Congratulations on your purchase of the Notebook PC. Your new
notebook features the most innovative advances in portable computing
technology. It combines state-of-the-art ergonomics with sophisticated
architecture to provide you with a personal computer that is compact,
powerful, and easy to use. Designed for a wide range of general,
business, and personal productivity applications, the notebook is an
ideal choice for use in the office, at home, and on the road.

This Manual contains all the information you need to set up and use
your new notebook. It describes all the features of the notebook in an
easy-to-read yet thorough manner.

2

Inventory

This computer system is designed for years of productive and
pleasurable computing. Use this section to keep details of your
purchase. This information will be required should you need to make
repairs to your notebook during the warranty period. Update this
section when you add new options.

Chapter 1

DATE OF PURCHASE:
PLACE OF PURCHASE:
DEALER'S NAME:
DEALER'S ADDRESS:
TELEPHONE:
E-MAIL ADDRESS/WWW:
CONTACT PERSON:
MODEL NUMBER:
SERIAL NUMBER:
BIOS VERSION:

The serial number is on the label (with a bar code) on the bottom side
of the computer. The BIOS revision number will appear briefly on the
screen after turning on the computer, before the graphic BIOS screen
appears. Press the Del key to enter BIOS setup screen.

3

Chapter 1

Safety and Maintenance

You can use your computer under a wide range of environmental
conditions. However, to ensure long use and continued high
performance, consider the following factors when setting up your
computer:

• Follow all warnings and instructions noted in this documentation
and in the Windows Help program.

• The first time you use your computer, we recommend that you
carefully read th e Making Connections section of t hi s ma nu al and
initialize the battery to ensure optimum battery performance.

• Unplug the computer from the power outlet before cleaning. Do
not use aerosols, solvents, or strong detergents.

• Do not use the computer near open water or other liquids. Never
spill liquid onto the computer.

• Do not place the computer in an unstable location where it might
slip or be knocked over. Serious damage could result from a fall.

• Slots and openings in the system cabinet are for ventilation
purposes. Do not block or cover these openings or the system
could overheat. Do not use or store the computer near a source of
heat or dust.

• On the base or rear panel of this notebook, there is a label with
information on the power requirements of this system. These
requirements mus t be followed. If you are unsure of your local
power supply, consult your dealer or local Power Company.

• Do not step on or place anything on the power cord.

• If you use the computer with an extension cord, ensure that the

total ampere rat ings of all the devices sharing the extension do not
exceed the rating of the extension cord or the rating of the wall
outlet.

• Never push foreign objects into the computer through any of the
slots or openings. Dangerous voltages are present, which could
cause electric shock or fire, or damage sensitive components.

• For best results, use a power strip with a built-in surge protector.
Do not use inferior extension cords as this may result in damage
to your computer.

4

• Set the computer on a flat, stable surface. To prevent damage to
the computer’s hard disk drive, avoid using the computer where it
will be exposed to strong vibration.

Checklists

After opening the package, carefully inspect the contents. If any of th e
items is missing or appear damaged, contact your dealer. The
shipping carton should contain the following:

STANDARD

A notebook computer with a hard disk drive
An internal battery
A COMBO or DVD-Super-Multi drive
An AC adapter with power cord

OPTIONS

The following items are normally optional, but some vendors may
include them in the standard package. Some items may not be
available in some countries, or some vendors may choose not to carry
all the items.

A Carry bag

Chapter 1

Caution: When purchasing any of the accessories
listed above, purchase only those accessories that
are approved for use with your computer. The above
accessories are proprietary items. Your system
vendor can obtain these approved accessories. If
you use items that are not approved for use with
this computer, you may cause your computer to
malfunction, or to emit or receive electro-magnetic
radiation in excess of local regulations. For non­proprietary accessories such as PC cards or
printers, ensure that the accessory functions
properly in your computer before making the
purchase. Your system vendor may be able to
recommend reliable brands and models.

5

Chapter 1

Features

High Capacity Hard Disk Drive

The computer has a high capacity hard disk drive, to store your favorite
programs and large multimedia files.

Built-in Modem/LAN Capability

Built-in 56k modem and 10/100 Mbps Ethernet port allows you to access
the Internet or a local area network (LAN).

Built-in Stereo Speakers

The stereo speakers enable you to run a variety of multimedia applications.

Convenient Audio Control

The conveniently located audio control knobs enable you to easily adjust
the volume to the stereo speakers.

Function Keys

Function keys give you easy control of power management and your
monitor.

Scrolling Buttons

Comfortably scroll through documents with the ergonomically designed
scrolling button.

Where to Look For Information

About Your Computer

This User’s Manual describes the key elements of your computer. New
users can find a simple step-by-step orientation in the Quick Start section
of this chapter.

About Windows

Windows Online Help, found on the Start menu, offers extensive Windows
assistance. Find it in:

Start/Programs/Accessories/System Tools.

6

Quick Start

Turning on the Computer for the First Time

1. Connect the AC adapter
power cord to the AC
adapter.

2. Connect the AC adapter
to the DC power port on
the left side of your
computer.

3. Connect the AC adapter
power cord to an AC
outlet.

4. Open the LCD panel to
a comfortable viewing
angle.

5. Press the power button
to turn on the power.

The battery is not fully charged.

Note:

Allow your battery to fully charge before
using it (i.e., before disconnecting AC
power). Calibrating the battery before use
is also highly recommended. Refer to
Chapter 5, Power Management, for further
information.

