Instruction Manual
Use and Maintenance
FLOOR WASHER / CARPET
CLEANER
DUPLEX 280i AC
DUPLEX 280i DC
Translation of original instructions
WARNINGS
CAREFULLY READ THE INSTRUCTIONS OF THIS
BOOKLET BEFORE USING THE MACHINE.
See Directive ISO 7000-0434-1691-0790
WARNING: This appliance cannot be used to collect hazardous dusts
DUPLEX 280i
TABLE OF CONTENTS
1.1 Congratulations on having chosen DUPLEX 280i machines. 5
1.2 GENERAL WARNINGS 6
POWER CORD WITH PLUG .................................................................................................................. 6
AVOID ANY CONTACT OF THE POWER CORD WITH BRUSHES ....................................................... 6
OTHER WARNINGS ............................................................................................................................... 6
1.3 DISTINCTIVE FEATURES AND COMPETITIVE ADVANTAGES OF DUPLEX 280i 7
1.4 TIPS FOR CLEANING FLOORS 10
CLEANING CARPETS OR RUGS ......................................................................................................... 10
CLEANING WOOD PARQUET ................................................................................................................... 10
CLEANING ALL TYPES OF FLOORING .............................................................................................. 10
CLEANING HEAVILY DIRTY, HARD OR DINGY FLOORS ................................................................... 10
CLEANING FLOORING WITH WAX CLEANERS ................................................................................. 11
WAX CLEANER “SHINY EFFECT” ....................................................................................................... 11
POLISHING WAXED FLOORS ............................................................................................................. 11
SOAKING/WASHING HEAVILY DIRTY FLOORING ............................................................................. 12
1.5 TRANSPORT 13
1.6 TECHNICAL FEATURES 14
1.7 ASSEMBLING THE HANDLE 16
1.8 LOADING THE WASHING LIQUID 17
1.9 HOW TO USE 18
MACHINE START-UP ....................................................................................................................................... 18
LOADING LITHIUM ION BATTERY ................................................................................................................ 19
BATTERY CHARGER ............................................................................................................................ 20
FITTING THE BATTERY TO THE MACHINE ........................................................................................ 20
SUPPORT TRIPOD AND FOR BRUSH PROTECTION ....................................................................... 22
MOTOR PROTECTOR .......................................................................................................................... 22
1.10 HOW TO WASH FLOORS 23
STAGE 1 ................................................................................................................................................ 23
STAGE 2 ................................................................................................................................................ 23
1.11 Cleaning and maintenance of the brushes 24
BRUSH MAINTENANCE: ...................................................................................................................... 25
BRUSH DEFORMATION ............................................................................................................................ 25
1.12 CLEANING THE MACHINE 26
DUPLEX 280i
1.13 TROUBLESHOOTING TIPS 27
WET STRIPES ON THE SIDES ............................................................................................................ 27
LIQUID FLOWS CONTINUOUSLY ............................................................................................................ 27
THE DIRT IS NOT PICKED UP ............................................................................................................. 27
DOES NOT START UP ......................................................................................................................... 27
DUPLEX 280I AC .................................................................................................................................. 28
BATTERY DUPLEX 280I DC ................................................................................................................. 28
VIBRATION DURING CLEANING ......................................................................................................... 28
1.14 WARRANTY 29
1.15 DISPOSAL AND WASTE SEPARATION 30
DISPOSAL OF LITHIUM ION BATTERIES ............................................................................................... 30
1.16 LITHIUM ION BATTERY (DUPLEX 280i DC) 31
FOREWARD .......................................................................................................................................... 31
PRECAUTIONS ..................................................................................................................................... 31
PARKING THE MACHINE WITH BATTERY .................................................................................................. 31
REPLACING OR DISPOSING OF THE BATTERY ....................................................................................... 31
IMPORTANT SAFETY NOTES ............................................................................................................. 32
BRIEF HISTORY OF LITHIUM ION BATTERIES ..................................................................................... 32
DUPLEX 280i
5
1.1 Congratulations on having chosen DUPLEX 280i machines.
The new DUPLEX 280i floor washing machine has a great performance and is highly efficient.
DUPLEX 280i washes any kind of floor including: wood parquet, carpets and rugs. It sweeps and
disinfects thoroughly, cleaning even the most hard to reach corners by means of its cantilever
brushes.
DUPLEX 280i AC and lithium ion battery DUPLEX 280i DC have an aluminium casing to ensure
each part is protected and has a tight seal against the infiltration of water, dust or other foreign
bodies.
DUPLEX 280i is easy to use and to carry from one place to the other as it weighs only 13 kg,
it takes up very little room and is easy to store.
The handle position can be reversed to allow bi-directional cleaning. The operator can clean
in both directions and perform cleaning and washing from right to left, forward and backward
and vice versa.
