Duplo Duprinter DP-22SII, Duprinter DP22LII, Duprinter DP-24SII Instruction Manual

Ver.1

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Introduction

Thank you for your purchase of the Duprinter DP-22SII/22LII/24SII. To ensure safe and efficient prolonged use of this machine, read and thoroughly understand this manual before using this machine. After using this manual, be sure to keep it in a place to handy reference.

PLEASE NOTE

In the interest of upgrading our products, specifications and other data given in this manual are subject to change without notice. If the manual contains anything that you do not understand, contact the manufacturer for clarification.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Function Quick Reference

The following is a quick reference to the functions of the DP-22SII/22LII/24SII printer.

Enlargement/Reduction ........

(a P.39)

This function copies a document on one standard paper size to another larger or smaller standard paper size.

B4 Printout

A4 Document

B5 Printout

94% Reduction .......

(a P.40)

This function slightly reduces the size of a document when printing to the same standard paper size as the document.

A4 Document A4 Printout

(94%)

1%-Step Enlargement and Reduction .........

(a P.42)

This function enlarges or reduces a document in 1% steps between 50% and 200%.

Printout

Document

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Book Shadow Eraser Mode .........

(a P.60)

This function erases the shadows on the center or edges of book or other folded documents when printing the open spread.

Printout

Document

Text/Photograph/Text and Photograph Mode .........

With shadow eraser

Printout

Without shadow eraser

(a P.47)

This function selects the optimum print quality to match the document.

Text

ABCDEFGH

ABCDEFGHIJKLNO PQRSTUVWXYZ abcdefghijklmnopqrs tuvwxyz ABCDEFGHIJKLNO PQRSTUVWXYZ abcdefghijklmnopqrs tuvwxyz ABCDEFGHIJKLNO PQRSTUVWXYZ

Text/Photograph

ABCDEFGH

ABCDEFGHIJKLNO PQRSTUVWXYZ abcdefghijklmnopqrs

Photograph

Multiple Printing .............

(a P.56)

This function prints Multiple images of a document on one page.

Document

2 images

4 images

8 images

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

2-in-1 Layout

Available only with ADF installed

.........

(a P.58)

This function prints two different documents on one page.

Documents

Batch Printing ........

(a P.63)

You can print the specified number of sets of copies in each set.

Document

1st set

5 copies x 2 sets

1 1 1

2nd set

3 copies x 4 sets

Printout

3rd set

2 copies x 5 sets

Changing Print Quantity per Document .........

(a P.67)

This function changes the number of prints made from each document.

Documents

1st document

5 copies x 2 sets

2nd document

3 copies x 4 sets

3rd document

2 copies x 5 sets

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Contents

Introduction ......................................................................................................................... 1

Function Quick Reference ................................................................................................. 2

Notes on Safety (Please Read and Observe) ................................................................... 8

Safety Precautions .............................................................................................. 8

Warning Sticker ........................................................................................................ 11

Positioning the Machine ........................................................................................... 12

Maintenance ............................................................................................................. 13

Printing and Duplicating Cautions ............................................................................ 14

Conventions Used in This Manual ............................................................................ 15

Chapter 1 Before Using This Machine

System Setup .................................................................................................................... 18

Part Names and Their Functions ..................................................................................... 19

Printer Appearance .................................................................................................. 19

Control Panel ............................................................................................................ 22

LCD Panel ................................................................................................................ 24

Turning Power ON/OFF .................................................................................................... 25

Turning ON Printer Power......................................................................................... 25

Turning OFF Printer Power ....................................................................................... 26

Standard Mode ......................................................................................................... 26

Key Card Counter [Available only with Key Card Counter installed] ......................... 27

Document/Printing Paper Specification ......................................................................... 28

Acceptable Documents ............................................................................................ 28

Acceptable Printing Paper ........................................................................................ 28

How Platemaking and Printing is Performed ................................................................. 29

Platemaking.............................................................................................................. 29

Printing ..................................................................................................................... 29

Chapter 2 Printing Using Basic Functions

Basic Printmaking ............................................................................................................ 32

Loading and Replacing Paper ......................................................................................... 34

Loading Paper .......................................................................................................... 34

Adjusting Paper Feed Pressure ................................................................................ 35

Loading Documents ......................................................................................................... 36

Positioning the Document......................................................................................... 36

Loading Document on Document Glass Plate ......................................................... 37

Loading Document in ADF [Available only when ADF installed] .............................. 38

Enlargement and Reduction ............................................................................................ 39

Enlarging/Reducing from Standard-Size Document to Standard-Size Paper .......... 39

94% Reduction ......................................................................................................... 40

1% - Step Enlargement and Reduction .................................................................... 42

Selecting Printing Paper Size .......................................................................................... 44

Text/Photograph/Text and Photograph Mode ................................................................ 46

Print Output ....................................................................................................................... 48

Installing Print Tray ................................................................................................... 48

Truing up Printed Pages ........................................................................................... 50

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Contents

Chapter 3 Printing With Various Function

Saving Settings................................................................................................................. 52

Saving Settings ........................................................................................................ 52

Retrieving Settings ................................................................................................... 54

Clearing Settings ...................................................................................................... 55

Multiple Printing on One Page......................................................................................... 56

2-up Function ........................................................................................................... 56

2-in-1 Layout [Available only when ADF installed].................................................... 58

Book Shadow Eraser Mode ............................................................................................. 60

Adjusting Plate Darkness ................................................................................................ 62

Batch Printing ................................................................................................................... 63

Batch Printing ........................................................................................................... 63

Batch Printing (changing print quantity per document) ............................................ 67

Dividing Sections with Tape [Available only with Tape Cluster Device]..................... 70

Chapter 4 Miscellaneous Functions

Confidential Safeguard Function .................................................................................... 74

Total Counter Display Function ....................................................................................... 75

Print Speed Adjustment Function ................................................................................... 76

Printing Position Adjustment Function .......................................................................... 77

On-Line Print Function [Available Only With Interface Kit Installed] ........................... 78

Chapter 5 Replacing Consumables

Replacing the Ink Pack..................................................................................................... 80

Replacing the Master Roll ................................................................................................ 83

Replacing the Master Ejection Core ............................................................................... 86

Replacing the Drum Unit .................................................................................................. 88

Removing the Drum Unit .......................................................................................... 88

Installing the Drum Unit ............................................................................................ 90

Chapter 6 Troubleshooting

Countermeasures to Troubles ......................................................................................... 94

Power Does Not Turn ON ......................................................................................... 94

Platemaking/Printing is Not Possible ........................................................................ 94

Error Messages ................................................................................................................. 95

Supplying or Changing Paper While Printing ................................................................ 98

If Paper Runs Out During Printing ............................................................................ 98

Adding Paper While Printing ..................................................................................... 98

Changing Paper Selection While Printing ............................................................... 100

Paper Jams ..................................................................................................................... 102

When “PAPER LEFT JAM” is Displayed (Feed Tray) .............................................. 102

When “PAPER RIGHT JAM” is Displayed (Print Tray) ............................................ 103

When “MAST. EJECT ERROR” is Displayed................................................................. 106

When “MASTER SET MISS” is Displayed ..................................................................... 109

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Contents

Chapter 7 Specifications and Maintenance

Specifications ................................................................................................................. 114

Appendix

Index ................................................................................................................................ 118

Quick Operation Guide .................................................................................................. 120

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

Safety Precautions

Various symbols and pictures are used in this manual and on the stickers affixed to the machine. These symbols and pictures provide warnings and instructions to prevent danger to you or other personnel, and to prevent damage to office property. The meanings of these symbols and pictures are explained below.

WARNING

CAUTION

[Examples of Pictorial Symbols]

• These are particularly important safety points and should always be observed.

If the machine is used after foreign matter (metal fragments, water, or liquid) has entered the machine, this may result in fire or electric shock.

• Turn the main unit’s power switch OFF, and then remove the power plug from the outlet. Contact

Indicates a high degree of potential danger. If the warning is ignored, death or serious injury may result.

Indicates a medium degree of potential danger. If the caution is ignored, medium injury or damage to property may result.

A circle with a line through it indicates a prohibited action. The particular act prohibited is indicated by a picture inside the circle. (In the example shown here, the prohibited act is disassembly.)

A black disc indicates an instruction, or sometimes a prohibited action. The instruction itself is indicated by pictorial symbols drawn in white on the disc. (In the example shown here, the instruction is “Remove the plug from the outlet.”)