Chapter 1

Use the touchpad to move the cursor on the screen. Move your finger across the pad to
control the cursor, and press the right and left buttons beneath with your thumb. These
buttons have the same functions as the right and left buttons of a standard mouse. You
can also click or double-click by tapping on the touchpad. The middle button can be
used to scroll up and down in documents and Web pages.

7

Chapter 1

Loading Windows

The following section is for installing the Windows operating system
only. If you are installing a different operating system, please check
with your vendor for installation details.

Your computer will
begin loading Windows
once you turn on the
power. Wait a few
seconds for Windows
setup to load. The
Windows setup will
prompt you for the
product key number,
shown to the right:

Note: The product key is on a sticker
attached to the bottom of the Notebook.

Type your name, and, if applicable, t he name of your company.
Read the End User's License Agreement. Click Next to accept it.
Enter the product key number. You can find this on the Certificate of

Authenticity on a sticker attached to the computer. Click Finish.
The Start Wizard will prompt you to set the date, and your local time.

After the Start Wizard updates your system settings, the Welcome to
Windows screen will appear. You may disable this feature by clearing
the check box labeled show this screen each time Windows starts.

Product key number

Some software comes preloaded with Windows. New users can
familiarize themselves with this software by selecting Programs from
the start menu, then clicking on programs to run them.

8

Adjusting the Volume

You can adjust the volume with hot key combination as below:

• Fn + F8 decreases the volume

• Fn + F9 increases the volume

• Fn + F10 Mute the volume

Alternatively, you can adjust
the volume with the Windows
volume control applet located
on the taskbar.

Chapter 1

Adjusting the Brightness

Use the following hot key combinations to adjust the LCD panel
brightness:

• Fn + F6 decreases the brightness

• Fn + F7 increases the brightness

9

Chapter 1

Turning off Your Computer

Turning off the computer properly is important to maintaining your
computer.

1. On the Start menu, click
off Computer.

If you are going to be away from the computer for a short period, there
are ways of conserving power without shutting down the system. See
Chapter 3, Power Saving Modes, for details.

Warning:
may result in data loss.

Turn

Shutting off the computer improperly

2. Click the radio button
in the Turn off Computer
Windows screen, and then
click OK.

Making a Startup Disk

If you have trou ble starting Wi ndows, the start up disk can be used to
start your computer and fix many problems. Refer to the Windows user
manual for instructions.

Turn Off

10

Tips for New Owners

Take responsibility for backup

Back up files often. Users who need to manage large amounts of data
may wish to use backup devices such USB drive. If you use your
notebook as a networked workstation with system backup, talk to the
system administrator about backup procedures for your notebook.

Don't leave passwords anywhere on your notebook or
carrying case

Be careful when placing your notebook on an airport
security conveyor belt

In most airports, security conveyor belts are safe for computers. If you
are not sure, ask the security staff. You should keep a close eye on
your computer. When you are in a hurry, make sure that you walk
away with the correct notebook computer!

Tape your business card to the notebook and accessories

Chapter 1

In the workplace, notebooks and accessories may often look exactly
alike, leadi ng to equipm ent mix-ups . Prevent s uch mix-ups by placing
your name on your equipment.

Develop ergonomic work habits

The science of ergonomics studies the relationship between health
and a suitable work environment. For more information on
ergonomics, contact your nearest computer bookstore, or local library.
The Internet also has information on this and other related subjects.

11

Chapter 1

Never take the notebook anywhere without the carrying
case

A broken screen or case can be costly to repair. Prevent accidents by
carrying the computer in a suitable carrying case.

Consider using a lock

For added s ecurity, c onsider pur chasing a Kensingt on lock t o put into
the Kensington lock hole on the left side of your computer (see
Chapter 2, Left View). Use the Ke ns i n gton lock to secure the computer
to a desk or table.

Note: Using a computer for extended periods of
time with a poor workstation setup and incorrect
work habits can cause health problems.

12

CChhaapptteerr 22

GGeettttiinngg SSttaarrtteedd

Chapter 2

Hardware and Software

This chapt er introduces the different components and controls of your
notebook computer, including the hardware components, the software, and
the audio and video systems.

Getting Started

Before you begin using your computer, read this chapter to familiarize
yourself with the main components installed in the system.

14

Front View

Chapter 2

1. LCD release latch

2. LCD panel

3. Keyboard

4. Speakers

5. Touchpad buttons

6. Touchpad

7. Scroll buttons

8. Microphone-in jack

9. Audio-out Jack

10. Status indicators

11. Power button

12. Wireless button

15

Chapter 2

Left View

1. Kensington Lock

Your computer includes a Kensington lock hole to be used with a
standard Kensington lock. You can connect the notebook to a large
object with the Kensington lock to prevent theft of your notebook.
See the documentation that comes with your Kensington lock for
more information.

2. DC-IN Jack

Connect the DC power cable from the AC adapter to this jack.

3. VGA Out ( E xt ernal Video Display) Po rt

The 15-pin VGA port can be used to connect your computer to an
external monitor. (See the Graphics System in chapter 2 for more
information).

4. LAN RJ-45 Jack

With the built-in Ethernet LAN function, you can make LAN
connections without installing PC cards. Connection speed is
10/100/1000 Mbps.

16

Chapter 2

5. USB (Universal Serial Bus) Ports

The Universal Serial Bus (USB) is the latest standard for attaching
monitors, input devices, scanners, and other devices to a PC. USB
devices can be chained together on a single cable.

