Duke Manufacturing FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120 Part Manual

Flexible Batch Broiler
Domestic Version

MODELS:

Illustrated Parts List

FBB-NO-120
FBB-NC-120
FBB-PO-120
FBB-PC-120

This manual is Copyright © 2006 Duke Manufacturing Company. All rights reserved.

Reproduction without written permission is prohibited. Duke is a registered

trademark of the Duke Manufacturing Company.

Duke Manufacturing Company

2305 N. Broadway

St. Louis, MO 63102

Phone: [phone]

Toll Free: 1-800-735-3853

Fax: [phone]

www.dukemfg.com

IPL - 175990A

Illustrated Parts List for

Flexible Batch Broiler Domestic Version

2

Illustrated Parts List for Flexible Batch Broiler Domestic Version

TABLE OF CONTENTS

FBB COVERS, ACCESS PANELS AND PANS ...................................................................................4

COMPONENTS – TOP, FRONT AND CONTROL SIDE.....................................................................6

COMPONENTS – REAR AND DISHCARGE SIDE ...........................................................................10

STAND COMPONENTS ....................................................................................................................12

3

Illustrated Parts List for

Flexible Batch Broiler Domestic Version

FLEXIBLE BATCH BROILER – DOMESTIC VERSION

MODELS FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120

Location Part Number Description Quantity

1 175300 Front Panel 1

2 175444 Loader 1

3 175430 Loader Tray 1

4 175438 Loader Mounting Bracket 1

5 175429 Door 1

6 175741 Loader Ramp 1

7 175293 Flame Arrestor 1

8 175325 “V” Grease Pan 1

9 175329 Main Grease Pan 1

10 175351 Panel, Lower “J” Burner 1

11 175200 Burner Shield 1

12 175934 Burner, Tube, J Style 1

175865 Burner, Tube, J Style (High Altitude) 1

13 175177 Motor Cover, Conveyor Drive Motor 1

14 175392 Panel, Right Side Upper Lift Off 1

15 175383 Panel, Access Electrical LWB 1

16 175305 Rear Access Panel 1

17 155695 Pan, PHU A/R

18 175353 PHU Pan Shelf 1

19 175778 Discharge Hood 1

20 175358 Discharge Pan 1

21 175357 Side, Grease Pan 1

22 175340 Discharge Chute 1

23 175250 Panel, Access Discharge 1

24 175150 Pivot Ash Scraper 1

25 175226 Impedance Pan (No Optional Catalyst) 1

175480 Catalyst, Optional (NOT SHOWN) 1
175482 Catalyst Guard, Required With Catalyst (NOT SHOWN) 1

26 175221 Body Top 1

4

Illustrated Parts List for Flexible Batch Broiler Domestic Version

16

26 25 15 14

1

42365

21 20 191718 22 23 24

13

12 7 10

Figure: PL-1 Exploded View FBB CoversS, Access Panels and Pans

11

8 9

5

Illustrated Parts List for Flexible Batch Broiler Domestic Version

FLEXIBLE BATCH BROILER – DOMESTIC VERSION

MODELS FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120

Location Part Number Description Quantity

27 175066 Burner, Mounting Bracket 2

28 175780 Burner, Infrared 2

29 175867 Motor, Conveyor Drive 1

30 175176 Mounting Bracket, Conveyor Drive Motor 1

31 175517 Sprocket, B21 × 3/8 Motor 1

32 175550 Light, Cook 1

33 175503 Switch, Main Power 1

34 175536 Igniter 3

35 175086 Shaft Plate, Right Side 2

36 175525 Bushing Block, Conveyor 4

37 175038 Conveyor Shaft, Right Side 1

38 175356 Frame, Control Board Mounting Bezel 1

39 175873 Control Board 1

40 175510 Gasket, Control Bezel 1

41 175538 Ignition Suppression Cable, Lower Ignition Module 1

42 175507 Capacitor, Motor, Conveyor 1

43 175868 Ignition Module, Lower J Burner (NATURAL GAS ONLY) 1

175872 Ignition Module, Lower J Burner (PROPANE ONLY) 1

44 175869 Ignition Module, Upper Burners 1