WARNING

the sales distributor.

If the machine is used after heat, smoke, strange smell, or other abnormality is detected, this may result in fire or electric shock.

• Turn the main unit’s power switch OFF, and then remove the power plug from the outlet. Contact the sales distributor.

Use only the power cord that is provided among the accessories.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

WARNING

Do not modify the machine.

• Doing so may result in fire or electric shock.

Do not remove the rear lid, cabinet, or covers from the machine.

• The inside of the machine contains high-voltage parts, which may cause electric shock.

Do not remove or insert the power plug with wet hands.

• Doing so may result in electric shock.

Do not damage, break, or modify the power cord.

• Do not place heavy objects on, tug, or unnecessarily bend the power cord. Doing so may result in fire or electric shock.

Do not insert or drop metal, flammable material, or other matter through the ventilation holes into the machine interior.

• Doing so may result in fire or electric shock.

Do not place flower vases, flowerpots, cups, or water containers (including metal containers) on top of the machine.

• Fire or electric shock may result if liquid spills inside the machine.

Do not use a source voltage other than that specified. Do not connect two or more loads to a single outlet.

• Doing so may result in fire or electric shock.

Do not place the machine in a humid or dusty area.

• Doing so may result in fire or electric shock.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

CAUTION

Before moving the machine, remove the power plug from the outlet.

• If the cord is damaged, this may result in fire or electric shock.

Remove the power plug itself, not the cord.

• Tugging the cord may damage it (expose conductors, or cause disconnections, etc.), resulting in fire or electric shock.

Do not place the machine in an unstable position, such as on an unsteady support or sloping area.

• If the machine is dropped or falls over, this could result in personal injury.

Once the machine is in position, secure in place using the casters.

• If the machine falls over, this could result in personal injury.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

Warning Sticker

Keep the WARNING stickers clean at all times. If stickers become damaged or come off, replace them with new ones.

WARNING

● Do not remove this cover. The inside of the printer contains movable cutting instruments, contact with which could result in injury.

L1-T3060

WARNING

Do NOT touch the drum or rollers when you operate the jog switch.

Do NOT put hands Inside machine while it is operatung. Hands could get caught up or crushed.

No. Parts No. Name Q’ty

q L1-T3060 Warning Sticker 1 1 w L5-T3020 Warning Sticker 2 1

L5-T3020

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

;

Notes on Safety (Please Read and Observe)

Positioning the Machine

Installing the machine on a flat, stable surface.

Avoid installing the machine in a dusty area.

Avoid installing the machine in the direct sunlight or heat, such as near a stove. Ink may deteriorate and may cause bad prints, while the machine may indicate errors due to overheating caused by sunlight. Also avoid hot, cold, or humid areas since paper may absorb moisture, causing paper jams or wrinkles.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

Maintenance

Clean the exterior of the machine as described below. Tightly wring a soft cloth that has been moistened with water or neutral detergent, and wipe dirt from the machine’s surface. Never use alcohol or organic solvents. Doing so may discolor or damage the machine exterior.

Dust and clean the machine at least once a week to avoid breakdowns. Before cleaning, turn the power switch OFF, and then remove the power plug from the outlet.

To clean the reader glass, use a dry, soft cloth and lightly wipe off any dirt.

WARNING

• Before cleaning, remove the power plug from the outlet. Doing so may result in fire or electric shock.

• Prevent water and neutral cleansers from getting inside the machine. If liquids spill inside the machine, contact your agent immediately. Using the machine with water spilled inside may result in fire or electric shock.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Notes on Safety (Please Read and Observe)

Printing and Duplicating Cautions

There are restrictions on what you may print on this printer. Please be aware that there are some printed materials that are illegal even to possess.

1. Printed Matter Banned by Law

• Paper money, currency, government bonds and national and local bonds cannot be duplicated, even if they are stamped with the “sample” seal.

• Paper money, currency and bonds, etc. that are valid in a foreign country cannot be duplicated.

• Unused postage stamps and postcards cannot be duplicated without government consent.

• Government-issued papers pertaining to stamps, liquor and sales tax laws cannot be duplicated.

2. Printed Matter that Require Caution

• Printed-issued securities (stocks, bills and checks, etc.), passes and tickets require caution in duplicating unless a business is duplicating them for required number for their own business needs.

• Government-issued passports, public- and private-issued driver’s licenses, permits, IDs, passes, food stamps, etc. require caution in duplicating.

3. Copyrighted Materials

Books, music, artwork, prints, maps, diagrams, movies, photography, etc. are banned from duplicating outside the limits of private home use and their related non-sale usage.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

A5 Document

A4 Printout

Notes on Safety (Please Read and Observe)

Conventions Used in This Manual

Each page of descriptions in this manual of how to operate the DP-22SII/22LII/24SII is set up as follows.

Title (Function)

Description of function and example of printing

The illustration is designed to indicate the result of using the selected function.

Enlargement and Reduction

Enlarging/Reducing from Standard-Size Document to Standard-Size Paper

You can enlarge or reduce a standard-size document onto standard-size printing paper.

The following zoom ratios are available when enlarging or reducing a standard-size document onto standard-size printing paper.

■ Enlargements

You can enlarge a standard-size document onto standard-size paper using the following zoom ratios:

● European paper sizes

<DP-22SII>

A5 → A4 .................... 141%

A5 → B5 .................... 122%

B5 → A4 .................... 115%

● U.S. paper sizes

<DP-22LII>

ST → LT..................... 129%

■ Reductions

You can reduce a standard-size document onto standard-size paper using the following zoom ratios:

● European paper sizes

<DP-22SII>

A4 → B5 ...................... 86%

B4 → A4 / B5 → A5 ....81%

A3 → A4 / B4 → B5 ....70%

● U.S. paper sizes

<DP-22LII>

LGL→ LT.....................77%

11×17→ LT ..................74%

11×17→ LT ..................64%

<DP-24SII>

B5 → B4 / A5 → A4 .. 141% A4 → B4 / A5 → B5 ..122%

B5 → A4 .................... 115%

141%

121%

<DP-24SII>

A3 → B4 / A4→ B5..... 86%

B4 → A4 / B5 → A5 ....81%

A3 → A4 / B4 → B5 ....70%

A3 Document

212

Printing Using Basic Functions

A4 Printout

IMPORTANT

• Set the desired zoom ratio before starting the platemaking process.

Description of operational steps

Each step is described in detail.

Illustrations

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

(ENLARGEMENT) key or

Press DUCTION) key.

(RE-

1:1

The illustrations provide a visual reference to which keys to operate and other related conditions.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

STD STD

■ Pictorial Symbols and Other Notations Used in This Manual

IMPORTANT : Introduces instructions for correct operation of the machine. If these instructions are ignored,

the machine may not be able to operate at optimum performance or may break down.

Tip : Introduces information that is useful for operation and maintenance of the machine, or

information about the machine’s performance, etc.

Continue Page

(a P.00 “xxxx”) : Indicates the page number and item containing related information.

In the text of this manual, keys are indicated as follows:

•••

: Indicates that the description of the operating sequence is continued on the next page.

: (PLATE MAKING) key

Chapter 1

Before Using This Machine

This chapter contains essential information such as the names of the machine parts, the

names and functions of keys, etc., on the control panel, and the sizes of documents and

printing papers that you can use. Please be sure to read this chapter carefully before

attempting to use the printer.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

System Setup ..................................................................................................... 18

Part Names and Their Functions ...................................................................... 19

Printer Appearance ...................................................................................... 19

Control Panel ............................................................................................... 22

LCD Panel.................................................................................................... 24

Turning Power ON/OFF ...................................................................................... 25

Turning ON Printer Power ............................................................................ 25

Turning OFF Printer Power .......................................................................... 26

Standard Mode ............................................................................................ 26

Key Card Counter [Available only with Key Card Counter installed] ............ 27

Document/Printing Paper Specification .......................................................... 28

Acceptable Documents ................................................................................ 28

Acceptable Printing Paper ........................................................................... 28

How Platemaking and Printing is Performed .................................................. 29

Platemaking ................................................................................................. 29

Printing......................................................................................................... 29

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Before Using This Machine

System Setup

The machine and its optional equipment are set up as follows:

Duplo Direct Print System

Personal computer

Documents prepared on a personal computer can be printed on this machine. PC interface kit is required to connect this machine to a personal computer.

