DX Engineering DXE-MIC-ID51-52 Brochure

Professional IP-67 Mics for
PRE-RELEASE Model No. KA-ID3151
IP-67 RATED HIGH AUDIO OUTPUT REMOTE CONTROL MICROPHONE FOR ICOM ID-31/ID-51 D-STAR SERIES RADIOS
This fully compatible and versatile speaker microphone for the Icom ID-31/51 series portable transceiver is a su­perior replacement for the Icom Model HM-75LS micro­phone.
Responding to the demand for higher audio output,
Infinity Advanced Technologies has designed this mic to
provide higher audio output without the need for a pow­ered internal amplifier providing the user with more intelli­gible and louder audio when compared to the OE Icom speaker microphone.
Designed for the Amateur as well as the ARES/CAP/ CERT operator, its housing is rated as IP-67 waterproof and comes with front mounted pushbutton controls for Channel UP/DOWN and Icom A/B function customary to the original equipment Icom HM-75LS mini-mic.
Meets rugged professional specifications as is standard within the Land Mobile Radio industry sector and is de­signed with a larger housing when compared with the OE Icom HM-75LS mini-mic. The microphones form and fit is a favorite for users operating with gloves or if used in more rugged environments needing a professional micro­phone.
MICROPHONE FOR ICOM ID-31/51 RADIOS
The Innity Advanced Technologies
division of Kirmuss & Associates
designs, designs and manufactures
two way radios and communication
accessories that respond to specific
user needs as required in the most
demanding of environments, primarily for commercial and
military use.
Specifications subject to change
without notice.
Available only through exclusive
worldwide distribution.
A unique wind - baffle provides for clearer transmitting audio when used in windy environments.
Connections to the transceiver use the standard Icom right angled 2-pin connector.
The base of the mic sees installed a 3.5 mm accessory jack that may be used with external bud earpieces for use
in loud environments or for discreet communications.
Robust, a professional swivel clothing mic clip assembly provides for 360 ° rotation with positive detent stops every 45°.
A Red PTT indicator is visible.
The mic offers on average a 7-9 dB audio gain over the original Icom manufactured HM-75LS.
Comes with an 18 month warranty.
