Page 1
Rear Panel Connectivity
Rear Panel Connectivity
VGA in S-Video Video
Audio in
(R&L)
USBRS-232
AC IN
Security
Lock
Rear IR receiver
VGA out
Audio in/out
(mini-jack)
ImagePro 8780
DLP Projector
• 2500 lumen brightness
• XGA resolution
• 1800:1 contrast ratio
• 3 Watt speaker
• Brilliant color images
• Vertical Keystone Correction
• Control remotely
• Only 7.8 lbs.
• Very low maintenance
8780
Page 2
ImagePro 8780
LCD projector
The ImagePro 8780 is a DLP projector that can be used
in a variety of applications. With a brightness of 2500
lumens the 8780 is great in classrooms and conference
rooms. The 8780 is designed to be reliable and extremely
easy to maintain since it has no filters to service.
This DLP projector has outstanding video and computer
images with the new 6 segment brilliant color wheel.
It has full XGA resolution
(1024 x 768) and can be
easily transported or mounted near the ceiling.
Key features:
• XGA (1024 x 768) resolution
• 2500 ANSI lumens of brightness
• 1800:1 contrast ratio
• 3 Watt speaker
• Brilliant color images
• Vertical Keystone Correction
• Only 7.8lbs
• No filter to service
• Easy lamp replacement through top cover
• Controllable remotely
• Three Year Warranty and One Year Peace of
Mind Service
8780 Projection Table
Image Size 4:3 Throw Distance
Diagonal Width Min. Max.
Inches Inches Feet Feet
40 32 5.0 5.9
60 48 7.6 8.8
100 80 12.6 14.7
150 120 18.9 22.0
200 160 25.2 29.3
Throw Ratio (distance to width), 1.89 2.18
Specifications 8780
Image Element 0.55” DND DLP
Brightness 2500 ANSI lumens
2000 (whisper mode)
Resolution 1024 x 768 pixels (H X V), XGA
Contrast 1800:1
Scanning Frequency fh 15, 31-90 kHz, fv 50-85 Hz
Lens Manual zoom, and Focus
Lens Throw Ratio 1.89 - 2.18 :1 throw distance to
image width
Keystone Correction Digital vertical +/-15 deg.
Aspect Ratio 4:3 native, 16:9 selectable
Computer Compatibility VGA, SVGA, XGA, SXGA,
Video Compatibility
Projection Modes Front/rear/ceiling
Color Reproduction 24 bit (16.7 million)
Lamp 230W
Lamp Life 2000 hours (4000 hours Whisper)
Audio 3W x 1
Throw Distance 40” to 330”
Screen Size, diagonal 23” to 260”
Inputs, Video (1) S-video, Min DIN 4-pin,
Inputs, Computer (1) RGB Signal: D-sub, 15 pin
Outputs Monitor (1) 15 pin, D-sub
Outputs Audio (1) Audio, Stereo mini jack
Outputs, Other 9 pin D-sub Connector, RS232
Security Kensington slot & password select
Fan Level 34dB, (31dB in whisper mode)
Operating Temperature 41 to 95 deg. F (5-35 deg C)
Power AC 110-240V (auto ranging)
Size (WxHxD) 11.8” x 9.6” x 3.5”
Weight 7.8 lbs. (3.5 kg)
Carton Size 17” x 15” x 8”
Shipping Weight 12 lbs.
Accessories Included Remote control, batteries (AA),
Safety FCC-B, UL/CUL, TUV, CB, CE, CCC
Optional Accessories Lamp 456-8780
Specifications subject to change without notice.
NTSC, NTSC 4.43, PAL B/G/H/I/M/N 60
SECAM, HDTV 1080i, 720p, 480/p
(1) Composite video, RCA x 1
(1) Audio, Stereo RCA x 2 (L&R)
(1) Audio, Stereo mini jack
USB Type A
50/60 Hz, 290W (<10W Standby)
power cord, Computer Cable,
CD-ROM, User Manual
Ceiling mount , universal; RPA-U
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, Illinois 60174
Toll-free: 800-676-2485
Fax: 630-584-5156
[email protected]
www.dukcorp.com/av
#080011 ImagePro is a registered trademark of Dukane Corporation
Three (3) year limited warranty on parts and labor in North America,
lamp excluded (for other locations, local warranties apply).Includes
Dukane’s FREE 1 year Peace-of-Mind Loaner Program.
3YR
