MODIFIED OR ALTERED.
WHEN WORKING ON OR REPLACING PARTS FOR
THE ENGINE OR PRODUCT, YOU MUST ALWAYS
PUSH THE RUN/STOP SWITCH TO THE OFF
POSITION.
Burns and Fires
The muer, muer guard and other parts of the engine
become extremely hot during the operation of the engine.
These parts remain extremely hot after the engine has
stopped.
Prevention of Burns and Fires
• Never remove the muer guard from the engine.
• Never touch the muer guard because it is extremely
hot and will cause severe burns.
• Never touch parts of the engine that become hot after
operation.
• Always keep materials and debris away from muer
guard and other hot parts of the engine to avoid res.
Children and bystanders
Tragic accidents can occur if the operator is not alert to the
presence of children and/or bystanders. Never assume that
others will remain where you last saw them.
• Keep the area of operation clear of all persons,
especially small children and pets. Keep children
under the watchful care of a responsible adult.
• Never allow children to operate the machine.
Service
• Always stop the engine whenever you leave the
equipment, before cleaning, repairing or inspecting
the unit. Engine should be turned o and cool. Never
make adjustments or repairs with the engine (motor)
running. Push the STOP position on the RUN/STOP
switch to prevent accidental starting.
• Always wear eye protection when you make
adjustments or repairs.
6
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
• Keep all nuts and bolts tight and keep equipment in
good condition.
• Never tamper with safety devices. Check their proper
operation regularly.
• When servicing or repairing the machine, do not tip the
machine over or up unless specically instructed to do
so in this manual. Service and repair procedures can be
done with the machine in an upright position. Some
procedures will be easier if the machine is lifted on a
raised platform or working surface.
• To reduce re hazard, keep machine free of grass,
leaves or other debris build-up. Clean up oil or fuel
spillage. Allow machine to cool before storing.
• Clean and replace safety and instruction decals as
necessary.
• To guard against engine over-heating, always have
engine lters mounted and clean.
• Inspect machine before storage. When not in use,
push the STOP position on the RUN/STOP switch.
Store indoors in a dry, securly locked location
inaccessible to children.
• Use only original equipment parts from Earthquake
including all nuts and bolts.
• Avoid connecting the generator to commercial power
outlets.
• Avoid connecting the generator in parallel with any
other generator.
Operator’s Manual
800 Watt Inverter Generator
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 7
Operator’s Manual
800 Watt Inverter Generator
SAFETY DECALS
This IG800W Inverter Generator has been designed and manufactured to provide you with the safety and reliability you would
expect from an industry leader in powered chore equipment manufacturing.
Reading this manual and the safety instructions it contains will provide you with the necessary basic knowledge to operate
this equipment safely and eectively. We have placed a safety decal on the generator to remind you of some of this important
information while you are operating the unit.
These important safety decals are illustrated below, and are shown here to help familiarize you with the location and content of
the safety messages you will see as you perform normal operations. Please review these decals now, and if you have any questions
regarding its meaning or how to comply with these instructions, reread the complete safety instruction text in this manual. For
additional questions European customers may contact their local dealer and US customers must call Earthquake customer service.
Should a decal become unreadable because of being worn, faded, or otherwise damaged during the use of your IG800W, please
use the part number information provided to order a replacement label. European customers can order from their local authorized
dealer and US customers can order by calling Earthquake customer service. These decals are easily applied, and will act as a
constant visual reminder to you, and others who may use the equipment, to follow the safety instructions necessary for safe,
eective operation of your inverter generator.
WARNING AVERTISSEMENT
Read owner’s manual before operating this machine.
Failure to follow operating instructions could result in death or serious injury.
Lire le mode d’emploi avant d’utiliser cette machine.
Le non-respect des instructions d’utilisation présente un danger de mort
ou de blessure grave.
Dangerous when wet.
Operate unit in dry area. Failure to operate in dry area may result in death or injury.
Dangereux en présence d’humidité.
Utiliser l’appareil dans un endroit sec. L’utilisation ailleurs que dans un
endroit sec présente un danger de mort ou de blessure.
CAUTION
Hot Surface, Carbon Monoxide, Keep Distance.
Muer area is hot and ejects poisionous carbon monoxide.
Touching muer panel, operating unit in closed area, and not
keeping distance may result in death or injury.
ATTENTION
Surface chaude, monoxyde de carbone, rester à l’écart.
Le pot d’échappement est chaud et dégage du monoxyde de
carbone toxique. Le fait de toucher le panneau d’échappement,
d’utiliser l’appareil dans un espace fermé et de se tenir trop
près présente un danger de mort ou de blessure.
16037
ARDISAM, INC.
1160 8th Avenue | Cumberland, WI 54829 | USA
Serial No.
16044
Model: IG800W Year: 2014
Type: Inverter Generator
Max. AC Output: 800 W
Mass: 9.5 kg L
(dBA): 58
WA
Shock hazard.
Unit must be grounded. Failure to ground unitmay result in death or injury.
Danger de choc électrique.
L’appareil doit être relié à la terre. Un appareil non relié à la terre présente
un danger de mort ou de blessure.
Unit is heavy.
Team lift with a partner. Failure to team lift may result in death or injury.
L’appareil est lourd.
Le soulever à deux personnes. Le levage par une seule personne présente
un danger de mort ou de blessure.
(Part # 16037)
IG800W MULTI
WARNING DECAL 2
Hot Surface, Carbon
Monoxide, Keep
Distance
(Part # 16044)
IG800W SERIAL
NUMBER DECAL
Product Name Plate
with Serial Number
16041
IG800W MULTI WARNING DECAL
Read Manual, Dangerous when
Wet, Shock Hazard Unit is Heavy.
(Part # 16045)
IG800W NO OIL
WARNING TAG
Add Specied
Engine Oil
(Part # 16041)
(Part # 16036)
IG800W EXHAUST
WARNING DECAL
Hot Surface, Carbon
Monoxide, Keep
CAUTION
ATTENTION
Distance
Before operating,
add specied engine
oil to crankcase
(see manual).
Vous devez ajouter
de l’huile-moteur
avant de démarrer
le moteur. (voir le
manuel).
