Crimp Connector Tools
Coaxial Cable and
Connector Reference Chart
for use with the DXE-UT-KIT-CC1 and DXE-UT-KIT-CRMP2 Kits
Coaxial Cable
Preparation
Tool for Crimp
Connectors
DXE-UT-405C-P1
Dark Red
DXE-UT-240C-P1
Spruce Green
DXE-UT-405C-N1
Orange
DXE-UT-240C-N1
Fluorescent Green
Connector Type
PL-259
PL-259
Type N
Type N
BNC
Connector Part Number
DXE-
PL259CS8U
AML-
182102
AML-
182130-10
DXE-
PL259CS8X
AML-
182115-10
AML-
172102
AML-
172102H2
AML-
172135
AML-
112533
Use Die DXE-UT-
DIE-8U
DIE-8U
DIE-8U
DIE-8X
DIE-8X
DIE-8U
DIE-8U
DIE-8X
DIE-8X
Hex Crimp Center Pin*
Solder Pin
0.100
0.118
Solder Pin
0.068
0.100
0.118
0.100
0.068
Hex Crimp Ferrule*
0.429
0.429
0.429
0.255
0.255
0.429
0.429
0.255
0.255
Coax Cable Type
DXE-400MAX
XX XX XX
DXE-11U
XX
XX DXE-213U
XX
XX XX DXE-8U
XX XX XX
DXE-8X XX
XX
XX
XX
LMR-240 XX
XX
XX
XX
LMR-400
XX XX XX
LMR-400 UltraFlex
XX XX XX
RG-213
XX
XX XX
RG-8 with 12-13 AWG
center conductor
XX
XX XX
RG-8U with 10-11 AWG
center conductor
XX XX XX
RG-8X XX
XX
XX
XX
Davis RF Bury Flex™
XX XX XX
Belden 8214
XX XX XX
Belden 9913F7
XX XX XX
Belden 8237
XX
XX XX Belden 8267
XX
XX XX Belden 9258
XX
XX
( * dimensions are in inches)
Samples of coaxial cables prepped using the Coaxial Cable Preparation Tool for Crimp Connectors
DXE-UT-KIT-CC1 Complete Kit includes:
DXE-UT-405C-P1 - crimp prep tool
DXE-UT-240C-P1 - crimp prep tool
DXE-UT-405C-N1 - crimp prep tool
DXE-UT-240C-N1 - crimp prep tool
DXE-UT-RB-CC1 10 pack of Spare Cutting Blades
DXE-CGH-8U Red Coaxial Cable Gripper for RG-213 sized coaxial cable
DXE-CGH-8X Green Coaxial Cable Gripper Tool for 8X sized coaxial cable
CNL-911 Coaxial Cable Shears
DXE-170M Precision Braid Trimmer
DXE-UT-CC1-CASE Custom Hard Plastic Carry Case with Custom Cut Foam Insert
DXE-UT-KIT-CRMP2 Complete Kit includes:
DXE-UT-CRMP2 Ultra-Grip-2 Crimp Connector Hand Tool
DXE-UT-DIE-8U Crimp Die for RG-8U/213/LMR-400 size cable
DXE-UT-DIE-8X Crimp Die for RG-8X/LMR-240 size cable
DXE-UT-DIE-PP Crimp Die for Powerpole® 15, 30, 45A contact
DXE-UT-DIE-INS for insulated crimp style terminals 22-18/15-14/12-10 AWG
DXE-UT-DIE-UNIS for uninsulated crimp style terminals 20-18/16-14/12-10/8 AWG
CNL-911 Coaxial Cable Shears
DXE-170M Precision Braid Trimmer
2.5 mm Allen Wrench
DXE-CRIMP-CASE Custom Hard Plastic Carry Case with Custom Cut Foam Insert
Close up showing the various sized die opening for the
UT-DIES-8U and UT-DIE-8X
Refer to the chart for the die openings used for
the various coaxial connectors.
© DX Engineering 2021
1200 Southeast Ave. - Tallmadge, OH 44278 USA
Phone: (800) 777-0703 - Tech Support and International - (330) 572-3200
Fax: (330) 572-3279 - E-mail: DXEngineering@DXEngineering.com
DXE-CRIMP-TOOL-CONN-CHART Rev 1a