DUPLEX 280i's ease of handling and lightness make it pleasant and easy to use.
DUPLEX 280i's construction qualities allow for a long lifespan.
We recommend you to closely follow the instruction for use and maintenance of the
machine.
The original bi-directional handle allows you to
reverse the work position to clean and wash
floors and carpets thoroughly in both directions
and from right to left.
Figure
1.1
DUPLEX 280i
6
1.2 GENERAL WARNINGS
POWER CORD WITH PLUG
• Check the power cord regularly to see if there is any sign of damage:
• If the power cord is damaged, replace it before using the machine.
• Use a cable of the same type used by the Manufacturer, certified according to “ENEC”
European standards
• Cable replacement must be performed by qualified personnel.
AVOID ANY CONTACT OF THE POWER CORD WITH BRUSHES
• Should the power cord get caught under the machine brushes, do not attempt to get it out
with the machine working. Stop operation immediately, remove the plug from the power
socket, check the cord. If damaged, do not try to repair it simply putting a tape around it,
but replace it.
OTHER WARNINGS
• Ensure the machine does not sit on the brushes when in its rest position, but that it is
supported and raised by the tripod (Fig “1.15” - page 25).
If this not the case, the machine weight could warp the brushes.
• Do not pour water or liquids directly onto the machine.
• Unplug the power cord plug from the power socket or battery before any maintenance
intervention.
• Store the machine in a closed and dry place after use.
• The machine is designed and constructed exclusively to clean floors. Any other use is
considered improper.
WARNING
CLEANING AND MAINTENANCE OPERATIONS MUST BE PERFORMED
WITH THE MACHINE DISCONNECTED FROM THE MAINS OR BATTERY.
DUPLEX 280i
7
1.3 DISTINCTIVE FEATURES AND COMPETITIVE ADVANTAGES OF
DUPLEX 280i
The DUPLEX brand name is synonymous with double efficiency and distinguishes a machine
that actually has a dual function thereby providing numerous advantages for the best possible
floor cleaning and hygiene.
• SMART BRUSHES
The unique smart brush system “patented” by DUPLEX allows the machine to reach more
easily into corners and along skirting boards of every surface.
• EASY-TO-DISASSEMBLE BRUSHES
The brushes are inserted with a patented "trigger fitting" which enables them to be removed
and replaced in just three seconds.
• OPTIONAL BRUSHES
They are provided for any type of floor and cleaning operation
• BI-DIRECTIONAL CLEANING SYSTEM
This system allows the work position to be reversed thanks to the bi-directional handle.
(see figure “1.1”, “1.10” and “1.13” ).
• DOUBLE WASHING SYSTEM
Two powerful brushes rotate in opposition at 3.75 mt/s, attacking dirt and trapping it with
their synergistic action and delivering it towards the two conveyor belts.
• DUAL DIRT COLLECTION SYSTEM
The patented conveyor belts which rotate quickly channel the dirt deposited on their surfaces
directly into the recovery tank.
• RECOVERY TANK
Situated conveniently in the middle of the machine and easy to remove. It is equipped with
two “scrapers” made of a special technopolymer, they are easy to replace and are needed
for the final collection of dirt.
DUPLEX 280i
8
• DOUBLE USE SYSTEM
Simultaneous washing and dirt recovery.
Soaking followed by dirt recovery.
• WATER AND DETERGENT TANK
Easy to remove and to refill under a water tap and to empty at the end of cleaning. This
system makes cleaning it easier.
• ADVANCED CONSTRUCTIVE TECHNOLOGIES
Forty years of activity and more than two hundred thousand DUPLEX machines manufactured
and sold worldwide, have allowed our Company to gain considerable experience, improving
our valuable and prestigious know-how.
Today, our know-how allows us to develop highly innovative technologies which find their
application in the design of the most cutting-edge floor cleaners, as happened recently in
the case of the new DUPLEX 280i.
Besides being able to clean perfectly any type of flooring by means of a new operational
concept, the DUPLEX 280i is equipped with a robust structure which can withstand heavy
use even exceeding allowed use limits, or in any case, it can tackle any involuntary distraction
of the user.
It cleans easily every floor including rugs, fabric flooring, carpets, etc. It can easily pick up
fine or coarse dirt, any type of solid dirt (cigarette butts, paper sheets, sand, etc.). It cleans
and removes dirt from the most deep recesses of any type of floor, embossed, studded
rubber flooring, etc.
In designing the DUPLEX 280i, we aimed to create a perfect machine. Each of its components
has been designed to ensure maximum safety and durability, without requiring any maintenance.
To this end a special pressure-diecast light alloy casing has been manufactured to enclose
all electrical parts and most sensitive mechanical gear drive parts in order for them to be
fully protected.
