DURKOPP 1230i - 6 Parts List
Spare parts list
1230i - 6
Minerva Boskovice, a.s., Sokolská 60, CZ - 680 17 Boskovice
Tel.: +420-516-453434, 453433, 494111 Fax: +420-516-452165 http://www.minerva-boskovice.com
Edition/Vydáno: 11/2005 Printed in Czech Republic/Tisk : Èeská republika S735 000714
How to read the spare parts list :
- The list is grouped according to construction modules. A module is a group of parts fulfilling in the machine a concrete
function. The abbreviated module designation is given in the left top corner both of the drawing and of the text. The complete
module designation (as given in the delivery note) is related to the abbreviated designation as follows:
Abbreviated Complete
M XXX = S980 000XXX
Items in the order are presented under complete code (ten-digit number)
- This catalogue is common for a number of machine models whose type designation agrees with the first five digits printed
on the catalogue cover. The complete type designation of the machine is then used for identifying the modules (lists
of parts)mounted on the machine in question.
The complete type designation has the following structure:
XXXX - XXX - XXX
Class Subclass Sewing category
The contents is divided into sections corresponding to this structure. A table situated at the head of each section gives
information on which modules are applied to a particular machine model. The machine class and subclass are printed on the
label situated on the machine bed plate and visible with tilted machine head. The sewing category is indicated on the tag
supplied together with the machine.
- All items, the complete code (ten-digit number) of which are presented in the tables there is possible to order as spare parts.
- The symbol shows that the part is to be lubricated by grease (used for the machine assembly).
- The symbol shows that the part is glued (used for the machine assembly).
Parts marked in the drawings with the symbol * and with the remark * SPARE PARTS SUPPLIED WITH THE MACHINE
are attached with head of machine.
CONTENTS :
Modules of machine head and of enclosed accessories
Abbreviated Ordering (complete) Denomination Table No.
module No. module No.
Class (modules identical for all subclasses)
M 501 Machine arm 1
M 534 Bed plate 2
M 537 Universal part group for flat bed machines 3
M 551 Needle and thread mechanism 4
M 517 Thread tensioner plate 5
M 075 Hook box 6
M 538 Bottom feed 7
M 522 Hook lubrication 8
M 514 Lubrication 9
Subclass
- Table of subclasses 10
M 820 Sewing hook (for right needle) 11
m 821 Sewing hook (for left needle) 12
M 552 S980 000552 Electromagnetically controlled presser foot lifting 13
M 084 S980 000084 Thread trimmer 14
M 519 S980 000519 Thread trimmer drive 15
M 249 S980 000249 Electromagnetically controlled backtacking 16
M 521 S980 000521 Push-button panel 17
M 008 S980 000008 Electrical switch board 18
M 520 S980 000520 Parts for machine without trimming 37
Abbreviated Ordering (complete) Denomination Table No.
module No. module No.
Parts sets
- Table of parts sets 19
1200 001000 Parts set for V-belt drive (clutch motor) 19
1200 007000 Parts set for V-belt drive (stopmotor EFKA) 19
1200 007100 Parts set for V-belt drive (without stopmotor) 19
1200 009000 Parts set for indented belt drive (minimotor EFKA) 19
1200 009100 Parts set for indented belt drive (without minimotor ) * 19
Sewing equipment
1230 E60300 Sewing set 31
Optional equipments
M 010 S980 000010 Lighting 32
Z 012 S794 222012 Lighting halogen (12 V, 20 W - contains transformer) 33
M 198 S980 000198 Sewn work guide 34
M 018 S980 000018 Sewn work guide 35
M 149 S980 000149 Sewn work guide 36
M 242 S980 000242 Adjustable gauge 37
*Delivery is possible with another minimotor than EFKA.
