Dynamics PE User Manual

3G MOBILE PHONE

User Manual

BRAND NAME: Ice Mobile

MODEL NAME: Prime Extreme

FCC ID:C89-PE

Contents

Safety .................................................................................................................... 4

Environment ........................................................................................................ 5

1 Getting Started ................................................................................................. 6

1.1 Getting to know your touch phone .................................................... 6

1.2 Installing the SIM card, battery, and storage card ............................. 6

1.3 Charging the Battery .......................................................................... 7

1.4 Starting up the device......................................................................... 8

1.5 Status Icons ...................................................................................... 10

2 Using phone features ..................................................................................... 12

2.1 Turning the phone function on and off ............................................ 12

2.2 Making a call ................................................................................... 12

2.3 Answering and Ending a call ........................................................... 13

2.4 In-call options .................................................................................. 13

2.5 Using call history ............................................................................. 14

2.6 Call settings ...................................................................................... 14

3 Setting on your device .................................................................................... 15

4 ActiveSync ....................................................................................................... 19

5 Contacts .......................................................................................................... 22

6 Exchanging Messages .................................................................................... 25

7 Internet ........................................................................................................... 31

7.1 Ways of Connecting to the Internet ................................................. 31

7.2 Browser ............................................................................................ 31

8 Experiencing Multimedia .............................................................................. 34

8.1 Camera & Picture ............................................................................. 34

8.2 Music................................................................................................ 36

8.3 FM Radio ......................................................................................... 39

8.4 Voice Search ..................................................................................... 39

8.5 Sound record .................................................................................... 39

9 Other applications .......................................................................................... 39

9.1 Calendar ........................................................................................... 39

9.2 Alarm Clock ..................................................................................... 41

9.3 Calculator ......................................................................................... 43

10 Android Market* ......................................................................................... 44

Safety

Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone i s prohibited. Use of your phone is subject to saf ety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, sw imming pool…). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than - 10°C and higher than + 5 The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested). Electrical safety: Only use the chargers listed in the manufacturer ’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line vo ltage must be exactl y the one indicated on the charger ’s serial plate. Aircraft safety: When traveling by plane, you will need to switch yo ur phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations.

0°C.

Explosive materials: Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way. Electronic equipment: To avoid the risk of demagnetization, do not let electronic devices close to your phone for a long time. Electronic medical equipment: Your phone is a radio transmitter which may

interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It i s recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in this area. Hospitals: A lways make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff. Road safety: Do not use your phone when driving. In order to give your full attention to driving, stop and park safely before making a call. You must compl y with any current legislation. Distance of operation: This phone model has been tested and meets radiofrequency exposure guidelines when used as follows:

• Against the ear: Place or receive a phone ca ll and hold the phone as you would a wire line telephone.

• Body worn: When transmitting, place the phone in a carry accessory that contains no metal and positions the pho ne a mini mum of 2.5 c m form your body. Use of other accessories may not ensure compliance with radiofrequency exposure guidelines. If you do not use a body worn accessory and are not holding the phone at the ear, position the phone a minimum of 2.5 cm from your body,

• Data operation: When using a data f eature, position the phone a minimum of

2.5 cm from your body for the whole duration of the data transmission.

Environment

Packaging: To facilitate the rec ycling of packaging materials, please obey the

sorting rules instituted locally for this type of waste.

Batteries: Spent batteries must be deposited at the designated collection points. The product: The crossed-out waste bin mark affixed to the product means that

it belongs to the family of electrical and electronic equipment. To promote the recycling and recovery of waste electrical and electronic equipment (WEEE) and at the same ti me safeguard the environment, European regulations require you to obey the sorting rules instituted locall y f or this type of waste.

1 Getting Started

1.1 Getting to know your touch phone

1.2 Installing the SIM card, battery, and storage card

You need to remove the back cover before you can install the SIM card and battery. Also, make sure to always turn off the power before installing or replacing the SIM card and battery.

To remove the back cover

1. Make sure your device is turned off.

2. Firmly hold the device with both hands and the front panel facing down.

3. Push the back cover up with your thumbs until it disengages f rom the device and then slide it up to remove. To install the SIM card The SIM card contains your phone number, service details, and phonebook/ message memory. Your device is supported both 2G and 3G (WCDMA) SIM cards.