• ELECTRIC MOTOR
This motor has been made perfectly seal-tight by means of rubber seals on each closure
and its external part is treated by an Anodic and Galvanic procedure to make it rustproof.
• EASY-TO-USE AND PERFECT BALANCE
The motor's central position and the tank above give the machine a perfect balance.
The weight distributed equally on the brushes allows an efficient cleaning. It is particularly
easy to handle for whoever uses this machine.
DUPLEX 280i
9
• TRANSPORTABILITY
The DUPLEX 280i AC weighs 13 kg.
The DUPLEX 280i DC plus Lithium Ion battery weighs only 12 kg.
The Duplex 280i can be carried easily given its reduced weight (13 kg max.), allowing anyone
to lift it. Moreover, it moves silently on its two small rubber wheels.
• QUIET OPERATION
Noise level and vibration dBA < 72.8
DUPLEX 280i
10
1.4 TIPS FOR CLEANING FLOORS
CLEANING CARPETS OR RUGS
Fit the yellow brushes (option).
We advise you to cross the washed tracks so that all fibres appear well cleaned taking care not
to wet them too much.
Carry out a few tests before starting to wash.
Use a non-foaming detergent appropriate to clean carpets or rugs.
LITHIUM ION BATTERY DUPLEX 280i DC
The lithium ion battery power decreases slightly when brushes face a
greater friction cleaning and washing fabric flooring.
CLEANING WOOD PARQUET
Fit the yellow brushes (option) or the supplied grey brushes if the parquet is very dirty.
Do not wet the floor too much, and in particular not painted flooring, which absorbs more moisture.
Be careful when cleaning this type of floor. Carry out a few tests before washing the entire
surface.
Use a non-foaming detergent appropriate for parquet flooring.
CLEANING ALL TYPES OF FLOORING
Install the supplied grey brushes.
Use an non-foaming and non-acid all-purpose cleaner (PH max. 9).
CLEANING HEAVILY DIRTY, HARD OR DINGY FLOORS
Fit the black brushes (option).
Use a concentrated non-foaming and non-acid all-purpose cleaner (PH max. 9).
DUPLEX 280i
11
CLEANING FLOORING WITH WAX CLEANERS
Some floors are well suited to be cleaned and treated at the same time with WAX CLEANERS,
such as:
• Florentine terracotta tiles
• Smooth tiles
• Clinker
• Marble
• Granite
• Industrial flooring
• Studded rubber flooring
• Wood flooring
• Old wax-treated flooring and many other.
WAX CLEANER “Shiny effect”
Fit the supplied grey brushes, use any wax cleaner available in shops, mix it with water
(see the instructions on the bottle for the dose). Follow the instructions on paragraph
“1.10 HOW TO WASH FLOORS” (Phase 1 and 2).
When cleaning is complete and the floor is thoroughly dry, wipe again after fitting the
brown polishing brushes.
Doing this you will obtain great results and have the entire surface cleaned to perfection with a
“shiny effect”. Moreover, dirt will be immediately recovered in a simple, quick and convenient way.
POLISHING WAXED FLOORS
Fit the brown brushes (option).
Turn the recovery tank knob to “1” (In this case only the brushes work and the recovery system
is deactivated).
DUPLEX 280i
12
SOAKING/WASHING HEAVILY DIRTY FLOORING
When you need to scrub flooring that has been dirty for a long time and has every sort of spots
and dirt, you are advised to proceed as follows:
1.
Fit the supplied grey brushes for medium dirt or the black brushes (option) for heavy dirt;
2.
Raise the recovery tank turning the knob and set it to 1 (Fig. 1.2). In this setting the recovery
system will not work and the liquid poured onto the floor will require a more emulsified solution,
and therefore, it will allow the detergent to
be more effective (“soaking”).
3.
Press the lever to dispense a large amount
of detergent consisting of product/water,
preferably warm at a temperature of
35/40°C.
4.
Move the machine forward on the entire
wet surface, in all directions or following
precise tracks;
5.
Stop the machine and turn the knob to “0”
to lower the tank and re-activate the dirty
water recovery system.
Figure
1.2
WARNING
Thoroughly clean the machine and brushes after cleaning heavily dirty
floors and before cleaning delicate floors.
Do not use the machine to spread the wax.
IMPORTANT!
Do not products that are: “Static dissipative detergents” as can damage
the brushes and plastic parts of the machine.
DUPLEX 280i
13
1.5 TRANSPORT
DUPLEX 280i can be carried easily from one room to the other. Tilt it to one side and let it move
using the two small rubber wheels (Figure 1.3).
