About this operating manual

1 About this operating manual

This operating manual for the special sewing machines 512 and 532 was compiled with the utmost care. It contains information and notes in order to make long-term and reliable operation possible.

Should you notice any discrepancies or if you have improvement requests, then we would be glad to receive your feedback,  4.11

Customer service.

Consider this operating manual part of the product and keep it on hand at all times. Be sure to read the manual completely before using the product for the first time. Only give the product to someone else along with the operating manual.

1.1 Scope

This operating manual describes the set-up and intended use of the special sewing machines 512 and 532.

1.2 For whom is this operating manual?

This operating manual is for:

• Operators: This group of employees has been trained in operating the machine and can access the operating manual. Specifically,  4 Operation is intended for this group.

• Technicians: This group of employees has the appropriate technical training allowing them to perform maintenance on the sewing unit or to repair faults. Specifically,  8 Setup is intended for technical personnel. Service instructions are supplied separately.

With regard to minimum qualification and other requirements to be met by the personnel, please also observe  3 Safety instructions.

Operating Manual 512/532 Version 00.0 - 12/2013 5

About this operating manual

2. ...

•



1.3 Representation conventions – symbols and characters

Various information in this operating manual is represented or highlighted by the following characters in order to facilitate easy and quick understanding:

Correct setting

Indicates proper setting.

Malfunctions

Specifies the faults that can occur due to an incorrect setting.

Steps to be performed when operating the machine (sewing and equipping)

Steps to be performed for servicing, maintenance, and installation

Steps to be performed via the software control panel

The individual steps are numbered:

1. First step

2. Second step

The sequence of the steps must always be followed.

Lists are identified by bullet points.

Result of performing an operation

Change to the machine or in the display.

Important

Special attention must be paid to this point when performing a step.

Operating Manual 512/532 Version 00.0 - 12/20136

About this operating manual

Information

Additional information, e. g. on alternative operating possibilities.

Order

Specifies the work to be performed before or after a setting.

References

 Reference to another section in the manual.

Safety Important warnings for the machine operator are specially

designated. Since safety is of particular importance, hazard symbols, levels of danger and their signal words are described separately in  3 Safety Information.

Orientation Information on where something is positioned using the terms

“right” or “left” must always be regarded from the operator's point of view if the figure gives no other obvious indication for determining the location.

1.4 Other documents

This equipment includes components from other manufacturers. Each manufacturer has performed a hazard assessment for these purchased parts and confirmed their design compliance with applicable European and national regulations. The proper use of these components is described in each manufacturer's manual.

Operating Manual 512/532 Version 00.0 - 12/2013 7

About this operating manual

1.5 Liability

All information in this operating manual was compiled with consideration to the state of the art, and applicable standards and regulations.

The manufacturer cannot be held liable for damages resulting from:

• Breakage and transport damages

• Failure to observe operating manual

• Improper use

• Unauthorized modifications to the machine

• Use of untrained personnel

• Use of unapproved replacement parts

1.5.1 Transport

Dürkopp Adler cannot be held liable for breakage and transport damages. Inspect the delivery immediately upon receiving it. Report any damage to the last transport manager. This applies even if the packaging is undamaged.

Leave machines, equipment and packaging material in the condition in which they were found when the damage was discovered. This will ensure any claims against the transport company.

Report all other complains to Dürkopp Adler immediately after receiving the product.

1.5.2 Proper use

The Dürkopp Adler 512/532 is intended for sewing light to moderately heavy material.

The machine is only intended for use with dry material. The material cannot contain any hard objects.

The seam is produced using core spun threads, polyester fibers, or cotton threads.

Class 512 thread strength of dimensions 50/3 - 130/3 Class 532 thread strength of dimensions 50/3 - 150/3 The sewing machine is intended for industrial use.

Operating Manual 512/532 Version 00.0 - 12/20138

About this operating manual

The machine may only be set up and operated in dry conditions on well-maintained premises. If the machine is operated on premises that are not dry and well-maintained, then further measures may be required which must be compatible with EN 60204-31:1999.