16045
8
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
800 Watt Inverter Generator
(Part #16042)
IG800W FIRE HAZARD
WARNING DECAL
Engine Fuel is Flammable
(Part # 16034)
IG800W SPARK PLUG
ACCESS DECAL
Spark Plug Location
(Part # 16065)
IG800W NO E85
WARNING DECAL
Use Premium
Unleaded Gasoline
16035
(Part # 16035)
IG800W FUEL
ON-OFF DECAL
Fuel Valve ON and O
OFF
ARRÊT
ON
MARCHE
PRIMER BULB
POIRE D’AMORÇAGE
STARTING INSTRUCTIONS
(Part # 16040)
IG800W STARTING
PROCEDURE DECAL
Starting Instructions
and Engine Oil Type
1. Open fuel cap vent and push engine switch
to the “ON”position
2. Turn fuel valve to the “ON” position
3. Push the primer bulb 6 times with the
choke in the “OFF” position
4. Push choke lever to the “ON” position
5. Pull 6 times; if it does not start
prime again and repeat
6. If it still does not start, call 800-345-6007
FUEL SHUT-OFF
ROBINET DE CARBURANT
RUN CHOKE
MARCHE ÉTRANGLÉ
16061
(Part # 16061)
IG800W CHOKE
GENERATOR DECAL
*Run and Choke
.35 L 10W30
INSTRUCTIONS DE DÉMARRAGE
1. Ouvrir le reniard du bouchon de carburant et mettre
l’interrupteur du moteur en position «Marche»
2. Mettre le robinet de carburant en position «Marche»
3. Enfoncer la poire d’amorçage 6 fois avec le volet de départ
en position «Désengagé»
4. Pousser le volet de départ jusqu’en position «Engagé»
5. Tirer 6 fois; si le moteur ne démarre pas, réamorcer et répéter
6. S’il ne démarre toujours pas, appeler le 800-345-6007
16040
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 9
Features & Controls
Operator’s Manual
800 Watt Inverter Generator
10
1
2
3
4
5
6
7
8
9
17
12
13
11
16
15
14
21
20
19
18
LEGEND:
1. ENGINE SWITCH 8. DC RECEPTACLE 15. FUEL VALVE
2. ECONOMY CONTROL SWITCH 9. AC RECEPTACLE 16. CHOKE LEVER
3. OUTPUT LIGHT 10. SPARK PLUG 17. AIR FILTER COVER
4. OVERLOAD INDICATOR LIGHT 11. CARRY HANDLE 18. OIL FILLER CAP
5. OIL WARNING LIGHT 12. PRIMER BULB 19. FUEL TANK
6. DC PROTECTOR 13. MUFFLER 20. FUEL STRAINER
7. GROUND (EARTH) TERMINAL 14. RECOIL STARTER 21. FUEL TANK CAP
PORTA-0005R1
10
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
ENG. SW.
PORTA-0003R1
PORTA-0003R1
800 Watt Inverter Generator
Oil Warning System
When the oil level reaches a low level, the engine will stop
automatically. In order to restart the engine, the oil must be
relled.
NOTE:
It is important to check the oil level before each use.
Engine Switch
The engine switch must be in the RUN position to start
and run the generator. Push the engine switch to the STOP
position to stop the generator. SEE FIGURE 1
NOTE:
It is recommended to keep the engine switch in the
STOP position while the generator is not in use.
Economy Control Switch
When the economy control switch is in the ON position, the
economy control unit controls the engine speed according to
the connected load. The results are better fuel usage and lower
noise levels. SEE FIGURE 1
NOTE: When starting the generator, and while plugging
in and starting connected devices, make sure the
economy control switch is in the OFF position.
When all units are running smoothly, push the
economy switch to the ON position .
DC Circuit Protector
The DC circuit protector turns o automatically when the load
exceeds the generator’s rated output. SEE FIGURE 1
NOTE: If generator turns o due to access load, reduce
the load to within specic generator rated output
levels.
Fuel Tank Cap Air Vent
The fuel tank cap is provided with an air vent knob to stop fuel
ow. The air vent knob must be turned clockwise to the OPEN
position to run the generator. This will allow for fuel ow in
the engine. When the generator is not in use, turn the air vent
knob counterclockwise to the CLOSED position. This will block
air ow to the fuel tank. SEE FIGURE 2
Fuel Valve
The fuel valve must be in the ON position to run the generator.
When the generator is not in use, turn the fuel valve to the
OFF position. SEE FIGURE 2
ON
ECON.
OFF
RUN
STOP
DC PROTECTOR
ONPUSH
FIGURE 1
CLOSEOPEN
OPEN
ONOFF
CLOSE
FIGURE 2
SPECIFICATIONS
Ac Voltage 60Hz -120V
Max Output 800 watts
Rated Output 700 watts
Dc Output 12V / 4.5A
Engine Displacement 40cc
Engine Type 4-cycle
Noise Level (@7M) 58 dB
Fuel Tank Capacity 0.55 gallons (2.1 liters)
Recommended Fuel Type Minimum 87 octane gasoline
with NO ethanol content
NOTE: If using an ethanol
blended fuel, a fuel
stabilizer, mixed
to manufacturer
specications, is
recommended.
Run Time (25% Load) 8.2 hours
Oil Tank Capacity 11.8 ounces (.35 liter)
Oil Type 10W-30 (SJ, SL or better)
Spark Plug CMR6A (TORCH)
Spark Plug Gap 0.6 - 0.7 mm
Weight Of Unit 20 lb
Unit Size L X W X H
(Inches)
15.6 x 8.2 x 14.0
OFF
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 11
WARNING
DO NOT REFILL TANK WHILE ENGINE IS RUNNING
OR HOT. ALWAYS CLOSE FUEL VALVE BEFORE
REFUELING.
BE CAREFUL NOT TO ALLOW DUST, DIRT, WATER
OR OTHER FOREIGN OBJECTS INTO FUEL.
DO NOT FILL ABOVE THE TOP OF THE FUEL
STRAINER OR IT MAY OVERFLOW WHEN THE FUEL
EXPANDS.
KEEP AWAY FROM OPEN FLAMES.
CAUTION
ENGINE IS SHIPPED FROM FACTORY WITHOUT OIL.