Figure
1.3
DUPLEX 280i
14
1.6 TECHNICAL FEATURES
Built in compliance with EN 30335-2-07-1998-2006/42/EC
DUPLEX 280i AC with power cord
GENERAL DATA:
Lithium ion battery DUPLEX 280i DC
Dimensions: Length - Width - Height mm 330 – 280 – 165
Brush Diameter mm 85
Brush Width mm 224
Tank capacity lt 1.75
Recovery tank capacity lt 1.0
Brushes pressure on flooring gr/cm2 200
Washed track/width mm 224
Theoretical working surface mq/h 200/250
Degree of protection class IP24
Weighted acceleration value m/s2 1.0
Noise level and vibration dBA < 72,8
DUPLEX 280i AC
Voltage Volt. 230 - 50 Hz.
Voltage Volt. 100/120 - 60 Hz
Power Watt 350
Brushes rpm 50 Hz and 60 Hz model rev./'1 780/936
Electrical insulation Class: I°
Unloaded Weight kg 13
Lithium ion battery DUPLEX 280i DC
Voltage Volt DC 36
Power Watt 260
Unloaded weight with lithium ion battery kg 12
Max. autonomy, with new battery
app ro x.
1.0
hours
LITHIUM ION BATTERY
Battery pack with PCB degree of protection
Supplied voltage
Volt.
36
Supplied current
Amp.
7.23
Dimensions Length - Width - Thickness mm 430x85x50
W
eight kg 2.3
SUPPLIED BATTERY CHARGER
Duplex Universal power supply Volt. 100/240
DUPLEX 280i
15
Universal frequency Hz 50/60
DUPLEX 280i
16
THE MACHINE IS REGISTERED
Trademark: DUPLEX INT.
Country: Italy
Universal identification Mod. DUPLEX 280i
Power Watt.
Power supply: Volt. xxx
Frequency: Hz. 50 or 60
Voltage DUPLEX 280i DC Volt. 36
Serial number Serial no. xxxx
Month and year of manufacture: Current month and year
Self-certification marking: CE
Weight Kg.
ELECTRIC MOTOR EQUIPPED WITH:
Original nameplate applied by the manufacturer
MACHINES MADE EXCLUSIVELY IN ITALY
DUPLEX INTERNATIONAL Srl
50058 SIGNA - FIRENZE - Italy - Via Gobetti 19, 21, 23
Tel +39 055 876437 - Fax +39 055 875229
www.duplexitaly.com - infoduplex@duplexitaly.com
DUPLEX 280i
17
F
B
1.7 ASSEMBLING THE HANDLE
Use the supplied hex wrench to assemble the handle as follows:
1.
Place the two conical inserts M into the seats of support C.
2.
Insert chromed rod B into support C already
fitted with the two conical inserts M.
3.
Screw the two screws N and tighten firmly.
4.
Place the two conical inserts M into the seats
L
of handle D.
D
5.
Insert handle D into the chromed rod B already
G
fitted with conical inserts M.
6.
Insert the transparent hose I for the washing
H
liquid into the appropriate coupling on the
machine casing.
7.
Insert tank E into the seat of support A that
M
will snap into place pressing it towards the
chromed rod.
N
8.
Safety handle L (Start&Stop) to immediately
E
switch on/off the machine.
9.
Couple flexible cable F to lever G making it
go through support H.
Only for DUPLEX 280i AC
10.
Fasten the electrical cable starting from handle
A
D up to the casing making it go through the
appropriate seat of support A;
N
M
I
C
Figure
1.4
DUPLEX 280i
18
1.8 LOADING THE WASHING LIQUID
Tank E which contains the washing liquid can be removed easily and quickly as it is snapped
into place on the chromed rod of the handle.
Filling of the tank can be performed as follows:
Mode 1:
1.
Remove the tank and refill under a water
tap.
2.
Add a non-foaming detergent.
3.
Stir the solution and re-insert the tank in
its housing.
Mode 2:
E
1.
Leave the tank assembled on the machine.
2.
Mix the detergent solution.
3.
Pour the liquid into the tank.
(See the instructions on the bottles for the
correct dose)
WARNING!
Do not use unsuitable detergents or
aggressive and acid-based chemicals like:
• Hydrochloric acid
• Trichloroethylene
• Methyl ethyl ketone
• Acetone
• Pure ammonia
• Bleach
• Pure sodium hypochlorite, etc.
Figure
1.5
Static dissipative detergents which can damage the brushes and plastic parts of the machine.
WARNING
The manufacturer declines any liability for damage caused to the machine,
flooring of any kind, including carpets and rugs, deriving from the use of
non conforming detergents or products (see “1.14 WARRANTY” - page 29 )
DUPLEX 280i
19
1.9 HOW TO USE
Turn the recovery tank knob to “0”. This operation allows you to lower the tank with its scrapers
until they touch the rubber conveyor belts for the collection of dirty liquid (Fig. 1.6).
After using the machine, turn the knob to “1” to avoid warping the scrapers and conveyor belts.
We recommend you to lubricate the rubber conveyors frequently using an ordinary silicone oil
spray available in shops.
