Dynalite Baja User Manual

dynamic lighting
Dynalite Baja Portable Electronic Flash
USER MANUAL
Introduction......................................................................... 3
Safety Guidlines .................................................................. 4
Dynalite Legacy ................................................................... 5
Using Dynalite Baja Portable Electronic Flash................. 6
Getting Started.................................................................... 8
Flash Modes......................................................................... 8
Adding/Removing Modiers............................................ 10
In the Box........................................................................... 10
Accessories ........................................................................ 10
Specs ................................................................................. 11
Introducon
Hi. Im Kevin Ames and I dont work for Dynalite. I am a working commercial photographer with a studio in Atlanta, Georgia. I am a Dynalite user and have been for many years.
This is the part of the normal instruction booklet where you are congratulated for choosing
(insert what you bought here,) the nest blah-blah-blah and so on. I am not going there. Ever. Rather than take that path, let me welcome you instead. If you are a rst time Dynalite
customer, thank you. You have joined a community of hard working pros and advanced amateurs that understand how important dependable lighting gear is to their careers and
hobbies—yes to their passion--photography. A lot of us have decades of experience shooting
photographs lit with Dynalite.
Thanks to you too, if you are one of the established Dynalite users and have added this gear to expand your lighting capabilities.
Users guides have all of the personality of a box of bricks. Id like to break out of that with this one. I want it to be readable, understandable, conversational and even fun. All of the information is here. In plain English. If I spoke Spanish it would be in plain Spanish as well. I dont. It isnt. Continuing to step out of the technospeak Ill explain the terms of each part and
what those terms mean. Personally I really hate having to search the web for what a ux-
capacitor is when the directions tell me to install it into socket B. What is socket B anyway? I want this guide to be clear and complete. Turn the page and get started using your new
Dynalite B-4...
There are only a few important things to know about handling any electronic ash systems when it comes to doing it
safely. This section is hyper-important for you to be safe and stay well while using your Dynalite Baja B-4. Most of this is common sense. Which we all know isnt common at all. So, please read them anyway.
1. Water and electricity dont mix well. When power packs, heads, and their cables are operating they have a lot of high
voltage electricity in them. Using a Dynalite Baja B-4 that’s wet
or standing in water can cause very serious injuries like death. Really.
2. The Baja ashtube gets outrageously hot while it is being
used. Avoid betting burned. Dont touch the pyrex cover over
the ashtube. After shooting ten full power ashes in fast succession, let the ashtube cool down for a couple of minutes. Don’t look directly at the ashtube close up when you re it to
avoid possible damage to your eyes.
3. Never re the Baja B-4 with the protective cover over the ashtube.
4. Don’t re the Baja B-4 near ammable liquids like gasoline or
gases like propane or natural gas.
5. Baja B-4 portable electronic ash units are lousy basketballs. It is
a really bad idea to use one if it has been dropped. Send it back to Dynalite to be checked instead.
6. Only use the battery charger that comes with your Baja B-4
to recharge the battery. Once the battery is fully charged
disconnect the charging cord from the Dynalite Baja B-4. It’s never a good idea to leave batteries charging indenitely.
Overcharging the Baja B-4’s battery can damage the cells;
possibly leading to an explosion. Dont overcharge the battery.
7. Excessive heat can cause the battery to explode. Dont leave
your Baja B-4 in direct sun for long periods of time. Let the unit
cool before using it.
8. Dynalite Baja B-4 portable electronic ash units have a lot of electrical energy inside the case even when they are turned o. Leave opening them to a qualied Dynalite technician or send them back to Dynalite. There are no user xable parts inside, just
a lot of current waiting to shock those (like me and Im guessing, you) who dont know what they are doing. Seriously.
Safety
The Dynalite Legacy
Dynalite began in 1971 when Paul Schwartz, an electronic engineer, teamed with photographer Ed Lambert and
silent investor John Poremba to create a rugged, dependable and portable electronic ash power pack and heads. Paul designed the original electronics including the non-arching connectors that allow heads to be added or
removed from a powered up pack safely. That circuit was so robust that, while it has been updated with modern technology, it remains the basis for every pack Dynalite makes today. While the insides of Dynalite packs and heads have evolved, the control layout has been mostly the same for over three decades. A photographer buying a new pack today knows it will work the same way one that has been in the studio for twenty years or more.
Dynalite was instantly popular with location photographers. Whether the subject was a celebrity or politician destined to grace a magazine cover or an ocean side beach resort showcasing its architectural interior elegance, Dynalite was likely on the scene. Photographers across the country adopted the super light packs that easily stood up to the rigors of the road. Whether piled in the back of a van or checked as luggage on airlines, Dynalite gear
stood up to the abuse travel wreaks on equipment that can be delicate.
