Duolabs Qbox One Quick User Manual

The QBox one carries the CE-Sign and fulfills all requirements from the EU.
Software: Release 1.5.2 on 15-09-2008. Subject to change without prior notification.

Quick User Manual

Digital satellite receiver for free and encrypted Digital Video Broadcasting

(DVB).

Communication-Port

Internal hard disk support.

Two Smartcard Readers

Linux OS

For Full User Manual please refer to www.q-box.tv

www.q-box.tv

Before initial operation on the receiver

Safety instructions

Please read the safety instructions completely and carefully, before using the Q-Box. The Manufacturer
takes no responsibility for damages as a result of incorrect handling of the QBox.

- The safety marking is located on the exterior of the bottom of the apparatus.

- The mains plug shall be installed near the equipment and shall remain readily operable.

- Allow enough space around the QBox for sufficient ventilation.

- Do not cover th e top of

the QBox and allow enoug h space to other devices. The louvers of the devices

must be free at all times to allow sufficient heat transfer from inside the device.

- Nev er put vases or any other liquid filled containers on top of the device. Do not expose th

e device to

dripping or splashing liquids.

- Do not place open flame sources, such as lit candles, on top of the device. -The device may only b

e

operated in moderate climate.

- Do n ot remove the cover. Risk of electric s hock. If it is necessary to open the

device please cont act a

trained professional.

-Do not put any metal things into the slots or ventilation openings.

-The installation of a hard disk is only allowed by skilled personal or your local dealer.

Shut down

- In case your QBox is not in use for a long period of time disconnect the power plug from the power outlet.

- During thunder storm the unit should also be physically disconnected from the power outlet.

Additional safety instruct ions

- (Dis-

)Connecting to a LN B: Turn the QBox off before you connect or disconnect a cable coming from or

going to a LNB.

- Connecting to a TV: Before connecting or disconnecting your QBox to/from a TV please turn it off.

- In case you notice any da mage to the

power cord or power plug immediately disconnect the de vice f rom t he

power outlet.

- In case the device was exposed to humidity immediately disconnect the device from the power outlet.

- In case you notice any ser ious damage to the outer shell of the device

immediately disconnec t the device

from the power outlet.

- Do not expose the QBox to direct sunlight, lightning or rain.

- Grounding: The LNB cable must be grounded. The grounding system must meet SABS 061 requirements.

- Cleaning: Dis connect the mains po

wer cord before cleaning the c over. Use a slightly damp cloth without

cleaning agents.

- Connect the QBox only to suitable sockets. Do not allow overloads to occur.

- Please be careful that the batteries of your remote control are not exposed to heat, sinc

e they might

explode.

Modifications and changes to the QBox lead to loss of warranty if not
performed and documented by skilled personal.

We recommend the installation of a hard disk by your local dealer.
Unskilled installat io n of a hard disk leads to loss of warrant y.

Disposal instructions

The packaging of the QBox only consists of reusable materials. Please recycle if possible.

This symbol on the product or on its packaging indicates that this product must not be disposed of
with your other household waste. Instead, it is your responsibility to dispose of your waste equipment
by handing it over to a designated collection point for the recycling of waste electric al and elec tr onic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human
health and the environment.

For more information about where you can drop off your waste equ ipment for recycling, pleas e
contact your local city office, your household waste disposal service or the shop where you

purchased the product.
Please note that empty batteries and electric waste is not to be put into the regular garbage.

CE Certification

Duolabs S.p.A. declares that this equipment complies to essential requisites and other relevant

provisions of Directives 2006/95/CE (“low voltage”) e 89/336/CE (“electromagnetic compatibility”).

For Wi-Fi sold models.

Duolabs S.p.A. Declares that this equipment complies to essential requisites and other relevant
provisions of Directive 1999/5/CE (“ Radio and Telecommunications Terminal Equipments”). The
declaration of conformity may be required to Duolabs S.p.A., via Baggi 28, 36061 Bassano del

Grappa (VI).
The use of the radio interface may be subjected to local restriction of use. Customers are responsible
for verifying approval for use in their individ

ual countries. Please consult your local spectrum

authority.

http://ec.europa.eu/enterprise/rtte/spectr.htm

Packaging contents Please check the completeness of the box’s contents. Included in box:

Qbox One

Remote Control

Batteries (1,5V Mignon

/ AA / LR6)

Power Supply 12Volts

Power Cord

1 IDE-Cable (already installed inside the device)
1 User manual

Smartcard Readers

USB Port

Satellite Antenna

Input/Output

USB Port

Terrestrial Antenna

Input/Output

Video /Audio

Output

Scart Input & VCR

Output

Power Supply

Ethernet Communication

Serial Communication

Digital Audio Output

Rear View

Reset Button

Power Supply

Input

Front View