WARNING
The knob which adjusts the recovery tank position must always be activated
with the machine at a standstill.
Figure
1.6
MACHINE START-UP
DUPLEX 280i AC:
Plug the cable into an earthed socket.
Remove the support tripod before starting up
the machine (Fig. 1.7).
Figure 1.7
DUPLEX 280i
20
L
S
DUPLEX 280i AC
Battery DUPLEX 280i DC;
Press the safety and pre-activation switch (S) on the
handle: a red light will switch on.
Machinestart-uptakesplacetakingholdofthehandleand
keeping pressed the yellow safety lever (L) (Figure 1.8).
LITHIUM ION BATTERY
IMPORTANT PRECAUTION
Switch off the safety and preactivation “S” switch each time the
machine is not used or in case of
interruptions or work breaks, even
short.
The red lit up switch key discharges
the battery, even if it consumes little
power.
Figure 1.8
LOADING LITHIUM ION BATTERY
WARNING
Carefully read information regarding the Lithium Ion battery on paragraph
“1.16 LITHIUM ION BATTERY (DUPLEX 280i DC)”
1.
The battery can be charged when it is out or into its housing on the machine.
2.
Insert the Battery charger plug into the charger socket (X).
3.
When the battery is discharged its LED turns red.
4.
The Battery charger LED turns green when the battery is charged.
5.
The PCB electronic system incorporated into the battery can stop machine operation
immediately when the battery power is low. If the PCB does not trigger, use the machine as
long as you notice a reduction in the rpm and in brush performance, then stop the machine
and do not insist or wait for the machine to stop on its own.
WARNING
DO NOT attempt to re-start the machine if the battery is discharged.
Immediately switch off the pre-activation (S) switch (Fig. 1.8).
DUPLEX 280i
21
BATTERY CHARGER
The lithium ion battery requires a special battery charger supplied with the machine. The charge
lasts about four hours. When the charge is complete you do not need to remove the battery
from the battery charger as it can be left either inserted into the battery or into the power socket
without time limits or problems.
EXTREMELY DANGEROUS!!!
DO NOT USE DIFFERENT BATTERY CHARGERS THE USE OF BATTERY
CHARGERS USED FOR COMMON LEAD BATTERIES, GEL BATTERIES, CAR
TOWING BATTERIES, CAR BATTERIES ETC. CAN SERIOUSLY DAMAGE
THE LITHIUM ION BATTERY OR CAUSE IT TO BURST VIOLENTLY
FITTING THE BA TTERY TO THE MACHINE
• Insert the battery on the handle chromed rod in its seats of support (A).
• Fasten it screwing knob (T)
• Plug the plug (U) into the battery socket (V)
V
W
• If the battery is charged the machine can work.
• W = Safety fuse: 15 amp. mm. 5x20.
• X = Socket to plug the Battery charger.
X
U
T
WARNING R
If the machine does not start in the
rare event of greater friction of the
brushes due to very rough flooring,
carpets or long hair rugs, raise the
machine slightly on one side to make
A
the motor start-up easier.
To gain more stability and control of the machine,
grip the handle and lower it in one of the two
directions before starting up the machine.
Figure
1.9
DUPLEX 280i
20
Move it forward in a straight line following the washed track (see Fig. “1.13” - page 23).
Activate the lever under the handle at short intervals to dispense a minimum quantity of washing
liquid, taking care not to wet too much and/or flood the floor.
Reversing the handle from right to left and vice versa, allows DUPLEX machines to work in
both directions and reach the opposite ends of every room, without requiring the machine to be
moved from its position (Figure 1.10).
Figure 1.10
IMPORTANT
Carry out the following procedure very carefully.
For safety reasons, when the machine is not used or in case of a temporary stop of cleaning
operations, disconnect the power supply to deactivate the machine electric circuits using the
pre-activation switch “S" (Figure “1.8” - page 19), the indicator light will switch off .
DUPLEX 280i
22
MP
SUPPORT TRIPOD AND FOR BRUSH PROTECTION
When you have finished using the machine,
place it on the support tripod to prevent the
brushes from getting deformed if they rest
on the floor.
The tripod is at the end of the machine and
can be put in position raising the machine
slightly on one side and making it turn towards
the floor (fIGURE 1.11).
Figure 1.11
MOTOR PROTECTOR
The “Motor Protector” (MP) (Figure 1.12), is a safety device which stops the machine in case
conditions occur that overload the motor (e.g. foreign
bodies caught in the brushes which can prevent their
rotation, locking of the brushes for failed start-up due
to great friction with the floor, mechanical fault, electric
motor fault, poor supply of power, overheating, etc.).
DUPLEX 280i AC: Disconnect the machine from the
power socket before removing any foreign bodies
caught in the brushes.
