Page 1
SensoWash® Slim shower-toilet seat for DuraStyle*SensoWash® Slim shower-toilet seat for DuraStyle* DimensionDimension WeightWeight Order numberOrder number
Rear-, Lady- and Comfortwash, with slow close, night light,
remote control included, locking function via remote control,
self-cleaning wand, on / off-button, with concealed connections,
automatic drainage in periods of prolonged disuse
ColorsColors
00 White
VariantVariant
AC 100-120V, 50-60 Hz, individual adjustment of water
temperature, spray wand position and water spray intensity,
seat and lid easily removable with one hand
14 3/4" x 21 1/4" Inch 12.1 lb 611200001001300
AC 100-120V, 50-60 Hz, individual adjustment of water- and
seat surface temperature as well as nozzle position and jet
strength, heated seat
14 3/4" x 21 1/4" Inch 12.1 lb 611200001101300
InfoboxInfobox
Install a water water softener with water hardness ≥ 2.4 mmol/l (≥ 14° dH or 24° fH).
Suitable productsSuitable products
One-Piece toilet for SensoWash® only in combination with
SensoWash, syphonic, 12" rough-in, connecting elements for
SensoWash with concealed connections included, vertical outlet,
cUPC® listed*, 14 5/8" x 28 3/8" Inch
14 5/8" x 28 3/8" Inch 215751
Toilet wall-mounted for SensoWash® washdown model, only in
combination with SensoWash, connecting elements for
SensoWash with concealed connections included, Durafix
included, cUPC® listed*, 14 5/8" X 24 3/8" Inch
14 5/8" X 24 3/8" Inch 253759
SensoWash® Slim SensoWash® Slim shower-toilet seat for
DuraStyle* # 611200001001300 / 611200001101300
|< 14 3/4" Inch >|
Page 2
Toilet close-coupled for SensoWash® (without tank), only in
combination with SensoWash, washdown model, outlet for vario
connector set, for horizontal and vertical outlet, length
adjustable from 2 3/4" - 6 3/4", and vario connecting bend,
vertical outlet from 6 3/4" - 8 5/8", connecting elements for
SensoWash with concealed connections included, hardware
included, cUPC® listed*, 14 5/8" x 27 1/2" Inch
14 5/8" x 27 1/2" Inch 215659
Two-piece toilet for SensoWash® (without tank), syphonic, only
in combination with SensoWash, 12" rough-in, connecting
elements for SensoWash with concealed connections included,
vertical outlet, cUPC® listed*, 14 1/8" x 27 1/2" Inch
14 1/8" x 27 1/2" Inch 216051
Toilet wall-mounted Duravit Rimless for SensoWash® rimless,
washdown model, only in combination with SensoWash,
connecting elements for SensoWash with concealed
connections included, Durafix included, cUPC® listed*, 14 5/8"
X 24 3/8" Inch
14 5/8" X 24 3/8" Inch 254259
Toilet kit One-Piece toilet for SensoWash® & SensoWash® Slim
shower-toilet seat, 14 3/4" x 28 3/8" Inch
14 3/4" x 28 3/8" Inch D40524
Toilet kit One-Piece toilet for SensoWash® & SensoWash® Slim
shower-toilet seat, 14 3/4" x 28 3/8" Inch
14 3/4" x 28 3/8" Inch D40526
Toilet kit Toilet bowl for SensoWash®, Tank & SensoWash®
Starck shower-toilet seat, 15 3/8" x 27 1/2" Inch
15 3/8" x 27 1/2" Inch D40528
Toilet kit Toilet bowl for SensoWash®, Tank & SensoWash®
Starck shower-toilet seat, 15 3/8" x 27 1/2" Inch
15 3/8" x 27 1/2" Inch D40529
Toilet kit Toilet bowl for SensoWash®, Tank & SensoWash®
Starck shower-toilet seat, 15 3/8" x 27 1/2" Inch
15 3/8" x 27 1/2" Inch D40531
Toilet kit Toilet bowl for SensoWash®, Tank & SensoWash®
Starck shower-toilet seat, 15 3/8" x 27 1/2" Inch
15 3/8" x 27 1/2" Inch D40532
Toilet kit One-Piece toilet for SensoWash® & SensoWash® Slim
shower-toilet seat, 14 3/4" x 28 3/8" Inch
14 3/4" x 28 3/8" Inch D40534
Toilet kit One-Piece toilet for SensoWash® & SensoWash® Slim
shower-toilet seat, 14 3/4" x 28 3/8" Inch
14 3/4" x 28 3/8" Inch D40535
All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch & mm and are nonbinding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
SensoWash® Slim SensoWash® Slim shower-toilet seat for
DuraStyle* # 611200001001300 / 611200001101300
|< 14 3/4" Inch >|