Table of subclasses machines and remove modules
Module
Sewing hook
Classe- M 820 M 821 M 008 M 552 M 084 M 520 M 519 M 249 M 521
subclasse
1230i - 611
1230i - 647
•
••
Sewing hook
•
•
Electrical switch board
presser foot lifting
Electromagnetically controlled
Thread trimmer
Set of parts
•
••
backtacking
Thread trimmer drive
Electromagnetically controlled
•
••
Push-button panel
Table of parts sets
(delivered with head of sewing machine)
Parts Cover of belt Knee lever Connecting Standard Special Set for Enlarged
set cable accessories accessories mini-stop bobbin stand
1230 001000 M 265 tab.20 M 070 tab.22 M 015 tab.26 M 179 tab.27 M 016 tab.30
1230 007000 M 265 tab.20 M 070 tab.22 M 163 tab.23 M 015 tab.26 M 179 tab.27 M 016 tab.30
1230 007100 M 265 tab.20 M 070 tab.22 M 055 tab.37 M 015 tab.26 M 179 tab.27 M 016 tab.30
1230 009000 M 267 tab.21 M 070 tab.22 M 301 tab.24 M 015 tab.26 M 255 tab.28 M 300 tab.29 M 016 tab.30
1230 009100 M 267 tab.21 M 070 tab.22 M 325 tab.25 M 015 tab.26 M 255 tab.28 M 300 tab.29 M 016 tab.30
M 501
61
56
54
4
4
4
3
6
6
5
53
54
55
60
57
59
12
50
4
94
93
41
40
41
24
16
111
95
112
29
29
107
107
15
30
36
9
37
20
14
13
2
35
7
26
31
31
32
32
10
8
2
87
117
117
118
28
18
19
19
27
19
21
22
23
88*
88
86
83
66
85
89
68
70
71
72
82
84
90
78
67
74
73
11
74
73
69
80
81
79
17
* SPARE PARTS SUPLIED WITH THE MACHINE
M 501
Pos. Dílec è. Název
Det. Part No. Denomination
2 ...... S321 000000 .............................................. ZÁTKA ..................................................... PLUG
3 ...... S080 831665 .............................................. KRYT ZADNÍ .......................................... COVER BACK
4 ...... S309 000410 .............................................. ROUB M4 x 10 .................................... SCREW M4 x 10
5 ...... S080 836476 .............................................. KONZOLA ............................................... CONSOLE
6 ...... S080 126102 .............................................. ROUB M5 x 8 ...................................... SCREW M5 x 8
7 ...... S080 615021 .............................................. ZVEDACÍ PÁKA ..................................... LIFTING LEVER
8 ...... S080 310468.............................................. KOLÍK ..................................................... PIN
9 ...... S981 043510 .............................................. NAPÍNACÍ KLADKA ÚPL. ..................... TENSION ROLLER CPL.
10 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
11 ...... S981 036164 .............................................. NAVÍJEÈ................................................. WINDER
12 ...... S981 025290.............................................. VODIÈ..................................................... GUIDE
13 ...... S080 836485.............................................. IPKA..................................................... ARROW
14 ...... S309 738406.............................................. ROUB M4 x 6 ...................................... SCREW M4 x 6
15 ...... S981 045576 .............................................. PÁSOVÉ KOLO ÚPLNÉ.......................... BELT WHEEL CPL.
16 ...... S981 045572.............................................. KOLO NAVÍJEÈE ÚPLNÉ ....................... WHEEL OF WINDER CPL.
17 ...... S981 045570 .............................................. ØEMENICE ÚPLNÁ ................................ PULLEY CPL.
18 ...... S980 027610.............................................. RUÈNÍ KOLO.......................................... HAND WHEEL
19 ...... S309 798511 .............................................. ROUB ................................................... SCREW
20 ...... S323 007065.............................................. LOISKO KU 1010 ................................ BEARING KU 1010
21 ...... S080 190707.............................................. DISTANÈNÍ KROUEK ........................... DISTANCE RING
22 ...... 0271 000260 .............................................. Nù ......................................................... KNIFE
23 ...... S309 000416 .............................................. ROUB ................................................... SCREW
24 ...... S981 043496.............................................. ZVEDACÍ HØÍDEL .................................. LIFTING SHAFT
26 ...... S080 955135.............................................. TÍTEK KNOFLÍKU DÉLKY STEHU ....... LABEL RELATED TO STITCH
LENGHT REGULATION KNOB
27 ...... S080 955132 .............................................. IPKA SMÌRU OTÁÈENÍ ...................... ARROW OF ROTATION SENSE
28 ...... S735 955136 .............................................. STUPNICE RUÈNÍHO KOLA .................. HAND WHEEL SCALE
29 ...... S321 001000.............................................. ZÁTKA PE............................................... PLUG
30 ...... S735 953288.............................................. TÍTEK ................................................... LABEL
31 ...... S080 191120.............................................. PODLOKA............................................. WASHER
32 ...... S080 146058.............................................. ROUB ................................................... SCREW
35 ............................................................................ VIZ POS. 9 ............................................. SEE 9
36 ............................................................................ VIZ POS. 9 ............................................. SEE 9
37 ...... 9352 000090 .............................................. POJ. KROUEK ...................................... RETAINING RING
40 ............................................................................ VIZ POS. 16 ........................................... SEE 16
41 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
50 ...... S080 161138 .............................................. MATICE .................................................. NUT
53 ...... 0221 110154 .............................................. VODIÈ ÚPLNÝ ....................................... GUIDE CPL.
54 ...... 0037 001280 .............................................. PODLOKA NAPÍNAÈE ......................... WASHER OF TENSIONER
55 ............................................................................ VIZ POS. 12 ........................................... SEE 12
56 ...... 0396 110470 .............................................. PRUINA................................................ SPRING
57 ............................................................................ VIZ POS. 12 ........................................... SEE 12
59 ............................................................................ VIZ POS. 12 ........................................... SEE 12
60 ............................................................................ VIZ POS. 12 ........................................... SEE 12
61 ...... 0993 411208 .............................................. RÝH. MATICE......................................... KNURLED NUT
66 ...... 0067 320150 .............................................. PRUINA................................................ SPRING
67 ............................................................................ VIZ POS. 11 ........................................... SEE 11
68 ............................................................................ VIZ POS. 11 ........................................... SEE 11
69 ...... 0367 170040 .............................................. PRUINA................................................ SPRING
70 ...... 0396 170060 .............................................. POUZDRO............................................... CASE
71 ...... 0396 170080 .............................................. PRUINA................................................ SPRING
72 ............................................................................ VIZ POS. 11 ........................................... SEE 11
73 ...... 9225 201740 .............................................. ROUB M4 x 6 ...................................... SCREW
74 ...... 0993 031357 .............................................. ROUB M4 x 8 ...................................... SCREW
78 ...... 0268 170063 .............................................. TÌLESO NAVÍJEÈE ................................ BODY OF WINDER
79 ...... S981 043503.............................................. HØÍDEL ÚPLNÁ...................................... SHAFT CPL.