6. PCMCIA Card Slot

The PC card slot can be used as an interface between your
computer and a variety of communications devices, such as
network adapters, SCSI adapters, fax/modems, or provide
additional data storage capacity.

17

Chapter 2

Right View

1. USB (Universal Serial Bus) Ports

The Universal Serial Bus (USB) is the latest standard for attaching
monitors, input devices, scanners, and other devices to a PC. USB
devices can be chained together on a single cable.

2. Fax/modem RJ-11 Jack

The fax/modem can transmit data using the 56 Kbps V.92 protocol,
and send and receive faxes at 14.4 Kbps. In some countries, local
regulations may not permit the use of the fax/modem designed for
this system. In this case, you may use a PCMCIA modem.

Warning:

Plug your modem into an analog telephone
jack only. Most homes use analog lines. Do
not use digital lines, such as the PBX and
ISDN systems found in many offices. Digital
lines may damage your modem.

18

Chapter 2

3. Optical Drive

The Notebook PC comes in various models with different optical
drives. See the marketing specifications for details on each model.

4. RS-232/Serial Port

The RS232 Port provides the connection for RS232 interface
devices such as mice and modem.

19

Chapter 2

Front View

1.Audio-out Jack

Connect a stereo headset or external speakers to this jack to listen
to multimedia.

2. Microphone-in Jack

Connect a microphone this jack to record audio.

20

Bottom View

1. Air Vents

2. Battery Release Button

3. Battery

Chapter 2

Note: Make sure that papers, books, clothing,
cables or other objects do not block any of the
air vents or else overheating of the Notebook PC
may occur.

21

Chapter 2

LED Status Indicators

The power and st atus indicators light up when a part icular functi on of
the computer is active. Each indicator is marked with a symbol.

Icon Light Description

The computer is reading

ODD Green

HDD Green

Number-Lock Green

Caps-Lock Green

Scroll -Lock Green

AC Power

Blue

Flash blue

from, or writing to the built­in ODD.

The computer is reading
from, or writing to the built­in HDD.

The keyboard is in Num­Lock mode.

The keyboard is in Caps­Lock mode.

The Touchpad is in scroll­Lock mode.

Power is on and the AC
adapter is in use

Power is in suspend mode

Battery Power

Battery
Charging

Blue

Flashing
blue

Green

Orange Battery charging
Flash orange

22

Power is on and the battery
is in use

Power is in suspend mode

Battery fully charged & AC
plugged in

Battery low

Function Keys

Hold the Fn key while pressing the numbered function key.

Function key Description

Fn + F3 Toggles backlight On/Off
Fn + F4

Fn + F5

Suspend to RAM/HDD
Suspend mode-Setup from Power Management

Toggles between LCD/CRT displays

(LCD  CRT  LCD+CRT)

Chapter 2

Fn + F6
Fn + F7
Fn + F8
Fn + F9
Fn + F10 Mute
Fn + F1 (F11)
Fn + F2 (F12)

Brightness Decrease
Brightness Increase
Volume down
Volume up

Select Boot device after POST finished
Select Boot from LAN function after POST finished

Numeric Keypad

The embedded numeric keypad
consists of ten keys that make
number intensive input more
convenient. Press <Num Lock>
to enable or disable the nume ric
keypad.

23

Chapter 2

Touchpad

The touchpad is a pressure sensitive pointing device that provides all the
features of a two-button mouse. Its primary function is to move the cursor
around the screen.

The instructions listed below describe how to use the touchpad.

1. First, place your fingers on the keyboard in the normal typing
position. The touchpad is easily accessible by moving either your
left or right thumb off the space bar and on to the touchpad.

2. Gently move your thumb across the pressure-sensitive touchpad in
the direction you want the cursor to move. The pad detects the
change in pressure and moves the cursor in the corresponding
direction.

3. The touchpad offers another method of making selections in a
software program. It is called double-tapping. This function
corresponds to double-clicking with a mouse. Once the cursor
has been moved to the object you want to select, lightly double­tap the pressure sensitive touchpad. This double-tapping on the
touchpad will select the desired item and prompt the software to
perform the related operation.

4. The buttons located directly below the touchpa d are the same in
function as those on a two-buttoned mouse. Clicking these buttons
makes selections, drags objects, or performs a variety of other
functions depending on the software. To select an object, first move
the pointer over the object you want to select, and then press the
left button one time. The functions of these buttons are software
specific.

24

Chapter 2

5. Double-clicking is a common technique for selecting objects or
launching programs from icons. Once you have moved the
pointer over the object you wish to select, rapidly press the left
button two times. This action is commonly referred to as “double­clicking” an object.

Dragging

There are two ways to drag:

• Move the pointer to the desired location then press down the left
button. While still holding down the left button, move the pointer to
the desired location. Release the button.

• Move the pointer to the desired location. Tap the touchpad twice
quickly as if you were double-clicking, however do not remove
your finger after the second tap. Move the cursor to the desired
location. Lift your finger to finish dragging.

Adjust the touchpad settings by selecting Settings / Control Panel /
Mouse / Buttons. These settings allow you to change the orientation of
the touchpad from right-handed to left-handed, and fine tune the
pointer movement and timing of clicks.

Touchpad Precautions

The Touchpad i s a pres sure-s ensi tive de vic e. If not pro perl y cared for,
it can be easily damaged. Please take note of the following
precautions.