1. Remove the battery if it is installed.

2. Locate the SIM card slot, and then insert the SIM card with its gold contacts facing down and its cut-off corner facing out the card slot.

3. Slide the SIM card completely into the slot.

Note: • The phone can be supported the double SIM cards. The card slot 1/2 will be both supp orted 3G SIM card (WCDMA), but one S IM card can use 3G networks only. If you need to use 3G operation, please insert 3G card in the card slot 1(Default SIM1 card, defined in the menu Settings/More…/Mobile networks/3G service), the SIM2 card will be supported 2G network only (If insert 3G card in the card slot 2, you can also use 2G operation only).

• Some legacy SIM cards may not function with your device. You should consult with your service provider for a re placement SIM card. There may be fees for this service. To install the battery

Your device comes with a rechargeable Lithium-ion batter y and is designed to

use only manufacturer-specified original batteries and accessories. Battery performance depends on man y f actors, including network configuration, signal strength, and usage patterns. Warning: To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or water.

• Do not expose to temperatures above 60°C (140°F).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

1. Align the battery’s exposed copper contacts with the battery connectors at the bottom part of the battery compartment.

2. Insert the contacts side of the battery first and then gently push the battery into place.

3. Replace the back cover.

To remove the battery

1. Make sure your device is turned off.

2. Remove the back cover.

3. The bottom of the p hone has a notch. Lif t the battery b y the notch to r emove it.

To install a memory card

To have additional storage for your images, videos, music, and files, you can purchase a memory card and install it into your device.

1. Make sure that your device is turned off, and then remove the back cover.

2. Locate the memory card slot on the upper part of the exposed right panel.

3. Insert the memory card into the slot with its gold contacts f acing down until it clicks into place. Note: To remove the memory card, press it to eject it from the slot.

1.3 Charging the Battery

New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles. Note: Only the AC adapter and USB sync cable provided with your device must

be used to charge the device. Connect the USB connector of the AC adapter to the sync connector on your device, and then plug in the AC adapter to an electrical outlet to start charging the battery. As the battery is being charged while the device is on, a charging icon appears in the title bar of the Home screen. After the battery has been fully charged, a full battery icon appears in the title bar of the Home screen. Warning: • Do not remove the battery from the device while you are charging it using the AC or car adapter.

• As a safety precaution, the battery stops charging before it overheats.

1.4 Starting up the device Power on/off

To power off your pho ne, press & hold POWER. On release, the Phone opti ons menu opens. Select ‘Power off’ and confirm. To power on again, press & hold POWER.

Silent mode

To silence your phone quickl y, press & hold the – volume button to zero volume. Or on the Home screen, touch ‘Silent’ check box.

Screen sleep

After a period of inactivity, your screen will go to sleep (display will turn black). In sleep, your phone uses less battery power. You can control this behavior: Set screen timeout period

1. On the Home screen, touch

2. Select Display option.

3. Select Sleep. Select a time from the menu. Prevent sleep while charging

and select Settings > Audio profiles. Select

and select Settings.

1. On the Home screen, then touch

2. Select Developer options.

3. Select ‘Stay awake’ check box. Lock screen & put phone to sleep Except when on a phone call, from any screen, press POWER (immediately).

and select Settings.

While not on a call, to lock your control buttons and screen from accidental touch activation, press POWER. You can increase the security of your phone by setting Screen unlock pattern. Once set, in order to unlock your screen, you’ll have to draw the correct unlock pattern. You can set your screen unlock pattern as follows:

1. On the Home screen, touch

2. Select Security and then scroll down to Screen lock pattern section.

3. Set or change your unlock pattern by selecting Screen lock pattern, as applicable.

4. Follow the prompts to define your pattern. Note: You must slide your finger along the screen to create the pattern, not select individual dots. Connect at least four dots. If you want your pattern to be hidden as you draw it, clear ‘Make pattern visible’ check box.

Home screen

The Home screen is your starting point for using all the applications on your phone. You can customize your Home scree n to display applications, shortcuts, and widgets as you like.

1. Touch the application tab

and select Settings.

with your fingertip to reveal the application

icons.

