Series DCV/RDCV Diaphragm Valves
Specifications - Installation and Operating Instructions
Bulletin V-14
DCV62T1D
DCV20C1D
The Series DCV/RDCV Dust Collection Valves are ideal for use with the Series
DCT1000 and Series DCT500 duct collection timer boards. Both the Series DCV
and RDCV have the option for either coupling or NPT connections. The coupling
connection allows for a quick and simple installation. Only the stub pipe and
blowtube need to be cleaned and deburred before the valve is fit into position. The
“T” Series DCV has female threaded connections. Both the “C” and “T” versions
have a 90° angle between the inlet and outlet the most suitable configuration for
pulse valve applications. The design offers not only ease of installation, but also
minimal airflow restriction for an exceptional cleaning pulse. The valves are offered
in both integrated and remote coil configurations.
Model
RDCV20T
RDCV20C
DCV20T1D
DCV20C1D
RDCV25T
RDCV25C
DCV25T1D
DCV25C1D
RDCV35T
RDCV35C
DCV35T1D
DCV35C1D
RDCV45T
RDCV45C
DCV45T1D
DCV45C1D
RDCV50T
DCV50T1D
RDCV62T
DCV62T1D
RDCV76T
DCV76T1D
*110 VAC with DIN Connector
Size
3/4˝
1˝
1-1/2˝
1-1/2˝
2˝
2-1/2˝
3˝
Solenoid
Remote
Remote
Integral*
Integral*
Remote
Remote
Integral*
Integral*
Remote
Remote
Integral*
Integral*
Remote
Remote
Integral*
Integral*
Remote
Integral*
Remote
Integral*
Remote
Integral*
Connection
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
Coupling
NPT
NPT
NPT
NPT
NPT
NPT
Number of
Diaphragms
1
1
1
2
2
2
2
Cv Factor
(gal/min)
14
23
42
51
106
136
167
RDCV62T
RDCV20C
SPECIFICATIONS
Service: Compatible gases, filtered and oil free.
Wetted Materials: Body: aluminum; Trim: 304 SS; Diaphragm and seals: NBR;
Diaphragm disc: polyamide.
Other Materials: Cover: aluminum; Body bolts and spring: 304 SS.
Pressure Limits: Minimum of 4.4 psi (0.3 bar), maximum of 124.7 psi (8.6 bar).
Temperature Limits: Ambient: -4 to 140°F (-20 to 60°C) for RDCV models, -4 to
122°F (-20 to 50°C) for DCV models; Operating: -4 to 185°F (-20 to 85°C).
Power Requirements: 110 VAC, 220 VAC, or 24 VDC for DCV models.
Power Consumption: 12 W, inrush: 17 VA; holding: 14.5 VA for DCV models.
Electrical Connection: DIN connection for DCV models.
Enclosure Rating: NEMA 4X (IP65) for DCV models.
Process Connection: See model chart.
Mounting Orientation: Any position.
Series DCV/RDCV Model Guide
Construction
Size
Connection
Voltage
Electrical
Connections
DCV
RDCV
20
25
35
45
50
62
76
Integrated Coil
Remote Coil
3/4˝
1˝
1-1/2˝
1-1/2˝ (2 Diaphragms)
2˝
2-1/2˝
3˝
NPT
T
Coupling (up to 1-1/2˝ only)
C
110 VAC (for integrated coil only)
1
220 VAC (for integrated coil only)
2
24 VDC (for integrated coil only)
3
DIN (for integrated coil only)
D
DWYER INSTRUMENTS, INC.
Phone: 219/879-8000 www.dwyer-inst.com
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: 219/872-9057 e-mail: info@dwyermail.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
C WIDTH
RDCV20T
RDCV25T
R
DCV35T
RDCV20C
RDCV25C
R
DCV35C
C WIDTH
C WIDTH
RDCV45TM
RDCV45CM
C WIDTH
C WIDTH
RDCV50TM
RDCV62TM
RDCV76TM
C
CV Dimensional Chart
C WIDTH
C
WIDTH
C WIDTH
C
C WIDTH
C
C WIDTH
D
Connection
NPT
Model
IN Electrical Connection
D
CV20T1D
D
CV25T1D
D
CV35T1D