Realizing that photographers want powerful, lightweight electronic ash systems Dynalite is proud to continue its legacy of innovation with the new Baja B-4.
dynamic lighting
The Dynalite Baja Portable Electronic Flash
1.
Flash Power Control Dial  Turn it clockwise to increase the power output. Moving the dial counter clockwise lowers the power.
2.
Modeling Light Power Control Dial
3.
RPT Button engages C or HSS modes. Press and release for C mode. It also cycles the C
mode for ve, ten or fteen stroboscopic ashes. Press and Hold for HSS (High Speed Sync.)
4.
Mode controls the ash duration. This button switches between Normal mode and T mode-­short duration ashes
5. Cell Button switches the ash tripping sensor on or o.
6.
Sound Button toggles an audible tone when the Dynalite Baja B-4 is fully charged.
7. Test Button res the ash without having to take photograph with the camera.
8.
Power Switch turns the Baja unit on or o.
9. 1/4 inch sync cord socket for wired or Pocket Wizard sync with a camera.
10. Charging Socket
11. Battery Power Level Indicator
12.
Battery Status  Bottom Amber = Charging, Middle Amber = Empty, Top Amber = Battery Fully Charged
13. Main Display shows Power Output Setting, Short Duration Setting, Stroboscopic Mode selected. Red LED lights show (top to bottom) RPT, Mode, Cell, Sound and Test
14. BRR616 — 6 group 16 channel receiver included with the Dynalite Baja B-4
15. Remote Trigger Sensor detects the ash from another Dynalite Baja, head or speedlite to
re the unit’s ash.
16. Easy Carry Handle
17. Battery Cover Release
18.
Accessory Release
19. Umbrella Socket  Push the umbrellas shaft into the socket. No tightening knob needed.
20. L.E.D Modeling Light  Note that the light is always on when Baja is powered up.
The Dynalite Baja B-4 is a self contained
400 watt / second portable monolight
ash. Powered by an internal Lithium
Ion rechargeable battery and controlled
with the optional BRT616 or BRT616c
radio transmitters, there are no cords
or cables to clutter a set in the studio or
at a location.
The Baja B-4 is light in weight while
remaining strong in features including
adjustments in one tenth of a stop
increments over a six f/stop range, high
speed sync, short duration ash and
stroboscopic ash modes.
Flash Power Control Dial
Remote Trigger Sensor
Easy Carry Handle
Accessory Release
Modeling Light Power Control Dial
Power Switch
1/4 Inch Sync Cord Socket
Charging Socket
Battery Power Level Indicator
Main Display
HSS Receiver
Battery Status
3. RPT Button
4. Mode Button
5. Cell Button
6. Sound Button
7. Test Button
3
1
2
8
9
10
12
13
14
4
5
6
7
Battery Cover Release
17
18
16
15
11
18
Accessory Release
19
Umbrella Socket
L.E.D. Modeling Light
20
Geng Started
Dynalite Baja Portable Electronic Flash units ship with a hard plastic cover that
protects the ashtube. Press the Accessory Release (18) at the top front of the unit then twist the ashtube cover counterclockwise. When it stops after about an
eighth of a turn, pull the cover away from the unit.
Charging the Baja
Connect the chargers output cord to the Charging Socket (10.) Plug its AC cord to
110 / 240 volt outlet. Turn the Power Switch ( 8 ) O.
The indicator light on the charger glows Red while the Baja is charging. It turns to Green when the battery is full.
Fully charge the battery before using your Dynalite Baja B-4. This takes about three and a half hours. When the battery is fully charged; the Battery Status (12) will show
Full. The Dynalite Bajas battery can be augmented by connecting the charger to the Charging Socket (10) while the unit is being used increasing the number of full
power ashes to 800.
Flash Modes
The Dynalite Baja B-4 oers four ash modes: Normal, High Speed Sync (HSS) Short
Duration and Stroboscopic. Heres a detailed explanation of each one.
Normal
Normal is the mode used most often. It provides a six f/stop range of power in one tenth of a stop increments from 1.0 (lowest power) to 7.0 (six f/stops brighter.) The chart below shows the power ratings on the Main Display (13) (top row) with the watt / second (w/s) output for each setting (middle row) and the color temperature.
f/stop range of power 1.0 2.0 30. 4.0 5.0 6.0 7.0
watt/sec output 6 w/s 12 w/s 25 w/s 50 w/s 100 w/s 200 w/s 400 w/s
color temperature 5420ºk 5480ºk 5560ºk 5600ºk 5590ºk 5500ºk 5500ºk
Main Display
High Speed Mode Button
Flash Control Dial
Test Button
13
4
7
1
Power Switch
8
Charging Socket
10
Battery Status
12
High Speed Sync (HSS)
Digital Single Lens Reex cameras have focal plane shutters. These allow for amazingly fast
shutter speeds  up to 1/8000th of a second in most modern cameras. The high speed is
achieved by using a thin slit formed by the rear shutter starting to close before the rst curtain
is fully open. This limited the fastest shutter speed to between 1/160 & 1/250th of a second
depending on the camera model. Both Canon & Nikon oer speedlites that can synchronize
with those thin slits. Good news! The Baja can too with its optional BRT616c transmitter that enables high speed sync with most Canon DSLR cameras. Nikon will be added soon. Enter HSS by pressing the
+ button on the BRT616c transmitter. Next, power on the Baja, then
hold down the rpt button (3) until the main display (13) reads H.1. Adjust the Flash Control Dial (1) for H.1 - H.7.
