OPERATING MANUAL
clik
2
1
3
clik
ASSEMBLY
WASH FILTER
Wash your filter with cold water
regularly or as required.
REGISTER
YOUR 2 YEAR
GUARANTEE
TODAY
FULLY
CHARGED
Your Dyson handheld vacuum will be covered for parts
and labour for 2 years from the date of purchase, subject
to the terms of the guarantee.
If you have a query about your Dyson handheld vacuum,
call the Dyson Customer Care Helpline quoting the serial
number and details of where/when you bought the Dyson
handheld vacuum. The serial number can be found on
the rating plate which is behind the filter.
Most queries can be solved over the phone by one of our
trained Dyson Customer Care Helpline staff.
Visit our website to register your full parts and labour
guarantee online (Australia only).
ww w.dyson.com.au/register
Note your serial number for future reference
This illustration is for example purposes only.
IMPORTANT SAFETY PRECAUTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
Use only as described in this Dyson Operating Manual. Use only Dyson recommended attachments.1.
Do not use outdoors, on wet surfaces or near a naked flame.2.
Do not use to pick up flammable or combustible liquids, such as petrol or use in areas where they may be present.3.
Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.4.
Do not use without the clear bin and the filter in place.5.
Children should be supervised to ensure they do not play with the Dyson handheld vacuum.6.
Do not use with damaged cable or plug. If the Dyson handheld vacuum is not working as it should, has been 7.
dropped, damaged, left outdoors or dropped into water, contact the Dyson Customer Care Helpline.
This Dyson handheld vacuum is not intended for use by persons (including children) with reduced physical, sensory 8.
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning the use of the Dyson handheld vacuum by a person responsible for their safety.
Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair and 9.
anything that may reduce air flow.
Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.10.
Use extra care when cleaning on stairs.11.
Use only the charger supplied with the product to recharge.12.
Do not charge the unit outdoors, in a bathroom or where it may be wet.13.
Do not handle charger, including the charger plug and the charger terminals with wet hands.14.
Do not unplug the charger by pulling on the cable. To unplug, grasp the plug, not the cable.15.
Do not incinerate the Dyson handheld vacuum even if it is severely damaged. The batteries may explode in a fire.16.
Do not use with an extension cable.17.
Unplug the charger from the supply before maintenance.18.
3 EASY WAYS TO REGISTER YOUR 2 YEAR GUARANTEE
REGISTER
ONLINE
Visit our website to register your
REGISTER
BY PHONE
Call our dedicated Helpline.
full parts and labour guarantee
online (Australia only).
AU 1800 239 766
NZ 0800 397 667
SG 7000 435 7546
www.dyson.com.au/register
ID 021 707 39766
REGISTER
BY MAIL
Complete and return
the form to Dyson in the
envelope supplied.
SAVE THESE INSTRUCTIONS
THIS HANDHELD VACUUM IS INTENDED FOR DOMESTIC HOUSEHOLD AND CAR USE ONLY.
Do not use near
naked fl ame.
Do not st ore near
heat so urce.
Do not pic k up water
or liquid s.
Do not pic k up
burning object s.
2
3
Looking for blockages
Power
Charging
Do not use under 3˚C
See page 8
clik
Tools
2
Emptying the clear bin
1
3
clik
Charging
Fully charged
Not charging,
battery
Not charging,
low temp
IMPORTANT!
WASH FILTER
clik
Wash your filter with cold water
1
4
2
1
2
regularly or as required.
5
12
IMPORTANT!
WASH FILTER
Wash your filter with cold water regularly or as required.
6
7
USING THE DYSON HANDHELD VACUUM
CAUTION:
Dirt and debris may be released from the Dyson handheld vacuum if it is turned •
upside down. Ensure the Dyson handheld vacuum remains upright in use and
storage.
Do not operate the D yson handheld vacuum while checking for blockages.•
PLEASE NOTE:
Do not carry out any maintenance or repair work other than that shown in this •
Dyson Operating Manual or advised by the Dyson Customer Care Helpline.
This Dyson handheld vacuum is designed for domestic indoor and car use only. •
Do not use it while the car is in motion or while driving.
Do not press down on the nozzle with exces sive force when using the Dyson •
handheld vacuum as this may cause damage.
If the motor overheats, the D yson handheld vacuum will cut out automatically.•
Leave it to cool for at least an hour and check for blockages before restarting.
Fine dir t such as flour or plaster dust should only be vacuumed in very small •
amounts.
Consult your flooring manufacturer’s recommended instructions before •
vacuuming and caring for your flooring, rugs and carp et.
TROUBLESHOOTING – DYSON HANDHELD VACUUM
Charged.
Less than one minute of charge remaining/fully discharged.