D
DCV45T1D
DCV50T1D
DCV62T1D
DCV76T1D
oupling
C
DCV20C1D
DCV25C1D
DCV35C1D
CV45C1D
D
CV20T2D
D
CV25T2D
D
CV35T2D
D
DCV45T2D
DCV50T2D
DCV62T2D
DCV76T2D
DCV20C2D
DCV25C2D
DCV35C2D
CV45C2D
D
CV20T3D
D
CV25T3D
D
CV35T3D
D
DCV45T3D
DCV50T3D
DCV62T3D
DCV76T3D
DCV20C3D
DCV25C3D
DCV35C3D
CV45C3D
D
ead Wires Electrical Connection
L
CV20T1L
D
CV25T1L
D
CV35T1L
D
DCV45T1L
DCV50T1L
DCV62T1L
DCV76T1L
CV20C1L
D
CV25C1L
D
CV35C1L
D
DCV45C1L
CV20T2L
D
CV25T2L
D
DCV35T2L
DCV45T2L
DCV50T2L
DCV62T2L
CV76T2L
D
DCV20C2L
DCV25C2L
CV35C2L
D
CV45C2L
D
CV20T3L
D
CV25T3L
D
CV35T3L
D
DCV45T3L
DCV50T3L
DCV62T3L
DCV76T3L
CV20C3L
D
CV25C3L
D
CV35C3L
D
DCV45C3L
(A mm)
A
-15/16˝ (100)
3
-1/8˝ (105)
4
5-1/8˝ (130)
5-1/8˝ (130)
8-1/16˝ (205)
8-9/32˝ (210)
8-19/32˝ (218)
4-13/32˝ (112)
4-5/8˝ (117)
5-13/16˝ (147)
-25/32˝ (147)
5
B (B mm)
4-13/16˝ (122)
4-31/32˝ (126)
6-1/16 (154)
-7/32˝ (183)
7
-29/32 (201)
7
-3/4˝ (222)
8
9-7/8˝ (251)
5-27/32˝ (148)
6-21/32˝ (177)
7-21/32˝ (194)
-27/32˝ (224)
8
(C mm)
C
-7/16˝ (87)
3
-1/4˝ (83)
3
4-3/8˝ (111)
4-3/8˝ (111)
7-1/4˝ (184)
7-1/4˝ (184)
7-7/8˝ (200)
3-7/16˝ (87)
3-1/4˝ (83)
4-3/8˝ (111)
-3/8˝ (111)
4
D (D mm)
2-3/16˝ (56)
2-1/2˝ (64)
-1/2˝ (114)
4
-1/2˝ (114)
4
-15/32˝ (113)
4
4-21/32˝ (118)
4-21/32˝ (118)
2-5/8˝ (67)
3˝ (76)
-5/8˝ (91)
3
-5/8˝ (91)
3
E (E mm)
5/32˝ (20)
2
/8˝ (22)
7
-9/32˝ (33)
1
1-9/32˝ (33)
1-9/16˝ (40)
1-29/32˝ (48)
2-1/2˝ (63)
1-25/32˝ (45)
2-3/4˝ (70)
3˝ (76)
˝ (76)
3
RDCV Dimensional Chart
Connection
NPT
Coupling
Model
RDCV20T
RDCV25T
RDCV35T
RDCV45T
RDCV50T
RDCV62T
RDCV76T
RDCV20C
RDCV25C
RDCV35C
RDCV45C
A (A mm)
3-15/16˝ (100)
4-1/8˝ (105)
5-1/8˝ (130)
5-25/32˝ (147)
8-1/16˝ (205)
8-9/32˝ (210)
8-19/32˝ (218)
4-13/32˝ (112)
4-5/8˝ (117)
5-13/16˝ (147)
5-25/32˝ (147)
B (B mm)
2-31/32˝ (75)
3˝ (76)
4-29/32˝ (125)
5-5/32˝ (131)
5-7/8˝ (149)
6-11/16˝ (170)
7-27/32˝ (199)
4˝ (102)
5˝ (127)
5-15/32˝ (139)
6-25/32˝ (172)
C (C mm)
3-7/16˝ (87)
3-1/4˝ (83)
4-3/8˝ (111)
4-3/8˝ (111)
7-1/4˝ (184)
7-1/4˝ (184)
7-7/8˝ (200)
3-7/16˝ (87)
3-1/4˝ (83)
4-3/8˝ (111)
4-3/8˝ (111)
D (D mm)
2-3/16˝ (56)
2-1/2˝ (64)
4-1/2˝ (114)
3-5/8˝ (91)
4-15/32˝ (113)
4-21/32˝ (118)
4-21/32˝ (118)
2-5/8˝ (67)
3˝ (76)
3-5/8˝ (91)
3-5/8˝ (91)
E (E mm)
25/32˝ (20)
7/8˝ (22)
1-9/32˝ (33)
3˝ (76)
1-9/16˝ (40)
1-29/32˝ (48)
2-1/2˝ (63)
1-25/32˝ (45)
2-3/4˝ (70)
3˝ (76)
3˝ (76)
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
PERATION
O
eries DCV includes an integral solenoid and Series RDCV needs to be used with
S
remote pilot solenoid valve. Both are normally closed valves. When the remote
a
ilot solenoid valve or integral solenoid opens, pressure is released (exhausted)
p
from the top of the diaphragm in the pulse valve. This allows the line pressure on
the bottom of the diaphragm to push the diaphragm up and open the main orifice
of the pulse valve. When the solenoid then closes the pressure on the bottom and
he top of the diaphragm equalize closing the main orifice of the pulse valve.
t
NSTALLATION
I
OCATION
L
elect a location that will not exceed the ambient temperature specifications of the
S
valve. The system must be located in an enclosure that meets relevant safety
standards and electrical codes of the environment.