Only authorized/trained personnel may operate the machine.

The manufacturer cannot be held liable for damages resulting from improper use.

ATTENTION Improper use can result in property damage.

Please observe all instructions in the manual.

WARNING

Risk of electric shock, crushing and punctures!

Improper use can result in injury. Please observe all instructions in the manual.

Operating Manual 512/532 Version 00.0 - 12/2013 9

About this operating manual

Operating Manual 512/532 Version 00.0 - 12/201310

Technical Specifications

2 Technical Specifications

The Dürkopp Adler 512 is a CNC double lockstitch bartack sewing machine. Die Dürkopp Adler 532 is a button sewing machine.

2.1 Characteristics of the 512

The existing programs are scalable and can be saved in this modified form. The machine is equipped with an automatic sewing foot lifter, thread cutter, thread wiper, a needle thread clamp below the stitch plate for reliable sewing-on and an integrated DC direct drive including an operating panel.

Technical features

• The sewing machine is driven by an integrated positioning

drive. A controller controls the sewing drive and also 2 stepper motors for the X and Y motions required for generating the seam geometry.

• The clamps are raised by a stepper motor.

• The maximum size of the sewing field is 40 mm in the X

direction (lateral to the arm) and 30 mm in the Y direction (parallel to the arm).

• The upper section is oil-free. This means that there is no

danger of soiling the sewn material with oil.

• The hook is lubricated by a wick lubrication system, fed from a

reservoir visible to the operator.

• 50 pre-programmed bartacks are available. The standard

patterns can be temporarily modified (changes to the total length, total width, speed). When the machine is switched off, the modified values of the most recently used bartack are restored when the machine is switched on again.

• 50 additional modified standard patterns can also be stored.

• A maximum of 16,000 stitches can be stored.

• 25 sequence programs with up to 30 seam appearances per

sequence can be stored.

• The coordinate entry system has an accuracy of 0.1 mm.

• The machine has a bobbin thread decrementing counter and a

daily item counter.

• The arm shaft is directly driven by a brushless DC motor.

• Speeds of up to 3000 min

-1

can be set, in 100 min-1 steps.

Operating Manual 512/532 Version 00.0 - 12/2013 11

Technical Specifications

2.2 Characteristics of the 532

Technical features

• The sewing machine is driven by an integrated positioning

drive. A controller controls the sewing drive and also 2 stepper motors for the X and Y motions required for generating the seam geometry.

• The clamps are raised by a stepper motor.

• The maximum size of the sewing field is 40 mm in the X

direction (lateral to the arm) and 30 mm in the Y direction (parallel to the arm).

• The upper section is oil-free. This means that there is no

danger of soiling the sewn material with oil.

• The hook is lubricated by a wick lubrication system, fed from a

reservoir visible to the operator.

• A maximum of 33 pre-programmed standard button patterns

are available. These standard patterns can be temporarily modified (changes to the total length, total width, speed). When the machine is switched off, the modified values of the most recently used bartack are restored when the machine is switched on again.

• A maximum of 16,000 stitches can be stored.

• 25 sequence programs with up to 30 seam appearances per

sequence can be stored.

• The coordinate entry system has an accuracy of 0.1 mm.

• The machine has a bobbin thread decrementing counter and a

daily item counter

• The arm shaft of the button sewing machine is directly driven

by a brushless DC motor.

• Speeds of up to 3000 min

• Up to 10 user-defined button patterns can be programmed

and stored.

• A total of 50 button patterns can be stored under the

25 favorite buttons.

-1

can be set, in 100 min-1 steps.

Operating Manual 512/532 Version 00.0 - 12/201312

Technical Specifications

2.3 Declaration of conformity

The machine complies with the European regulations specified in the declaration of conformity or in the installation declaration.