Less than 3°C – do not use.
Filter missing/f ilter fitted incorrectly.
EMPTYING THE CLEAR BIN
CAUTION:
Switch off the Dyson handheld vacuum and disconnect from charger before •
emptying the clear bin.
Empty as soon as the dirt reaches the level of the • MAX mark – do not overfill.
To release the dirt, push the but ton at the side of the cle ar bin as shown.•
PLEASE NOTE:
Do not use the Dyson handheld vacuum without the clear bin in place.•
CLEANING THE CLEAR BIN
CAUTION:
Ensure the clear bin is completely dry before replacing.•
PLEASE NOTE:
To remove the clear bin, push the release button on the underside of the Dyson •
handheld vacuum as shown.
Use only cold water to clean the clear bin. Do not use detergents, polishes or •
air fresheners.
Do not put the clear bin in a dishwasher.•
WASHING THE FILTER
CAUTION:
Switch ‘OFF’ and disconnec t from charger before removing the filter.•
Ensure filter is completely dry before refit ting to the Dyson handheld vacuum.•
PLEASE NOTE:
This Dyson handheld vacuum has one filter, located as shown. It is important to •
check your filter and wash with cold water regularly or as required, to maintain
performance. Please leave to dr y completely for 12 hours.
The filter may require more frequent washing if vacuuming fine dust.•
Do not use detergents to clean the filter.•
Do not put the filter in the dishwasher, washing machine, tumble dryer, oven, •
microwave or near an op en flame.
LOOKING FOR BLOCKAGES
CAUTION:
Switch off the Dyson handheld vacuum and disconnect from charger before •
looking for blockages.
Beware of sharp objects when clearing blockages.•
Refit all parts of the Dyson handheld vacuum securely before using.•
PLEASE NOTE:
Clearing blockages is not covered by the Dyson handheld vacuum’s guarantee. •
If any par t of the Dyson handheld vacuum become s blocked, it may overheat
and then automatically shut off.
Unplug the Dyson handheld vacuum and le ave to cool down. Clear blockage •
before restar ting.
CHARGING AND STORING THE DYSON
HANDHELD VACUUM
The Dyson handheld vacuum will turn of f if the battery temperature is below
3°C. This is designed to protect the motor and batter y of your product. Do
not charge the Dyson handheld vacuum and then move it to an area with a
temperature below 3˚C for storage purposes.
TROUBLESHOOTING – CHARGER
Charging.
Fully charged.
Not charging – bat tery.
Not charging – low temp.
BATTERY SAFETY INSTRUCTIONS
Use only D yson batteries and charging unit for the Dyson handheld vacuum.
The bat tery is a sealed unit and under normal circumstances poses no safety
concerns. In the unlikely event that liquid leaks from the bat tery do not touch
the liquid and obser ve the following precautions:
Skin contact – can cause irritation. Wash with soap and water.
Inhalation – can cause respiratory irritation. Expose to fresh air and seek
medical advice.
Eye contact – can cause irritation. Immediately flush eyes thoroughly with
water for at least 15 minutes. Seek medical attention.
Disposal – wear gloves to handle the battery and dispose of immediately
following local ordinances or regulations.
CAUTION:
The bat tery used in this device may present a risk of fire or chemical burn if
mistre ated. Do not disassemble, short contacts, heat above 140° F (60° C), or
incinerate. Replace battery with a Dyson battery only, use of any other ba tter y
may present a risk of fire or explosion. Dispose of used battery promptly. Keep
away from children. D o not disassemble and do not dispose of in fire.
The bat tery must be removed from the Dyson handheld vacuum before it is •
scrapped.
The bat tery is to be disposed of saf ely.•
The Dyson handheld vacuum must be disconnected from the supply mains when •
removing the bat tery.
The symbol
should not be treated as household was te. Instead it should be handed over
to the applicable collection point for the recycling of electrical and electronic
equipment – this may be your local civic amenity site product. By ensuring
this product is disposed of correctly, you will help prevent potential neg ative
consequences for the environment and for human health, which could otherwise
be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, ple ase contact the Dyson Customer
Care Helpline, your lo cal authority civic amenit y site pro duct.
on the product or on its packaging indicates that this produc t
2 YEAR GUARANTEE - TERMS AND CONDITIONS
To help us ensure you receive prompt and efficient ser vice, please register as a
Dyson owner. There are three ways to do this:
Online (Australia only) at customercare@dyson.com.au•
By calling the Dyson Customer Care Helpline.•
By completing and returning the enclosed form to us by mail.•
This will confirm ownership of your Dyson handheld vacuum in the event of an
insurance loss and e nable us to contact you if necessary.
