Toilet wall-mounted Duravit Rimless for SensoWash®Toilet wall-mounted Duravit Rimless for SensoWash® DimensionDimension WeightWeight Order numberOrder number
rimless, washdown model, Durafix included, only in
combination with SensoWash, connecting elements for
SensoWash with concealed connections included, cUPC listed
ColorsColors
00 White 20 HygieneGlaze (an antibacterial ceramic glaze that
provides almost indefinite effectiveness)
VariantVariant
© 1.6/0.8 gpf
15" x 22 1/2" Inch 54 lb 256159..92
InfoboxInfobox
Durafix for concealed fixation is included, In-wall tank & carrier and actuator plate required for installation / Refer
to page XXX
Sanitary ceramics with the special WonderGliss surface finish will remain clean and attractive-looking for a long
time to come.
When ordering WonderGliss please add a "1" as eleventh digit to the model number.
Connecting set in combination with SensoWash 100691
Pre-installation set in combination with SensoWash, for in-wall
carrier with horizontal support without shower toilet preinstallation/condiut pipe
005072
Noise reduction gasket for wall-mounted toilet 0.7 lb 005064
Suitable productsSuitable products
SensoWash Slim shower-toilet seat for P3 Comforts* with
concealed connections, remote control included, locking
function via remote control, rear-, front and oscillating wash,
individual adjustment of water temperature, spray wand
position and water spray intensity, self-cleaning wand, with
slow close, night light, seat and lid easily removable with one
hand, automatic drainage in periods of prolonged disuse, on /
off-button, 15 1/8" x 21 1/4" Inch
15 1/8" x 21 1/4" Inch 611400
P3 Comforts Toilet wall-mounted Duravit Rimless for
SensoWash® # 256159..92
|< 15" Inch >|
Page 2
All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch & mm and are nonbinding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
P3 Comforts Toilet wall-mounted Duravit Rimless for
SensoWash® # 256159..92
|< 15" Inch >|