• Make sure the touchpad does not come into contact with dirt,
liquids or grease.

• Do not touch the touchpad if your fingers are dirty.

• Do not rest heavy objects on the touchpad or the touchpad

buttons.

25

Chapter 2

The Optical Drive

Your computer comes with a pre-installed optical drive can read both DVDs
and CDs. Your notebook identifies the drive with the latter following the hard
drive. If your hard drive is D, then the optical drive will be E.

Inserting a Disk

1. Press the button on the front of the
drive to open the disk tray and pull
the tray open.

2. Place the disk on the tray, label
side up.

3. Place the disk on the central
spindle and press ge nt l y unt il the
disk clicks into place.

4. Slide back the tray until it clicks
shut.

Removing a Disk

1. Make sure the computer is not
accessing the optical drive.

2. Press the eject button and pull the
tray all the way out.

3. Pick up the CD by the edges and
remove the disk from the tray.
Push the tray into the computer
until it closes fully.

Warning: When the computer is reading from the optical
drive, the indicator LED will flash on. Do not
attempt to remove a disk while this LED is active.

26

Chapter 2

Precautions for Handling DVD-ROM Discs

Keep these precautions in mind when handling DVD-ROM discs.

Always hold the disc by the edges; avoid touching the surface of

•

the disc.

• Use a clean, dry, cloth to remove dust, smudges, or fingerprints.
Wipe from the center outward.

• Do not write on the surface of the disc.

• Extremes in temperature may damage discs. Store discs in a cool

dry place.

• Do not use benzene, thinners, or cleaners with detergent. Only
use optical drive cleaning kits.

• Do not bend or drop the discs.

• Do not place objects on top of discs.

Warning: Do not insert any
foreign objects into the disc
tray. Do not force the tray to
open or close manually. When
not in use, keep the tray
closed to prevent dust or dirt
from entering the drive unit.
If you experience difficulty
when removing a CD disc,
stretch a paper clip (or use a
pin or a thin metal rod) and
insert it into the emergency
eject hole located on the
front panel:

The CD disk tray should eject immediately. This procedure
can also be used to remove a CD from the drive when the

notebook is powered off.

27

Chapter 2

Connecting the Printer

To connect a printer to your notebook via the USB port, use t he supplied
USB to printer adapter cable.

Before use, you must install the driver for the adapter cable.

Note:

The Express Card Slot

The express card slot can be used as an interface between your
computer and a variety of communications devices, such as network
adapters, SCSI adapters, fax/modems, or provide additional data
storage capacity.

Installing a Card

1. The top side of a express card is
usually identified with a label.
Insert the card into the slot with
the label side up and the edge
with pinhole contacts going in
first.

2. Insert the card into the slot. You
will feel some resistance as the

Slide the card into the slot.

card slides into the back of the
slot.

3. Express cards require drivers, or a program that allows the operating
system to use a specific device. Many drivers are included with Windows,
but if not, you will be prompted to install the driver included with your
card.

4. The comput er will beep twice to indicate successful installation.

28

Note: Please read the instructions included with individual express

cards. Some cards may be inserted with power on, while others
require that the computer be turned off.

Removing a Card

Press again to release the card.

Express Card Size Restrictions

Chapter 2

• The card will not able to eject if it is less the 75mm.

29

Chapter 2

The Graphics System

Your computer has a graphics system, which can easily handle the
demands of today's multimedia computing.

Screen Controls

Brightness

Function keys can increase or decrease the brightness of the monitor.

• <Fn> + <F6> decreases the LCD brightness
<Fn> + <F7> increases the LCD brightness

•

Resolution

1. Click My Computer/Control Panel/Display/Settings. Click the

Settings tab. The dialog box indicates the monitor resolution.

2. Use the slide bar to adjust the resolution. Normally, you should

use the resolution the LCD or monitor was designed for.

High Resolution with an external monitor

Higher resolution modes may be used, as long as the monitor supports
them.

30

Chapter 2

Connecting to an External Monitor

The notebook has a VGA monitor port to connect your computer to an
external monitor.

Using the VGA monitor port

1. Locate the 15-pin VGA monitor port on the left side of your
notebook and connect the video signal cable from the external
monitor (or the VGA adapter) to the monitor port.

2. Connect the power cable from the ext ernal monitor to a power
outlet and turn on the monitor.

3. On your notebook, click the right touchpad button on the
Windows desktop to open the desktop menu. Click Properties
to open the Display Properties window.

4. In the Display Properties window, click

Advanced

in the

Settings tab. Click the Display Modes tab.

5. Under Driver mode, you can select the appropriate options to
change the display to an external monitor.

6. Adjustments to screen resolution and color depth can also be
made in this dialog box.

Tip: To ensure trouble-free video output, the first
time you use an external monitor; change the output in
the Display Properties dialog box. After successfully
switching modes, you may use the video function keys.

Note: Light or dark dots may appear on the LCD due to
technical limitations of LCD manufacturing. This will
not effect normal operation of the LCD.

31

Chapter 2

A

Communication Components

This system provides powerful communication functions, including
built-in Fax/ M ode m an d WLA N .

Fax/Modem

A phone jack on the right side of the computer al lows you to connec t
to the Internet to send and receive data. When used with fax software,
it can be used as a fax. When using this function, first plug the phone
cord into the jack.

ttention:

When using the data communications function, please do
not plug the phone cord into the ISDN or PBX jack to
avoid an electrical surge that will cause the MDC
module to burn.