ADF

Key card counter

Tape cluster

Cabinet

Drum unit

: Option

Part Names and Their Functions

Printer Appearance

Before Using This Machine

No. Name Function

q Document cover Keeps the document in contact with the document glass plate. w Feed tray descend switch Press to lower the feed tray. e Feed pressure adjuster lever Use to adjust the paper feed pressure. r Side guides Slide to match the width of the paper. t Feed tray Load paper in this tray. y Support tray Pull out when loading paper. u Power switch Press to switch the power on and off. i Cabinet (Option) Place the printer on this stand. o Castor locks Lock the printer in position on the floor. Always lock the castor

locks when installing the printer.

!0 Front cover Open to replace ink pack and drum unit, etc. !1 Control panel Displays operations and statuses, and sets functions.

Reference

page

32, 38,

25, 26

—

80, 88

Part Names and Their Functions

Master set lever

When the master set lever is pushed, the master is pulled in and set.

Master roll

Scanner unit

Master cover release lever

Lever

This lever releases the ink pack holder.

Master cover

Front cover

Drum handle

Drum unit

Ink pack

Lever

This lever is locks or unlocks the drum.

Part Names and Their Functions

Master ejection core

Before Using This Machine

No. Name Function

Plate ejection box release lever

!3 JOG switch Press and hold to rotate the drum for a set time. Use to remove

!4 Print tray Holds the printed paper. !5 Paper stopper Slide to match the size of printed paper. !6 Paper stacker guides Slide to match the size of printed paper. !7 Master ejection box Open to replace the master ejection core, etc.. !8

Plate ejection box lid release lever

Press to open the master ejection box.

paper jams, etc..

Press to open the top of the master ejection core box. Use when replacing the master ejection core, etc..

Reference

page

—

49 50 49 86

Part Names and Their Functions

Control Panel

q w e r

1:1

STD STD

No. Name Function

q “OK” monitor Flashes to display the content of the trouble and lights to indicated

the part that caused the trouble in the machine.

w “ENLARGEMENT” key Press to set the enlargement ratio.

“100%” key Press to reset the ration to 100%.

“REDUCTION” key Press to set the reduction ratio.

100% lamp Lights when the 100% ratio is selected.

e “DOCUMENT MODE Press to switch between the text mode, text/photograph mode and

SWITCH” key

Document mode indicator lamps

r LCD panel Displays the number of printed paper.

“FUNCTION SWITCH” key

“SELECT” key Press to select a function.

y “TEST PRINT” key Press to print only one piece of paper for checking the print dark-

u “PLATEMAKING” key Press to start platemaking.

photograph mode. Each press of this key moves the position of the lit lamp that indicates the selected document mode.

The lamp of the selected mode lights.

Also displays an error message when an error occurs.

Press to toggle between the normal mode and the function select mode.

ness or printed position.

Reference

page

24, 95

!4!5!7 !6

Part Names and Their Functions

y ur t

Before Using This Machine

o!0!1!2!3!4

No. Name Function

i “STOP” key Press to stop printing on the way.

o “PRINT” key Starts printing. This will not start platemaking.

!0 “ALL CLEAR” key Returns the control panel settings to the “Standard

!2 Key pad Use to enter the number of prints. !3 “CLEAR” key Press to reset the displayed number of prints to “0”.

!4 Printing speed indicator lamp The lamp of the specified printing speed lights. !5 !6 !7 Printing position indicator lamp The lamp of the specified printing speed lights.

key Press to enter the number of prints and number of sets

“PRINTING SPEED ADJUSTMENT” keys

“PRINTING POSITION ADJUSTMENT” keys

If this key is pressed while the machine is stopped, the total number of prints and plates will be displayed on the LCD panel.

Platemaking will start automatically after the end of printing if there is a document on the ADF (Option).

Mode” settings. Press and hold for at least 0.5 seconds.

for sectional prints.

Only the number of prints is cleared.

Press to adjust the printing speed.

Press to adjust the printing position.

Reference

page

Part Names and Their Functions

LCD Panel

q w e

100

No. Name Function

q Print count Displays the number of prints to be made. w Sets Displays the number of sets to be printed. e Zoom ratio Displays the selected (enlargement/reduction)ratio.

sht 1set

Reference

page

Turning Power ON/OFF

This section describes the operating sequence from turning ON the power switch until the printer is ready to make prints, and how to turn OFF the printer power.

Turning ON Printer Power

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Connect the power cable to the printer and a wall outlet.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Switch the power switch to the “

The power turns ON.

” position.

Before Using This Machine

The message “SET PRINT PAPER” is displayed on the LCD panel. The printer functions are now set in “Standard Mode” (a page 26).

When paper is loaded in the feed tray, the screen shown at right is displayed.

When the screen shown at right is displayed, insert a key card. (a See page 27, “Key Card Counter”.)

SET PRINT PAPER

100

sht 1set

SET KEYCARD

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Turning Power ON/OFF

Turning OFF Printer Power

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Switch the power switch to the “ ” position.

The power turns OFF and the display lamps on the control panel turn OFF.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Standard Mode

When the printer power is first turned ON or (ALL CLEAR) key is pressed, the functions are reset to standard mode. The standard mode settings are as follows:

• Print quantity : 0

• Print position : Standard lit

• Print speed : Standard lit

• Zoom : 100% lights

• Document mode : Standard

• PLATE SIZE : DP-22SII/A4, DP-24SII/B4

• PLATE DARKNESS : NORMAL

• ✕94% : OFF

• Multiple EXPOSURE : OFF

• SHADOW ERASER : OFF

• FREE ZOOM : OFF

Turning Power ON/OFF

Key Card Counter

With the key card counter installed, you can control the platemaking and print quantities per person or per department, etc. See the Instruction Manual for the Key Card Counter for details.

■ Inserting a key card

When you turn on the power, the icon shown at right is displayed if no key card has been inserted in the key card counter.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Insert a key card in the key card counter.

The printer can now be operated as normal.

Available only with Key Card Counter installed

SET KEYCARD

Before Using This Machine

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

■ Handling key cards

Do not bend or soil a key card. Do not insert any objects other than

Keep your key card well away from magnetic fields.

key cards into the key card slot.

Document/Printing Paper Specification

Acceptable Documents

■ Document glass plate

• Weight : Sheet documents, books, etc, not exceeding 10kg.

• Size : 297mm X 432mm

■ ADF

• Document thickness : 64g/m2 to 128g/m

• Document size : A3 to A5 size

ST to 11x17-in. (ST size in landscape mode: STR cannot be used.)

• Stacking capacity in document tray : 100 sheets (64g/m2)

IMPORTANT

The following types of document cannot be used:

• Documents with large file-binding holes, tears, or missing parts

• Documents with staples or paper clips attached

• Documents with markedly curling ends/sides, or marked folds

• Carbon-backed documents

• Sticky documents

• Highly transparent documents such as OHP film

When ADF is installed:

• To make a new plate from a document from which a plate has already been made, remove and then reload the document.

• Always use documents of the same size.

• If you load documents of different lengths, the printer may not operate correctly.

Acceptable Printing Paper

DP-22SII DP-22LII DP-24SII

Paper thickness

Paper stacking capacity

Paper size

Printing area 204mm X 288mm 210mm X 347mm 250mm X 355mm

IMPORTANT The following types of paper cannot be used.

• Paper with large file-binding holes

• Paper with staples or paper clips attached

• Paper with markedly curling ends/sides, or marked folds

• Carbon-backed paper

• Paper with smaller pieces of glued paper

45g/m2 to 210g/m2 (40kg ~ 180kg), 131b (Roud)-1101b (Index)

Feed tray : 1300 sheets (64g/m2 top-grade paper) Print tray : When a cabinet is used:1300 sheets (64g/m2 top-grade paper)

When the printer is used on a table: 900 sheets (64g/m2 top-grade paper)

Max. 297mm X 382mm Max. 297mm X 382mm Max. 297mm X 420mm Min. 100mm X 148 mm Min. 100mm X 148 mm Min. 100mm X 148 mm

DP-22SII DP-22LII DP-24SII

How Platemaking and Printing is Performed

The machine performs two processes: platemaking and printing.

Platemaking

In the “platemaking” process, the old master on the drum is removed while the thermal head creates the scanned image on the new master and transfers it onto the drum.

Before Using This Machine

Printing

In the “printing” process, paper separated from the stack by the feeder roller and paper separator unit is pressed against the drum unit by the press roller. There are small holes over only the image area of the master that is attached to the drum, and ink that seeps from these holes is transferred to the paper. The paper is then peeled from the master by the paper stripper finger. The paper is directed onto the paper ejection belt by a fan unit and discharged from the machine.