DYSON CUSTOMER CARE
If you have a query about your D yson handheld vacuum call the D yson
Customer Care Helpline and quote your serial number or contact us via the
Dyson website. The serial number can be found on the main bod y of the
handheld vacuum behind the filter.
Most queries can be solved over the phone by one of our Dyson Customer Care
Helpline staf f.
If your Dyson handheld vacuum needs a service, call the Dyson Customer Care
Helpline so we can discuss the available options.
DYSON CUSTOMER CARE DETAILS
Any queries – just call the Dyson Customer Care Helpline
AU: 1800 239 766 (Mon-Fri 8:0 0am to 6:0 0pm EST,
Sat-Sun 8:30am to 4.00pm EST) w ww.dyson.com.au
NZ: 0800 397 667 (Mon-Fri 8:30am to 5:00pm) www.dy son.co.nz
ID: 021 707 39766 www.dyson.com
SG: 700 0 435 7546 ww w.dyson.com.sg
SUMMARY OF COVER
Terms and conditions of the Dyson 2 year guarantee.
The guarantee be comes ef fective from the date of purchase.•
All work w ill be carried out by Dyson Appliances ( Aust) P ty Ltd, Avery Robinson •
Ltd (New Zealand).
Any par ts replaced will become the proper ty of Dy son Appliances (Aust) Pty Ltd.•
The repair or replacement of your Dyson handheld vacuum under guarantee will •
not extend the period of guarantee.
The guarantee provides benefits which are additional to and do not af fect your •
statutory rights as a consumer.
You must provide proof of purchase before any work can be carried out on •
your Dyson handheld vacuum. Without this proof, any work carried out will be
chargeable. Please keep your receipt.
WHAT IS COVERED
The repair or replacement of your Dyson handheld vacuum if your vacuum •
cleaner is found to b e defec tive due to faulty materials, workmanship or
function within 2 years of purchase (if any part is no longer available or out of
manufacture, Dyson will replace it with a functional replacement part).
WHAT IS NOT COVERED
Dyson shall not be liable for costs of rep air or replacement of a product incurred
as a result of:
Normal wear and tear.•
Industrial use of the Dyson handheld vacuum such as vacuuming gyprock dust •
or builders dust may void your guarantee.
Accidental damage, faults caused by negligent use or care, neglect, careless •
operation or handling of the Dyson handheld vacuum which is not in
accordance with this Dyson Operating Manual.
Blockages – please refer to the Dyson Operating Manual for details on how to •
unblock your Dyson handheld vacuum.
Use of the Dyson handheld vacuum for any thing other than normal domestic •
purposes.
Use of parts not assemble d or installed in accordance with the instructions •
of Dyson.
Use of parts and accessories other than those produced or recomm ended •
by Dyson.
External sources such as transit damage or weather.•
Repairs or alterations carried out by parties other than Dyson or its authorised •
agents.
If you are in any doubt as to what is covered by your guarantee, please call the •
Dyson Customer Care Helpline on:
Australia 1800 239 766
New Zealand 080 0 397 667
Indonesia 021 707 39766
Singapore 7000 435 7546
ABOUT YOUR PRIVACY
Dyson may use this information for future marketing and research purposes
(including sending commercial electronic messages) and may disclose it to third
parties for the purposes of providing the ser vices you have requested or to our
business partners or professional advisers. If you wish to access your personal
information or se e our full privacy policy, please contact us at
customercare@dyson.com.au
CONFORMITY INFORMATION
A sample of this product has been tested and found to be in conformity with the
following European Directive: 2006/95/EC Low voltage Directive, 93/68/EEC
CE Marking Directive, 2004/108/EC EMC Directive, and the following Austraila
and New Zealand Directive: A S/NZS60335.2.2 2002.
PRODUCT INFORMATION
Net weight: 1.23kg
This product is protected by the following intellectual proper ty rights:
PATENTS/APPLICATIONS
CA 2544609; JP 2007-508934; US 2007-0079579; AU 2004294771;
AU 2002226556; CA 2,439,250; EP 1370172; JP 4002185; US 6991666;
AU 2002225207; EP 1361814; JP 3860541; US 7018439; AU 2001240894;
EP 1268076; JP 2003-528704; US 6,835,222; AU 2002-225232; EP 1361815;
JP 3940082; US 6,974,488; EP 1748848; JP 20 07-534377;
US 2007-0175189; WO 2005/110608; WO 200 8/009884; WO 2008/009891;
WO 2008/015377; WO 2008/015378; WO 2008/009886;
WO 2008/00988 8; WO 2008/009883; GB 2440515; GB 2440514;
GB 2440126; GB 2440109; GB 2440107.