32

Information about the Wireless button

Wireless LAN button

Enables or disables the built­in wireless LAN. When
enabled, the wireless status
indicator will light. Windows
software settings are
necessary before use.

Even when a Wireless LAN
module has not been built-in
to your computer, the
Wireless LAN indicator lights
and remains active when you
turn on the Wireless LAN
button near the power button
of your computer.

If Wireless LAN module has
been built-in, your notebook
will search for the device and
will display an icon on the
Windows task bar.

Note: If your Notebook does not include a
built-in Wireless LAN module, please turn off
the Wireless LAN button. If turned on, the
indicator lights and remains active even if
no wireless LAN is present.

Chapter 2

Built-in Wireless Local Area Network

The built-in Wireless Local Area Network (WLAN) interface card can
provide a quick access without using cables for the connection to the
network equipments. The interface card adopts the IEEE 802.11
protocol and uses the 5GHz ISM electric wave frequency band as the
transmission interface to set up the communications between the host
computer and other computers.

33

Chapter 2

The way of processing communications through the WLAN interface
card is the same as that through Ethernet interface card. The
“Configurat ion Tool” i s a Window appl ication pr ogram. If us ers have a
computer equipped with the WLAN interface card, then users can use
it to set up the interface card and show the current configuration and
status.

Note: Contact your distributor for the information of
upgrading the wireless local area network.

34

35

CChhaapptteerr 33

PPoowweerr

Maannaaggee

M

meenntt

m

Power Management

Battery Calibration

The first time you use a battery, you should calibrate it. The calibration
process empties and charges the battery one time. This allows the
Windows battery gauge to accurately monitor battery status. To
calibrate a battery, follow these steps:

1. Plug in the AC adapter.

2. Restart the computer and when the startup screen appears,
press

3. In the BIOS Setup Utility, select Advance settings. , choose
Battery Calibration, then press enter.

4. Choose <O K> at the above Battery Learning dialog to begin the
battery calibration.

Battery Calibration will take from 6 to 8 hours, depending on how
much power the battery may already contain.

key to enter the BIOS Setup Utility.

Del

Do you want to do Battery Learning?

[OK] [Cancel]

Chapter 3

Note:

calibrating the battery again every three months.
Each time you charge and discharge a battery, it
loses a tiny part of its storage capacity, so that,
over time, it will store less than its potential
charge. Similarly, if you do not use the battery
for a few days, it will slowly self-discharge, and
when it is recharged, it will hold less than 100%
of the potential charge.

For optimum performance, we recommend

37

Chapter 3

Monitoring Battery Power

There are two ways to
monitor how much power
the battery has left.

1. Click start/Control
Panel/Power
Options; then click
Power Meter.

2. Moving t he cursor to
the battery icon on
the taskbar is the
simplest way to
check on battery
power status.

If you do not see the battery icon, enable it in Start /Control Panel/Power
Options. C hoose the Advanced tab and click “Always show icon on the
taskbar.”

Low Battery Alarms

How your computer responds to a low battery condition is set under

Start/Control Panel/Power Options/Alarms.

Two different power alarms can be enabled or disabled: the Low
Battery Alar m, and the Critical Bat tery Alarm. Use the sli de bar to set the
power level at which the alarms are activated. Click on the Alarm Action
button to choose whether the alarm sounds, displays a message, or both.

Warning: When battery power is low, the Notebook

will display a warning on the screen. Take immediate
action, such as saving files or connecting to the AC
adapter, or data may be lost.

When the computer alerts you that the battery is low, immediately do
one of the following:

• Connect the AC power adapter

• Save your work, turn off the computer and replace the discharged

battery with a charged battery (See Changing the Battery below).

Do not restart the computer until you have connected to an AC
adapter, or replaced the discharged battery with a charged battery.

38

Battery Charging

When you use the AC adapter to connect your Notebook to a power
outlet, the internal battery will automatically begin to recharge. While
the battery is charging, the Battery Charge icon on the Indicator panel
will be active. When the battery is fully charged, the Battery Charge
icon will turn to green.

Power Saving Modes

Adjust the default power management settings in the Power Options/
Advanced dialog box in the Control panel. The Power Options
Properties dialog box allows you to set different actions to take when
the computer is left idle for a certain amount of time.

Suspend Mode

There are sev eral possible sett ings for suspend mode, which can be
selected in the Power Management dialog box: You may have the
notebook standby, suspend, or you can power off the computer
altogether.

Initiating Suspend Mode

There are ways to initiate suspend mode. The settings can be
adjusted in the Power Management dialog box:

Chapter 3

• The computer will automatically enter suspend mode when not
used for a set period of time.

• Selecting the Stand by button in the Shut Down Windows dialog
box.

• Closing the screen cover (assuming no external monitor has been
connected).

• Pressing the power button (if enabled in power settings).

• Pressing the suspend function key <Fn> + <F4>.

Power Button Settings

The function of the power button can be set to Shutdown or Standby in
the Power Man agement Propert ies dial og box in t he Windows Control
Panel. However, holding the power button down for more than four
seconds will force a power off while operating under any situation,
resulting in the loss of any unsaved information.

39

Chapter 3

Power Saving Tips

Avoid operating the fax/modem, or audio and video applications

•

when using battery power. Operating a fax modem, video, or audio
equipment increases the computer's power requirements.

• Decreasing monitor brightness can also save power. Decrease
brightness by pushing <Fn> + <F6>. Increase it by pushing <Fn>
+ <F7>.