Master roll

Thermal head

Master ejection box

Drum

unit

Paper

Feeder roller

Paper separator unit

Drum unit

Ink

Press roller

Paper stripper finger

Paper ejection belt

Fan unit

Chapter 2

Printing Using Basic Functions

This chapter describes how to make prints using the basic functions, including how to load

the document, set zoom ratio, etc.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Basic Printmaking.............................................................................................. 32

Loading and Replacing Paper .......................................................................... 34

Loading Paper.............................................................................................. 34

Adjusting Paper Feed Pressure ................................................................... 35

Loading Documents .......................................................................................... 36

Positioning the Document ............................................................................ 36

Loading Document on Document Glass Plate ............................................. 37

Loading Document in ADF [Available only when ADF installed].................. 38

Enlargement and Reduction ............................................................................. 39

Enlarging/Reducing from Standard-Size Document to Standard-Size Paper

94% Reduction ............................................................................................ 40

1% - Step Enlargement and Reducation ..................................................... 42

Selecting Printing Paper Size ........................................................................... 44

Text/Photograph/Text and Photograph Mode ................................................. 46

Print Output ........................................................................................................ 48

Installing Print Tray....................................................................................... 48

Truing up Printed Pages .............................................................................. 50

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

.... 39

Printing Using Basic Functions

Basic Printmaking

This section describes how to make prints using the basic functions.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Turn ON the power. (

Tip

• If the power is already ON, press

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Load paper. (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

a See page 34, “Loading and Replacing Paper.”)

Load the document.

◆If you are positioning the document on the document glass

plate (a See page 37, “Loading Document on Document Glass Plate”) ...

• Open the document cover.

• Place the document face down on the document

glass plate aligned with the scale.

• Close the document cover.

a See page 25, “Turning Power ON/OFF”)

(ALL CLEAR) key.

Scale

◆If you are loading the document in the optional ADF

(a See page 38, “Loading Document in ADF”) ...

• Adjust the slide guide to the marks for the size of the document.

• Place the document face up in the document tray.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Select the zoom ratio.

The zoom ratio is set to 100%. Press (ENLARGEMENT)key or zoom ratio. (a See page 39, “Enlargement and Reduction”.)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

ABC

(REDUCTION)key to set a desired

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PLATE MAKING) key.

When the plate has been made, one test print is automatically made.

Basic Printmaking

IMPORTANT

• The test print is for verification purposes only and may be fainter than the final print.

Tip

• You can enter the number of desired prints before pressing (PLATE MAKING) key to immediately print the required number of copies.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to specify the number of prints to make.

Tips

• You can specify up to 9999 prints.

• If you make a mistake entering the number of

prints, press correct number.

(CLEAR) key then enter the

Printing Using Basic Functions

Key pad

100

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PRINT) key.

The count displayed on the LCD panel is decremented by one for each print made. The printed pages are output to the print tray. (a See page 48, “Print Output”.)

Tip

• To stop a print run, press (STOP) key. To restart the print run, press (PRINT) key again.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

sht 1set

Repeat steps 3 to 7 to print multiple documents.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Loading and Replacing Paper

Loading Paper

This section describes how to load the printer with paper. You can load approximately 1,300 sheets in this printer.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the support tray.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Hold the lever and adjust the side guides to the paper size.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Load a stack of aligned sheets between the paper guides and press the stack lightly toward the machine.

IMPORTANT

• You can load the feed tray with approximately

1,300 sheets of 55gsm high-grade paper.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Adjusting Paper Feed Pressure

Adjust the paper feed pressure if an feeding error occurs when using thick or thin paper.

■ When no thick paper is fed

Adjust the paper feed pressure adjuster lever to “HIGH”.

■ When two pieces of thin paper are fed

Adjust the paper feed pressure adjuster lever to “LOW”.

Loading and Replacing Paper

Printing Using Basic Functions

Loading Documents

Positioning the Document

The document can be loaded in the “portrait” or “landscape” position.

IMPORTANT

• A4 and B5-size documents can be loaded in the “portrait” or “landscape” position.

• Use the landscape position when enlarging or reducing from standard-size documents to

standard-size paper, such as A5 to A4.

• A3 and B4 documents can only be loaded in the landscape position.

◆ Document Glass Plate

◆ ADF

Portrait (Vertical) Placement Landscape (Lateral) Placement

ABC

Portrait (Vertical) Placement Landscape (Lateral) Placement

ABC

Loading Documents

Loading Document on Document Glass Plate

Use the platen glass when copying from books, thick documents, or thin documents.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Gently open the document cover.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Position the document on the document glass plate.

Place the document face down on the document glass plate, aligned with the guide.

Scale

Printing Using Basic Functions

IMPORTANT

• When you load a non standard-size docu-

ment, place it with the center of the document aligned with the arrow on the guide.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Gently close the document cover.

IMPORTANT

• When you place a thick document such as a

book on the document glass plate, take care not to force the document cover as this may damage the document glass plate with a risk of personal injury.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Loading Documents

Loading Document in ADF

Load documents that consist of a series of sheets to be printed in the ADF. When one or more documents are loaded in the ADF, platemaking and printing are automatically repeated until the document tray is empty.

IMPORTANT

• ADF mode is automatically selected when a document is loaded in the ADF. The ADF then

takes priority over the document glass plate in the platemaking process.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Align the document guide with the marks for the size of document to be loaded in the ADF.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Place the document face-up in the document tray.

Platemaking starts with the top document in the tray.

IMPORTANT

• Do not attempt to remove or add to the

documents in the document tray while platemaking and printing are in progress.

Available only when ADF installed

Document Guide

ABC

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

A4 Printout

A3 Document

Enlargement and Reduction

Enlarging/Reducing from Standard-Size Document to Standard-Size Paper

You can enlarge or reduce a standard-size document onto standard-size printing paper.

The following zoom ratios are available when enlarging or reducing a standard-size document onto standard-size printing paper.

■ Enlargements

You can enlarge a standard-size document onto standard-size paper using the following zoom ratios:

● European paper sizes

<DP-22SII>

A5 → A4 .................... 141%

A5 → B5 .................... 122%

B5 → A4 .................... 115%

● U.S. paper sizes

<DP-22LII>

ST → LT ..................... 129%

141%

121%

<DP-24SII>

B5 → B4 / A5 → A4 .. 141% A4 → B4 / A5 → B5 .. 122%

B5 → A4 .................... 115%

A5 Document

A4 Printout

■ Reductions

You can reduce a standard-size document onto standard-size paper using the following zoom ratios:

● European paper sizes

<DP-22SII>

A4 → B5 ...................... 86%

B4 → A4 / B5 → A5 .... 81%

A3 → A4 / B4 → B5 .... 70%

● U.S. paper sizes

<DP-22LII>

LGL→ LT..................... 77%

11×17→ LT ..................74%

11×17→ LT ..................64%

<DP-24SII>

A3 → B4 / A4→ B5 ..... 86%

B4 → A4 / B5 → A5 .... 81%

A3 → A4 / B4 → B5 .... 70%

Printing Using Basic Functions

IMPORTANT

• Set the desired zoom ratio before starting the platemaking process.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(ENLARGEMENT) key or

DUCTION) key.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

(RE-

1:1

STD STD

Enlargement and Reduction

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(ENLARGEMENT) key or

(REDUCTION) key several times to display

the desired zoom ratio.

In about 3 seconds, the screen changes to the number display screen and the zoom ratio is selected. Press

(ENLARGEMENT) key or

(REDUCTION) key to move the arrow on the LCD panel.

◆ European paper sizes

141% B5 B4/A5 A4 122% A4 B4/A5 B5

141%

0sht

Tip

To return to “100%”, use one of the following two methods:

• Press

• Press (ALL CLEAR) key. In this case, all settings are reset to standard mode

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

1:1

(100%) key. The 100% indicator lamp lights.

(a page 26).

1set

◆ U.S paper sizes

141% 129% ST LT

141%

0sht 1set

94% Reduction

In this mode, the copy is printed at 94% the size of the document. When it is not possible to print the edges of the document image, this mode allows you to make a minor reduciton so that the edges of the image are included.

IMPORTANT

• Select “94% Reduction” before platemaking.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key several times to show the screen at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

3.x 94%

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key to display “ON”.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

94% reduction is set, and the standard screen appears.