TAB.
80 ...... 0268 170103 .............................................. PÁKA ÚPLNÁ......................................... LEVER CPL.
81 ............................................................................ VIZ POS. 11 ........................................... SEE 11
1
Pos. Dílec è. Název
Det. Part No. Denomination
82 ............................................................................ VIZ POS. 11 ........................................... SEE 11
83 ...... 9357 000050 .............................................. PODLOKA............................................. WASHER
84 ............................................................................ VIZ POS. 11 ........................................... SEE 11
85 ...... 0367 170083 .............................................. KOLO NAVÍJEÈE .................................... WHEEL OF WINDER
86 ............................................................................ VIZ POS. 11 ........................................... SEE 11
87 ...... 9205 102168 .............................................. ROUB M5 x 6 ...................................... SCREW M5 x 6
88 ...... 0998 861590 .............................................. O-KROUEK ........................................... O-RING
89 ............................................................................ VIZ POS. 11 ........................................... SEE 11
90 ...... 0993 060967 .............................................. ROUB ................................................... SCREW
93 ...... S080 839312 .............................................. ZVEDACÍ PLECH.................................... LIFTING SHEET
94 ...... S311 732050 .............................................. POJ. KROUEK ...................................... RETAINING RING
95 ...... S980 060175 .............................................. PÁKA...................................................... LEVER
107 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
111 ............................................................................ VIZ POS. 15 ........................................... SEE 15
112 ............................................................................ VIZ POS. 15 ........................................... SEE 15
117 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
118 ............................................................................ VIZ POS. 17 ........................................... SEE 17
M 534
5
5
5
5
2
16
19
17
31
33
33
33
33
32
36
35
41
3
6
36
M 534
Pos. Dílec è. Název
Det. Part No. Denomination
2 ...... S981 045573 .............................................. POJISTNÁ SPOJKA ÚPLNÁ .................. SAFETY CLUTCH CPL.
3 ...... S981 052064.............................................. LOISKO ÚPLNÉ.................................... BEARING CPL.
5 ...... S080 126096 .............................................. ROUB M5 x 12 .................................... SCREW M5 x 12
6 ...... S080 341261.............................................. SPODNÍ HØÍDEL .................................... LOWER SHAFT
16 ............................................................................ VIZ POS. 3 ............................................. SEE 3
17 ............................................................................ VIZ POS. 3 ............................................. SEE 3
19 ............................................................................ VIZ POS. 3............................................. SEE 3
31 ...... S980 045574 .............................................. OZUBENÁ ØEMENICE............................ TOOTHED WHEEL
32 ...... S080 161339 .............................................. MATICE .................................................. NUT
33 ...... S080 420010.............................................. TALÍØOVÁ PRUINA ............................. WASHER SPRING
35 ...... S324 049910.............................................. LOISKO ÚPLNÉ.................................... BEARING CPL.
36 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
41 ...... S311 988232 .............................................. TALÍØOVÁ PRUINA ............................. WASHER SPRING
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
2
M 537
16
23
17
25
12
11
13
28
1
2
2
26
22
20
24
18
21
19
10
9
7
7
3
7
7
4
5
M 537
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... S080 744533 .............................................. DRÁK VARIÁTORU .............................. HOLDER OF THE DRIVE
.............................................................................................................................................. CONVERSION UNIT
2 ...... 9202 002558 .............................................. ROUB M5 x 45 .................................... SCREW M5 x 45
3 ...... S080 260608 .............................................. PRUINA ................................................ SPRING
4 ...... S080 161142 .............................................. MATICE .................................................. NUT
5 ...... S080 161333 .............................................. OPÌRKA ................................................. SUPPORT
7 ...... 9202 003738 .............................................. ROUB M10 x 35 .................................. SCREW M10 x 35
9 ...... S272 100517.............................................. OZUBENÝ ØEMEN FLENNOR................. TOOTHED BELT FLENNOR
10 ...... S080 425326 .............................................. POUZDRO............................................... CASE
11 ...... S321 920024.............................................. ÈELNÍ KRYT........................................... FRONTAL COVER
12 ...... S080 120270 .............................................. ROUB M5 x 18 .................................... SCREW M5 x 18
13 ...... S080 120100.............................................. ROUB ................................................... SCREW
16 ...... S980 060207.............................................. PÁKA ÚPLNÁ......................................... LEVER CPL.
