Dynamics G3PRO User Manual
English User Manual
FCC ID: C89G3PRO
Thanks for buying this Tablet PC. This manual will introduce you to the functions of
your device and make you aware of anything requiring attention. Please read this
manual carefully before using the device.
①
②
③
④
⑤
⑥
⑦
⑧
⑨
1. Power button
2. VOL+
3. VOL-
4. Earphone jack
5.OTG USB Port
6. DC Socket
7. TF card slot
8. Reset
9.Speaker
10.Bluetooth
Content
1. Notifications ………………………………………………………………1
2. Introduction ……………………………………………………………………2
2.1 Key Functions……………………… ………… ……………………………………..2
2.2 Features Overview. ……………………………………………………………………2
2.3 Technical Specifications……………………………………………………………………..3
3. Quick Guide …………………………………………………………………3
3.1 About the Touch screen……………………………………………………………….......3
3.2 Switch On/Off. ………………………………………………………………........................3
3.3 Power Save Modes and lock screen…………………………………………………3
3.4 Battery management and charging. ………………………………………………………3
3.5 Explanation of Function items………….………………………………………………4
3.6 USB HOST Function………………………………………………………………..............4
3.7 TF Card Storage………………………………………………………………....................5
4. Network Access …………………………………………………………………5
4.1 Wi-Fi Network Access ……………………………………………………………….....5
4.2 3G Network Access ………………………………………………………………...........5
5. Storage File Copy……………………..………………………………………5
6. Main Functions ……………. ……………………………………………6
6.1 Audio Function……………………………………………………………………...… 6
6.2 Video Function……………………………………………………………………………7
6.3 Picture Function……………………………………………………………………… 7
6.4 Record Function…………………………………………………………………………7
6.5 File Manager………………………………………………………………………..........8
6.6 E-book Function…………………………………………………………………………8
6.7 Internet Browser………………………………………………………………………8
6.8 E-mail Function…………………………………………………………………………9
6.9 Calendar……………………………………………………………………………….........9
6.10 Calculator……………………………………………………………………………….....9
6.11 Alarm Clock……………………………………………………………………………….9
6.12 APK Installer……………………………………………………………………………10
6.13 Pictures and Video………… … … …………………………… … ………………11
7. System Settings……………………………………………...............…………11
8. FAQ………………………………………………………………......…..………12
1
1. Notifications
①. Please protect the device away against moisture and dust.
②. Do not leave the device in a high-temperature environment, especially a closed car in hot
weather.
③. Do not drop or strike the device.
④. Do not shake the device violently, particularly the LCD screen, as this may cause the display to
malfunction.
⑤. Please make sure to carefully adjust the earphone volume; excessive volume may be harmful to
your hearing.
⑥. Please charge the device when
(1) The power icon shows that the battery is nearly flat
(2) The device turns itself off automatically and will not come back on.
(3) There is no response when operating the buttons.
Attention: Please use only the charger provided by the manufacturer; other chargers may
damage the device.
Input: 100-240V ~ 50/60 Hz
Output: 5V 2800 mA
⑦. Do not disconnect the device from your PC when downloading, uploading or formatting as this
may cause programming errors in the device.
⑧. Do not disassemble the device yourself; only allow an expert to do so.
⑨. Do not use alcohol, thinner or benzene-based chemicals to clean the surface of the device.
⑩. Do not use the device in places where its use is prohibited, like aircraft.
⑪. Please make sure to always back up your device. The manufacturer is not responsible for lost
files or data after damage to or repair of the device.
⑫. The manufacturer reserves all the rights to the technology and design of the device and has no
obligation to inform the user if new versions or designs have been developed.
⑬. The device is NOT waterproof; please keep it away from moisture at all times.
This device will take approximately 20 seconds to power up; please don't try to operate the
device during this period.