Battery DUPLEX 280i DC: Unplug the plug from the
power socket on the lithium ion battery before removing
any foreign bodies caught in the brushes.
After checking and possibly eliminating the cause
which led to motor overload, press the “Motor protector”
(MP) button after about 2 minutes to restore machine
operation.
Only for DUPLEX 281i AC:
PAY ATTENTION TO THE POWER CORD
Figure 1.12
We recommend keeping the power cord away from the brushes when using
the machine to avoid damaging them.
DUPLEX 280i
23
1
st
Stage
2
st
Stage
1.10 HOW TO WASH FLOORS
Stage 1
1.
From the starting position, move forward towards the corner as indicated in the figure.
2.
When you have reached the corner, move back with the machine and keep cleaning the lane
until you reach your starting position.
3.
From the starting position move to the second lane to wash slightly overlapping the area
you have cleaned before.
4.
Repeat this operation until you complete stage 1.
5.
Clean the outer edge on the opposite side of the cleaning area, reversing the machine.
Stage 2
6.
Reverse the machine cleaning direction using the handle.
7.
Repeat the operations described in Stage 1.
Starting position
1
nd
Stage
Starting position
2
nd
Stage
Figure 1.13
DUPLEX 280i
24
1.11 Cleaning and maintenance of the brushes
The DUPLEX 280i allows brushes to
be removed and replaced in just a few
seconds by means of its unique and
patented “Trigger fitting“ (Figere 1.14).
Figure 1.14
This way, you can insert quickly the brushes most suited to the type of cleaning required:
BRUSH colour
Use
YELLOW
Cleaning of carpets, rugs or parquet flooring
GREY
All-purpose for light dirt of all types of flooring
smooth or embossed: tiles, ceramic tiles, marble,
smooth industrial flooring,
Even,
Glassy
Plastic (linoleum, etc.)
BLACK
Cleaning of heavily dirty flooring.
BROWN
Polishing
WARNING
DUPLEX 280i AC:
REMOVE THE PLUG FROM THE POWER SOCKET BEFORE CLEANING
AND REPLACING BRUSHES.
Battery DUPLEX 280i DC:
REMOVE THE PLUG FROM THE POWER SOCKET ON THE BA TTERY
DUPLEX 280i
25
BRUSH MAINTENANCE:
Brushes require little routine maintenance. The high rotation speed during cleaning manages
to centrifugate dirt and keep them clean and efficient at all times.
However, check their state, and if necessary, proceed as follows:
1.
Remove the brushes from the machine;
2.
Immerse them in a container of cold or lukewarm water and let them soak for a few hours;
3.
Stir and rinse well;
4.
Re-fit the brushes in reversed position in relation to the one they had before. This operation
is required to correct the bending of the bristles.
5.
BROWN POLISHING BRUSHES:
Wash the brushes after each use to keep them in good working order. Immerse them in
lukewarm water and diluted degreasing detergent. Stir and rinse. Use them only when
thoroughly dry.
BRUSH DEFORMATION
Wear and storing the machine without lowering the tripod ( 1 Figure 1.15) can cause the brushes
to warp resulting in bouncing and/or vibrations during work stages.
Replace the brushes to prevent damaging the machine.
1
Figure 1.15
DUPLEX 280i
26
1.12 CLEANING THE MACHINE
All mechanical and electrical parts of Duplex 280i machines are sealed and enclosed in a light
alloy casing and do not require maintenance.
The casing is closed by a robust cover with a rubber gasket and fastened with six screws. The
cover prevents dust, water, dirt or the like from entering.
To carry out routine maintenance of the machine external parts, proceed as follows:
1.
DUPLEX 280i AC: disconnect the power cord plug from the socket.
2.
DUPLEX 280i DC: lithium ion battery: Remove the battery.
3.
Remove the recovery tank.
4.
Remove the two guards covering the brushes and wash under running water, using a flat
brush. Thoroughly clean all corners and dry.
5.
Remove the detergent tank on the handle rod, empty it and rinse its interior.
6.
Remove the brushes and clean them (Figure “1.14” - page 24)
7.
Carefully clean the rest of the machine, the upper and lower part including the motor with a
sponge dipped in water. Dry.
8.
Re-fit the removed parts when they are dry.
9.
We recommend you to lubricate the rubber conveyors frequently using an ordinary silicone
oil spray available in shops.
10.
Turn the knob to "1" before storing the machine and as you are reassembling the recovery
tank(Figure “1.6” - page 18).
IMPORTANT!
These simple operations require just a few minutes and are essential to
keep the machine in good working order at all times.
DUPLEX 280i
27
1.13 TROUBLESHOOTING TIPS
WET STRIPES ON THE SIDES
• Excessive liquid dispensed
• Irregular paths are covered failing to follow the instructions on paragraph “1.10 HOW TO
WASH FLOORS” - page 23.