17 ...... S080 120698.............................................. ROUB ................................................... SCREW
18 ...... S080 161146.............................................. MATICE .................................................. NUT
19 ...... S080 190346.............................................. PODLOKA............................................. WASHER
20 ...... S080 333175.............................................. ÈEP ......................................................... PIN
21 ...... S080 384113.............................................. TÁHLO ..................................................... ROD
22 ...... S080 418182.............................................. KLADKA ................................................. ROLLER
23 ...... S080 633220.............................................. PÁKA...................................................... LEVER
24 ...... S311 214051.............................................. PODLOKA............................................. WASHER
25 ...... S311 318012.............................................. ZÁVLAÈKA............................................. SPLIT PIN
26 ...... S311 732040.............................................. POJISTNÝ KROUEK ............................ RETAINING RING
28 ...... 0744 001155 .............................................. ZÁTKA ..................................................... PLUG
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
3
M 551
9
1
16
4
41
14
43
14
46
10
15
6
12
40
44
48
42
2
27
31
13
31
8
7
11
30
29
21
23
24
28
25
3
15
26
33
20
32
5
22
50
M 551
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... S080 831666 .............................................. KRYT ...................................................... COVER
2 ...... S981 021403 .............................................. DRÁK JEHELNÍ TYÈE .......................... HOLDER OF NEEDLE BAR
3 ...... S080 330134 .............................................. ÈEP ......................................................... PIN
4 ...... S981 052076 .............................................. HLAVA KLIKY ÚPLNÁ .......................... HEAD OF CRANK CPL.
5 ...... S080 146063.............................................. ROUB ................................................... SCREW
6 ...... S080 410680 .............................................. KROUEK ............................................... RING
7 ...... S980 021396 .............................................. NIOVÁ PÁKA ÚPLNÁ .......................... TAKE UP LEVER CPL.
8 ...... S080 338229.............................................. KLIKA ..................................................... CRANK
9 ...... S980 025305 .............................................. VÝSTØEDNÍK ÚPLNÝ ............................ ECCENTRIC CPL.
10 ...... S311 732060.............................................. POJ. KROUEK ...................................... RETAINING RING
11 ...... S080 153045.............................................. ROUB ................................................... SCREW
12 ...... S080 328235.............................................. ÈEP ......................................................... PIN
13 ...... S309 791616.............................................. ROUB ................................................... SCREW
14 ...... S309 738406.............................................. ROUB ................................................... SCREW
15 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
16 ...... 9205 102473 .............................................. ROUB ................................................... SCREW
20 ............................................................................ VIZ POS. 2 ............................................. SEE 2
21 ............................................................................ VIZ POS. 2 ............................................. SEE 2
22 ...... S080 111223 .............................................. ROUB ................................................... SCREW
23 ............................................................................ VIZ POS. 50 ........................................... SEE 50
24 ............................................................................ VIZ POS. 50 ........................................... SEE 50
25 ...... S311 515091 . ........................................... KOLÍK 1,6 x 6 ........................................ PIN 1.6 x 6
26 ...... S080 124050 .............................................. ROUB ................................................... SCREW
27 ............................................................................ VIZ POS. 50 ........................................... SEE 50
28 ............................................................................ VIZ POS. 50 ........................................... SEE 50
29 ............................................................................ VIZ POS. 2 ............................................. SEE 2
30 ...... S080 826403 .............................................. PØÍCHYTKA ........................................... CLIP
31 ...... S080 120367.............................................. ROUB ................................................... SCREW
32 ...... S311 318016.............................................. ZÁVLAÈKA............................................. SPLIT PIN
33 ...... 9203 113681 .............................................. ROUB ................................................... SCREW
40 ............................................................................ VIZ POS. 4 ............................................. SEE 4
41 ...... S311 799410 .............................................. ROUB M4 x 10 .................................... SCREW M4 x 10
42 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
43 ...... S080 138009 .............................................. ROUB ................................................... SCREW
44 ............................................................................ VIZ POS. 4 ............................................. SEE 4
46 ............................................................................ VIZ POS. 4 ............................................. SEE 4
48 ...... S080 120295 .............................................. ROUB ................................................... SCREW
50 ...... S981 021406.............................................. OJNICE ÚPLNÁ ...................................... ROD CPL.