YOU MUST ADD ENGINE OIL BEFORE STARTING
ENGINE. IF ENGINE IS STARTED WITHOUT OIL,
ENGINE MAY BE DAMAGED BEYOND REPAIR AND
WILL NOT BE COVERED BY WARRANTY.
NEVER STORE ENGINE WITH FUEL IN THE TANK
INDOORS. FUEL AND FUEL VAPORS ARE HIGHLY
FLAMMABLE.
AN ADULT ONLY MUST ALWAYS HANDLE AND
FILL THE ENGINE WITH FUEL.
ALWAYS HANDLE FUEL IN A WELL VENTILATED
AREA, OUTDOORS, AWAY FROM FLAMES OR
SPARKS.
DO NOT START ENGINE IF FUEL IS SPILLED. WIPE
OFF EXCESS FUEL AND ALLOW TO DRY. REMOVE
ENGINE FROM AREA TO AVOID SPARKS.
Operator’s Manual
800 Watt Inverter Generator
3. Clean debris from area around the fuel cap.
4. Loosen fuel cap slowly. Prevent the cap from coming in
contact with dirt or debris.
5. Carefully add fuel without spilling.
6. Do not ll fuel tank completely full, allow space for fuel to
expand.
7. Immediately replace fuel cap and tighten. Wipe o spilled
fuel and allow to dry before starting engine.
Check Engine Oil
Make sure the engine oil is at the upper level of the oil ll hole.
Add oil as necessary.
To add/check the engine oil:
1. Be sure the generator is located on a level surface before
checking or relling the oil.
2. Remove the side panel on the engine recoil side of the
generator. Four screws must be removed, one from each
corner of the side panel.
NOTE:
Included in
3. Clean around oil ll area.
4. Unscrew dipstick and wipe clean with cloth.
5. Reinsert dipstick without tightening. SEE FIGURE 3
6. If oil level is below the lower level line, rell with 10W30 (SJ, SL or better) oil to upper level line (capacity 11.8
ounces).
the
box is a Phillips head screwdriver.
IMPORTANT
DO NOT SPRAY WATER ON OR NEAR THE
ELECTRONICS OF THE GENERATOR AS THIS
MAY RESULT IN DAMAGE TO THE ELECTRICAL
COMPONENTS.
PREOPERATION CHECK
NOTE: Pre-Operation checks should be made each time
the generator is used.
Check Fuel
Make sure there is sucient fuel in the tank. If fuel is low,
rell with a minimum 87 octane gasoline with No Ethanol
Content.
• Be sure to use the fuel lter screen on the fuel strainer
neck.
• Fuel tank capacity is 0.55 gallons.
Filling Fuel Tank:
1. Make sure the generator is not running and is completely
cool before relling the fuel tank.
2. Move to a well ventilated area, outdoors, away from
ames and sparks.
NOTE: Change oil if contaminated.
Ground Generator
Make sure to properly ground the generator. The generator
must be on a rm, level surface with at least ve feet of
clearance on all sides.
REMOVE SIDE PANEL
OIL FILL CAP
UPPER LEVEL
LOWER LEVEL
FIGURE 3
PORTA-0002R1
12
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
CAUTION
ENG. SW.
PORTA-0003R1
• IF ENGINE FAILS TO START AFTER FOLLOWING
STARTING PROCEDURES, PLEASE CONTACT
OUR CUSTOMER SERVICE DEPARTMENT AT
8003456007.
• STARTER ROPE CAN CAUSE AN
UNANTICIPATED JERK TOWARDS ENGINE.
PLEASE FOLLOW INSTRUCTIONS TO AVOID
INJURY.
• NEVER LEAVE ENGINE RUNNING WHILE
UNATTENDED. TURN OFF AFTER EVERY USE.
• NEVER CARRY GENERATOR FROM ONE
LOCATION TO ANOTHER WHILE ENGINE IS
RUNNING.
• ALWAYS WEAR A PROTECTIVE HEARING
DEVICE.
• DO NOT START ENGINE IF FUEL IS SPILLED.
WIPE OFF EXCESS FUEL AND ALLOW TO DRY.
• STARTING THE GENERATOR WITH ELECTRICAL
DEVICES CONNECTED COULD DAMAGE THE
GENERATOR AND THE CONNECTED DEVICES.
Operator’s Manual
800 Watt Inverter Generator
NOTE:
If the engine does not start prime again and repeat.
7. Allow the engine to warm up.
8. Move choke lever back to RUN position. SEE FIGURE 6
9. Allow for the engine to run without a load for a few
minutes.
NOTE: For cold weather operation, store the unit in a cool
environment. Transferring the unit from a cold to
a warm place can cause the build up of harmful
condensation.
To Stop The Generator
1. Disconnect any electrical devices.
2. Put the engine switch in the STOP position. SEE FIGURE
5
3. Turn the fuel valve to the OFF position. SEE FIGURE 4
4. Turn the fuel tank cap air vent counterclockwise to the
CLOSED position. SEE FIGURE 4
OPERATION
Starting Generator
Before starting make sure nothing is connected to the
generator and it is in a stable position. The economy control
switch should be in the OFF position until the generator and
the later connected devices are running smoothly.
1. Turn the fuel tank cap air vent to the OPEN position. SEE
FIGURE 4
2. Turn the fuel valve to the ON position. SEE FIGURE 4
3. Push engine switch to the RUN position. SEE FIGURE 5
4. Press the primer bulb six times with the choke in the RUN
position. SEE FIGURE 6
NOTE: Priming the engine should only be necessary for
cold starts and after refueling.
5. Move choke lever to the CHOKE position. SEE FIGURE 6
NOTE: The choke is not necessary if the engine is warm.
WARNING
MAKE SURE THE UNIT IS IN A STABLE POSITION
BEFORE PULLING THE STARTER HANDLE.
ONOFF
FIGURE 4
ECON.