When to Replace the Battery

Over time, the battery's capacity gradually decreases. We recommend
that you repla ce your battery when you notice that it begins to st ore
significantly less charge.

Changing the Battery

Change the main battery pack as
follows:

1. Turn off the computer.

2. Close the screen cover and turn the
computer over.

3. Slide the battery latch away from
the battery. Continue to hold it until
the battery is removed.

4. Remove the battery.

5. Make sure the replacement battery
is properly orientated. Insert the
battery into the battery
compartment. Check that the latch
locks back into position.

Heat Considerations

The computer's processor has been specially designed to consume
little power, and generates very little heat. However, working in a hot
environment, or working for long periods may raise the temperature.
Your computer takes the following steps to lower temperature:

40

Chapter 3

 The cooling fan will automatically turn on. You may feel air coming

from a vent at the left side when this happens.

 If the temperature continues to rise, processor activity will be

reduced. You may notice a slight loss of performance when this
happens.

41

CChhaapptteerr 44

UUssiinngg tthhee BBIIOOSS

SSeettuupp UUttiilliittyy

Chapter 4

Using the BIOS Setup Utility

Your notebook has a BIOS setup utility which allows you to configure
important system settings, including settings for various optional
functions of the compute r. This chap ter explai ns how to us e the BIOS
setup utility.

BIOS Setup Menu

The BIOS setup Utility allows you to configure your computer’s basic
settings. When you turn your computer on, the system reads this
information to initialize the hardware so that it can operate correctly.
Use the BIOS setup utility to change your computer’s start-up
configuration. For example, you can change the security and power
management routines of your system.

Starting the BIOS Setup Utility

You can only enter the BIOS setup utility as the computer is booting,
that is between the time you turn on the computer and before the
Windows interface appears. If your computer is already on, shut down
your computer completely (power off) and restart it and then press the
Del key to enter the setup utility.

43

Chapter 4

Navigating and Entering Information in BIOS

Use the following keys to move between fields and to enter
information:

 

↑↓

+ -

Tab

F1

F10

ESC

Users are allowed to enter new values to replace the default settings
in certain fields, and the rest fields are specified by system default
parameters and cannot be modified by users. Reverse the attribute of
the main options and press the Enter key to enter into the submenu.
Press the Esc key to return to the previous configuration page.

Select Screen
Push the up and down arrow keys to move

among selections, then press Enter to make a
selection.

Change Option
Select Field
General Help
Save and Exit

Press Esc to exit any section. If you wish to exit
the BIOS utility without saving changes, go to
the main menu, then press Esc.

44

Chapter 4

The Main Menu

Main Advanced Boot Security Exit

BIOS SETUP UTILITY

System Overview

AMIBIOS

Version: RX.XX

Processor

Type : Intel ® Atom ™ CPU N270 @1.60GHz
Speed: 1660MHz

Processor

Size: 504MB

System Time [XX:XX:XX]

System Date

[ XX/XX/XXXX]

V02.61 ©Copyright 1985-2006, American Megatrends , Inc.

Use [ENTER] , [TAB]
Or [SHIFT-TAB]
to select a field.

Use [+] or [-] to
Configure system Time

←→ Select Screen
↑↓ Select Item

+- Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit

Figure 4-1

45

Advanced Menu

Main Advanced Boot Security Exit

Chapter 4

BIOS SETUP UTILITY

Advanced Setting

Legacy USB Support [ Enabled ]
Configure SATA as [AHCI]
Start FAN Calibration [ Enter ]
Battery Calibration [ Enter ]

Battery Learning Function

←→ Select Screen
↑↓ Select Item

Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit

Figure 4-2

V02.61 ©Copyright 1985-2006, American Megatrends , Inc.

46

Chapter 4

Boot menu

BIOS SETUP UTILITY

Main Advanced Boot Security Exit

1st Boot Device [SATA]

nd

2

Boot Device [CD/DVD]

3rd Boot Device [Network]

Specifies the boot
sequence from the
available devices.

A device enclosed in
Parenthesis has been
disabled in the
corresponding type
menu.

←→ Select Screen
↑↓ Select Item

+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit

Figure 4-3

V02.61 ©Copyright 1985-2006, American Megatrends , Inc.

47

Security menu

Chapter 4

BIOS SETUP UTILITY

Main Advanced Boot

Security Settings

Supervisor Password : Not Installed

User Password : Not Installed

Change Supervisor Password

Change User Password

V02.61 ©Copyright 1985-2006, American Megatrends , Inc.

Figure 4-4

Security

Exit

Install or Change the password.

←→ Select Screen
↑↓ Select Item

Enter Change
F1 General Help
F10 Save and Exit
ESC Exit

48

Chapter 4

Exit menu

BIOS SETUP UTILITY

Main Advanced Boot Security

Exit Options

Save Changes and Exit
Discard changes a nd Exit
Discard Changes

Load Optimal Defaults

V02.59 ©Copyright 1985-2005, American Megatrends, Inc.

Figure 4-5

Exit system setup
after saving the changes.

F10 key can be used
for this operation.

←→ Select Screen
↑↓ Select Item

Enter Go To Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit

Exit

49

Change User Password

With a User password, you can enter the Setup Utility and change or
remove the User password, but you cannot enter the Setup Utility and
change or remove the Supervisor password, nor enable diskette
access if it has been disabled.