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
4
M 517
31
9
10
23
54
42
26
27
52
53
55
28
56
18
22
3
57
21
2
58
20
34
34
30
20
19
65
66
67
68
16
17
1
15
36
6
69
7
11
4
5
41
65
66
67
68
69
30
7
8
37
38
13
36
14
59
12
24
39
5
6
32
50
34
45
46
47
48
33
29
57
58
59
60
61
62
7
8
37
38
39
M 517
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... S080 826404 .............................................. DESKA .................................................... PLATE
2 ...... S273 005025 .............................................. KROUEK ............................................... RING
3 ...... S080 425329 .............................................. POUZDRO ............................................... CASE
4 ...... S324 031651 .............................................. VÁLEÈEK JEHLOVÝ .............................. NEEDLE ROLLER
5 ...... 0367 110120 .............................................. NAPÍNACÍ ÈEP ...................................... TENSIONING PIN
6 ...... S321 941159 .............................................. PODLOKA ............................................. WASHER
7 ...... 0467 110220 .............................................. MISKA NAPÍNAÈE ................................ DISH OF TENSIONER
8 ...... S321 941158 .............................................. PODLOKA ............................................. WASHER
9 ...... S080 391134 .............................................. JEHELNÍ TYÈ ......................................... NEEDLE BAR
10 ...... S080 135022.............................................. ROUB ................................................... SCREW
11 ...... S080 190708.............................................. KROUEK ............................................... RING
12 ...... S080 310478.............................................. KOLIK ..................................................... PIN
13 ...... S309 738406.............................................. ROUB ................................................... SCREW
14 ...... S080 821181.............................................. VODIÈ..................................................... GUIDE
15 ...... S273 001000.............................................. O-KROUEK ........................................... O-RING
16 ...... S080 318256.............................................. ÈEP ......................................................... PIN
17 ...... 0265 000911 .............................................. O-KROUEK ........................................... O-RING
18 ...... S980 047280 .............................................. PÁKA ÚPLNÁ......................................... LEVER CPL.
19 ...... S080 323203.............................................. ÈEP ......................................................... PIN
20 ...... S311 732032.............................................. POJ. KROUEK ...................................... RETAINING RING
21 ...... S080 142027.............................................. ROUB ................................................... SCREW
22 ...... S311 732050.............................................. POJ. KROUEK ...................................... RETAINING RING
23 ...... S981 060243.............................................. KLADKA ÚPLNÁ .................................... ROLLER CPL.
24 ...... S080 190709.............................................. PODLOKA............................................. WASHER
26 ...... 9234 000057 .............................................. MATICE .................................................. NUT
27 ...... S080 436457 .............................................. STAVÌCÍ KROUEK ............................... REGULATING RING
28 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
29 ...... 0367 110254 M .......................................... NAPÍNAÈ NITÌ ÚPLNÝ ......................... TENSIONER COMPLET CPL.
30 ...... 0271 001391 .............................................. VODIÈ ÚPLNÝ ....................................... GUIDE CPL.
31 ...... S981 021400.............................................. JEHELNÍ TYÈ ÚPLNÁ ............................ NEEDLE BAR CPL.
32 ...... S980 060231.............................................. DESKÁ ÚPLNÁ ...................................... PLATE CPL.
33 ...... S080 126073.............................................. ROUB ................................................... SCREW
34 ...... 9205 101868 .............................................. ROUB ................................................... SCREW
36 ...... S309 000410 .............................................. ROUB ................................................... SCREW
37 ...... 0061 001050 .............................................. PODLOKA............................................. WASHER
38 ...... 0099 004800 .............................................. PRUINA................................................ SPRING
39 ...... 0271 000238 .............................................. MATICE .................................................. NUT
41 ...... S080 190701 .............................................. PODLOKA............................................. WASHER
42 ...... S735 955142.............................................. SAMOLEPKA ......................................... LABEL
45 ...... S080 839349.............................................. PØÍLOKA.............................................. SPLICE
46 ...... S080 410699.............................................. POUZDRO............................................... CASE
47 ...... S080 260617.............................................. PRUINA................................................ SPRING
48 ...... S309 000306.............................................. ROUB ................................................... SCREW
50 ...... S981 025306.............................................. VODIÈ NITÌ ÚPLNÝ .............................. THREAD QUIDE CPL.
52 ...... 9357 000060 .............................................. POJ. KROUEK ...................................... RETAINING RING
53 ...... 0367 110160 .............................................. POUZDRO............................................... CASE
54 ...... 0993 520940 .............................................. ROUB ................................................... SCREW
55 ...... 0367 110170 .............................................. ÈEP ......................................................... PIN
56 ...... 0068 004910 .............................................. PRUINA................................................ SPRING
57 ...... 0367 110350 .............................................. PODLOKA............................................. WASHER
58 ...... 0367 110340 .............................................. ROLNA .................................................... ROLLER
59 ...... 0367 110360 .............................................. PODLOKA............................................. WASHER
60 ...... 0367 110183 .............................................. PODLOKA ÚPLNÁ ............................... WASHER CPL.
61 ...... 0367 110290 .............................................. POUZDRO............................................... CASE
TAB.