Tip

You can cancel 94% reduction using one of the following two methods.

• Set to “OFF” in the same procedure.

• Press

settings are reset to standard mode (a page 26).

(ALL CLEAR) key. In this case, all

Enlargement and Reduction

3.x 94% ON OFF

1 2 3

100% 0sht 1set

1 2 3

94%

Printing Using Basic Functions

You can select 94% reduction even when you have selected other than “100%”. In this case, the zoom ratio will be the zoom ratio shown on the LCD✕94%.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Enlargement and Reduction

1%-Step Enlargement and Reduction

You can set a zoom ratio between 50% and 200% in 1% steps.

IMPORTANT

• Select “1%-Step Enlargement and Reduction” before starting platemaking.

• You cannot select “94% Reduction” at the same time as “1%-Step Enlargement and Reduc-

tion”.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 1 to 4 of the sequence described in “ Basic Printmaking” (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key several times to show the screen at right.

7.FREE ZOOM 100%

a page 32).

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key several times to display actual zoom ratio.

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows. “OFF” → actual zoom ratio → “OFF” ...

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to enter the scaling ratio.

Example:70%

Tip

• You can enter a value for the scaling ratio within the range 50 to 200%. If you enter a value smaller than 50%, "50%" will automatically be selected and displayed, and if you enter a value larger than 200%, "200%" will automatically be selected and displayed.

1 2 3

7.FREE ZOOM 100% OFF

1 2 3

Key pad

7.FREE ZOOM 70% OFF

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

The scaling ratio is set, and the 100% lamp goes out.

key.

Enlargement and Reduction

Tip

• To return to "100%", press C (CLEAR) key.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Stare platemaking and printing. (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

a See steps 5 to 8 of “ Basic Printmaking” (

a page 32).

Printing Using Basic Functions

Selecting Printing Paper Size

Select a paper size.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The screen at right appears on the LCD panel.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key and display the paper size to be used.

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows.

◆ European paper sizes ◆ U.S. paper sizes

• FOR DP-22SII • FOR DP-22LII

“A4” → “B5” → “A5” → “POST”“LG” → “LT ” → “ST” → “MAX” →

• FOR DP-24SII

“B4” → “A4” → “B5” → “A5” → “POST”

1.PLATE SIZE B4

1 2 3

“POST”

[European paper sizes]

1.PLATE SIZE B4 A4 B5 A5

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The paper size is set, and the standard screen appears.

[U.S. paper sizes]

1.PLATE SIZE LG LT ST

1 2 3

100% 1sht 1set

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

MEMO

Printing Using Basic Functions

Text/Photograph/Text and Photograph Mode

This function includes three modes for enhancing text and photographic documents.

■ Text/Photograph/Text and Photograph Mode

In this mode, the print quality is adjusted to match the document.

Text

ABCDEFGH ABCDEFGH

ABCDEFGHIJKLNO PQRSTUVWXYZ abcdefghijklmnopqrs tuvwxyz ABCDEFGHIJKLNO PQRSTUVWXYZ abcdefghijklmnopqrs tuvwxyz ABCDEFGHIJKLNO PQRSTUVWXYZ

Text mode: Enhances the printing of text documents

Documents suited for text mode:

• Text documents

• Documents that include black and white photos that have already been screen

processed.

Text/Photograph mode: Enhances the printing of documents with both text and photographs.

Documents suited for text/photograph mode:

• Documents with both text and photographs.

Text/Photograph Photograph

ABCDEFGHIJKLNO

ABCDEFGHIJKLNO PQRSTUVWXYZ

PQRSTUVWXYZ abcdefghijklmnopqrs

abcdefghijklmnopqrs

Photo mode: Enhances the printing of the subtle gradations of photographs and light images from

color documents. Document suited for photo mode:

• Light-colored color documents

• Color photographs

• Documents with non-screened black and white photographs

IMPORTANT

• Select “Text/Photograph/Text and Photograph Mode” before starting platemaking.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Text/Photograph/Txt and Photograph Mode

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 1 to 4 of the sequence described in “Basic Printmaking” (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(DOCUMENT MODE SWITCH) key

a page 32).

to select the desired mode.

Each time pressed, the lit document mode indicator lamp changes as follows. “Tex t” → “Text/Photograph” → “Photograph” → “Tex t”...

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Start platemaking and printing. (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

(DOCUMENT MODE SWITCH) key is

Tip

To return to “Text mode” use one of the following two methods:

• Press

(DOCUMENT MODE SWITCH) key

to select “Text”.

(ALL CLEAR) key. In this case, all

settings are reset to standard mode (a page 26).

a See steps 5 to 8 of “Basic Printmaking” page 32.)

1:1

STD STD

Printing Using Basic Functions

Print Output

This section describes how to install the print tray and remove printed pages from the print tray.

Installing Print Tray

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Remove the print tray.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Install the print tray.

• When you use the printer on a table, install the print tray into the upper fitting. (Stacking capacity; 900 sheets, 55 kg, high-grade paper)

• When you use a cabinet (option), install the print tray into the lower fitting. (Stacking capacity; 1300 sheets, 55 kg, high-grade paper)

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

When the printer is used on a table.

When a cabinet is used.

Open out the paper stacker guides.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Print Output

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open out the paper stopper.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Adjust the paper stacker guides and paper stopper to the size of the printing paper.

Printing Using Basic Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Print Output

Truing up Printed Pages

Adjust when the edges of the printed pages are not trued up.

■ Adjusting jump plate

Adjust the plate according to the paper size. Ex: Expand the guides fully when using paper with B4

or larger size.

■ Truing up printed pages

When using thinner paper, turn the lever up. When using thicker paper, turn the lever down.

Available only when sorter is installed

Chapter 3

Printing With Various Function

This chapter describes how to make prints using the various printer functions.

Printing With Various Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Saving Settings .................................................................................................. 52

Saving Settings ............................................................................................ 52

Retrieving Settings ....................................................................................... 54

Clearing Settings ......................................................................................... 55

Multiple Printing on One Page .......................................................................... 56

2-up Function ............................................................................................... 56

2-in-1 Layout [Available only with ADF installed] ......................................... 58

Book Shadow Eraser Mode............................................................................... 60

Adjusting Plate Darkness.................................................................................. 62

Batch Printing .................................................................................................... 63

Batch Printing .............................................................................................. 63

Batch Printing (changing print quantity per document) ................................ 67

Dividing Sections with Tape [Available only with Tape Cluster Device] ........ 70

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Saving Settings

You can save and retrieve nine sets of settings for platemaking and printing. The settings are stored in memory even when the power is turned OFF.

Tips

The following settings are saved:

• Number of prints (including sets) • Zoom ratio (Fixed zoom ratios only)

• Plate size • 94% reduction

• Platemaking darkness • Printing speed

• Text/Photo • Printing position

Saving Settings

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Confirm that the LCD panel displays the settings you want to store.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen at right.

5.MEMORYMODE

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times , select "SAVE", then press (FUNCTION SWITCH) key.

The settings are saved, and the standard screen appears. Each time (SELECT) key is pressed, the arrow on the LCD panel moves as follows. “RETRIEVE” → “SAVE” → “CANCEL” →

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to specify the number you want to store. You can store numbers from 1 to 9. Select "C" to cancel.

Tips

• The numbers already stored are displayed flashing. Select a number that is not flashing.

1 2 3

5.MEMORYMODE SAVE

1 2 3

SAVE 123456789 C

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The settings are saved, and the standard screen appears.

Saving Settings

100% 0sht 1set

IMPORTANT

• Any previous settings stored in the memory channel will be deleted when you save new settings.

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Printing With Various Functions

Retrieving Settings

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to display “RE- TRIEVE”.

Each time (SELECT) key is pressed, the arrow on the LCD panel moves as follows. “RETRIEVE” → “SAVE” → “CLEAR” → “CANCEL”

5.MEMORYMODE

1 2 3

5.MEMORYMODE RETRIEVE

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to specify the number you want to retrieve. The saved number blinks. Select the blinking number.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The saved data is retrieved, and the standard screen appears.

1 2 3

RETRIEVE 123456789 C

1 2 3

100% 0sht 1set

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

1 2 3

Clearing Settings

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key several times to show the screen at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to return to the standard screen.

