Page 1

Jasmine

❍❍❍

Bathroom Vanity & Sconce 3000K

Model & Size

WS-77127

Example: WS-77127-BK

27" 3000K 90 8W 1000 504 BK Black

DESCRIPTION

Irresistibly attractive. Wrapped around her little finger.

FEATURES

• Frosted silicone diffuser with 360 degree illumination

• Oval backplate

• Driver concealed within the canopy

• 5 year warranty

SPECIFICATIONS

Color Temp:

Input:

CRI:

Dimming:

Rated Life:

Mounting:

Standards:

Construction:

REPLACEMENT PARTS

HDW-HY21-WA - Hardware Pack

Color Temp & CRI

3000K

120/277 VAC, 50/60Hz

ELV: 100-10%, TRIAC: 100-10%

50000 Hours

Can be mounted on wall in all orientations

ETL, cETL, Title 24: 2019

Damp Location Listed

Aluminum body, silicone diffuser

Watt

LED Lumens

Delivered Lumens

FINISHES

Fixture Type:

Catalog Number:

Project:

Location:

Finish

CH Chrome

Black Chrome

LINE DRAWING

waclighting.com | Phone (800) 526.2588 | Fax (800) 526.2585 | Headquarters/Eastern Distribution Center 44 Harbor Park Drive Port Washington, NY 11050

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. February 2021