62 ...... 0381 110043 .............................................. MATICE .................................................. NUT
65 ...... 0271 001392 .............................................. VODIÈ NITÌ ........................................... THREAD GUIDE
66 ...... 0244 000415 .............................................. OBJÍMKA ............................................... SLEEVE
5
Pos. Dílec è. Název
Det. Part No. Denomination
67 ...... 0244 000414 .............................................. OBJÍMKA ............................................... SLEEVE
68 ...... 0271 001397 .............................................. PRUINA................................................ SPRING
69 ...... 0271 001398 .............................................. RÝHOVANÁ MATICE ............................. MILLED NUT
M 075
16
17
16
12
13
20
20
3
4
10
11
5
8
7
16
14
9
16
15
18
17
19
28
51
52
51
31
46
33
21
22
47
2
23
M 075
Pos. Dílec è. Název
Det. Part No. Denomination
2 ...... S981 023159 .............................................. NOSIÈ CHAPAÈE .................................. POST BED FOR SEWING HOOK
3 ...... S080 126178 .............................................. ROUB ................................................... SCREW
4 ...... S080 345089 .............................................. HØíDEL ................................................... SHAFT
5 ...... S080 426096 .............................................. POUZDRO ............................................... CASE
7 ...... S080 346078 .............................................. MAZACÍ TRUBKA .................................. LUBRICATING TUBE
8 ...... S080 110105 .............................................. ROUB ................................................... SCREW
9 ...... S273 002001 .............................................. O-KROUEK ........................................... O-RING
10 ...... 0002 008308 3335 .................................... MAZACÍ PLST ....................................... OIL FELT
11 ...... S080 945379 .............................................. MAZACÍ PLST ....................................... OIL FELT
12 ...... S080 338232 .............................................. ÈEP ......................................................... PIN
13 ...... S080 452053.............................................. SMYKADLO ........................................... BLOCK
14 ...... 9202 002063 .............................................. ROUB M4 x 10 .................................... SCREW M4 x 10
15 ...... S311 212043 .............................................. PODLOKA............................................. WASHER
16 ...... S080 120695.............................................. ROUB ................................................... SCREW
17 ...... S311 433060.............................................. PODLOKA............................................. WASHER
18 ...... S309 281514.............................................. ROUB M5 x 16 .................................... SCREW M5 x 16
19 ...... S080 141322 .............................................. ROUB M5 x 30 .................................... SCREW M5 x 30
20 ...... S080 112088 .............................................. ROUB M5 x 8 ...................................... SCREW M5 x 8
21 ...... S324 512910 .............................................. LOISKO ................................................ BEARING
22 ...... S080 190681.............................................. PODLOKA............................................. WASHER
23 ...... S981 045550.............................................. OZUBENÉ KOLO ÚPLNÉ ........................ TOOTHED WHEEL CPL.
28 ...... S981 060189.............................................. OZUBENÉ KOLO ÚPLNÉ ........................ TOOTHED WHEEL CPL.
31 ...... S080 126078.............................................. ROUB M3 x 8 ...................................... SCREW M3 x 8
32 ...... S080 424164 .............................................. KONCOVKA............................................ TERMINAL
33 ...... S080 945387.............................................. MAZACÍ PLST ....................................... OIL FELT
34 ............................................................................ VIZ POS. 2 ............................................. SEE 2
35 ............................................................................ VIZ POS. 2 ............................................. SEE 2
36 ............................................................................ VIZ POS. 2 ............................................. SEE 2
37 ...... S273 001003 .............................................. O-KROUEK ........................................... O-RING
46 ...... S080 111375.............................................. ROUB ................................................... SCREW
47 ............................................................................ VIZ POS. 23 ........................................... SEE 23
51 ...... S080 111376.............................................. ROUB ................................................... SCREW
52 ............................................................................ VIZ POS. 28 ........................................... SEE 28
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
6
M 538
3
3
8
3
3
24
37
35
6
25
2
34
29
15
191
2
9
38
66
160
141
18
27
142
21
140
124
123
28
43
56
56
45
46
44
59
54
68
52
44
53
68
63
47
56
64
67
47
1
16
125
69
4
72
20
76
7
5
36
19
74
70
73
78
77
56
48
17
55
58
49
50
51
62
11
13
22
40
41
20
163
42
33
162
164
20
10
12
168
182
167
176
169
190
172
171
175
179
180
80
82
81
83
84
14
175
177
23
183
M 538
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... S080 392050 .............................................. PØÍTLAÈNÁ TYÈ ................................... PRESSURE BAR
2 ...... S080 111379 .............................................. ROUB ................................................... SCREW
3 ...... 9202 002477 .............................................. ROUB M5 x 10 .................................... SCREW M5 x 10
4 ...... S080 120246 .............................................. ROUB ................................................... SCREW
5 ...... S080 120239 .............................................. ROUB ................................................... SCREW
6 ...... S080 271544 .............................................. SPONA ................................................... CLIP
7 ...... S080 190554 .............................................. PODLOKA ............................................. WASHER
8 ...... S080 156045 .............................................. SEØIZOVACÍ ROUB ............................ SETTING-UP SCREW
9 ...... S080 260602 .............................................. PRUINA ................................................ SPRING
10 ...... S080 260604.............................................. PRUINA................................................ SPRING
11 ............................................................................ VIZ POS. 40 ........................................... SEE 40
12 ...... S080 324062.............................................. ÈEP ......................................................... PIN
13 ...... S080 320342.............................................. ÈEP ......................................................... PIN
14 ...... S080 341258.............................................. HØÍDEL................................................... SHAFT
15 ...... S315 263275.............................................. PRUINA................................................ SPRING
16 ...... S080 410676.............................................. POUZDRO............................................... CASE
17 ...... S080 281139.............................................. PRUINA................................................ SPRING
18 ...... S080 412222.............................................. POUZDRO............................................... CASE
19 ...... S080 426098.............................................. VÝSTØEDNÉ POUZDRO ........................ ECCENTRIC CASE
20 ...... S080 425319.............................................. POUZDRO............................................... CASE
21 ...... S980 060241.............................................. PÁKA ÚPLNÁ......................................... LEVER CPL.