2. The Home screen actually extends beyond the screen width. On Home screen, slide your fingertip left and right along the screen to reveal the f ull width of the Home screen. This additional space gives you more room to customize Home with applications, shortcuts, and widgets.

3. Create Home screen shortcuts and widgets:

• Touch the application tab icons, slide your fingertip right to show the shortcuts and widgets.

• Select an Application shortcut, a Shortcut to some of your saved information (such as a play list), a Widget (a clock or picture frame) for your Home screen.

• The application, shortcut, folder, or widget appears on Home screen. Tip: To create an application shortcut quickly, touch the applica tion t ab to revea l all the application icons, then touch & hold an applica tion icon. Its shortcut is

with your fingertip to reveal the application

added to the Home screen; close the application tab to see it.

4. To remove a shortcut or widget from your Home screen, touch & hold the item to enter “move mode”. The application tab turns into a Trash button. Drag the item to the Trash button and release. You’ll know when your item is in the Trash because the item and the tab will turn red.

5. Move objects on the Home screen

• To move an icon or other item on the Home screen, you must first touch & hold it to enter move mode. The object will magnify when it’s ready to be moved.

• Without lifting your finger (or you’ll drop o ut of move mode), dra g the object to the new position. To move an item to a section of the Home screen not in view, move it to the edge of the screen and hold it there for a moment. The screen view will shift; position the object and release.

1.5 Status Icons Connection status icons

Along the top of your phone screen is the stat us bar. On the left side , icons will appear, notifying you of a new message, upcoming calendar event, or something else you should notice. On the right side of the status bar, you’ll see connection status icons.

Network signal EDGE service

connected, data flowing

WCDMA service connected, data flowing

Sign-in/sync error

Song is playing

Ringer is off (Silent mode)

WLAN service

SMS/MMS

Call in progress

connected Wireless services are

off (Airplane mode)

Missed call

Call forward

Read your notifications

When you see a notification in the status bar, touch the bar and slide your finger down the screen to open the list of notifications displayed in the sliding window.

Alarm is set

Bluetooth is on Connected the

Phone on mute

Battery is low

Battery is very low!

Battery is charging Connected the

earphone

Ongoing notifications report activities such a s call forwarding ON, current call status, song playing. Notifications report the arrival of new messages, calendar events, and alarms. You can clear notifications list by selecting ‘Clear’ notif ications at the top of the notifications window. To open the message, reminder, or other notification, you can touch the items. To close the notifications window, slide your finger up the screen.

Notes: On the home screen, touch the bar and slide your finger down the

screen to open the list of notifications disp layed in the sliding window, you can touch the icon on the top of the screen to enter the shortcuts screen, such as Airplane mode, Wi-Fi, Bluetooth, Data connection, Airplane mode, Brightness, you can open or close the selected function directly.

2 Using phone features

2.1 Turning the phone function on and off To enable or disable Airplane Mode

In many countries, you are required by law to turn off the phone while on board an aircraft. Another way to turn off the phone function is to switch your device to Airplane Mode. When you enable Airplane Mode, all wireless radios on your device are turned off, including the phone function, Bluetooth, and WLAN.

1. Touch

2. Touch ‘Airplane mode’ to enable or disable. When you disable Airplane mode, the phone function is turned back on and the previous state of Bluetooth and WLAN are restored.

Adjusting the volume

Press Volume button on the side of the phone to show the volume screen. If the phone is in vibrating mode, the voice w ill be muted auto matically and the device will vibrate when there is an incoming call.

2.2 Making a call Calling a voice call

On Home screen, touch Touch the on-screen di al pad to enter a number, touch ‘Delete’ button to delete numbers you’ve entered. Touch & hold to delete all the numbers in the field. To dial a number, touch ‘Voice Call’ butt on (Green icon

-> Settings -> More… -> Airplane mode.

-> Phone to enter the dial screen.

) to select SIM1

card or SIM2 card to make a call. To end a call, touch ‘END’ button (Red icon).

1. Call log tab: Select an entry listed in the log to call the number.

2. Contacts tab: Contacts with phone numbers are listed. Select a contact, and then select the phone number to dial the call.

