Furniture handrinse basinFurniture handrinse basin DimensionDimension WeightWeight Order numberOrder number
with overflow, with faucet deck, underside fully glazed, wallmounted, hardware included, cUPC® listed*, 19 5/8" Inch
ColorsColors
00 White
VariantVariant
# # pre-marked faucet hole on left and right side, without
faucet hole
19 5/8" x 9 7/8" Inch 21.9 lb 0703500000
p faucet hole on right side
19 5/8" x 9 7/8" Inch 21.9 lb 0703500008
p faucet hole on left side
19 5/8" x 9 7/8" Inch 21.9 lb 0703500009
InfoboxInfobox
* Complies with following standards: ASME A112.19.2/CSA B45.1
Sanitary ceramics with the special WonderGliss surface finish will remain clean and attractive-looking for a long
time to come.
When ordering WonderGliss please add a "1" as eleventh digit to the model number.
Space-saving siphon 1 1/4" Inch 0.9 lb 005076
Suitable productsSuitable products
Vanity unit wall-mounted 1 door, for Vero # 070350, 17 3/4" x 8
7/8" Inch
17 3/4" x 8 7/8" Inch KT6629 L/R
Vanity unit wall-mounted 1 door, for Vero # 070350, 17 3/4" x
9" Inch
17 3/4" x 9" Inch XL6208 L/R
All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch & mm and are nonbinding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
Vero Furniture handrinse basin # 0703500000 / 0703500008 /
0703500009
|< 19 5/8" Inch >|