22 ...... S080 425322.............................................. POUZDRO............................................... CASE
23 ...... S080 839333.............................................. ZÁVÌS .................................................... HANGER
24 ...... S080 831671.............................................. KRYT ZADNÍ .......................................... COVER BACK
25 ...... S080 945397.............................................. MAZACÍ VLOKA .................................. LUBRICATING INSERT
27 ...... S080 943214.............................................. PODLOKA............................................. WASHER
28 ...... S080 314270.............................................. ÈEP ......................................................... PIN
29 ...... S080 271533.............................................. HÁÈEK PRUINY................................... HOOK OF SPRING
33 ...... S311 732050.............................................. POJ. KROUEK ...................................... RETAINING RING
34 ...... S980 039113.............................................. TÁHLO ..................................................... ROD
35 ...... 9840 120030 .............................................. PØÍCHYTKA........................................... CLIP
36 ...... S311 733140 .............................................. POJ. KROUEK ...................................... RETAINING RING
37 ...... S080 120218.............................................. ROUB ................................................... SCREW
38 ...... S980 052070.............................................. ÈEP ÚPLNÝ ........................................... PIN CPL.
40 ...... S980 060216.............................................. PÁKA ÚPLNÁ......................................... LEVER CPL.
41 ...... 9202 002493 .............................................. ROUB ................................................... SCREW
42 ...... S080 613588 .............................................. PÁKA...................................................... LEVER
43 ...... S981 022878.............................................. TØMEN-SESTAVA .................................. STIRRUP-ASSEMBLY
44 ...... 9205 121868 .............................................. ROUB M4 x 6 ...................................... SCREW M4 x 6
45 ...... S080 120364 .............................................. ROUB M5 x 14 .................................... SCREW M5 x 14
46 ...... 9202 002088 .............................................. ROUB M4 x 12 .................................... SCREW M4 x 12
47 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
48 ...... S080 138009 .............................................. ROUB ................................................... SCREW
49 ...... S080 826402.............................................. PØÍLOKA.............................................. SPLICE
50 ...... 0888 220250 .............................................. ROUB ................................................... SCREW
51 ...... S080 283176 .............................................. PRUINA ................................................ SPRING
52 ............................................................................ VIZ POS. 43 ........................................... SEE 43
53 ............................................................................ VIZ POS. 43 ........................................... SEE 43
54 ............................................................................ VIZ POS. 43 ........................................... SEE 43
55 ............................................................................ VIZ POS. 43 ........................................... SEE 43
56 ............................................................................ VIZ POS. 43 ........................................... SEE 43
58 ............................................................................ VIZ POS. 43 ........................................... SEE 43
59 ...... S080 635302.............................................. PÁKA...................................................... LEVER
62 ............................................................................ VIZ POS. 43 ........................................... SEE 43
TAB.
63 ...... S311 732060.............................................. POJ. KROUEK ...................................... RETAINING RING
64 ...... S311 733280.............................................. POJ. KROUEK ...................................... RETAINING RING
66 ............................................................................ VIZ POS. 43 ........................................... SEE 43
7
67 ...... S980 060222.............................................. VÝSTØEDNÍK S OJNICÍ ........................ ECCENTRIC WITH ROD
Pos. Dílec è. Název
Det. Part No. Denomination
68 ............................................................................ VIZ POS. 43 ........................................... SEE 43
69 ...... S981 022875 .............................................. NOSIÈ PODAVAÈE ÚPLNÝ................... FEED CARRIER CPL.
70 ...... 9202 002493 .............................................. ROUB ................................................... SCREW
72 ............................................................................ VIZ POS. 69 ........................................... SEE 69
73 ............................................................................ VIZ POS. 69 ........................................... SEE 69
74 ............................................................................ VIZ POS. 69 ........................................... SEE 69
76 ...... S981 052067 .............................................. KROUEK ÚPLNÝ .................................. RING CPL.
77 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
78 ...... S080 436453 .............................................. KROUEK ............................................... RING
80 ...... S981 060219 .............................................. OJNICE ÚPLNÁ ...................................... ROD CPL.
81 ...... 0244 000700 .............................................. ROUB ................................................... SCREW
82 ...... S080 630305 .............................................. OJNICE ................................................... ROD
83 ...... 9202 002118 .............................................. ØOUB ................................................... SCREW
84 ...... S980 060220 .............................................. VÝSTØEDNÉ POUZDRO ........................ ECCENTRIC CASE
123 ...... S981 052044 .............................................. STAVÌCÍ KROUEK ÚPLNÝ.................. REGULATING RING CPL.