Note：If you inserted dual SIM card, the dial screen is default dual call (Defined in the menu Settings/SIM management/Voice call). Calling a video call

On Home screen, touch Touch the on-screen dial pad to enter a number, touch ‘Video Call’

-> Phone to enter the dial screen.

button to make a video call.

Notice: • SIM slot 1 can be supported video call default (SIM 1 ca rd must be supported 3G network).

• Your phone must be in of the normal W C DMA network coverage, and the other side (the receiver’s phone and SIM card) can also be supported the video call function of 3G.

2.3 Answering and Ending a call

When you receive a phone call, the incoming voice call screen will appear, allowing you to either answer or ignore the call.

1. To answer an incoming call, slide ‘ANSWER’ (Green icon) button rightward.

2. To reject a call, slide ‘REJECT’ button (Red icon) button leftward.

2.4 In-call options

While on a call, reveal the in-call options: Speaker, Mute, Hold, End. Note that if Bluetooth services are on and you are connected to a hands-free device, the more menu indicator will show Bluetooth on.

1. Speaker: To use the speaker, select ‘Speaker’ so it shows a green bar. To tur n it off, select it again so the bar is unfilled. The status bar will display this icon when the speaker is on.

2. Mute: To mute your side of the conversation, select ‘Mute’ so it shows a green bar. To turn it off, select it again so the bar is unf illed. The status bar will display this icon when Mute is on.

3. Hold: To put an active call on hold, select ‘Hold’ so it shows a green bar. To resume the call, or take the call off hold, select it again so the bar is unfilled. If you take a call while already on a call, the first call will be placed on hold automatically. The status bar will display this icon when a call is on hold.

4. Add call: If you need to enter numbers while on a call, touch ‘Add call’.

5. Incoming call: During call in progress, if you are on a call (“call in progress”) when another call comes in (“incoming call”), you have a few choices:

• Answer the incoming call and place the call in progress on hold. To switch calls at any time, touch ‘Swap calls’.

• If you don’t want to interrupt your call in progress, then touch ‘END’.

• If you have one call in progress and one caller on hold, to end both calls, touch ‘End all’.

6. While on a call, you can conference up to six callers, counting yourself. Note that you can also have an additional caller on hold during a conference call, regardless of how many participants are on the conference. Note: Whether the group call function can be used depends on whether the network operator supports and provides such function as well as whether you have applied for such function. Please contact network operator for details.

2.5 Using call history

1. The missed call icon

2. Use ‘Call log’ tab to check who the caller was, or view all your dialed numbers, and received calls. To open ‘Call log’ tab, touch ‘Call log’ button in the phone screen to enter the call history list.

3. Scroll to select the contact or number you want to dial, touch ‘Call’ button.

4. Tap and hold the sel ected contact you want to call, and then you can make to do the following options of call, edit number before call, send text message, add to contacts or remove from call log phone on the shortcut menu.

2.6 Call settings

On the dialing screen or call log screen, press MENU > Settings to enter Call settings，you can make the operation of voice call, voice call and the other settings. Note that when you open ‘Call settings’ for SIM1 or SIM2, your current settings are fetched, which can take a few moments.

appears in the title bar when you missed a call.

3 Setting on your device

Control phone-wide settings from the Home settings screen: touch and select Settings.

3.1 Wireless & networks

SIM management You can select to activate or deactivate the SIM card you want to open. Set the default SIM to use voice call, Video call, messaging and data connection. Wi -Fi Wi-Fi on/off: Select this check box if you prefer to use Wi-Fi for your data connection. Wi-Fi settings: Open the Wi-Fi settings screen; select it from the network list. Provide your username or password if required. Bluetooth Bluetooth on/off: Use this check box to turn Bluetooth services on or off. Bluetooth settings: With Bluetooth services on, you can open the Bluetooth settings screen to:

• Rename your device.

• Select to be discoverable for up to 120 seconds, or not discoverable.

• Pair or unpair with one of the Bluetooth devices in range - You will be asked to type a PIN before p airing. Refer to the manufacturer ’s documentation for the PIN code.

• Rescan for devices. More… Airplane mode on/off: When airplane mode is selected, all wireless connectivit y is off. This icon selected. Mobile network

• Select data roaming capability.

• Select a wireless operator network - Scan for all available network s, or select a network automatically.

will display in the status bar when airplane mode is