Change Supervisor Password

A supervisor password must be set before a lower-level user
password can be set. After selecting Change Supervisor Password,
press Enter. You will be prompted for the new password, and then
again to verify it. Type in 6 or fewer keystrokes. If you make an error,
press Esc to start over.

Resetting the CMOS to Default Settings

The main page provides the system parameters for you to reset the
CMOS to default settings. After you enter this page, select the Load
Optimal Defaults:

Load Optimal Defaults?

[OK] [Cancel]

Chapter 4

Select [OK] to reset the CMOS to default settings.

Exiting and Saving

Save Settings
and Exit

Exit Without
Saving

Select this option to save changes to the field
values, and rest art t he c omp ute r us ing t he new
values. (Pres s ing F10 fro m any of th e men u
screens also allows you to save settings and exit.)

Select thi s opt io n t o di sc ard a ny c han ges y ou h ave
made to the fiel d v al ues, an d res t art t he c omp ute r
using the old val ues .

50

AAppppeennddiixx AA

FFrreeqquueennttllyy

AAsskkeedd

QQuueessttiioonnss

Appendix A

Frequently Asked Questions

Q: My screen seems to time out too quickly. I have to constantly

hit a key or move the mouse in order to bring it back. How can
I adjust the screen time-out?

A: This is part of Windows Power Management. Access Power

Management by clicking on
Power Management. Adjust the display time-out by selecting a
time next to the Turn off monitor option. You may also select
different time-out values for adapt er and battery power states.

Q: I've heard that cleaning up and rearranging files on the hard

drive will improve the startup speed of my programs. How do I
do this?

A: Hard disk maintenance can improve the startup speed of programs.

This maintenance includes deleting unnecessary files, and
defragmenting, which rearranges data into more efficient
groupings. Windows includes utilities for performing these
maintenance tasks. Run Disk Cleanup to remove unnecessary
files, and Disk Defragmenter to defragment the hard drive. For
more information, refer to Windows documentation.

Start / Settings / Control Panel /

Q: The internal fax/modem dial tone sound is too low. How can I

increase the volume?

A: There are two methods t o adj u st the volume of the internal

fax/modem dial tone:

Method 1:

Method 2:

To Start/Setting/Control panel/Phone and Modem
Options/Modem/Properties/Modem/Speaker Volume Adjust.
Move the slider to adjust the modem speaker volume..

Use the volume control button on the front of the
computer.

Q: What kind of external microphone can I use with my notebook

computer?

A: You will need to use a self-amplifying microp hone.

Q: There is feedback noise coming from my speakers. What can I

do?

52

Appendix A

A: Double click on the Speaker icon on the task bar. Then, under

Microphone Balance, check the Mute box.

Q: Because of a software problem, I was unable to shut down

power normally. I pressed the power button to force a power
off, but it didn't work. How can I force a power off?

A: Make sure you press the power button for at le ast 4 seconds.

Normally, this will force a power off. If this does not work, you can
shut down the computer by inserting a needle into the reset button
pinhole. (The reset button locates on the computer bottom side.)

Q: Why can’t I charge the battery of my portable computer after it

was out of use for some time?

A: Aft er portable computers hav e not been used for a long time (more

than one month), the batteries will go into the low voltage
protection mode due to data back-ups and natural electrical
discharge. At that point, restoring normal voltage will require slow
charging over a period of several hours. Calibration can be
performed after the battery has returned to a normal condition.

Q: My computer alerts “CMOS Battery Low”, what can I do?

A: If you keep your computer in no power situation (unplug the

computer from the power outlet and remove battery at the same)
over 45 days, your data in CMOS will be lost.

Please reconfigure your CMOS by following steps:

1. Press

to enter the BIOS setup utility.

DEL

2. Select “Load Optional Defaults?”. When you see the
following prompt, choose <OK> and then press <Enter>.

Load Optional Defaults?

[OK] [Cancel]

3. Select

“Save Changes and Exit”.

When you see the
following prompt, choose <OK> and then press <Enter> to
restart your computer.

53

Appendix A

Save configur ation changes and exit setup?

[OK] [Cancel]

54

AAppppeennddiixx BB

SSttaatteem

meennttss

Appendix B

Statements

Federal Communications Commission Statement

This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:

 Reorient or relocat e the receiving antenna.
 Increase the separation between the equipment and the receiver.
 Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

 Consult the dealer or an experienced radio/TV technician for

help.

Shielded interconnect cables and shielded AC power cable must be
employed with this equipment to insure compliance with the pertinent
RF emission limits governing this device. Changes or modifications not
expressly approved by the system's manufacturer could void the
user's authority to operate the equipment.

Declaration of Conformity

This device complies with part 15 of the FCC rules. Operation is
subject to the following conditions:

• This device may not cause harmful interference

• This device must accept any interference received, including

interference that may cause undesired operation.

56

Appendix B

About The Modem

This equipment complies with Part 68 of FCC rules. On the bottom of
this equipment is a label that contains, among other information, the
FCC registration number and ringer equivalence number (REN) for
this equipment. If requested, this information must be provided to the
telephone company.

The modem jack of this equipment com plies with Sub-part F of Part 68
of FCC rules.

The REN is used to determine the quant ity of devices that may be
connected to the telephone line. Excessive RENs on the telephone
line may result in the devices not ringing in response to an incoming
call. In most, but not all areas, the sum of the RENs should not exceed
five (5.0). To be certain of the number of devices that may be
connected to the line, as determined by the total RENs contact the
telephone company to determine the maximum REN for the calling
areas.