124 ...... S080 111375 .............................................. ROUB ................................................... SCREW
125 ...... S080 436444 .............................................. STAVÌCÍ KROUEK............................... REGULATING RING
140 ...... S981 052049 .............................................. VEDENÍ ÚPLNÉ ...................................... GUIDANCE CPL.
141 ...... S080 120543 .............................................. ROUB ................................................... SCREW
142 ............................................................................ VIZ POS. 140 ......................................... SEE 140
160 ...... S080 349218 .............................................. HØÍDEL................................................... ROD
162 ...... S981 060193 .............................................. VAÈKA ÚPLNÁ ...................................... CAM CPL.
163 ...... S080 120705 .............................................. ROUB ................................................... SCREW
164 ............................................................................ VIZ POS. 162 ......................................... SEE 162
167 ...... S981 060194 .............................................. ZPÁTKOVACÍ PÁKA .............................. BACKTACKING LEVER
168 ...... S080 340203 .............................................. HØÍDEL................................................... SHAFT
169 ...... S080 621040 .............................................. ZPÁTKOVACÍ PÁKA .............................. BACKTACKING LEVER
171 ...... S311 733120 .............................................. POJ. KROUEK ...................................... RETAINING RING
172 ...... S315 263276 .............................................. PRUINA................................................ SPRING
174 ...... S981 060195 .............................................. KNOFLÍK ÚPLNÝ.................................... BUTTON CPL.
175 ...... 9205 102488 .............................................. ROUB M6 x 10 .................................... SCREW M6 x 10
176 ...... S080 233061 .............................................. KNOFLÍK................................................. BUTTON
177 ...... S080 441687 .............................................. KOTOUÈ ................................................. DISK
179 ...... S273 001002 .............................................. O-KROUEK 9 x 2 .................................. O-RING 9 x 2
180 ...... S311 515021 .............................................. KOLÍK 2 x 10 ......................................... PIN 2 x 10
182 ...... S080 332172 .............................................. ROUB ................................................... SCREW
183 ...... S735 975184 .............................................. SAMOLEPÍCÍ TÍTEK-STUPNICE ........ LABEL-SCALE
190 ...... S311 515055 .............................................. KOLÍK 6 x 20 ......................................... PIN 6 x 20
191 ...... S283 068001 .............................................. HADIÈKA PVC OLEJ. ............................ HOSE PVC OIL
M 522
7
6
8
5
8
2
4
3
1
2
M 522
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... 0265 002402 .............................................. OLEJOVÁ NÁDRKA.............................. OIL TANK
2 ...... 9217 300528 .............................................. ROUB ................................................... SCREW
3 ...... S158 076500 .............................................. DRÁT ....................................................... BLOWER
4 ...... 0211 000806 .............................................. PRÙCHODKA ......................................... BUSHING
5 ...... 9840 120027 .............................................. PØÍCHYTKA ........................................... CLIP
6 ............................................................................ VIZ S980 000522 .................................. S980 000522
7 ............................................................................ VIZ S980 000522 .................................. S980 000522
8 ...... S512 228001 .............................................. SPOJKA ................................................. CONNECTOR
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
8
M 514
7
4
4
3
8
6
25
10
9
26
5
32
2
26
24
12
31
22
20
23
1
5
24
7
24
5
M 514
Pos. Dílec è. Název
Det. Part No. Denomination
1 ...... S981 052071 .............................................. MAZACÍ SKØÍÒ ÚPLNÁ ........................ LUBRICATION BOX CPL.
2 ...... S981 052075.............................................. ODSÁVACÍ KNOT ÚPLNÝ ..................... WICK CPL.
3 ...... S080 826412 .............................................. PØÍCHYTKA ........................................... CLIP
4 ...... S311 400515 .............................................. VRUT UN ................................................ SCREW UN
5 ...... 0211 000806 .............................................. PRÙCHODKA ......................................... BUSHING
6 ...... 9840 120026 .............................................. PØÍCHYTKA ........................................... CLIP
7 ...... 9217 300528 .............................................. ROUB ................................................... SCREW
8 ...... S309 287416 .............................................. ROUB ................................................... SCREW
9 ...... S080 310483 .............................................. KOLÍK ..................................................... PIN
10 ...... 9205 102478 .............................................. ROUB ................................................... SCREW
12 ...... S562 411000 .............................................. NG PÁSEK ............................................. NG BAND
20 ...... 0265 002402 .............................................. OLEJOVÁ NÁDRKA.............................. OIL TANK
22 ............................................................................ VIZ POS. 1 ............................................. SEE 1
23 ............................................................................ VIZ POS. 1 ............................................. SEE 1
24 ...... S158 076500 .............................................. DRÁT....................................................... BLOWER
25 ...... S283 003001.............................................. HADIÈKA PVC ....................................... HOSE PVC
26 ...... 0211 000085 .............................................. PRÙCHODKA ......................................... BUSHING
31 ............................................................................ VIZ POS. 2 ............................................. SEE 2
32 ............................................................................ VIZ POS. 2 ............................................. SEE 2
Pos. Dílec è. Název
Det. Part No. Denomination
TAB.
9
Loading...