• Recovery tank raised (1) turn the knob to “0” (Figure “1.6” - page 18).
• Recovery tank scrapers dirty or worn. Replace.
Liquid flows continuously
• Valve in the tank remained open because the clamp screw under the handle lever has slid
or moved. Loosen the screw and adjust.
• Foreign bodies inside the valve. Disassemble and clean.
• Valve rubber seal worn. Replace.
The dirt is not picked up
• Recovery tank raised (1) or not properly inserted into its housing.
• Recovery tank with dirty or worn scrapers. Replace scrapers.
• Worn brushes.
• Cleaning liquid not coming out.
Does not start up
• Sometimes the machine does not start given the strong friction of the brushes. Lift slightly
tilting the handle (see “Warning” page 20).
• Scrapers left resting on and stuck to the conveyor belts by the dry residual dirt deposited
from the previous cleaning operation. Turn the knob to (1) to raise the recovery tank and
separate it from the conveyors. Clean and then start up returning the knob to (0).
• “Motor Protector” tripped. Press the (MP) button (page 8) to re-activate it. Reactivation occurs
approx. after 2 minutes.
• Faulty motor.
• “Start&stop” button switch tripped, replace.
DUPLEX 280i
28
DUPLEX 280i AC
• Power cord faulty or plug not correctly inserted into the socket.
• Power cord tripped.
• Voltage too low.
• Start-up capacitor tripped or in short circuit.
Battery DUPLEX 280i DC
• Battery fuse tripped. Remove the fuse cap on the battery and replace with an identical one
of 15 Amp. Do not use fuses with different values.
• If the fuse trips again, search for the fault on the machine.
• Power cord plug not correctly inserted into the battery.
• Discharged battery: re-charge or replace with a fully charged spare battery.
VIBRATION DURING CLEANING
Brushes worn out, replace them. (see paragraph “1.11 Cleaning and maintenance of the brushes”
- page 24)
DUPLEX 280i
29
1.14 WARRANTY
DUPLEX 280i AC with power cord
Lithium ion battery DUPLEX 280i DC
The commercial warranty issued by the seller has a validity of “12 months”
Warranty acknowledgement can be achieved showing a photocopy of the receipt or invoice
along with the machine serial number.
Failure to send this document entails the non-acknowledgement of the warranty.
The warranty does not cover expendable components such as:
• Brushes.
• Scrapers.
• Conveyor belts.
• Power cord.
• Casing connection cable.
• Safety handle and its switch.
• The two large transfer wheels.
• The two small wheels and their casing to which they are fastened.
• Plastic or metal parts damaged out of negligence.
• Lithium ion battery.
• Battery charger.
FORFEITURE OF THE WARRANTY
The warranty will be invalid in the following cases:
• The machine is used for purposes not complying with those for which it has been designed
or is used improperly.
• Failure to observe the indications for use described in the manual.
• The machine gets damaged due to the use of unsuitable detergents or aggressive and
unsuitable chemical products, like strongly acid products: Static dissipative detergents,
Hydrochloric acid, trichloroethylene, methyl ethyl ketone, acetone, pure ammonia, bleach
or pure sodium hypochlorite, etc.
DUPLEX 280i
30
1.15 DISPOSAL AND WASTE SEPARATION
Pursuant to art. 13 of Legislative Decree of 25
th
July 2005, no. 151 “Fulfilment of the Directives
2002/95/EC, 2002/96/EC and 2003/108/EC on the restriction of the use of certain hazardous
substances in electrical and electronic equipment and disposal of their waste”.
The crossed-out bin symbol on the equipment indicates
that at the end of its lifespan, the product, must be collected
separately from other waste.
The user must deliver the DUPLEX 280i, at the end of its
lifespan, to an appropriate collection point for the recycling
of electric and electronic equipment or deliver it back to
the retailer when purchasing a new equivalent machine on
a one-to-one basis.
Correct disposal of the DUPLEX 280i for its recycling and
treatment will help prevent potential negative consequences
for the environment and human health, and will help
recycling the materials of which the machine consists.
Disposal of lithium ion batteries
The DUPLEX 280i DC is equipped with a lithium ion battery inserted in an appropriate fireproof
plastic enclosure, hermetically closed and easy to remove from the machine by simply unscrewing
a knob manually.
The battery, at the end of its lifespan, must be disposed of separately from other waste.
WARNING
Do not burn lithium ion batteries as they could explode or blow up violently.
Carefully collect the batteries for disposal. Avoid them being short-circuited
or their enclosure being compacted or destroyed.
Check and follow all local, regional and national laws on the disposal of
these materials. The user is legally responsible for hazards generated
during the disposal of batteries and preservation of material resources
which enable the recovery of valuable materials.