ON
FIGURE 5
PRIMER BULB
OFF
RUN
CLOSEOPEN
OPEN
CLOSE
DC PROTECTOR
STOP
ONPUSH
OFF
RUN CHOKE
PORTA-0003R1
6. Use one hand to securely hold the carrying handle of the
generator. With the other hand pull the starter handle
slowly until resistance is felt (this is the “compression”
point). Return the handle to its original position and then
pull swiftly. Do not fully extend the rope. After starting,
slowly return the starter handle to its original position.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 13
FIGURE 6
PORTA-0006R1
WARNING
DO NOT USE WORN, BARE, FRAYED OR OTHERWISE
DAMAGED ELECTRICAL CORD SETS WITH THE
GENERATOR. DO NOT HANDLE ANY KIND OF
ELECTRICAL DEVICE WHILE STANDING IN WATER,
WHILE BAREFOOT OR WHILE HANDS OR FEET ARE
WET.
CAUTION
• BE SURE THE ELECTRICAL DEVICES ISARE
TURNED OFF BEFORE PLUGGING IN.
• BE SURE THAT THE TOTAL LOAD IS WITHIN
GENERATOR RATED OUTPUT.
• BE SURE THE SOCKET LOAD CURRENT IS
WITHIN THE SOCKET RATED CURRENT.
• THE ECONOMY CONTROL SWITCH MUST BE
TURNED TO THE OFF POSITION WHEN USING
ELECTRIC DEVICES THAT REQUIRE A LARGE
STARTING CURRENT.
• THE AC OUTPUT OF THE GENERATOR
AUTOMATICALLY RESETS WHEN THE ENGINE
IS STOPPED AND THEN RESTARTED.
• THE OVERLOAD INDICATOR LIGHT MAY COME
ON FOR A FEW SECONDS AT FIRST WHEN
USING ELECTRIC DEVICES THAT REQUIRE A
LARGE STARTING CURRENT.
• BE SURE THE ECONOMY CONTROL SWITCH
IS IN THE OFF POSITION WHILE CHARGING
BATTERIES WITH THE DC APPLICATION.
Operator’s Manual
800 Watt Inverter Generator
USING ELECTRICAL POWER
AC Application:
1. Turn o the switch(es) of the electrical device(s) before
connecting to the generator.
2. Insert the plug(s) of the electrical device(s) into the
receptacle.
3. Start electrical device(s). Let run for a few moments
and then push the economy control switch to the ON
position.
Overload Indicator Light:
The overload indicator light comes on when an overload of
a connected electrical device is detected, the inverter unit
overheats or the AC output voltage rises. The electronic
breaker will then activate, stopping power to the generator
in order to protect the generator and any connected electric
devices. The output light (green) will icker and the overload
indicator light (red) will turn on, then the engine will stop
running. If so please follow the following steps:
1. Turn o any connected electric devices.
2. Reduce the total wattage of connected electric devices to
be within the generators range.
3. If total wattage is within range, check for blockages in
the cooling air inlet and around the control unit. If any
blockages are found, remove.
NOTE: The AC output of the generator automatically
resets when the engine is stopped and then
restarted.
4. Restart engine. Make sure to follow starting instructions.
DC Application (Option):
This usage is applicable to 12V battery charging only. Make
sure that the economy control switch is in the o position while
charging the battery.
1. Connect the battery charging cable to DC receptacle on
the generator.
14
NOTE:
A battery charging cable is included in the box.
2. Connect to the battery terminals using the charging
leads. Make sure the red lead is going to the positive (+)
post of the battery and the black lead is going to the
negative (-) post of the battery.
3. Once the connection is conrmed make sure the DC
circuit protector is in the ON position.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
800 Watt Inverter Generator
MAINTENANCE
Generator Maintenance
Please read the maintenance schedule and observe these recommendations to extend the life of your generator.
Good maintenance is essential for safe, economical, and trouble-free operation. It will also help reduce air pollution. To help you
properly care for your generator, the following pages include a maintenance schedule, routine inspection procedures, and simple
maintenance procedures using basic hand tools. Other service tasks that are more dicult, or require special tools, are best
handled by professionals and are normally performed by a technician or other qualied mechanic.
Maintenance, replacement or repair of the emissions control devices and systems may be performed by any non-road
engine repair establishment or individuals. However, items must be serviced by an authorized dealer to obtain “no charge”
emissions control service.
The maintenance schedule applies to normal operating conditions. If you operate your engine under unusual conditions, such as
sustained high-load or high-temperature operation, or use in unusually wet or dusty conditions, consult your servicing dealer for
recommendations applicable to your individual needs and use.
MAINTENANCE SCHEDULE
Maintenance Item Remarks
Spark Plug Type: TORCH CMR6A
(NGK 1223)
Gap: 0.6 - 0.7 mm
Engine Oil Check oil level. X
Air Filter Clean. Replace if necessary. X
Fuel Strainer Clean fuel strainer.
Choke Check choke operation. X
Valve Clearance -
Intake: 0.15mm (0.006”)
Exhaust: 0.20mm (0.008”)
Fuel / Oil Lines Check hoses for crack or damage.
Exhaust System Check for leakage.
Starting System Check recoil starter operation. X
Screws / Fasteners Check that all hardware is secure.
Generator Check the output light comes on. X
Check condition, adjust gap and
clean. Replace if necessary.
Replace. X X
Replace if necessary.
Check and adjust when
engine is cold.
Replace if necessary.
Retighten if necessary.
Check muer screen.
Clean/replace if necessary
Correct if necessary.
Pre-operation
check (daily)
X
X
Initial
month
or 20 hrs
Every 3
months
or 50 hrs
Every 6
months
or 100 hrs
X
X
X
Every 12
months
or 300 hrs
X
X
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 15
CAUTION
ENGINE MUST BE TURNED OFF AND COOL
BEFORE CHECKING AND ADJUSTING ENGINE OR
EQUIPMENT.
TEMPERATURE OF MUFFLER AND NEARBY AREAS
MAY EXCEED 150° F 65° C. AVOID THESE AREAS.
NEVER STORE ENGINE WITH FUEL IN THE TANK
INSIDE A BUILDING. POTENTIAL SPARKS MAY
BE PRESENT FOR IGNITION OF FUEL AND FUEL
VAPORS.
AN ADULT ONLY MUST DO MAINTENANCE AND
REPAIR ON GENERATOR.
ENGINE MUST BE TURNED OFF AND COOL BEFORE
ANY REPAIR OR MAINTENANCE CAN BE DONE.
DO NOT OVER FILL THE ENGINE CRANKCASE WITH
OIL. HIGH OIL PRESSURE MAY RESULT, CAUSING
PREMATURE ENGINE WEAR AND DAMAGE.