MOUNTING
he DCV/RDCV can be mounted in any position. For optimum life and performance
T
t is recommended that the unit be mounted vertically and upright to reduce the
i
hance of foreign matter accumulating in the valve. For DCV in weatherproof
c
applications it is recommended that the cable gland be positioned face down to
avoid possible rainfall or water from entry.
PROCESS CONNECTIONS
or DCV/RDCV with coupling connections:
F
. Connect piping so that pneumatic input is the bottom connection and the outlet
1
s the side connection at 90°.
i
2. Stub pipe (blow tube) must be free of burrs, rust, oil, and other debris.
3. Disassemble compression fittings and place the retaining nut, retainer, and gas
ket onto the piping. Make sure that the beveled edge of the gasket faces the
valve body.
4. Connect fittings to the valve body. Make sure that the pipe is inline with the valve
ports. Nut and seals are for connection only and should not be used for support
purposes.
arning: Before installation make sure all air pressure has been
W
released, electric power has been turned off, and air pressure source
has been closed. Turn power on and increase pressure only after
installation is complete.
iring Connections
W
For DCV units)
(
ire in accordance with the National Electrical Code and local regulations. To aid
W
n wiring the solenoid on the DCV may be rotated 360°. It is recommended to use
i
18 AWG copper wire rated at 90°C or greater.
Wiring the DCV with DIN connector. See Figure 1.
. Remove center screw and pull wiring assembly from the body.
1
. Remove gasket and place small screwdriver in slot to pry out the terminal block
2
rom the cover.
f
. Thread wire through the gland nut, gland gasket, washer and connector cover.
3
4. Connect wires to proper terminals on the terminal block.
5. Snap terminal block back into the cover. The connector cover may be rotated in
90° increments to position the cable entry as needed for the application.
einstall the center screw and screw back into the solenoid body.
R
AINTENANCE
M
Warning: To prevent the possibility of death, serious injury or property damage, turn
off electrical power, depressurize system and unit, and vent fluid to a safe area
before servicing.
The DCV/RDCV should be cleaned periodically. The amount of time between
leanings depends on the application. Preventive Maintenance includes keeping
c
edia clean of material and oil free, and periodic testing to ensure proper operation
m
nd to look for wear or damage. Replacement diaphragm assemblies are available
a
from the factory.
Notes:
• Make sure pipes are anchored securely to avoid separation from the valve.
• Do not use the valve for leverage when connecting piping.
• Do not over-tighten retaining nut or valve damage may result. Tighten retaining
nuts just sufficiently for sealing to prevent leakage. This is a gasket seal and does
not require excessive turning of the nut.
For DCV/RDCV with NPT connections:
1. Connect piping so that pneumatic input is the bottom connection and the outlet
is the side connection at 90°.
2. Stub pipe (blow tube) must be free of burrs, rust, oil, and other debris.
3. Thread piping into the valve body. Make sure that the pipe is inline with the valve
ports. If using tape or pipe compound, apply to the male piping threads and use
sparingly as it may come loose and affect valve operation. Do not apply tape or
pipe compound directly to the female valve body threads.
Notes:
• Make sure pipes are anchored securely.
• Do not use the valve for leverage when connecting piping.
Pressure Connection from Remote Pilot Solenoid Valve
(For RDCV units)
The RSV, remote pilot solenoid valve, should be mounted as close as possible to
the RDCV pulse valve. The maximum distance is 9.8 ft (3 m). Tubing from the
remote solenoid valve is connected to the exhaust port on the top of the RDCV
pulse valve. If using tape or pipe compound, apply to the male piping threads and
use sparingly as it may come loose and affect valve operation. Do not apply tape
or pipe compound directly to the female valve body threads.
Figure 1
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
olenoid Valve Troubleshooting
S
roblem
P
o pulse
N
Leakage in outlet port
ow pulse
L
haking noise
S
olenoid noise
S
WARRANTY
The Series DCV/RDCV is not field serviceable and should be returned if repair is
needed (field repair should not be attempted an may void warranty). Be sure to
nclude a brief descr iption of the problem plus any relevant applicatio n notes.
i
ontact customer service to receive a return goods authorization number before
C
hipping.
s
Possible Cause
o supply air
N
ir pressure is too high
A
o voltage to RSV
N
olenoid is damaged
S
Improper installation of inlet port
Low air pressure
alve screws are loose
V
olenoid mounting screws are loose
S
Action Required
heck whether the air compressor and valve have been turned on
C
heck the pressure of the air supply
C
heck supply voltage
C
end back for evaluation
S
Check the pipe connections between the inlet and outlet
Check air supply pressure
Verify that the air supply was distributed properly
ighten the loose screws
T
ighten the loose screws
T
©Copyright 2014 Dwyer Instruments, Inc. Printed in U.S.A. 9/14 FR# RV-443335-01 Rev. 2
DWYER INSTRUMENTS, INC.
Phone: 219/879-8000 www.dwyer-inst.com
P.O. BOX 373 • MICHIGAN CITY, INDIANA 46360, U.S.A. Fax: 219/872-9057 e-mail: info@dwyermail.com
Find Quality Products Online at: sales@GlobalTestSupply.com
www.GlobalTestSupply.com
Loading...