Short Duration
Short Duration or t mode shortens the ash duration to stop motion. Use this mode for freezing action like a drop hitting a saucer full of milk or for pouring liquids. Enter this mode by
pressing the Mode button. The Main Display now shows a digital t followed by a number. t.1 is the fastest duration and lowest power output while t.7 is the longest duration and the highest power output. Change the duration by turning the Flash Control Dial. The chart below shows the settings (top row) the speeds (middle row) and the color temperature (bottom row.)
setting t.1 t.2 t.3 t.4 t.5 t.6 t.7
speed 1/12,800s 1/6,400s 1/4,000s 1/2,500s 1/1,s250 1/640s 1/500s
color temperature 6200ºk 5700ºk 5500ºk 5450ºk 5450ºk 5300ºk 5300ºk
The Dynalite Baja stores extra power in the Short Duration mode. After switching back to Normal mode, discharge the Baja two or three times with the Test button.
Stroboscopic (C-Mode)
Stroboscopic Mode oers three preset ash rates ve, ten and fteen ashes in one second. Begin by setting the Flash Power Control Dial (1) to one of these Normal mode settings: 1.0 to
1.9 or 2.0 to 2.9 In the t-modes use t-1 or t-2 then press the rpt button (3) for Stroboscopic mode. The Main Display (13) will show C.1 or C.2 The rst press is ve ashes in one second,
the second press is ten ashes in one second and the third press is fteen ashes in one
second. C.1 is a lower power setting than C.2. The ash duration and color temperature for C.1 or C.2 are similar to those of t.1 and t.2 in the chart above.
8
10
Adding / Removing Modiers
The Dynalite Baja B-4 uses the very popular Bowens style accessory mount. Reectors, speed rings, snoots and many other modiers are available either directly from Dynalite or from
other manufacturers.
Press the Accessory Release (18) at the front of the Dynalite Baja B-4 back toward the Easy Carry Handle (16), twist the cover clockwise an eighth of a turn to remove it. Mount a modier
by twisting it counter clockwise until the tab locks it in place.
In the box...
Here are all the goodies that come installed in or with your new Dynalite Baja B-4 Battery Powered Flash.
 Protective Flashtube Cover
 Pyrex Flashtube Protector (installed)
 Lithium Ion Battery
 AC Battery Charger with Power Cord  BRR616 Radio Receiver  External Battery Charging Cable
18
Accessory Release
Easy Carry Handle
16
Accessories...
BRT616 Radio Transmitter controls up to 6 groups Dynalite Baja B-4 ashes on one of 16 channels.
BRT616c Canon HSS Radio Transmitter adds High Speed Sync for Canon DSLRs. Nikon version coming soon.
B4-Li Battery The Dynalite Baja B-4 delivers ve hundred full power ashes on a single charge. An extra battery
doubles that. Spare batteries are good!
BRT616c
HSS Transmitter
for Canon
11
Model Baja B4
Flash Power (w/s) 400 w/s
ƒ-Stop (Max) (ISO 100, RSH 165H, m) 32
Variable Range of Flash 6.0 ƒ-stops in 1/10 stop increments
Color Temperature 5500(±200)
Flash Duration (0.5ft) @ min:max 1/12800 : 1/500
Recycling Time 3.7 sec
Modeling Lamp 5W LED
Flash Count (Full Battery @ Max Power) 550-800* (*while charging)
Weight 6.1lbs
Dimensions (L x W x H, inches) 13.5 x 4.75 x 8.625
Battery Power Rechargeable 11.1V 8.8 Li-ion
*800 ashes with A/C charger plugged into the Baja
Specs
 400 w/s of Portable Strobe Power
• 550-800* Shots @ Full Power
• 6 ƒ-stop Range
• 1/10 ƒ-stop adjustment
 3.7 Recycle Time  High Speed Sync  Fast Flash Duration Mode  Stroboscopic Mode  Digital Display Screen  16 Channel Wireless Control  AC/DC Power Options
1050 Commerce Avenue, Union, NJ 07083 • 800.722.6638 • 908.687.8800 • ash@dynalite.com • dynalite.com
All photographs: ©2014Kevin Ames • kevin@amesphoto.com • kevinamesphotography.com