If the terminal equipment causes h arm to the telephone network, the
telephone company will notify you in advance that temporary
discontinuance of service may be required. However, if advance notice
isn't practical, the telephone company will notify the customer as soon
as possible. Also, you will be advised of your right to file a compliant
with the FCC if you believe it necessary.

The telephone c ompany may mark changes in it s facilities, equipment,
operations, or procedures that could affect the operation of the
equipment. If this happens, the telephone company will provide
advance notice in order for you to make the necessary modifications in
order to maintain uninterrupted service.

If trouble is experienced with this equipment, please contact the
manufacturer for repair and (or) warranty information. If the trouble is
causing harm to the telephone network, the telephone company may
request you remove the equipment from the network until the problem
is resolved.

The equipment cannot be used on public coin service provided by the
telephone company. Connection to Party Line Service is subject to
state tariffs. (Contact the state public utility commission, public service
commission or corporation commission for information.)

57

Appendix B

The Telephone Consumer Protection Act of 1991 marks it unlawful for
any person to use a computer or other electronic device, including fax
machines, to send any message unless such message clearly
contains in a margin at the top or bottom of each transmitted page or
on the first page of the transmission, the date and time it is sent and
an identification of the business or other entity, or other individual
sending the message and the telephone number of the sending
machine or such business, other entity, or individual. (The telephone
number provided may not be a 900 number or any other number for
which charges exceed local or long-distance transmission charges.)
To program this information, refer to the manual of the communication
software.

UL CAUTION

To reduce the risk of fire, use onl y No. 26 AWG or larger
telecommunication line cord.

IMPORTANT SAFETY INSTRUCTIONS

When using your telephone equipment, basic safety precautions
should always be followed to reduce the risk of fire, electric shock and
injury to persons, including the following:

Do not use this product near water, for example, near a bathtub, wash
bowl, kitchen sink or laundry tub, in a wet basement or near a
swimming pool.

Avoid usin g a telephone (other than a cordless type) during an
electrical storm. There may be a remote risk of electric shock from
lightning.

Do not use the telephone to report a gas leak in the vicinity of the leak.
Use only the power cord and batteries indicated in this manual. Do not

dispose of batteries in a fire. They may explode. Check with local
codes for possible special disposal instructions.

Canadian Department of Communications

This class B digital apparatus meet s all requirements of the Canadian
Interference-causing Equipment Regulations.

58

Appendix B

About the Modem

The Industry Canada label identifies certified equipment. This
certification means that the eq uipment meets certain
telecommunications network protective, operational and safety
requirements. The department does not guarantee the equipment will
operate to the user's satisfaction.

Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local
telecommunications company.

The equipment must also be installed using an acceptable method of
connection. In some cases, the company's inside writing associated
with a single line individual service may be extended by means of a
certified connector assembly (telephone extension cord). The
customer should be aware that compliance with the above conditions
may not prevent degradation of service in some situations.

Repairs to certified equipment should be made by an authorized
Canadian maintenance facility designated by the supplier. Any repairs
or alterations made by the user to this equipment, or equipment
malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.

Users should ensure for their own protection that the electrical ground
connections of the power utility, telephone lines and internal metallic
water pipe system, if present, are connected together. This precaution
may be particularly important in rural areas.

CAUTION:

"The Load Number (LN ) ass igned to each terminal devic e de no t e s t he
percentage of the total load to be connected to a telephone loop which
is used by th e device. To prevent overloading, the termination on a
loop may consist of any combination of devise subject only to the
requirement that the total of the Load Numbers of all the devices does
not exceed 100."

Users should not attempt to make such connections
themselves, but should contact the appropriate electric
inspection authority, or electrician, as appropriate.

Battery disposal

THIS PRODUCT CONTAINS A LITHIUM-ION OR NICKEL- M ETAL HYDRIDE
BATTERY. IT MUST BE DISPOSED OF PROPERLY. CONTACT LOCAL
ENVIRONMENTAL AGENCIES FOR INFORMATION ON RECYCLING AND
DISPOSAL PLANS IN YOUR AREA.

59

Appendix B

CAUTION FOR AC ADAPTER

THIS NOTEBOOK COMPUTER IS FOR USE WITH SUITABLE ADAPTER RATED
20V, 3.25A

CAUTION FOR EXPRESS CARD SLOT

PLEASE INSERT THE DUMMY CARD WHEN THE SLOT HAS NOT BEEN USED

BATTERY CAUTION

DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.
REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY

THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE
MANUFACTURER'S INSTRUCTIONS.

OPERATING ENVIRONMENT

OPERATING TEMPERATURE: 5 ℃ ~ 35 ℃

CLASS 1 LASER PRODUCT

LASERSCHUTZKLASSE 1 PRODUKT TO EN60825

CAUTION:

THIS APPLIANCE CONTAINS A LASER SYSTEM AND IS
CLASSIFIED AS A "CLASS 1 LASER PRODUCT.” TO USE THIS
MODEL PROPERLY, READ THE INSTRUCTION MANUAL
CAREFULLY AND KEEP THIS MANUAL FOR FUTURE
REFERENCE. IN CASE OF ANY TROUBLE WITH THIS MODEL,
PLEASE CONTACT YOUR NEAREST "AUTHORIZED SERVICE
STATION.” TO PREVENT DIRECT EXPOSURE TO THE LASER
BEAM, DO NOT TRY TO OPEN THIS ENCLOSURE.

60