CAUTION
BE SURE NO FOREIGN MATERIAL ENTERS THE
CRANKCASE WHEN ADDING OR CHANGING OIL.
DO NOT TILT GENERATOR WHEN ADDING OIL. THIS
COULD RESULT IN OVERFILLING AND DAMAGE.
THE ENGINE SHOULD NEVER RUN WITHOUT THE
AIR FILTER; EXCESSIVE PISTON AND/OR CYLINDER
WEAR MAY RESULT.
CAUTION
TO AVOID INJURY OR DEATH, NEVER SIPHON
FUEL BY MOUTH.
NEVER STORE GENERATOR WITH FUEL IN THE
FUEL TANK INSIDE AN ENCLOSED AREA OR
BUILDING.
Operator’s Manual
800 Watt Inverter Generator
Steps For Working On Equipment
1. Push the engine switch to the STOP position.
2. Replace or repair the part on the IG800W.
3. Check all parts that were repaired, or removed during
repair, that they are secure and t correctly.
NOTE: Only use approved Earthquake spare parts. Never
replace parts that are not specically designed for
the generator.
Oil Maintenance
After the rst twenty hours of operating a new Viper engine
the oil should be replaced, and every 100 hours of operating
time thereafter. The oil should be changed every 50 hours if
used under severe conditions, such as in high temperatures or
under heavy loads. Check oil periodically; do not overll!
Engine oil Replacement
1. Place the machine on a level surface and warm up the
engine for several minutes. Then stop the engine and
turn the fuel valve to the OFF position and the fuel tank
cap air vent to the CLOSED position.
2. Remove the side panel on the starter handle side of the
generator by loosening the four screws holding it in
place.
3. Remove the oil ll cap.
4. Place an oil pan under the engine. Tilt the generator to
drain the oil completely. Once oil has been removed
return the generator to the level surface.
5. Add engine oil, 10W-30 (API Service SJ, SL or better). Fill
to the upper level. For extreme high and low temperature
conditions refer to SAE chart. SEE FIGURE 7
6. Install the oil ll cap back in place.
7. Reconnect the side panel to the generator and tighten
the four screws.
SAE
10W-40
10W-30
5W-30
IMPORTANT
NEVER TWIST AIR FILTERS WHEN CLEANING. ALWAYS
PRESS.
16
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
-20 0 20 40 60 80 100 °F
-30 -20 -10 0 10 20 30 40 °C
Environment Temperature
FIGURE 7
Air Filter
Maintaining an air lter cleaner in proper condition is very
important. Dirt induced through improperly installed,
improperly serviced, or inadequate lters damages and wears
out engines. Keep the lter clean.
Cleaning / Replacing Air Filter:
1. Remove the side panel on the starter handle side of the
generator by loosening the four screws holding it in
place. SEE FIGURE 8
2. Remove the air lter cover by loosening the one screw
holding it in place and then remove the air lter.
3. Replace with a new oiled lter, or wash the current
lter with warm water and mild soap. Remember to
thoroughly oil the foam lter with 30 or 40 weight motor
oil and squeeze out any excess oil before reinstalling it.
NOTE: Make sure to press the lter evenly into place to
ensure that the foam is fully seated into its sealed
position.
4. Reconnect the air lter cover and secure it with the screw.
5. Reconnect the side panel, securing with the four screws.
Operator’s Manual
800 Watt Inverter Generator
WARNING
ALWAYS BE SURE THE TANK CAP IS TIGHTENED
SECURELY TO PREVENT FUEL SPILLS.
THE ENGINE AND MUFFLER WILL BE VERY HOT
AFTER THE ENGINE HAS BEEN RUNNING. ALLOW
ENGINE TO COOL BEFORE CLEANING/REPLACING
PARTS.
AVOID TOUCHING THE ENGINE OR MUFFLER
WHILE THEY ARE STILL HOT WITH ANY PART OF
YOUR BODY OR CLOTHING DURING INSPECTION
OR REPAIR.
AIR FILTER COVER
SIDE PANEL
AIR FILTER
Fuel Tank Strainer
Cleaning / Replacing:
1. Remove the fuel tank cap and strainer. SEE FIGURE 9
2. Clean the strainer with solvent. If damaged, replace.
3. Wipe the strainer and reinsert it.
NOTE: Make sure the tank cap is tightened securely.
Spark Arrester
Cleaning / Replacing:
1. Remove the muer shroud. SEE FIGURE 10
2. Remove muer clamp using a athead screwdriver to
remove the spark arrester.
4. Remove the carbon deposits on the spark arrester using a
wire brush. If damaged, replace.
5. Reinstall the spark arrester.
6. Reinstall the muer shroud.
Spark Plug
The recommended spark plug is a Torch CMR6A (NGK 1223).
For maintenance and care of the spark plug go online to
www.getearthquake.com for instructions or call Earthquake
customer service.
Carburetor
Never tamper with factory setting of the carburetor.
PORTA-0007R1
FIGURE 8
FUEL TANK CAP
FUEL TANK STRAINER
PORTA-0008R1
FIGURE 9
MUFFLER
CLAMP
SPARK
ARRESTER
MUFFLER
SHROUD
PORTA-0009R1
FIGURE 10
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 17
Operator’s Manual
800 Watt Inverter Generator
TRANSPORT & STORAGE
WARNING
DO NOT TRANSPORT GENERATOR INSIDE AN
ENCLOSED SPACE OR WITHIN A VEHICLE. FUEL
OR FUEL VAPORS MAY IGNITE CAUSING SERIOUS
INJURY OR DEATH.
Transporting Your Generator
1. After using the generator, and before transporting it,
make sure:
• the fuel cap is screwed on tightly (clockwise),
• the fuel cap vent is closed,
• the fuel valve is o.
2. If fuel is present in the fuel tank, transport in an open
vehicle in an upright position.
3. If an enclosed vehicle must be used, allow generator to
cool completely and then remove fuel into an approved
red fuel container. DO NOT siphon by mouth.
4. Wipe away any spilled fuel and allow to dry.
5. Run engine to use up the fuel in the carburetor and fuel
tank. Always run engine in a well ventilated area.
