Two-Piece toiletTwo-Piece toilet DimensionDimension WeightWeight Order numberOrder number
(without tank), syphonic, 12" rough-in, vertical outlet, cUPC®
listed*
ColorsColors
00 White 20 HygieneGlaze (an antibacterial ceramic glaze that
provides almost indefinite effectiveness)
VariantVariant
© 1.32/0.92 gpf 14 1/8" x 27 1/2" Inch 92 lb 216001..00
© 1.28 gpf 14 1/8" x 27 1/2" Inch 92 lb 216001..85
© 1.28 gpf 14 1/8" x 27 1/2" Inch 92 lb 216001..85
InfoboxInfobox
* Complies with following standards: ASME A112.19.2/CSA B45.1
Sanitary ceramics with the special WonderGliss surface finish will remain clean and attractive-looking for a long
time to come.
When ordering WonderGliss please add a "1" as eleventh digit to the model number.
Mounting set for One-Piece and Two-Piece toilets, outlet 3/8" male thread, wall connection 1/2" - female thread, 1/2'', North
American version
17 3/4" Inch 1.1 lb 001417
Suitable productsSuitable products
Toilet seat and cover removable, elongated, hinges stainless
steel, without slow close,
006051
DuraStyle Two-Piece toilet # 216001..00 / 216001..85 /
216001..85
|< 14 1/8" Inch >|
Page 2
Toilet seat and cover removable, elongated, hinges stainless
steel, with slow close,
006059
Tank for bottom left supply, cUPC® listed*, 15 3/8" x 6 3/4"
Inch
15 3/8" x 6 3/4" Inch 093520
All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch & mm and are nonbinding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
DuraStyle Two-Piece toilet # 216001..00 / 216001..85 /
216001..85
|< 14 1/8" Inch >|
