Duplo DocuCutter DC-545 Specifications

HUDSON’S GOOD

March 2002

Finished Documents

(Creased)

Document Finishing

Requirements

Digital Colour

Document

DocuCutter DC-545

Popular Applications:

■ Full Bleed Trimming

■ Brochures

■ Annual Reports

■ Book Covers

■ Catalogues

■ Greeting Cards

■ Photographs

■ Business Cards

■ Flyers

■ Posters

■ More

Perfect Slit, Cut and Crease Finishing Solution

for Digital Colour Printing

S

e

e

D

e

m

o

a

t IP

EX

on Duplo & Xerox Stands

DocuCutter DC-545

A. E. HUDSON — GOOD IMPRESSIONS

• Slit, Cut and Crease (eliminates unsightly toner cracking) in One Pass

• Barcode Reader That Performs Automatic Setting of Slit, Cut, and Crease Position

• Registration Mark Recognition for Image Shift Correction

• Simple Operation and User Friendly

CCD Barcode and Registration
Mark Reader

Speed Up to 12 ppm

Input Paper Size 215.9 mm x 279.4 mm to 320 mm x 457.2 mm

(8.5" x 11" to 12.6" x 18")

Finishing Size Min.: 51 mm x 89 mm (2" x 3.5") - business card size

Output Paper Size 50.80 mm x 88.90 mm to 320.04 mm x 457.20 mm

(2" x 3.5" to 12.6" x 18")

Lead Edge Trim 0.125 mm minimum

Trail Edge Trim 0.125 mm minimum

Side Edge Trim 0.125 mm minimum

Slit Tolerance +/- 0.03" (+/- 0.762 mm)

Paper Weights 21 to 85 lbs (80 to 230 gsm)

Cutting and Creasing Tolerance +/- 0.02" (0.5 mm)

Power Requirements 120/240 V, 50/60 HZ, 2.1 Amp

Machine Dimensions In Storage: 23.2"(W) x 22.2"(D) x 13"(H)

In Use: 51.2"(W) x 22.2"(D) x 11.8"(H)

Weight 56.25 kg (124 lbs)

Additional Features 80 job memories, LCD display, image shift correction

and barcode

Status Indicator Jam, safety cover open and out-of-paper detection

Slitters Two margin and three centre

Optional Auto Feeder

Feeding Method Air suction belt feeder

Feed Capacity 135 mm (5.3")

* Specifications subject to change

Digital colour documents need
professional finishing to prevent the
unattractive white borders and toner
cracking that occurs wherever they are
folded.

The Duplo DocuCutter has the ability to
automatically slit, cut, and crease a
document in one pass, making it the
ideal finishing solution for the short-run
on-demand market. It allows users to
quickly and easily produce professionally
finished, full-bleed documents by simply
loading a sheet!

The DocuCutter DC-545 makes it easy
and economical to produce a wide

variety of applications including: business
cards, greeting cards, invitations,
brochures, catalogues, posters, book
covers, photographs and more.

A barcode reader not only enables the
system to recall pre-programmed jobs, thus
providing a fully automatic slitting, cutting,
and creasing solution, but will also read a
registration mark ensuring precise output
every time. The DC-545 will compensate for
image shift from start to finish.

The easy to use DocuCutter features an
LCD control panel that guides the user
through the set-up of the slit, cut, and
crease positions. And with 80 memory

settings, there is plenty of storage for
commonly used jobs.

In addition, the optional auto feeder will
continuously feed sheets, which provides a
highly productive slitting, cutting, and
creasing solution.

Duplo Corporation is represented in
Australia by A.E. Hudson Pty Ltd.

Three Centre Slitters

Precision Cutter and Dual Margin Slitters

The Finishing Solution
for Printed Output
From Digital Colour
Printers and Copiers

The Finishing Solution
for Printed Output
From Digital Colour
Printers and Copiers

Specifications

A. E. HUDSON — GOOD IMPRESSIONS

The unit has a tare function with a re­zero capability. This feature makes

short work of mixing a specific colour.

For example, to print a job that requires
one kilo of Pantone 186 red:

1. Place a metal mixing plate on the
scales. Press button to re-zero.

2. Dispense 739 grams of warm red.
Press button to re-zero.

3. Dispense 246 grams of rubine red.
Press button to re-zero.

4. Add 15 grams of Pantone black.

5. Remove plate from scales and
thoroughly mix in the usual manner.

Scales for Ink Mixing

Wedderburn Digital Benchtop scales
make mixing PMS colours a breeze.

The Wedderburn Digital scales have an
easy-to-read liquid crystal display and a
weighing platform made of durable,
easy-to-clean, stainless steel.

The scales have a capacity of 5 kg in
increments of one gram.

Wedderburn Digital Scales - 5 kg

$399.00* per unit

Order Code 275-220

QL Blue

Blankets

A new buffed blue, compressible blanket
designed for the quality sheet fed offset
printer with high speed presses, is now
available from Hudson’s.

The Micro-Cel blanket consists of a
blended polymer surface applied to a
micro cellular compressible base. This
results in a blanket offering quick
release, good ink affinity and resilience.

The precision buffed surface provides a
micro-textured printing substrate that
enhances sheet and ink release. The
buffing also permits much greater gauge
control, with thickness tolerances of
+0.01 mm.

The unique fabric construction of the QL
Blue Blanket makes it less susceptible to
smashing and shrinking due to over
tightening or excessive tension.