6. Fuel cap should be screwed down tightly, fuel cap
vent closed and fuel valve o before transporting your
generator in a vehicle.
Long-Term Storage
It is important to prevent gum deposits from forming in
essential fuel system parts such as the carburetor, fuel hose
or tank during long-term storage. It is recommended to use
a minimum 87 octane gasoline with No Ethanol Content
due to indication that blended fuels can attract moisture and
damage the an engine during storage. If your generator will
not be used for more than one month, prepare it for long-term
storage.
Steps for Long-Term Storage
1. Allow generator to cool completely and then remove
all of the fuel from the fuel tank into an approved fuel
container. Discard appropriately.
2. Start and run engine to use up the fuel in the carburetor
and fuel tank. Be sure to close the fuel valve once
complete.
3. After the engine cools down, drain oil from crankcase.
Rell with recommended grade.
4. Remove spark plug. Pour about 1/2 ounce (15 ml) of
engine oil into the cylinder (the spark plug location).
Cover spark plug hole with rag. Pull the starting rope
several times to coat the cylinder wall with engine oil.
5. Install and tighten the spark plug.
6. Clean the generator outer surfaces. Check that cooling
air slots and openings on generator are open and
unobstructed.
7. Store the unit in a clean, dry place.
NOTE: Do not store gasoline from one season to another.
If possible, store the unit indoors and cover it to
give protection from dust and dirt.
TROUBLESHOOTING & REPAIR
At Earthquake , we build quality and durability into the design
of our products; but no amount of careful design by us, and
careful maintenance by you, can guarantee a repair-free life
for your Earthquake Inverter Generator. Most repairs will be
minor, and easily xed by following the suggestions in the
troubleshooting guide in this section.
The guide will help you pinpoint the causes of common
problems and identify remedies.
For more complicated repairs, you may want to rely on your
retailer, an authorized service center or Earthquake customer
service. Earthquake will make the necessary repairs if a service
center is not available. A parts breakdown is located toward
the end of this manual.
We will always be glad to answer any questions you have, or
help you nd suitable assistance. To order parts or inquire
about warranty, call or e-mail us using the contact information
found in this section.
Ordering Replacement Parts
To order replacement parts visit www.GetEarthquake.com or
call Earthquake customer service at 1-800-345-6007.
For other general questions, you can e-mail us at info@
ardisam.com.
Please include the following information with your order:
1) Part numbers
2) Part description
3) Quantity
4) Model number and serial number
Spare Parts
Only use approved Earthquake spare parts.
18
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
800 Watt Inverter Generator
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE REMEDY/ACTION
Engine will not start 1. Engine switch in STOP position 1. Push engine switch to RUN position
2. Out of fuel 2. Refuel
3. Fuel valve in OFF position 3. Turn fuel valve to ON position
4. Spark plug wire disconnected 4. Connect spark plug wire to spark plug
5. Spark plug wet, faulty or improperly gapped 5. Clean, replace or gap spark plug
6. Economy switch in ON position 6. Push economy switch to the OFF position; Once
generator is running push to the ON position
7. Fuel tank cap air vent in CLOSED position 7. Turn to OPEN position
Operator’s Manual
Engine starts, then
runs rough
Engine is hard to start 1. Stale fuel 1. Drain old fuel and replace with fresh. Use fuel
Engine misses or lacks
power
Engine runs, then
quits
1. Dirty air lter 1. Clean or replace air lter
2. Choke partially engaged 2. Turn o choke
3. Defective or dirty spark plug 3. Clean or replace spark plug
4. Economy switch is defective 4. Replace economy switch
5. Carburetor out of adjustment 5. Call Earthquake Customer Service
stabilizer at end of season
2. Spark plug wire loose 2. Make sure spark wire is securely attached to
spark plug
3. Dirty carburetor 3. Clean carburetor, use fuel stabilizer, new fuel can
1. Clogged fuel tank 1. Remove and clean fuel tank
2. Clogged air lter 2. Clean or replace air lter
3. Carburetor out of adjustment or bad 3. Call Earthquake Customer Service
4. Spark plug wet, faulty or improperly gapped 4. Clean, replace or gap spark plug
1. Fuel tank cap air vent in CLOSED position 1. Turn to OPEN position
2. Low fuel level 2. Add fuel to tank
3. Incorrect engine oil level 3. Check engine oil level, add or drain as needed
4. Contaminated fuel 4. Remove and replace contaminated fuel; Clean or
replace fuel strainer
5. Defective low oil level switch 5. Replace low oil level switch
6. Defective ignition coil 6. Replace ignition coil
Engine revs too high 1. Carburetor out of adjustment 1. Call Earthquake Customer Service
Engine speed increases and decreases, this is normal as the generator starts up and as loads vary.
Contact Earthquake customer service at 800-345-6007 if additional assistance is needed.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 19
ELECTRICAL WIRE DIAGRAM
Operator’s Manual
800 Watt Inverter Generator
20
PORTA-0010R1
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
ILLUSTRATED PARTS BREAKDOWN
7
6
Operator’s Manual
800 Watt Inverter Generator
10
9
4,5
3
1
2
KEY PART # DESCRIPTION Q TY.
1 16116 KIT, CIRCUIT BREAKER 4.5 AMP 1
2 16118 KIT, US OUTLET/SOCKET 110VAC 1
3 16117 KIT, I-O SWITCH WITH COVER 2
4 16113 KIT, PANEL S PLUG PANEL SIDE W/
1
SCREWS
5 16072 SCREW M4.8 X 13 PPHB GR8.8 BLK
4
OX T/F
8
4
PORTA-0011R1
KEY PART # DESCRIPTION QTY.
6 15993 FUEL FILL STRAINER 1
7 15992 CAP, FUEL MANUAL VENT 1
8 16110 KIT, SPARK PLUG ACCESS PANEL 1
9 16107 KIT, 40CC 4-CYCLE COIL W/ SPARK
1
PLUG
10 13243 SPARK PLUG TORCH CMR6A (NGK
1
1223)
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 21
Operator’s Manual
800 Watt Inverter Generator
ILLUSTRATED PARTS BREAKDOWN
VIEW A
8
PORTA-0012R1
13
12
11
6,7
4
4,5
5
10
9
3,4
4
4,5
3,4
3
3,16
6
3,15
3
3,14
2
22
7
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
20
1,2
ILLUSTRATED PARTS BREAKDOWN
VIEW A
Operator’s Manual
800 Watt Inverter Generator
17
18
19
PORTA-0016R1
KEY PART # DESCRIPTION QTY.
