Duronic BL10 User Manual
Blender Model: BL10
Creative
Consumer
Products
2 3
English Manual
Manuel d’utilisation en Français
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
5
15
25
35
Contents
4 5
English Manual
6 7
Main Part
1.Feeding cover
2.Spatula
3.Lid
4.Blender/stir jar
5.Blade
6.Blending knife stand
7.Main machine
Product Features
1. The functions of mixing, grinding, meat chopping, while also equipped with one-click
pulse switch, milkshakes and ice function keys, meet a variety of needs.
2. Using transparent glass jar, cap feeding, products can be observed clearly.
3. Innitely variable speeds adjustment function, meet the demand of various speed,
with the high-grade generous electroplating knob.
4. Security and protection of franchising switch design, operate more secure, more at
ease.
5. Detachable blade, easy to clean; In addition to the main machine, all parts are
available for a dishwasher to clean.
6. Convenient spatula to ensure ingredients mix well.
Safety Tips
1. Please do not let children operate
the machine.
2. Before power supply is switched on, please check whether the machine
indicate voltage is consistent with the local voltage.
3. If the power cord plug is damaged, please don’t use the product, refer to
Duronic Customer Service at sales@duronic.co.uk
4. Before turning the machine on, please make sure to all parts installed correctly;
5. Before disassembling any attachments or adjusting the blenders position , please
remove the plug.
6. Before cleaning any parts of the machine, please unplug the machines power plug;
7. Do not put the main motor part into water or any other liquid, do not rinse under the
tap. Please use wet cloth to wipe instead.
8. Please do not leave the product blending for long periods of time without supervision.
In order to to prolong the blender’s life span, take intermittent stops after every min.
9. When blending the ingredients, do not exceed the markings on the jar.
10. Please disassemble the blender before attempting to clean.
11. After use, please stow away blender out of the reach of children
12. Do not place the cutter holder without screwing the glass alone on the main
machine, so as to avoid accidents.
13. When the machine is working do not insert your ngers or other body parts into the
mixing jar.
14. The machine blade is very sharp, washing up gloves are required when cleaning.
15. When cleaning the blade, please refer to the section “ cleaning”.
8 9
17. When you have nished using the machine, please remember unplug the unit.
18. This product uses a stainless steel blade.
19. This product has a glass mixing jar. Please note when the
washing the jar, water temperature must be warm and not cold.
Installation
1. Clean all parts which contact with food.
2. Blender assembly shown below:
Scope of application
The Mixing/blending components are suitable for stirring, mixing, crushing fruit,
vegetables, nuts and other kinds of food raw materials and condiments. Make all kinds
of fruit juice, crushed ice, milkshakes, beverage, seasoning liquor, soup, porridge,
paste, juice, sauce etc. Can also be used to mix ingredients for health and beauty, such
as face mask, etc.
Tips For Use
1. If you want to quickly process the ingredients , you can press P button (pulse).
Release the button to stop.
2. If you want to do milk-shake or smoothie, you can press the milkshake button. Press
twice to stop.
3. If you want to crush ice, you can press ice button. To stop, press twice.
Note: if you want to crush the ice to snowake form, you should choose the highest
speed or continually press the P button for a few seconds. If the ice is still very thick,
can press the P button to crush again.
Cleaning
1. Close the machine and unplug the power plug.
2. All removable parts must be removed before cleaning.
Quick Clean Mixing Jar
1.Fill the jug halfway with water, then add a few drops of washing up liquid.
2.Turn control knob switch to ON, then press the P button several times in a row.
3.Remove the mixing jar and empty it, wash down with tap water.
Tips: All removable parts are (excluding the motor base) is dishwasher safe.
Note: please don’t use steel wool/wire, corrosive cleaning solvents or corrosive solution
to clean.
Safety Tips
10 11
Food Preparation
You can be in a very short period of time to make all kinds of fruit juices, smoothies,
milkshakes, beverage, liquor, soup, porridge, paste food, juice, sauce and so on
characteristics foods.
In order to let you know the possibilities, we have listed some below;
• 1 banana, sliced
• 150g (5 oz) green grapes
• 1 (200g) tub vanilla yoghurt
• 1/2 apple, cored and chopped
• 50g (2 oz) fresh spinach leaves
Green Smoothie
• 8 strawberries, hulled
• 110ml (4 oz) skimmed milk
• 120g (4 oz) low-fat plain yoghurt
• 3 tablespoons demerara sugar
• 1 to 2 teaspoons vanilla extract
• 6 cubes ice, crushed
Classic Strawberry Smoothie
• 400g/14oz peeled and chopped ripe mango
• 2 x 125g pots fat-free mango yogurt
• 250ml skimmed milk
• juice 1 lime
• 4 passion fruits, halved
Mango and Passion fruit Smoothie
• 3 Tbsp water
• 1 green tea bag
• 2 tsp honey
• 1½ c frozen blueberries
• ½ med banana
• ¾ c calcium fortied light vanilla soy milk
Green tea, Blueberry and Banana Smoothie
Problem Solutions
Blender does not work
Please check whether the jug is tted
securely to the motor base. If it is not, then
the blender will not switch on. Also check if
unit is plugged into mains socket
Motor device emits a burning smell
when in use
As this blender is brand new from the factory
and never used, a slight odor or smoke smell
emitting is a normal phenomenon. fter using
a few times this will disappear.
Jar Leakage
Shut down, move the jar to pour out of
the raw material, then counterclockwise to
unscrew the blade device. Check whether
the seal is correctly installed in the stirring
knife base device.
Can I boil soup?
This blender can be used to make soup.
However it is very important that you allow
the jug to cool down before washing with
warm water, NOT cold.
Is the blender dishwasher-safe?
Do not use the dishwasher for the following:
Motor Base, Blade and ring seal.
Only the glass jar and lid are dishwasher
safe.
I was using the blender for a while until
is suddenly stopped?
To prolong the working life of the machine,
the motor a over-heat temperature protection
feature. Once the motor runs for a long time
and heats up as a result, it will automatically
power off. After the machine stops working,
you must unpin the plug and wait for the
motor to cool down before using again.
Cooldown time is 60 mins.
Problems & Solutions