Abusive disposal of the DUPLEX 280i by the user entails the application
of penalties according to the regulations in force. Professional users
who decide to dispose of the DUPLEX 280i at the end of its lifespan and
purchase a new equivalent machine with the same features can agree upon
the collection of the old DUPLEX 280i and delivery of the new machine.
DUPLEX 280i
31
1.16 LITHIUM ION BATTERY (DUPLEX 280i DC)
FOREWARD
New lithium ion batteries have a higher energy density if compared to conventional batteries.
They are more compact in size and weigh less compared to old lead batteries in their various
variations, lead acid, gel lead, calcium lead and hermetic batteries.
If, on one hand, lead batteries cost less, on the other they are very heavy and require specific
maintenance. They produce hydrogen when recharging (pollutant gas) and contain lead (a
cancer causing and tetragonus agent). They require to be disposed of according to severe
and precise methods. Our choice to use lithium ion batteries to supply the DUPLEX 280i DC
is a major step forward, bearing in mind the future as we are among the first to use a type of
long-range technology, able to activate the first floor cleaner worldwide. The machine is fitted with
two powerful and smart cylindrical brushes along with a patented high performance collection
system of solid and liquid dirt.
As for all other lithium ion batteries used in other devices: computers, mobile phones, vehicles,
towing vehicles, etc. their durability over time is determined by the number of charging cycles,
which sometimes exceeds 2,000 cycles.
Re-charging can take place at any time without requiring them to be fully discharged by means
of their appropriate battery charger. Should they be inadvertently charged using a conventional
battery charger for lead batteries, they will be irreparably damaged.
PRECAUTIONS
The lithium ion battery autonomy can be compromised if it is deposited, used or recharged in
places at temperatures exceeding 40°C. On the other hand, using and storing the battery in a
cold environment will reduce its duration, but in this case it is a fleeting issue as battery capacity
is restored by recharging it.
Exposing the battery to sun rays can damage it irreparably.
PARKING THE MACHINE WITH BATTERY
If the machine is not used for long periods of time and is left parked, the battery might selfdischarge. Therefore, it needs to be recharged every 40 days.
REPLACING OR DISPOSING OF THE BATTERY
At the end of its lifespan, do not burn lithium ion batteries as they could explode or blow
up violently.
Do not dispose of with other waste. Dispose of batteries delivering them to the authorised
collection points.
DUPLEX 280i
32
IMPORTANT SAFETY NOTES
A) Use the supplied lithium ion battery only on the DUPLEX 280i DC.
B) Do not expose to direct sunlight.
C) Keep away from heat sources: radiators, heaters, stoves, mantelpieces, etc.
D) Recharge using the appropriate battery charger for the supplied lithium battery.
E) Do not use a battery charger for lead batteries. Doing this damages the battery, which might
explode or blow up violently endangering people's safety.
F) Do not try to open the battery fireproof plastic enclosure.
G) Do not break or pierce the battery pack: Extremely dangerous!
H) Do not burn: violent explosion or blow up hazard.
I) Do not weld the cables at the ends of the batteries.
J) Do not short circuit positive and negative terminals.
K) Stock and store in a cool and dry place.
L) For their correct disposal, see and follow all local, regional and national laws on the disposal
of these materials. The user is legally responsible for dangers generated during battery
disposal.
BRIEF HISTORY OF LITHIUM ION BATTERIES
Lithium ion batteries take advantage of the high electro-chemical potential of Lithium (compared
to its low overpotential) and their low weight. Other advantages lie in high energy (mass and
volume), long cycle duration and minimum self-discharge. Moreover, using lithium accumulators
you do not run the risk of contaminating the environment as it happens with lead or cadmium
accumulators. Recharge times are short and have no memory effect. Even if they require particular
chargers, their cost prevents them from being widely distributed even if their use is expanding.
Lithium can be found abundantly in nature, even if it never occurs freely because of its high
reactivity. It can be found in small amounts in all igneous rocks and salts from mineral springs.
Starting from the Second World War, the production of lithium has grown considerably by separating
the metal from the other elements of igneous rocks or extracting it from mineral water springs.
Lithium comprises the following minerals: Lepidolite, Spodumene, Petalite and Amblygonite.
However, the discovery of lithium batteries is not recent. Gilbert N. Lewis manufactured the first
lithium ion batteries in 1912, even if they were produced and first launched on the market by
Japanese Company SONY in 1991.
DUPLEX 280i
NOTE
DUPLEX 280i
NOTE
DUPLEX 280i
NOTE
European Mark of conformity
Made in Italy
DUPLEX INTERNATIONAL Srl
50058 SIGNA - FIRENZE - Italy - Via Gobetti 19, 21, 23
Tel +39 055 876437 - Fax +39 055 875229
www.duplexitaly.com - infoduplex@duplexitaly.com
Loading...