45 175516 Transformer, 40VA, 120VAC – 24VAC 2

46 165870 Relay, Solid State 2

47 175537 Ignition Suppression Cable, Upper Ignition Module 2

48 175553 Connect Block, 3 Wire 1

49 175531 Valve, Natural Gas Combo 120VAC (Natural Gas Only) 1

175766 Valve, LP-Gas Combo 120VAC (LP Gas Only) 1

50 175540 Brass Fitting – Gas Valve to Burner Supply Tube 2

51 175545 Orifice, Holder, 3/8″ Comp. Straight × Bulkhead 1

52 175734 Orifice, Lower Burner, #31 (Natural Gas) 1

175737 Orifice, Lower Burner, #49 (Propane Gas) 1

53 175511 Gasket, Blower Inlet 1

54 175871 Blower, Dayton 60Hz 115VAC 1

6

Illustrated Parts List for Flexible Batch Broiler Domestic Version

30

27 28 2728

50

34 33 38 39 40 32 34 51

52 48 49

31 35 362937

41 44435453 47 42 45 46

Figure: PL-1 Exploded View Components – Top, Front and Electrical Compartment Side

7

Illustrated Parts List for Flexible Batch Broiler Domestic Version

FLEXIBLE BATCH BROILER – DOMESTIC VERSION

MODELS FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120

Location Part Number Description Quantity

55 175380 Shield, Ignition Cable 2

56 175477 Tubing, Tee to Valve, Kit 1

57 175535 Sensor, IR Burner 2

58 175549 Hose Clamp 2

59 175532 Hose, Blower 1

60 175108 Blower Box Cover 1

61 175476 Tubing – Tee to IR Kit 2

62 175541 Tee, Compression Fitting 1

63 175542 Orifice, Holder IR Burners Orifice, Holder Only, IR Burners 2

(Additional Parts: 175547 3/8″ Sleeve & 175548 3/8″ Nut)

64 175735 Orifice, IR Front Burner #40 (NATURAL GAS) 1

175767 Orifice, IR Front Burner #52 (PROPAGE GAS) 1

65 175736 Orifice, IR Rear Burner #36 (NATURAL GAS) 1

175768 Orifice, IR Rear Burner #51 (PROPAGE GAS) 1

66 175478 Tubing, Lower Burner to Valve, Kit 1

175612 Kit, LP Gas Conversion (NOT SHOWN) 1

8

Illustrated Parts List for Flexible Batch Broiler Domestic Version

64 61 6362 65

60 58

59 55

56

57

66

Figure: PL-1 Exploded View Components – Top, Front and Electrical Compartment Side

9

Illustrated Parts List for Flexible Batch Broiler Domestic Version

FLEXIBLE BATCH BROILER – DOMESTIC VERSION

MODELS FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120

Location Part Number Description Quantity

35 175086 Shaft Plate, Right Side 2

36 175525 Bushing Block, Conveyor 4

67 175534 Sensor, Lower Burner 1

68 175977 Kit, Temperature Probe 1

69 175515 Strain Relief, Power Cord 1

70 175022 Conveyor, Bushing Block Mounting Bracket, Left Side 2

71 175037 Shaft, Discharge Side 1

72 175551 Chain, Drive 1

73 175674 Chain, Cook Conveyor 1

10

35 36

Illustrated Parts List for Flexible Batch Broiler Domestic Version

36 70 71 72 73

68 67 69

Figure: PL-1 Exploded View Components – Rear and Discharge Side

11

Illustrated Parts List for Flexible Batch Broiler Domestic Version

FLEXIBLE BATCH BROILER – DOMESTIC VERSION

MODELS FBB-NO-120, FBB-NC-120, FBB-PO-120, FBB-PC-120

Location Part Number Description Quantity

74 175748 Bracket, Sanitation Pail 1

75 175842 Sanitation Pail, Red 1

76 175461 Weldment, Broiler Stand 1

77 175570 Gas Piping Kit 1

78 175565 U-Bolt 2

79 175563 Casters, Swivel, Non Braking 2

80 175562 Casters, Swivel With Brake 2

81 175485 Tube Burner Cleaning Tool 1

82 175705 Brush, Flame Rod Tube Cleaner 1

83 175701 Flame Rod Tube Cleaner 1

84 0220750 Nut, Acorn 1/4″ × 20-3 4

85 175459 Saddle, U-Bolt 2

86 175618 Label, Re-lighting Instructions 1

12

75 74 76

Illustrated Parts List for Flexible Batch Broiler Domestic Version

78 80

77

84 85

83 82 81

Figure: PL-1 Exploded View Components – Stand

80

79

13