The memory setting that you selected is cleared, and the standard screen appears. Each time (SELECT) key is pressed, the arrow on the LCD panel moves as follows. "SAVE" → "RETRIEVE" → "CLEAR" → "CANCEL"

Clearing Settings

5.MEMORYMODE

1 2 3

5.MEMORYMODE CLEAR

1 2 3

Printing With Various Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to select the number you want to delete.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The number display screen returns.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

CLEAR 123456789 C

1 2 3

Multiple Printing on One Page

This mode allows you to print Multiple copies of the document on one page.

■ Multiple Function (

This mode prints multiple images of the document on one page.

Document

■ 2-in-1 Layout (

This mode prints two different document pages on one page.

a page 58)

a page 61)

Documents

2 images

Available only with ADF installed

Printout

4 images

8 images

2-up Function

This mode prints multiple copies of the document on one page.

• Copying B5 to B4 (2 prints on one page)

Example : DP-24SII

Portrait Placement

B5 B5 B5

Zoom ratio:

IMPORTANT

• Select “2-up Function” before starting platemaking.

• The printable range is slightly smaller than the printing paper.

• You cannot obtain the correct layout if you select the wrong paper size.

Available only with ADF installed

B4, LDG

100%

Multiple Printing on One Page

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 1 to 4 of the sequence described in “Basic Printmaking” (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The 2-UP selection screen appears.

4.MULTI EXPOSURE OFF

1 2 3

a page 32).

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key several times to select “2-UP”.

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows. “2-UP” → “4-UP” → “8-UP” → “OFF” → “2-UP”

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

2-up Function is set, and the standard screen appears.

Printing With Various Functions

4.MULTI EXPOSURE 2-UP

1 2 3

100% 0sht 1set

1 2 3

Multiple Printing on One Page

2-in-1 Layout

Two-in-one (2-in-1) mode allows you to print two small documents on one page and also easily print for creating booklets that will be saddle stitched. When you use 2-in-1 mode, the layout is as follows:

1 2 3 4

Documents (even number)

1 2 3 4 5

Documents (odd number)

IMPORTANT

• Select “2-in-1 Layout” before starting platemaking.

• You cannot use 2-in-1 mode unless the optional ADF is installed.

• Always load the documents in the ADF.

• If you are printing the documents at 100%, select a printing paper that is the size of the two

documents.

• When you enlarge or reduce two documents size by side, select a zoom ratio so that the documents fit exactly on one page.

• Note the following when using 2-in-1 layout mode:

• You must load the document in the ADF in portrait orientation.

• You must select a paper size and zoom ratio that will accommodate two documents.

• Correct layout may not be obtainable with other than standard size papers.

Available only with ADF installed

Printout1

Printout2

Printout3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The 2 IN 1 screen appears.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

4.MULTI EXPOSURE OFF

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press “2IN1”.

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows. “OFF” → “2-UP” → “4-UP” → “8-UP” → “2IN1”

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

2 IN 1 Function is set, and the standard screen appears.

(SELECT) key several times to select

Multiple Printing on One Page

4.MULTI EXPOSURE 2IN1

1 2 3

100% 0sht 1set

Printing With Various Functions

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Book Shadow Eraser Mode

■ Prints book documents without shadows

This mode erases the shadows caused by the book binding when printing an open spread from a book or other folded document. It also erases the shadow around the periphery of the document.

Printout

Document

With shadow eraser

Printout

Without shadow erase

IMPORTANT

• Select “Book Shadow Eraser Mode” before starting platemaking.

• When you select “No shadow erase”, the shadow is erased from approximately 3mm

around the periphery of the document.

• When you select “Shadow erase”, the machine reproduces the document as follows.

6mm

15mm

6mm

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 1 to 4 of the sequence described in “Basic Printmaking” (

a page 32.)

Place the document on the platen glass.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen

6. SHADOW ERASER

at right.

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Book Shadow Eraser Mode

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The book shadow eraser selection screen appears.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key and select “paper size”.

European paper sizes

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows.

“A3” → “B4” → “A4” → “B5” → “A5” → “POST” → “OFF” → “A3”

U.S paper sizes

“WLT” → “10x14” → “LG” → “LT ” → “ST” → “POST” → “OFF”

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

Book Shadow Eraser Mode is set.

Tip

You can cancel Book Shadow Eraser Mode using one of the following two methods.

• Set to “OFF” in the same procedure.

• Press

settings are reset to standard mode (a page 26).

(ALL CLEAR) key. In this case, all

6. SHADOW ERASER A3 B4 A4 B5

1 2 3

Printing With Various Functions

100% 0sht 1set

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Start platemaking and printing. (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

a See stepes 5 to 8 of “Basic Printmaking” page 32).

Adjusting Plate Darkness

The plate darkness (the level at which black and white are differentiated) can be adjusted in 3 steps. Make the plate more “dark” if the document is light, or “light” if the document is dark.

IMPORTANT

• Set the “Plate Darkness” before making the plate.

• If you adjust the plate darkness, you must repeat the platemaking process before making

prints.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key. Press (SELECT) key several times to show the screen at right.

2.PLATE DARKNESS NORMAL

1 2 3

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (FUNCTION SWITCH) key.

The plate darkness screen appears.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (SELECT) key several times to display the desired plate darkness.

Each time (SELECT) key is pressed, the display of the LCD panel changes as follows. “LIGHT” → “DARK” → “NORMAL” → “LIGHT”

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

2.PLATE DARKNESS DARK

1 2 3

Press (FUNCTION SWITCH) key.

The plate darkness is selected, and the standard screen appears.

Tip

There are two ways to return the darkness to

“NORMAL” as follows.

• Set the darkness to “NORMAL” in the same

procedure.

• Press

(ALL CLEAR) key. In this case, all

settings are reset to standard mode (a page 26).

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

100% 0sht 1set

1 2 3

Batch Printing

You can print the specified number of sets of prints in each set.

■ Batch Printing (

The machine stops after each set of prints.

Document

■ Changing Print Quantity per Document (

This function changes the number of prints made from each document.

Documents

a page 63)

1st set

5 copies x 2 sets

1 1 1

1st document

5 copies x 2 sets

2nd set

3 copies x 4 sets

a page 67)

2nd document

3 copies x 4 sets

3rd set

2 copies x 5 sets

3rd document

2 copies x 5 sets

Printing With Various Functions

Batch Printing

In this mode, each set comprises the specified number of prints and the machine prints the specified number of sets, stopping after each set. You can enter up to 15 groups of the specified number of prints x number of sets.

IMPORTANT

• Select “Batch Printing” after platemaking.

Batch Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 1 to 5 of the sequence described in “Basic Printmaking” (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press display.

(CLEAR) key to clear the number

a page 32).

100%

sht 1set

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to enter the number of prints.

Example: 25

Tip

• If you make a mistake, start over again by press

(CLEAR) key and start from the beginning. When you press number of prints and the number of sets are

cancelled.

(CLEAR) key, both the

Key pad

100%

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

sht 1set

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

The number of prints is set.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

key.

Use the keypad to enter the number of sets.

Example: 3 sets

Tip

• If you make a mistake, start over again by press

(CLEAR) key and start from the beginning. When you press number of prints and the number of sets are

cancelled.

(CLEAR) key, both the

Batch Printing

100%

sht 0set

sht 3set

Printing With Various Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

key.

Repeat steps 2 to 5.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Continue Page

•••

Batch Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(PRINT) key.

The print runs starts from the last-entered set, and stops after the first set of printouts.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Collate by inserting a piece of paper that acts as a marker or by removing the whole set from the machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PRINT) key.

The print run starts.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Repeat steps 8 and 9 until all entered sets have been printed.

IMPORTANT

• (PLATE MAKING) key will not work until all the sets have been printed.

• Press (STOP) key then

(CLEAR) key to abort the print run.

Tip

• When two or more documents are loaded in the ADF, platemaking of the following documents and printing will automatically start after the entire printing is completed.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Batch Printing

Batch Printing (changing print quantity per document)

You can change the number of prints made from each document. You can separate the number of prints for up to 15 documents.

IMPORTANT

• Select “Batch Printing” before starting platemaking.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press display.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

“sht” and “set” begin to flash and the number setting by document mode returns.

(CLEAR) key to clear the number

key.

Printing With Various Functions

100%

sht 1set

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

100%

sht 1set

Continue Page

•••

Batch Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to enter the number of prints.

Example: 25

Tip

• If you make a mistake, start over again by press

(CLEAR) key and start from the beginning. When you press number of prints and the number of sets are

cancelled.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

The number of prints is set.

key.