Compressibility & Recovery

Curves illustrate exceptional resiliency
and stability

QL Blue Blankets are recommended for:

* High Speed Sheet Fed Presses

* Coated & Uncoated Stocks

* Cartons & Boards

* Dry Offset Printing

* Solvent Resistant

Contact Hudson’s for more

information.

ABW-2010*

A General Purpose Blanket
& Press Wash

ABW-2010* is a highly
effective and efficient blanket
wash that is fully water
miscible, forming highly
stable emulsions with up to
50% of water. As a water
mix it will not only remove
ink but will also remove
gums and paper pile caused
by a build up of paper
coating and paper fibre on
the blanket.

• Less greasy than some
other water miscible
washes.

• Non red label flammability
(flash point 64oC).

• Non regulated under UN
regulations, emergency
procedures (EPG) &
packaging groups.

* Bonus until 30 April 2002:
receive a free VAN SON fan

book, TOP 100 PANTONE

COLOURS, with your order

from Hudson’s.

Dynamic Compressibility (mm)

N/p Pressure (N/cm)

0

0

Recovery

0.05 0.10 0.15

50

100

150

QL Blue Micro-Cel

Compression

DRL-2010*

Dry Run Lubricant

DRL-2010* forms a thin
lubricating film over all inking
surfaces throughout the
roller train and guards the
roller ends during running.

It protects rollers from
friction damage and heat
build-up on units running
without ink. Treated rollers
remain ink receptive.

The non-drying film protects
stored rollers from dirt,
moisture and oxidation for
very long periods.

DRL-2010* will not affect
the ink drying, gloss or
colour when used as
directed and cleans up
quickly with normal press
wash.

FBW-2010*

Fast Blanket and Roller
Wash

FBW-2010* is a fast,
efficient and highly
effective blanket and roller
wash designed for use on
all types of machines and
on all blankets and rollers.

It will not cause swelling or
delamination of blankets
and will not damage the
rubber or blankets.

When used regularly,
FBW-2010* will impede
glazing of blankets and
rollers, maintaining them in
a clean, matt condition
aiding their ink transfer
properties.

Reliable Press Chemistry

Hudson’s Catalogue
now on the Internet at

www.hudsons.com.au

PRINTED USING VAN SON QUICKSON SIGNATURE PREMIUM PROCESS PRINTING INKS ON AUSTRALIAN MADE PAPER

Please note all material contained in Hudson’s Good Impressions is subject to copyright and may not be reprinted in whole or in part without the express permission of

A.E. Hudson Pty Ltd. Prices quoted by A.E. Hudson Pty Ltd are trade prices and do not include GST. Limited stock is available on specials. Freight and GST are additional.

BRISBANE: 18 EDMONDSTONE ROAD

BOWEN HILLS QLD 4006
TELEPHONE: [phone]
Email: [e-mail]

FAX: [phone]

SYDNEY: JAMES & EAST STS

LIDCOMBE NSW 2141
TELEPHONE: [phone]
Email: [e-mail]

FAX: [phone]

QLD COUNTRY: [phone]
ADELAIDE: [phone]
PERTH: [phone]
TASMANIA: [phone]

MELBOURNE: 26 CEYLON STREET

NUNAWADING VIC 3131
TELEPHONE: [phone]
Email: [e-mail]

FAX: [phone]

A.B.N. 52 004 432 286

www.hudsons.com.au

Features of the Matte Guide include:

• A section of 147 new designer-inspired colours

• Seven new exciting polymetallic colours

• All 1,114 solid PANTONE® colours printed on brighter
matte coated stocks

• Contains lithographic ink mixing formulas for every
colour including the 147 additional colours

• Icon (::) on colours achievable in CMYK

Plus Colour Systems Update

Included in the package is a CD-ROM with instructions
for using the new colours in desktop applications.

All trademarks noted herein are either the property of Pantone, Inc. or their
respective companies Pantone, Inc. 1997.

Complete

package from

Hudson’s

PACK PRICE

$135.00

*

PAY ONLY

$85.00*

Only while stocks last

Order code 265-8030

PANTONE® Formula Guide Printed

on Matte Coated Stock

with 147 Additional

Colours

Large 1000 mm x 750 mm size with 2
mm scale. Heavier lines each 10 mm.
Black image on 0.175 mm thick polyester
stable film.

Usually $54.95*

Special

$

35.00*

each

Order Code: 275-G100-75-2

RED HOT BONUS

Receive a free Hudson typesize gauge when you place an order
for any special shown on this page (until 30 April 2002).

HUDSON TYPESIZE GAUGE: Made of clear polyester film (0.007")

the gauge is 240 mm x 100 mm. With capital Es from 6 point to 72

point and leading scales for 6, 7, 8, 9, 10, 11, 12 and 14 point

type, making this gauge a must for graphic artists, typographers,

typesetters and anyone concerned with marking-up type.

Trade Price: $6.85* Each Order Code: 275-009

* All prices are plus GST

YOU WILL NEVER BUY A PMS GUIDE CHEAPER!

GREAT

BUY

Letterpress

Quoins

Single

Double

Triple

Buy 6 single for $99.00*

usually $29.50* ea SAVE $78.00*

Single - Order Code: 260-001-S

Double - Order Code: 260-002-S

Triple - Order Code: 260-003-S

Buy 4 double for $99.00*

usually $39.50* ea SAVE $59.00*

Buy 2 triple for $69.00*

usually $45.00* ea SAVE $21.00*

Square-up

Graph on Film

RED HOT SPECIALS