2
2.1 Key functions
Name
Description
POWER
Press this button briefly for sleep/wake up mode, press and
hold for several seconds to turn device ON or OFF
MENU
Press this button briefly to access the submenu
ESC
Press briefly to exit current mode
TF Card Slot
For external TF card, 1GB to 16GB
Stereo earphone jack
Stereo jack for earphone
DC Socket
To connect device to 5V DC charger
Micro USB Port
Micor 5-pin USB Port
USB Host Port
Port for external USB driver, 3G dongle, mouse, keyboard,
etc. (2.0)
Display
HD Display area
Screen
7inch Capacitive Touch Screen. Ten Points Multi-touch
Resolution: 800*480 Aspect Ratio:16 : 9
CPU
Chipset: A23; Processor: Cortex A9; Frequency: 1.2GHz
RAM
DDR3: 512MB
Storage
4GB-16GB optional
External TF card increase storage from 1GB to 16 GB.
System
Android 4.2.2
Network
Wi-Fi: Built-in Wi-Fi Module. Bluetooth IEEE 802.11b/g/n. 11Mbps to 54Mbps
3G: External 3G by USB Dongle.
Applications
APK format applications
Video
RM, AVI, MOV, WMV, MP4, ASF, 3GP, TS, MKV, MPEG, etc. All videos support HD
2. Introduction
2.2 Features Overview
CPU: A23 Cortext A9, 1.2GHz. with ANDROID 4.2.2 operating system.
7' TFT touch screen LCD display, 800*480 pixel resolution.
Supports 4~16GB built-in Flash Memory, support 128MB-16GB external TF card.
Media support for video, audio, pictures, E-books, etc.
Built-in Wi-Fi Bluetooth supports external 3G USB-DONGLE wireless network card (3G card
or USB-Dongle are not provided by the Tablet PC manufacturer).
Various applications are available in the ANDROID 4.2.2 OS (APK applications only).
Supports built-in microphone record function (optional).
Supports USB-HOST and external U-disk, MP3, MP4, mouse, keyboard, etc.
Supports G-sensor screen rotation function.
Supports stereo earpieces and speaker.
Supports multiple languages.
The device can be used as a USB portable hard disk, driver not needed for WIN2000 or above.
2.3 Technical Specifications
3
1080P.
Music
MP3, WMA, WAV, APE, FLAC, AAC, OGG, etc.
Pictures
JPG, BMP, PNG, TIFF, etc.
E-books
TXT, PDF, CHM, HTML, PDB, UMD, FB2, LRC, EPUB.
Office Files
Supported files: Word, Excel, PDF, etc.
PC Connection
Micro USB2.0 x 1
Battery
Built-in Lithium Battery: 2800 mAh.
3. Quick Guide
3.1 About the Touch screen
The screen is a capacitive touch screen; you can use five fingers to touch the screen at the same
time.
3.2 Switch On/Off.
Switch On and Unlock: When the device is in the OFF mode press and hold the Power key for 3
seconds to enter the Android start-up progress bar; it takes approx. 20 seconds to display the
system desktop. When the LCD is in locked mode please press and drag the icon to the green
point and the LCD will unlock automatically, see the illustration below:
3.3 Power Save Modes and lock screen.
Briefly press the 'POWER' key after starting up for the system to go to power save and lock
mode.
Briefly press the 'POWER' key or tap the touch screen and system will return to bright in 1
second
The primary functions of the device – e.g. playing music, movies, etc. – will not stop in the
power save mode; only the LCD is turned off and shows a black screen.
Switch OFF: When the device is in the OFF mode press and hold the 'POWER' key for 3
seconds. The screen will display the power off interface; select the power off icon to confirm
and the system will shut down automatically.
【Note】When the battery is low the device will give a continuous alarm and shut off automatically
if it is not charged. If the device will not start up please check if the battery is low and try again
after the battery has been charged.
3.4 Battery management and charging.
3.4.1 Before using your device for the first time charge the battery for 8-12 hours to give the