1 16072 SCREW (M4.8 X 13 PPHB GR8.8 BLK OX T/F) 4
2 16111 KIT, RECOIL PANEL SIDE W/ SCREWS 1
3 16086 KIT, AIR FILTER ASSEMBLY WITH CHOKE 1
4 16087 KIT, CARBURETOR REPLACEMENT 1
5 16115 KIT, THROTTLE CONTROL 1
6 16108 KIT, FUEL SYSTEM 1
7 16109 KIT, REMOTE PRIMER BULB W/ 2.5MM LINES 1
8 13393 KIT, OIL CAP WITH O-RING 1
9 16024 RECOIL ROPE GUARD 1
10 6272 BOLT (M6 X 1.0 X 12 HHFCS GR8.8 ZN) 1
11 16146 WASHER M6 X 13 X 2 FLAT ALUM 1
12 16101 KIT, RECOIL ASSEMBLY 1
13 16114 KIT, RUBBER FEET W/ SCREWS X4 1
14 16070 SCREW M5-0.8 X 12 PTHMS ZN 2MM SHLDR 1
15 15963 AIR FILTER, (XY139F-6) 1
16 15964 KIT, AIR BOX ASSEMBLY WITH CHOKE 1
17 20351 KIT, MUFFLER SHROUD IG800W 1
18 16166 MUFFLER 40CC 4-CYCLE 1
19 16176 GASKET, MUFFLER IG800W 1
20 20368 KIT, FUEL PETCOCK IG800W
NOT SHOWN PARTS
15258 KIT, LOW OIL SENSOR 1
16106 RETAINING PIN 7/16 SHAFT X 1/2 X 0.05 DI 1
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 23
NOTES
Operator’s Manual
800 Watt Inverter Generator
24
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
800 Watt Inverter Generator
IG800W Inverter Generator
Warranty Terms and Conditions
PRODUCT WARRANTY: 1YEAR LIMITED WARRANTY
Ardisam, Inc., a manufacturing company, warrants this IG800W Earthquake Inverter Generator to be free from defects
in the material or workmanship for a period of one year from the date of purchase. During the one-year warranty of
this product, Ardisam will furnish, at their discretion, parts and labor to correct any defect caused by faulty material or
workmanship. Any unit used in a commercial application is covered for a period of 90 days after purchase. This warranty
applies to the original owner with a proof of purchase and is not transferable. For the warranty to be valid, the product
must be registered online, or the warranty card must be lled out and received by Ardisam, Inc., within 30 days of
purchase.
ENGINE WARRANTY: 2YEAR LIMITED EMISSIONS CONTROL WARRANTY
SEE FEDERAL EMISSION CONTROL WARRANTY STATEMENT FOR DETAILS
Ardisam, Inc., a manufacturing company warrants its Viper® Engines under a two-year limited emissions control warranty
to be free from defects in materials and workmanship for the service life of the product not to exceed twenty-four
consecutive months from the date of purchase for consumer applications.
*These warranties apply only to products which have not been subjected to negligent use, abuse, misuse (including
the use of this pump in place of your well or water utility), overload, improper installation, alteration, accident, acts of
God (or other events beyond Ardisam’s control), unauthorized parts, failure to use proper fuel and oil, or if repairs have
been performed at a non-authorized service facility. These warranties shall not cover damage from normal wear and
tear, normal maintenance parts and services, lightning; nor improper installation, operation, storage, or maintenance;
nor operating the equipment above recommended maximums as stated in this manual and the accompanying engine
manual. These warranties supersede all other warranties either expressed or implied and all other obligations or liabilities
on the part of Ardisam. Ardisam, does not assume, and does not authorize any other person to assume for Ardisam, any
liability in connection with the sale of Ardisam products. To be at “No Charge,” warranty work must be sent directly to and
performed by Ardisam or an Ardisam Authorized Warranty Service Facility. To obtain warranty service and/or replacement
instructions, contact the Ardisam Customer Service Department at 800-345-6007. Ardisam will cover the cost of shipping
only for purchasers located more than 100 miles from an Ardisam Authorized Warranty Service Facility if it is determined
that warranted repair is indeed necessary. If you choose to ship your product to Ardisam for warranty repair, you must
rst have prior approval from Ardisam by calling the Ardisam Customer Service Department for a return material
authorization number (RMA#). Under these circumstances, all items must be shipped prepaid. Ardisam will at no charge,
repair or replace, at the discretion of Ardisam, any defective part which falls under the conditions stated above. Ardisam
retains the right to change models, specications and price without notice. Ardisam shall not be obligated to ship any
repair or replacement product to any location outside of the United States of America or Canada. Some states and
countries do not allow the limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental
or consequential damages, so the above limitation may not apply to you. This warranty gives you specic legal rights, and
you may also have other rights which vary from state to state and country to country.
Earthquake
A Division of Ardisam, Inc.
1160 Eighth Avenue; P.O. Box 666
Cumberland, Wisconsin 54829
800-345-6007 · Fax (715) 822-4180
E-mail: info@GetEarthquake.com
TM
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 25
Operator’s Manual
800 Watt Inverter Generator
COMBINED EXHAUST AND EVAPORATIVE
EMISSIONS CONTROL WARRANTY STATEMENT
Your Warranty Rights And Obligations
The California Air Resources Board, the United States
Environmental Protection Agency and Ardisam, Inc. (Ardisam),
are pleased to explain the emission control system warranty
on your 2014 model year small o-road engine/equipment. In
the United States and California, new small o-road engine/
equipment must be designed, built and equipped to meet the
State’s stringent anti smog standards. Ardisam must warrant
the emission control system on your small o-road engine/
equipment for the periods of time listed below provided there
has been no abuse, neglect or improper maintenance of your
small o-road engine/equipment.