(CLEAR) key, both the

Key pad

100%

sht 1set

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Use the keypad to enter the number of sets.

Example: 3 sets

Tip

• If you make a mistake, start over again by press

(CLEAR) key and start from the beginning. When you press number of prints and the number of sets are

cancelled.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

(CLEAR) key, both the

100%

sht 0set

100%

sht 3set

Batch Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

key.

Repeat steps 2 to 6.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Proceed with steps 2 and 4 of the sequence described in “Basic Printmaking”

(

a page 32).

IMPORTANT

• When loading document, load the document for the first-entered number of prints and sets

uppermost and the document for the last-entered number of prints and sets at the bottom.

Printing With Various Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PLATE MAKING) key.

Platemaking starts.

IMPORTANT

• Plate making and printing starts from the last-

entered print and set quantities.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

After the first document is printed, platemaking of the next document and printing will automatically start.

Tip

• Using the optional tape cluster you can successively perform the platemaking and collating of prints of multiple documents.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Batch Printing

Dividing Sections with Tape-04

Only the specified number of sets is printed with the specified number of prints taken as one set. Paper tape is inserted when printing of each set is completed. You can enter up to 15 groups of number of prints x number of sets.

IMPORTANT

• The optional tape cluster is required for dividing sections with tape.

• You can select “Batch Printing” after platemaking.

• When the optional tape cluster is installed, you cannot stop printing after each section.

• See the user's manual for Tape 05 for details on the setting procedure.

Tip

• The length of the paper tape separating groups is longer than the paper tape separating sets.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the tape cluster cover.

Available only with Tape Cluster Device

Cover

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Insert the tape while checking for the direction of the tape roll.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Insert the tape while lifting the two levers up.

Levers

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Leave end of tape approximately 1 cm out.

Batch Printing

1cm

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Close the cover.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Tip

• The paper tapes are inserted so that the length of the paper tape separating sets is longer than the paper tape separating groups.

Printing With Various Functions

Chapter 4

Miscellaneous Functions

This chapter describes miscellaneous functions such as the confidential safeguard function,

and the print speed and print position adjustments.

Miscellaneous Functions

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Confidential Safeguard Function ..................................................................... 74

Total Counter Display Function ........................................................................ 75

Print Speed Adjustment Function .................................................................... 76

Printing Position Adjustment Function ........................................................... 77

On-Line Print Function [Available Only With Interface Kit Installed] ............ 78

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Confidential Safeguard Function

The confidential safeguard function, which prevents printing unless platemaking has been completed, is a simple means of prohibiting others from printing sensitive documents.

IMPORTANT

• When the Confidential Safeguard function is ON, printing cannot be performed with

(PRINT) or

• Turning the power OFF does not turn the Confidential Safeguard function OFF.

• Once platemaking is carried out, the Confidential Safeguard function is cleared.

• Platemaking still functions even if the Confidential Safeguard function in ON.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(STOP) key while also pressing

(CLEAR) key.

The machine beeps and the Confidential Safeguard function is activated.

(TEST PRINT) keys. Other operations can be performed as normal.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PRINT) key or

(TEST PRINT) key to check that no print is made.

Tips

• The message “PLEASE PLATE MAKING” is displayed on the LCD panel and the machine will not print when you press

(TEST PRINT) key while the Confidential

Safeguard function is ON.

(PRINT) or

PLEASE PLATE MAKING

• To cancel the Confidential Safeguard function, press

(PLATE MAKING) key to start

platemaking.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Total Counter Display Function

This function displays the total numbers of prints and plates on the LCD panel.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Check that the machine is not printing.

IMPORTANT

• If the machine is printing, press

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

The total print and plate counts are displayed while you press and hold

The number of prints is displayed on the left side and the number of plates on the right side of the LCD panel. Example: In this example, the total number of prints is

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

(STOP) key.

455132, and the total number of plates is 245.

(STOP) key to stop the print run.

P 455132 F 245

Miscellaneous Functions

Print Speed Adjustment Function

The printing speed can be selected from among 60 pages per minute, 80 pages per minute and 120 pages per minute. The default setting when the power is turned ON is about 80 pages per minute.

Tips

• Paper jams may become more frequent and the paper stacking deteriorate at high and low speeds with certain types of paper and with certain images. Satisfactory performance of printing can be obtained by adjusting the printing speed.

• The prints may be slightly lighter at high printing speeds and slightly darker at slow printing speeds.

• You can adjust the printing speed while the machine is printing.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press or keys to adjust the speed.

Press key to decelerate printing. The printing speed indicator lamp moves to the left. Press key to accelerate printing. The printing speed indicator lamp moves to the right.

STD STD

1:1

“PRINTING SPEED ADJUSTMENT key”

Tip

To return to the default setting (about 80 pages per minute), use one of the following two methods:

• Press orr key repeatedly until the center

speed lamp is lit.

• Press (ALL CLEAR) key. In this case, all

settings are reset to standard mode (a page

26). Do not press (ALL CLEAR) key while the machine is printing.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Printing Position Adjustment Function

After platemaking has finished, you can fine-tune the position of the image (in the horizontal direction) within ±10mm.

Tip

• You can adjust the printing position while the machine is printing.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press or “PRINTING POSITION ADJUSTMENT” keys to adjust the printing position.

Pressing and holding or (PRINTING POSITION ADJUSTMENT) keys continuously adjusts the printing position. The printing position indicator lamps change for each approximately 3mm change in the printing position.

●To move the printing position to the left, press key.

The printing position indicator lamp moves to the left.

Paper

Direction of paper movement

STD STD

1:1


●To move the printing position to the right, press key.

The printing position indicator lamp moves to the right.

Paper

Direction of paper movement


Tip

To return to the default settings, use one of the following two methods:

• Press or key repeatedly until the center printing position indicator lamp is lit.

• Press (ALL CLEAR) key. In this case, all settings are reset to standard mode (a page

26). Do not press (ALL CLEAR) key while the machine is printing.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

STD STD

1:1

Miscellaneous Functions

On-Line Print Function

This function allows you to make prints of documents directly from on-line data from personal computers.

IMPORTANT

• PC interface kit is required to connect this machine to a personal computer.

• Please contact your service person on information regarding installation and settings.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Available Only With Interface Kit Installed

Check that the top menu is displayed.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Set the size of the printing paper. (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

a See page 44, “Selecting Printing Paper Size”.)

Use the print command of the computer applications according to the manual.

Platemaking and printing start automatically.

Tip

When platemaking ends and printing starts, you can again use the keys on the control panel.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Chapter 5

Replacing Consumables

This chapter describes how to supply paper, ink pack, and other consumables.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing the Ink Pack ...................................................................................... 80

Replacing the Master Roll ................................................................................. 83

Replacing the Master Ejection Core................................................................. 86

Replacing the Drum Unit ................................................................................... 88

Removing the Drum Unit ............................................................................. 88

Installing the Drum Unit ............................................................................... 90

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing Consumables

Replacing the Ink Pack

The message “EXCHANGE INK” is displayed on the LCD panel when the remaining ink is low. Replace the ink pack using the following procedure.

EXCHANGE INK

IMPORTANT

• Only use ink packs designed for this machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the front cover.

Front cover

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Grasp the lever and pull it toward you.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Lift out the empty ink pack.

Lever

Ink pack

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

“U” groove of holder

Remove the cap from a new ink pack.

IMPORTANT

• Do not leave an ink pack uncapped for longer than necessary.

Replacing the Ink Pack

Ink pack

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Insert the ink pack so that the groove on the lip fits onto the “U” groove of the holder.

Ink pack Ink pack

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Push the ink pack in to the set line on the ink pack.

Set line

Replacing Consumables

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press the back of the holder in with the palm of your hand.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Continue Page

•••

Replacing the Ink Pack

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Close the front cover.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Front cover

Replacing the Master Roll

The message “ROLL-MASTER END” is displayed on the LCD panel when the master roll is used up. Replace the master roll using the following procedure.

IMPORTANT

• Only use a master roll designed for use in this machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Slide the scanner unit.

IMPORTANT

• Do not touch the heat generator of thermal head. Doing so may cause damages, leading to a malfunction of plate making.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press the master cover ralease lever.

The master cover will open up.