DESIGNS/DESIGN APPLICATIONS:
GB 3025398; GB 3025399; GB 302540 0; GB 3025401; GB 3025402;
GB 3025403; GB 3025 404; EU 651849.
Equivalent patents, regis tered designs and applications exist in other countries.
8
9
IMPORTANT!
WASH FILTER
QUESTIONNAIRE
Please take a few moments to answer our questions.
They will help us develop new products for the future.
Wash your filter with cold water regularly or as required.
Register for a filter wash reminder by email (Australia only);
customercare@dyson.com.au
Dyson Customer Care
If you have a qu estion a bout you r Dyson handhel d vacuum,
call th e Dyson Custome r Care He lpline wi th your s erial number
and details of w here and when you bought t he Dyson handhe ld
vacuum, or contact us via the Dyson website. The serial number
can be found on the main body of the Dys on handheld vacuu m
behind the filt er.
AU Dyson Customer Care
customercare@dyson.com.au
1800 239 766
Dyson A pplianc es (Aust) Pty Ltd.,
PO Box 28 35,
Taren Point, NS W 2229,
Australia
www.dys on.com.au
NZ Dyson Customer Care
dyson@averyrobinson.co.nz
0800 397 667
Avery R obinson Lt d.,
Unit F, 151D Marua Road,
Ellers lie, Auckla nd 1051,
New Zealand
www.dyson.co.nz
1 This handheld cleaner is…
My first handheld cleaner
A replacement handheld cleaner
An additional handheld cleaner
2 Which brand of cleaner are you replacing or adding to?
Dyson Electrolux
Hoover LG
Miele Panasonic
Samsung Nilfisk
Vax Kambrook
Volta Wertheim
Other, please specify
3 Why did you choose to buy a Dyson handheld cleaner?
(Please rank in order, 1-5. 1 being the most important).
Dyson reputation
Good for pet hair pick-up
Performs consistently well
No loss of suction
Previous experience of Dyson
Features
HEPA filtration
Price/special offer
Wanted a bagless handheld
Compact and easy to store
Store staff recommendation
Picks up more dust than others
Latest model/technology
Reliabilit y/quality
Friend/family recommendation
Other
4 Where did you first hear about the Dyson model you bought?
From friends and family
Saw it on the internet
From a TV/magazine advert
Saw it in a store catalogue
Saw it in a store
Recommended by salesperson
6 What is your average household income?
Less than $45,000
Bet ween $45,000 – $74,000
Bet ween $75,000 – $100,000
Over $100,000
7 Do you have any household pets?
Dog Cat
None Other
8 Does anyone in your household suf fer from any of the following?
Asthma Allergies
None
9 To which age group do you belong?
16 – 24 25 – 34
35 – 44 45 – 54
55 – 64 65+
10 Would you recommend a Dyson handheld cleaner to your family
and friends?
Yes No
11 Do you have children?
Pre-school Aged 5-17 years
Aged +17 years Children no longer at home
Pregnant No children
12 Which best describes your house?
(Tick one from each column).
Own house Up to 2 beds
Rented house 3-4 beds
Own apartment/villa More than 4 beds
Rented apartment/villa
Live with parents
Share accommodation
JN.30 565 PN.17811-05-01 29.05.09
www.dyson.com
5 Do you own a Dyson handheld?
Yes No
THANK YOU FOR YOUR TIME
GUARANTEE FORM
Date of purchase
Serial number
Did you purchase an extended warranty?
If yes, for what additional period?
Title
First name
Address
/ /
Surname
Store of purchase
1 year
Yes
No
2 years 3 years
Postcode Countr y of purchase Australia New Zealand
e-mail
Telephone Mobile
As a Dyson owner, you can hear about Dyson inventions and ideas before anyone else. If it’s okay to contact you, please let us know how we may
do this.
By mail Yes No
By phone Yes No
Privacy Act
Dyson may use this information for future marketing and research purposes (including sending commercial elec tronic messages) and may
disclose it to third par ties for the purposes of providing the services you have requested or to our business par tners or professional advisers.
If you wish to access your personal information or see our full privacy policy, please contact us at customercare@dyson.com.au
If you do not wish to receive marketing information by these methods from Dyson please tick this box.
By email Yes No
By text message Yes No
3 EASY WAYS TO REGISTER YOUR 2 YEAR GUARANTEE
REGISTER
ONLINE
Visit our website to register your
full parts and labour guarantee
online (Australia only).
www.dyson.com.au/register
REGISTER
BY PHONE
Call our dedicated Helpline.
AU 1800 239 766
NZ 0800 397 667
SG 7000 435 7546
ID 021 707 39766
REGISTER
BY MAIL
Complete and return
the form to Dyson in
the envelope supplied.
Loading...