2.4 Technical data

Class 512 532

Stitch type 301 301

Hook type Oscillating hook Oscillating hook

Number of needles 1 1

Needle system 134 | DPx5 135x17 | DPx17

Needle thicknesses 80 - 130 | 12 - 20 80 - 110 | 12 - 18

Stitch length [mm] Depends on seam

appearance

(0.1 - 10 mm)

Max. speed

Speed on delivery

Sewing field size [mm] max. in X direction: 40

Number of standard patterns 50 33

Number of storable modified patterns

Number of sequences 25 25

Number of seam appearances per sequence

Soft start Can be switched

Operating Manual 512/532 Version 00.0 - 12/2013 13

[min

-1

]

-1

]

max. in Y direction: 30

3000 3000

2700 2700

50 50

30 30

in and out

Depends on seam

appearance

(0.1 - 10 mm)

max. in X direction: 40 max. in Y direction: 30

Can be switched

in and out

Technical Specifications

Class 512 532

Operating pressure [bar] -- --

Air consumption [NL] -- --

Length, width, height (upper section incl. packaging)

Length, width, height (upper section only)

Weight (upper section, excluding controller)

Length, width, height (controller incl. packaging)

Weight (controller only) [kg] 18 18

[mm] 870 /430 / 890 870 /430 / 890

[mm] 660 / 230 / 430 660 / 230 / 430

[kg] 69 69

[mm] 600 / 450 / 300 600 / 450 / 300

Dimensional data

Class 512 532

Voltage [V] 230 230

Frequency [Hz] 50 / 60 50 / 60

Power [W] 500 500

Operating Manual 512/532 Version 00.0 - 12/201314

Safety Information

3 Safety Information

This section contains basic information for your safety. Read the instructions carefully before setting up or operating the machine. Make sure to follow the information included in this section. Failure to do so can result in serious injury and damage to the machine.

3.1 Basic safety instructions

The machine may only be used as described in this operating manual.

The operating manual should be available at the machine's location at all times.

Work on live components and equipment is prohibited. Exceptions are defined in the specifications in DIN VDE 0105.

For the following work, the machine must be disconnected from the power supply using the main switch or by disconnecting the power plug:

• Replacing the needle or other sewing tools

• Leaving the workplace

• Performing maintenance work and repairs

Missing or faulty spare parts could impair safety and damage the machine. Make sure you only use original replacement parts from the manufacturer.

Transport Use a sturdy lifting carriage or forklift for transporting the machine.

Raise the machine max. 20 mm and secure it against slipping off.

Setup The power cable must have a plug authorized for the country in

which the machine is being used. The power plug may only be connected to the power cable by a qualified specialist.

Operating Manual 512/532 Version 00.0 - 12/2013 15

Safety Information

Obligations

of the operator

Observe the country specific safety and accident prevention regulations and the legal regulations concerning industrial safety and the protection of the environment.

All warnings and safety signs on the machine must always be in legible condition and may not be removed. Missing or damaged labels should be replaced immediately.

Requirements to

The machine should only be set up by qualified technicians.

be met by the

personnel

Maintenance work and repairs should only be carried out by qualified technicians.

Work on electrical equipment may only be carried out by qualified specialists.

Only authorized persons may work on the machine. Every person who works on the machine must have read the operating manual first.

Operation Inspect the machine while in use for any externally visible damage.

Stop working if you notice any changes to the machine. Report any changes to your supervisor. A damaged machine should no longer be used.

Safety

equipment

Safety equipment should not be removed or deactivated. If this cannot be avoided for a repair operation, the safety equipment must be refitted and put back into service immediately afterwards.

Operating Manual 512/532 Version 00.0 - 12/201316

Safety Information

3.2 Signal words and symbols used in warnings

Warnings in the text are distinguished by color bars. The color scheme is oriented towards the severity of the danger. Signal words indicate the degree of risk:

Signal words Signal words and the endangerment that they describe:

Signal word Endangerment

DANGER Will result in serious injury or death.

WARNING Can result in serious injury or death.

CAUTION Can result in minor or moderate injury.

ATTENTION Can result in property damage.

Symbols The following symbols indicate the type of risk to personnel:

Symbol Type of danger

General risk

Risk of electric shock

Risk of puncturing

Risk of crushing

Examples Examples of the layout of the warnings in the text:

Operating Manual 512/532 Version 00.0 - 12/2013 17