Scanner unit

Master cover release lever

ROLL-MASTER END

Replacing Consumables

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Lift out the master roll.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Master cover

Master roll

Continue Page

•••

Replacing the Master Roll

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Take out a new master roll from the bag.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Set the master roll in the direction as shown in the illustration at right.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Pull out the master , and insert the master aligned with the loading line under the guide panel until it contacts the roller.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Close the master cover.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Push the master set lever.

The master is pulled in.

IMPORTANT

• If the master is not pulled in open the master cover, and gently press in as far as possible to set again.

Master cover

Master set lever

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Make sure that the leading edge of the master is protruding from the inner side of the master cover.

Replacing the Master Roll

IMPORTANT

• If the master cannot be set correctly, its leading edge will not be visible. Open the master cover, and set again.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Slide the scanner unit and return it to the original position.

WARNING

•

Do not remove the cover affixed with Warning Label 1.

• Personnel may be injured by the movable cutter inside the machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing Consumables

Replacing the Master Ejection Core

The message “EXCHANGE EJECT ROLL” is displayed on the LCD panel when the master ejection core is full. Remove the master ejection core using the following procedure:

EXCHANGE EJECT ROLL

IMPORTANT

• Use only a master ejection core designed for use in this machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press the plate ejection box release lever to open the master ejection box.

Plate ejection box release lever

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the master ejection box until it stops.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the cover while pressing and holding the plate ejection box lid release lever.

Plate ejection box lid release lever

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing the Master Ejection Core

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Holding the edges of the master ejection core, pull out the core and discard it.

IMPORTANT

• Ink adheres to the master ejection core. Take care to prevent ink from getting onto your clothing.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Insert a new master ejection core.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Gently close the master ejection box cover, pressing it until it locks.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Close the master ejection box, pressing it until it locks.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing Consumables

Replacing the Drum Unit

Removing the Drum Unit

WARNING

• Avoid pressing and damaging the drum surface with fingers etc. It can stain your clothes, and the warp in the drum surface may cause bad prints.

• Always place the drum unit on flat and stable surface. Otherwise, the drum surface may be damaged or warped and may cause bad prints.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press and hold the JOG switch until the drum comes to a stop with a beep.

WARNING

• Do not touch the drum or rollers when you operate the JOG switch.

• Do not put your hands or fingers inside the machine while it is operating. Your hands may be pulled in or nipped.

JOG switch

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Open the front cover toward you.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Lift the drum securing lever toward you and, holding it there, then pull out the drum handle straight toward you until it stops.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Front cover

Drum securing leverDrum handle

Replacing the Drum Unit

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Hold the handle on the far end of the drum, and lift the front end of the drum slightly to pull the drum toward you.

IMPORTANT

• Do not touch the drum surface. Ink may transfer to your clothes.

• Hold the drum level and place it on a flat, solid surface.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Handle for end of drum

Replacing Consumables

Replacing the Drum Unit

Installing the Drum Unit

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Hold the drum level and place the drum guide roller onto the rail in the machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Release the handle at the far end of the drum and press the drum in about 10cm while lifting up the front end slightly.

Roller

Rail

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Hold the drum level and press it in gently until it comes to a stop.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Lift the drum securing lever toward you while

Lever

pressing the drum in.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing the Drum Unit

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Lower the lever.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Close the front cover.

Lever

Front cover

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Replacing Consumables

Chapter 6

Troubleshooting

This chapter describes how to remove paper jams and what to do when error messages are

displayed.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Countermeasures to Troubles........................................................................... 94

Power Does Not Turn ON............................................................................. 94

Platemaking/Printing is Not Possible ........................................................... 94

Error Messages .................................................................................................. 95

Supplying or Changing Paper While Printing .................................................. 98

If Paper Runs Out During Printing ............................................................... 98

Adding Paper While Printing ........................................................................ 98

Changing Paper Selection While Printing .................................................. 100

Paper Jams ....................................................................................................... 102

When “PAPER LEFT JAM” is Displayed (Feed Tray) ................................. 102

When “PAPER RIGHT JAM” is Displayed (Print Tray)................................ 103

When “MASTER EJECT MISS” is Displayed.................................................. 106

When “MASTER SET MISS” is Displayed ...................................................... 109

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Troubleshooting

Countermeasures to Troubles

Power Does Not Turn ON

If the power does not turn ON, check the following.

THE MACHINE DOESN'T TURN ON.

IS POWER PLUG INSERTED?

Insert the power

IS POWER SWITCH ON?

plug securely.

NOYES

Turn the power switch ON.

Please contact your service person.

Platemaking/Printing is Not Possible

If platemaking/printing is not possible, check the following.

IS THERE A MESSAGE DISPLAYED

ON ERROR DISPLAY PANEL?

See "Error Messages" on page 95.

YES

Please contact your service person.

Error Messages

Message Countermeasure

SET PRINT PAPER

EXCHANGE INK

ROLL-MASTER END

EXCHANGE EJECT ROLL

There is no paper in the feed tray. Load the feed tray with printing paper.

There is no ink. Replace the old ink pack with a new one. (a For details, see page 80, “Replacing the Ink Pack”.)

There is no master. Replace the master roll with a new one. (a For details, see page 83, “Replacing the Master Roll”.)

The master ejection core is full. Replace the core with a new one. (a For details, see page 86, “Replacing the Master Ejection Core”.)

DRUM NOT SET

FRONT-COVER OPEN

UP-COVER OPEN

There is no drum. Install a drum in the machine. (a For details, see page 88, “Replacing the Drum Unit”.)

The front cover is open. Close the front cover.

The upper cover is open. Close the upper cover.

Troubleshooting

Error Messages

Message Countermeasure

PAPER LEFT JAM.

PAPER RIGHT JAM.

MASTER EJECT MISS

A paper jam has occurred in the feed tray. Remove the jammed paper. (a For details, see page 102, “When ‘PAPER LEFT JAM’ is displayed (Feed Tray)”.)

A paper jam has occurred on the print tray side. Inspect the print tray side and remove the jammed paper. (a For details, see page 103, “When ‘PAPER RIGHT JAM’ is displayed (Print Tray)”.)

There is an old master on the drum. Remove all the masters from the drum. (a For details, see page 106, “When ‘MAST.EJECT ERROR’ is Displayed”.)

MASTER SET MISS

SCANNER OPEN

ORIGINAL JAMMING

SET KEYCARD

There is an error during master setting. Open the top cover and remove the master that is left in the plate feeder. (a For details, see page 109, “When ‘MASTER SET MISS’ is Displayed”.)

The scanner cover is open. Close the sucanner cover.

The document is jammed on the ADF. Remove the jammed document in accordance with the ADF instruction manual.

Insert the key card into the key card counter. For details, see the Key Card Counter Instruction Manual.

Message Countermeasure

Error Messages

PLEASE PLATE MAKING

--PRINTING--

--SCANNING--

ORIGINAL NOT SET

Cannot print. This message is displayed just after the master setting error or plate ejection error occurs. It is also displayed if you PRINT) key without making a plate while the confidential safeguard function is activated. Make a plate first.

Printing is not complete. Either press (CLEAR) key to clear the counter.

A plate is being made. Wait until it is completed.

There is no document. Set a document.

(PRINT) key to resume printing or press

(PRINT) key or

(TEST

The printer is not ready. Wait a while with the power turned ON. If this message does

--WAIT--

not disappear after several minutes, turn the power OFF and contact servicepersons.

The master is not set correctly. Set the master again.

RESET MASTER.ROLL

Turn the power OFF once and turn the power ON again in

SERVICE CALL

This message blinks alternately with the message “Exxx”.

several seconds. If the same display appears, make a memo of the message “Exxx” and contact servicepersons.

Troubleshooting

Supplying or Changing Paper While Printing

If Paper Runs Out During Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

If paper runs out during printing, printing stops and the feed tray is lowered automatically.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Load paper (

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

Printing resumes.

a See page 34, “Loading and Replacing Paper”.)

(PRINT) key.

SET PRINT PAPER

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Adding Paper While Printing

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press

(STOP) key.

Printing stops.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press the feed tray descend switch continuously. Release the switch when the feed tray reasches the proper height.

The feed tray will stop.

Feed tray descend switch

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Supplying or Changing Paper While Printing

IMPORTANT

• If the sheet is still in the feed roller ring, pull it out and align it with the stack.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Align the stack to be added and place it on top of the existing stack. Press the stack lightly toward the machine.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Press (PRINT) key.

The feed tray will rise automatically and printing will resume.

Tip

• When you press (STOP) key, printing stops.

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

Troubleshooting