Your emission control system may include parts such as
the carburetor or fuel injection system, the ignition system,
catalytic converter, fuel tanks, fuel lines, fuel caps, valves,
canisters, lters, vapor, hoses, clamps, connectors, and other
associated components. For engines less than or equal to 80
cc, only the fuel tank is subject to the evaporative emission
control warranty requirements of this section. (California only)
Where a warrantable condition exists, Ardisam will repair your
small o-road engine/equipment at no cost to you including
diagnosis, parts and labor.
Manufacturer’s Warranty Coverage:
This emissions control system is warranted for two years. If any
emission-related part on your equipment is defective, the part
will be repaired or replaced by Ardisam.
Owner’s Warranty Responsibilities:
As the small o-road engine/equipment owner, you are
responsible for the performance of the required maintenance
listed in your owner’s manual. Ardisam recommends that you
retain all receipts covering maintenance on your small o-road
engine/equipment, but Ardisam cannot deny warranty for the
lack of receipts or for your failure to ensure the performance of
all scheduled maintenance.
As the small o-road engine/equipment owner, you should
however be aware that Ardisam may deny you warranty
coverage if your small o-road engine/equipment or a part
has failed due to abuse, neglect, improper maintenance or
unapproved modications.
You are responsible for presenting your small o-road engine/
equipment to a Ardisam distribution center as soon as a
problem exists. The warranty repairs should be completed in a
reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and
responsibilities, you should contact Ardisam at 1-800-345-6007
or E-mail: info@ardisam.com.
Defects Warranty Requirements:
(A) The warranty period begins on the date the engine/
equipment is delivered to an ultimate purchaser.
(B) General Emissions Warranty Coverage. Ardisam warrants to
the ultimate purchaser and each subsequent owner that
the engine/equipment is:
(1) Designed, built, and equipped so as to conform with all
applicable regulations adopted by the Air Resources
Board; and
(2) Free from defects in materials and workmanship that
causes the failure of a warranted part for a period of two
years.
(C) The warranty on emissions-related parts will be interpreted
as follows:
(1) Any warranted part that is not scheduled for replacement
as required maintenance in the written instructions
required by subsection (D) must be warranted for the
warranty period dened in subsection (B)(2). If any such
part fails during the period of warranty coverage, it
must be repaired or replaced by Ardisam according to
subsection (4) below. Any such part repaired or replaced
under the warranty must be warranted for the remaining
warranty period.
(2) Any warranted part that is scheduled only for regular
inspection in the written instructions required by
subsection (D) must be warranted for the warranty
period dened in subsection (B)(2). A statement in such
written instructions to the eect of “repair or replace
as necessary” will not reduce the period of warranty
coverage. Any such part repaired or replaced under
warranty must be warranted for the remaining warranty
period.
(3) Any warranted part that is scheduled for replacement as
required maintenance in the written instructions required
by subsection (D) must be warranted for the period of
time prior to the rst scheduled replacement point for
that part. If the part fails prior to the rst scheduled
replacement, the part must be repaired or replaced
by Ardisam according to subsection (4) below. Any
such part repaired or replaced under warranty must be
warranted for the remainder of the period prior to the
rst scheduled replacement point for the part.
26
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Operator’s Manual
800 Watt Inverter Generator
(4) Repair or replacement of any warranted part under the
warranty must be performed at no charge to the owner
at a warranty station.
(5) Notwithstanding the provisions of subsection (4) above,
warranty services or repairs must be provided at all
Ardisam distribution centers that are franchised to service
the subject engine/equipment.
(6) The owner must not be charged for diagnostic labor
that leads to the determination that a warranted part is
in fact defective, provided that such diagnostic work is
performed at a warranty station.
(7) Ardisam is liable for damages to other engine/equipment
components proximately caused by a failure under
warranty of any warranted part.
(8) Throughout the emissions warranty period dened in
subsection (B)(2), Ardisam must maintain a supply of
warranted parts sucient to meet the expected demand
for such parts.
(9) Any replacement part may be used in the performance
of any warranty maintenance or repairs and must be
provided without charge to the owner. Such use will not
reduce the warranty obligations of Ardisam.
(10) Add-on or modied parts that are not exempted by the
Air Resources Board may not be used. The use of any nonexempted add-on or modied parts will be grounds for
disallowing a warranty claim. Ardisam will not be liable to
warrant failures of warranted parts caused by the use of a
non-exempted add-on or modied part.
(11) Ardisam issuing the warranty shall provide any
documents that describe that manufacturer’s warranty
procedures or policies within ve working days of request
by the Air Resources Board.
(D) Emission Warranty Parts List.
(1) Fuel Metering System
(i) Carburetor and internal parts (and/or pressure
regulator or fuel injection system).
(ii) Air/fuel ratio feedback and control system.
(iii) Cold start enrichment system.
(iv) Fuel Tank.
(2) Air Induction System
(i) Controlled hot air intake system.
(ii) Intake manifold.
(iii) Air lter.
(3) Ignition System
(i) Spark Plugs.
(ii) Magneto or electronic ignition system.
(iii) Spark advance/retard system.
(4) Exhaust Gas Recirculation (EGR) System
(i) EGR valve body, and carburetor spacer if applicable.
(ii) EGR rate feedback and control system.
(5) Air Injection System
(i) Air pump or pulse valve.
(ii) Valves aecting distribution of ow.
(iii) Distribution manifold.
(6) Catalyst or Thermal Reactor System
(i) Catalytic converter.
(ii) Thermal reactor.
(iii) Exhaust manifold.
(7) Particulate Controls
(i) Traps, lters, precipitators, and any other device used
to capture particulate emissions.
(8) Miscellaneous Items Used in Above Systems
(i) Electronic controls.
(ii) Vacuum, temperature, and time sensitive valves and
switches.
(iii) Hoses, belts, connectors, and assemblies.
Ardisam will furnish with each new engine/equipment written
instructions for the maintenance and use of the engine/
equipment by the owner.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5 27
Earthquake™, Division of Ardisam, Inc.
1160 8th Avenue, PO Box 666
Cumberland, WI 54829
800-345-6007 | Fax 715-822-2223
E-mail: info@Ardisam.com
All weights, specications and features are approximate and are subject to change without notice. Due to continuous product
improvements, product images may not be exact. Items used for props not included. Some assembly may be required.
Check for parts online at www.getearthquake.com or call 800-345-6007 M-F 8-5
Loading...
